Lesson 21 Wafers电子技术专业英语教程
- 格式：ppt
- 大小：263.00 KB
- 文档页数：34
文档推荐
-
LessonFlipFlop电子技术专业英语教程页数:42
-
通信工程专业英语电子版页数:5
-
计算机科学与技术专业课程表页数:15
下载文档原格式
合集下载
电子信息工程专业英语教程 第一课
gates per chip, 1.5 micrometer chip geometries. • 1984: 0.5 micrometer chip geometries.
2020/3/24
《电子信息工程专业英语教程》
17
Company Information
• The vacuum tube is an electron tube from which all or most of the gas has been removed, permitting electrons to move with no or low interaction with any remaining gas molecules.
• Company Information
– Bell Laboratories
– Texas Instruments – Intel Corporation
2020/3/24
《电子信息工程专业英语教程》
3
Terminology
2020/3/24
《电子信息工程专业英语教程》
4
Transistor vs. vacuum tube
chip geometries. • 1971: 16-bit Microprocessors are introduced. • 1980's: Very Large Scale Integration (VLSI), over 5000 gates per chip. • 1981: Very High Speed Integration (VHSIC), tens' of thousands of
creation of integrated circuits that had previously been made from multiple discrete components. • VLSI：Very Large-scale Integration 超大规模集成(电 路) • VLSI circuits can contain millions of transistors.
2020/3/24
《电子信息工程专业英语教程》
17
Company Information
• The vacuum tube is an electron tube from which all or most of the gas has been removed, permitting electrons to move with no or low interaction with any remaining gas molecules.
• Company Information
– Bell Laboratories
– Texas Instruments – Intel Corporation
2020/3/24
《电子信息工程专业英语教程》
3
Terminology
2020/3/24
《电子信息工程专业英语教程》
4
Transistor vs. vacuum tube
chip geometries. • 1971: 16-bit Microprocessors are introduced. • 1980's: Very Large Scale Integration (VLSI), over 5000 gates per chip. • 1981: Very High Speed Integration (VHSIC), tens' of thousands of
creation of integrated circuits that had previously been made from multiple discrete components. • VLSI：Very Large-scale Integration 超大规模集成(电 路) • VLSI circuits can contain millions of transistors.
Lesson 12 Oscilloscope电子技术专业英语教程
2010-1-1
《电子技术专业英语教程》
6
The concept of oscilloscopes
The word "oscilloscope" has evolved to describe any of a variety of electronic instruments used to observe, measure, or record transient physical phenomena and present the results in graphic form. Perhaps the popularity and usefulness of the oscilloscope spring from its exploitation of the relationship between vision and understanding.
Structure Reading/writing techniques
2010-1-1
《电子技术专业英语教程》
13
Vocabulary
2010-1-1
《电子技术专业英语教程》
14
evolve in dictionary
– vi. 进展, 进化, 展开
evolve as (逐渐)成为 evolve from 从...进化而来 evolve into 发展[进化]成
Text tour
Outline
– The concept of oscilloscopes – The prototypical oscilloscopes – Examples of oscilloscopes test – The basic principles of oscilloscopes – Applications
Unit 2电子技术专业英语
电子技术专业英语
》》
UNIT TWO
Part Three
Inductors
电感
An inductor is an electrical device, which can temporarily store electromagnetic energy in the field about it as long as current is flowing through it. The inductor is a coil of wire that may have an air core or an iron core to increase its inductance. A powered iron core in the shape of a cylinder may be adjusted in and out of the core.
