CHAPTER 1 AUTOMOTIVE BASICS1.1 Principal ComponentsToday's average car contains more than 15,000 separate, individual parts that must work together. These parts can grouped into four major categories: engine, body, chassis and electrical equipment.1.2 EngineThe engine acts as the power unit. The internal combustion engine is most common: this obtains its power by burning a liquid fuel inside the engine cylinder. There are two types of engine :gasoline(also called a spark-ignition engine) and diesel(also called a compression-ignition engine).Both engines are called heat engines; the burning fuel generates heat which causes the gas inside the cylinder to increase its pressure and supply power to rotate a shaft connected to the transmission.1.3 BodyAn automobile body is a sheet metal shell with windows, doors, a hood, and a trunk deck builtinto it. It provides a protective covering for the engine, passengers, and cargo. The body is designed to keep passengers safe and comfortable. The body styling provides an attractive, colorful, modern appearance for the vehicle.1.4 ChassisThe chassis is an assembly of those systems that are the major operating part of a vehicle. The chassis includes the transmission, suspension, steering, and brake systems.Transmission systems ― conveys the drive to the wheels. The main components are clutch, gearbox, driveshaft, final drive, and differential.Suspension― absorbs the road shocks.Steering― controls the direction of the movement.Brake― slows down the vehi cle.1.5 Electrical EquipmentThe electrical system supplies electricity for the ignition, horn, lights, heater, and starter. The electricity level is maintained by a charging circuit. This circuit consists of the battery, alternator (or generator). The battery stores electricity. The alternator changes the engine's mechanical energy into electrical energy and recharges the battery.New WordsPrincipal component 主要部件category 种类，类型body 车身chassis 底盘layout 布置power unit 动力装置internal combustion engine 内燃机cylinder 汽缸gasoline 汽油spark 火ignition 点燃，点火diesel 柴油机compression 压缩shaft 轴transmission 传动系sheet metal 金属板shell 外壳hood （发动机）罩trunk deck 行李舱盖cargo 货物styling 样式assembly 总成，装配suspension 悬挂，悬置shock 冲击steering 转向，操纵brake 刹车，制动器clutch 离合器gearbox 变速器driveshaft 传动轴final drive 主减速器，后桥differential 差速器slow down （使）慢下来，减速horn 喇叭starter 起动机charge 充电alternator 交流发电机Review Questions1. List the main parts of an automobile?2. What are the common types of a vehicle according to body styling?3. Which systems does a chassis include and what are the main functions of the chassis?4. Why are suspension systems used on vehicles?CHAPTER2 INTERNAL COMBUSTION ENGINE2.1 principle of operation2.1.1 Engine and powerEngine is used to produce power. The chemical energy in fuel is converted to heat by the burning of the fuel at a controlled rate. This process is called combustion. If engine combustion occurs with the power chamber. ,the engine is called internal combustion engine. If combustion takes place outside the cylinder, the engine is called an external combustion engine.Engine used in automobiles are internal combustion heat engines. Heat energy released in the combustion chamber raises the temperature of the combustion gases with the chamber. The increase in gas temperature causes the pressure of the gases to increase. The pressure developed within the combustion chamber is applied to the head of a piston to produce a usable mechanical force, which is then converted into useful mechanical power.2.1.2 Engine TermsLinking the piston by a connecting rod to a crankshaft causes the gas to rotate the shaft through half a turn. The power stroke “uses up” the gas , so means must be provided to expel the burnt gas and recharge the cylinder with a fresh petrol-air mixture :this control of gas movement is the duty of the valves ;an inlet valve allows the new mixture to enter at the right time and an exhaust valve lets out the burnt gas after the gas has done its job. Engine terms are :TDC(Top Dead Center):the position of the crank and piston when the piston is farther away from the crankshaft.BDC(Bottom Dead Center):the position of the crank and piston when the piston is nearest to the crankshaft.Stroke : the distance between BDC and TDC; stroke is controlled by the crankshaft.Bore : the internal diameter of the cylinder.Swept volume : the volume between TDC and BDC.Engine capacity : this is the swept volume of all the cylinder e.g. a four-stroke having a capacity of two liters(2000cm) has a cylinder swept volume of 50cm.Clearance volume: the volume of the space above the piston when it is at TDC. Compression ratio = (swept vol + clearance vol)\(clearance vol)Two-stroke : a power stroke every revolution of the crank.Four-stroke : a power stroke every other revolution of the crank..2.1.3 The Four-stroke Spark-ignition Engine CycleThe spark-ignition engine is an internal-combustion engine with externally supplied in ignition, which converts the energy contained in the fuel to kinetic energy.The cycle of operations is spread over four piston strokes. To complete the full cycle it takes two revolutions of the crankshaft.The operating strokes are :This stroke introduces a mixture of atomized gasoline and air into the cylinder. The stroke starts when the piston moves downward from a position near the top of the cylinder. As the piston moves downward, a vacuum, or low-pressure area, is created.During the intake stroke, one of the ports is opened by moving the inlet valve. The exhaustvalve remains tightly closed.Compression strokeAs the piston moves upward to compress the fuel mixture trapped in the cylinder, the valves are closed tightly. This compression action heats the air/fuel mixture slightly and confines it within a small area called the combustion chamber.Power strokeJust before the piston reaches the top of its compression stroke, an electrical spark is introduced from a spark plug screwed into the cylinder head.The spark ignites the compressed, heated mixture of fuel and air in the combustion chamber to cause rapid burning. The burning fuel produces intense heat that causes rapid expansion of the gases compressed within the cylinder. This pressure forces the piston downward. The downward stroke turns the crankshaft with great force.Exhaust strokeJust before the bottom of the power stroke, the exhaust valve opens. This allows the piston, as it moves upward, to push the hot, burned gases out through the open exhaust valve.Then, just before the piston reaches its highest point, the exhaust valve closes and the inlet valve opens. As the piston reaches the highest point in the cylinder, known as TDC, it starts back down again. Thus, one cycle ends and another begins immediately.2.1.4 Engine Overall MechanicsThe engine has hundreds of other parts . The major parts of engine are engine block , engine heads, pistons, connecting rods, crankshaft and valves. The other parts are joined to