普鲁狮智能锁介绍

Philips 7000 seriesFacial recognition smartlock3D face unlockUltrasonic sensing wake-upHidden fingerprint sensorWi-Fi connectionDDL702NAGBWEnjoy touchless unlock experienceWith 3D face unlockPhilips DDL702-8HWS brings you a new and convenient door opening experience byemploying the accurate and efficient 3D facial recognition technology, with its falseacceptance rate (FAR)=0.0001%*, that allows you to open the door by face sSmart life lock with excellence•The quicker way to unlock•With power-saving smart detection•Allow easy connection with built-in Wi-Fi moduleUpgraded smart chip enhances home security•Avoid technical lock-picking for more than 270 mins•Provide further security•Allow easy unlocking with one gripEasy life doesn't stop here•Eliminate the hassle of manually locking the door•The door will open when the hand is detectedHighlights3D facial recognitionPhilips DDL702-8HWS comes with a dual camera that simulates human eye imaging to obtain dynamic three-dimensional data of objects and creates 3D images of the user's face. It can effectively recognize not just people in pictures or videos but also people wearing makeup, which offers you the zero-operation unlocking experience.Ultrasonic sensing wake-upWhen a target approaches and stops in front of the lock, the equipped ultrasonic sensor module will quickly calculate the wavesreflected from the target. If it detects a human movement, facial recognition will start to work. Test data shows the powerconsumption of the ultrasonic sensor module is only 10% of the traditional infrared sensor module, which is highly energy-efficient and guarantees the long-lasting battery life of DDL702-8HWS.Wi-Fi connection A built-in Wi-Fi module allows easy access to the internet. You can check the smart lock access records and PIN code information via the Philips EasyKey App anywhere. Remote distribution of a temporary PIN code makes your home accessible to relatives and friends even if you are not at home.Hidden fingerprint sensor With a hidden design of the fingerprint sensor on the inside of the handle, Philips DDL702-8HWS could effectively protect the sensor from malicious destruction and extend its lifetime. Once you hold the handle, yourfingertip will naturally fall on the sensor. Upon a successful authentification, you can push the handle to unlock the door.Dual verificationIn the dual verification mode, you could open the door with any two verification methods (facial recognition, fingerprint, and PIN code), which provides double protection for home security.C-grade lock cylinderThe lock cylinder is the key component that controls the opening of the lock. The Philips DDL702-8HWS employs multiple anti-theft technologies with a unique design of pin tumbler and vane structure. As the time for avoiding technical lock-picking is more than 270 mins, plus the hidden lock cylinder design, the security level of the lock has been further enhanced.Indoor infrared sensor unlockWith a touch sensor and an infrared sensor on the handle, the door could be open much simpler. Once the hand touches the touch sensor and the infrared sensor detects the obstruction, the lock will open.Fully automatic mortisePhilips DDL702-8HWS utilizes fully automatic mortise. Without the need for any extra action, the deadbolt will spontaneously pop out after you close the door. If the door is not locked fitly, it will trigger an alert to remind you of the door lock status.Issue date 2023-11-29 Version: 1.0.1EAN: 69 71318 50302 3© 2023 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsDesign & Appearance•Color: Obsidian black•Handle: Push-pull handle•Fingerprint Sensor: SemiconductorAccess Solution•Fingerprint•Password/PIN Code•Mechanical Key•Face UnlockLock Capacity•Master PIN Code: 1•User PIN Code: Up to 20•One-time PIN Code: 1Power Specification•Time of Use: 6 months*•Maximum Batteries Capacity: 8 batteries •Emergency Power Supply: 5V power bankEasy Operation•Indicator: Door locks status prompt, Low batteryprompt, Mute status prompt, Outside forced lockprompt, System locking prompt•Voice Guide: Human voice guideSmart Lock Functions•Mortise: C grade lock cylinder•Locking Function: Indoor deadlock, System locking•Safety Function: Dual verification, Fake PIN code,Outside forced lock function•Alarm Function: Abnormal bolt alarmMode•Operationg Mode: Auto mode, Manual modeInstallation•Door Thickness: 38-60 mm, 60-90 mm, 90-120mm, Other range*•Door Opening Direction: Left inward opening, Leftoutward opening, Right inward opening, Rightoutward oepning•Door Type: Antitheft door, Copper door,Wooden door*May be less depending on the actual usage*The effect of the digital keypad showed in the photos of this productmay be inconsistent with the actual display effect. Please be subjectto the digital keypad displaying status under the actual usagescenarios.*Other door thickness range: If the thickness of the door is out of thementioned range, please contact our local dealers or consumer carecenter.。

