常用电气术语英汉对照表2014-1剖析

Aabort 中断,停止abnormal 异常abrader 研磨,磨石,研磨工具absence 失去Absence of brush 无(碳)刷Absolute ABS 绝对的Absolute atmosphere A TA 绝对大气压AC Lub oil pump 交流润滑油泵absorptance 吸收比,吸收率acceleration 加速accelerator 加速器accept 接受access 存取accomplish 完成,达到accumulator 蓄电池,累加器Accumulator battery 蓄电池组accuracy 准确,精确acid 酸性,酸的Acid washing 酸洗acknowledge 确认,响应acquisition 发现,取得action 动作Active power 有功功率actuator 执行机构address 地址adequate 适当的，充分的adjust 调整，校正Admission mode 进汽方式Aerial line 天线after 以后air 风，空气Air compressor 空压机Air duct pressure 风管压力Air ejector 抽气器Air exhaust fan 排气扇Air heater 空气加热器Air preheater 空气预热器Air receiver 空气罐Alarm 报警algorithm 算法alphanumeric 字母数字Alternating current 交流电Altitude 高度，海拔Ambient 周围的，环境的Ambient temp 环境温度ammeter 电流表，安培计Ammonia tank 氨水箱Ampere 安培amplifier 放大器Analog 模拟Analog input 模拟输入Analog-to-digital A/D 模拟转换Analysis 分析Angle 角度Angle valve 角伐Angle of lag 滞后角Angle of lead 超前角anthracite 无烟煤Anion 阴离子Anionic exchanger 阴离子交换器Anode 阳极，正极announce 通知，宣布Annual 年的，年报Annual energy output 年发电量anticipate 预期，期望Aph slow motion motor 空预器低速马达Application program 应用程序approach 近似值，接近Arc 电弧，弧光architecture 建筑物结构Area 面积，区域armature 电枢，转子衔铁Arrester 避雷器Ash 灰烬，废墟Ash handling 除灰Ash settling pond 沉渣池Ash slurry pump 灰浆泵assemble 安装，组装Assume 假定,采取,担任Asynchronous motor 异步马达atmosphere 大气，大气压Atomizing 雾化Attempt 企图Attemperater 减温器，调温器Attention 注意Attenuation 衰減,减少,降低Auto reclose 自动重合闸Auto transfer 自动转移Autoformer 自耦变压器Automatic AUTO 自动Automatic voltage regulator 自动调压器Auxiliary AUX 辅助的Auxiliary power 厂用电Available 有效的,可用的Avoid 避免,回避Avometer 万用表,安伏欧表计Axial 轴向的Axis 轴,轴线Axis disp protection 轴向位移，保护Axle 轴，车轴，心捧BBack 背后，反向的Back pressure 背压Back wash 反冲洗Back up 支持，备用Back ward 向后Baffle 隔板Bag filter 除尘布袋Balance 平衡Ball 球Ball valve 球阀Bar 巴，条杆Bar screen material classifier 栅形滤网base 基础、根据Base load 基本负荷Base mode 基本方式Batch processing unit 批处理单元Battery 电池Bearing BRG 轴承before 在…之前bell 铃Belt 带，皮带Bend 挠度，弯曲Besel 监视孔BLAS 偏置，偏压Binary 二进制，双Black 黑色Black out 大停电，全厂停电blade 叶片Bleed 放气，放水Blocking signal 闭锁信号Blow down 排污Blowlamp 喷灯blue 蓝色Bms watchdog Bms看门狗，bms监视器boiler BLR 锅炉Boiler feedwater pump BFP 锅炉给水泵Boil-off 蒸发汽化bolt 螺栓bore 孔，腔boost BST 增压，提高Boost centrifugal pump BST CEP 凝升泵Boost pump BP 升压泵Boot strap 模拟线路，辅助程序bottom 底部Bowl mill 碗式磨brash 脆性，易脆的bracket 支架，托架，括号breadth 宽度break 断开，断路breaker 断路器，隔离开关Breaker coil 跳闸线路breeze 微风，煤粉Brens-chluss 熄火，燃烧终结bridge 电桥，跨接，桥形网络brigade 班，组，队，大队broadcast 广播brownout 节约用电brush 电刷，刷子Brush rocker 电刷摇环Brown coal 褐煤Buchholtz protecter 瓦斯保护bucket 斗，吊斗Buffer tank 缓冲箱built 建立bulletin 公告，公报bump 碰，撞击bunker 煤仓burner 燃烧器Burner management system 燃烧器管理系统Bus section 母线段busbar 母线Busbar frame 母线支架buscouple 母联Bypass/by pass BYP 旁路Bypass valve 旁路阀Ccabinet 柜cable 电缆calculator 计算器caliber 管径、尺寸、大小calorie 卡caloric 热的、热量Caloric value 发热量、热值calorific 发热的、热量的Calorific efficiency 热效率cancel 取消、省略capacitance CAPAC 电容Capacitive reactance 容抗capacity 容量、出力、能量card （电子）板、卡carrier 搬运机、载波、带电粒子Carrier protection 高频保护cascade CAS 串级Case pipe 套管casine 壳、箱casual 偶然的、临时、不规则的Casual inspection 不定期检查、临时检查casualty 人身事故、伤亡、故障catastrophe 灾祸、事故Catastrophe failure 重大事故Cat-pad 猫爪cathode 阴板、负极Cathode ray tube CRT 显示器Cation exchanger 阳离子交换器caution 注意Center 中心centigrade 摄氏温标Central control room 中控室Central processing unit CPU 中央处理器Centrifugal 离心的Certificate 证明书、执照Centrifugal fan 离心风机Certification of fitness 合格证书、质量证书Chamber 办公室、会议室Change 改变Channel 通道、频道Character 字符Characteristics 特性、特性曲线Charge 负荷、充电、加注Charge indicator 验电器、带电指示器Chart 图、图线图chassis 底座、机壳Chassis earth 机壳接地Check 检查Check valve CK VLV 截止线、止回线Chemical 化学Chemical dosing 化学加药Chest 室Chief 主要的、首长、首领Chief engineer 总工程师Chief operator 值班长Chimney 烟囱、烟道Chlorine 氯Circuit 电路Circuit breaker 电路断路器Circuit diagram 电路图Circular current 环流Circulating 循环Circulating water pump 循环水泵Circulating cooling water 循环冷却水Clamp 夹具、钳Clarification 澄清Class 类、等级、程度Class of insulation 绝缘等级Clean 清洁的、纯净的Cleanse 净化、洗净、消毒Clear 清除CLEARING OF FAULT 故障清除Clock interface unit CIU 时钟接口单元Clockwise 顺时针、右旋的Close 关闭Closed cooling water 闭式冷却水Closed-loop 闭环Cluster 电池组、组、群Coal 煤Coal ash 煤灰Coal breaker 碎煤机Coal consumption 耗煤量、煤耗Coal crusher 碎煤机Coal handling 输煤设备、输煤装置Coal dust 煤粉Coal-fired power plant 燃煤发电厂Coal hopper 煤斗Coal yard 煤场Coarse 粗的、不精确的Coaxial cable 同轴电缆Code 代号、密码Coil 线圈Coil pipe 蛇形管Cold 冷Cold air 冷风Cold reheater CRH 再热器冷段Cold reserve 冷备用（锅炉）Cold start 冷态启动Cold test 冷态试验Collect 收集Collecting pipe 集水管Collector 收集器Colour 颜色Colour library 颜色库Combin 合并、联合Combustion 燃烧Command 命令、指挥Commission 使投入、使投产Common 共同的、普通的Communication 联系、通讯Commutator 换向器Compensation 补偿Company CO 公司Company limited CO LTD 有限公司Complexity 复杂Complete 完成Component 元件Compress 压缩Compress air 压缩空气Compresser 压缩机Computer 计算机Concrete 混凝土制的Concurrent 同时发生的、一致的Concurrent boiler 直流锅炉Cond press 凝结器压力Condensate 冷凝、使凝结Condensate extraction pump CEP 凝结水泵Condenser COND/CNDER 凝结器Condensive reactance 容抗Condition 条件、状况Conduct 传导Conductivity 导电率Conference 会议、商讨、谈判Congealer 冷却器、冷冻器Configure 组态Connection 联接Connector 联接器、接线盒Console 控制台Consult 商量、咨询、参考Consumption 消费、消耗Consumption steam 汽耗Constant 恒定的Contact 触点Contactor 接触器、触头Contact to earth 接地、触地、碰地Content 目录Contin blwdwn 连排Continuous 连续的Contract 合同Control CNTR/CNTPL 控制Control & instrument 仪控Control loop 控制环Control oil 控制油Control panel 控制盘Controller 控制器Control stage 调节级、控制级Control valve 调节阀Conve cton sh 低温过热器Convection 对流Convertor 运输机、传输机Cool 冷的Cooler 冷却器Cooling 冷却Cooling fan 冷却风机Cooling water pump 冷却水泵Cooling tower 冷却塔Coordinate COORD 协调Coordinate boiler follow mode 协调的锅炉跟随方式Coordinate control system 协调控制系统Coordinate turbine follow mode 协调的汽机跟随方式Copy 拷贝Core 铁心、核心、磁心Core loss 铁（芯损）耗Corner 角落Correction 修正、改正Corrosion 腐蚀Cost 价格、成本、费用Cost of fuel 燃料费用Cost of upkeep 日常费用、维护费用Coupler 联轴器Coupling 耦合、联轴Couple CPL 联轴器Crane 起重机Critical 临界的Critical speed 临界速度Crusher 碎渣机Current transformer CT 电流互感器Cube 立方（体）Cubicle illumination 箱内照明Curdle 凝固Current 电流、当前Cursor 光标Curve 曲线Custom 习惯、海关Custom keys 用户键Cutter 切削工具Cyanic 青色、深蓝色Cycle 循环、周期、周波Cymometer 频率表Cyclome classifier 旋风分离器Cylinder CYL 汽缸DDaily load curve 日负荷曲线Daily load 日负荷Damage 损坏、破坏Damper DMPR 阻尼器、挡板Danger 危险、危险物Dank 潮湿Danger zone 危险区Data 数据Data base 数据库Data acquisition system DAS 数据采集系统Data highway 数据高速公路Date 日期Data pool 数据库Dc lub oil pump 直流润滑油泵Dead band 死区Deaerator DEA/DEAE/DEAER 除氧器Decimeter 分米Decrease DEC 减少Deep 深度、深的、深Default 默认、缺席Degree 度、等级Demand 要求、查问Delay 延迟Delay time 延时Delete 删除Demineralized water 除盐水Demineralizer 除盐装置Deposit 沉积结垢Desalt 除盐设备Description 说明、描述Destination 目标、目的地Desuperheater 减温器Desuperheater water DSH WTE 减温水Detail 细节Detect 发现、检定Deviate 偏离、偏差Device 设备、仪器Diagnosis 诊断Diagram 图形、图表Diagram directory 图目录Diagram number 图形号Diameter 直径Diaphragm 膜片、隔板Dielectric 介质、绝缘的Diesel generator 柴油发电机Difference 差异、差别、差额Differential protection 差动保护Diff press 差压Diff expansion DIFF EXP 胀差Differential pressure DP/DSP 差压Digital 数字的Digital electric hydraulic 电调Digital input/output 数字量输入／输出Digital-to-analog D/A 数／模转换Dioxde 二氧化碳Direct current DC 直流（电）Direct digital control DDC 直接数字控制Disassembly 拆卸Disaster 事故、故障Disc 叶轮Disaster shutdown 事故停机Discharge 排除、放电、卸载Discharge current 放电电流、泄漏电流Disconnector 隔离器、隔离开关Disconnect switch 隔离开关Discrete input/output 离散输入／输出Disk 磁盘Disk manage commands 磁盘管理命令Dispatch 调度、发送派遣Dispatcher 调度员Dispatching station 调度站（局）Disconnector 隔离器、隔离开关Discrete input/output 离散输入／输出Disk 磁盘Displacement 位移Displacement pump 活塞泵Display 显示、列屏Distance 距离Distilled water DISTL WTR 蒸馏水Distributed 分布\分配\配电（水、汽）Distributed control system DCS 集散控制系统Distributed processing unit DPU 分布处理单元Distributing board 配电盘Distribution network 配电网络Distribution substation 二次变电站Disturbance 扰动Diverter vlv 切换线Divided by 除以Design 设计、发明Division 分界、部门Division wall 分割屏Documentation 文件Door 门Dosing pump 加药泵Dowel pin 定位销Down pipe 下降管Download 下载Downtime 停机时间Dozer 推土机Draft 通风、草图Drain DRN 疏水、排放Drain pump 疏水泵Drain tank 疏水箱Drawing 图样、牵引Drill 钻孔、钻头、钻床Drive 驱动、强迫Drn collector 疏水收集器Drop 站Drowned pump 潜水泵Drum 汽包Drum-type boiled 汽包式锅炉Dry 干、干燥Dual 双重的Duct 风道、管道Dust 灰尘Dust helmet 防尘罩Dust catcher 除尘器、吸尘器Duty 责任Dynamic 动态的Dynamometer 功率表EEarth 大地Earth fault 接地故障Earth connector 接地线、接地Earth lead 接地线、接地Eccentricity 偏心、扰度Econ recirc vlv 省煤器再循环线Economizer ECON 省煤器Edit 编辑Efficiency 效率Eject pump 射水泵Ejection 射出Ejector 抽气器Electric 电的Elbow 弯管、弯头Electric-hydraulic control 电／液控制Electrical 电的、电气的Electrical lockout solenoid vlv 电磁阀锁阀Electrical machine 电机Electrical service 供电Electric power industry 电力工业Electrode 电极Electric power company 电力公司Electric power system 电力系统Electronic 电子的、电子学的Electrotechnics 电工学、电工技术Electrostaic precipitator 静电除尘器Electrostatic 静电的Element 元件、零件、单元Elevation ELEV 标高Elevator 升降机Ellipse 椭圆Emergency decree 安规Emerg lub oil 事故润滑油Emerg off 事故停／关闭Emerg seal oil 事故密封油Emergency EMERG 紧急事故Emergency drain 事故疏水Emergency governet／intercepter 危急遮断器Employee 雇员Empty 排空Enclosure 外壳、包围End 末端、终结End cover 端盖Energize 激励、加电Energy 能、能量Energy meter 电度表Energy source 能源Engineer keyboard 工程师键盘Engineer station 工程师站Engineer's console 工程师操作站Engineering 工程Enter 开始、使进入Entry 输入Equalizer valve 平衡线Equipment 设备Erase 删除Error 错误Escape valve 安全线Evaporate 蒸发、冷化Evaporating 蒸发量Event 事件Excess 超过、过度Excess combustion air 过剩燃烧空气Excitation 励磁Exciter 励磁机Exhaust EXH 排汽Exhaust portion 排汽段Exit 出口Expansion EXP 膨胀Expansion tank 扩容箱Expenditure 费用Expert 专家、能手Explosion 爆炸Exponent 指数幂External 外部的、表面的Extinguisher 灭火器Extinguishing medium 灭弧介质Extraction check valve EXTR CHK VLV 抽汽逆止阀Extra-high voltage 超高压Extend 扩展、延伸Exteral 外部的、表面的Extr press 抽汽压力Extr temp 抽汽温度Extraction EXTR 抽汽FFactor 因素、因数Fahrenheit 华式温标Failure FAIL 失败FALSE 假的、错误的Fan 风扇、风机Fan duty 风机负荷Fast cut back FCB 快速切回Fault 故障Faulty operation 误操作Features 特点Feed 馈、供给Feedback 反馈Feed forward 前馈Feed water 给水Feed-water makeup 补给水Fiber optic 光纤Field 磁场、现场Field operator 现场运行人员Figure 数字、图案File 文件Filter 滤网、过滤器Filter differential pressure FILTR DP 滤网压差Final 最后的Final super-heater FSH 末级过热器、高过Fine ash silo 细灰库Fire 燃烧、火焰Fire-proof 耐火的、防火的Fire-extinguisher 灭火器Fire-hose 消防水带Fire hydrant 消防栓Fire-fight 灭火Fireproof 防火的、阻燃的Fire pump 消防水泵First stage 第一级、首级First stage guide vane 第一级导叶Flame 火焰Flame check 火检Flame detect cable FLM DET CAB 火检电缆Flange 法兰Flange joint 法兰结合面Flank 侧翼、侧面Flash 闪光、闪烁、闪蒸Flash lamp 闪光灯Flash light 闪光Flasher 闪光装置Flexible 灵活的、柔性的Flexible joint 弹性联接器Flip-flop 触发器、双稳态电路Float-charge 浮充电Floppy disk 软磁盘Floppy driver 磁盘机Flow 流量、流动Flowmeter 流量计Flue 烟道Format 形式、格式Flue gas 烟气Fluid 液体Fly ash 飞灰Follow 跟随Forbid 禁止Force 强制Force circulation 强制循环Force draft fan 送风机Forney 福尼（公司）Forward 向前Free end 自由端Frequency 频率From 从、来自Front 前面的Fuel 燃料Fuel safety 燃料保护Full speed 额定频率Fully 充分的、完全的Function 功能Function group 功能组Furnace 炉膛Fuse 保险丝、熔断器Fuse holder 保险盒Fusible cutout 熔断开关Fw bypass 给水旁路GGAIN 增益Gang 班、组Gas 气体、烟气Gate 闸门Gate damper 闸门式挡板Gateway 入口、途径Gauge 仪表、标准Gauge float 水位、指示、浮标Gear 齿轮Gear pump 齿轮泵Gear shift housing 变速箱Gen main breaker 发电机出口总开关General control panel 总控制屏General vlv 总阀Generate 引起、产生Generator 发电机、发生器Gland 密封套Gland heater GLAND HTR 轴封加热器Gland seal 轴封Glass-paper 砂纸Goal 目的、目标Go on 继续Govern vlv GV 调速器、调节器Graphics 调节阀Grease 图形Green 绿色Grid 高压输电网、铅板Grid system 电网系统Gross rating 总出力、总额定值Ground/earth 地、大地Group 组、群Group library 组库HHalt instruction 停机指令Hangers 悬吊管Hardware 硬件Hardness 硬度、困难的Hazardous 危险的、冒险的Header 联箱Heat 热、加热Heater 加热器Heating 加热Heat rate 热效率Heat soak 暖机Hertz HZ 赫兹Hesitate HESI 暂停、犹豫High 高的、高等的、高大的High pressure HP 高压High pressure heater HPH 高压加热器History 历史Historical date reporter HDR 历史数据报告Historical storage & retrieval unit HSR 历史数据报告存储与检索单元Hold 保持Home 家、处所Hopper 漏斗、料斗Hori vib(vibration) 水平振动Horizontal 水平的、横式Horse power 马力Hose 软管、水龙带Hot 热的Hot air 热风Hot rh 再热（器）热段Hot start 热态启动Hot well 热水井Hour 小时Hp cyl cross pipe 高压缸短管Hp turb exh press 高压缸排汽压力Hybrid 混合物Hydraulic 液压Hydrogen 氢（H）Hydrogen purity 氢气纯度Hydrobin/ dewatering bin 脱水仓IIdiostaic 同电位的Idle 空载的、无效的Ignition light oil 轻油点火Ignition 引燃、电火Ignitor 电火器Ignore 忽视Illustrate 说明Impeller 推进器、叶轮Impedance 阻抗Import 进口、引入Impulse 脉冲、冲击、冲量Inch IN 英寸Inching 缓动、点动Income 进线Increase INC 增加Index 索引、指示Indicator 指示器Individual 单个的、独立的Inductive reactance 感抗Input/output I/O 输入／输出Induced draft fan IDF 引风机Inductance 电感Induction motor 异步电动机Industrial water 工业水Industry 工业Inflatable seal 充气密封Inhibit 禁止Initial 最初的Inlet 入口Input group 输入组Insert 插入Inside 内侧、内部Inspection 观察、检查Install 安装Inspection hole 检查孔、人孔Installed capacity 装机容量Instantaneous 即时的、瞬时的Instantaneous power 瞬时功率Instruction 说明书、指南、指导Instrument 仪器Instrument panel 仪表盘Insulate 绝缘、绝热、隔离Insulator 绝缘子Intake 输入端、进线Integer 整数Integral 积分Intensity 强度Interpole 换向板Inter-stage extraction 中间抽头Interface 接口Interference 干扰、干涉Interlock 联锁Intermediate 中间的Internal 内部的Interrogation 质问、问号Interrupt 中断Interval 间隔Interlock auto on 联锁投自动Inverter 逆变器、反向器、非门Invoice INV 发票、发货单、托运Intermediate pressure IP 中压Intermediate relay 中间继电器Invalid 无效的、有病的Investment 投资Ion-exchange 离子交换器IP.cyl 中压缸Isolation 隔离Isolator 隔离、刀闸JJacking oil 顶轴油Jacking pump 顶轴泵Job 工作Jumper 跳线、跨接Junction box 接线盒KKey 键销、钥匙、键槽Keyboard 键盘Key library 键库Key switch 键开关Kilovolt-ampere KV A 千伏安Kink 弯曲、缠绕Knack 技巧、窍门、诀窍Knife-switch 闸刀开关LLabel 标号、标签Laboratory 实验室Labyrinth seal 迷宫密封Ladder 梯子、阶梯Ladder diagram 梯形图Lamp 灯、光源Large platen LARGE PLT 大屏Last 最后的Latch 止动销、挂闸、插锁Leak 泄漏（动词）Leakage 泄漏（名词）Left 左Length 长度Level 液位、水平Lifebelt 安全带、保险带Lift 提、升Light 光亮、点、点燃、照亮Lightning 雷电Light run 空转Lightning arrestor 避雷器Limit LMT 极限、限制Limiter 限制器、限位开关Line 线、直线Line impedance 线路阻抗Lining 衬层、内衬Linkage 连杆List 列表Liter 公升Ljungstrom trisector air preheaters 容克式空预器Load 负荷Load demand compute LDC 负荷指令计算Load impedance 负荷阻抗Load limit 负荷限制Load rejection 甩负荷Load shedding 甩负荷Loading 加负荷Load thrown on 带负荷Local 局部Local attendant 现场值班员Local repair 现场检修Local start 就地启动Local stop 就地停止Location 处所、位置Lock 闭锁、密封舱、固定Logger 记录器、拖车Logic 逻辑Long 长Loop 环、回路Loss 损失、减少Loss of excitation 励磁损失Loss of phase 失相Low 低Low press LP 低压Low press heater LPH 低压加热器Low-half 下半Lower 较低的、降低Lower heating value 低位发热量Low pressure cylinder LPC/LP CYL 低压缸Low temperature superheater LT SH 低温过热器Lub oil 润滑油Lub oil pump 润滑油泵Lubricate LUB 润滑MMagenta 品红色Magnet 磁Main 主要的/主蒸汽的/电力网Main oil tank 主油箱Main screen 主屏Main steam 主蒸汽Main transformer 主变压器Maintenance 维护、检修、小修Maintenance manual 检修手册Major overhaul 大修Make up 补充（补给）Makers works 制造厂Malfunction 出错、误动、失灵Management 管理、控制、处理Manhole 人孔、检查孔、出入孔Manifold 各式各样的联箱、集气管Manometer 压力表Man-machine interaction 人机对话Manual 手动、手册Manual reject MRE 手动切换Manual/Auto station M/A STATION 手动／自动切换站Mark 型号、刻度、标志、特征Mass memory 大容量存储器Master 主要、控制者Master control room 主控室、中央控制室Master fuel trip MFT 主燃料跳闸Maximum 最高的、最大Maximum continue rate MCR 最大连续率Mechanocaloric 热机的Mean 平均值、中间的Mean water level 平均水位Measure 量度、测量Mechanical 机械的、力学的Mechanical trip vlv 机械跳闸阀Mechanism 机械、力学、方法Medial 中间的、平均的Mediate 间接的、调解Medium 装置、介质、工质Megawatt 兆瓦Memory 存储Metal 金属Meter 集量器、仪表、米Meter switch 仪表开关Method 方法、规律、程序Method of operation 运行方式Mica 云母Mica dielectric 云母电介质Microcallipers 千分尺Microphone 麦克风、话筒Middle MID 中间的Middle-temperature rh MT RH 中温再热器Mill 磨、磨煤机、铣刀Minimum 最小的Minor overhaul 小修Minus 减、负号Minus phase 负相位Minute 分钟Miss operation 误动作、误操作Miss trip 拒跳闸Mistake 错误、事故Mixed bed 混床Mixture 混合物Man-machine interface MMI 人机接口Modem 调制解调器Modify 修改Modulating control 调节控制Modulating valve 调节阀Module 模件Moisture 湿度、湿汽Monitor 监视器、监视Monoxide 一氧化物Month 目Motor MTR 马达Motor control center MCC 马达控制中心Motor winding 电动机组绕组Mouldproof 防霉的Mount 安装、固定Mountain cork 石棉Mouse 鼠标Move 移动Multidrop 多站Multispeed 多速Mult-multi 多、多倍Multimeter 万用表Multiplication 乘Multivibrator 多谐振荡器NName 名、名字Natural 自然的Naught line 零线Needlepoint vlv 针阀Negative 负的Negative pressure NEG PRESS 负压Neon tester 试电表Net ratine/net output 净出力Network 网络Neutral line 中性线Neutral 中性的Neutral point 中性点Next 其次的Night shift 夜班Nipper 钳子、镊子Noise 噪音No-loading 空载Nominal 标称的、额定的Nominal power 额定功率Nominal rating 标称出力、额定出力Non-return vlv 逆止线Non-work 非工作的Normal 正常的、常规的Normal closed contact 常闭触点Normal makeup wtr 正常补水Not available 无效、不能用No touch relay 无触点继电器Non-work pad / n-work pad 非工作瓦Nozzle 喷嘴Number 数字、号码、数目Number of turns 匝数Nut 螺母、螺帽OOccur 发生Odd 奇数Office 办公室Oil 油Oil breaker 油开关Oiler 注油器Oil fuel trip OFT 油燃料跳闸Oil gun 油枪Oil immersed natural cooling 油浸自然冷却Oil purifier 油净化装置On-line 在线、联机的On-load test 带负荷试验On/off 开／关Onset 开始、发作Open 开、打开Open-air 露天的、开启的Open-loop 开环Open work 户外作业Operating panel 操作盘Operation 操作、运行Operational log 运行记录Operator 操作员Operator keyboard 操作员键盘Operator station 操作员站Operator's alarm console 操作员报警台Optimal 最优的、最佳的Optimal value 最佳值Optional 可选的Option switch 选择开关Orifice plate 孔板Original 初始的、原始的Oscillator 振荡器Oscilloscope 示波器Out 出、出口Outage 停用Out-of-service 为投入运行的Outlet 出口Output 产量、产品、输出Output group 输出组Outside 外边、外面Over current 过流Over load 过负荷Overload protection 过载保护Overall design 总体设计Over voltage 过压Overflow 溢流Overflow vlv station 溢流阀门站Overhaul 大修Overhaul life 大修间隙Overhead 顶部Overhead line 架空线Override 超越Overspeed 超速Overspeed trip 超速跳闸Overview 概述、总述Own demand 厂用电量Oxide film 氧化膜、氧化层Oxygen 氧PPackage 组件、包Packed group 组合组Pad 瓦、衬垫Page 页Panel 屏、盘Parameter 参数Part 部分、部件Part per million PPM 百万分率Password 口令Path 路线Peak 峰值Peak load 峰值负荷Pendant 悬吊Pendant pull switch 拉线开关Penthouse 顶棚Penumatics 汽动装置Percent PCT 百分数Percentage 百分比Perfect 完全的、理想的Perfect combustion 完全燃烧Performance 完成、执行、性能Performance calculation 性能计算Performance curve 性能曲线Periodic 周期的、循环的Periodic inspection 定期检查Peripheral 周围的Peripheral equipment 外围设备Permanent 永久的、持久的Permanent magnetic generator 永磁发电机Permit 允许Permit to work 允许开工Petrol 汽油Phase PH 阶段、状态、方面、相Phase angle 相角Phase-failure protection 断相保护Phase not together 缺相、失相Phase sequence 相序Phase-in 同步Piezometer 压力计Pitch coal 烟煤Pid drawing 流程图Pilot 导向、辅助的、控制的Pilot bearing 导向轴承Pipe 管、管道Pitch 投、掷、节距、螺距Plan 计划Plant 工场、车间Plant load factor 电厂负荷因数Plastics 塑料Platen 台板、屏式Platen superheater PLT SH 屏式过热器Plug 塞子、栓、插头Plug socket 插座Plunger 柱塞、滑阀Plunger pump 柱塞泵Plus 加Plyers 钳子、老虎钳Pneumatic 气动的Point 点Point database 测点数据库Point directory 测点目录Point name 测点名Point record 测点记录Point field 泡克区Phase voltage 相电压Pole 机、柱Policher 除盐装置Pollution 污染Pop valve 安全阀、突开阀Portion 一部分Position POS 位置Positive 确定的、正的、阳性的Potable water 饮用水Potential transformer PT 电压互感器Pound