make systems. These systems are the fuel system, intake system, ignition system, cooling system, lubrication system and exhaust system. Each of these systems has a definite function. These systems will discussed in detail later.NEW WORDPiston 活塞Connecting rod 连杆Crankshaft 曲轴Power stoke 活塞行程Expel 排出Valve 气阀inlet(intake) valve 进气阀exhaust valve 排气阀term 术语TDC 上止点BDC 下止点Bore 缸径swept volume 有效容积engine capacity 发动机排量clearance volume 余隙容积,燃烧室容积compression ratio 压缩比revolution 旋转,转数every other 每隔一个cycle 循环spread over 分布,遍及intake stroke 进气行程compression stroke 压缩行程knock 敲缸,敲打exhaust stroke 排气行程engine block 发动机缸体lubrication 润滑2.2 Engine Block and Cylinder Head2.2.1 Engine BlockThe engine block is the basic frame of the engine. All other engine parts either fit inside it or fasten to it. It holds the cylinders, water jackets, and oil galleries. The engine block also holdsthe crankshaft, which fastens to the bottom of the block. The camshaft also fits inside the block, except on overhead-cam engines (OHC). In most cars, this block is made of gray iron, or an alloy (mixture) of gray iron and other metals, such as nickel or chromium. Engine blocks are castings.Some engine blocks, especially those in smaller cars, are made of cast aluminum. This metal is much lighter than iron. However, iron wears better than aluminum. Therefore, the cylinders in most aluminum engines are lined with iron or steel sleeves. These sleeves are called cylinder sleeves. Some engine blocks are made entirely of aluminum.2.2.2 Cylinder HeadThe cylinder head fastens to the top of the block, just as a roof fits over a house. The underside forms the combustion chamber with the top of the piston. The most common cylinder head types are the hemi, wedge, and semi-hemi. All three of these terms refer to the shape of the engine's combustion chamber. The cylinder head carries the valves, valve springs and the rockers on the rocker shaft, this part of the valve gear being worked by the push-rods. Sometimes the camshaft is fitted directly into the cylinder head and operates on the valves without rockers. This is called an overhead camshaft arrangement. Like the cylinder block, the head is made from either cast iron or aluminum alloy.2.2.3 GasketThe cylinder head is attached to the block with high-tensile steel studs. The joint between the block and the head must be gas-tight so that none of the burning mixture can escape. This is achieved by using cylinder head gasket. This is a sandwich gasket, i.e. a sheet of asbestos between two sheets of copper, both these materials being able to withstand the high temperature and pressures within the engine.2.2.4 Oil Pan or SumpThe oil pan is usually formed of pressed steel. The oil pan and the lower part of the cylinder block together are called the crankcase; they enclose, or encase, the crankshaft. The oil pump in the lubricating system draws oil from the oil pan and sends it to all working parts in the engine. The oil drains off and runs down into the pan. Thus, there is constant circulation of oil between the pan and the working parts of the engine.New Wordsengine block 缸体cylinder head 气缸盖fasten 使固定water jacket 水套oil gallery 油道camshaft 凸轮轴overhead-cam(OHC) 顶置凸轮gray iron 灰铸铁alloy 合金nickel 镍chromium 铬casting 铸件head cover 汽缸盖罩intake manifold 进气总管distributor 分电器oil pan 油底壳aluminum 铝be lined with 镶有cylinder sleeve 气缸套hemi 半球形wedge 楔型，楔入semi-hemi 准半球形rocker 摇臂push-rod 推杆gasket 衬垫high-tensile 高强度的stud 螺栓gas-tight 密封的asbestos 石棉crankcase 曲轴箱，曲柄箱encase 封闭，把…包起来drain off 排出，流出Review Question1. What do TDC, BDC, stroke, compression ratio and engine capacity stand for?2. How do you calculate swept volume and compression ratio?3. What controls the length of the stroke?4. List the main parts of the engine overall mechanics?5. What are the main function of the engine block?2.3 Piston Connecting Rod and Crankshaft2.3.1 Piston AssemblyThe piston is an important part of a four-stroke cycle engine. Most pistons are made from cast aluminum. The piston , through the connecting rod, transfers to the crankshaft the force create by the burning fuel mixture. This force turns the crankshaft .Thin, circular , steel bands fit into grooves around the piston to seal the bottom of the combustion chamber. These bands are called piston rings. The grooves into which they fit are called ring grooves. A piston pin fits into a round hole in the piston . The piston pin joins the piston to the connecting rod . The thick part of the piston that holds the piston is the pin boss.The piston itself , its rings and the piston pin are together called the piston assembly.2.3.2.PistonTo withstand the heat of the combustion chamber, the piston must be strong. It also must be light, since it travels at high speeds as it moves up and down inside the cylinder. The piston is hollow. It is thick at the top where it take the brunt of the heat and the expansion force. It is thin at the bottom, where there is less heat. The top part of the piston is the head , or crown . The thin part is the skirt The sections between the ring grooves are called ring lands.The piston crown may be flat , concave ,dome or recessed . In diesel engine , the combustion chamber may be formed totally or in part in the piston crown , depending on the method of injection . So they use pistons with different shapes.2.3.3Piston RingsAs Fig.2-9 shows , piston rings fit into ring grooves near the of the piston. In simplest terms, piston rings are thin, circular pieces of metal that fit into grooves in the tops of the pistons.In modern engines ,each piston has three rings. (Piston in older engines sometimes had four rings, or even five.) The ring’s outside surface presses against the cylinder walls. Rings provide the needed seal between the piston and the cylinder walls. That is, only the rings contact the cylinder walls. The top two rings are to keep the gases in the cylinder and are called compression rings. The lower one prevents the oil splashed onto the cylinder bore from entering the combustion chamber , and is called an oil ring. Chrome-face cast-iron compression rings are commonly used in automobile engines. The chrome face provide a very smooth , wear-resistant surface.During the power stoke , combustion pressure on the combustion rings is very high. It causes them to untwist . Some of the high-pressure gas gets in back of the rings. This force the ring face into full contact with the cylinder wall. The combustion pressure also holds the bottom of the ring tightly against the bottom of the ring groove. Therefore , high combustion pressure causes a tighter seal between the ring face and the cylinder wall.2.3.4 Piston PinThe piston pin holds together the piston and the connecting rod . This pin fits into the piston pin holes and into a hole in the top end of the connecting rod. The top end of is much smaller than the end that fits on the crankshaft . This small end fits inside the bottom of the piston . The