（原文片段） 原文片段）
电子技术专业英语
》》
UNIT TWO
Part One
Resistors
第一部分 电阻器
电阻
电阻器是一种电子元件，它能阻碍电流的流动。 电阻器是一种电子元件，它能阻碍电流的流动。在电阻器中流过的电 流与加在电阻两端的电压成正比，与电阻的阻值成反比。 流与加在电阻两端的电压成正比，与电阻的阻值成反比。这就是欧姆定 律，可以用公式表示成 I = U R / R 。电阻器一般是线性元件，它的 电阻器一般是线性元件， （伏安）特性曲线形成一条直线。 伏安）特性曲线形成一条直线。 电阻器常用做限流器， 电阻器常用做限流器，限制流过元件的电流以防止元件因流过的电 流过大而烧坏。电阻器也可用做分压器，以减少其他电路的电压， 流过大而烧坏。电阻器也可用做分压器，以减少其他电路的电压，如晶 体管偏置电路。电阻器还可以用做电路的负载。 体管偏置电路。电阻器还可以用做电路的负载。
电子专业英语lesson21-DSP
electrocardiograph[ilektrəʊ'kɑ:diəʊgrɑ:f] 心电图，心电图仪
电源示波器
• The signal is often strongly affected by “main pickup” due to electrical interference from the [,intə'fiərəns] mains supply. 市电电源 干扰，干涉 • Processing the signal using a filter circuit can remove or at least reduce the unwanted part of the signal. 滤波器
单元，电池
• DSP signal compression technology allows people not only to talk to one another by telephone but also to see one another on the screens of their PCs, using small video cameras mounted on the computer monitors, with 摄像机 only a conventional telephone line linking them together.
股票 信息流 遥感
[træ ns'dju:sə] 传感器，转换器
• In many cases, the signal is initially in the form of an analog electrical voltage or current, produced for example by a microphone or some other types of transducer. • In some situations the data is already in digital form – such as the output from the readout system of a CD (compact disc) player.
电源示波器
• The signal is often strongly affected by “main pickup” due to electrical interference from the [,intə'fiərəns] mains supply. 市电电源 干扰，干涉 • Processing the signal using a filter circuit can remove or at least reduce the unwanted part of the signal. 滤波器
单元，电池
• DSP signal compression technology allows people not only to talk to one another by telephone but also to see one another on the screens of their PCs, using small video cameras mounted on the computer monitors, with 摄像机 only a conventional telephone line linking them together.
股票 信息流 遥感
[træ ns'dju:sə] 传感器，转换器
• In many cases, the signal is initially in the form of an analog electrical voltage or current, produced for example by a microphone or some other types of transducer. • In some situations the data is already in digital form – such as the output from the readout system of a CD (compact disc) player.
电子信息工程专业英语教程Lesson3Microprocessors
• 流水线是一种在前一条指令全部执行完之前就开始取下一条指 令，以提高处理速度的技术。
2024/8/6
7
A brief summary of all Pentium families
2024/8/6
8
• Pentium 4 - Introduced in 2000 (1.4-3.4GHz)
Latest Pentium architecture started out with a 400MHz system bus and 256KB L2 cache (later increased to 800MHz and 2MB). The first models contained 42 million transistors, used the 0.18 micron process and came in 423pin and 478-pin PGA packages. Intel's first Pentium 4 chipset was the 850 and supported only Rambus memory (RDRAM), but subsequent chipsets switched to DDR SDRAM.
• Difference
– Transistors – Microns – Clock speed – Data width – MIPS
2024/8/6
15
Brief introduction
Intel 4004
2024/8/6
Pentium IV
16
Brief introduction
Intel 4004
• Pentium II Xeon - 1998-1999 (400MHz-450MHz) Typically used in high-end and 2-way and 4-way servers, Xeon specs were like Pentium II with L2 cache from 512KB to 2MB and 100MHz system bus.
2024/8/6
7
A brief summary of all Pentium families
2024/8/6
8
• Pentium 4 - Introduced in 2000 (1.4-3.4GHz)
Latest Pentium architecture started out with a 400MHz system bus and 256KB L2 cache (later increased to 800MHz and 2MB). The first models contained 42 million transistors, used the 0.18 micron process and came in 423pin and 478-pin PGA packages. Intel's first Pentium 4 chipset was the 850 and supported only Rambus memory (RDRAM), but subsequent chipsets switched to DDR SDRAM.