LB 磅Power PWR 功率、电源Power factor 功率因子Power plant 电厂Pre-alarm 预报警Precipitator PRECI/PRECIP 除尘器Preheat 预热Pre light 预点火Preliminary 准备工作Present 出现Preset 预设、预置Pressure PRES 压力Primary 初级的、一次的Primary air 一次风Primary air fan PAF 一次风机Primary superheater 低温过热器Primary grid substation 主网变电站Prime 首要的Printer 打印机Principle 原理、原则Priority 优先级、优点Probe 探头Process 过程、方法Processing time 处理时间Program 程序Programmable 可编程的Programmable logical controller PLC 可编程逻辑控制器Prohibit 禁止Proportional / integral / derivative PID 比例／积分／微分Protection PROT 保护Protection bolt 危急遮断器飞锤Protection ring 危急遮断器飞环Protocol 规约（数据通信）Potential transformer PT 电压互感器Psig 磅／平方英寸（表压力）Psia 磅/平方英寸(绝对压力)Puffer breaker 压力式断路器Pulse 脉冲、脉动Pulverizer PULV 磨煤机Pump 泵Punch 冲床、冲压机Purge 净化、吹扫Purifier 净化器Purify 纯度Purpose 目的、用途Push and pull switch 推拉开关Push button 按钮Put into operation 投入运行Pyod 热电偶Pyrology 热工学QQ-line Q线Quad 回芯组线Quality 质量Quartz 石英、水晶Query 询问、查询Quick 快Quicksilver 水银、汞Quick open 快开Quit 停止、离开、推出RRack earth 机壳接地Radial 径向的、半径的Radication 开方Radiator wall rh 壁式再热器Radiator 散热（辐射）器Radiation fin 散热片Raise 升高Range 范围、量程Rap 敲打Rap device （除尘器）振打装置Rapid charge 快速充电Rated 额定的、比率的Rated conditions 额定条件Rated power 额定功率Ratio 比率Raw material 原材料Ray 光线、射线Reactance 电抗、反作用Reactive capacity 无功容量Reactive power 无功功率Read out 读出、结果传达Ready 准备好Real power 有效功率Real time 实时的Rear 后面Recall 重新调用、重查Receive tank 回收箱、接收箱Recipe 处方、配方Recire/Recycle damper 再循环挡板Recirculate 再循环Reclaim 再生回收Reclosing 重合闸Recommend 介绍、建议Recording 记录、录音、唱片Recovery 恢复、再生Recovery time 恢复时间Rectification 整流、检波、调整Rectifier 整流器Red 红色Reduction 还原、缩小、降低Redundancy 冗余、多余Reference REF 参考、参照、证明书Reflux 倒流、回流Region 地域、领域Register 寄存器Regulate 调节、控制Regulating stage 调节级Regulating valve 调节阀Reheater RH 再热器Relative REL 相对的Relative expansion 相对膨胀Relay 继电器Relay panel 继电器屏Release 释放Reliability 可*的、安全的Relief 去载、卸载、释放、解除Relieve valve 安全阀、减压阀Remote 遥远的、远方的Remote select 遥控选择Remote technical center RTC 遥控技术中心Renewal 更新、更换Repair 修理Repairer 修理工、检修工Repeat 重复、反复Replacement parts 备件、替换零件Request REO 请求Require 要求Reserve parts 备件Reserved 备用的Reset 复位Resistance 阻力、电阻Resonate 谐振、调谐Response 响应Responsibility 责任Retract 可伸缩的、缩回Retractable thermoprobe 可伸缩的温度探头Retrieval 可检索的、可追忆的Return 返回Return oil 回油Reverse power 逆功率Reverse rotation 反转Review 检查Rig 安装、装配、调整Right 右Right-of-way 公用线路Ring 环Roller 辊子Roof 顶、炉顶Root 跟Rotary switch 转换开关Rotating 旋转Rotating joint 液压联轴器Rotor 转子Routine 例行的、日常的Routing inspection 日常检查、日常检测Routing maintenance 日常维护Run 运行Run back 返回Rundown 迫降Running conditions 运行情况Running current 工作电流Running in 试运行、试转Running/operation overhaul 临时检修SSafe 安全的、可*的、稳定的Safe potential 安全电压Safety 安全Safety cap 安全帽Safety measure 安全措施Safety rules 安全规程Safety valve 安全线Sample 取样、举例Sampler 取样器Saturate 饱和Saturate condition 饱和条件、饱和状态Saturated steam SAT STM 饱和蒸汽Scale 铁锈水垢Scan 扫描Schedule 时间表、计划表Schematic 图解的、简图Scoop 勺管Scr controller 屏幕控制器Screen 屏幕Screw 螺杆、螺丝Screwdriver 螺丝刀Scroll 滚屏Sea 海Seal 密封Seal air 密封风Sealing gland 密封盖Seal oil 密封油Seal steam SEAL STM 密封蒸汽Search 寻找、查找Seawater 海水Second 秒、第二Second air SEC AIR 二次风Secondary 二次的Seep 渗出、渗漏Seepage 渗漏现象Select 选择Self 自己、自我、本人Self-hold 自保持Self-running 自启动Sensor 传感器Sensitive 灵敏器Sensitiveness 灵敏性Separator 分离器Sequence 顺序、序列Sequence of emergence SOE 事故追忆Sequential control system SCS 顺序控制系统Series-longitudinal layout 串联纵向布置Service 服务、伺服Service power 厂用电Servomotor 伺服电机Set 设定Setpoint 设定点Set up 安装、调整、建立Severity 刚度、硬度、严重Sewage treatment 废水处理Shadow 影子、屏蔽Shaft 轴、烟囱Shaft seal 轴封Shake 摇动、振动Shakeproof 防振Shaft 轴、手柄、矿井Shaped 形状Share 共享、分配Share memory 共享存储器Sheet 表格、纸张Shell 壳Shield 屏蔽层Shift 值、替换Shift charge engineer 值班工程师Shoe 推力瓦Shortage of water 缺水Short circuit 短路Shot 发射、冲击、钢粒Shunt reactor 并联电抗器Shut off 关闭Shutdown 停止、停机Siccative 干燥剂Side 侧边Sidewall 侧墙Sifter 筛子、滤波器Signal 信号Signal lamp 信号等Sign 标记、注册Significance 意义、有效Silence 消音、沉寂Silicon SI 硅Silicon stack 硅堆Silo 灰库Single 单个的、个体的Station interface module SLM 站接口模件Simple 单纯的、简单的Similar 同样的、类似的Simulator 仿真机Single blade switch 单刀开关Sinusoid 正弦曲线Site 现场Site commissioning test 现场投运方式Size 尺寸、大小Size of memory 存储量Sketch 图纸、草图Skin effect 集肤效应Skip 空指令、跳跃Slag 结垢Sliding key 滑销Sliding press mode 消压方式Sluiceway 水沟Slurry 灰浆Smoke 烟、冒烟Smokes-stack 烟囱Smooth 平滑的、光滑的Socket 插座Soft 软的、柔软的Software 软件Solenoid SOLN 螺线圈Solid 固体Sootblower 吹灰、吹灰器Sound detection 声音探测Source 源、电源Spanner 扳手Spare 备用的、空余的Spare parts 备件、备品Specification 技术说明Specific weight 比重Speed 速度Speed protection 超速保护Spray 喷射Spray nozzle 喷嘴Spray water 喷水Spring 弹簧、春天Spring clutch 弹簧离合器Square 广场、方的Squirrel-cage armature 鼠笼式电枢Stabiliser 稳定器Stability 稳定（性）Stack 烟囱Staff 职工Stage 级、台Stall 停车、阻止Standard 标准Standby 备用、待机Standby heat 热备用Star 星、星形连接Star connected system 星形连接制"Y" Start 启动、开始Starting conditions 启动条件Start up 启动Start-up sequence 启动程序State 状态Statement 说明、语句Static 静电Static storage 静态存储器Station 站、发电厂、地点Station capacity 发电厂容量Station interface unit SLU 站接口单元Stator 静子Stator coil 定子线圈Stator core 定子铁芯Status 状态Status display 状态显示Steadiness 稳定性Steam STM 蒸汽Steam cylinder 汽缸Steam exhaust 乏气、废气Steam feed pump 汽动给水泵Steam-turbine generator 汽轮发电机Step 步Step-by-step motor 步进电动机Step ladder 阶梯Step-down transformer 降压变压器Step-up transformer 升压变压器Stere 立方米Stockyard 储煤场Stop 停止Stop vlv 主汽线Storage 储存Storage battery 蓄电池Storage tank 储存箱Straight 直的、直线Strainer 滤网Stress 应力、强调Styrofoam 泡沫塑料。

电气工程常用名词中英文对照表Part1：缩写全称中文AC alternating current 交流电AC automatic control 自动控制ACA accident consequence assessment 事故后果评价ACB air circuit breaker 空气断路器ACC accident 故障、事故ACCUM accumulate accumulate 累计、蓄电池ACDS acourtic crack detection system 声裂纹检测系统ACT/S active side 带电部件、有功部件ACW anti-clockwise 反时针方向ACW anti-clockwise 反时针方向AD analog-digital 模拟-数字AEOD analysis and evaluation of operational data 运行数据分析和管理AFC automatic frequency control automatic following control 自动频率控制：自动跟踪控制AI artificial intelligence 人工智能ALT alternate 交变的、交替的ALTNTR alternator 同步发电机AM ammeter 电流表AMP ampere 安培AN air natural cooled 空气自然冷却AOC automatic overload control 自动过载控制APC automatic plant coordinate control automatic power control 机组自动协调控制：自动功率控制APP appendix auxiliary power plant 附录：辅助电源设备APS acessory power supply 辅助电源APU auxiliary power unit 辅助动力装置：辅助电源设备ARM armature 电枢、衔铁ASR automatic speed run up 自动升速ASU automatic synchronizing unit 自动同步系统AT auxiliary transformer 辅助变压器AUS auxiliary switch 辅助开关AUX auxiliany 辅助、备用A VL automatic voltage control 自动电压控制A VR automatic voltage regulator 自动调压器BAT battery 电池BD block decrease 闭锁减BDUC bus duct 母线导管、母线沟BDV blowdown voltage 击穿电压BF back feed 反馈BHP brake horse power 制动马力BI block increase 闭锁增BKR breaker 断路器BOS back-out system 补偿系统BOT build-operate-tranfer 建造-运行-移交BR brush 电刷、刷子BRKG breaking 断开BYC battery charger 电池充电器CA compressed air 压缩空气CAOS completely automatic operate system 全自动操作系统CAP capactty 电容、出力、容量CAP capacity 容量、功率CATS computer-aided trouble-shooting 计算机辅助故障查寻CB control buton circuit breaker circuit board 控制钮：线路断路器：电路板CBL line circuit breaker 线路断路器CC charactevistic curve 特性曲线CCW counter-clockwise 反时针CD control desk 控制台CEMF cownta electromotive force 反电动势CG center of gravity 重心CHGR charger 充电器CKT circuit 电路、线路CKW clockwise 顺时针方向CL center line 中心线CLSG closing 关闭、合闸CMR continuous maxinum rating 连续最大功率CNDN condition 工况、参数CO con-out 关闭、切断COEF coefficient 系数CONST constans construction 常数：构造、结构CONT contact control 接点：调节、控制CP control panel 控制板CPD capacitor potential device 电容器分压器CRT cathode-ray tube 阴极射线管CRT circuit 回路CS controlled switch controll signal 控制开关：控制信号CT current transformer 电流互感器CW clockwise 顺时针方向CY cycle 循环、周期DB distribution box 配电箱DBMS data base management system 数据库管理系统DC direct current 直流电DCAS data collection and analysis system 数据收集分析系统DE digital equipment display equipment 数字元件：显示设备DELIV deliver 供给、供电/输出DG diesel generator 柴油发电机DG diesel generator 柴油发电机DHP delivered horse power 输出功率DI data input 数据输入DISC disconnect 断开DISC SW disconnect swtich 隔离开关DISTR diatribution 分散、分配、配电DL data line 数据传输线DMM digital multimeter 数字万用表DMS data management system 数据管理系统DO diesel oil 柴油DO digital output 数字输入DOS dosing 量DPDT double-pole double-throw 双刀双掷开关DPST double-pole sigle-throw 双刀单掷开关DSCH discharge 放电DSL diesel 柴油机DSL line desconnect switch 隔离开关DT dawn time 故障停机时间DTS data transimission 数据传输系统DYNA dynamic analysis 动态分析E.U engineering units 工程单位E/P electrical to pneumatic converter 电动气动转换器EAF equivalent available factor 等效可运系数ECR economical continuous rating 经济连续出力EE electrical engineer 电气工程师EFF efficiency 效率EFFT effective 有效的EHV extra-high voltage 超高压ELEC electric 电气的EMER emergency 紧急、事故EMER emergency 事故保安EMF inductive electromotive force 感应电动势EMLON emergency condition 事故状态EMP eletromechanical power 机电功率EMS emergency switch 紧急开关、事故按钮ENCL enclose 封闭、包围ENER energize 励磁、使带电ENERD energized 已励磁的、已带电的ENG engage 发动机EP extreme power 极限功率ESD emergency shutdown 事故停机ESS essential service system 主要厂用系统ETS electrical trip solenoid 电气跳闸线圈EXC exciter 励磁机、励磁EXD external device 外部设备EY voltage transducer 电压变送器FB fuse block 保险盒FC fast closing 快关F-F flip-flop 触发器FL full load 满负荷FLF flip-flop 触发器FME frequency measuring equipment 频率计FP full power 满功率FREQ frequency 频率FU fuse 保险丝、熔断器FWR full-wave rectifier 全波整流器Part2：缩写全称中文GEN generator 发电机GIS gas-insulated metal-enclosed switch gear 全封闭组合电器GPT generator potential transformer 发电机电压互感器GRD ground 接地GRD FLT ground fault 接地故障GT grounding transformer 接地变压器HC holding coil 保持线圈HF high frequency 高频HG harmonic generator 谐波发生器HIPOT high potential test 高电压实验HLDG holding 保持HP horse power 马力HS hand switch 手动开关HT high tension 高压HTN high tension 高电压HV high voltage 高电压HV high voltage high velocity 高压：高速HVDC high voltage direct current transmission system 高压直流输电系统HVPC high voltage power supply 高电压源I/O input/output 输入/输出IC integrated circuit input circuit 集成电路：输入电路ICL incoming line 引入线IMP impedance 阻抗IMPLS impulse 脉冲、冲动INDN induction 感应INIT initial 启动、励磁INITD initiated 已励磁的、已启动的INSUL insulate 绝缘、隔热INTMT intermediate 间断的、间歇的INVR inverter 逆变器、反相器ISLN isolation 隔离开关ISOL isolation 隔离的、绝缘的JY watt transduce 有功变送器K kilo 千KW kilowatt 千瓦KWH kilowatt-hour 度L electrical power line 电线LA lightening arrester 避雷器LC load centre 负荷中心LC load center 负荷中心LDS line disconnecting switch 线路隔离开关、线路断路器LN line 线路LOC local 就地LPC linear power controller 线性功率放大器LR line relay 线性继电器LSIC large scale integrated circuit 大规模集成电路LV low voltage 低电压MAG magnet 磁铁/磁场的MAN manual 手动的MC manual control magnet contactor 人工控制：磁铁开关MCB molded case circuit breaker 模板式断路器MCC motor control centre 马达控制中心MCC motor control center 马达控制中心MCR main control room maxium capacity rating maxium continuous rating 主控室：最大额定出力：最大连续出力MDS motor disconnect switch 马达隔离开关MG motor generator 电动发电机ML mechanical loss 机械损失MNXFMR main transformor 主变压器MO motor 马达MOD motor operated disconnect 电动断开MPR motor protrelay 电机保护继电器MSTR motor starter 马达启动器MWE megawatt electric 兆瓦电MWH megawatt-hour 兆瓦小时NADVD not advanced 滞后NEG negative 阴极的、负的NET network 网络NEUT neutral 中性的NGT neutral groundong transformer 中性点接地变压器NL noload 空载、无负荷NOM nominal 额定的NRP normal rated power 额定功率O&R overhaul and repair 大小修OA operator auto mode 运行人员监控下的自动控制运行方式OL motor overload device 电机过负荷装置OP output power operating procedure 输出功率：运行规程OPER operating 操作OR operating record 停运记录OVHL overhaul 大修P.O. power output 功率输出P.U. per unit 标幺值PA power amplifier 功率放大器PAMS post-accident montoring instrumentation 事故后监测仪表PB push button 按钮开关PC power center 动力中心PCB power circuit breaker 功率继电器PCC power conditioning and control 电力调节与控制PCM pulse-code modulation 脉冲编码调制PD potenial difference power driven 电位差：电动的PE power equipment 发电综合控制PF power factor indicator 功率因数PFI power factor indicator 功率因数表PGCC power generation control complex 相位PH phase 功率输入PI power input 峰值负荷PK peak 峰值PL plate 板、极板PL peak load 峰值负荷PLD payload 有效负载PM phase midulation 调相PO power operator 电动操作POH planned outage hours 计划停运小时POOH planned overhaul outage hours 计划大修停运小时POS positive 正的、正极的POS position 位置POT potential transformer 电势、电位计PP peak power 峰值功率PPS plant protective system primary protection system 电厂保护系统：一次保护系统PS power station power supply power system 电站：电源：电力系统PSS power support stabilizer 电力系统稳定器PT potential transformer 电压互感器PT potential transformer 电压互感器PT pressure transducer 压力变送器PWR power 功率Q transistor 晶体管QA quick acting 快速动作QMQB quick-make quick-break 快通快断R rate rotor ratio 速率：转子：比率系数RA remote auto 远程自动RAM repair and maintenance 检修与维护RB run back 甩负荷RD run down 降负荷RF reserve free 备用ROT rate of turn reserve oil tank 转动速度：备用油箱RP rated power 额定功率RPM revolution per minute 转/分RPS revolution per second 转/秒RS resistor 电阻器RSV reserve 备用RTD resistance temperature device 电阻测量计RU run up 升负荷RU run up 升负荷Part3：缩写全称中文S/C short circuit 短路SC short circuit 短路SC semi-conductor 半导体SCR silicon-controlled rectifier 可控硅整流器SECT sectional 等级、分级SEN sensor 传感元件、传感器SERV service 工作、厂用SG standby generator 备用发电机SO shut-off 停机、遮断SOE sequence of events 事故顺序记录SOH scheduled outage hours 计划停机时间SOV solenoid -operated valve 电磁阀SP single pole spare 单极：备用SPC system power control 系统电源控制SPDT single-pole double-throw 单刀双掷SR speed reguletor standard rating silicon rectifier 调速器：额定容量：硅整流器SS station service 厂用SS stopping switch 停机开关SST station service transformer 厂用变压器ST starter startup transformer 启动器：启动变压器STA stationary 固定的STAT stator 定子STBY standby 备用STBY stand by 备用STR reserve station service transformer 厂用备用变压器SUBSTA substation 变点站SUPL supervisory 供电、电源SUR surge 冲击、波动SV solenoid valve 电磁阀、滑阀SW switch 开关SW switch 开关、手把SW short wave switch 短波：开关SWBD switchboard 配电SWBD switchboard 开关板、配电盘SWC surge withstand capability 冲击电压承受能力SWGR switchyard 配电装置SWYD switchyard 开关场SY synchroscope 同步指示器SYM symmetrical system 对称系统SYNC synchronize 使---同步SYNCG synchronizing 同步SYNSCP synchroscope 同步指示器SYS system 系统SYST system 系统T&D transimission and distribution 输电与配电T&M testing and maintenance electrical trip and monitoring 实验与维修：电电气跳闸与监视系统TACH tachometer 转速表TASS technique assembly 装配工艺TB therminal board 端子板、终端板TBO time between overhaul 大修间隔TC thermocouple 热电偶TD time delay 延时TD technique data time delay 技术数据：时滞、延时TDC time delay closing 延时闭合TDD time delay on deenerization 延时失励TDE time delay energization 延时激励TDO time delay opening 延时打开TE thermoelectric test equipment 热电的：测试设备TH thermal element 热电偶、热偶元件TIS test instrumentation system thermal insulation system 测试仪表系统：绝缘系统TL total loss total load time limit 总损失：总负荷：时间限制TM time monitor 时间监视器TOT total 总共TP test point time pulse 实验点、测试点：时间脉冲TPDT triple-pole double-throw 三刀双掷开关TR test run transducer 试运行：变送器TRANS transport 运输TRC transmission and reception controller 传输及接收控制器TRIAC triode altermating current switch 三极管交流开关TRU transmit-receive unit 发送接收装置TSI turbine supervisory instrument 汽轮机监视仪表TVM transistor voltmeter 晶体管电压表U unit 机组UAT unit auxiliary transformer 厂用变压器UDF unit derating factor 机组降低出力系数UDG unit derating generation 机组降低出力少发电量UDH unit derating hours 机组降低出力小时UERS unusual event recording system 异常事故记录系统UNDH unit derating hours 机组降低出力小时UNIV universal 通用UNLD unloading 无载的、空载的UO unit operator 机组操作员UOF unplanned outage factor 非计划停运系数UOH unplanned outage hour 非计划停运小时UOR unplanned outage rate 非计划停运率UPS uninterrupted power supply 不停电电源URT unit run time 设备运行时间UST unit station service transformer 厂用变压器UV under voltage 电压不足、低电压UV 电压监察V AR variable 变量V ARHM garhour meter 无功电度表VC variable capacitor voltage comparator 可变电容:电压比较器VCB vacuum circuit breaker 真空断路器VCT voltage current transformer 电压电流互感器VENT ventilator 通风VF vriable frequency 可变频率VOLTREG voltage regularor 电压调节器VR variable resistor voltage regulator 可变电阻：稳压器VT vibration testing 振动实验VT voltage time to breakdown 击穿电压时间VTVM vacuum-tube voltmeter 真空管电压表W/O without 没有WDG winding 绕组、线圈WH watt-hour 瓦特小时WHM watthour meter 有功电度表WTR water 水WV working voltage 工作电压WZJ 绝缘监察XDCR transducer 变送器XFER transfer 转换XFMR transfoormer 变压器XMSN transmission 输电XMTR transmitter 变送器XS transfer switch 转换开关YD yard 工作场。

Mould . n模具Polishing .n抛光Leakage .n泄漏、渗出Electrics appliance (group) corporation .n电器集团有限公司corporation .n有限公司；公司、企业；（律）社团、法人Ltd. .a有限的Rear .n后面、背面、后方；屁股；.a后面的、后方的、背后的Peg .n销子.vt固定Temperature control dial .n调温旋钮Temperature control rod .n 调温连杆Water filling inlet .n加水口Water filling cap .n加水口盖Steam button .n蒸汽按钮Heat-isolating husk .n隔热壳Washer .n垫圈Idler wheel .n滚轮Piston .n活塞Piston ring .n活塞环Piston-rod .n活塞杆Column pin .n圆柱销Sieve .n滤网Elbow .n弯头Silica gel .n硅胶Swivelling cord protector .n护线套Swivelling .n可转、可转动Supply cord .n电源线Transparent lamp-chimney .n透明灯罩Transparent water tank .n透明水箱Water tank .n水箱、水糟Soleplate .n底板、床板Maximum water level .n最高水位Water level .n水位、水平面、水准仪Super-steam .n强蒸汽Transparent .a透明的、明晰的、显然的Knob .n旋钮Filler .n漏斗Bolier .n锅炉Plate .n金属板.vt电镀；给---装钢板Heat treatment .n热处理Socket .n插座Plug .n插头Appliance .n用具、器具AC (altemating current) .n交流电Specify .vt指定、详细说明、列入清单GF(glass fibre) .n玻璃纤维Radio ceramic .n高频瓷Bracket .n支架Electrothermal pipe .n电热管Handle .n柄、把手Switch .n开关Slippage .n滑动Nut .n螺帽Screw .n螺丝钉Steel .n钢Pump .n泵Spray organ .n 雾化器Super-steam tie-in .n强蒸汽接头Vocalism spring .n发声弹簧Ordinary steam cap .n普通蒸汽Porcelain pole .n瓷柱Unilateral valve .n单向阀Unilateral valve spring .n单向阀弹簧Stainless steel .n不锈钢Strut point .n支撑点Airproof loop .n密封圈Elbow of suction pipe .n吸水管弯头Plane washer .n平垫圈Spring washer .n弹簧垫圈Thermal link plate .n热保护压扣Aluminium .n铝Ourselves .n本公司Brass .n黄铜National standard .n国标Suction pipe for super-steam .n强蒸汽软管Thermostat .n温控器Terminal box .n接线端子盒Knob cap .n旋钮座Copper pin .n铜针Copper .n铜Steel ball .n钢珠Net piece .n网片Water pump spring .n水泵弹簧“E” model buckle .n E形卡圈Super-steam buttons .n强蒸汽按钮Spray buttons .n喷水按钮Plate for generation of steam .n汽化盖Tamper-proof screw (Cross shaped head ) .n十字标准螺钉Ceramic .n陶瓷Inside diameter .n 内径Rack .n 齿条Graduation board .n 刻度板Needle valve .n 针阀Rion husk .n 铁壳Steam dial block .n 蒸汽拨块Pressure board of cord .n 压线板Exploding buttons .n 爆炸按钮Electric vacum cleaner .n 吸尘器Electronic oven .n 电烤箱Electric iron .n 电熨斗Air conditioning .n 空调Home appliance .n 家用电器Electric shaver .n 电动剃须刀Electric cook .n 电饭锅Refrigerator .n 电冰箱、冰冻机Microwave oven .n 微波炉Electric heater .n 电暖气Scrap iron .n 废铁Cast iron .n 铸铁Clamp .n 夹具、夹子Fitting .n 配件、附件Fixture .n 夹具、固定物Die .n 拉模Gear .n 齿轮Hardware .n 五金器具Lathe .n 车床Hook .n 钩Hammer .vt 锤、敲打.n 锤Punch .n 冲床Bolt .n 螺栓Pig iron .n 生铁Deterrent sheet .n 挡片Winding wire rack .n 绕线架Pointing light .n 指示灯Cross model limiting object. 十字架“Auto stop” pilot light 自动停电指示灯Temperature pilot light 温度(电源)指示灯。

