桌面云管理系统-说明书目录前言.................................................................................................... 错误！未定义书签。
第一章：软件概述 .. (4)1、软件说明 (4)2、系统结构 (4)3、系统特点 (4)4、主要功能 (4)5、应用领域 (5)6、术语解释 .................................................................................. 错误！未定义书签。
第二章：系统安装说明 . (5)1、系统安装环境 (5)2、网络环境要求 ........................................................................... 错误！未定义书签。
3、安装流程图............................................................................... 错误！未定义书签。
第三章：服务器安装............................................................................. 错误！未定义书签。
1、快速安装指南 ........................................................................... 错误！未定义书签。
2、安装服务器操作系统................................................................. 错误！未定义书签。
3、ADS 服务端安装与配置 ............................................................ 错误！未定义书签。
H64N11普清网络终端使用说明书2.0版本2010年12月目录一、概述 --------------------------------------------------------------------------------------- 2二、系统要求 ----------------------------------------------------------------------------------- 2三、安装网络广告管理系统AdServer2.0 ------------------------------------------------------------2四、操作说明 ------------------------------------------------------------------------------------54.1基本使用方法-------------------------------------------------------------------------------5 4.2遥控器说明 --------------------------------------------------------------------------------74.3终端遥控界面操作---------------------------------------------------------------------------7五、配置管理服务器IP地址 -----------------------------------------------------------------------55.1局域网设置---------------------------------------------------------------------------------55.2广域网设置 --------------------------------------------------------------------------------7六、使用网络终端管理系统 ------------------------------------------------------------------------76.1界面简介 --------------------------------------------------------------------------------- 76.1.1 系统设置 -----------------------------------------------------------------------------86.1.2 启用密码 -----------------------------------------------------------------------------86.1.3 恢复缺省窗口布局----------------------------------------------------------------------8 6.2 终端状态图标 ----------------------------------------------------------------------------- 9 6.3增加、删除、修改组 ----------------------------------------------------------------------- 136.4增加、删除、修改终端 -------------------------------------------------------------------- 13 6.5正常连接状态 ---------------------------------------------------------------------------- 13 6.6查看和管理终端----------------------------------------------------------------------------- 