德国大熊智能锁说明书
1、进入管理模式：打开智能锁的电池盖，然后按下密码键，再按
下【#】键，进入管理模式。

2、设置管理员密码：在管理模式中，输入管理员密码（默认为
123456），然后按下【#】键确认，进入设置用户密码界面。

输入新密码，按下【#】键确认，进入设置管理密码界面。

再次输入新密码，按下【#】键确认，即完成管理员密码的设置。

3、添加用户：在管理模式中，按下【*】键，进入添加用户界面。

输入用户密码（即步骤2中设置的管理员密码），然后按下【#】键确认，进入添加用户信息界面。

输入用户的姓名、性别、生日、编号等信息，然后按下【#】键确认，完成用户的添加操作。

4、删除用户：在管理模式中，按下【-】键，进入删除用户界面。

输入用户密码（即步骤2中设置的管理员密码），然后按下【#】键确认，进入删除用户信息界面。

选择要删除的用户，然后按下【#】键确认，完成用户的删除操作。

5、修改密码：在管理模式中，按下【0】键，进入修改密码界面。

输入当前密码，然后输入新密码，按下【#】键确认，即完成密码的修改操作。

6、锁定和解锁：在管理模式中，按下【#】键，进入锁定和解锁界
面。

按下【0】键，进入锁定模式，输入管理员密码（默认为123456），然后按下【#】键确认。

如果要解锁，请再次按下【0】键，输入管理员密码（默认为123456），然后按下【#】键确认。

7、关闭智能锁：在管理模式中，按下【*】键，进入关闭智能锁界
面。

输入管理员密码（默认为123456），然后按下【#】键确认，即可关闭智能锁。

亲爱的用户：感谢您购买普罗巴克电子门锁！在使用本产品前，请您务必仔细阅读使用说明书，并请妥善保管。

您能成为我们的用户，是我们莫大的荣幸。

为了使您尽快掌握普罗巴克电子门锁的使用方法，我们特别为您编写了说明书。

我们对产品说明书的编排力求全面而又简洁。

从中您可以获得有关电子门锁的安装步骤及基本使用方法等方面的一些知识。

我们强烈建议您在使用本产品之前，务必先仔细阅读，这会有助于您更好地使用电子门锁。

如果您未按说明书的要求操作电子门锁而由此引起的任何损失，根据相关规定普罗巴克科技股份有限公司将不承担责任。

使用说明书仅适用于书中所介绍的普罗巴克电子门锁同型号产品的使用和使用条件及环境要求的说明，不具体表明产品软硬件的实际配置和界面，实际配置请以您所购买的产品及装箱清单为准。

本说明书不一定能适用于其它型号和配置的普罗巴克电子门锁，更不一定适用于其它品牌的产品。

我们已经尽我们最大的努力尽量避免人为的失误，以确保说明书中所提供的信息是正确可靠的，但我们不能完全保证：不会有在印刷之前未曾发现或检查出的差错，以及那些我们无法控制的印刷、装订、分发等环节的疏漏，请您多加包涵！有时，我们为了提高部件及整机的性能和可靠性，可能会对产品的硬件或软件配置作了一些小调整，这样有可能会导致产品的实际情况与说明书有某些不一致的地方，但这不会实质性地影响您对产品的使用，请您能够谅解。

○c版权所有普罗巴克。

保留所有权利。

目 录1产品简介 (6)1.1产品图 (6)1.1.1外观图 (6)1.1.2尺寸图 (7)1.2产品特点 (7)1.3适用范围 (7)1.4开门方向 (8)1.5技术参数 (9)2操作使用 (10)2.1基本功能 (10)2.1.1开门功能 (10)2.1.2反锁功能 (10)2.1.3常开功能 (10)2.1.4警示功能 (10)（1）斜舌报警 (10)（2）低压报警 (10)（3）防拆报警 (11)（4）伪密码报警 (11)2.2操作与管理 (11)2.2.1键盘操作方法 (11)（1）按键图 (11)（2）输入密码编号方法 (11)（3）输入感应卡编号方法 (11)（4）输入密码方法 (12)（5）数字键功能 (12)2.2.2管理密码、感应卡 (12)2.2.3密码、感应卡权限 (14)2.2.4开门方法 (14)2.2.5使用应急电源 (15)2.2.6安装电池 (15)3安装与调试 (16)3.1装配图 (16)3.2安装步骤 (17)3.2.1第1步 门板开孔 (17)3.2.2第2步 门扣盒开孔 (17)3.2.3第3步 安装 (18)3.3安装注意事项 (19)3.4调试 (19)4维护及保养 (20)4.1日常维护及保养 (20)4.2常见问题排除 (20)5售后服务 (22)5.1保修原则 (22)5.2装箱清单 (22)5.3安装工具一览表 (23)重要提示1 指纹锁作为高科技产品，安装的好坏直接影响到门锁的正常操作及使用寿命，建议您聘请对锁具有相当经验的师傅进行安装，并根据产品附件中门板开孔图样板进行开孔，凿支承窝，确认所开凿的孔准确无误，然后严格按照产品说明书中的步聚进行操作，如果安装后发现锁有任何异常，请及时和当地的经销商或本公司的售后服务部门联系，以便快速解决问题。

2
⼆、如何开通微信提醒
4
1. 点击“开通提醒”进⼊设置⻚⾯，如未登录，请先登录；“开通提醒”，如下图即为开通成功；
.当智能锁发⽣开锁或远程开锁等事件时，微信实时提醒。

2 . 远程开锁操作
远程开锁需在锁上按⻔铃键发出请求，“客⼈请求，主⼈开锁”，⽤收到开锁请求，或点击播放进视频对讲，或直接输⼊安全密码开锁
五、如何备注⻔锁⽤⼾
. 进⼊⻔锁界⾯，点击右上⻆“更多−⽤⼾列表”，进⼊⽤⼾列表界
⾯，如下图；
．点击⽤⼾，直接备注⽤⼾名称如下图。