一．电气名词 Electric items二．二．线路（母线、回路）Lines (Bus, circuits) 三．三．设备 Equipment四．四．保护、继电器 Protection, relays五．五．电气仪表 Electric instruments六．六．防雷 Lightning protection七．七．接地 Grounding, earthing八．八．室、所 Room, Substation九．九．电修车间设备 Equipment of electric repair room 十．十．材料 Material十一．十一．图名 Drawings, diagrams十二．十二．表头 Tables十三．十三．标准图词汇 Terms from standard DWG一．电气名词 Electric items交（直）流 Alternating (direct) current短路电流 Short-circuit current起始次暂态短路电流Initial subtransient short-circuit current冲击/脉冲电流 Impulse current稳态短路电流Steady state short-circuit current临界电流 Critical current切断电流 Rupturing current熔断电流 Blow-out current故障电流 Fault current计算电流 Calculating current极限有限电流 Limit effective current过电流 Over current逆电流 Inverse current整定电流 Setting current额定电流 Rated current电流密度 Current density短路电流最大有效值 Maximum effective value of short-circuit current高压 High-voltage , High-tension低压 Low-voltage , Low-tension计算电压 Calculating voltage激磁电压 Exciting voltage冲击电压 Impulse voltage临界电压 Critical voltage残留电压 Residual voltage击穿电压 Puncture voltage脉动电压 Pulsating voltage供电电压 Supply voltage电力电压 Power voltage照明电压 Lighting voltage灯丝电压 Filament voltage额定电压 Rated voltage电压损失 Voltage loss过(欠)电压 Over (under) voltage 线路电压 Line voltage电压降 Voltage drop工作电压 Working voltage一次电压 Primary voltage二次电压 Secondary voltage电源 Electric source (power supply)自控电压 Power supply for process control6kV控制闪光电源Flashing supply for 6kV control工作电源Working power supply (electric source)保安电源Emergency power supply (electric source)直流稳压电源 Stabilized D.C. source控制电源 Control supply直流电源 D.C. source交流电源 A.C. source负荷计算 Load calculation设备容量 Installed capacity需要容量 Electric demand功率因数 Power factor安装高度 Mounting height耐电压 Withstand voltage击穿电压Breakdown voltage工频耐压 Working frequency withstand voltage 表面闪络 Surface flash-over直流泄漏 D.C. leakage体电阻率 Volume resistivity介质损失角 Dielectric loss angle击穿强度 Breakdown/Puncture intensity电压等级 Voltage grade比重 Specific gravity性能 Feature相序 Phase sequence瞬时 Instantaneous倾角 Angle of inclination跨度 Span正极 Positive pole负极 Negative pole截面(积) Cross section area辅助电源 Auxiliary source遮断容量 Interrupting capacity载流量 Current-carrying capacity校正系数 Correction factor连续负荷 Continuous load长期载流量 Continuous capacity长时间额定值 Longtime rating电动机堵转电流 Locked-rotor motor current限定负荷 Limited load电感负荷 Inductive load感应电流 Induced current二．线路（母线、回路）Lines (Bus , circuits) 母线 Bus-bar合闸电源母线 Closing power source bus闪光母线 Flashing-bus备用母线 Spare bus装在支柱上的插接式母线Post-supported plug-in bus way装在吊钩上的插接式母线Hook-supported plug-in bus way装在支架上的插接式母线Bracket-supported plug-in bus way小母线 Miniature bus电源小母线 Power supply miniature bus操作小母线 Operating miniature bus事故信号小母线 Miniature bus for fault signal 闪光小母线 Flashing miniature bus主母线 Main bus直流主母线 D.C. main bus预告母线 Prewarning bus干线 Main line照明干线 Lighting main line接地干线 Grounding main line插座干线 Receptacle main line 电压干线 Voltage main line端子出线 Terminal outgoing中性线 Neutral支线 Branch-line引入线 Lead-in电气线路 Electric circuit交流配电线路 A.C. distribution circuit直流配电线路 D.C. distribution circuit事故照明线路 Emergency lighting circuit控制线路 Control circuit接地或接零线路Grounding or neutralizing circuit信号线路 Signal circuit有接地极的接地线路网Grounding with grounding electrodes定子绕组测温回路Temperature measuring circuit for stator winding接地信号回路 Grounding signal circuit闪光信号回路 Flashing-signal circuit开阀回路 Circuit for opening valve关（闭）阀回路 Circuit for closing valve开度计回路 Circuit for opening meter电流测量回路 Current-measuring circuit差动保护回路 Differental protective circuit 过流保护回路 Over-current protective circuit合闸回路 Closing circuit停车延时回路 Delayed shutdown circuit掉闸回路 Trip circuit激磁回路 Exciting circuit备用回路 Spare circuit主回路 Main circuit馈路 Feeder circuit现有回路 Existing circuit单线回路 Single-wire circuit接地回路 Earthed circuit有电压的电路 Live circuit三．红色障碍灯 Red obstruction lamp for aviation 厂区道路照明灯 Street lighting in plant area路灯 Street lamp视孔灯 Inspection hole lamp立杆弯灯 goose-neck post lamp , pole lamp 模拟报警信号 Semigraph and alarm signal自整角机 Selsyn励磁机 Exciter显示器 Display电位器 Potentiometer内电阻 Internal resistance固定电阻（器） Fixed resistance脱扣 Release , trip分励 Shunt trip特殊失压脱扣器 Special no-voltage release “或”开关放大器“Or” switch amplifier制动器 Brake电容 Capacitor整流器 Rectifier镇流器 Chock分流器 Shunt油变阻器 Oil immersed rheostat频敏电阻器 Frequency sensitive rheostat滑线变阻器 Sliding rheostat蜂鸣器 Buzzer电机加热器 Space heater (for motor)空气断路器电机操作机构 Motor operating mechanism for air circuit-breaker可控硅励磁装置 Silicon controlled rectifier excitation device保护装置 Protective device (element)闪光装置 Flashing device接闪装置（避雷器） Lightning arrester断相保护 Phase failure protection四．保护、继电器 Protection , relays信号继电器 Signal relay过电流继电器 Over-current relay电压继电器 Voltage relay时间继电器 Time relay中间继电器 Auxiliary relay热继电器 Thermal relay温度继电器 Temperature relay瓦斯继电器 Gas relay 控制电源中间继电器Auxiliary relay for control supply自动操作继电器 Relay for auto-operation低电压继电器 Under-voltage relay过电压继电器 Over-voltage relay联锁继电器 Interlock relay冲击继电器 Impact relay合闸位置继电器 Close position relay逆流继电器 Reverse-current relay差流继电器 Differential current relay差动继电器 Differential relay电流继电器 Current relay功率继电器 Power relay接地继电器 Earthing relay重合闸继电器 Reclosing relay同步继电器 Synchronous relay速动继电器 Quick acting relay定时限继电器 Definite time relay光电继电器 Photoelectric relay电子继电器 Electronic relay电磁式继电器 Electromagnetic relay电动式继电器 Electrodynamic relay气压继电器 Gas-pressure relay继电器常开触点 Relay N.O. contact继电器常闭触点 Relay N.C. contact继电器保护触点（常开） Relay holding contact (N.O.)能自动返回的常闭按钮触点 Self-return button with N.C. contact模拟信号触点 Contact for semigraph signal强励磁接点 Shock excitation contact电感线圈 Induction coil电流线圈 Current coil脱扣线圈 Trip coil合闸线圈 Close coil释放线圈 Releasing coil掉闸线圈 Tripping coil予告信号 Prewarning signal掉闸回路断线信号Breakage signal of trip circuit断路器事故掉闸信号Fault trip signal of breaker掉闸音响信号 Tripping audible signal重瓦斯预告信号 Heavy gas prewarning signal 温度预告信号 Temperature prewarning signal 手动、自动操作时事故信号Fault signal in manual/automatic operation保护掉闸 Protective trip控制掉闸 Control trip手动跳闸 Manual trip变电所紧急停车Emergency shutdown at substation工艺故障 Fault in process励磁故障 Fault in excitation工作电源失电报警 No-voltage alarm of working electric source工作电源分合闸 On and off of working electric source工作电源投入Throw-in of working electric source保安电源送电supply of emergency electric source运转指示 Indicating of operation投入指示 Indicating of throw-in同步指示 Indicating of synchronism延时停车 Delayed shutdown电源切除 Switch off the power supply速断及过流断通Instantaneous trip and over-current off/on自保持 Self-holding自锁 Self-lock联锁 Interlocking绝缘监视 Insulation supervision电压监视 Voltage supervision 联锁解除 Release of interlock工作、保安电源切换 Transfer of working and emergency power supply发电机与工作母线并车Synchronization of generator to working bus重瓦斯保护 Heavy gas protection开或闭超扭矩保护Over-torque protection during opening and closing valve电机起动顺序 Sequence of motor starting铭牌框注字Name plate denotation (inscription)五．电气仪表 Electric instruments电流表 Ammeter电压表 Voltmeter三相三线有功电度表Three-phase three-wire kilowatt-hour meter , kWh meter单相电度表 Single-phase kilowatt-hour meter 三相无功电度表Three-phase kilovar-hour meter有功功率表 Active power meter , kilowatt meter 无功功率表Reactive power meter , kilovar meter三相瓦特表(功率表) Three-phase watt meter功率因数表 Power factor meter频率表 Frequency meter验电流器 Galvanoscope欧姆表 Ohmmeter相位表 Phase meter转速表 Tachometer波长表 Wave-length meter三相四线制标准电度表 3-phase 4-wire standardwatthour-meter过载电流表 Overload ammeter低功率因数瓦特表 Low power-factor wattmeter 交直流两用钳型电流表 A.C./D.C. multi-purpose tongtester兆欧表 Megger , Megohmmeter万用表 Avometer微安表 Microammeter毫安表 Milliammeter各种测量仪表 Various kind of measuring instruments接地电阻测量仪 Earthing resistance tester真空管电压表 Vacuum tube voltmeter电动秒表 Electric second-meter六．防雷 Lightning protection避雷装置 Lightning protector避雷针 Lightning rod避雷带 Strap type lightning protector避雷网 Network of lightning protector避雷针支架 Lightning rod support避雷针尖 Tip of lightning rod避雷针拉铁 Brace for lightning rod避雷器 Lightning arrester , surge discharger 球型避雷器 Spherical arrester管形避雷器 Tubular arrester阀形避雷器 Auto-valve arrester低压避雷器 Low voltage arrester角形避雷器 Horn arrester多隙避雷器 Multigap arrester铝避雷器 Aluminum cell arrester氧化膜避雷器 Oxide film arrester击穿保险器 Puncture lightning arrester雷击 Lightning stroke直接雷击 Direct lightning stroke感应雷击 Induction lightning stroke雷电日 Thunderbolt days雷电或然率 Lightning and thunder probability 触电 Electric shock静电感应 Electrostatic induction七．接地 Grounding, earthing接地保护 Ground protection , earth protection 防雷接地 Grounding for lightning保护接地 Protective earthing人工接地 Artificial grounding工作接地 Working grounding , working earthing 重复接地 Multiple earthing屏蔽接地 Screen earthing , shielding ground 中性点接地 Neutral point grounded接地系统 Grounding system , earthing system 接地故障 Ground fault , earth fault单相接地 Single phase earthing母线接地 Bus ground接地装置 Grounding device , earthing device 引下线 Down-lead , down conductor引下线固定Clamping plate of support for fixing支架夹板 Down lead引下线固定支脚 Support for fixing down lead 接地线 Ground connector接地干线 Ground(ing) main , (bus)接地网 Grounding network , earthing network 接地极 Earth electrode (pole)接地电阻 Earth resistance接地电路 Earth (ground) circuit连接条 Connecting strip断接卡 Connecting clamp八．室、所 Room , Substation贮藏室 Storage套间 Compartment蓄电池室 Battery room控制室 Control room配电室 Distribution room维修间 Repair room变电所 Substation高压配电室 H.V. distribution room休息室 Rest room九．电修车间设备Equipments of electric repair砂轮机 Emery wheel grinder台钻 Bench drilling machine交流电焊机 A.C. welding machine移动式空气压缩机 Portable air compressor手电钻 Electric hand drill单速手摇绕线机Single speed hand winding machine导线钳压器 Wire jointing press-clamp油压千斤顶 Hydraulic jack电吹尘器 Electric dust cleaner存放柜 Store chest高压试验变压器 H.V. testing transformer泄漏试验变压器 Leakage testing set大电流发生器 Strong current generator油浸自冷感应调压器 Oil-immersed self-cooled induction voltage regulator多量程仪用电流互感器Multi-range current transformer for measurement仪用电感互感器Instrumental voltage transformer单相自耦变压器 Single-phase auto-transformer 三相自耦变压器 3-phase auto-transformer硅整流器 Silicon rectifier仪表试验台 Testing stand for instrument接触器，继电器试验台Relay and contactor testing stand慢扫描示波器 Slow scanning oscillograph交流电子稳压器 A.C. electronic voltage stabilizer携带式交流电桥 Portable A.C. electric bridge 接地电阻测量仪 Earthing resistance tester电缆故障探伤仪 Cable fault detector直流单臂电桥 D.C. single-arm electric bridge , Wheatstone bridge十．材料 Material绝缘包布 Insulating tape填料 Filler , packing绝缘膏 Insulating compound电缆膏 Cable compound防腐油 Anti-corrosive oil沥青漆 Bituminous varnish 绝缘漆 Insulating varnish瓷漆 Enamel varnish有色金属 Non-ferrous metal黑色金属 ferrous metal白金属 White metal云母 Mica环氧树脂 Epoxy resin聚氯乙烯 Polyvinyl chloride , PVC 蜡 Wax滑石粉 Talc powder电胶木 Bakelite聚丙烯外壳 Polyacrylic cover耐油橡胶管 Oil-proof rubber tubes 接地铜线 Grounding copper wire垫圈 Pad塑料绝缘线 Plastics insulated wire 橡套电缆 Rubber sheathed cable中间接头 Splice填充剂 Filling agent绝缘电线 Insulated wire移动软电缆 Movable flexible cable 补偿导线 Extension wire套管 Bushing母线槽 Busway悬索 Cable suspension滑触线 Trolley conductor镀锌煤气管 Galvanized gas pipe镀锌角钢 Galvanized steel angle镀锌扁钢 Galvanized steel strap钢丝绳 Steel wire rope电笛 Siren电磁阀 Electromagnetic valve连接片 Connecting link切换片 Transfering link端子排 Terminal board半导体二极管 Semiconductor diode 开度计 Opening meter逻辑元件 Logical element接线盒 Junction box仪表槽板 Instrument trunking电缆吊架 Cable hanger出线套 Outgoing line sleeve十一．图名 Drawings , diagrams电气图纸目录 Contents of electric drawings 电力系统图 Electric power system diagram照明系统图 Lighting system diagram电力平面布置图 Electric power layout plan照明平面布置图 Lighting layout plan单线图 One line diagram控制箱面部布置图Surface arrangement of control box背部接线图 Back wiring (diagram)外部接线图 External (outside) wiring diagram 内部接线图 Internal (inside) wiring diagram 控制原理图 Principle control diagram原理图 Schematic diagram展开图 Developed diagram电气标准图 Electric standard drawing电气施工图 Electric working drawing复用图 Reproducibles (drawing)电缆联系图 Cable hook-up diagram转换开关接点图 Contact diagram of transfer switch箱侧视图 Side view of box正视图 Front view , facade背视图 Back view剖面图 Section参考图 Reference drawing电缆敷设图 Cable laying diagram箱内框架布置图 Arrangement of frames inside the cabinet控制箱台面展开图 Surface developed diagram of console出线端子示意图 Schematic diagram of terminal outgoing lines端子接线图 Diagram of terminal connections 电气管线表 List of wire , cable and conduits 设备材料表 List of equipment and materials 十二．表头 Tables电力系统图 Power system diagram引入线 Lead in保护设备 Protective device型号 Type额定值 Rating整定值 Setting主启动设备回路 Circuit to starting device导线型号、芯数、截面及管径 Conductor type , cores , section & diameter of conduit线长 Wire length管长 Conduit length启动设备 Starting device型号规格 Type , specification保护元件 Protective element计量装置 Calculating device用电设备主回路Main circuit of electric equipment控制回路 Control circuit控制装置 Control device用电设备 Electric equipment设备容量 Consumer capacity生产设备 Production equipment位号 No. of location名称 Name备注 Remarks引入线 Feed in配电箱 Distribution cabinet型号及编号 Type and No.开关型号 Switch type保护装置 Protective device回路编号 Circuit No.相别 Phase灯数 Number of lamps插座数 Number of receptacles电缆编号 No. of line起点 Starting终点 Ending母线截面 Section of bus零母线 Neutral bus屏编号 Panel No.型号及方案号 Type and variant No.控制原理图号 Principle control diagram工艺位号 Process item No.十三．标准图词汇 Terms from standard DWG电工系统图图形符号Graphic symbols for electric system交流电的相别 A.C. phase sequence直流电的正负极 D.C. positive and negative poles有中性点引出线的星形连接的三相绕组Star-connected three phase windings with neutral outlet开口三角形连接的三相绕组3-phase winding with open delta connection互相连接的导线 Cross connection of wires不连接的跨越导线Crossing wires not in contact with each other可拆卸的电气连接 Removable connection电缆终端头 Pothead of cable or cable end自耦变压器 Auto-transformer感应调压器 Induction voltage regulator凸极同步电动机 Salient pole synchronous motor 带接换装置的蓄电池组Accumulator battery with tap-changers空气断路器 Air circuit-breaker保持触点 Holding contact热元件 Thermal element自动复位的操作开关 Spring-return operating switch插接器 Plug-in connector电喇叭 Horn 电炉 Electric furnace分流器 Shunt可控硅整流箱屏 Silicon controlled rectifier box panel直流配电屏 D.C. distributing panel磁力起动器组 Magnetic starter group自动开关箱 Automatic switch box行程开关 Limit switch局部灯 Local lighting fitting荧光灯列 Series fluorescent lighting fitting 防护式灯开关 Protective switch导线引上 Conductors turning up导线引下 Conductors turning down导线由上引来 Conductors turning from above 导线由下引来 Conductors turning from below 电缆沟 Cable trench调压器 Voltage regulator隔离变压器 Isolating transformer击穿保护器 Puncturing safety device晶体管 Transisorized diode地坪 Grade level电缆与水管平行 Cable running parallel to a water supply pipe电缆与热力管道交叉敷设 Cable running across heat pipeline车道 Drive way电缆穿管与管道交叉Cable protective pipe across a pipeline双(单)侧支架电缆沟 Trench with rack on both sides (one side)室外地坪 Outdoor grade跨接线 Jumper金属软管 Flexible metal tube过渡接头 Adapter电气工程及其自动化专业术语翻译transistor 晶体管audion? 三极管capacitance? 电容Diesel 柴油机AC- motors 交流电机transistorcoupling 联结耦合current carrying capacity? 载流能力（最大允许电流）conductivity 传导性in isolation 绝缘lead 导线leakage current 泄漏电流inductance 感应系数loops 线圈macroprocessor 微处理器multimedia show 多媒体展示medium-power distribution 中压配电motor and soft starters 电机及软起动器numerical controls 数控系统optimal 最佳的，最理想的overload relays 过载继电器overshoot 过冲peak current 峰值电流power dissipation 电力分散process automation 过程自动化process instrumentation and analytics 过程仪表及分析仪器punch 穿孔，冲压reactance 电抗recharge 再充regulated power supply 稳压电源resistance 阻抗resistor? 电阻器resonate 共振self-inductance 自感应series inductance 串联感应simulation 模拟switching 配电；交流thermal cycle 热循环thickness 厚度voltage regulator 调压器warping 扭曲，变形wiring layout 线路配置图AC-drives 交流变频器asymmetrical 非对称的attenuation? 衰减bridged impedance 桥接阻抗cable bridge 电缆桥架charge 电荷circuit schematic diagram 电路原理图解coefficient 系数configuration 构造constant 常量copper sheet 铜片damping 阻尼decomposition 分解decouple 分离delay circuit 延迟电路dielectric sheets? 介电原片diode clamping钳位edge connector 边缘连接器electrical infrastructure 电气基础设施electrical installation 电气安装技术equations set 方程组four-layer 四层hookup? 接线图human machine interface 人机界面impedance 阻抗incidence 入射incident wave 入射波incorporated 合成一体的instantaneous 瞬间的interleaved 交叉load admittance? 负载导纳lumped? 集中的modal 模式的modeling 建模motor management systems 电机管理系统mounting pads 安装垫片noise margins 噪音安全系数proximity effect? 邻近效应radian 弧度resistive 有抵抗力的schematic 示意图services & industry solutions 服务和工业解决方案terminator 终结器undershoot 负脉冲信号；下冲。

