丰田普锐斯电机及驱动控制系统解析作为全球最成功的环保车型，丰田普锐斯（PRIUS）早已成为油电混合动力车型中的全球销量冠军，即使在我们的身边，也经常可以见到它们的身影。
目前，在国内生产的丰田普锐斯（PRIUS）是采用丰田第二代混合动力系统，集发动机和电动机组合而成的并行混合动力车（图1）。
丰田第二代混合动力系统(THS-Ⅱ)，可以根据车辆行驶状态，灵活地使用2种动力源，并且弥补2种动力源之间不足之处，从而降低燃油消耗，减少有害气体排放，发挥车辆的最大动力。
由于其THS-Ⅱ电机及驱动系统结构复杂，技术先进，本文将为大家详细介绍该系统的结构及基本原理，以帮助读者更进一步了解THS-Ⅱ系统。
一、THS-Ⅱ电机及驱动控制系统的特点1.在电动机和发电机之间采用AC500V高压电路传输，可以极大地降低动力传输中电能损耗，高效地传输动力。
2.采用大功率电机输出，提高电机的利用率。
当发动机工作效率低时，此系统可以将发动机停机，车辆依靠电机动力行驶。
3.极大地增加了减速和制动过程中的能量回收，提高能量的利用率。
二、THS-Ⅱ电机及驱动系统基本组成1.HV蓄电池：由168个单格镍氢电瓶（1.2V×6个电瓶×28个模块）组成，额定电压DC20 1.6V，安装在车辆后备厢内。
在车辆起步、加速和上坡时，HV蓄电池将电能提供给驱动电机。
2.混合动力变速驱动桥：混合动力变速驱动桥由发电机MG1、驱动电机MG2和行星齿轮组成（图2）。
3.变频器：由增压转换器、逆变整流器、直流转换器、空调变频器组成。
（1）增压转换器：将HV蓄电池DC201.6V电压增压到DC500V（反之从DC500V降压到DC201.6V）。
（2）逆变整流器：将DC500V转换成AC500V，给电动机MG2供电。
反之将AC500V 转换成DC500V，经降压后，给HV蓄电池充电。
（3）直流转换器：将HV蓄电池DC201.6V降为DC12V，为车身电器供电，同时为备用蓄电池充电。
第二部分实训指导书实训一混合动力系统的认识及组成一、实训目的与要求1．了解混合动力系统部件的组成；2．掌握普锐斯混合动力系统各零部件的名称。
二、使用教具、仪器设备和工、量具1．汽车维修常用工、量具若干套。
2．工具车和实训台。
3．混合动力系统实验台架。
三、实训内容和步骤1.普锐斯混合动力的组成部件普锐斯混合动力系统包括：混合动力发动机总成、包括变速器、变频器、HV蓄电池组成。
各部件组成特点如下：发动机：1).发动机型号及参数：序号名称参数序号名称参数1 发动机型号1NZ-FXE2 排量(L) 1.4973 缸径（mm）754 冲程(mm) 84.75 最大马力(Ps) 76 6 最大功率(kW) 57/5000转7 发动机特有技术 单VVT-i 8 最大扭矩(N ·m) 111/4200转1.发动机型号的识别：2． 发动机位置图：3.阿特金森循环代表第1代（如：2代表第2代）。
1NZEF代表一个系列（如：NZ 、GR 、AZ 、AR 、MZ ）。
代表窄气门夹角（G--代表宽气门夹角）。
代表电子喷射。
X代表阿特金森循环。
发动机型号发动机型号刻在进气歧管上4.节气门体普锐斯节气门体采用电子节气门控制，在混合动力系统中油门踏板踩下的行程与节气门开度不一致，这是正常现象。
5.油门踏板普锐斯油门踏板由混合动力系统控制模块控制。
变速器：普锐斯混合动力系统采用内置两个电机的CVT无极变速驱动桥，其中MG1负责发电和发动机的起动机，MG2负责发电和驱动车辆。
MG1、MG2额定电压均为AC 500V。
此外，该变速器还使用了电子控制换档杆，档位切换通过安装在变速器的换档控制执行器控制。
电机MG1 MG2类型同步交流电机同步交流电机功能发电机, 发动机的起动机发电,驱动车轮额定电压V AC 500AC 500最大输出功率kW (PS) / rpm 37.8 (51) / 950050 (68) / 1200 –1540MG2最大输出扭矩N·m (kgf·m) / rpm 45 (4.58) / 0 – 6000400 (40.8) / 0 - 1200最大转速转/分10,000 rpm 6,700 rpm 冷却系统水冷水冷普锐斯变速器解剖图换档杆(瞬时换档)驻车开关换档杆运作驻车开关状态机械驻车锁止机构MG1, MG2组合仪表变速驱动桥档位显示器发动机控制发动机ECU(ECM)HVECU普锐斯换档控制示意图变频器：变频器实物图变频器的作用蓄电池：HV蓄电池:由168个单格镍氢电瓶(1.2V>6个电瓶>28个模块)组成，额定电压DC201.6V，安装在车辆后备厢内。