piston pin fits through one side of the piston , through the small end of the rod , and then through the other side of the piston . It holds the rod firmly in place in the center of the piston. Pins are made of high-strengh steel and have a hollow center . Many pins are chrome-plated to help them wear better.2.3.3 Connecting rodThe connecting rod is made of forgedhigh-strength steel . It transmits and motion from the piston to the crankpin on the crankshaft . The connecting rod little end is connected to the piston pin . A bush made from a soft metal , such as bronze , is used for this joint . The lower end of the connecting rod fits the crankshaft journal . This is called the big end . For this big-end bearing , steel-backed lead or tin shell bearing are used . These are the same as those used for the main bearings . The split of the big end is sometimes at an angle , so that it is small enough to be withdrawn through the cylinder bore . The connecting rod is made from forged alloy steel .2.3.5 CrankshaftThe crankshaft , in conjunction with the connecting rod , coverts the reciprocating motion of the piston to the rotary motion needed to drive the vehicle . It is usually made from carbon steel which is alloyed with a small proportion of nickel .The main bearing journals fit into the cylinder block and the big end journals align with the connecting rods .At the rear end of the crankshaft is attached the flywheel , and at the front end are the driving whells for the timing gears , fan , cooling water and alternator .The throw of the crankshaft , the distance between the main journal and the big end centers , controls the length of the stroke . The stroke is double the throw , and the stroke-length is the distance that the piston travels from TDC to BDC and vice versa .2.3.6 FlywheelThe flywheel is the made from carbon steel . It fit s onto the rear of the crankshaft . As well as keeping the engine rotating between power strokes it also carries the clutch , which transmits the drive to the transmission , and has the starter ring gear around its circumference . There is only one working stroke in four so a flywheel is needed to drive the crankshaft during the time that the engine is performing the non-power strokes .New WordsComprise 由。

Principal Components(汽车主要组成部分)Today's average car contains more than 15,000 separate, individual parts that must work together. These parts can grouped into four major categories: engine, body, chassis and electrical equipment.现代汽车有超过15000个零件组成，分成几个必须在一起工作的功能部分。

主要包括4个功能部分：引擎，车身，底盘和电控。

引擎Engine 引擎1、The engine acts as the power unit. 引擎为汽车提供能源。

2、 The internal combustion engine is most common: this obtains its power by burning a liquid fuel inside the engine cylinder . 一般是内燃机：通过在引擎缸内燃烧液体燃料获得能量。

3、There are two types of engine :gasoline(also called a spark-ignition engine) and diesel(alsocalled a compression-ignition engine). 引擎有两种：汽油机和柴油机。

4、Both engines are called heat engines; the burning fuel generates heat which causes the gas inside the cylinder to increase its pressure and supply power to rotate a shaft connected to the transmission.两种引擎都叫热机。

汽车构造英文版-免费下载版CHAPTER 1 AUTOMOTIVE BASICS1.1 Principal ComponentsToday's average car contains more than 15,000 separate, individual parts that must work together. These parts can grouped into four major categories: engine, body, chassis and electrical equipment.1.2 EngineThe engine acts as the power unit. The internal combustion engine is most common: this obtains its power by burning a liquid fuel inside the engine cylinder. There are two types of engine :gasoline(also called a spark-ignition engine) and diesel(also called a compression-ignition engine).Both engines are called heat engines; the burning fuel generates heat which causes the gas inside the cylinder to increase its pressure and supply power to rotate a shaft connected to the transmission.1.3 BodyAn automobile body is a sheet metal shell with windows, doors, a hood, and a trunk deck built into it. It provides a protective covering for the engine, passengers, and cargo. The body is designed to keep passengers safe and comfortable. The body styling provides an attractive, colorful, modern appearance for the vehicle.1.4 ChassisThe chassis is an assembly of those systems that are the major operating part of a vehicle. The chassis includes the transmission, suspension, steering, and brake systems.Transmission systems ― conveys the drive to the wheels. The main components are clutch, gearbox, driveshaft, final drive, and differential.Suspension― absorbs the road shocks.Steering― controls the direction of the movement.Br ake― slows down the vehicle.1.5 Electrical EquipmentThe electrical system supplies electricity for the ignition, horn, lights, heater, and starter. The electricity level is maintained by a charging circuit. This circuit consists of the battery, alternator (or generator). The battery stores electricity. The alternator changes the engine's mechanical energy into electrical energy and recharges the battery. New WordsPrincipal component 主要部件category 种类，类型body 车身chassis 底盘layout 布置power unit 动力装置internal combustion engine 内燃机cylinder 汽缸gasoline 汽油spark 火花ignition 点燃，点火diesel 柴油机compression 压缩shaft 轴transmission 传动系sheet metal 金属板shell 外壳hood （发动机）罩trunk deck 行李舱盖cargo 货物styling 样式assembly 总成，装配suspension 悬挂，悬置shock 冲击steering 转向，操纵brake 刹车，制动器clutch 离合器gearbox 变速器driveshaft 传动轴final drive 主减速器，后桥differential 差速器slow down （使）慢下来，减速horn 喇叭starter 起动机charge 充电alternator 交流发电机Review Questions1.List the main parts of an automobile?2.What are the common types of a vehicle according to body styling?3.Which systems does a chassis include and what are the main functions of the chassis?4.Why are suspension systems used on vehicles?CHAPTER2 INTERNAL COMBUSTION ENGINE2.1 principle of operation2.1.1 Engine and powerEngine is used to produce power. The chemical energy in fuel is converted to heat by the burning of the fuel at a controlled rate. This process is called combustion. If engine combustion occurs with the power chamber. ,the engine is called internal combustion engine. If combustion takes place outside the cylinder, the engine is called an external combustion engine.Engine used in automobiles are internal combustion heat engines. Heat energy released in the combustion chamber raises the temperature of the combustion gases with the chamber. The increase in gas temperature causes the pressure of the gases to increase. The pressure developed within the combustion chamber is applied to the head of a piston to produce a usable mechanical force, which is then converted into useful mechanical power.2.1.2 Engine TermsLinking the piston by a connecting rod to a crankshaft causes the gas to rotate the shaft through half a turn. The power stroke “uses up” the gas , so means must be provided to expel the burnt gas and recharge the cylinder with a fresh petrol-air mixture :this control