电力行业的专业用语，中英对照表，太全了Part1电气名词Electric items交(直)流：Alternating (direct) current短路电流：Short-circuit current起始次暂态短路电流：Initial subtransient short-circuit current 冲击电流：Impulse current稳态短路电流：Steady state short-circuit current临界电流：Critical current切断电流：Rupturing current熔断电流：Blow-out current故障电流：Fault current计算电流：Calculating current极限有限电流：Limit effective current过电流：Over current逆电流：Inverse current整定电流：Setting current额定电流：Rated current电流密度：Current density短路电流最大有效值：Maximum effective value of short-circuit current高压：High-voltage , High-tension低压：Low-voltage , Low-tension计算电压：Calculating voltage激磁电压：Exciting voltage冲击电压：Impulse voltage临界电压：Critical voltage残留电压：Residual voltage击穿电压：Puncture voltage脉动电压：Pulsating voltage供电电压：Supply voltage电力电压：Power voltage照明电压：Lighting voltage灯丝电压：Filament voltage额定电压：Rated voltage电压损失：Voltage loss过(欠)电压：Over (under) voltage线路电压：Line voltage电压降：Voltage drop工作电压：Working voltage一次电压：Primary voltage二次电压：Secondary voltage电源：Electric source (power supply)自控电压：Power supply for process control6KV 控制闪光电源：Flashing supply for 6kV control 工作电源：Working power supply (electric source) 保安电源：Emergency power supply (electric source) 直流稳压电源：Stabilized D.C. source控制电源：Control supply直流电源：D.C. source交流电源：A.C. source负荷计算：Load calculation设备容量：Installed capacity需要容量：Electric demand功率因数：Power factor安装高度：Mounting height耐电压：Breakdown voltage工频耐压：High-voltage test with working frequency 表面闪络：Surface flash-over直流泄漏：D.C. leakage体电阻率：Volume resistivity介质损失角：Dielectric loss angle击穿强度：Puncture intensity电压等级：Voltage grade比重：Specific gravity性能：Feature相序：Phase sequence瞬时：Instantaneous倾角：Angle of inclination跨度：Span正极：Positive pole负极：Negative pole截面(积)：Cross section area辅助电源：Auxiliary source遮断容量：Interrupting capacity载流量：Current-carrying capacity校正系数：Correction factor连续负荷：Continuous load长期载流量：Continuous capacity长时间额定值：Longtime rating电动机堵转电流：Locked-rotor motor current 限定负荷：Limited load电感负荷：Inductive load感应电流：Induced currentPart2线路(母线、回路)Lines (Bus , circuits)母线：Bus-bar合闸电源母线：Closing power source bus闪光母线：Flashing-bus备用母线：Spare bus装在支柱上的插接式母线：Post-supported plug-in bus way装在吊钩上的插接式母线：Hook-supported plug-in bus way 装在支架上的插接式母线：Bracket-supported plug-in bus way 小母线：Miniature bus电源小母线：Power supply miniature bus操作小母线：Operating miniature bus事故信号小母线：Miniature bus for fault signal闪光小母线：Flashing miniature bus主母线：Main bus直流主母线：D.C. main bus预告母线：Prewarning bus干线：Main line照明干线：Lighting main line接地干线：Grounding main line插座干线：Receptacle main line电压干线：Voltage main line端子出线：T erminal outgoing中性线：Neutral支线：Branch-line引入线：Lead-in电气线路：Electric circuit交流配电线路：A.C. distribution circuit直流配电线路：D.C. distribution circuit事故照明线路：Emergency lighting circuit控制线路：Control circuit接地或接零线路：Grounding or neutralizing circuit信号线路：Signal circuit有接地极的接地线路网：Grounding with grounding electrodes定子绕组测温回路：Temperature measuring circuit for stator winding接地信号回路：Grounding signal circuit闪光信号回路：Flashing-signal circuit开阀回路：Circuit for opening valve关(闭)阀回路：Circuit for closing valve开度计回路：Circuit for opening meter电流测量回路：Current-measuring circuit差动保护回路：Differental protective circuit过流保护回路：Over-current protective circuit合闸回路：Closing circuit停车延时回路：Delayed shutdown circuit掉闸回路：Trip circuit激磁回路：Exciting circuit备用回路：Spare circuit主回路：Main circuit馈路：Feeder circuit现有回路：Existing circuit单线回路：Single-wire circuit接地回路：Earthed circuit有电压的电路：Live circuitPart 3设备Equipments高压开关柜：H.V. switchgear动力配电箱：Power distribution cabinet电源配电箱：Source distribution cabinet直流配电屏：D.C. switchboard (distribution panel)交流低压配电屏：A.C.L.V. switchboard (distribution panel)静电电容器柜：Static capacitor cabinet多种电源插销箱：Receptacle box for miscellaneous powersupplies控制箱：Control cabinet照明配电箱：Lighting (distribution panel)连接箱：Junction box出线盒：Outlet box开关箱：Switch box控制台：Console分段屏：Sectionalizing panel进线屏：Incoming line panel电控箱：Electric control panel边屏：Side board端子箱：Terminal box供电盘：Power supply box瓶车箱：Synchronizing cabinet电压互感器柜：Potential transformer cabinet信号屏：Signal panel浮充屏：Floating panel蓄电池屏：Battery panel充电屏：Charging panel母线联络柜：Bus tie cabinet转换开关：Transfer switch电压表转换开关：Voltmeter change-over switch 铁壳开关：Metal-clad switch (Iron-clad switch) 管式熔断器：Cartridge fuse真空断路器：Vacuum circuit breaker (V.C.B.)自动开关：Automatic switch高压负荷开关：H.V. load break switch三极高压断路器：3-pole HV circuit-breaker刀开关：Knife switch转换开关：Transfer switch双极铁壳开关：2-pole iron-clad switch风扇变速开关：Fan speed regulator switch密闭照明灯开关：Hermetic lighting switch防爆照明灯开关：Explosion-proof lighting switch行程开关：Limit switch高压隔离开关：H.V. disconnecting switch明装单极板钮开关：Surface-mounted single-pole toggle switch暗装单极板钮开关：Flush-mounted single-pole toggle switch 三路开关：Three-way switch气密式组合开关：Hermetic packet type switch防护式开关：Guard type switch联锁开关：Interlock switch操作方式选择开关：Selecting switch for types of operation控制电源开关：Switch for control supply主令开关：Master switch (controller)多切点切换开关：Multi-point change-over switch按钮：Push-button控制按钮：Control push-button防爆控制按钮：Explosion-proof control push-button事故紧急按钮：Emergency stopping push-button起动按钮：Starting push-button停止按钮：Stopping push-button现场按钮：Push-button in field挡板：damper音响解除按钮：Push-button for sound release起动器：Starter磁力起动器：Magnetic starter综合起动器：Combination starter (Magnetic starter combination)电力变压器：Power transformer调压变压器：Voltage regulating transformer电压互感器：Potential transformer电流互感器：Current transformer照明变压器：Lighting transformer三相三绕组变压器：3-phase tertiary winding transformer高压试验变压器：H.V. testing transformer局部照明变压器：Local lighting transformer多量程仪用电流互感器：Multi-range current transformer for measurement降压变压器：Step-down transformer伺服电动机：Servo-motor双电压电动机：Dual-voltage motor感应电动机：Induction motor交流异步电动机：A.C. asynchronous motor同步电动机：synchronous motor三相滑环感应电动机：3-phase slip-ring induction motor三相鼠笼感应电动机：3-phase squirrel-cage induction motor 绕线式电动机：Wound-rotor induction motor反应式电动机：Reaction motor柴油发电机：Diesel generator励磁发电机：Excitation generator明装双极插座：Surface-mounted 2-pole receptacle暗装双极插座：Flush-mounted 2-pole receptacle双极带接地插座：2-pole receptacle with grounding contact 单相三孔明插座：Surface-mounted single phase 3-pole receptacle防护式明装三相四孔插座：Guard type surface-mounted 3-phase 4-pole receptacle配照型灯：Standard dome lighting fitting搪瓷深照型灯：Enameled high bay lighting fitting防水防尘灯：Water and dust proof lighting fitting安全灯：Safety lighting fitting隔爆灯：Explosion-proof lighting fitting弯灯：Goose-neck light壁灯：Wall light高压水银灯：High pressure mercury vapor lighting fitting 投光灯：Flood-light (projection light)信号灯：Signal lamp天棚灯：Ceiling-mounted lighting fitting局部照明灯：Local lighting fitting灯座：Lamp holder事故照明灯：Emergency lighting fitting高压水银荧光灯：H.P. mercury fluorescent lighting fitting 广照型工厂灯：Wide lit type industrial fitting深照型灯具：High bay lighting fitting白炽灯具：Incandescent lamp (bulb)圆球型灯：Globe lamp嵌入式荧光灯：flush type fluorescent lighting fitting红色障碍灯：Red obstruction lamp for aviation厂区道路照明灯：Street lighting in plant area路灯：Street lamp视孔灯：Inspection hole lamp立杆弯灯：goose-neck post lamp , pole lamp模拟报警信号：Semigraph and alarm signal自整角机：Selsyn励磁机：Exciter显示器：Display电位器：Potentiometer内电阻：Internal resistance固定电阻(器)：Fixed resistance脱扣：Release , trip分励：Shunt trip特殊失压脱扣器：Special no-voltage release“或”开关放大器：“Or” switch amplifier制动器：Brake电容：Capacitor整流器：Rectifier镇流器：Chock分流器：Shunt油变阻器：Oil immersed rheostat频敏电阻器：Frequency sensitive rheostat滑线变阻器：Sliding rheostat蜂鸣器：Buzzer电机加热器：Space heater (for motor)空气断路器电机操作机构：Motor operating mechanism for air circuit-breaker可控硅励磁装置：Silicon controlled rectifier excitation device 保护装置：Protective device (element)闪光装置：Flashing device接闪装置(避雷器)：Lightning arrester断相保护：Phase failure protectionPart4保护、继电器Protection , relays信号继电器：Signal relay过电流继电器：Over-current relay电压继电器：Voltage relay时间继电器：Time relay中间继电器：Auxiliary relay热继电器：Thermal relay温度继电器：Temperature relay瓦斯继电器：Gas relay控制电源中间继电器：Auxiliary relay for control supply自动操作继电器：Relay for auto-operation低电压继电器：Under-voltage relay过电压继电器：Over-voltage relay联锁继电器：Interlock relay冲击继电器：Impact relay合闸位置继电器：Close position relay逆流继电器：Reverse-current relay差流继电器：Differential current relay差动继电器：Differential relay电流继电器：Current relay功率继电器：Power relay接地继电器：Earthing relay重合闸继电器：Reclosing relay同步继电器：Synchronous relay速动继电器：Quick acting relay定时限继电器：Definite time relay光电继电器：Photoelectric relay电子继电器：Electronic relay电磁式继电器：lectromagnetic relay电动式继电器：Electrodynamic relay气压继电器：Gas-pressure relay继电器常开触点：Relay N.O. contact继电器常闭触点：Relay N.C. contact继电器保护触点(常开)：Relay holding contact (N.O.)能自动返回的常闭按钮触点：Self-return button with N.C. contact模拟信号触点：Contact for semigraph signal强励磁接点：Shock excitation contact电感线圈：Induction coil电流线圈：Current coil脱扣线圈：Trip coil合闸线圈：Close coil释放线圈：Releasing coil掉闸线圈：Tripping coil予告信号：Prewarning signal掉闸回路断线信号：Breakage signal of trip circuit断路器事故掉闸信号：Fault trip signal of breaker掉闸音响信号：Tripping audible signal重瓦斯预告信号：Heavy gas prewarning signal温度预告信号：T emperature prewarning signal手动、自动操作时事故信号：Fault signal in manual/automatic operation保护掉闸：Protective trip控制掉闸：Control trip手动跳闸：Manual trip变电所紧急停车：Emergency shutdown at substation工艺故障：Fault in process励磁故障：Fault in excitation工作电源失电报警：No-voltage alarm of working electric source工作电源分合闸：On and off of working electric source工作电源投入：Throw-in of working electric source保安电源送电：supply of emergency electric source运转指示：Indicating of operation投入指示：Indicating of throw-in同步指示：Indicating of synchronism延时停车：Delayed shutdown电源切除：Switch off the power supply速断及过流断通：Instantaneous trip and over-current off/on 自保持：Self-holding自锁：Self-lock联锁：Interlocking绝缘监视：Insulation supervision电压监视：Voltage supervision联锁解除：Release of interlock工作、保安电源切换：Transfer of working and emergency power supply发电机与工作母线并车：Synchronization of generator to working bus重瓦斯保护：Heavy gas protection开或闭超扭矩保护：Over-torque protection during opening and closing valve电机起动顺序：Sequence of motor starting铭牌框注字：Name plate denotation (inscription)Part5电气仪表Electric instruments电流表：Ammeter电压表：Voltmeter三相三线有功电度表：Three-phase three-wire kilowatt-hour meter , kWh meter单相电度表：Single-phase kilowatt-hour meter三相无功电度表：Three-phase kilovar-hour meter有功功率表：Active power meter , kilowatt meter无功功率表：Reactive power meter , kilovar meter三相瓦特表(功率表)：Three-phase watt meter功率因数表：Power factor meter频率表：Frequency meter验电流器：Galvanoscope欧姆表：Ohmmeter相位表：Phase meter转速表：Tachometer波长表：Wave-length meter三相四线制标准电度表：3-phase 4-wire standard watthour-meter过载电流表：Overload ammeter低功率因数瓦特表：Low power-factor wattmeter交直流两用钳型电流表：A.C./D.C. multi-purpose tongtester 兆欧表：Megger , Megohmmeter万用表：Avometer微安表：Microammeter毫安表：Milliammeter各种测量仪表：Various kind of measuring instruments接地电阻测量仪：Earthing resistance tester真空管电压表：Vacuum tube voltmeter电动秒表：Electric second-meterPart6防雷Lightning protection避雷装置：Lightning protector避雷针：Lightning rod避雷带：Strap type lightning protector避雷网：Network of lightning protector避雷针支架：Lightning rod support避雷针尖：Tip of lightning rod避雷针拉铁：Brace for lightning rod避雷器：Lightning arrester , surge discharger球型避雷器：Spherical arrester管形避雷器：Tubular arrester阀形避雷器：Auto-valve arrester低压避雷器：Low voltage arrester角形避雷器：Horn arrester多隙避雷器：Multigap arrester铝避雷器：Aluminum cell arrester氧化膜避雷器：Oxide film arrester击穿保险器：Puncture lightning arrester雷击：Lightning stroke直接雷击：Direct lightning stroke感应雷击：Induction lightning stroke雷电日：Thunderbolt days雷电或然率：Lightning and thunder probability 触电：Electric shock静电感应：Electrostatic inductionPart7接地Grounding , earthing接地保护：Ground protection , earth protection 防雷接地：Grounding for lightning保护接地：Protective earthing人工接地：Artificial grounding工作接地：Working grounding , working earthing 重复接地：Multiple earthing屏蔽接地：Screen earthing , shielding ground中性点接地：Neutral point grounded接地系统：Grounding system , earthing system 接地故障：Ground fault , earth fault单相接地：Single phase earthing母线接地：Bus ground接地装置：Grounding device , earthing device引下线：Down-lead , down conductor引下线固定：Clamping plate of support for fixing支架夹板：Down lead引下线固定支脚：Support for fixing down lead接地线：Ground connector接地干线：Ground(ing) main , (bus)接地网：Grounding network , earthing network接地极：Earth electrode (pole)接地电阻：Earth resistance接地电路：Earth (ground) circuit连接条：Connecting strip断接卡：Connecting clampPart8室、所Room , Substation贮藏室：Storage套间：Compartment蓄电池室：Battery room控制室：Control room配电室：Distribution room维修间：Repair room变电所：Substation高压配电室：H.V. distribution room休息室：Rest roomPart9电修车间设备Equipments of electric repair砂轮机：Emery wheel grinder台钻：Bench drilling machine交流电焊机：A.C. welding machine移动式空气压缩机：Portable air compressor手电钻：Electric hand drill单速手摇绕线机：Single speed hand winding machine导线钳压器：Wire jointing press-clamp油压千斤顶：Hydraulic jack电吹尘器：Electric dust cleaner存放柜：Store chest高压试验变压器：H.V. testing transformer泄漏试验变压器：Leakage testing set大电流发生器：Strong current generator油浸自冷感应调压器：Oil-immersed self-cooled induction voltage regulator多量程仪用电流互感器：Multi-range current transformer for measurement仪用电感互感器：Instrumental voltage transformer单相自耦变压器：Single-phase auto-transformer三相自耦变压器：3-phase auto-transformer硅整流器：Silicon rectifier仪表试验台T esting stand for instrument慢扫描示波器：Slow scanning oscillograph交流电子稳压器：A.C. electronic voltage stabilizer携带式交流电桥：Portable A.C. electric bridge接地电阻测量仪：Earthing resistance tester电缆故障探伤仪：Cable fault detector直流单臂电桥：D.C. single-arm electric bridge , Wheatstone bridgePart10材料Material绝缘包布：Insulating tape填料：Filler , packing绝缘膏：Insulating compound电缆膏：Cable compound防腐油：Anti-corrosive oil沥青漆：Bituminous varnish绝缘漆：Insulating varnish瓷漆：Enamel varnish有色金属：Non-ferrous metal黑色金属：ferrous metal白金属：White metal云母：Mica环氧树脂：Epoxy resin聚氯乙烯：Polyvinyl chloride , PVC 蜡：Wax滑石粉：Talc powder电胶木：Bakelite聚丙烯外壳：Polyacrylic cover耐油橡胶管：Oil-proof rubber tubes 接地铜线：Grounding copper wire 垫圈：Pad塑料绝缘线：Plastics insulated wire 橡套电缆：Rubber sheathed cable 中间接头：Splice填充剂：Filling agent绝缘电线：Insulated wire移动软电缆：Movable flexible cable 补偿导线：Extension wire套管：Bushing母线槽：Busway悬索：Cable suspension滑触线：Trolley conductor镀锌煤气管：Galvanized gas pipe 镀锌角钢：Galvanized steel angle 镀锌扁钢：Galvanized steel strap钢丝绳：Steel wire rope电笛：Siren电磁阀：Electromagnetic valve连接片：Connecting link切换片：Transfering link端子排：Terminal board半导体二极管：Semiconductor diode开度计：Opening meter逻辑元件：Logical element接线盒：Junction box仪表槽板：Instrument trunking电缆吊架：Cable hanger出线套：Outgoing line sleevePart11图名Drawings , diagrams电气图纸目录：Contents of electric drawings电力系统图：Electric power system diagram照明系统图：Lighting system diagram电力平面布置图：Electric power layout plan照明平面布置图：Lighting layout plan单线图：One line diagram控制箱面部布置图：Surface arrangement of control box 背部接线图：Back wiring (diagram)外部接线图：External (outside) wiring diagram内部接线图：Internal (inside) wiring diagram控制原理图：Principle control diagram原理图：Schematic diagram展开图：Developed diagram电气标准图：Electric standard drawing电气施工图：Electric working drawing复用图：Reproducibles (drawing)电缆联系图：Cable hook-up diagram转换开关接点图：Contact diagram of transfer switch箱侧视图：Side view of box正视图：Front view , facade背视图：Back view剖面图：Section参考图：Reference drawing电缆敷设图：Cable laying diagram箱内框架布置图：Arrangement of frames inside the cabinet 控制箱台面展开图：Surface developed diagram of console出线端子示意图：Schematic diagram of terminal outgoing lines端子接线图：Diagram of terminal connections电气管线表：List of wire , cable and conduits设备材料表：List of equipment and materialsPart12表头Tables电力系统图：Power system diagram引入线：Lead in保护设备：Protective device型号：Type额定值：Rating整定值：Setting主启动设备回路：Circuit to starting device导线型号、芯数、截面及管径：Conductor type , cores , section & diameter of conduit线长：Wire length管长：Conduit length启动设备：Starting device型号规格：Type , specification保护元件：Protective element计量装置：Calculating device用电设备主回路：Main circuit of electric equipment 控制回路：Control circuit控制装置：Control device用电设备：Electric equipment设备容量：Consumer capacity生产设备：Production equipment位号：No. of location名称：Name备注：Remarks引入线：Feed in配电箱：Distribution cabinet型号及编号：Type and No.开关型号：Switch type保护装置：Protective device回路编号：Circuit No.相别：Phase灯数：Number of lamps插座数：Number of receptacles电缆编号：No. of line起点：Starting终点：Ending母线截面：Section of bus零母线：Neutral bus屏编号：Panel No.型号及方案号：Type and variant No.控制原理图号：Principle control diagram工艺位号：Process item No.Part13标准图词汇T erms from standard DWG电工系统图图形符号：Graphic symbols for electric system交流电的相别：A.C. phase sequence直流电的正负极：D.C. positive and negative poles有中性点引出线的星形连接的三相绕组：Star-connected three phase windings with neutral outlet开口三角形连接的三相绕组：3-phase winding with open delta connection互相连接的导线：Cross connection of wires不连接的跨越导线：Crossing wires not in contact with each other可拆卸的电气连接：Removable connection电缆终端头：Pothead of cable or cable end自耦变压器：Auto-transformer感应调压器：Induction voltage regulator凸极同步电动机：Salient pole synchronous motor带接换装置的蓄电池组：Accumulator battery with tap-changers空气断路器：Air circuit-breaker保持触点：Holding contact热元件：Thermal element自动复位的操作开关：Spring-return operating switch插接器：Plug-in connector电喇叭：Horn电炉：Electric furnace分流器：Shunt可控硅整流箱屏：Silicon controlled rectifier box panel直流配电屏：D.C. distributing panel磁力起动器组：Magnetic starter group自动开关箱：Automatic switch box行程开关：Limit switch局部灯：Local lighting fitting荧光灯列：Series fluorescent lighting fitting防护式灯开关：Protective switch导线引上：Conductors turning up导线引下：Conductors turning down导线由上引来：Conductors turning from above导线由下引来：Conductors turning from below电缆沟：Cable trench调压器：Voltage regulator隔离变压器：Isolating transformer击穿保护器：Puncturing safety device晶体管：Transisorized diode地坪：Grade level电缆与水管平行：Cable running parallel to a water supply pipe电缆与热力管道交叉敷设：Cable running across heat pipeline 车道Drive way电缆穿管与管道交叉：Cable protective pipe across a pipeline 双(单)侧支架电缆沟：Trench with rack on both sides (one side) 室外地坪：Outdoor grade跨接线：Jumper金属软管：Flexible metal tube过渡接头：AdapterPart14电气工程及其自动化专业术语晶体管：transistor三极管：audion电容：capacitance柴油机：Diesel联结耦合：coupling载流能力(最大允许电流)：current carrying capacity传导性：conductivity绝缘：in isolation导线：lead泄漏电流：leakage current感应系数：inductance线圈：loops微处理器：macroprocessor多媒体展示：multimedia show中压配电：medium-power distribution电机及软起动器：motor and soft starters数控系统：numerical controls最佳的，最理想的：optimal过载继电器：overload relays过冲：overshoot峰值电流：peak current电力分散：power dissipation过程自动化：process automation过程仪表及分析仪器：process instrumentation and analytics 穿孔，冲压：punch电抗：reactance再充：recharge稳压电源：regulated power supply阻抗：resistance电阻器：resistor共振：resonate自感应：self-inductance串联感应：series inductance模拟：simulation热循环：thermal cycle厚度：thickness调压器：voltage regulator扭曲，变形：warping线路配置图：wiring layout交流变频器：AC-drives非对称的：asymmetrical衰减：attenuation桥接阻抗：bridged impedance电缆桥架：cable bridge电荷：charge电路原理图解：circuit schematic diagram 系数：coefficient构造：configuration常量：constant铜片：copper sheet阻尼：damping分解：decomposition分离：decouple延迟电路：delay circuit介电原片：dielectric sheets钳位：diode clamping边缘连接器：edge connector电气基础设施：electrical infrastructure 电气安装技术：electrical installation方程组：equations set四层：four-layer接线图：hookup人机界面：human machine interface阻抗：impedance入射：incidence入射波：incident wave合成一体的：incorporated瞬间的：instantaneous交叉：interleaved负载导纳：load admittance集中的：lumped模式的：modal建模：modeling电机管理系统：motor management systems安装垫片：mounting pads噪音安全系数：noise margins邻近效应：proximity effect弧度：radian有抵抗力的：resistive示意图：schematic服务和工业解决方案：services & industry solutions 终结器：terminator。