3. ⽤⼾备注好后，就清楚地知道是谁开了锁，关⼼家⼈。

四、如何分享设备
侧边栏，选择“家庭管理”−点击
输⼊要添加的⽤⼾⼿机号码和称谓。

注意该
⽤⼾必须提前关注此公众号并注册。

6。

Philips 6000 seriesPush pull smart door lockIntuitive push-pull useSystem wake-up by manual touchManual Locking FunctionDDL161LEFG0Trend leading one-step door openingYour new home derves a new lockPhilips 6100 series push-pull door lock is designed compact and stylish, perfect for youngpeople. With any of the 6 unlocking solutions, you can open the door in one step. Now,forget the keys and embrace an affordable smart new life.Extraordinary design brings outstanding experience•IML brushed finishing: Smooth and wearable as newEasy life doesn't stop there•Patented full auto mortise: Unlock and open at one go•Auto locking: Enjoy the reassurance after closing the door•Intuitive fingerprinting: Unlock swiftly at one goMultiple protection in one for overall home safety•Dual verification unlocking: Security is never forgotten•Fake PIN code: Protect your password security in real time•Outside forced lock: Instant alarm upon inside unlocking•Safe handle: No more safety risks, be reassured while away•C grade lock cylinder: Higher reliability and securityHighlightsAuto locking functionPhilips 6100 series push-pull smart door lock employs full automatic mortise. Without the need for any extra action, the deadbolt will spontaneously pop out after you close the door. If the door is not locked properly, the mortise will give an alarm to remind you of the door lock status.Dual verification unlockingIn dual verification mode, you can use a combination of any two factors (fingerprint, password and card) as the unlocking solution to ensure doubled security for your home.Fake PIN codePhilips 6100 series push-pull smart door lock comes with the feature of Fake PIN Code technology which allows you to enter random number combinations to successfully getidentified as long as there is consecutive input of the real password. This feature caneffectively prevent peeping and safeguard your real password.IML brushed finishing The IML brushed surface has the hardness higher than 2H. Besides, it's waterproof, moisture proof and can keep fingerprint residue out.Intuitive fingerprintingThe fingerprint sensor is integrated in the push-pull handle so that when you hold the handle, your finger will naturally fall on the snesor. You can simply reach out andintuitively touch the sensor, then push to open after a successful fingerprint verification. The one-step unlocking feature will definately bring you a fast and convenient door opening experience.One-key outside forced lockBefore leaving home, you can touch theoutside forced lock key to enable the function.In this mode, opening the door from inside the room will trigger an alarm. This feature can effectively warn you of security risks and upgrade the level of home security.Patented full auto mortiseThe upgraded full automatic mortise makes it possible for instant unlocking right after a successful verification. Once you arerecognized, you can directly push or pull the handle to open the door, which greatlysimplifies the use of your door lock and brings you a fast and convenient in and out experience.Safe handle switchYou can enable the safe handle function before you leave home. After the door is locked, the indoor handle will be fixed to ensure that nobody could open the door by pushing the indoor handle. This feature can effectively prevents unlocking from indoor, thuseliminating security risks and improves anti-theft performance.Issue date 2023-11-28 Version: 1.2.1EAN: 69 71318 50060 2© 2023 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsDesign & Appearance•Color: Champagne gold•Main Material: Zinc alloy•Surface Processing: Electroplating •Fingerprint Sensor: Semiconductor •Emergency Escape Design: Indoor fast opening mortise•Ergonomic Design: Push-pull handle design Access Solution•Fingerprint•Password/PIN Code•Card/Key Tag•Mechanical KeyLock Capacity•Fingerprint: Up to 100•Card/Key Tag: Up to 100•Master PIN Code: 1•User PIN Code: Up to 10•One-time PIN Code: 1Power Specification•Power Supply: 4 AA batteries•Battery Type: Alkaline Batteries•Time of Use: 8 months*•Maximum Batteries Capacity: 8 batteries •Emergency Power Supply: 5V power bank •Working Voltage: 4.5-6VEasy Operation•Indicator: Door locks status prompt, Low battery prompt, Mute status prompt, Outside forced lock prompt, System locking prompt•Voice Guide: Human voice guide Smart Lock Functions•Mortise: Full auto mortise, Super B-class lockcylinder•Locking Function: Electronic deadlock, Systemlocking•Safety Function: Dual verification, Fake PIN code,Outside forced lock function, Safe handle funtion•Alarm Function: Anti-dismantle alarm, Anti-pryingalarm, Outside forced lock alarmMode•Operationg Mode: Auto mode, Manual mode•System Setup Mode: Dual verification mode,Normal modeInstallation•Door Thickness: 38-60 mm, 60-90 mm, 90-120mm, Other range*•Door Opening Direction: Left inward opening, Leftoutward opening, Right inward opening, Rightoutward oepning•Door Type: Antitheft door, Copper door,Wooden doorAccessory Parts•Accessorial Battery: 4 AA alkaline batteries•Mechanical Key: 2 keys•Smart Key Tag: 2 cards•Installation Accessories•Mortise•Mounting Plate•Drilling Template•Certificate•Cleaning Pad•User Manual•Warranty Card•Quick Start Guide*May be less depending on the actual usage.*Please contact our service agents or authorized dealers for otherdoor range.。