• Difference
– Transistors – Microns – Clock speed – Data width – MIPS
2024/8/6
15
Brief introduction
Intel 4004
2024/8/6
Pentium IV
16
Brief introduction
Intel 4004
• Pentium II Xeon - 1998-1999 (400MHz-450MHz) Typically used in high-end and 2-way and 4-way servers, Xeon specs were like Pentium II with L2 cache from 512KB to 2MB and 100MHz system bus.
电子与通信工程专业英语Unit 21
许多新的卫星(电视)系统以及DVD，是采用可以提供十分清晰图像的数字编码 机制。这种系统中，数字信息被转换成模拟格式，以便显示在模拟电视机上。与 VHS式图像相比，这种图像很清晰，但如果不把这些图像转换成模拟格式，图像 将会更加清晰。
There is now a big push underway to convert all TV sets from analog to digital, so that digital signals drive your TV set directly.
Digital Television & Liquid Crystal Display
Translation Reading More Translating skills Text
Digital Television & Liquid Crystal Display
1. Digital TV The horizontal resolution is something like 500 dots for a color analog TV set. This level of resolution was amazing 50 years ago, but today it is rather passe. The lowest resolution computer monitor that anyone uses today has 640×480 pixels, and most people use a resolution like 800×600 or 1024×768. We have grown comfortable with the great clarity and solidity of a computer display, and analog TV technology pales by comparison.
There is now a big push underway to convert all TV sets from analog to digital, so that digital signals drive your TV set directly.
Digital Television & Liquid Crystal Display
Translation Reading More Translating skills Text
Digital Television & Liquid Crystal Display
1. Digital TV The horizontal resolution is something like 500 dots for a color analog TV set. This level of resolution was amazing 50 years ago, but today it is rather passe. The lowest resolution computer monitor that anyone uses today has 640×480 pixels, and most people use a resolution like 800×600 or 1024×768. We have grown comfortable with the great clarity and solidity of a computer display, and analog TV technology pales by comparison.
电子科学与技术专业英语资料
电子科学与技术专业英语复习资料一，单词翻译（20 分）heterojunction collector junction发射结emitter junction 基区base region肖特基接触schottky contact 复合recombination固相扩散Solid phase diffusion 多晶硅polycrystalline微波器件microwave devices 损耗depletion漏电流leakage current 多数载流子majority - carrier少数载流子minority - carrier 封装package电阻resistance 电流current电流密度current density 电压voltage输入端input port 输出端output port近红外near-infrared 紫外ultraviolet传输模式transport form 饱和电流saturation currents光学吸收optical absorption 受激辐射stimulated emission自发辐射spontaneous emission二、阅读理解（20 分）三、段落翻译（40 分）1、The unfolding story of solid-state electronics can be told rather completely in terms of evolving fabrication technology, constantly expanding the number of options available to the device and integrated-circuit designer. It was for technological reasons that an early and important kind of BJT was a germanium PNP device. The term PNP labels the conductivity types of the three regions within a BJT, regions separated by two PN junctions. In later years, and again partly for technological reasons, the dominant BJT was a silicon NPN device. In integrated circuits today, the combination of silicon NPN and PNP devices is a growing practice because the resulting complementary circuits have important power-dissipation and performance advantages. For convenience and consistency, however, and because of its continuing importance, the silicon NPN BJT will be the vehicle for this chapter.根据制备技术的进化，给器件和集成电路设计者的可用选择数不断扩展，使得固态电子学的演变故事可以描述得更为完整。
电子信息工程专业英语28SignalSources
2024/8/6
《电子信息工程专业英语教程》
14
Basic Signal Source Applications
stress/margin test
• Stressing Communication Receivers
Engineers working with serial data stream architectures (commonly used in digital communications buses and disk drive amplifiers) need to stress their devices with impairments, particularly jitter and timing violations. Advanced signal sources save the engineer untold hours of calculation by providing efficient built-in jitter editing and generation tools. These instruments can shift critical signal edges as little as 0.3 ps.