电气专业英语词汇——中英对照表AAbnormal 异常Accuracy 精度ACSR = aluminum conductor steel reinforced 钢芯钻铰线adjustment 调整adjustable range 可调范围fine adjustment 细调rough adjustment 粗调air gap 气隙alarm 报警alarm bell 警铃alarming window 报警窗口ampacity 载流量ampere 安培kilovolt ampere 千伏安amperemeter 安培表，电流表amplifier 放大器announciator 报警器anode 阳极anti-corrosion 防腐蚀anti-pumping device 防跳装置AOL = aircraft obstruction lamp 航空障碍灯low intensity AOL 低光强航空障碍灯high intensity AOL 高光强航空障碍灯AQR = automatic reactive power regulator 自动无功功率调整器arcing chamber 灭弧室armature 电枢ASS = automatic synchronizing system 自动同期系统asynchronous 非同期non-asynchronous capability 非同期能力Bballast 镇流器ballast-factor 镇流器系数ball eyes 球头挂环battery 蓄电池Cd-Ni battery 镉-镍蓄电池lead-acid battery 铅-酸蓄电池maintenance free battery 免维护蓄电池battery capacity 蓄电池容量battery rack 电池架battery room 蓄电池室end battery 端电池BIL = basic insulation level 绝缘基本冲击耐压水平blocking diode 闭锁二极管box 盒，箱cast aluminum junction box 铸铅接线盒cast Ferro alloy junction box 铸铁合金接线盒junction box 接线盒lead box 出线箱maintenance box 检修箱marshalling box (总配线箱)power supply box 动力箱terminal box 端子箱test box 试验盒normal lighting box 工作照明箱breaker 断路器close the breaker 合断路器open the breaker 打开断路器breaker compartment 断路小室PT circuit broken PT回路断线brush 刷graphite brush 石墨碳刷brush holder 刷握brush supporter 刷架brushless excitation system 无刷励磁系统bus 母线branch bus 分支母线by-pass bus 旁母main bus 主母线bus tie 母联flexible busbar 软母线hard busbar 硬母线miniature busbar 小母线tubular busbar 管型母线changeover busbars 倒母线bushing 套管oil filled bushing 充油套管seal-off bushing 密封套管wall bushing 穿墙套管bushing lead terminal 套管端子button 钮子push button 按钮self-holding push-button 自保持按钮turn button 旋钮buzzer 蜂鸣器Ccabinet 柜control cabinet 控制柜distribution cabinet 配电柜cable 电缆3 cores cable 三芯电缆armoured cable 铠装电缆coaxial cable 同轴电缆control cable 控制电缆copper wire braid shield cable 铜编织线屏蔽电缆fiber-optical cable 光纤电缆fire resistant cable 耐火电缆flame retardant cable 阻燃（难燃）电缆heat tracing cable 伴热电缆heating cable 加热电缆heating sensitive cable 热敏电缆high voltage oil-filled cable 高压充油电缆impregnated paper insulated cable 油浸纸绝缘电缆lead covered cable 铅皮电缆mineral insulated cable 无机绝缘电缆overhead cable 架空电缆power cable 动力电缆signal cable 信号电缆stranded copper cable 铜铰线电缆telephone cable 电话电缆triple-core cable 三芯电缆twin-core cable 两芯电缆unarmoured cable 非铠装电缆communication cable 通讯电缆single-core cable 单芯电缆tag of cable 电缆标牌cable clip 电缆夹flexible cable conduit 电缆软管cable conduit 电缆管cable head 电缆头1cable laying 电缆敷设cable laying & list 电缆敷设及清册cable mezzanine 电缆夹层cable raceway system 电缆通道系统cable rack 电缆支架cable shaft 电缆竖井cable support 电缆支架cable suspender 电缆吊架cable terminal 电缆终端头cable tray 电缆桥架cable trench 电缆沟cable tunnel 电缆隧道cable vault 电缆夹层control cable with copper tape shield 铜带屏蔽的控制电缆call 呼叫call back 回叫call signal 呼叫信号external calling 外部呼叫internal calling 内部呼叫calling 主叫detail calling record 呼叫详细记录candle power distribution curve 配光曲线capability 能力out-of-phase breaking capability 失步开断能力pressure relief capability 压力释放能力rated closing capability 额定关合能力short-line fault breaking capability 近区故障开断能力transient overvoltage capability 暂态过电压能力capability of switching long no-load line 分合长空载线路能力capability of switching no-load transformer 分合空载变压器能力capacitance 电容adjustable capacitor 可变电容器shunt capacitor 并联电容器voltage sharing capacitor 均压电容器capacitor 电容器capacitor divider 电容分压器capacity 能量,容量current carrying capacity 载流能量spare capacity 备用容量cavity ratio 室腔比cell jar 电瓶chain link 挂环changeover 切换automatic changeover 自动切换star-delta changing device 星角切换装置charge 充电equalizing charge 均衡冲电float charge 浮充电fully charged 全充charger 充电器boost charging voltage 大充电压initial charging voltage 起始充电电压check phase order 核对相序circuit 电路，回路auxiliary circuit 辅助回路follow-up circuit 跟踪回路main circuit 主电路short circuit plate 短路板spare circuit(feeder) 备用回路series circuit 串联电路circuit breaker 断路器air circuit breaker 空气断路器bus tie circuit breaker 母联断路器by-pass bus circuit breaker 旁路断路器current-limiting circuit breaker 限流断路器earth leakage circuit breaker 漏电开关field circuit breaker 磁场开关oil circuit breaker 油断路器residual current circuit breaker 漏电开关sectionalized circuit breaker 分段断路器SF6 gas insulated circuit breaker 六氟化硫断路器frame-type circuit breaker 框架式断路器clamp 线夹strain clamp 耐张线夹suspension clamp 悬垂线夹clearance 带电距离clip 线夹quick clip 快速线夹closing 合闸open phase closing of breaker 非全相合闸closing pulse 合闸脉冲coil 绕组arc-suppression coil 消弧线圈armature coil 电枢绕组holding coil 保持线圈redundant trip coil 双跳闸线圈reset coil 复归线圈shunt excitation coil 分励线圈trip coil 跳闸线圈combined 综合combined filter 综合滤波器combined starter 综合起动器commission 调试communication 通信communication building 通信楼communication line 通信线communication monitoring 通信监听dispatching communication system 调度通信系统intra-plant communication system 厂内通信系统wireline communication system 有线通信系统component 分量fundamental component 基波分量harmonic component 谐波分量conductor 导体high conductivity 高导电率composite conductor 组合导线flexible conductor 伸缩节flexible conductor 软导线conductor cross-section 导体截面conform to 符合connection 连接，接线double bus connection 双母线接线open-delta connection 开口三角形连接star connection 星形连接zigzag connection 曲折形连接1 and 1/2 circuit breaker connection 1个半断路器接线connection pin 连接端子connection plate 联接片double bus connection with bypass 双母线带旁路接线end connector 终端接头power connector 电源接头removable connector 可拆接头oil conservator 油枕contact 触头arcing contact 弧触头arcing-extinguishing contact 灭弧触头2common alarm contact 公用报警接点electrical independent contact 无源接点main contact 主触头moving contact 动触头normally closed contact 常闭接点normally opened contact 常开接点stationary contact 静触头auxiliary contact 辅助触头contactor 接触器electromagnetic pneumatic contactor 电磁气动接触器vacuum contactor 真空接触器electromagnetic contactor 电磁接触器between open contacts 断口间continuous duty (service) 连续运行continuous rating 连续额定值control 控制automatic control 自动控制centralized control 集中控制local control 就地控制one-to-one control 一对一控制photoelectric control 光电控制器remote control 远方控制control circuit 控制回路electrical auxiliary control panel 电气辅助控制屏mosaic surface control panel 马赛克控制屏network control room 网控室cool 使冷却hydrogen inner cooled 氢内冷water cooled 水冷却natural cooling 自冷式forced air cooling system 强迫风冷系统copper bus-bar 铜母线core limb 铁芯柱corona 电晕corona-proof cover 防晕罩correcting circuit 校正电路correction factor 校正系数COS = change-over switch 切换开关CP = candle power 烛光creepage distance 爬距crest 峰，峰值crest voltage 峰值电压CS = control switch 控制开关CT = current transformer 电流互感器burden of CT CT的二次容量zero sequence CT 零序CTCU = coefficient of utilization 利用系数current电流capacitive current 电容电流dynamic stable current 动稳定电流field current 磁场电流impressed current 外加电流inductive current 电感电流interrupting current 开断电流leakage current 泄漏电流line-charging current 线路充电电流making current 关合电流momentary current 瞬时电流negative sequence current 负序电流no-load current 空载电流nominal discharge current 标称放电电流peak withstand current 峰值耐受电流rated breaking current 额定开断电流rated short time current 额定短时耐受电流reactive current 感性电流short circuit current 短路电流starting current 起动电流stray current 泄漏电流rated continuous current 额定持续电流zero sequence current 零序电流current amplification 电流放大current collector 集电器current converter 变流器current intensity 电流强度secondary current of CT CT的二次电流current shunt 分流器phase current 相电流DDC system 直流系统de-energized equipment 不带电设备definite time lag 定时限deformation 变形dehydrating breather 吸湿器delay 延时long time delay 长延时short time delay 短延时delta connection 三角形连接depth of embedded grounding wire 接地线埋深derating factor 降容系数diagram 图图纸CWD =control wiring diagram 控制接线图EWD =elementary wiring diagram 原理接线图mimic diagram 模拟图one-line diagram 单线图dial 拔号diameter 直径direct dialling 直拨directly burying 直埋敷设discharge 放电deep discharge 过放电intercept lightning discharge 截取雷电流self discharge 自放电discharge counter 放电计数器discharge final voltage 放电未期电压disconnection 解列busbar disconnection 母线解列system disconnection 系统解列system disconnection and field extinction解列灭磁dispatcher 调度员distortion factor 畸变系数diversity factor 分散系数document 文件double column 双柱DP = drip-proof 防滴型draw-out carriage 抽出式小车dust proof type 防尘型Eearthing 接地earthing rod 接地极earthing terminal 接地端子efficiency 效率electric 电气electric braking 电气制动electric welding machine 电焊机electrical life 电气寿命electricity engineering 电气工程electrode pole 电极electrolyte 电解液electromagnet 电磁铁3electromagnetic induction 电磁感应electromotance 电动势electronic element 电子元件emergency bell 事故铃energy 能，能量forced line energization 线路强送电successful forced line energization 线路强送电成功trial line energization 线路试送电enter the cubic from the top 柜顶进线enter the cubicle from the bottom 柜底进线excitation 励磁reducing excitation 减励磁force excitation 强励low excitation 低励磁over excitation 过励磁excitation cubicle 励磁柜excitation current 励磁电流force excitation factor 强励系数excitation initiating equipment 起励设备static excitation system 静态励磁系统excitation system response ratio 励磁系统响应比excitation transformer 励磁变压器excitation voltage 励磁电压exciter 励磁机main exciter 主励磁机pilot exciter 副励磁机standby exciter 备用励磁机expansion join 伸缩节expected life 期望寿命explosion-proof type 防爆型Ffailure alarming signal 事故报警信号fault 故障grounding fault 接地故障fault recollecting and recording device 事故追忆记录装置fault recorder 故障记录F-C = high-voltage current limiting fuse and vacuum contactor 高压限流熔断器及真空接触器feeder 馈线incoming feeder 进线outgoing feeder 出线feeder bay 馈线间隔field 磁场field extinction 灭磁field flashing equipment 起励设备field voltage 磁场电压fire 火fire proof blockage 防火堵料fire proof limit 耐火极限fire proof partition 耐火隔板fire protection pillows 阻火包fire retardant coating 阻燃涂料single face exit sign fixture 单面出口标志灯flexible joint 挠性接头FOA = forced oil air cooled 强油风冷foot candle ( F.C ) 英尺-烛光forced outage 强迫停机frequency 频率frequency converter station 变频站fuse 熔断器no powder-filled cartridge fuse 无填料封闭管式熔断器plug-in type fuse 插入式熔断器powder-filled cartridge fuse 有填料封闭管式熔断器screw-type fuse 螺旋式熔断器self-mending fuse 自复熔断器fast acting fuse 快速熔断器fuse blow 熔断器熔断Ggalvanic protection system 牺牲阳极保护系统galvanized steel 镀锌钢gap 间隙protective gap 保护间隙gapless metaloxide type 无间隙金属氧化型generator 发电机direct current generator 直流发电机dual inner water cooled generator 双水内冷发电机signal generator 信号发生器water-hydrogen-hydrogen coolinggenerator 水-氢-氢冷发电机generator hydrogen cooling system 发电机氢冷却系统generator load curve 发电机负荷曲线generator pedestal 发电机基座generator rotor 发电机转子generator sealing oil system 发电机密封油系统generator stator 发电机定子generator terminal 发电机端子generator terminal lead 发电机引出线generator termination room 发电机出线小室generator water cooling system 发电机水冷却系统generator-transformer extension unit 发变组扩大单元generator-transformer unit 发电机变压器组GIS = gas insulated switchgear 全封闭组合电器Glare 眩光glass cloth tape 波纤带grading ring 均压环、屏蔽环ground pad 接地端子groundbed 接地床anode groundbed 阳极接地床distributed-type groundbed 分散型接地床impressed current groundbed 泄漏电流接地床directly (solid) grounded 直接接地effectively grounded 有效接地un- grounded 不接地grounded through resistor 通过电阻接地grounding 接地single-phase grounding 单相接地grounding conductor 接地导体grounding megger 接地电阻测试仪main grounding network (grid) 主接地网grounding system 接地系统grounding terminal 接地端子grounding wire 接地线guarantee 保证Hharmonics 谐波4even harmonic 偶次谐波odd harmonic 奇次谐波heater 加热器self limiting parallel heater 自限制式并联加热器heating element 加热元件hertz (Hz) 赫兹high 高high pressure sodium ( HPS ) 高压钠灯high voltage transmission line 高压线路high-frequency amplification 高频放大high-frequency filter 高频滤波器hot-dipped galvanized 热镀锌Iidentification 识别igniter 触发器illuminance 照度impedance 阻抗asymmetrical impedance 不对称阻抗negative-sequence impedance 负序阻抗positive-sequence impedance 正序阻抗zero sequence impedance 零序阻抗impressed current cathodic protection 外加电流阴极保护indicator 指示器indoor type 户内式initial 首次initial power transmission 首次送电initial synchronization 首次并网input 输入instrumentation 测量仪表insulation 绝缘epoxy resin insulation 环氧树脂绝缘insulating strength 绝缘强度layer insulation 层间绝缘mica insulation 云母绝缘plastic insulation 塑料绝缘section insulation 段间绝缘turn insulation 匝绝缘insulation between phase 相间绝缘insulation class 绝缘等级insulation level 绝缘水平porcelain insulator 瓷质绝缘子post insulator 柱式绝缘子supporting insulator 支撑绝缘子suspending insulator 悬挂式绝缘子tension insulator 耐张绝缘子insulator 绝缘子interlock 联锁inverse time lag 反时限inverter 逆变器IPB = isolated phase bus duct 离相封闭母线Jtesting jack 试验端子Kkilovar (kVAR) 千乏kilovolt 千伏kilowatt (kW) 千瓦kilowatt-hour 千瓦时Llagging phase 滞后相lamp 灯left（right）arrow lamp 单面出口标志灯portable lamp 行灯mercury lamp 水银灯metal halide lamp 金属卤化物灯high intensity discharge lamp 高强气体放电灯fluorescent lamp 荧光灯incandescent lamp 白炽灯self-ballasted lamp 自镇流灯tungsten halogen lamp 碘钨灯projection lamp 投光灯lamp socket 灯座layer-to-layer 层间LDD = luminaire dirt depreciation 照明器污秽减光系数leading phase 超前相down- light 筒灯light source (illuminant) 光源flood lighting 泛光照明local lighting 局步照明emergency lighting 应急灯lighting box 照明箱emergency lighting box 事故照明箱double-faced plate lighting fixture 双块板灯flush mounted fluorescent lighting fixture嵌入式荧光灯tube fluorescent lighting fixture 简式荧光灯anticorrosive, dust-proof andwater-resistant lighting fixture 三防灯具wrap-around fluorescent lighting fixture全密封荧光灯garden lighting fixture 庭院灯waterproof fluorescent lighting fixture 防水荧光灯flameproof fluorescent lighting fixture 防爆耐火荧光灯road lighting fixture 路灯lighting fixture 灯具lightning 雷电tube type lightning arrester 管形避雷器valve type lightning arrester 阀型避雷器lightning arrester 避雷器lightning current 雷电流lightning protection 防雷lightning recorder 雷电记录器lightning rod 避雷针lightning strike 雷击lightning wave front shape 雷电波头形状lightning wire 避雷线live line connection 带电接线live line disconnection 带电拆线LLD = lamp lumen depreciation 光通量衰减系数Load 负荷target load 目标负荷load characteristic curve 负载特性曲线load rejection 甩负荷locked rotor current 转子堵转电流locked rotor torque 转子锁定转矩looping-off 解环loss 损耗copper loss 铜损iron loss 铁损load loss 负载损耗no-load loss 空载损耗supplementary load loss 附加损耗loss-ratio 损耗比5louver 格栅louver all ceiling 大面积发光天棚lug 接线片ring lug 环型接线片spade lug 铲型接线片terminal lug 接线端子lumen 流明background luminance 背景亮度luminaries 照明器effective luminous intensity 有效光强LX = lux 勒克司Mmagnetic lock 电磁锁maintenance 维护malfunction 误动作manhole 人孔marking strip 标识条MCB = miniature circuit breaker 微型断路器MCCB = moulded case circuit breaker 塑壳式断路器mechanical life 机械寿命megawatt (MW) 兆瓦metal clad 金属铠装meter 表计gravity meter 比重计insulation supervision meter 绝缘监察表kVAR-hour meter 无功电度表kW-hour meter 有功电度表phase meter 相位表plier-type current meter 钳型表power factor meter 功率因数表secondary meter 二次表计single-phase kilowatt-hour meter 单相电能表three-phase kilowatt-hour meter 三相电能表voltage meter 电压表watt-hour meter 电度表MF = maintenance factor 维护系数MHF = mounting height above the floor 距地面安装高度MHWP = mounting height above the work-place 距工作面安装高度milliammeter 毫安表millivoltmeter 毫伏表mimic bus 模拟母线mis-operation 误操作MOC = mechanism operated cell switch机构操作式开关motor 电动机adjustable speed motor 调速电动机commutator motor 整流子电动机governor motor 调速电动机horizontal type motor 卧式电动机induction motor 诱导电动机synchronous motor 同步电动机variable speed motor 可变速电动机vertical type motor 立式电动机motor maximum torque 电动机最大转矩mounted 镶嵌，安装standing pole mounted 立杆安装ceiling mounted 嵌入顶棚handrail mounted 扶手安装open mounted 明装wall mounted 吸壁flush mounted 暗装pendant mounted 悬挂stanchion mounted 柱上安装surface mounted 吸顶安装mounting type 安装方式movable type 移动式Nnameplate 铭牌negative pole 负极neutral point 中性点normal 正常NPB = non-segregated phase bus duct 共箱母线Oohm 欧姆OHM = ohmmeter 欧姆表oil level indicator 油位指示器OLTC = on-load tap-changer 有载分接开关open circuit characteristic curve 开路特牲曲线operate 操作operated in single phase 分相操作operated in three phase 三相操作operating duty cycle 操作顺序hydraulic operating mechanism 液压操作机构pneumatic operating mechanism 气动操作机构spring stored-energy operatingmechanism 弹簧贮能操作机构operating mechanism 操作机构operation 运行load limit operation 限负荷运行open phase operation 非全相运行trial operation 试运行pole slip operation 滑差运行operation mode 运行方式oscilloscope 示波器outdoor type 户外式outgoing feeder gantry structure 出线门型架构outgoing line 出线direction of outgoing line 出线方向output 输出shaft output 轴功率output increment 增负荷output reduction 降负荷overhead line 架空线over-flux 过激磁over-voltage times 过电压倍数oxygen index 氧指数PP.U. value = per unit value 标幺值packing instruction 包装说明paging dispatching unit 扩音调度机panel 盘control panel 控制盘side panel 边屏parallel 并联parallel branch 并联支路parameter 参数partial discharge 局部放电periodic duty service 定期运行phase 相in-phase 同相6phase angle 相角phase sequence 相序phase shifter 移相器phase to ground 相对地phase-angle difference 相角差plug-in unit 插件pole and tower 杆塔pole plate 极板pole-mounting type 柱上式positive pole 正极potential 电位,电势protective potential 保护电位step potential 跨步电压touch potential 接触电压transferred potential 传递电位zero potential 零电位potentio meter 电位计power 功率,能量active power 有功功率apparent power 视载功率electric power 电功率loss of power 失电reactive power 无功功率stand by power 备用电源power factor 功率因数line power flow 线路潮流power grid 电网auxiliary power ratio 厂用电率AC power source 交流电源DC power source 直流电源power system swing 系统振荡auxiliary power system 厂用电系统power system 电力系统printed wiring board 印刷电路板protection 保护back-up protection 后备保护branch overcurrent protection 分支过流保护busbar protection 母线保护cathodic protection 阴极保护differential protection 差动保护distance protection 距离保护freeze protection 防冻generator main protection 发电机主保护grounding protection 接地保护high-frequency protection 高频保护impedance protection 阻抗保护instantaneous overcurrent protection 速断保护longitudinal differential protection 纵差保护loss-of field protection 失磁保护low frequency protection 低频保护negative-sequence current protection 负序电流保护out-of step protection 失步保护over current protection 过流保护over excitation protection 过励磁保护reverse power protection 逆功率保护start-up protection 起动保护thermo-magnetic protection 热磁保护transverse differential protection 横差保护under voltage protection 低电压保护zero-sequence current protection 零序电流保护PT (=potential transformer) balanceprotection PT断线保护protection level at steep current 陡波冲击保护水平protective zone 保护范围PVC(polyvinyl chloride) insulated cable 聚氯乙烯绝缘电缆Qquality assurance 质量保证quality control 质量控制Rradio 无线电rated 额定rated input 额定输入rated output 额定输出rated value 额定值reactance 电抗capacitive reactance 容抗inductance reactance 感抗subtransient reactance 次暂态电抗synchronous reactance 同步电抗transient reactance 暂态电抗reactive power compensation device 无功补偿装置reactor 电抗器current-limiting reactor 限流电抗器disruptive reactor 分裂电抗器grounding reactor 接地电抗器shunt reactor 并联电抗器receiver 接收机receptacle (socket) 插座receptacle plug 插头re-close 重合闸recording 记录recording duration 记录时间recording instrument 记录仪表rectifier 整流器rectify 整流redial 重拨reflectance factor 反射系数reignite 重燃relative 有关的relay 继电器auxiliary relay 辅助（中间）继电器blocking relay 闭锁继电器Buchholtz relay 瓦斯/压力断电器closing relay 合闸继电器control relay 控制继电器current relay 电流继电器current-limiting relay 限流继电器delayed relay 延时继电器digital type protection relay 数字式继电保护directional relay 方向继电器distance relay 距离继电器flicker relay 闪光继电器lockout relay 出口继电器micro-processor based protective relay微机继电保护pilot relay 辅助继电器plugging relay 防逆转继电器position relay 位置继电器reclosing relay 重合闸继电器reed relay 舌簧继电器self-starting relay 自启动继电器SIC