Philips 1000 seriesVisor de puerta inteligenteamplioDetección del cuerpo con elsensor PIRMonitoreo remoto inteligenteInterconexión con cerradurainteligenteDDA131FCWNuevo horizonte visualSeguridad visible, al alcance de su manoLa lente ultra gran angular de 170° con función de visión nocturna por infrarrojos con cancelación deruido y la detección del cuerpo humano de 24 horas de la IA permiten ver lo que sucede delante desu puerta en cualquier momento y en cualquier lugar, lo que hace que su hogar sea mucho más seguro.La visión nocturna HD hace que la seguridad sea visible•La lente de 170° y la pantalla HD de 1080P ofrecen una mejor visión•Llamada de audio bidireccional: comuníquese en tiempo real y en todas partes•Pantalla táctil HD de 5 pulgadas: manejo simple para toda la familiaUn chip inteligente permite almacenar más información•Procesador de cuatro núcleos ARM: asegúrese de contar con un sistema estable•Detección de movimiento humano de la IA:La vida inteligente nunca se detiene aquí•Estructura de metal intensivo: con alarma antiapalancamiento•Almacenamiento local y en la nube: permite ver los registros a través de la aplicación encualquier momento•El soporte magnético permite desmontar y cargar fácilmente•Batería de litio grande: hasta 90 días de duración•Enlace con el bloqueo de puerta inteligente: para garantizar una mayor seguridadLente de 170° y pantalla HD Cuenta con una lente de 170° de nivel de monitoreo, el visor de puerta inteligente puede absorber un alto volumen de luz, junto con cuatro luces infrarrojas brillantes, ofrece una mejor visión nocturna, incluso en entornos que tienen poca iluminación.Llamada de audio bidireccionalCuando toque el timbre o presione el botón de llamada en la pantalla, puede iniciar la llamada de audio en tiempo real con elmicrófono y el altavoz integrados. Le permite disfrutar de una experiencia de llamada perfecta.Pantalla táctil HD de 5 pulgadasLa pantalla con tecnología IPS multitáctil HD de 5 pulgadas cuenta con gafas curvas delaminación completa 2.5D, lo que hace que todo luzca fabuloso. El diseño interactivo es simple de manejar para los niños y ancianos.Procesador de cuatro núcleos ARMSe incorpora el procesador de cuatro núcleos ARM, el producto muestra un rendimiento sólido con un menor consumo de energía, que ejecuta varias tareas con mayor facilidad y hace que el sistema de control de alertas de la puerta sea más rápido y estable.Detección de movimiento humano de laIAEquipado con un sensor infrarrojo PIR, cuando alguien aparece en un rango de tres metros hacia el exterior de la puerta, el visor de puerta inteligente realizará la identificación a través del algoritmo de detección de cuerpo humano de la IA y capturará instantáneamente una foto o un video. Al mismo tiempo, envíanotificaciones a la aplicación móvil a través del servidor de cifrado en la nube para monitorear la situación en la puerta.Estructura de metal intensivoCuenta con el diseño de estructura metálica robusta y el sensor integradoantiapalancamiento que, cuando el visor de puerta inteligente reconoce la dinámica anormal y se desconecta de Internet, elproducto activará una alarma para advertir a los extraños y a la familia, luego, recibiránotificaciones automáticas en tiempo real en la aplicación móvil.Almacenamiento local y en la nubeEl almacenamiento local 4G en la nube podría satisfacer sus necesidades diarias, ya que puede guardar los registros incluso sin conexión a Internet. Cualquier foto o video cifrado que se suba al servidor de la nube se puede guardar durante 3 días y puede ver los registros a través de la aplicación Philips en cualquier momento.El soporte magnéticoSimplemente utilice los cuatro imanesintegrados para instalar el producto y retirar la pantalla a fin de desmontar el producto. Con el cable reforzado, el producto podría ser muy duradero.Fecha de publicación 2023-11-29Versión: 3.1.1EAN: 69 71318 50230 9© 2023 Koninklijke Philips N.V.Todos los derechos reservados.Las especificaciones quedan sujetas a modificaciones sin previo aviso. Las marcas comerciales son propiedad de Koninklijke Philips N.V. o sus respectivos titulares. Diseño y apariencia •Color: Cobre rojo Función extendida •Módulo IoT:Wi-Fi Piezas de accesorios •Adaptador de corriente •Soporte magnético •Manual del usuario •Tarjeta de garantía。

UIOT超级智能锁说明书温馨提醒：1.智能锁配套的机械钥匙，作为紧急开锁方式，切记请勿放于室内，可存放于非室内的安全场所，以备紧急状况下使用（如自家车内或办公室内）。

2.产品安装视频、设置视频，请关注公司微信公众号或者拨打服务热线。

3.产品规格参数表如下（以下数据以实验室测试为准）：一、产品概述1.产品示意图2.产品功能配置二、系统功能与介绍1.初始状态1.1初始状态下管理员密码为“123456”；1.2初始状态需通过管理员密码，进入系统菜单增加用户才可正常开门。