146.6.1 基本信息 ------------------------------------------------------------------------------ 146.6.2 播放模式 ------------------------------------------------------------------------------ 156.6.3 时间音量------------------------------------------------------------------------------- 166.6.4 网络配置------------------------------------------------------------------------------- 176.6.5 存储卡管理----------------------------------------------------------------------------- 176.6.6 本机下载------------------------------------------------------------------------------- 176.6.7 FTP下载------------------------------------------------------------------------------- 176.6.8 插入字幕------------------------------------------------------------------------------- 176.6.9 初始化存储卡--------------------------------------------------------------------------- 176.6.10重启---------------------------------------------------------------------------------- 176.6.11刷新---------------------------------------------------------------------------------- 17七、远程智能升级--------------------------------------------------------------------------------- 20八、故障判断------------------------------------------------------------------------------------- 21一、概述AdServer2.0是针对H64N11网络终端开发的一款功能强大的管理系统,通过该软件可以对网络终端进行管理。
可视化智控平台（专业版）用户手册目录目录 (i)1 产品简介 (1)2 软件安装 (2)3 典型组网 (3)4 软件授权 (5)5 可视化综合管理平台 (7)5.1 平台登录 (7)5.2 配置登录方式 (9)5.3 大屏控制 (14)5.3.1 添加图层 (14)5.3.2 管理场景 (17)5.3.2.1 添加场景 (17)5.3.2.2 场景其他操作 (18)5.3.2.3 场景轮巡 (18)5.3.3 添加OSD (19)5.3.4 设置反控 (22)5.3.5 大屏标注 (22)5.3.6 关闭视频流 (24)5.3.7 多屏控制 (24)5.3.8 开启辅码流 (25)5.4 环境控制 (25)5.5 系统拓扑 (26)5.6 IPC管理 (28)5.6.1 查看监控画面 (28)5.6.2 控制摄像头 (29)5.6.3 信号源轮巡 (30)5.7 预案管理 (33)5.8 多媒体控制 (34)5.9 音频处理器 (37)5.9.1 调整音量 (37)5.9.2 配置音频矩阵 (38)5.10 智能反控 (39)5.10.1 添加反控设备 (39)5.10.2 反控输入源 (41)5.10.3 修改反控设备信息 (41)5.10.4 删除反控设备 (42)5.11 设置 (42)5.11.1 查看系统消息 (42)5.11.2 自定义菜单 (43)5.11.3 退出系统 (44)6 分布式综合管控系统 (45)6.1 配置设备信息 (45)6.1.1 配置分布式设备信息 (45)6.1.2 配置媒体服务器信息 (48)6.1.3 添加音频控制器 (51)6.2 进入系统 (54)6.3 多媒体播控 (54)6.3.1 主界面介绍 (55)6.3.2 添加图层 (56)6.3.3 修改图层属性 (56)6.3.4 删除图层 (57)6.3.5 切换图层媒体 (58)6.3.6 播放节目 (58)6.3.7 播放控制 (58)6.3.8 切换媒体服务器 (58)6.4 大屏控制 (59)6.4.1 主界面介绍 (60)6.4.2 图层操作 (61)6.4.2.1 添加图层 (61)6.4.2.2 调整图层属性 (61)6.4.2.3 删除图层 (62)6.4.2.4 切换图层输入源 (62)6.4.2.5 设置输入源音频 (63)6.4.2.6 配置OSD (64)6.4.3 场景操作 (67)6.4.3.1 加载场景 (67)6.4.3.2 场景轮巡 (67)6.4.4 屏幕控制 (68)6.5 环境控制 (69)6.6 IPC管理 (70)6.6.1 添加IPC摄像头 (70)6.6.2 控制IPC摄像头 (71)6.6.3 编辑IPC摄像头 (72)6.7 音频控制 (72)6.7.1 调整音量 (72)6.7.2 配置音频矩阵 (73)6.8 智能点播 (74)7 导入工程 (77)7.1 导入到IPAD系统 (77)7.2 导入到安卓系统 (79)7.3 导入到WINDOWS系统 (80)8 FAQ (81)8.1 如何查询媒体服务器的IP信息？ (81)8.2 如何获取媒体服务器的端口信息？ (82)1 产品简介可视化智控平台（专业版）是一款针对工程固装展厅、会议室、会议中心、媒体中心、指挥控制中心和智慧城市数据中心等多媒体、音视频和环境控制综合应用场景而设计研发的一款平板应用软件。