protection relay 半导体继电保护thermal relay 热继电器time relay 时间继电器tripping relay 跳闸继电器two zone distance relay 两段距离继电器7voltage relay 电压继电器voltage-controlled overcurrent relay 电压控制过电流继电器relay 继电器combined protection relay 综合保护继电器protection relay panel 继电保护屏relay protection 继电保护relay station 中继站relevant 相关的repeater 中继器repeater circuit 中继电路repeater group 中继组resistance 电阻high resistance 高阻low resistance 低阻arc suppression resistor 灭弧电阻dynamic braking resistor 制动电阻non-liner resistor 非线性电阻standard resistor 标准电阻starting resistor 起动电阻resistor 电阻器resolution 分辨率rheostat 变阻器slider-type rheostat 滑线式变阻器start rheostat 起动变阻器ripple contain factor 波纹系数RMS = root-mean-square 有效值rotor 转子squirrel-cage type rotor 鼠笼型转子wound type rotor 绕线式转子rotor conductor slot 转子线槽rotor retaining ring 转子护环rotor slip ring 转子滑环rotor winding 转子线圈rubber cushion 橡皮绝缘垫SS/MH = spacing-to-mounting height ratio 距高比sampling frequency 采样频率saturation 饱和saturation characteristics 饱和特性saturation factor 饱和系数scanner 扫描器scope 范围scope of supply 供货范围scope of work 工作范围seismic 地震self-holding 自保持sensitivity 灵敏度series 串联serial capacitor compensation device 串联电容补偿装置service level 服务级别setting range 整定范围setting value 整定值SF6 gas leakage detector SF6气体泄漏检测器SF6 gas moisture analyzer SF6气体湿度分析仪SF6 gas reclaiming equipment SF6气体回收设备shade and railing 遮栏sheath 护套inner sheath 内护套outer sheath 外护套shield 屏蔽short circuit 短路three-phase short circuit 三相短路two-phase short circuit 两相短路system short circuit capacity 系统短路容量short circuit characteristic curve 短路特牲曲线short circuit ratio 短路比short time parallel 短期并列signal 信号failure signal 事故信号flash signal 闪光信号status signal 状态信号signal indicator 信号指示器SIL = switching impulse level 操作冲击水平silicon-steel sheet 硅钢片single-phase 单相sinusoid 正弦波slight pressure device 微正压装置soil resistivity 土壤电阻率solid state rectifier 固态整流器solver plated 镀银spacer 间隔棒spare parts 备品备件special tool 专用工具splice 接头factory splice 工厂接头field splice 现场接头SS = select switch 选择开关stabilized power supply device 稳压电源装置starter 起动器full-voltage starter 全电压启动器reduced-voltage starter 降压启动器rotor resistance starter 转子电阻启动器star-delta starter 星-三角起动器magnetic starter 磁力起动器stator 定子stator core 定子铁芯stator end cover 定子端盖stator housing 定子外壳stator winding 定子线圈storage 贮存storage battery 蓄电池substation 变电站sub-synchronous resonance 低频共振surge 冲击浪涌surge absorber 过电压吸收装置zinc- oxide surge arrester 氧化锌避雷器surge arrester 避雷器magnetic blow surge arrester 磁吹避雷器SVC =static VAR compensator 静态无功补偿装置switch 开关disconnecting switch 隔离开关double earthing switch 双接地刀electronic switch 电子开关fuse- switch 熔断器式开关grounding (earthing) switch 接地开关iron clad switch 铁壳开关proximity switch 极近开关single earthing switch 单接地刀static transfer switch 静态转换开关voltmeter change-over switch 电压表切换开关switch 开关dimmer switch 调光开关knife switch 刀开关pull switch 拉线开关single pole switch 单极开关8switch off 断开switch on 合上switch-fuse 负荷开关switchgear 配电装置in-door switchgear 屋内配电装置out-door type switchgear 户外配电装置day-night switching unit 昼夜开关step-up switchyard 升压站switchyard 开关站symmetrical 对称的synchronization 同期single phase synchro-control 单相同期控制synchronization checking 同期鉴定automatic quasi-synchronization 自动准同期manual quasi-synchronization 手动准同期synchronizing device 同期装置synchronous condenser 调相器synchroscope 同期表system 系统system oscillation 系统振荡Ttap lead 抽头tap position indicator 分接头位置指示器tapping 分接tapping range 分接范围tapping step 分接级TEFC = totally enclosed with fan cooler 全封闭风冷型telecontrol 遥控telemetering 遥测telephon 电话telephon set 电话机automatic exchange telephone 自动交换机dispatching telephone 调度电话机extension telephone 电话分机noise-reducing telephone 抗噪音电话机talking on the telephone 通话video telephone 可视电话telephone booth 电话亭telephone handset 电话听筒teleregulation 遥调telesignalisation 遥信terminal 端子compression terminal 压缩端子compression type terminal 压接型端子terminal block 端子排terminal screw 端子螺钉test 试验AC withstand voltage test 交流耐压试验continuous breaking capability test 连续开断能力试验DC withstand voltage test 直流耐压试验evolving fault breaking test 开断发展性故障试验insulation withstanding test 绝缘耐受试验mechanical performance test 机械性能试验out-of-phase breaking test 失步开断试验parallel breaking test 并联开断试验partial discharge test 局部放电试验performance test 性能试验rain proof test 防雨试验routine test 例行试验routine test 常规试验sealing test 密封试验seismic test 抗震试验short circuit test 短路试验short circuit making and breaking test 短路关合和开断性能试验short-line fault test 近区故障试验site test 现场试验standard type test 标准型式试验static test 静态试验switching no-load long line test 分合空载长线试验switching no-load transformer test 分合空载变压器试验switching shunt reactor test 分合并联电抗器试验temperature rise test 温升试验test report 试验报告test voltage 试验电压pen tester 试电笔TEWAC = totally enclosed with watercooled air cooler 全封闭水空冷型thermo-couple 热电偶thermometer 温度计thyristor element 硅整流元件auto-reclosing dead time 自动重合闸无电流时间time 时间breaking time 分闸时间inherent closing time 固有合闸时间inherent opening time 固有分闸时间reclosing time 重合闸时间Max.breaking time 最大全分闸时间time delay de-engergizing 延时释放time delay energizing 延时带电time lead 导前时间tin galvanized 镀锡TOC = truck operated cell switch 小车操作式开关torque 转矩breakdown torque 破坏转矩starting torque 起动转矩torsional stress 扭应力transducer 变送器transformer 变压器auto- transformer 自耦变压器booster transformer 增压变压器busbar straight-through currenttransformer 母线式电流互感器bushing current transformer 套管式电流互感器core type transformer 芯式变压器coupling-capacitor voltage transformer耦合电容式电压互感器current transformer 电流互感器dry type transformer 干式变压器isolated transformer 隔离变压器lighting transformer 照明变压器low voltage auxiliary transformer 低压厂用变压器low voltage common transformer 低压公用变压器main transformer 主变压器maintenance transformer 检修变压器measuring transformer 测量用互感器oil-immersed type transformer 油浸变压器protecting transformer 保护用互感器PT = potential transformer 电压互感器shell type transformer 壳式变压器9。

电气常用词汇_中英对照电子产品常用英文词汇一、常见电子电气类英文单词1.功率power2.电压voltage3.电流current4.频率frequency5.效率efficiency6.波形waveform7.交流alternating-current8.直流direct-current9.适配器adaptor10. 转换器converter11. 逆变器inverter12. 充电器charger13. 控制器controller14. 启动器jump starter15. 器件device16. 元件component17. 电容器capacitor18. 电阻resistor19. 电感inductor20. 二极管diode21. 稳压二极管zener22. 三极管audion23. 场效应管MOSFEET(Metel-Oxide-Semiconductor Field Effect Transistor)24. 变压器transformer25. 光藕optical coupler26. 保险丝fuse27. 半导体semiconductor28. 瓷片电容ceramic capacitor29. 电解电容electrolytic C30. 电感inductance31. 电容capacitance32. 电阻resistance33. 感性的inductive34. 容性的capacitive35. 阻性的resistive36. 阻抗impedance37. 纯正弦波pure sine wave38. 修正正弦波modified sine wave39. 方波square wave40. 恒流源constant current source 41. 恒压源constant voltage source42. 纹波电流ripple current43. 涌入电流inrush current44. 空载电流no-load current45. 电网power system46. 死区时间dead time47. 浮充电压float charge voltage48. 正向电压forward voltage drop49. 续流二极管freewheel diode50. 肖特基二极管schottky51. 整流桥bridge rectifier52. 超快速整流器ultra fast rectifier53. 检测电阻sense resistor54. 振荡电阻timing resistor55. 散热片thermal slug/heat sink/ radiator56. 断路器breaker57. 过流保护器circuit breaker58. 自由运行free running59. 满负载full load60. 过载overload61. 轻载light load62. 加载upload63. 静态static （state）64. 动态dynamic （state）65. 稳态的steady66. 静电static electricity67. 电源调整率line regulation68. 负载调整率load regulation69. 满载效率full load efficiency70. 最佳效率optimum efficiency71. 输出效率output efficiency72. 峰值效率peak efficiency73. 标称效率declared efficiency74. 视在功率apparent power75. 有功功率active power76. 无功功率reactive power77. 功率因数power-factor78. 耗散功率power dissipation79. 空载损耗no-load loss80. 关断状态off state81. 电源工作电压operating supply voltage82. 电压参考voltage reference83. 参考值reference value84. 反馈feedback85. 产品型号part number86. 掉电power down87. 上电power up88. 电源正常power good89. 欠压锁定under voltage lock out (UVLO)90. 上拉pull up91. 下拉pull down 92. 上升沿rising edge93. 下降沿falling edge94. 上限upper limit95. 下限lower limit96. 极性polarity97. 藕合coupling98. 故障malfunction99. 原理图schematic diagram 100. 封装footprint101. 设计流程design cycle 102. 设计余量design margin二、常用电源类英文缩写SPS：switching power supplyPWM: pulse width modulation 脉冲宽度调制ZCS：zero current switchingZVT: Zero Voltage TransitionPFC: Power Factor CorrectionRMS: Root mean square （均方根）THD: Total Harmonic Distortion (总谐波失真)OVP: Over Voltage ProtectionOCP: Over Current ProtectionOTP: Over Temperature ProtectionMCU: Micro Controller unitTVS: Transient voltage suppressorPCB: Printed circuit boardSMT: surface mounting technologyECR: Engineering Change RequestECN: Engineering Change noticeFMEA: Failure Mode Efficiency AnalysisIC: integrated circuitIE: Industrial EngineeringIT: information technologyAQL: Acceptable Quality LevelQA: Quality AssuranceQC: Qualty ControlIQC: Incoming Quality controlIPQC: In- process Quality control三绕组变压器：three-column transformer ThrClnTrans双绕组变压器：double-column transformer DblClmnTrans 电容器：Capacitor并联电容器：shunt capacitor 电抗器：Reactor 母线：Busbar 输电线：Transmission Line 发电厂：power plant断路器：Breaker刀闸(隔离开关)：Isolator 分接头：tap电动机：motor2、状态参数有功：active power无功：reactive power电流：current容量：capacity电压：voltage档位：tap position 无功损耗：reactive loss有功损耗：active loss功率因数：power-factor功率：power功角：power-angle电压等级：voltage grade 空载损耗：no-load loss铁损：iron loss铜损：copper loss空载电流：no-load current 阻抗：impedance正序阻抗：positive sequence impedance 负序阻抗：negative sequence impedance 零序阻抗：zero sequence impedance 电阻：resistor电抗：reactance电导：conductance电纳：susceptance无功负载：reactive load 或者QLoad有功负载: active load Load励磁电流(转子电流)：magnetizing current 定子：stator上限:upper limit下限：lower limit并列的：apposable 电力系统power system发电机generator励磁excitation励磁器excitor母线bus变压器transformer升压变压器step-up transformer高压侧high side输电系统power transmission system 输电线transmission line 固定串联电容补偿fixed series capacitor compensation稳定stability电压稳定voltage stability 功角稳定angle stability暂态稳定transient stability 电厂power plant能量输送power transfer 交流AC装机容量installed capacity 电网power system落点drop point开关站switch station双回同杆并架double-circuit lines on the same tower变电站transformer substation补偿度degree of compensation高抗high voltage shunt reactor无功补偿reactive power compensation 故障fault调节regulation裕度magin三相故障three phase fault故障切除时间fault clearing time 极限切除时间critical clearing time切机generator triping高顶值high limited value强行励磁reinforced excitation线路补偿器LDC(line drop compensation) 机端generator terminal静态static (state)动态dynamic (state)单机无穷大系统one machine - infinity bus system机端电压控制AVR 电抗reactance电阻resistance有功（功率）active power无功（功率）reactive power 功率因数power factor无功电流reactive current下降特性droop characteristics 斜率slope额定rating变比ratio参考值reference value分接头tap仿真分析simulation analysis 传递函数transfer function 框图block diagram 受端receive-side同步synchronization失去同步loss of synchronization 阻尼damping摇摆swing保护断路器circuit breaker电阻：resistance电抗：reactance阻抗：impedance电导：conductance电纳：susceptance导纳：admittance电感：inductance电容: capacitanceComponent 零件Bobbin线轴tape 胶带Bridge 桥式整流tapping screw 自攻螺丝Cable tie 束带terminal 端子Capacitor 电容transformer(XFMR) 变压器Case 外壳transistor 电晶体Ceramic capacitor 陶瓷电容tube 套管Chip capacitor 芯片电容varistor 突波吸收器Chip resistor 芯片电阻VR (variable resistance) 可变电阻Choke 线圈washer 垫片Connector 连接器zener 齐纳Control board 基板Diode(dio) 二极管process (制程)Epoxy 脂assembly 组立Fan 风扇burn-in (B/I) 崩应FET 埸效晶体管component 零件Filter 滤波器flux 助焊剂Fuse clip 保险丝座function test 功能测试Fuse holder 保险丝座gravity 比重Glue 胶Hi-pot test 耐高压测试Heatsink 散热片insertion 插件Fuse 保险丝ORT 可靠度测试IC 集成电路packing 包装Inductor 电感solder machine 锡炉Insulator 绝缘片station 站别Jumper wire 跳线supplier/vender 厂商Label 标签temperature 温度Lock washer 接地星形垫片torque 扭距NTC 热敏电阻touch-up(T/U) 补焊Nut 螺丝帽Output cable 输出线Output wire 输出线PCB 电路板Photo couple 光藕合二极管Regulator 稳压器Resistor 电阻Rivet 柳钉Screw 螺丝Socket 插座Solder bar 锡棒Spring washer 弹簧垫片Stand-off 支柱Star washer 星形垫片Switch 开关CRT (cathode-ray tube) 示波器Anode 阳(正，板)极PROCESS (制程)Resistor(res) 电阻pre-forming 加工成型VR(variable) 可变电阻component 零件Chip resistor 芯片电阻Capacitor(cap) 电容insertion 插件Ceramic capacitor 陶磁电容solder machine 锡炉Transformer(X’FNR)变压器assembly 组立Fuse holder 保险丝座Bridge diode 桥式整流Transistor 电晶体input(I/P) 输入output(O/P) 输出regulation 调整pecification 规格Regulation 稳压器ripple 涟波noise 噪声Control board 小基板noise buzz 无音protection 保护OVP 过电压保护OCP 过电流保护OPP 过功率保护no output(NOP) 无输出Tapping screw 自动螺丝broken/blow out (BRO) 烧机Nut 螺帽short 短路open 开路Spring washer 弹簧垫片voltage 电压Star washer 星形垫片Lock washer 接地星形垫片frequency 频率Output wire 输出线load 负载Output cable 输出线full load 满载Cable tie 束带low load 轻载Connector 连接器damage 损坏Rivet 铆钉oscilloscope 示波器Terminal 端子test 测试Stand-off 支柱adjust 调整Heatsink 散热片inspection 检验Insulator 绝缘体hi-pot test 高压测试Tape 胶带grounding 接地Tube 套管Label caution 标签(警告标签) Jumper wire 跳线Solder bar 锡棒。

电气的专业术语英文（一）电气专业术语二1. Personnel 人员职员2. Voltmeter 电压表伏特计3. Ohmmeter 欧姆计电阻表4. Megohmmeter 兆欧表5. Wattmeter 瓦特计电表功率6. Watt-hour 瓦时瓦特小时7. Ammeter 安培计电流表8. calibrate 校正9. scale 刻度量程10. rated 额定的11. interfere with 有害于。

12. indicating needle 仪表指针13. hazardous 危险的14. pivot 支点15. terminal 端子16. spiral 螺旋形的17. spring 弹簧18. shunt 分流，分路，并联，旁路19. rectifier 整流器20. electrodynamometer 电测力计21. strive for 争取22. vane 机器的叶，叶片23. strip 条，带，（跨接）片24. crude 不精细的，粗略的25. polarity 极性26. fuse 保险丝，熔丝27. rugged 坚固的28. depict 描绘，描写29. cartridge 盒式保险丝30. blow （保险丝）烧断31. plug fuse 插头式保险丝32. malfunction 故障33. deen ergize 不给…通电34. insulation 绝缘35. generator 发电机36. magneto 磁发电机37. humidity 湿度38. moisture 潮湿湿气39. abbreviate 缩写，缩写为40. transformer 变压器41. thumb 检查，查阅42. milliammeter 毫安表43. multimeter 万用表dynamometer 测力计，功率计45. aluminum 铝46. deteriorate 使….恶化47. eddy current 涡流48. gear 齿轮，传动装置49. dial 刻度盘50. semiconductor 半导体51. squirrel 鼠笼式52. diode 二极管53. thyristor 晶闸管54. transistor 电子晶体管55. triac 双向可控硅56. phase 相位（控制）57. silicon 硅58. crystal 晶体59. wafer 薄片60. anode 阳极，正极61. cathode 阴极62. collector 集电极]63. emitter 发射极64. schematic （电路）原理图符号65. leakage 漏电流66. rating 额定值，标称值，定额67. dissipate 散发68. breakdown 击穿69. heat sink 散热器70. self-latching 自锁71. commutation 换向72. geometry 几何结构73. squeeze 压榨，挤，挤榨74. light-dimmer 调光75. capability 容量76. studmounted 拴接式77. hockey puck 冰球78. fin 飞边79. active 有源的80. horsepower 马力81. diameter 直径82. in. (inch ,inches) 英寸83. extruded 型材的84. clamp 夹住，夹紧85. compound 紧密结合86. wrench 扳手87. torque 转矩，扭矩88. enclosure 外( 机) 壳89. ventilation 通风，流通空气90. sealed-off 封的91. thermal 热的，热量的92. substantially 主要地，实质上地93. aptly 适当地，适宜地94. demystify 阐明95. allude 暗指，直接提到96. cease 停止，终了97. line 线电压98. ripple 脉动.99. redundant 多余的100. separately 单独励磁地101. synchronous 同步电动机102. circuitry 电路，线路103. cost-effective 花费大的104. capacitor 电容器105. dictate 确定106. trade-off 权衡，折衷107. criteria 标准，判据108. analog electronics 电力电子学109. saturate 使…饱和110. active region 动态区域111. due 应得到的112. ratio 比，比率113. signify 表示114. encode 编码115. resonance 共鸣116. radiated 传播117. molecule 分子118. diaphragm 震动膜119. acoustic wave 声波120. wavy groove 起伏的沟槽121. deflection 挠度，挠曲122. strain gage 应变计量器123. tachometer 转速计124. thermocouple 热电偶125. oscilloscope 示波器126. analytical 解析的127. numerical 数值的128. integrate 求…的积分129. scale 改变比例130. frequency- domain 频域131. random 随机的132. audio 音频的133. operation amplifier 运算放大器134. summation 求和，加法135. sophisticated 复杂的，完善的136. mass-produce 大量生产137. subtract 减去138. inverting amplifier 反向放大器139. uninverting amplifer 同相放大器140. derive 推倒141. active filter 有源滤波器142. stabilize 使稳定143. moderate 适度的，适中的144. virtue 优点145. amplification 扩大146. capacitor 电容器147. impedance 阻抗148. bode plot 波特图149. simulate 模拟，方针150. narrowband filter 带通滤波器151. low-pass filter 低通滤波器152. high-pass filter 高通滤波器153. differential equation 微分方程154. prebias 预偏置155. summer 加法器156. weighted 加权的157. refinement 改进158. accommodate 适应159. envision 预见160. alphabet 字母表161. validity 正确性162. proposition 命题163. binary 二进制164. nevertheless 然而165. reveal 展现166. complement 补码167. truthtable 真值表168. algebraical 代数的169. trial and error 试错法，试凑法170. elapse 时间（流逝）171. enumerate 列举172. expire 期满, 终止173. brute 僵化的174. prime 上撇号175. trigger 引起, 触发176. inversion 反相, 反转177. quadruple 四合一178. fabricate 制造179. integrated circuit 集成电路180. capsule 封装181. compatible 兼容的182. obsolete 废弃的183. threshold 门限, 阈值184. zener diode 齐纳二极管185. adjacent 临近的, 接近的186. arc welding 电弧焊187. intimately 密切地188. recast 重做189. bistable circuit 双稳电路190. cutoff 截止, 关闭191. symmetry 对称192. lable 为..... 