– Full range 满量程
– Troubleshooting 发现并修理故障
– DMM: Digital Multimeter 数字多用表
– UUT: Unit Under Test 被测设备
2024/8/6
《电子信息工程专业英语教程》
3
Backgrounds
• Terminology
– AWG: Arbitrary Waveform Generator 任意波形发生器
电子信息专业英语(第二版)课件：科技英语基础知识(一)
科技英语基础知识(一)
例4 If we consider binary transmission， the complete information about a particular message will always be obtained by simply detecting the presence or absence of pulse.
(7) 词语上，力求短小精悍，常用复合词。
科技英语基础知识(一)
(8) 文章结构上，力求层次分明，多用连接词，例如: first，secondly，thirdly，then，thus，therefore，hence， further，furthermore，moreover，besides，in addition， while，meanwhile，in the meantime，at the same time， whereas，also，at last，finally，in conclusion，as a result， consequently，in order to，however nevertheless, in fact， as a matter of fact，in other words，in a word，summarily， as a rule，generally，generally speaking，broadly speaking， in general
result，unit，value，area，field，method，effect，distance， limit，period，direction
代词: other，such，that，this，their，these，which，it， its，itself
LessonMoore#;slaw电子技术专业英语教程
2020/4/10
9
The origins of Moore's Law
• The part of Moore's original 1965 paper that's …
• Moore was ultimately interested…
2020/4/10
10
The effects of Moore's Laws
• A worldwide silicon fab network… • The world's first 32nm silicon technology… • The world's first 2-billion transistor microprocessor… • Revolutionary technologies on a chip… • Advanced research …
• 过去的四十年里，计算机从神秘不可近的庞然大物成 为多数人都不可或缺的工具，信息技术由实验室进入 无数个普通家庭。因特网将全世界联系起来，多媒体 视听设备丰富着每个人的生活。
2020/4/10
16
Mystery in use
[英古] 手工艺; 行会; 行业 • the art and mystery of . ...的技艺和手艺(学徒满期证书上用语) • president of the -ries of the workers in iron • 铁工工会会长
能源、环境和纳米技术
memory capacity
• 存储容量是指电子器件最大所能存储的数据量，是便 携存储产品最为关键的参数。 一般便携存储的容量有16MB、32 MB、64 MB、128 MB、256 MB、512 MB、1GB、2GB。
电子类专业英语电子教案第一课
• This depletion zone controls the behaviours of the diode and permits current to flow predominantly in only one direction. • When the p-type region of the p-n junction is connected to the positive terminal of a power supply, current will flow and this is said to be forward bias. • However, when the terminals of a power supply are reversed, there will be a tiny current through the diode and this is called reverse bias.
• • • • • • • •
transistor [ træn'zistə ] n. 晶体（三极）管 depletion [ di'pli:ʃən ] n. 耗散 doping [ 'dəupiŋ ] n. (半导体)掺杂(质) germanium [ dʒə:‘meiniəm ] n. 锗 silicon [ ‘silikən ] n. 硅 thyristor [ θai‘ristə ] n. 闸流晶体管 gain [ gein ] n. 增益；获得 v. 得到；增进 photosensitive [ .fəutəu‘sensitiv ] a. 光灵 敏的；感光性的
• The limiting voltages and currents permissible must be considered in practical application. For example, when used for rectification, the diodes have to withstand a reverse voltage. If the diodes are not chosen properly, they will be broken down.
Lesson 20 Flip-Flop电子技术专业英语教程
• The name flip-flop was later derived from the sound produced on a speaker connected to one of the back coupled amplifiers outputs during the trigger process within the circuit.
2020/10/21
5
Flip-flop’s invention
• The first electronic flip-flop was invented in 1918 by William Eccles and F. W. Jordan.
• It was initially called the Eccles-Jordan trigger circuit and consisted of two active elements.
• The more advanced clocked devices are specially designed for synchronous systems; such devices therefore ignore its inputs except at the transition of a dedicated clock signal.
2020/10/21
4
Flip-flop
• In digital circuits, a flip-flop is a term referring to an electronic circuit (a bistable multivibrator) that has two stable states and thereby is capable of serving as one bit of memory.
2020/10/21
5
Flip-flop’s invention
• The first electronic flip-flop was invented in 1918 by William Eccles and F. W. Jordan.