of gas movement is the duty of the valves ;an inlet valve allows the new mixture to enter at the right time and an exhaust valve lets out the burnt gas after the gas has done its job. Engine terms are :TDC(Top Dead Center):the position of the crank and piston when the piston is farther away from the crankshaft.BDC(Bottom Dead Center):the position of the crank and piston when the piston is nearest to the crankshaft.Stroke : the distance between BDC and TDC; stroke is controlled by the crankshaft.Bore : the internal diameter of the cylinder.Swept volume : the volume between TDC and BDC.Engine capacity : this is the swept volume of all the cylinder e.g. a four-stroke having a capacity of two liters(2000cm) has a cylinder swept volume of 50cm.Clearance volume: the volume of the space above the piston when it is at TDC.Compression ratio = (swept vol + clearance vol)\(clearance vol)Two-stroke : a power stroke every revolution of the crank.Four-stroke : a power stroke every other revolution of the crank..2.1.3 The Four-stroke Spark-ignition Engine CycleThe spark-ignition engine is an internal-combustion engine with externally supplied in ignition , which converts the energy contained in the fuel to kinetic energy.The cycle of operations is spread over four piston strokes. To complete the full cycle it takes two revolutions of the crankshaft.The operating strokes are :This stroke introduces a mixture of atomized gasoline and air into the cylinder. The stroke starts when the piston moves downward from a position near the top of the cylinder. As the piston moves downward, a vacuum, or low-pressure area, is created.During the intake stroke, one of the ports is opened by moving the inlet valve. The exhaust valve remains tightly closed.Compression strokeAs the piston moves upward to compress the fuel mixture trapped in the cylinder, the valves are closed tightly. This compression action heats the air/fuel mixture slightly and confines it within a small area called the combustion chamber.Power strokeJust before the piston reaches the top of its compression stroke, an electrical spark is introduced from a spark plug screwed into the cylinder head.The spark ignites the compressed, heated mixture of fuel and air in the combustion chamber to cause rapid burning.The burning fuel produces intense heat that causes rapid expansion of the gases compressed within the cylinder. This pressure forces the piston downward. The downward stroke turns the crankshaft with great force.Exhaust strokeJust before the bottom of the power stroke, the exhaust valve opens. This allows the piston, as it moves upward, to push the hot, burned gases out through the open exhaust valve.Then, just before the piston reaches its highest point, the exhaust valve closes and the inlet valve opens. As the piston reaches the highest point in the cylinder, known as TDC, it starts back down again. Thus, one cycle ends and another begins immediately.2.1.4 Engine Overall MechanicsThe engine has hundreds of other parts . The major parts of engine are engine block , engine heads, pistons, connecting rods, crankshaft and valves. The other parts are joined to make systems. These systems are the fuel system, intake system, ignition system, cooling system, lubrication system and exhaust system. Each of these systems has a definite function. These systems will discussed in detail later.NEW WORDPiston 活塞Connecting rod 连杆Crankshaft 曲轴Power stoke 活塞行程Expel 排出Valve 气阀inlet(intake) valve 进气阀exhaust valve 排气阀term 术语TDC 上止点BDC 下止点Bore 缸径swept volume 有效容积engine capacity 发动机排量clearance volume 余隙容积,燃烧室容积compression ratio 压缩比revolution 旋转,转数every other 每隔一个cycle 循环spread over 分布,遍及intake stroke 进气行程compression stroke 压缩行程knock 敲缸,敲打exhaust stroke 排气行程engine block 发动机缸体lubrication 润滑2.2 Engine Block and Cylinder Head2.2.1 Engine BlockThe engine block is the basic frame of the engine. All other engine parts either fit inside it or fasten to it. It holds the cylinders, water jackets, and oil galleries. The engine block also holds the crankshaft, which fastens to the bottom of the block. The camshaft also fits inside the block, except on overhead-cam engines (OHC). In most cars, this block is made of gray iron, or an alloy (mixture) of gray iron and other metals, such as nickel or chromium. Engine blocks are castings.Some engine blocks, especially those in smaller cars, are made of cast aluminum. This metal is much lighter than iron. However, iron wears better than aluminum. Therefore, the cylinders in most aluminum engines are lined with iron or steel sleeves. These sleeves are called cylinder sleeves. Some engine blocks are made entirely of aluminum.2.2.2 Cylinder HeadThe cylinder head fastens to the top of the block, just as a roof fits over a house. The underside forms the combustion chamber with the top of the piston. The most common cylinder head types are the hemi, wedge, and semi-hemi. All three of these terms refer to the shape of the engine's combustion chamber. The cylinder head carries the valves, valve springs and the rockers on the rocker shaft, this part of the valve gear being worked by the push-rods. Sometimes the camshaft is fitted directly into the cylinder head and operates on the valves without rockers. This is called an overhead camshaft arrangement. Like the cylinder block, the head is made from either cast iron or aluminum alloy.2.2.3 GasketThe cylinder head is attached to the block with high-tensile steel studs. The joint between the block and the head must be gas-tight so that none of the burning mixture can escape. This is achieved by using cylinder head gasket. This is a sandwich gasket, i.e. a sheet of asbestos between two sheets of copper, both these materials being able to withstand the high temperature and pressures within the engine.2.2.4 Oil Pan or SumpThe oil pan is usually formed of pressed steel. The oil pan and the lower part of the cylinder block together are called the crankcase; they enclose, or encase, the crankshaft. The oil pump in the lubricating system draws oil from the oilpan and sends it to all working parts in the engine. The oil drains off and runs down into the pan. Thus, there is constant circulation of oil between the pan and the working parts of the engine.New Wordsengine block 缸体cylinder head 气缸盖fasten 使固定water jacket 水套oil gallery 油道camshaft 凸轮轴overhead-cam(OHC) 顶置凸轮gray iron 灰铸铁alloy 合金nickel 镍chromium 铬casting 铸件head cover 汽缸盖罩intake manifold 进气总管distributor 分电器oil pan 油底壳aluminum 铝be lined with 镶有cylinder sleeve 气缸套hemi 半球形wedge 楔型，楔入semi-hemi 准半球形rocker 摇臂push-rod 推杆gasket 衬垫high-tensile 高强度的stud 螺栓gas-tight 密封的asbestos 石棉crankcase 曲轴箱，曲柄箱encase 封闭，把…包起来drain off 排出，流出Review Question1.What do TDC, BDC, stroke, compression ratio and engine capacity stand for?2.How do you calculate swept volume and compression ratio?3.What controls the length of the stroke?4.List the main parts of the engine overall mechanics?5.What are the main function