标号193. equilibria 平衡194. lever 杆, 杠杆195. latch circuit 锁存电路196. depress 压下197. flip-flop 触发器198. glitch 同步199. leading edge 上升沿200. lagging(trailing) edge 下降沿201. inhibit 禁止202. hitherto 迄今, 至今203. toggle ( 来回)切换204. impulse 推动力205. air gap 气隙206. aircraft 飞机207. alternating current, AC 交流208. armature 电枢209. automobile 汽车210. bearing 轴承211. brush 电刷212. carbon213. circumference 圆周214. clearance 间隙215. coils 线圈绕组216. commutator 换向器217. connection 接线端218. copper bar 铜导条219. copper end rings 铜端环220. core 铁心221. cylindrical 圆柱式的222. doubly excited 双边励磁223. electromechanical 机电的224. felt 毡225. ferromagnetic 铁磁的226. field pole 磁极227. flux density 磁通密度228. frame 机座，机壳229. generator 发电机230. glue 胶合，粘贴231. graphite 石墨232. induction motor 感应电动机233. laminate 叠制，叠压234. lubricant 润滑剂，润滑油235. magnetic flux 磁通236. magnetizing current 磁化电流，励磁电流237. mechanical rectifier 机械式换向器238. metallic 金属的239. penetrate 透过，渗透240. periphery 周围，圆周241. perpendicular 垂直的，正交的242. polarity 极性243. protrude 使伸出，突出244. reluctance 磁阻245. revolving magnetic field 旋转磁场246. rotor 转子247. salient 突出的248. salient-pole 凸极式249. servo 伺服250. singly excited251. slip rings 252. slot 槽，开槽253. squirrel-cage 鼠笼式，笼型254. stator 定子255. synchronous machine 同步电机256. torque 转矩257. toroid 环状物258. transformer 变压器259. unidirectional 单方向的，方向不变的260. winding 绕组261. wound-rotor 绕线式262. wrap 捆，缠，环绕263. yoke 轭264. allowable temperature rise 允许温升265. alnico 铝镍钴合金266. asynchronous machine 异步电机267. automobile starter motor 汽车启动机268. backlash 啮合间隙，齿隙269. centrifugal force 离心力270. ceramic 陶瓷的271. compound-wound 复励272. constraint 强制，约束273. counter emf 反电势274. counterpart 对应物275. culminate 达到极值点276. cumulative compound 积复励277. demagnetization 退磁，去磁278. denominator 分母279. differential compound差复励280. dissipate 浪费281. equilibrium level 平均值 282. equivalent circuit 等效电路283. figure of merit 品质因数，优值284. flicker 闪烁，摇曳 单边励磁 滑环285. flux per pole 每极磁通286. friction 摩擦287. in parallel with 并联288. in series with 串联289. in terms of 根据，在……方面290. in the vicinity of 在…附近，在…左右291. indispensable 必需的，必不可少的292. inherent 固有的293. insulation 绝缘294. long-shunt 长复励295. loss 损耗296. magnetization curve 磁化曲线297. merit 优点，长处，指标298. no load 空载299. nonetheless ，none the less 仍然，依然300. numerator 分子301. overload 过载302. permissible 允许的303. permanent-magnet 永磁304. pertinent 有关的305. power flow diagram 功率流程图306. prefix 前缀，把…放在前面307. rated torque 额定转矩308. reaction 电感309. rheostat 变阻器，电阻箱310. series-wound 串励311. shunt-wound 并励312. short-shunt 短复励313. starting current 启动电流314. starting torque 启动转矩315. synchronous speed 同步转速316. theorem 定理317. turns 匝数318. undervoltage 欠电压319. Ward-Leonard system 发电机- 电动机组系统320. windage 通风321. yield 产生，提供322. adjacent 相邻的，邻近的323. autotransformer 自耦变压器324. braking 制动325. cam 凸轮326. chamber 室，腔327. conveyor 传送机328. corrosion 腐蚀329. counterclockwise 逆时针330. counter electromotive force , CEMF反电势331. dashpot relay 油壶式继电器332. diaphragm 膜片，挡板333. drill 钻床334. elapse 过去，消逝335. enclosure 机壳336. expel 排出，放出337. fasten 固定，连接338. furnace 炉339. fuse 熔断器，保险丝340. general-purpose relay 通用继电器341. hydraulic 液压传动342. initiate 引起，促进343. intake 吸入344. knob 旋钮，圆形把手345. latching relay 自锁继电器346. lathe 车床347. limit switch 限位开关348. moisture 潮气，湿度349. mount 安装350. octal-base 八脚的351. orifice 孔，注孔352. pedal 踏板，踏蹬353. phase sequence 相序354. piston 活塞355. pivot 轴，支点，旋转中心356. plunger 可动铁心，插棒式铁心357. pneumatic 气动的358. relay 继电器359. single-phase 单相的360. solenoids 螺线管361. solid-state relay 固态继电器362. spring 弹簧363. tap 抽头364. three-phase 三相365. timing relay 延时继电器366. toggle 搬扭，刀闸367. vibration 振动368. absolute encoder 绝对编码器369. accelerometer 加速度测量仪370. actuator 执行机构371. analog-to-digital conversion, ADC 模数转换器372. angular 角的373. auxiliary 辅助的374. as a rule of thumb 根据经验375. bellows 膜盒376. binary-coded decimal,BCD377. calibration 校准，标定，刻度378. cantilever 悬臂379. closed-loop 闭环■380. induction machine 感应式电机381. horseshoe magnet 马蹄形磁铁382. magnetic field 磁场383. eddy current 涡流384. right-hand rule 右手定则385. left-hand rule 左手定则386. slip 转差率387. induction motor 感应电动机388. rotating magnetic field 旋转磁场389. winding 绕组390. stator 定子391. rotor 转子392. induced current 感生电流393. time-phase 时间相位394. exciting voltage 励磁电压395. solt 槽396. lamination 叠片397. laminated core 叠片铁芯398. short-circuiting ring 短路环399. squirrel cage 鼠笼400. rotor core 转子铁芯401. cast-aluminum rotor 铸铝转子402. bronze 青铜403. horsepower 马力404. random-wound 散绕405. insulation 绝缘406. ac motor 交流环电动机407. end ring 端环408. alloy 合金409. coil winding 线圈绕组410. form-wound 模绕411. performance characteristic 工作特性412. frequency 频率413. revolutions per minute 转/ 分414. motoring 电动机驱动415. generating 发电416. per-unit value 标么值417. breakdown torque 极限转矩418. breakaway force 起步阻力419. overhauling 检修420. wind-driven generator 风动发电机421. revolutions per second 转/ 秒422. number of poles 极数423. speed-torque curve 转速力矩特性曲线424. plugging 反向制动425. synchronous同步转速speed426. percentage 百分数427. locked-rotor torque 锁定转子转矩428. full-load torque 满载转矩429. prime mover 原动机430. inrush current 涌流431. magnetizing reacance 磁化电抗432. line-to-neutral 线与中性点间的433. staor winding 定子绕组434. leakage reactance 漏磁电抗435. no-load 空载436. full load 满载437. Polyphase 多相( 的)438. iron-loss 铁损439. complex impedance 复数阻抗440. rotor resistance 转子电阻441. leakage flux 漏磁通442. locked-rotor 锁定转子443. chopper circuit 斩波电路444. separately excited 他励的445. compounded 复励446. dc motor 直流电动机447. de machine 直流电机448. speed regulation 速度调节449. shunt 并励450. series 串励451. armature circuit 电枢电路452. optical fiber 光纤453. interoffice 局间的454. waveguide 波导波导管455. bandwidth 带宽456. light emitting diode 发光二极管457. silica 硅石二氧化硅458. regeneration 再生, 后反馈放大459. coaxial 共轴的, 同轴的460. high-performance 高性能的461. carrier 载波462. mature 成熟的463. Single Side Band(SSB) 单边带464. coupling capacitor 结合电容465. propagate 传导传播466. modulator 调制器467. demodulator 解调器468. line trap 限波器469. shunt 分路器470. Amplitude Modulation(AM 调幅471. Frequency Shift Keying(FSK) 移频键控472. tuner 调谐器473. attenuate 衰减474. incident 入射的475. two-way configuration 二线制476. generator voltage 发电机电压477. dc generator 直流发电机478. polyphase rectifier 多相整流器479. boost 增压480. time constant 时间常数481. forward transfer function 正向传递函数482. error signal 误差信号483. regulator 调节器484. stabilizing transformer 稳定变压器485. time delay 延时486. direct axis transient time constant直轴瞬变时间常数487. time invariant 时不变的488. transient response 瞬态响应489. solid state 固体490. buck 补偿491. operational calculus 算符演算492. gain 增益493. pole 极点494. feedback signal 反馈信号495. dynamic response 动态响应496. voltage control system 电压控制系统497. mismatch 失配498. error detector 误差检测器499. excitation system 励磁系统500. field current 励磁电流501. transistor 晶体管502. high-gain 高增益503. boost-buck 升压去磁504. feedback system 反馈系统505. reactive power 无功功率506. feedback loop 反馈回路507. automatic Voltage regulator(AVR)自动电压调整器508. third harmonic voltage 三次谐波电压509. reference Voltage 基准电压510. magnetic amplifier 磁放大器511. amplidyne 微场扩流发电机512. self-exciting 自励的513. limiter 限幅器514. manual control 手动控制515. block diagram 方框图516. linear zone 线性区517. potential transformer 电压互感器518. stabilization network 稳定网络519. stabilizer 工含宀w 稳定器520. air-gap flux 气隙磁通521. saturation effect 饱和效应522. saturation curve 饱和曲线523. flux linkage 磁链524. per unit value 标么值525. shunt field 并励磁场526. magnetic circuit 磁路527. load-saturation curve 负载饱和曲线528. air-gap line 气隙磁化线529. polyphase rectifier 多相整流器530. circuit components 电路元件531. circuit parameters 电路参数532. electrical device 电气设备533. electric energy 电能534. primary cell 原生电池535. energy converter 电能转换器536. conductor 导体537. heating appliance 电热器538. direct-current 直流539. self-inductor 自感540. mutual-inductor 互感541. the dielectric 电介质542. storage battery 蓄电池543. e.m.f = electromotive fore 电动势544. unidirectional current 单方向性电流545. circuit diagram 电路图546. load characteristic 负载特性547. terminal voltage 端电压548. external characteristic 外特性549. conductance 电导550. volt-ampere characteristics 伏安特性551. carbon-filament lamp 碳丝灯泡552. ideal source 理想电源553. internal resistance 内阻554. active (passive) circuit elements有(无) 源电路元件555. deviation 偏差556. leakage current 漏电流557. circuit branch 支路558. P.D. = potential drop 电压降559. potential distribution 电位分布560. r.m.s values = root mean square values 均方根值561. permanent magnet 永磁体562. effective values 有效值563. steady direct current 恒稳直流电564. sinusoidal time function 正弦时间函数565. complex number 复数566. Cartesian coordinates 笛卡儿坐标系567. modulus 模568. real part 实部569. imaginary part 虚部570. displacement current 位移电流571. trigonometric transformations 瞬时值572. epoch angle 初相角573. phase displacement 相位差574. signal amplifier 小信号放大器575. mid-frequency band 中频带576. bipolar junction transistor（BJT 双极性晶体管577. field effect transistor（FET）场效应管578. electrode 电极电焊条579. polarity 极性580. gain 增益581. isolation 隔离分离绝缘隔振582. emitter 发射管放射器发射极583. collector 集电极584. base 基极585. self-bias resistor 自偏置电阻586. triangular symbol 三角符号587. phase reversal 反相588. infinite voltage gain 无穷大电压增益589. feedback component 反馈元件590. differentiation 微分591. integration 积分下限592. impedance 阻抗593. fidelity 保真度594. summing circuit总和线路反馈系统中的比较环节595. pneumatic 气动的596. Oscillation 振荡597. inverse 倒数598. admittance 导纳599. transformer 变压器600. turns ratio 变比匝比601. ampere-turns 安匝（数）602. mutual flux 交互（主）磁通603. vector equation 向（相）量方程604. power frequency 工频605. capacitance effect 电容效应606. induction machine 感应电机607. shunt excited 并励608. series excited 串励609. separately excited 他励610. self excited 自励611. field winding 磁场绕组励磁绕组612. speed-torque characteristic 速度转矩特性613. dynamic-state operation 动态运行614. salient poles 凸极615. excited by 励磁616. field coils 励磁线圈617. air-gap flux distribution 气隙磁通分布618. direct axis 直轴619. armature coil 电枢线圈620. rotating commutator 旋转（整流子）换向器621. commutator-brush combination换向器-电刷总线622. mechanical rectifier 机械式整流器623. armature m.m.f. wave 电枢磁势波624. Geometrical position 几何位置625. magnetic torque 电磁转矩626. spatial waveform 空间波形627. sinusoidal - density wave 正弦磁密度628. external armature circuit 电枢外电路629. instantaneous electric power 瞬时电功率630. instantaneous mechanical power 瞬时机械功率631. effects of saturation 饱和效应632. reluctance 磁阻633. power amplifier 功率放大器634. compound generator 复励发电机635. rheostat 变阻器636. self - excitation process 自励过程637. commutation condition 换向状况638. cumulatively compounded motor 积复励电动机639. operating condition 运行状态640. equivale nt T - circuit T 型等值电路641. rotor (stator) winding 转子（定子绕642. winding loss 绕组( 铜) 损耗643. prime motor 原动机644. active component 有功分量645. reactive component 无功分量646. electromagnetic torque 电磁转矩647. retarding torque 制动转矩648. inductive component 感性（无功）分量649. abscissa axis 横坐标650. induction generator 感应发电机651. synchronous generator 同步发电机652. automatic station 无人值守电站653. hydropower station 水电站654. process of self —excitati on 自励过程655. auxiliary motor 辅助电动机656. technical specifications 技术条件657. voltage across the terminals 端电压658. steady - state condition 瞬态暂态659. reactive in respect to 相对….呈感性660. active in respect to 相对….呈阻性661. synchronous condenser 同步进相（调相）机662. coincide in phase with 与… . 同相663. synchronous reactance 同步电抗664. algebraic 代数的665. algorithmic 算法的666. biphase 双相的667. bilateral circuit 双向电路668. bimotored 双马达的669. corridor 通路670. shunt displacement current 旁路位移电流671. leakage 泄漏672. lightning shielding 避雷673. harmonic 谐波的674. insulator string 绝缘子串675. neutral 中性的676. zero sequence current 零序电流677. sinusoidal 正弦的678. square 平方679. corona 电晕, 放电680. bypass 旁路681. voltmeter 电压表682. ammeter 电流表683. micrometer 千分尺684. thermometer 温度计685. watt-hour meter 电度表686. wattmeter 电力表687. private line 专用线路688. diameter 直径689. centimeter 厘米690. restriking 电弧再触发691. magnitude 振幅692. oscillation 振荡693. auxiliary 辅助的694. protective gap 保护性间隙放电695. receptacle 插座696. lightning arrester 避雷装置697. bushing 套管698. trigger 起动装置699. stress 应力700. deterioration 损坏, 磨损701. spark gap 火花放电隙702. traveling-wave 行波703. wye-connected 星形连接704. enclosure 设备外壳705. live conductor 带电导体706. fuse 熔断器707. structural 结构上的708. out-of-step 不同步的709. resynchronize 再同步710. synchroscops 同步指示器711. automatic oscillograph 自动示波器712. nominally 标称713. sampling 采样714. potential transformer 电压互感器715. fraction 分数716. switchyard 户外配电装置717. hazard 危险718. bushing 高压套719. contact 触点720. energize 励磁721. trip coil 跳闸线圈722. over-current relay 过电流继电器723. armature 衔铁724. pickup current 始动电流725. release current 释放电流726. solenoid relay 螺管式继电器727. induction-disc relay 感应圆盘式继电器728. inverse time relay 反时限继电器729. hydraulic 液力的730. dashpot 阻尼器733. electrical stressing 电气应力734. mechanical stressing 机械应力・735. crystal 晶体的，水晶，晶体736. demodulation 解调737. derivative 导数738. diaphragm 膜片739. differentiation 微分740. discrete 离散的741. displacement 位移742. eddy 涡流743. encoder 编码器744. error 误差，偏差745. expedite 加速746. feedback 反馈747. feedforward 前馈748. forging 锻造749. hysteresis 磁滞750. immunity 抗扰性751. impedance 阻抗752. increment encoder753. inertia754. integration 755. interface756. jerk 757. kinematic758. longitudina l 759. manipulation s760. manipulat or 振动，冲击运动的，运动学的 经度了 ; 纵向的操作，控制，处理机械手，操作器 被测量，被测量对象 调制 多路转换器 偏心开环 垂直的，正交的垂直的，正交的 光电传感器 压电的设备 电位器 主要的，突出的棱型的 距离 量化径向的 多余的，重复的代表，表示解算器 共振 旋转的，转动的 设备鲁棒性 轧制785. sampling period 采样周期增量编码器 惯性 积分 接口761. measurand 762. modulation 763. multiplexer764. offset 765. open-loop 766. orthogonal 767. perpendicular 768. photosensor769. piezoelectric 770. plant 装置， 771. potentiometer 772. predominant 773. prismatic 774. proximity 775. quantization 776. radial 777. redundant 778. representation 779. resolver780. resonance 781. revolute 782. rig 783. robustness784. rolling786. signal-to-noise ration ,SNR言噪比787. strategy 策略788. subsequently 其后789. tachometer 测速仪790. terminology 术语，专门名词791. threshold 门，界限，阈值792. trajectory 轨迹793. transducer 传感器794. transient 瞬态的795. transistor-to-transistor logic，TTL 晶体管- 晶体管逻辑796. transit 运输797. translatory 平移的798. algorithm 算法799. ambiguity 模棱两可800. antenna 天线801. arbitration 仲裁，公断802. autonomous 匿名的803. capacity 容量804. chao 混乱805. checksum 检查和806. circumnavigate 饶过807. client-server 客户- 服务器808. client-server model 客户服务器模型809. corridor 通道，走廊810. decouple 解耦，去除干扰811. depict 描述812. distributed system 分布式系统813. dungen 地牢814. electronic mail 电子邮件815. entity 实体816. etiquette 规则817. exponential 指数818. fallout 余波，附带结果819. forward 转发820. full-duplex 全双工821. gamut 全体，整体822. goggles 护目镜，潜水镜823. half-duplex 半双工824. hierarchy 阶梯，等级825. host 主机826. infrastructure 基础，底层结构827. interactive 交互式828. interface data unit 接口数据单元829. inventory 存货，清单830. killer 迷人的831. newsgroup 新闻组832. object-oriented 面向对象的833. outgoing 外出了，离开的834. pointer 指针835. primitive 操作，原型836. process 进程837. propagation 传播，宣传838. protocol 协议839. protocol data unit 协议数据单元840. remote database 远程数据库841. remote login 远程登陆842. remote terminal 终端843. reprisal 报复844. router 路由器845. service data unit 服务数据单元846. simultaneous 同时的847. static allocation 静态分配848. subnet 子网849. taxonomy 分类学，分类850. telemedicine 远程医疗851. terminology 术语852. testbed 测试平台853. therapy 治疗854. token 令牌855. topology 拓扑学856. videoconference 可视会议857. virtual reality 虚拟现实858. worldwide shared 全球共享的859. wide area network 广域网860. actuator 执行器861. bar code reader 条码阅读器862. by-product 副产品863. call for864. contiguous 邻近的865. culprit 犯罪者866. elusive 难以捉摸的867. filter 滤波器868. fluctuation 升降剥动，不规则的变化869. hardwired 硬接线的870. havoc 大破坏871. high-volume 大容量872. induction coupling 感应耦合873. inference 干扰874. injection molding 注模875. instruction set 指令集876. interconnection 相互连接877. isolation transformer 隔离变压器878. maintenance 维护879. multiple axis drive 多轴驱动880. pilot light 信号灯881. RF noise 射频干扰882. shock 冲击883. solenoid 线圈884. stand-alone 独立的885. stepper 步进电机886. thermocouple 热电偶887. troubleshoot 排除故障888. uninterruptible power supply 不间断电源889. vendor 生产厂商890. vibration 震动891. water-tight 防水892. wreak 发泄，报复893. configuration 组态894. Cyclic Redundancy Check 895. electromagnetic interference 896. meticulous 897. nonvolatile 898. parity 899. peripheral 900. pharmaceutical901. rack mounting 902. resident program 903. spare 904. standby 905. volatile 循环冗余检查 电磁干扰 详细的 非挥发的 校验 外设 药剂，药品 机架安装 驻留程序 备用的 后备的 906. watchdog timer 907. distribution 908. primary 909. radial 910. premise 挥发的，易失的 看门狗定时器 分配，配电 911. residential 912. residence 913. occupancy 914. tap 915. establishment 916. dwelling 917. panel 最初的，基本的，初级线圈 径向的，辐射状的 上述各点，前言，根据 住宅的，居住的 住宅 占有，占用，居住 抽头 组织，部门 住房 918. laundry 919. means 920. condominium ( 921. branch circuit 922. conduit 923. rigid 操纵台，面板 洗衣房 手段，工具 国际 ) 共官 直路 924. clamp 925. bolt 926. cubicle 927. interrupter 导线，导线管 刚性的，坚固的 夹，钳 螺栓 立方体 电、路 ) 器 断续( 流、 928. margin 余量，裕度 929. nuisance 障碍，公害930. receptacle 插座，插孔931. algebraic 代数的936. ballast镇流器 937. feeder 馈电线，电源线，馈电板 938. ground-fault protector (GFP)接地故障保护器，接地故障断 路器941. whilst=while942. sphere 球体943. counteract 抵抗，抵消，消除944. joint 关节，铰链945. keyway 键槽946. pivot 轴，支点947. link 连杆948. throttle 节流阀，风门949. synthesis 综合物950. mass 物质，块，堆951. classic 古典的，经典的，传统的952. steer 驾驶，操纵，引导953. servomechanism 伺服机构，伺服系统954. actuate 激励，驱动955. intimately 紧密地，直接的956. academic 纯理论的957. dial 刻度盘，调节控制盘958. calibration 标定，标准化959. lubrication 润滑，注油960. arrangement 结构961. wear 磨损，损耗962. subtle 微妙的，巧妙的963. transducer 变送器964. hand-wheel 手轮，驾驶盘，操纵盘965. hydraulic 液压的，液压传动装置 966. pneumatic 气动的，气动力学的932. virtually 实际上，实质上933. fluorescent 荧光的，有荧光性的934. fixture 设备，装置 ]935. vicinity 附近，邻近，接近939. ground-fault circuit interrupter(GFCI)940. centrifugal离心的，离心力967. electro-hydraulic 电动液压的968. electro-pneumatic 电动气动的969. coincidence 一致，相等970. faithful 正确的，可靠的971. fidelity 重现精度，真实，正确972. oscillatory 振动的，摆动的973. align 调整，校准974. profile 轮廓，仿行975. milling machine 铣床976. gyroscope 陀螺仪977. launcher 发生器，启动装置978. inertial 惯性的，惯量的979. electrolytic 电解的980. plate （电）镀981. distillation 蒸馏982. blend 混合，调和，配料983. philosophy 基本原理984. analytical 分析的，分解的985. orifice 侧流板，隔板986. diaphragm 膜，隔板987. knob 钮，圆形把手988. nomenclature 术语989. liable 有责任的990. autonomic 自治的991. grossly 大概，大体上的992. ideological 思想的993. morally 道德上，道义上994. boredom 讨厌，无趣995. deterioration 变化，降低品质996. ambient 环境的997. remarks 附注，要点998. differential pressure transducer 差压变送器999. viscous 粘稠的1000. viscous粘滞摩擦.friction1001.bearing 轴承1002.rolling mill 轧钢机1003.mine minder 矿坑卷扬机1004.velodyne 伺服积分器1005.feasible 可行的1006.regenerative braking 回馈制动1007.eddy currentbraking涡流制动1008.dynamic braking 能耗制动1009.reverse braking 反接制动1010.advent 出现1011.prolong 延长1012.armature 电枢1013.contactor 接触器1014.hoist 起重机1015.field winding 励磁绕组mutator 换向器1017.riiple 纹动1018.creep 蠕动1019.tachogenerator 测速发电机1020.quadrant 象限1021.coast 跟踪惯性1022.profile 轮廓1023.conveyance 运输工具1024.lever 手柄，控制杆1025. forced commutation 强迫换流1026. ac squirrel cage induction motor交流笼型感应电动机1027. accutrol 控制器1028. stator 定子1029. rotor 转子1030. DC link 直流环节1031. Triac 双向晶闸管1032. Adjustable-voltage inverter 电压型逆变器1033. Current source inverter 电流型逆变器1034. refinement 明确表达1035. pros and cons 优缺点1036. cogging1037. retrofit1038. damp er 1039. pitfall1040. verni er 1041. jog 齿槽效应 .改型 减速器 缺陷 游标尺 啮合输出轨道 熟料冷却器 炉磨床齿轮 存货塔轮，快慢轮 升级，提高 强制通风 吸风机 弯头11. interfere with 有害于。

