OptiSystem 仿真实例目录1光发送机（Optical Transmitters）设计1.1光发送机简介1.2光发送机设计模型案例：铌酸锂（LiNbO3）型Mach-Zehnder调制器的啁啾（Chirp）分析2光接收机（Optical Receivers）设计2.1光接收机简介2.2光接收机设计模型案例：PIN光电二极管的噪声分析3光纤（Optical Fiber）系统设计3.1光纤简介3.2光纤设计模型案例：自相位调制（SPM）导致脉冲展宽分析4光放大器（Optical Amplifiers）设计4.1光放大器简介4.2光放大器设计模型案例：EDFA的增益优化5光波分复用系统（WDM Systems）设计5.1光波分复用系统简介5.2光波分复用系统使用OptiSystem设计模型案例：阵列波导光栅波分复用器（AWG ）的设计分析6光波系统（Lightwave Systems）设计6.1 光波系统简介6.2 光波系统使用OptiSystem设计模型案例：40G单模光纤的单信道传输系统设计7色散补偿（Dispersion Compensation）设计8.1 色散简介8.2 色散补偿模型设计案例：使用理想色散补偿元件的色散补偿分析8孤子和孤子系统（Soliton Systems）9.1 孤子和孤子系统简介9.2 孤子系统模型设计案例：9结语1 光发送机（Optical Transmitters）设计1.1 光发送机简介一个基本的光通讯系统主要由三个部分构成，如下图1.1所示：图1.1 光通讯系统的基本构成1）光发送机2）传输信道3）光接收机作为一个完整的光通讯系统，光发送机是它的一个重要组成部分，它的作用是将电信号转变为光信号，并有效地把光信号送入传输光纤。
光发送机的核心是光源及其驱动电路。
现在广泛应用的有两种半导体光源：发光二级管（LED）和激光二级管（LD）。
其中LED输出的是非相干光，频谱宽，入纤功率小，调制速率低；而LD是相干光输出，频谱窄，入纤功率大、调制速率高。