of the engine block?2.3 Piston Connecting Rod and Crankshaft2.3.1 Piston AssemblyThe piston is an important part of a four-stroke cycle engine. Most pistons are made from cast aluminum. The piston , through the connecting rod, transfers to the crankshaft the force create by the burning fuel mixture. This force turns the crankshaft .Thin, circular , steel bands fit into grooves around the piston to seal the bottom of the combustion chamber. These bands are called piston rings. The grooves into which they fit are called ring grooves. A piston pin fits into a round hole in the piston . The piston pin joins the piston to the connecting rod . The thick part of the piston that holds the piston is the pin boss.The piston itself , its rings and the piston pin are together called the piston assembly.2.3.2.PistonTo withstand the heat of the combustion chamber, the piston must be strong. It also must be light, since it travels at high speeds as it moves up and down inside the cylinder. The piston is hollow. It is thick at the top where it take the brunt of the heat and the expansion force. It is thin at the bottom, where there is less heat. The top part of the piston is the head , or crown . The thin part is the skirt The sections between the ring grooves are called ring lands.The piston crown may be flat , concave ,dome or recessed . In diesel engine , the combustion chamber may be formed totally or in part in the piston crown , depending on the method of injection . So they use pistons with different shapes.2.3.3Piston RingsAs Fig.2-9 shows , piston rings fit into ring grooves near the of the piston. In simplest terms, piston rings are thin, circular pieces of metal that fit into grooves in the tops of the pistons.In modern engines ,each piston has three rings. (Piston in older engines sometimes had four rings, or even five.) The ring’s outside surface presses against the cylinder walls. Rings provide the needed seal between the piston and the cylinder walls. That is, only the rings contact the cylinder walls. The top two rings are to keep the gases in the cylinder and are called compression rings. The lower one prevents the oil splashed onto the cylinder bore from entering the combustion chamber , and is called an oil ring. Chrome-face cast-iron compression rings are commonly used in automobile engines. The chrome face provide a very smooth , wear-resistant surface.During the power stoke , combustion pressure on the combustion rings is very high. It causes them to untwist . Some of the high-pressure gas gets in back of the rings. This force the ring face into full contact with the cylinder wall. The combustion pressure also holds the bottom of the ring tightly against the bottom of the ring groove. Therefore , high combustion pressure causes a tighter seal between the ring face and the cylinder wall.2.3.4 Piston PinThe piston pin holds together the piston and the connecting rod . This pin fits into the piston pin holes and into a hole in the top end of the connecting rod. The top end of is much smaller than the end that fits on the crankshaft . This small end fits inside the bottom of the piston . The piston pin fits through one side of the piston , through the small end of the rod , and then through the other side of the piston . It holds the rod firmly in place in the center of the piston. Pins are made of high-strengh steel and have a hollow center . Many pins are chrome-plated to help them wear better.2.3.3 Connecting rodThe connecting rod is made of forgedhigh-strength steel . It transmits and motion from the piston to the crankpin on the crankshaft . The connecting rod little end is connected to the piston pin . A bush made from a soft metal , such as bronze , is used for this joint . The lower end of the connecting rod fits the crankshaft journal . This is called the big end . For this big-end bearing , steel-backed lead or tin shell bearing are used . These are the same as those used for the main bearings . The split of the big end is sometimes at an angle , so that it is small enough to be withdrawn through the cylinder bore . The connecting rod is made from forged alloy steel .2.3.5 CrankshaftThe crankshaft , in conjunction with the connecting rod , coverts thereciprocating motion of the piston to the rotary motion needed to drive thevehicle . It is usually made from carbon steel which is alloyed with asmall proportion of nickel .The main bearing journals fit into the cylinderblock and the big end journals align with the connecting rods .At the rearend of the crankshaft is attached the flywheel , and at the front end are thedriving whells for the timing gears , fan , cooling water and alternator .The throw of the crankshaft , the distance between the mainjournal and the big end centers , controls the length of the stroke . Thestroke is double the throw , and the stroke-length is the distance that thepiston travels from TDC to BDC and vice versa .2.3.6 FlywheelThe flywheel is the made from carbon steel . It fit s onto the rear of the crankshaft . As well as keeping the engine rotating between power strokes it also carries the clutch , which transmits the drive to the transmission , and has the starter ring gear around its circumference . There is only one working stroke in four so a flywheel is needed to drive the crankshaft during the time that the engine is performing the non-power strokes .New WordsComprise 由。

（汽车行业）汽车构造(英文版)CHAPTER 1 AUTOMOTIVE BASICS1.1 Principal ComponentsToday's average car contains more than 15,000 separate, individual parts that must work together. These parts can grouped into four major categories: engine, body, chassis and electrical equipment.1.2 EngineThe engine acts as the power unit. The internal combustion engine is most common: this obtains its power by burning a liquid fuel inside the engine cylinder. There are two types of engine :gasoline(also called a spark-ignition engine) and diesel(also called a compression-ignition engine).Both engines are called heat engines; the burning fuel generates heat which causes the gas inside the cylinder to increase its pressure and supply power to rotate a shaft connected to the transmission.1.3 BodyAn automobile body is a sheet metal shell with windows, doors, a hood, and a trunk deck built into it. It provides a protective covering for the engine, passengers, and cargo. The body is designed to keep passengers safe and comfortable. The body styling provides an attractive, colorful, modern appearance for the vehicle.1.4 ChassisThe chassis is an assembly of those systems that are the major operating part of a vehicle. The chassis includes the transmission, suspension, steering, and brake systems.Transmission systems ― conveys the drive to the wheels. The main components are clutch, gearbox, driveshaft, final drive, and differential.Suspension― absorbs the road shocks.Steering― controls the direction of th e movement.Brake― slows down the