注：“123456”为出厂默认的管理员密码，当注册管理员用户后，该密码会自动失效，下次进入系统菜单需要验证已经注册的管理员指纹或密码。

2.操作概述◆系统菜单：唤醒状态下按“*#”号键后可开始验证管理员用户，并进入系统菜单,支持指纹/密码验证，不支持刷卡进入系统菜单----管理员用户。

◆开门：直接刷卡/输入密码/指纹正常开门，不进入系统菜单----管理员/普通用户。

◆系统导航键：系统将播报数字对应的语音内容，通过选定数字来进入对应功能设置。

◆门铃键：在系统主界面按“门铃符号按键”触发门铃。

3.开锁用户管理与信息概述3.1用户信息包括：用户指纹信息（1个），用户密码信息（1个），用户刷卡信息（1个）；用户ID号将对应用户权限等级信息。

3.2用户权限等级分为管理员用户，普通用户。

普通用户无法进行相关设置，只可验证身份开门；管理员用户除验证开门外，还可进入系统配置菜单。

3.3用户信息可创建，修改，删除；不能删除当前登录的管理员信息。

3.4开锁用户存储个数为100组，开锁记录信息为512个，此为门锁本地贮存的开锁日志，而云端开锁日志不限制个数。

注：密码不可重复设置，即用户A设置过的密码，用户B不可再重复使用。

4.密码开锁4.1有效密码位为最低不少于6位，最高不超过9位。

两个管理级别的密码，分为管理员密码，普通用户密码；4.2支持虚位密码，输入密码不超过12位，其中有连续的密码信息在其中，即可开锁。

User Manual for Bluetooth○R Smart LockDP1511.Install BatteryTake off battery cover and install 4* AAA alkanline batteries. After hearing a beep, put the cover back. Battery installation completes.App InstallationScan QRcode to download and install.Search "Soulzen"Soulzen in appstore to download for iPhone.2.Start APPClick the icon [ ] then you will see the welcome page.Tips: Start APP in Android will turn on Bluetooth automatically, but it requires to turn onBluetooth manually in iOS because of system limits.Mobile Phone System:Hardware support BLE 4.0 or above, supportsiOS system version 7.0 or above, Android system version 4.3 or above,the higher system of phone, the better experience operation with APP.3.Search DevicesSelect [Add] to start automatic searching for visible Bluetooth devices. If it haven't beensearched for a long time, please click [ ] for manual searching.Select the Bluetooth lock device when it is connectable. Enter password in the pop-upwindow to pair with the APP (Initial password is “000000”).4. Operation of HomepageDescriptions:.Click [①Home ] 、[Setting ] 、[Add ] 、[Help ] on bottom navigation bar to switch the interface. .Long press 1.5 seconds the connecting lock bar on [②Home ] can quick switch to the setting sub page.[Home ] is the main operating page,connecting lock is in color, unconnected lock is in grey, the paired lock will connect automatically. Icons and lock modes are shown as below:Notes:Effective connection and range of operation are within 10 meters. Notes:In the first time to pair the lock, entering number 0 six times "000000" will automatic to go the page of changing the pairing password, for security purpose, user must change the "000000" to a new 6 digits password.Operation guide for three modes of unlocking and locking:Precondition of operation: Bluetooth lock has been connected with mobile phone.①.Mode of Unlock Automatically: it will be unlocked automatically when mobile phone stay 3 meters of the connecting range, right side of lock bar indicates UNLOCK status. After door close, it will be locked when the mobile phone away from the locking connection range, lock bar indicates unconnected status.②.Mode of Slide to Unlock: slide to right side on lock bar then you will hear a beep of unlocking, right side of lock bar indicates UNLOCK status. It will be locked automatically after 2 seconds when door close, lock bar indicates LOCK status.③.Mode of Password Unlock: click the lock bar then enter the correct password on pop-up input box, you will hear a beep of unlocking, right side of lock bar indicates UNLOCK status. It will be locked automatically after 2 seconds when door close, lock bar indicates LOCK status.Beep alarms:5. Change the Unlocking ModeModes ], there are three modes [Unlock Automatically ] [Slide to Unlock ] [Password Unlock ] for selection.Modes features:.Please open the drawer or swing door within 5 seconds under mode of Sliding to unlock ①and Password unlock, otherwise it will be locked again automatically. If you open then close it again, the door would be locked after 2 seconds..Under mode of Unlock automatically, the lock will remain the OPEN status after ②unlocking as long as you keep the smart phone connecting to the lock, no matter whether open drawer or swing door.6. RenameNotes:[Password Unlock ] is the highest security level. Switching from the high security locking mode into any a lower mode, you need to unlock the device before switching.[Unlock Automatically ] & [Slide to unlock ] are of the low security level. Switching from low security modes to high mode can be operated either in lock or unlock status.to rename the Bluetooth lock.7. Change the Unlocking PasswordClick [Setting ] to enter setting interface, click lock bar to enter sub page, then click [Unlock Password] and enter the current password (Initial password is 123456), enter new password twice then press [Confirm ] to complete the password change.Name length: The maximum length of the name can bein 18 English letters or 9 Chinese characters (including numbers).8. Change the Binding PasswordClick [Setting ] to enter setting interface, click lock bar to enter sub page, then click [Pairing Password] and enter a pairing