协作云终端桌面宝DX70/DX80完全使用手册ce8.3Version 1.5城云视界（杭州）有限公司网站：电话：*************地址：杭州市上城区望江东路332号望江国际3号楼17层版权声明本文档版权归城云视界（杭州）科技有限公司所有，未经城云视界（杭州）科技有限公司书面许可，任何单位或个人不得以任何形式或任何手段复制或传播本文档的一部分或全部内容。
Copyright © 2017 City Cloud Vision (HangZhou) Technology Co., Ltd. All Rights Reserved.This document is proprietary to City Cloud Vision (HangZhou) Technology Co., Ltd., which regards information contained herein as its intellectual property. Under the copyright laws, no part of this document may be copied, translated, or reduced to any electronic medium or machine readable form, in whole or in part, without prior written consent of City Cloud Vision (HangZhou) Technology Co., Ltd.前言在迈向万物互联的时代，视频会议系统为我们提供了随时随地、畅享交流的新办公体验。
作为一种新型的沟通工具，视频会议系统通过逼真的音视频效果为企业带来身临其境的会议感受，帮助各地员工轻松实现“面对面”跨地域的沟通交流，从而节约时间、资源，提高工作效率，让企业在瞬息万变的竞争环境中赢得先机。
目录前言 (3)第一章：软件概述 (4)1、软件说明 (4)2、系统结构 (4)3、系统特点 (4)4、主要功能 (4)5、应用领域 (5)6、术语解释 (5)第二章：系统安装说明 (5)1、系统安装环境 (5)2、网络环境要求 (6)3、安装流程图 (6)第三章：服务器安装 (7)1、快速安装指南 (7)2、安装服务器操作系统 (7)3、ADS 服务端安装与配置 (7)4、ADS服务端启动 (10)第四章：镜像制作与镜像管理 (11)1、快速使用指南 (11)2、安装前的准备 (11)3、镜像制作 (11)3．1、客户端分区规划 (11)3．2、安装操作系统及软件 (11)3．3、安装 ADS 客户端 (11)4、镜像上传 (14)4．1、启动A DS 客户端登陆服务器 (14)4．2、上传系统盘镜像 (15)4．3、上传数据盘镜像 (16)5、多系统镜像制作与上传 (18)第五章：磁盘管理 (19)1、快速使用指南 (19)2、创建磁盘 (19)3、创建操作系统及数据盘 (20)4、多操作系统创建 (22)5、磁盘属性设置『重点』 (23)6、多个磁盘的创建 (25)第七章：分组管理 (26)1、快速使用指 (26)2、创建分组 (27)3、组策略配置说明 (27)3．1、基本设置 (28)3．2、执行软件预注册 (28)3．3、高级设置 (28)3．4、部署方式 (28)4、多个组的创建与配置 (29)5、添加占位机 (30)第七章：智能部署 (31)1、快速使用指南 (31)2、客户端准备 (31)4、部署策略执行 (32)5、客户端执行情况 (34)6、增量部署 (36)7、多任务部署 (37)第八章：系统修改及自动维护 (37)1、快速使用指南 (37)2、镜像修改 (37)3、增量上传 (39)4、客户端自动更新 (41)5、删除镜像 (42)6、镜像重命名 (42)第九章：操作系统管理 (43)1、设置操作系统属性 (43)2、快照管理 (43)3、创建分区 (44)4、设置分区属性 (44)5、复制分区到镜像 (44)6、删除分区 (44)第十章操作系统复制 (44)第十一章：日常管理和维护 (47)1、添加操作系统 (47)2、删除操作系统 (48)3、保护还原方式修改 (49)4、引导选单策略 (49)5、USB 及串并口等设置 (50)6、添加分组 (51)7、删除分组 (52)8、远程终端系统修复 (52)9、导入、导出组内终端信息 (53)10、组内终端管理及终端管理 (53)11、远程停止部署服务 (54)12、强制执行垃圾回收 (55)13、重建数据库索引 (55)14、服务器运行参数设置 (56)第十二章：软件升级 (57)1、服务器端升级 (57)2、客户端升级 (57)前言感谢您在众多管理系统中，选择使用集智（ADS）桌面云管理系统。
本软件是由国人自行独立开发的一套系统。
具备了所有终端集中管理，系统自动部署和维护，部署完成后完全可断网使用、终端多系统引导实现一机多用及本地保护还原策略等。
完全代替了诸如硬盘保护卡和桌面虚拟系统等机房管理工具。
我们将以优质的产品和全新的服务来回报我们的客户。
在您使用本系统之前，请您认真阅读本使用手册。
本使用手册主要介绍“集智（ADS）桌面云管理系统”在集群计算机管理中的意义、使用环境和安装过程以及各管理功能的设置与操作，并配有大量的实例图片。
以便帮助您尽快掌握和熟悉本系统的使用方法，让“集智（ADS）桌面云管理系统”在您的计算机管理工作中发挥最大的作用。
在您使用本系统时，如有任何疑问，请您选择以下方式（010—62195430 ；;）和我们取得联系，我们将第一时间对您的问题进行响应。
同时我们热忱欢迎大家对本系统的改进及本手册中存在的问题和缺点提出建议、批评和指正。
我们将以高度负责的态度对待您所提出的建议和批评，做出修改和完善，以便推出更优秀的产品回报大家。
东方亿盟全体同仁感谢您对我们的支持！第一章：软件概述1、软件说明集智（ADS）桌面云管理系统，利用强大的虚拟技术和PAAS（平台即服务）、SAAS（软件即服务）交付技术，针对大规模计算机的系统自动部署、集中统一管理等而量身定制的一款平台软件；通过一台服务器实现对几千台电脑终端的管理集中化、系统部署智能化、更新维护自动化；构建一个高效、安全、统一的计算机教学实验管控平台。