vehicle.1.5 Electrical EquipmentThe electrical system supplies electricity for the ignition, horn, lights, heater, and starter. The electricity level is maintained by a charging circuit. This circuit consists of the battery, alternator (or generator). The battery stores electricity. The alternator changes the engine's mechanical energy into electrical energy and recharges the battery.New WordsPrincipal component 主要部件category 种类，类型body 车身chassis 底盘layout 布置power unit 动力装置internal combustion engine 内燃机cylinder 汽缸gasoline 汽油spark 火ignition 点燃，点火diesel 柴油机compression 压缩shaft 轴transmission 传动系sheet metal 金属板shell 外壳hood （发动机）罩trunk deck 行李舱盖cargo 货物styling 样式assembly 总成，装配suspension 悬挂，悬置shock 冲击steering 转向，操纵brake 刹车，制动器clutch 离合器gearbox 变速器driveshaft 传动轴final drive 主减速器，后桥differential 差速器slow down （使）慢下来，减速horn 喇叭starter 起动机charge 充电alternator 交流发电机Review Questions1.List the main parts of an automobile?2.What are the common types of a vehicle according to body styling?3.Which systems does a chassis include and what are the main functions of the chassis?4.Why are suspension systems used on vehicles?CHAPTER2 INTERNAL COMBUSTION ENGINE2.1 principle of operation2.1.1 Engine and powerEngine is used to produce power. The chemical energy in fuel is converted to heat by the burning of the fuel at a controlled rate. This process is called combustion. If engine combustion occurs with the power chamber. ,the engine is called internal combustion engine. If combustion takes place outside the cylinder, the engine is called an external combustion engine.Engine used in automobiles are internal combustion heat engines. Heat energyreleased in the combustion chamber raises the temperature of the combustion gases with the chamber. The increase in gas temperature causes the pressure of the gases to increase. The pressure developed within the combustion chamber is applied to the head of a piston to produce a usable mechanical force, which is then converted into useful mechanical power.2.1.2 Engine TermsLinking the piston by a connecting rod to a crankshaft causes the gas to rotate the shaft through half a turn. The power stroke “uses up” the gas , so means must be provided to expel the burnt gas and recharge the cylinder with a fresh petrol-air mixture :this control of gas movement is the duty of the valves ;an inlet valve allows the new mixture to enter at the right time and an exhaust valve lets out the burnt gas after the gas has done its job. Engine terms are :TDC(Top Dead Center):the position of the crank and piston when the piston is farther away from the crankshaft.BDC(Bottom Dead Center):the position of the crank and piston when the piston is nearest to the crankshaft.Stroke : the distance between BDC and TDC; stroke is controlled by the crankshaft. Bore : the internal diameter of the cylinder.Swept volume : the volume between TDC and BDC.Engine capacity : this is the swept volume of all the cylinder e.g. a four-stroke having a capacity of two liters(2000cm) has a cylinder swept volume of 50cm.Clearance volume: the volume of the space above the piston when it is at TDC. Compression ratio = (swept vol + clearance vol)\(clearance vol)Two-stroke : a power stroke every revolution of the crank.Four-stroke : a power stroke every other revolution of the crank..2.1.3 The Four-stroke Spark-ignition Engine CycleThe spark-ignition engine is an internal-combustion engine with externally supplied in ignition, which converts the energy contained in the fuel to kinetic energy.The cycle of operations is spread over four piston strokes. To complete the full cycle it takes two revolutions of the crankshaft.The operating strokes are :This stroke introduces a mixture of atomized gasoline and air into the cylinder. The stroke starts when the piston moves downward from a position near the top of the cylinder. As the piston moves downward, a vacuum, or low-pressure area, is created. During the intake stroke, one of the ports is opened by moving the inlet valve. The exhaust valve remains tightly closed.Compression strokeAs the piston moves upward to compress the fuel mixture trapped in the cylinder, the valves are closed tightly. This compression action heats the air/fuel mixture slightly and confines it within a small area called the combustion chamber.Power strokeJust before the piston reaches the top of its compression stroke, an electrical spark is introduced from a spark plug screwed into the cylinder head.The spark ignites the compressed, heated mixture of fuel and air in the combustion chamber to cause rapid burning. The burning fuel produces intense heat that causes rapid expansion of the gases compressed within the cylinder. This pressure forces the piston downward. The downward stroke turns the crankshaft with great force.Exhaust strokeJust before the bottom of the power stroke, the exhaust valve opens. This allows the piston, as it moves upward, to push the hot, burned gases out through the open exhaust valve.Then, just before the piston reaches its highest point, the exhaust valve closes and the inlet valve opens. As the piston reaches the highest point in the cylinder, known as TDC, it starts back down again. Thus, one cycle ends and another begins immediately.2.1.4 Engine Overall MechanicsThe engine has hundreds of other parts . The major parts of engine are engine block , engine heads, pistons, connecting rods, crankshaft and valves. The other parts are joined to make systems. These systems are the fuel system, intake system, ignition system, cooling system, lubrication system and exhaust system. Each of these systems has a definite function. These systems will discussed in detail later.NEW WORDPiston 活塞Connecting rod 连杆Crankshaft 曲轴Power stoke 活塞行程Expel 排出Valve 气阀inlet(intake) valve 进气阀exhaust valve 排气阀term 术语TDC 上止点BDC 下止点Bore 缸径swept volume 有效容积engine capacity 发动机排量clearance volume 余隙容积,燃烧室容积compression ratio 压缩比revolution 旋转,转数every other 每隔一个cycle 循环spread over 分布,遍及intake stroke 进气行程compression stroke 压缩行程knock 敲缸,敲打exhaust stroke 排气行程engine block 发动机缸体lubrication 润滑2.2 Engine Block and Cylinder Head2.2.1 Engine BlockThe engine block is the basic frame of the engine. All other engine parts either fit inside it or fasten to it. It holds the cylinders, water jackets, and oil galleries. The engine block also holds the crankshaft, which fastens to the bottom of the block. The camshaft also fits inside the block, except on overhead-cam engines (OHC). In most cars, this block is made of gray iron, or an alloy (mixture) of gray iron and other metals, such as nickel or chromium. Engine blocks are castings.Some engine blocks, especially those in smaller cars, are made of cast aluminum. This metal is much lighter than iron. However, iron wears better than aluminum. Therefore, the cylinders in most aluminum engines are lined with iron or steel sleeves. These sleevesare called cylinder sleeves. Some engine blocks are made entirely of aluminum.2.2.2 