password in length of 6 digits twice then press [Confirm ] tocomplete password change.Notes: The Unlock Password MUST be in 6 digits in length. It is changeable only when the device is in unlock status.9. Viem the Bound Mobile PhonesClick [Setting] to enter setting interface, click lock bar to enter sub page, you can find the quantity of bound mobile phones, up to three mobile phones be bound.10. UnbindingClick [Setting] to enter setting interface, click lock bar to enter sub page, select [Unpair] to unbind the currently using mobile phone, press [Confirm] to complete unbinding.Notes: Performing the unbindingonly can be done when the lockconnecting with mobile phone.Notes: The Bluetooth lock will beremoved from the Homepage afterunbinding. It can be found when youclick [Add].11. Delete a Bluetooth Lock DeviceTo delete a disconnected Bluetooth lock device in iOS system, slide the device bar to the left and click [Delete]. In Android system, press the Bluetooth lock device bar for more than 2 seconds, then select [Confirm] on the pop-up window. If you want to use this lock again, it must been searched and paired again.12. Low Battery AlarmWhen battery power is low, there will be three short beeps, meanwhile pop-up the lower voltage alarm, the power can support at least 100 times of operation since the first time of alarm notice until it runs out.If user do not replace new batteries in time,with the result that batteries run out of power, please take off the plastic cap and follow two methods for charging in emergency(Please replace new batteries after unlocking):①.Connect the USB cable date in the packing to standard mobile phone power bank..Connect the USB c②able date in the packing to standard mobile phone charger incharging.13. Operation for Master KeyWhen password is lost or reset operation is needed, please take off the receiver cap and plug in the Master Key. The lock will be unlocked and reset to factory default status automatically at the same time.Factory Default Settings:① Name of the Bluetooth Smart Lock: DP151-xxxxxx;.②.Unpaired/Unbounded all mobile phone devices;③.Reset the unlocking mode to Sliding to unlock;④0;.Pairing Password: 00000⑤.Unlock Password: 123456;14. HelpClick [Help] to enter help center, select the items to find the solutions.15. Descriptions of Test Experience before InstallingIf user needs to test the lock before installing, please note that:①. After unlocking with mode of sliding to unlock and password unlock, please put the lock plate on deadbolt position (Lock body) and remain 2 seconds to achieve LOCK function as below photo shown.②After unlocking with mode of unlock automatically, please keep the lock plate on .deadbolt position (Lock body) as photo shown, then let the mobile device away from connecting range to achieve LOCK function.16. Technical InformationGentle hints:1. Please update your mobile system to Android 5.0 or above / Apple iOS 9.0 or above for better operation before using this Bluetooth lock.2. APP can not run in the background in iOS system because of Apple system limits which only affects the mode of unlocking automatically.3. As features of Bluetooth technology itself, if this Bluetooth lock already been connected to Mobile A, other mobile devices can not search and connect to it; If Mobile B need to connect to this lock, Mobile A must disconnect it first.The ways to disconnect:①m, double click key “Home” then .Exit APP. (Click “Exit” on page “Help” in Android systeremove it in iOS system.)②.Turn off Bluetooth on mobile phone.③ Keep mobile away from connecting range..4. If APP can not search out the Bluetooth lock:①try to reboot again..Please confirm the Bluetooth on or off, if the Bluetooth on, please②.Please confirm whether this lock has been connected with other mobile device, please disconnect the connecting by mobile device then search the lock again.5. For security purpose, changing the unlocking password for the first time in using the Bluetooth lock is suggested.6. The APP software will continue to update for optimizing the user experience, in order to avoid the lost of user information, we suggest that user manually download and install the newer version over the older version of APP which was not necessary to uninstall first.7. Please do not put the USB Key into the locker with this mating Bluetooth lock.FCC Statement:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Thisequipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna.•Increase the separation between the equipment and receiver.•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•Consult the dealer or an experienced radio/TV technician for help.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation.The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.RF warning statement:The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.。