电力行业的专业用语，中英对照表，太全了Part1电气名词Electric items交(直)流：Alternating (direct) current短路电流：Short-circuit current起始次暂态短路电流：Initial subtransient short-circuit current 冲击电流：Impulse current稳态短路电流：Steady state short-circuit current临界电流：Critical current切断电流：Rupturing current熔断电流：Blow-out current故障电流：Fault current计算电流：Calculating current极限有限电流：Limit effective current过电流：Over current逆电流：Inverse current整定电流：Setting current额定电流：Rated current电流密度：Current density短路电流最大有效值：Maximum effective value of short-circuit current高压：High-voltage , High-tension低压：Low-voltage , Low-tension计算电压：Calculating voltage激磁电压：Exciting voltage冲击电压：Impulse voltage临界电压：Critical voltage残留电压：Residual voltage击穿电压：Puncture voltage脉动电压：Pulsating voltage供电电压：Supply voltage电力电压：Power voltage照明电压：Lighting voltage灯丝电压：Filament voltage额定电压：Rated voltage电压损失：Voltage loss过(欠)电压：Over (under) voltage线路电压：Line voltage电压降：Voltage drop工作电压：Working voltage一次电压：Primary voltage二次电压：Secondary voltage电源：Electric source (power supply)自控电压：Power supply for process control6KV 控制闪光电源：Flashing supply for 6kV control 工作电源：Working power supply (electric source) 保安电源：Emergency power supply (electric source) 直流稳压电源：Stabilized D.C. source控制电源：Control supply直流电源：D.C. source交流电源：A.C. source负荷计算：Load calculation设备容量：Installed capacity需要容量：Electric demand功率因数：Power factor安装高度：Mounting height耐电压：Breakdown voltage工频耐压：High-voltage test with working frequency 表面闪络：Surface flash-over直流泄漏：D.C. leakage体电阻率：Volume resistivity介质损失角：Dielectric loss angle击穿强度：Puncture intensity电压等级：Voltage grade比重：Specific gravity性能：Feature相序：Phase sequence瞬时：Instantaneous倾角：Angle of inclination跨度：Span正极：Positive pole负极：Negative pole截面(积)：Cross section area辅助电源：Auxiliary source遮断容量：Interrupting capacity载流量：Current-carrying capacity校正系数：Correction factor连续负荷：Continuous load长期载流量：Continuous capacity长时间额定值：Longtime rating电动机堵转电流：Locked-rotor motor current 限定负荷：Limited load电感负荷：Inductive load感应电流：Induced currentPart2线路(母线、回路)Lines (Bus , circuits)母线：Bus-bar合闸电源母线：Closing power source bus闪光母线：Flashing-bus备用母线：Spare bus装在支柱上的插接式母线：Post-supported plug-in bus way装在吊钩上的插接式母线：Hook-supported plug-in bus way 装在支架上的插接式母线：Bracket-supported plug-in bus way 小母线：Miniature bus电源小母线：Power supply miniature bus操作小母线：Operating miniature bus事故信号小母线：Miniature bus for fault signal闪光小母线：Flashing miniature bus主母线：Main bus直流主母线：D.C. main bus预告母线：Prewarning bus干线：Main line照明干线：Lighting main line接地干线：Grounding main line插座干线：Receptacle main line电压干线：Voltage main line端子出线：T erminal outgoing中性线：Neutral支线：Branch-line引入线：Lead-in电气线路：Electric circuit交流配电线路：A.C. distribution circuit直流配电线路：D.C. distribution circuit事故照明线路：Emergency lighting circuit控制线路：Control circuit接地或接零线路：Grounding or neutralizing circuit信号线路：Signal circuit有接地极的接地线路网：Grounding with grounding electrodes定子绕组测温回路：Temperature measuring circuit for stator winding接地信号回路：Grounding signal circuit闪光信号回路：Flashing-signal circuit开阀回路：Circuit for opening valve关(闭)阀回路：Circuit for closing valve开度计回路：Circuit for opening meter电流测量回路：Current-measuring circuit差动保护回路：Differental protective circuit过流保护回路：Over-current protective circuit合闸回路：Closing circuit停车延时回路：Delayed shutdown circuit掉闸回路：Trip circuit激磁回路：Exciting circuit备用回路：Spare circuit主回路：Main circuit馈路：Feeder circuit现有回路：Existing circuit单线回路：Single-wire circuit接地回路：Earthed circuit有电压的电路：Live circuitPart3设备Equipments高压开关柜：H.V. switchgear动力配电箱：Power distribution cabinet电源配电箱：Source distribution cabinet直流配电屏：D.C. switchboard (distribution panel)交流低压配电屏：A.C.L.V. switchboard (distribution panel)静电电容器柜：Static capacitor cabinet多种电源插销箱：Receptacle box for miscellaneous powersupplies控制箱：Control cabinet照明配电箱：Lighting (distribution panel)连接箱：Junction box出线盒：Outlet box开关箱：Switch box控制台：Console分段屏：Sectionalizing panel进线屏：Incoming line panel电控箱：Electric control panel边屏：Side board端子箱：Terminal box供电盘：Power supply box瓶车箱：Synchronizing cabinet电压互感器柜：Potential transformer cabinet信号屏：Signal panel浮充屏：Floating panel蓄电池屏：Battery panel充电屏：Charging panel母线联络柜：Bus tie cabinet转换开关：Transfer switch电压表转换开关：Voltmeter change-over switch 铁壳开关：Metal-clad switch (Iron-clad switch) 管式熔断器：Cartridge fuse真空断路器：Vacuum circuit breaker (V.C.B.)自动开关：Automatic switch高压负荷开关：H.V. load break switch三极高压断路器：3-pole HV circuit-breaker刀开关：Knife switch转换开关：Transfer switch双极铁壳开关：2-pole iron-clad switch风扇变速开关：Fan speed regulator switch密闭照明灯开关：Hermetic lighting switch防爆照明灯开关：Explosion-proof lighting switch行程开关：Limit switch高压隔离开关：H.V. disconnecting switch明装单极板钮开关：Surface-mounted single-pole toggle switch暗装单极板钮开关：Flush-mounted single-pole toggle switch 三路开关：Three-way switch气密式组合开关：Hermetic packet type switch防护式开关：Guard type switch联锁开关：Interlock switch操作方式选择开关：Selecting switch for types of operation控制电源开关：Switch for control supply主令开关：Master switch (controller)多切点切换开关：Multi-point change-over switch按钮：Push-button控制按钮：Control push-button防爆控制按钮：Explosion-proof control push-button事故紧急按钮：Emergency stopping push-button起动按钮：Starting push-button停止按钮：Stopping push-button现场按钮：Push-button in field挡板：damper音响解除按钮：Push-button for sound release起动器：Starter磁力起动器：Magnetic starter综合起动器：Combination starter (Magnetic starter combination)电力变压器：Power transformer调压变压器：Voltage regulating transformer电压互感器：Potential transformer电流互感器：Current transformer照明变压器：Lighting transformer三相三绕组变压器：3-phase tertiary winding transformer高压试验变压器：H.V. testing transformer局部照明变压器：Local lighting transformer多量程仪用电流互感器：Multi-range current transformer for measurement降压变压器：Step-down transformer伺服电动机：Servo-motor双电压电动机：Dual-voltage motor感应电动机：Induction motor交流异步电动机：A.C. asynchronous motor同步电动机：synchronous motor三相滑环感应电动机：3-phase slip-ring induction motor三相鼠笼感应电动机：3-phase squirrel-cage induction motor 绕线式电动机：Wound-rotor induction motor反应式电动机：Reaction motor柴油发电机：Diesel generator励磁发电机：Excitation generator明装双极插座：Surface-mounted 2-pole receptacle暗装双极插座：Flush-mounted 2-pole receptacle双极带接地插座：2-pole receptacle with grounding contact 单相三孔明插座：Surface-mounted single phase 3-pole receptacle防护式明装三相四孔插座：Guard type surface-mounted 3-phase 4-pole receptacle配照型灯：Standard dome lighting fitting搪瓷深照型灯：Enameled high bay lighting fitting防水防尘灯：Water and dust proof lighting fitting安全灯：Safety lighting fitting隔爆灯：Explosion-proof lighting fitting弯灯：Goose-neck light壁灯：Wall light高压水银灯：High pressure mercury vapor lighting fitting 投光灯：Flood-light (projection light)信号灯：Signal lamp天棚灯：Ceiling-mounted lighting fitting局部照明灯：Local lighting fitting灯座：Lamp holder事故照明灯：Emergency lighting fitting高压水银荧光灯：H.P. mercury fluorescent lighting fitting 广照型工厂灯：Wide lit type industrial fitting深照型灯具：High bay lighting fitting白炽灯具：Incandescent lamp (bulb)圆球型灯：Globe lamp嵌入式荧光灯：flush type fluorescent lighting fitting红色障碍灯：Red obstruction lamp for aviation厂区道路照明灯：Street lighting in plant area路灯：Street lamp视孔灯：Inspection hole lamp立杆弯灯：goose-neck post lamp , pole lamp模拟报警信号：Semigraph and alarm signal自整角机：Selsyn励磁机：Exciter显示器：Display电位器：Potentiometer内电阻：Internal resistance固定电阻(器)：Fixed resistance脱扣：Release , trip分励：Shunt trip特殊失压脱扣器：Special no-voltage release“或”开关放大器：“Or” switch amplifier制动器：Brake电容：Capacitor整流器：Rectifier镇流器：Chock分流器：Shunt油变阻器：Oil immersed rheostat频敏电阻器：Frequency sensitive rheostat滑线变阻器：Sliding rheostat蜂鸣器：Buzzer电机加热器：Space heater (for motor)空气断路器电机操作机构：Motor operating mechanism for air circuit-breaker可控硅励磁装置：Silicon controlled rectifier excitation device 保护装置：Protective device (element)闪光装置：Flashing device接闪装置(避雷器)：Lightning arrester断相保护：Phase failure protectionPart4保护、继电器Protection , relays信号继电器：Signal relay过电流继电器：Over-current relay电压继电器：Voltage relay时间继电器：Time relay中间继电器：Auxiliary relay热继电器：Thermal relay温度继电器：Temperature relay瓦斯继电器：Gas relay控制电源中间继电器：Auxiliary relay for control supply自动操作继电器：Relay for auto-operation低电压继电器：Under-voltage relay过电压继电器：Over-voltage relay联锁继电器：Interlock relay冲击继电器：Impact relay合闸位置继电器：Close position relay逆流继电器：Reverse-current relay差流继电器：Differential current relay差动继电器：Differential relay电流继电器：Current relay功率继电器：Power relay接地继电器：Earthing relay重合闸继电器：Reclosing relay同步继电器：Synchronous relay速动继电器：Quick acting relay定时限继电器：Definite time relay光电继电器：Photoelectric relay电子继电器：Electronic relay电磁式继电器：lectromagnetic relay电动式继电器：Electrodynamic relay气压继电器：Gas-pressure relay继电器常开触点：Relay N.O. contact继电器常闭触点：Relay N.C. contact继电器保护触点(常开)：Relay holding contact (N.O.)能自动返回的常闭按钮触点：Self-return button with N.C. contact模拟信号触点：Contact for semigraph signal强励磁接点：Shock excitation contact电感线圈：Induction coil电流线圈：Current coil脱扣线圈：Trip coil合闸线圈：Close coil释放线圈：Releasing coil掉闸线圈：Tripping coil予告信号：Prewarning signal掉闸回路断线信号：Breakage signal of trip circuit断路器事故掉闸信号：Fault trip signal of breaker掉闸音响信号：Tripping audible signal重瓦斯预告信号：Heavy gas prewarning signal温度预告信号：T emperature prewarning signal手动、自动操作时事故信号：Fault signal in manual/automatic operation保护掉闸：Protective trip控制掉闸：Control trip手动跳闸：Manual trip变电所紧急停车：Emergency shutdown at substation工艺故障：Fault in process励磁故障：Fault in excitation工作电源失电报警：No-voltage alarm of working electric source工作电源分合闸：On and off of working electric source工作电源投入：Throw-in of working electric source保安电源送电：supply of emergency electric source运转指示：Indicating of operation投入指示：Indicating of throw-in同步指示：Indicating of synchronism延时停车：Delayed shutdown电源切除：Switch off the power supply速断及过流断通：Instantaneous trip and over-current off/on 自保持：Self-holding自锁：Self-lock联锁：Interlocking绝缘监视：Insulation supervision电压监视：Voltage supervision联锁解除：Release of interlock工作、保安电源切换：Transfer of working and emergency power supply发电机与工作母线并车：Synchronization of generator to working bus重瓦斯保护：Heavy gas protection开或闭超扭矩保护：Over-torque protection during opening and closing valve电机起动顺序：Sequence of motor starting铭牌框注字：Name plate denotation (inscription)Part5电气仪表Electric instruments电流表：Ammeter电压表：Voltmeter三相三线有功电度表：Three-phase three-wire kilowatt-hour meter , kWh meter单相电度表：Single-phase kilowatt-hour meter三相无功电度表：Three-phase kilovar-hour meter有功功率表：Active power meter , kilowatt meter无功功率表：Reactive power meter , kilovar meter三相瓦特表(功率表)：Three-phase watt meter功率因数表：Power factor meter频率表：Frequency meter验电流器：Galvanoscope欧姆表：Ohmmeter相位表：Phase meter转速表：Tachometer波长表：Wave-length meter三相四线制标准电度表：3-phase 4-wire standard watthour-meter过载电流表：Overload ammeter低功率因数瓦特表：Low power-factor wattmeter交直流两用钳型电流表：A.C./D.C. multi-purpose tongtester 兆欧表：Megger , Megohmmeter万用表：Avometer微安表：Microammeter毫安表：Milliammeter各种测量仪表：Various kind of measuring instruments接地电阻测量仪：Earthing resistance tester真空管电压表：Vacuum tube voltmeter电动秒表：Electric second-meterPart6防雷Lightning protection避雷装置：Lightning protector避雷针：Lightning rod避雷带：Strap type lightning protector避雷网：Network of lightning protector避雷针支架：Lightning rod support避雷针尖：Tip of lightning rod避雷针拉铁：Brace for lightning rod避雷器：Lightning arrester , surge discharger球型避雷器：Spherical arrester管形避雷器：Tubular arrester阀形避雷器：Auto-valve arrester低压避雷器：Low voltage arrester角形避雷器：Horn arrester多隙避雷器：Multigap arrester铝避雷器：Aluminum cell arrester氧化膜避雷器：Oxide film arrester击穿保险器：Puncture lightning arrester雷击：Lightning stroke直接雷击：Direct lightning stroke感应雷击：Induction lightning stroke雷电日：Thunderbolt days雷电或然率：Lightning and thunder probability 触电：Electric shock静电感应：Electrostatic inductionPart7接地Grounding , earthing接地保护：Ground protection , earth protection 防雷接地：Grounding for lightning保护接地：Protective earthing人工接地：Artificial grounding工作接地：Working grounding , working earthing 重复接地：Multiple earthing屏蔽接地：Screen earthing , shielding ground中性点接地：Neutral point grounded接地系统：Grounding system , earthing system 接地故障：Ground fault , earth fault单相接地：Single phase earthing母线接地：Bus ground接地装置：Grounding device , earthing device引下线：Down-lead , down conductor引下线固定：Clamping plate of support for fixing支架夹板：Down lead引下线固定支脚：Support for fixing down lead接地线：Ground connector接地干线：Ground(ing) main , (bus)接地网：Grounding network , earthing network接地极：Earth electrode (pole)接地电阻：Earth resistance接地电路：Earth (ground) circuit连接条：Connecting strip断接卡：Connecting clampPart8室、所Room , Substation贮藏室：Storage套间：Compartment蓄电池室：Battery room控制室：Control room配电室：Distribution room维修间：Repair room变电所：Substation高压配电室：H.V. distribution room休息室：Rest roomPart9电修车间设备Equipments of electric repair砂轮机：Emery wheel grinder台钻：Bench drilling machine交流电焊机：A.C. welding machine移动式空气压缩机：Portable air compressor手电钻：Electric hand drill单速手摇绕线机：Single speed hand winding machine导线钳压器：Wire jointing press-clamp油压千斤顶：Hydraulic jack电吹尘器：Electric dust cleaner存放柜：Store chest高压试验变压器：H.V. testing transformer泄漏试验变压器：Leakage testing set大电流发生器：Strong current generator油浸自冷感应调压器：Oil-immersed self-cooled induction voltage regulator多量程仪用电流互感器：Multi-range current transformer for measurement仪用电感互感器：Instrumental voltage transformer单相自耦变压器：Single-phase auto-transformer三相自耦变压器：3-phase auto-transformer硅整流器：Silicon rectifier仪表试验台T esting stand for instrument慢扫描示波器：Slow scanning oscillograph交流电子稳压器：A.C. electronic voltage stabilizer携带式交流电桥：Portable A.C. electric bridge接地电阻测量仪：Earthing resistance tester电缆故障探伤仪：Cable fault detector直流单臂电桥：D.C. single-arm electric bridge , Wheatstone bridgePart10材料Material绝缘包布：Insulating tape填料：Filler , packing绝缘膏：Insulating compound电缆膏：Cable compound防腐油：Anti-corrosive oil沥青漆：Bituminous varnish绝缘漆：Insulating varnish瓷漆：Enamel varnish有色金属：Non-ferrous metal黑色金属：ferrous metal白金属：White metal云母：Mica环氧树脂：Epoxy resin聚氯乙烯：Polyvinyl chloride , PVC 蜡：Wax滑石粉：Talc powder电胶木：Bakelite聚丙烯外壳：Polyacrylic cover耐油橡胶管：Oil-proof rubber tubes 接地铜线：Grounding copper wire 垫圈：Pad塑料绝缘线：Plastics insulated wire 橡套电缆：Rubber sheathed cable 中间接头：Splice填充剂：Filling agent绝缘电线：Insulated wire移动软电缆：Movable flexible cable 补偿导线：Extension wire套管：Bushing母线槽：Busway悬索：Cable suspension滑触线：Trolley conductor镀锌煤气管：Galvanized gas pipe 镀锌角钢：Galvanized steel angle 镀锌扁钢：Galvanized steel strap钢丝绳：Steel wire rope电笛：Siren电磁阀：Electromagnetic valve连接片：Connecting link切换片：Transfering link端子排：Terminal board半导体二极管：Semiconductor diode开度计：Opening meter逻辑元件：Logical element接线盒：Junction box仪表槽板：Instrument trunking电缆吊架：Cable hanger出线套：Outgoing line sleevePart11图名Drawings , diagrams电气图纸目录：Contents of electric drawings电力系统图：Electric power system diagram照明系统图：Lighting system diagram电力平面布置图：Electric power layout plan照明平面布置图：Lighting layout plan单线图：One line diagram控制箱面部布置图：Surface arrangement of control box 背部接线图：Back wiring (diagram)外部接线图：External (outside) wiring diagram内部接线图：Internal (inside) wiring diagram控制原理图：Principle control diagram原理图：Schematic diagram展开图：Developed diagram电气标准图：Electric standard drawing电气施工图：Electric working drawing复用图：Reproducibles (drawing)电缆联系图：Cable hook-up diagram转换开关接点图：Contact diagram of transfer switch箱侧视图：Side view of box正视图：Front view , facade背视图：Back view剖面图：Section参考图：Reference drawing电缆敷设图：Cable laying diagram箱内框架布置图：Arrangement of frames inside the cabinet 控制箱台面展开图：Surface developed diagram of console出线端子示意图：Schematic diagram of terminal outgoing lines端子接线图：Diagram of terminal connections电气管线表：List of wire , cable and conduits设备材料表：List of equipment and materialsPart12表头Tables电力系统图：Power system diagram引入线：Lead in保护设备：Protective device型号：Type额定值：Rating整定值：Setting主启动设备回路：Circuit to starting device导线型号、芯数、截面及管径：Conductor type , cores , section & diameter of conduit线长：Wire length管长：Conduit length启动设备：Starting device型号规格：Type , specification保护元件：Protective element计量装置：Calculating device用电设备主回路：Main circuit of electric equipment 控制回路：Control circuit控制装置：Control device用电设备：Electric equipment设备容量：Consumer capacity生产设备：Production equipment位号：No. of location名称：Name备注：Remarks引入线：Feed in配电箱：Distribution cabinet型号及编号：Type and No.开关型号：Switch type保护装置：Protective device回路编号：Circuit No.相别：Phase灯数：Number of lamps插座数：Number of receptacles电缆编号：No. of line起点：Starting终点：Ending母线截面：Section of bus零母线：Neutral bus屏编号：Panel No.型号及方案号：Type and variant No.控制原理图号：Principle control diagram工艺位号：Process item No.Part13标准图词汇Terms from standard DWG电工系统图图形符号：Graphic symbols for electric system交流电的相别：A.C. phase sequence直流电的正负极：D.C. positive and negative poles有中性点引出线的星形连接的三相绕组：Star-connected three phase windings with neutral outlet开口三角形连接的三相绕组：3-phase winding with open delta connection互相连接的导线：Cross connection of wires不连接的跨越导线：Crossing wires not in contact with each other可拆卸的电气连接：Removable connection电缆终端头：Pothead of cable or cable end自耦变压器：Auto-transformer感应调压器：Induction voltage regulator凸极同步电动机：Salient pole synchronous motor带接换装置的蓄电池组：Accumulator battery with tap-changers空气断路器：Air circuit-breaker保持触点：Holding contact热元件：Thermal element自动复位的操作开关：Spring-return operating switch插接器：Plug-in connector电喇叭：Horn电炉：Electric furnace分流器：Shunt可控硅整流箱屏：Silicon controlled rectifier box panel直流配电屏：D.C. distributing panel磁力起动器组：Magnetic starter group自动开关箱：Automatic switch box行程开关：Limit switch局部灯：Local lighting fitting荧光灯列：Series fluorescent lighting fitting防护式灯开关：Protective switch导线引上：Conductors turning up导线引下：Conductors turning down导线由上引来：Conductors turning from above导线由下引来：Conductors turning from below电缆沟：Cable trench调压器：Voltage regulator隔离变压器：Isolating transformer击穿保护器：Puncturing safety device晶体管：Transisorized diode地坪：Grade level电缆与水管平行：Cable running parallel to a water supply pipe电缆与热力管道交叉敷设：Cable running across heat pipeline 车道Drive way电缆穿管与管道交叉：Cable protective pipe across a pipeline 双(单)侧支架电缆沟：Trench with rack on both sides (one side) 室外地坪：Outdoor grade跨接线：Jumper金属软管：Flexible metal tube过渡接头：AdapterPart14电气工程及其自动化专业术语晶体管：transistor三极管：audion电容：capacitance柴油机：Diesel联结耦合：coupling载流能力(最大允许电流)：current carrying capacity传导性：conductivity绝缘：in isolation导线：lead泄漏电流：leakage current感应系数：inductance线圈：loops微处理器：macroprocessor多媒体展示：multimedia show中压配电：medium-power distribution电机及软起动器：motor and soft starters数控系统：numerical controls最佳的，最理想的：optimal过载继电器：overload relays过冲：overshoot峰值电流：peak current电力分散：power dissipation过程自动化：process automation过程仪表及分析仪器：process instrumentation and analytics 穿孔，冲压：punch电抗：reactance再充：recharge稳压电源：regulated power supply阻抗：resistance电阻器：resistor共振：resonate自感应：self-inductance串联感应：series inductance模拟：simulation热循环：thermal cycle厚度：thickness调压器：voltage regulator扭曲，变形：warping线路配置图：wiring layout交流变频器：AC-drives非对称的：asymmetrical衰减：attenuation桥接阻抗：bridged impedance电缆桥架：cable bridge电荷：charge电路原理图解：circuit schematic diagram 系数：coefficient构造：configuration常量：constant铜片：copper sheet阻尼：damping分解：decomposition分离：decouple延迟电路：delay circuit介电原片：dielectric sheets钳位：diode clamping边缘连接器：edge connector电气基础设施：electrical infrastructure 电气安装技术：electrical installation方程组：equations set四层：four-layer接线图：hookup人机界面：human machine interface阻抗：impedance入射：incidence入射波：incident wave合成一体的：incorporated瞬间的：instantaneous交叉：interleaved负载导纳：load admittance集中的：lumped模式的：modal建模：modeling电机管理系统：motor management systems安装垫片：mounting pads噪音安全系数：noise margins邻近效应：proximity effect弧度：radian有抵抗力的：resistive示意图：schematic服务和工业解决方案：services & industry solutions 终结器：terminator。