Cylinder HeadThe cylinder head fastens to the top of the block, just as a roof fits over a house. The underside forms the combustion chamber with the top of the piston. The most common cylinder head types are the hemi, wedge, and semi-hemi. All three of these terms refer to the shape of the engine's combustion chamber. The cylinder head carries the valves, valve springs and the rockers on the rocker shaft, this part of the valve gear being worked by the push-rods. Sometimes the camshaft is fitted directly into the cylinder head and operates on the valves without rockers. This is called an overhead camshaft arrangement. Like the cylinder block, the head is made from either cast iron or aluminum alloy.2.2.3 GasketThe cylinder head is attached to the block with high-tensile steel studs. The joint between the block and the head must be gas-tight so that none of the burning mixture can escape. This is achieved by using cylinder head gasket. This is a sandwich gasket, i.e.a sheet of asbestos between two sheets of copper, both these materials being able to withstand the high temperature and pressures within the engine.2.2.4 Oil Pan or SumpThe oil pan is usually formed of pressed steel. The oil pan and the lower part of the cylinder block together are called the crankcase; they enclose, or encase, the crankshaft. The oil pump in the lubricating system draws oil from the oil pan and sends it to allworking parts in the engine. The oil drains off and runs down into the pan. Thus, there is constant circulation of oil between the pan and the working parts of the engine.New Wordsengine block 缸体cylinder head 气缸盖fasten 使固定water jacket 水套oil gallery 油道camshaft 凸轮轴overhead-cam(OHC) 顶置凸轮gray iron 灰铸铁alloy 合金nickel 镍chromium 铬casting 铸件head cover 汽缸盖罩intake manifold 进气总管distributor 分电器oil pan 油底壳aluminum 铝be lined with 镶有cylinder sleeve 气缸套hemi 半球形wedge 楔型，楔入semi-hemi 准半球形rocker 摇臂push-rod 推杆gasket 衬垫high-tensile 高强度的stud 螺栓gas-tight 密封的asbestos 石棉crankcase 曲轴箱，曲柄箱encase 封闭，把…包起来drain off 排出，流出Review Question1.What do TDC, BDC, stroke, compression ratio and engine capacity stand for?2.How do you calculate swept volume and compression ratio?3.What controls the length of the stroke?4.List the main parts of the engine overall mechanics?5.What are the main function of the engine block?2.3 Piston Connecting Rod and Crankshaft2.3.1 Piston AssemblyThe piston is an important part of a four-stroke cycle engine. Most pistons are made from cast aluminum. The piston , through the connecting rod, transfers to the crankshaft the force create by the burning fuel mixture. This force turns the crankshaft .Thin, circular , steel bands fit into grooves around the piston to seal the bottom of the combustion chamber. These bands are called piston rings. The grooves into which they fit are called ring grooves. A piston pin fits into a round hole in the piston . The piston pin joins the piston to the connecting rod . The thick part of the piston that holds the piston is the pin boss.The piston itself , its rings and the piston pin are together called the piston assembly.2.3.2.PistonTo withstand the heat of the combustion chamber, the piston must be strong. It also must be light, since it travels at high speeds as it moves up and down inside the cylinder. The piston is hollow. It is thick at the top where it take the brunt of the heat and the expansion force. It is thin at the bottom, where there is less heat. The top part of the piston is the head , or crown . The thin part is the skirt The sections between the ring grooves are called ring lands.The piston crown may be flat , concave ,dome or recessed . In diesel engine , the combustion chamber may be formed totally or in part in the piston crown , depending on the method of injection . So they use pistons with different shapes.2.3.3Piston RingsAs Fig.2-9 shows , piston rings fit into ring grooves near the of the piston. In simplest terms, piston rings are thin, circular pieces of metal that fit into grooves in the tops of the pistons.In modern engines ,each piston has three rings. (Piston in older engines sometimes had four rings, or even five.) The ring’s outside surface presses against the cylinder walls. Rings provide the needed seal between the piston and the cylinder walls. That is, only the rings contact the cylinder walls. The top two rings are to keep the gases in the cylinder and are called compression rings. The lower one prevents the oil splashed onto the cylinder bore from entering the combustion chamber , and is called an oil ring. Chrome-face cast-iron compression rings are commonly used in automobile engines. The chrome face provide a very smooth , wear-resistant surface.During the power stoke , combustion pressure on the combustion rings is very high. It causes them to untwist . Some of the high-pressure gas gets in back of the rings. This force the ring face into full contact with the cylinder wall. The combustion pressure also holds the bottom of the ring tightly against the bottom of the ring groove. Therefore , high combustion pressure causes a tighter seal between the ring face and the cylinder wall.2.3.4 Piston PinThe piston pin holds together the piston and the connecting rod . This pin fits into the piston pin holes and into a hole in the top end of the connecting rod. The top end of is much smaller than the end that fits on the crankshaft . This small end fits inside the bottom of the piston . The piston pin fits through one side of the piston , through the small end of the rod , and then through the other side of the piston . It holds the rod firmly in place in the center of the piston. Pins are made of high-strengh steel and have a hollow center . Many pins are chrome-plated to help them wear better.2.3.3 Connecting rodThe connecting rod is made of forgedhigh-strength steel . It transmits and motion from the piston to the crankpin on the crankshaft . The connecting rod little end is connected to the piston pin . A bush made from a soft metal , such as bronze , is used for this joint . The lower end of the connecting rod fits the crankshaft journal . This is called the big end . For this big-end bearing , steel-backed lead or tin shell bearing are used . These are the same as those used for the main bearings . The split of the big end is sometimes at an angle , so that it is small enough to be withdrawn through the cylinder bore . The connecting rod is made from forged alloy steel .2.3.5 CrankshaftThe crankshaft , in conjunction with the connecting rod , coverts the reciprocating motion of the piston to the rotary motion needed to drive the vehicle . It is usually made from carbon steel which is alloyed with a small proportion of nickel .The main bearingjournals fit into the cylinder block and the big end journals align with the connecting rods .At the rear end of the crankshaft is attached the flywheel , and at the front end are the driving whells for the timing gears , fan , cooling water and alternator .The throw of the crankshaft , the distance between the main journal and the big end centers , controls the length of the stroke . The stroke is double the throw , and the stroke-length is the distance that the piston travels from TDC to BDC and vice versa .2.3.6 FlywheelThe flywheel is the made from carbon steel . It fit s onto the rear of the crankshaft . As well as keeping the engine rotating between power strokes it also carries the clutch , which transmits the drive to the transmission , and has the starter ring gear around its circumference . There is only one working stroke in four so a flywheel is needed to drive the crankshaft during the time that the engine is performing the non-power strokes .New WordsComprise 由。