REMOVAL AND INSTALLATIONRF KeypadRemoval - RF Keypad1.Please read ALL of these instructions before proceeding.Removal and Reprogram ProcedureNOTE:This procedure should be used if the remote entry transmitters need to be reprogrammed to vehicle after the RF keypad has been installed to the exterior.NOTE:Step 3 is to be completed only if Step 2 is unsuccessful. If Step 2 is successful no further action is required.2.Try to reprogram the RF keypad and other remote entry transmitters while the RF keypad is stillattached to the exterior of the vehicle.To program the RF keypad to your vehicle go to the appropriate "Programming and Installation"section, reference the application table below.3.Remove the RF keypad from the vehicle exterior.1Clean area around RF keypad.2Slide cutting line behind RF keypad to cut tape.3Remove the RF keypad.4Remove adhesive from the vehicle using adhesion remover or strip off wheel.5Remove adhesive from the back of the RF keypad.6Scuff the back side of the keypad, with a scuff pad or wire brush.7Clean the back of the keypad.8Add new tape if the RF keypad is to be re-used.▪To ensure proper keypad mounting, avoid covering the protruding portion of the keypad back.▪Use 3M™ Acrylic Plus Tape PT1100.4.Reprogram the RF keypad from the driver seat area.To program the RF keypad refer to the table below for appropriate reprogramming procedure.CONFIGURATION CHARTModel Year Model Communication Type Installation Method 2014+Fusion2C2015+F-1502C2015+Edge2C2016+Explorer2C2017+Super Duty2C2010+Transit Connect1A2007+Focus1A2011+Fiesta1A2013+Escape1A2013+C-Max1A2014+Transit1A2013Fusion Not Supported Not Supported-Intelligent Access Not Supported Not SupportedVehicles2005+All Else1B Configure DeviceNOTE:Reference the table above for communication type that applies for the vehicle.NOTE:The keyless entry keypad can be used in various vehicle applications. The following procedure describes the method to switch between the two communication types.5.Upon pressing the 1/2, 3/4, and 9/0 buttons simultaneously for at least one second, all five buttonswill flash at a two flashes per second rate. This indicates the keypad is waiting for master code entry. The master code is entered as in a normal keypad unlock, each button press will give another five second window for the next button press. If no button is pressed within five seconds theconfigure mode will exit.6.When the proper master code is entered the 9/0 button will flash a pattern that corresponds to thecurrent protocol set:•One flash per second for "Communication Type 2".•Three flashes per second for "Communication Type 1" (Default).7.You will have 10 seconds to:•Press the 9/0 button to change the protocol to "Communication Type 2".•Press the 1/2 button to change the protocol to "Communication Type 1" (Default).Type A - Programming and InstallationNOTE:It is easier to program the keypad prior to attaching it to the vehicle.NOTE:After five seconds of idle time, the keypad will reset itself.NOTE:You must have all remote entry transmitters available before beginning this procedure, IKTs, Fobs and RF keypads. Check owners guide "Locks and Security" for maximum remote entry transmitters allowed,and proper key positions.If all remote entry transmitters are not present during the programming procedure, the missing transmitters will not work following programming.NOTE:The vehicle will exit programming mode after 20 seconds of inactivity.NOTE:Ensure the brake pedal is not depressed during this procedure; the electronic signal could interfere with programming.9.Make sure that you have all of the IKTs, fobs and RF keypads for this vehicle.NOTE:Only one button press is recognized. After the button press is registered, the flash rate will change to reflect the new setting of the protocol. If you first press the 1/2 button, you cannot then press the 9/0button to change the selection. You must exit the session.8.Press the 5/6 button to confirm the entry, the 1/2, 3/4, 5/6 and 7/8 buttons will flash four times to confirm protocol change and the keypad will turn off and sleep. If the 5/6 button is not pressed within 10 seconds of protocol change, the protocol will NOT change and the procedure will need to be repeated.13.Within 10 seconds of completing the previous step, press any button on remote entry transmitter, ifequipped.The system will chime once, to confirm that the Fob has been programmed.14.Within 10 seconds of completing the previous step, press any button on remote entry transmitter, ifequipped.The system will chime once, to confirm that the Fob has been programmed.15.Within 10 seconds of completing the previous step, press the 7/8 and 9/0 buttons simultaneously onthe RF keypad 1.The system will chime once, to confirm that the RF keypad has been programmed.Repeat this step if more than one RF keypad is used.16.After all remote entry transmitters have been programmed; turn the ignition to the RUN position forthe vehicle to exit programming mode.17.Test all remote entry transmitters for proper operation, perform a lock/unlock cycle on all remoteentry transmitters.NOTE:Most vehicles have an audible feedback when programming such as horn honks, door locks/unlocks, or chimes.Some vehicles may not have audible feedback e.g C-MAX18.If the remote entry transmitters do not program properly repeat the "Type A - Programming andInstallation" procedure. The driver's door may need to be opened and closed to reset the system.10.Unlock the vehicle with programmed keyfob.11.Insert a key in the ignition.12.NOTE:Some vehicles may require eight key cycles before returning to the OFF position.Turn the key from the OFF position to the RUN (not START) position four times within sixseconds.The fourth turn must end in the OFF position.The system will chime to confirm the vehicle is in programming mode.20.Unlock the vehicle with programmed keyfob.21.Put a key in the ignition.22.Turn the key from the OFF position to RUN (not START) position eight times within 10 secondswith the eighth turn ending in the RUN position. The doors will lock, and then unlock, to confirm the vehicle is in programming mode.23.Within 20 seconds of completing the previous step, press any button on fob 1, if equipped. Thedoors will lock, and then unlock, to confirm that the fob has been programmed.24.Within 20 seconds of completing the previous step, press any button on fob 2, if equipped. Thedoors will lock, and then unlock, to confirm that the fob has been programmed.25.Within 20 seconds of completing the previous step, press the 7/8 and 9/0 buttons simultaneously onthe RF keypad 1.The doors will lock, and then unlock, to confirm that the RF keypad has been programmed.Repeat this step if more than one RF keypad is used.NOTE:2Q VRPH ,.7 NH\V WKH GRRU ORFNV ZLOO QRW DFWLYDWHType B - Programming and Installation19.Make sure that you have all of the fobs and RF keypads for this vehicle.28.If the remote entry transmitters do not program properly repeat the "Type B- Programming andInstallation" procedure. The Driver's door my need to be opened and closed to reset the system.Type C - Programming and Installation30.Verify that the Integrated Diagnostic System (IDS) is updated to the most current version.31.Connect IDS:•Follow the prompts to select new vehicle session.•Enter VIN.32.Program the keyless entry keypad to the vehicle using the IDS.•Select the Tool Box icon.•Select Body.•Select RF Keypad Learn Process.26.After all remote entry transmitters have been programmed, turn the ignition to the OFF position.The doors will lock, and then unlock, to confirm that the vehicle has exited programming mode.27.Test all remote entry transmitters for proper operation, perform a lock/unlock cycle on all remoteentry transmitters.29.Refer to the Configuration Chart of this document to ensure the correct Communication Type isused on the keyless entry keypad. Instructions for programming to the correct communication type may be found under Configure Device.34.Enter the device’s serial number and select the tick button.•The serial number is up to six digits.•The serial number is located on the part package.•If IDS responds with “Serial Number is not Valid”, go to the "Alternate Programming Method" section.