通过校园网，将分布在不同地点的计算机进行整合统一自动化管理，提高学校计算机的现代化管理水平。
2、系统结构3、系统特点3．1、基于校园网，支持跨网段跨路由，采用组策略，实现校园电脑机房及终端的集中统一管理；3．2、独系统镜像和磁盘分别管理，在虚拟磁盘上进行配置客户端的系统环境、配置及策略设置，快速创建客户端模版。
3．3、系统部署维护的自动化、智能化，在使用中完成部署，无须专属部署时间，提高终端设备使用效率；3．4、部署与维护均系真实写入客户端本地硬盘，减少对网络和服务器的依赖与占用；3．5、直观友好的人机交互界面，简单易学易操作，良好的兼容性、稳定性和扩展性。
4、主要功能分组管理-----将所有终端依据不同类型划分为不同的组，由ADS 服务器进行集中统一管理；磁盘管理-----为各组在服务器上创建一个虚拟磁盘，通过对该磁盘的管理实现所有终端硬盘的集中统一管理；镜像管理------所有的系统镜像均存储在服务器上，根据实际需要配置到相应的磁盘；智能部署------所有客户端开机即可使用，ADS 在后台将自动进行部署或更新。
无须机房停课即可进行部署和维护；断网使用-----ADS 的智能部署是真实的写入客户端本地硬盘，首次部署完成后，便与服务器无关。
日后均可脱离服务器或网络进行使用；多重引导-----可部署多个系统到客户端，真正实现一机多用，以满足不同的教学和办公需要。
保护还原-----客户端具备硬盘保护还原功能；自动修改IP 地址------无须手工逐台修改；远程管理----可远程登陆服务器进行各组或终端的管理；比如：进行系统部署和更新、强制本地系统还原等；远程开关机-----支持网络唤醒和远程关机。
…….5、应用领域集智（ADS）桌面云管理系统主要针对学校及培训单位的公用机房及多媒体教室的系统自动部署和管理领域的应用。
同时，也可应用于企事业单位的公用电脑及办公电脑等不同领域。
6、术语解释镜像：指安装好系统及应用软件的系统分区，或装有其他数据的逻辑分区。
管理机：指安装有ADS 客户端的任何客户端，用于登陆集智（ADS）桌面云管理系统；服务器：指安装有ADS 服务端的机器，可以是普通台式机或专用服务器；客户端：指供使用者使用的电脑。
磁盘：本手册所指磁盘为在服务器上为各组创建的虚拟磁盘。
分组：即硬件配置相同和计划安装的软件一致的一批客户端机器。
系统选单：指客户端开机启动时显示的系统环境名称。
第二章：系统安装说明1、系统安装环境：1．1、服务器最低需求CPU：Intel Pentium IV 2.8 G以上；内存： 2 GB以上；硬盘：300 GB以上, 7200转, SATA接口；网络接口：100Mb/1000Mb；操作系统：可选择任何系统作为ADS服务器系统，建议选用Windows 2003 Server。
1．2 客户端要求CPU：Intel Pentium IV 2.8 G 以上内存：2 GB 以上硬盘：80G 以上；网络接口：100Mb/1000Mb；需支持PXE 网络启动；支持的操作系统：Windows XP、 Windows 2000、Windows 2003 、Windows 7、Linux 等。
2、网络环境要求：标准100MB 或1000MB 以太网网络环境，网络上无其他DHCP Server。
3、安装流程图★重要提示：本系统除了“镜像制作与上传”必需选择一台对应组中的客户端作为管理机执行外，其他的如磁盘管理、分组管理、部署和维护等即可在任何组内选择任何客户端（必须安装有ADS 客户端）作为管理机登陆服务器。
也可直接在服务器上登陆ADS 管理界面进行操作。
不管哪种方式，ADS 系统都不允许服务器和管理机同时登陆或者多个管理机同时登陆ADS 系统。
本手册图片仅供参考，以您所使用版本实际界面为准。
第三章：服务器安装1、快速安装指南：2、安装服务器操作系统（本手册服务器操作系统以Windows 2003 为例）2．1、准备服务器系统：根据用户的需求来选择安装不同的操作系统(Windows 2000 、Windows XP 、Windows 2003,Windows 7)；建议采用Windows 2003 Server，但不要求必须是Server 版操作系统。
2．2、win 2003 系统安装选择集智（ADS）桌面云管理系所在的服务器，按照Windows 系统的一般安装方式安装操作系统，操作系统安装完成后，将系统升级至最新的微软官方发布的操作系统补丁包。
2．3、服务器网络配置:配置好服务器的网关、IP 地址等。
3、ADS 服务端安装与配置服务器的系统安装完成后，在系统中运行集智（ADS）桌面云管理系统（以下简称集智 ADS）光盘中的“SetupMain.exe”,如图3--1：图3--1单击“服务端”按钮开始安装，如图3--2：图3--2单击“下一步”按钮，请选择安装目录：如图3--3图3--3下一步后出现如图3--4：图3-4服务端配置说明“镜像文件路径”----选择存放ADS数据的路径；“服务器管理密码”----设置管理员密码（最大为12 位，支持数字和英文字符，区分大小写）“服务器的IP 地址”-------服务器使用网卡的IP 地址“服务器的守候端口”------使用默认即可；“服务器的部署端口”-使用默认即可；“接收部署的接收端口”---使用默认即可；“默认包MTU 尺寸设置”---使用默认即可；“PXE 默认MTU 尺寸设置”---使用默认即可；“默认部署数据包MTU 尺寸设置”---一般使用默认即可；“服务器缓冲池”---使用默认即可；“代理机缓冲池”---使用默认即可；接着单击“确定”按钮，会弹出日志窗口出现如下图3-5日志窗口中显示“部署服务器开启成功”，此时服务器安装完毕。
4、ADS 服务端启动重新启动服务器后，ADS 服务端将自动启动。
在系统中的计算机管理服务列表中查看集智ADS 服务“BSSvr ”是否已启动。
如下图3--6图3-6单击“开始”→“程序”→“集智 ADS 桌面云管理系统”，将会看到服务器安装程序的两个选项， 如图 3-7:★特别提示：图 3-71、安装时，切记一定要将本软件所带的加密狗插入服务器 USB 接口，蓝灯亮代表加密狗开始工作。