汽车专业英语专业英语一automobile 汽车（美）assembly line 装配线petroleum refining石油提炼body and frame 车身与车架engine发动机、引擎drive line 传动系统running gear 控制装置suspension 悬架系统unitized body 承载式车身gasoline engine 汽油机diesel engine 柴油机gas turbine 燃气轮机battery 电池（组）fuel cell 燃料电池hybrid power混合动力系统piston 活塞rotary engine 转子发动机vehicle 车辆transmission 变速器drive shaft 传动轴differential 差速器rear axle 后轴rear-wheel drive 后轮驱动front-wheel drive 前轮驱动braking system 制动系统wheel 车轮tire 轮胎steering system 转向系统spring 弹簧shock absorber 减震器Macpherson strut 麦弗逊式悬架torsion bar 扭力杆strut rod 支撑杆stabilizer bar 横向稳定杆二internal combustionengine 内燃机external combustionengine 外燃机fuel 燃料steam engine 蒸汽机intermittent combustionengine 间隔燃烧式发动机continuous combustionengine 连续燃烧式发动机turbine engine 涡轮发动机rocket engine 火箭发动机jet engine 火箭发动机Wankel engine 汪克尔发动机、转子发动机stroke 行程cooling system 冷却系统仅供学习与交流，如有侵权请联系网站删除谢谢2fuel system 燃料系统ignition system 点火系统spark-ignition engine 火花点燃式发动机compression-ignition engine 压燃式发动机liquid-cooled 水冷式（液体冷却）air-cooled 风冷式（空气冷却）三cylinder block 缸体cylinder 气缸connecting rod 连杆crankshaft 曲轴cylinder head 气缸盖combustion chamber燃烧室valve 气门、阀camshaft 凸轮轴flywheel 飞轮intake manifold 进气歧管exhaust manifold 排气歧管carburetor 化油器fuel injector 燃料喷射器cast iron 铸铁aluminum 铝cooling fluid 冷却液spark plug 火花塞intake valve 排气门cam 凸轮gear 齿轮belt 皮带chain 链条overhead camshaft（OHC）上置式凸轮轴rpm=revolutions perminute 转速、转数每分钟horsepower 马力intake system 进气系统sensor 传感器oxygen sensor 氧传感器fuel induction燃料吸入系统四fuel tank 油箱fuel line 燃料管路fuel pump 燃料泵fuel filter燃料滤清器power train controlmodule（PCM）动力系统控制模块fuel injection system 燃料喷射系统distributor 分电器ignition coil 点火线圈ignition wire 点火线路charging system 充电系统ignition switch 点火开关solenoid 电磁线圈starter motor 起动电机alternator 交流发电机仅供学习与交流，如有侵权请联系网站删除谢谢3voltage regulator 稳压器lubrication system润滑系统oil pump 机油泵oil filter 机油滤清器oil cooler 机油冷却器antifreeze 防冻液coolant pump 冷却液泵thermostat 节温器radiator 散热器、水箱clutch 离合器radiator overflow tank 散热器溢流箱、膨胀水箱air intake ducting 进气管air filter 空气滤清器manifold air pressure sensor 进气歧管压力传感器turbocharger 涡轮增压器muffler 消声器、消音器catalytic converter 催化转化器exhaust pipe 排气管pollution control system排放控制系统carbon monoxide 一氧化碳nitrogen oxide 氮氧化物hydrocarbons 碳氢化合物carbon canister 碳罐exhaust gas recirculator（EGR）废气再循环positive crankcase ventilation强制曲轴箱通风diverter valve 分流阀vapor-liquid separator 气液分离器vacuum modulator 真空调节器五timing 正时、定时air-fuel ratio 空燃比stoichiometric ratio 理论空燃比mixture 混合气top dead center（TDC）上止点bottom dead center（BDC）下止点bore 气缸直径、孔径crankpin 连杆轴颈、曲柄销throw 曲柄半径displacement 排量compression ratio 压缩比four-stroke engine 四冲程发动机intake stroke 进气冲程compression stroke 压缩冲程power stroke 做功行程exhaust stroke 排气行程preignition 提前点火valve overlap 气门重叠六仅供学习与交流，如有侵权请联系网站删除谢谢4two-stroke engine 二冲程发动机truck 货车、卡车bus 公共汽车Mercedes-Benz 梅赛德斯奔驰pickup truck 皮卡camper 露营车travel trailer 旅行拖车high-pressure injection 高压喷射low-pressure injection低压喷射injector 喷油器、喷嘴psi 磅/平方英寸（英制压强单位）photochemical smog 光化学烟雾outboard motor 舷外发动机snowmobile 摩托雪橇chain saw 链锯、电锯reed valve 簧片阀lubricant 润滑剂、润滑油scavenging 扫气General Motors 通用汽车blower 扫气泵rotor 转子coal-fired 燃煤的、烧煤的nuclear-powered 核动力的drivability 动力性、驱动性能generator 发电机transaxle 变速差速器、联合传动器electronic controller 电子控制器downshift 降档manual transmission 手动变速器hydrogen 氢carbon dioxide 二氧化碳oxygen 氧methanol 甲醇spacecraft 航天器、宇宙飞船anode 正极、阳极cathode 阴极、负极七oil pan 油底壳、机油盘water jacket 水套cylinder sleeve 气缸套dry sleeve 干缸套wet sleeve 湿缸套warpage 变形liner 衬套、衬垫bearing 轴承harmonic balancervibration damper 扭转减震器timing gear 正时齿轮connecting rod journal 连杆轴颈仅供学习与交流，如有侵权请联系网站删除谢谢5main(bearing)journal主轴颈counterweight 平衡重thrust surface 推力面drive flange 传动法兰盘、凸缘fillet 圆角nose （曲轴）前端pulley 皮带轮air conditioning 空调bearing cap 轴承盖copper 铜lead 铅Babbitt 巴氏合金tin 锡bearing clearance 轴承间隙thrust bearing 推力轴承、止推轴承thrust washer 推力垫圈、止推垫圈piston ring 活塞环compression ring 气环oil control ring 油环piston pin 活塞销lock ring 锁环piston land 活塞顶部heat dam 绝热槽piston head 活塞头部piston skirt 活塞裙部ring groove 活塞环槽piston pin bushing 活塞销衬套ring end gap 活塞销开口间隙ductile iron 球墨铸铁chromium 铬molybdenum 钼torsional ring 扭曲环chrome-plated 镀铬的rod cap 连杆盖bearing insert 轴承衬套八cross-flow head 横流式气缸盖coolant 冷却液head gasket 气缸垫wedge-shapedcombustion chamber 楔形燃烧室hemisphericalcombustion chamber 半球形燃烧室open combustionchamber 开式燃烧室、统一式燃烧室pre-combustion chamber预燃式燃烧室valve seat 气门座valve guide 气门导管retainer 弹簧座valve spring 气门弹簧high-chrome steel 高铬钢stellite 钴铬钨硬质合金keeper 锁紧装置valve stem 气门杆仅供学习与交流，如有侵权请联系网站删除谢谢6lifter 挺柱pushrod 推杆rocker arm 摇臂valve train clearance 气门间隙variable valve timing 可变气门正时九oil pressure regulator 机油压力调节器main oil gallery 主油道oil screen 机油滤网oil pressure sensor 机油压力传感器dashboard 仪表板sump 机油箱、油底壳baffle 挡板gear-type oil pump齿轮油泵rotor oil pump 转子油泵pressure regulator valve 调压阀十water pump 冷却水泵pressure cap 压力水箱盖fan 冷却风扇temperature indicator 温度指示器air-cooled system 风冷系统liquid-cooled system 水冷系统transmission cooler 自动变速箱油冷却器expansion tank 膨胀水箱housing 外壳impeller 叶轮、转子hub 轮毂pulley 皮带轮closed cooling system 闭式冷却系统十一electronic carburetor 电控化油器fuel vapor line 燃油蒸汽管fuel injector pump 喷油泵nozzle 喷嘴、管嘴plastic 塑料fuel cap 油箱盖filler neck 油箱填充口颈fuel metering unit 油量计量装置mechanical fuel pump 机械燃油泵electrical fuel pump 电动燃油泵fuel pressure regulator 燃油压力调节器injector fuel rail 燃油分配管、燃油轨direct injection system直接喷射式燃料系统仅供学习与交流，如有侵权请联系网站删除谢谢7indirect injection system 非直喷式燃料系统port fuel injection （PFI）进气道燃油喷射throttle body injection （TBI）气门体燃油喷射multiple-point fuel injection 多点燃油喷射single-point fuel injection 单点燃油喷射continuous injection 连续喷射十二dry-type air filter 干式空气滤清器exhaust pipe 排气管undercarriage 底盘、下部结构fiberglass 玻璃纤维glass pack muffler 玻璃纤维消声器supercharging system 进气增压系统turbocharger 涡轮增压十三conventional ignitionsystem 传统点火系统primary circuit 初级回路（低压回路）secondary circuit 次级回路（高压回路）ballast resistor 附件电阻、稳流电阻crank 起动、摇转primary winding 初级线圈、一次绕组breaker 断电器secondary winding 次级线圈、二次绕组condenser 电容器arc 电弧distributor cap 分电器盖coil tower 点火线圈顶端接头surge 电涌振荡distributor shaft 分电器轴firing order 点火顺序electronic ignition system电子点火系统semiconductor 半导体electronic spark timing（EST）电子点火正时ignition control（IC）点火控制hight energy ignition（HEI）module 高能点火模块computer-controlled coilignition system 微机控制线圈点火系统electronic ignition（EI）电子点火distributorless ignitionsystem 无分电器点火系统仅供学习与交流，如有侵权请联系网站删除谢谢8ignition module 点火控制模块direct ignition system 直接点火系统cableless EI system 无高压线电子点火系统十四仅供学习与交流，如有侵权请联系网站删除谢谢9。