•If all four storage locations are in use, go to the "Free Storage Location" section.Synchronize Keyless Entry Keypad to Vehicle (Type C - Continued)35.Once the unique data is entered, the programming routine will ask to select the tick button andactivate the Lock command on the keypad. This step will ensure that the keypad and the vehicle are synchronized.• A progress bar will be displayed and will complete over 10 seconds while the vehicle is commanded to synchronize with the keypad.•During the display of the 10 second progress bar, activate the Lock command by pressing DQG WKHQ UHOHDVLQJ the 7/8 and 9/0 buttons on the keypad simultaneously.33.Follow On-screen instructions until the screen below is displayed:4Within 5 seconds of Master Code entry, press the 3/4 button to unlock all doors.5Within 5 seconds of pressing the 3/4 button, press the 5/6 button multiple times to release the trunk.Alternate Programming Method (Type C - Continued)37.If IDS responds with “Serial Number is not Valid”, answer YES to the question “Would you like toenter 48-character SK/TIC/RC string?”•The 48-character string is located on the part package.•Using either the computer keyboard or the on-screen buttons, enter the 48 characters, 4 digits at a time.•Select the tick button when all 48 characters have been entered.Test Keyless Entry Keypad Operation (Type C - Continued)36.When the synchronization is complete, the programming routine will instruct the installer to turn offthe vehicle ignition key and test operation of the keypad. At this time, perform the following steps:1Close all vehicle doors.2Press the 7/8 and 9/0 buttons on the keypad to lock all doors.3Enter the keypad’s Master Code to unlock the driver’s door.Free Storage Location (Type C - Continued)38.If all four storage locations are in use, IDS will ask if you would like to determine which keypadunits are programmed to which storage locations. The process will begin by asking you to activate device #1:•Press the 7/8 and 9/0 buttons on the first keypad that is already programmed to the vehicle. Then, select the tick button on IDS.•IDS will ask if you would like to check another device. If there is another keypad on the vehicle, select YES on IDS to check that keypad unit. Proceed with the activation process to see if it isprogrammed to the vehicle.•Repeat this process for all keypads attached to the vehicle. Up to four keypads can be programmed to the vehicle.39.When all keypads have been tested, select NO when asked by IDS whether you would like to testanother device. A screen similar to the one below will be displayed:1Location # 1 – 4 refers to the four storage locations on the vehicle that may be programmed with information for a keypad.2“2 in use” refers to the second keypad device that was activated during the device check.3“2 in use” is listed next to the storage location where it is programmed.▪If you want to delete keypad #2 from the vehicle, select Location #2 and select the tick button.▪If you want to keep keypad #2 programmed to the vehicle and delete all other locations, selectLocation #1, Location #3, and Location #4. Then select the tick button.Troubleshooting (Type C - Continued)40.If the programming procedure has been completed, and the vehicle does not respond to commandsfrom the keyless entry keypad, try these suggestions:•Ensure that the vehicle is NOT a push-button start vehicle.•Ensure that the device is configured properly by following the steps in the "Configure Device"section.•Ensure that the device is synchronized to the vehicle:▪Enter the programming process ("Program Device to Vehicle" section).▪Instead of entering the device’s serial number, select the Delete button to determine whetherthe vehicle recognizes the keypad.▪If the device is recognized by the vehicle (listed as In Use when activated), delete the storagelocation contents.▪Re-enter the programming process and complete all steps through the synchronization process and the operational test.Programming a Personal Entry Code (if desired) - All VehiclesNOTE:If you lose your code card, please contact your Ford or Lincoln dealership for factory code retrieval. NOTE:Do not set a personal code that uses five of the same number. Do not set a personal code that uses five numbers in sequential order. There is a maximum of two access codes; the factory set code and one personal code. If you reprogram the personal code the prior personal code will be erased.NOTE:Do not repeat the "Programming and Installation" section if a mistake is made in the "Programminga Personal Entry Code" section.41.Enter the factory set code, as indicated on your code card.42.Within five seconds of entering the factory code, press and hold the 1/2 button for 1 second, the 9/0button will flash twice to confirm the keypad is in programming mode.43.Within five seconds, enter your desired personal 5-digit code. Each digit must be entered within fiveseconds of the previous digit.44.The vehicle doors will unlock-lock-unlock to confirm that your personal code has been programmedto the keypad and the 9/0 button will flash twice to confirm that the keypad has exited programming mode.Adhering the Keypad to the Vehicle - All VehiclesNOTICE:Do not adhere to moveable glass or windshield.NOTE:For proper adhesion, the mounting surface should be at least 60°F (15°C).NOTE:The tape is very sticky and will adhere quickly once contact is made.NOTE:This product is designed to attach to your car door, centered between the door handle and the window sill, but will work mounted to a relatively flat surface.45.Hold keypad up to desired mounting surface to confirm that all the tape will contact the mountingsurface.46.Clean the vehicle surface where the keypad is to be adhered with the alcohol wipe provided.47.Pull the tape tabs off the keypad tape, orient the keypad in the desired location and press onto thedoor surface.•Be sure to press firmly on all edges to ensure proper adhesion of the tape.Using the Keypad - All VehiclesNOTE:Refer to the "Locks and Security" section of your vehicle Owner’s Guide for operation of remote transmitters during RUN/START. Remote transmitter operation in RUN/START key position is model dependent.48.To unlock the drivers door, enter your personal 5-digit code or the factory set code.•Each digit must be pressed within five seconds of each other.49.To unlock all doors, press 3/4 button within five seconds of entering a valid keypad code.51.To unlock and open the driver side power sliding door, if equipped, press the 7/8 button twicewithin five seconds of entering a valid code.52.To lock all doors, press the 7/8 and the 9/0 keys simultaneously.•You do not have to enter a 5-digit code.Low Power Warning - All Vehicles53.If you unlock the door with the keypad and the locks cycle one additional time, it is time to replacethe unit.•The battery is not replaceable.50.To unlock the trunk or hatch, if equipped, press the 5/6 button within five seconds of entering avalid keypad code (IKT vehicles may require the 5/6 button to be pressed twice). Press the 5/6button twice to open or close the passenger side power sliding door, if equipped.Anti-Scan Mode - All Vehicles54.If the wrong code has been entered 7 times (35 consecutive button presses) the keypad is disabledfor one minute and the keypad lights will flash during this time.To Remove a Personal Code, If Desired - All Vehicles55.Enter the factory code, then within five seconds press and hold the 1/2 button, for 5 seconds. Thevehicle will unlock, lock and then unlock to confirm that your personal code has been removed. The 9/0 key will flash four times (2 quick then 2 slow) to confirm that your personal code has been removed.56.Release the 1/2 button.Owners Instructions - All Vehicles57.Place the user manual with the vehicle's owners manual when programming and installation iscomplete.58.This device complies with part 15 of the FCC rules and with RSS-210 of Industry Canada.Operation is subject to the following two conditions:1This device may not cause harmful interference.2This device must accept any interference received, including interference that may cause undesired operation.•Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.。