• It was initially called the Eccles-Jordan trigger circuit and consisted of two active elements.
• The more advanced clocked devices are specially designed for synchronous systems; such devices therefore ignore its inputs except at the transition of a dedicated clock signal.
2020/10/21
4
Flip-flop
• In digital circuits, a flip-flop is a term referring to an electronic circuit (a bistable multivibrator) that has two stable states and thereby is capable of serving as one bit of memory.
Lesson 02 Moore与#39;s law电子技术专业英语教程
• 由于1958年集成电路的发明，晶体管的数量在集成电 路中潜在的增长，大约每两年增加一倍。
2020/10/21
19
Doubling in use
• frequency doubling 倍频
• ice doubling 破冰加强板
• somatic doubling 体细胞(染色体)加倍
• successive doubling 顺次加 倍
• Transistors per integrated circuit… • Cost per transistor… • Computing performance per unit cost … • Power consumption …
2020/10/21
11
The future of Moore's Law
14
Mystery in dictionary
• Something that is not fully understood or that baffles or eludes the understanding; an enigma: 秘密，谜：不能被完全理解或在理解上困难或困惑的事物；谜语：
2020/10/21
15
Mystery in text
• Moore's Law summed up the pace of progress in information technology. In the past 40 years, the computer has become an indispensable tool for the majority of people instead of the mystery of the monster
2020/10/21
19
Doubling in use
• frequency doubling 倍频
• ice doubling 破冰加强板
• somatic doubling 体细胞(染色体)加倍
• successive doubling 顺次加 倍
• Transistors per integrated circuit… • Cost per transistor… • Computing performance per unit cost … • Power consumption …
2020/10/21
11
The future of Moore's Law
14
Mystery in dictionary
• Something that is not fully understood or that baffles or eludes the understanding; an enigma: 秘密，谜：不能被完全理解或在理解上困难或困惑的事物；谜语：
2020/10/21
15
Mystery in text
• Moore's Law summed up the pace of progress in information technology. In the past 40 years, the computer has become an indispensable tool for the majority of people instead of the mystery of the monster
电子科学与技术_专业英语_第三章大部分翻译
电子科学与技术专业英语第三章大部分翻译（P139）3.1晶界生长与外延正如前面第一章所讨论的那样，在分立器件和集成电路中最重要的两种半导体是硅和砷化镓，在这一章我们叙述这两种半导体的常用的单晶生长技术，基本的工艺流程是从原料到抛光晶片，原料经过化学处理做成一个用来生长单晶的高纯多晶半导体。
单晶硅锭铸形，以定义材料的直径，这些晶片经过腐蚀和抛光来提供一个光滑的特定的且器件将做在上面的表面。
一种和单晶生长密切相关的技术包含一个单晶半导体层在一个单晶半导体衬底的生长，这叫外延，它是从希腊语epi和taxis得来的，外延工艺提供了一种重要的控制掺杂形貌的技术，以至于器件和电流性能可以被优化。
例如，一个掺杂浓度相称低的半导体层可以在一个同型掺杂而浓度很高的衬底外延生长，通过这种方式和衬底相关联的体电阻将被充分地减少，许多新的器件结构，特别是微波和光学器件，可以通过外延工艺制得。
在这章的后面我们将考虑讨论一些重要外延生长技术。
（p140）3.2从熔体生长单晶从熔体生长单晶有两种基本方法，直拉法和布里奇曼法，用于半导体行业的充足百分比的硅单晶是通过直拉法制备的，实际上所有的用于集成电路制造的硅都是用这方法制备的。
大部份的砷化镓，在另一方面，是通过布里奇曼法生长的。
然而，直拉法在生长大直径的砷化镓方面变得越来越流行。
3.2.1原始材料硅的起始材料是一种相当纯的叫做石英的沙子形式。
它和各种形式的碳被置于炉中，当很多反应在炉中发生时，总的反应式是SI+SIO2=这种工艺生产出纯度98%的冶金及的硅。
下一步，硅被磨碎和氯化氢反应生成三氯氢硅（SIHCL3）SI + 2HCL三氯氢硅在温室下是液体，液体分馏除去不要的杂质，净化过后的SIHCL3用于与氢气反应。
制备电子级的硅（EGS）：SIHCL3+这个反应在包括为硅的沉积提供晶体成核点的电阻加热硅棒的反应堆中发生，纯度为电子级别的硅，也就是一个高纯的多晶硅材料，是用于制备器件级质量的单晶硅的未加工材料。
电子科学与技术专业外语全译文样本
Semiconductor Materials• 1.1 Energy Bands and Carrier Concentration• 1.1.1 Semiconductor Materials固态材料可分为三种: 绝缘体、半导体和导体。
图1－1 给出了在三种材料中一些重要材料相关的电阻值( 相应电导率ρ≡1/δ)。
绝缘体如熔融石英和玻璃具有很低电导率, 在10-18 到10-8 S/cm;导体如铝和银有高的电导率, 典型值从104到106S/cm;而半导体具有的电导率介乎于两者之间。
半导体的电导率一般对温度、光照、磁场和小的杂质原子非常敏感。
在电导率上的敏感变化使得半导体材料称为在电学应用上为最重要的材料。
早在19世纪人们已经开始研究半导体材料。
多年来人们研究了很多半导体材料。
表1给出了与半导体相关的周期表中的部分元素。
由单种元素组成的单质半导体如硅和锗在第Ⅳ族。
而大量的化合物半导体有两个甚至更多元素组成。
如GaAs是Ⅲ-Ⅴ化合物是由Ⅲ族的Ga和Ⅴ族的As化合而得。
在1947年双极晶体管创造之前, 半导体仅用作双极型器件如整流器和光敏二极管。
早在20世纪50年代, 锗是主要的半导体材料。
然而锗不太适合在很多方面应用因为温度适当提高后锗器件会产生高的漏电流。
另外, 锗的氧化物是水溶性的不适合器件制作。
因此20世纪60年代实际上锗被硅所取代, 事实上硅替代锗成为半导体制作的材料之一。
我们用硅材料的主要原因有硅器件存在非常低的漏电流且能够经过热法生长出高质量的二氧化硅。
器件级硅成本远少于其它半导体材料。
硅以硅石和硅酸盐形式存在并占地球地表层的25％, 而且硅元素在分布中排在氧之后的第二位。
当今硅是在元素周期表中研究最多的元素; 硅技术是在所有半导体技术中最先进的。
有很多化合物半导体具有硅所缺少的电光性能。
这些半导体特别是GaAs主要用作微波和光学应用。
虽然我们了解化合物半导体技术不如硅材料的多, 但化合物半导体技术由于硅技术的发展而发展。
电子信息工程专业英语教程__ Lesson 4 Operational Amplifiers
• µA709 - the first commercially successful IC op amp
• µA741 followed the µA709 • a never-ending series of new op amps released
each year since then…
2021/9/19
– using graphical methods – a log technique – simple and perceptive – the application of feedback to machines began to grow
2021/9/19
13
Op amps & computer
• Op amps in signal conditioning applications • Op amp survived…
– the analog computers lost favor to digital computers – the demand for op amps increased as measurement
2021/9/19
17
Language in use
• Vocabulary
– underlying , present, graphical , perceptive , passive, predominant
• Structure
– to the point where
• Reading/writing techniques
2021/9/19
3
Terminology
2021/9/19
4
transducer
• µA741 followed the µA709 • a never-ending series of new op amps released
each year since then…
2021/9/19
– using graphical methods – a log technique – simple and perceptive – the application of feedback to machines began to grow
2021/9/19
13
Op amps & computer
• Op amps in signal conditioning applications • Op amp survived…
– the analog computers lost favor to digital computers – the demand for op amps increased as measurement
2021/9/19
17
Language in use
• Vocabulary
– underlying , present, graphical , perceptive , passive, predominant
• Structure
– to the point where
• Reading/writing techniques
2021/9/19
3
Terminology
2021/9/19
4
transducer
