单周期CPU——verilog语⾔实现⼀. 实验内容设计⼀个单周期CPU，要求：1. 实现MIPS的20条指令2. 在该CPU上实现斐波那契函数计算机每执⾏⼀条指令都可分为三个阶段进⾏。
即取指令（IF）——>分析指令（ID）——>执⾏指令（EXE）取指令：根据程序计数器PC中的指令地址，从存储器中取出⼀条指令，同时，根据控制信号，决定选择某个来源的指令地址作为下⼀条指令的地址。
分析指令：对取指令操作中得到的指令进⾏分析并译码，确定这条指令需要完成的操作，从⽽产⽣相应的操作控制信号，⽤于驱动执⾏状态中的各种操作。
执⾏指令：根据指令译码得到的操作控制信号，具体地执⾏指令动作。
⼆. 20条指令的情况R指令I指令J指令三. 取指令（IF）的相关模块代码//PCmodule PC(input [31:0] next_addr,input rst,input clk,output reg [31:0] addr);always @(posedge clk)beginif(rst==1'b1)beginaddr<=next_addr;endelsebeginaddr<=32'b0;endendinitial$monitor($time,,"PC：addr=%h",addr);endmodule//ROMmodule rom(input [31:0] addr,output [31:0] data);reg[31:0] romdata;always @(*)case(addr[31:2])4'h0:romdata=32'b10001100000000110000000000100000; //lw $0,$3,32 *4'h1:romdata=32'b00110100000100000000000000000010; //ori $0,$16,2 *4'h2:romdata=32'b00000000000000111000100000100101; //or $0,$3,$17 * 4'h3:romdata=32'b00110100000100110000000000000001; //ori $0,$19,1 *4'h4:romdata=32'b00110100000001000000000000000001; //ori $0,$4,1 *4'h5:romdata=32'b00010010001100110000000000001011; //beq $17,$19,11 * 4'h6:romdata=32'b00000000000001000100000000100101; //or $0,$4,$8 *4'h7:romdata=32'b00100010011100110000000000000001; //addi $19,$19,1 * 4'h8:romdata=32'b00110100000001000000000000000001; //ori $0,$4,1 *4'h9:romdata=32'b00010010001100110000000000000111; //beq $17,$19,7 * 4'ha:romdata=32'b00000000000001000100100000100101; //or $0,$4,$9 * 4'hb:romdata=32'b00000001000010010010000000100000; //add $8,$9,$4 * 4'hc:romdata=32'b00000000000010010100000000100101; //or $0,$9,$8 *4'hd:romdata=32'b00000000000001000100100000100101; //or $0,$4,$9 *4'he:romdata=32'b00100010000100000000000000000001; //addi $16,$16,1 * 4'hf:romdata=32'b00010110000100011111111111111011; //bne $16,$17,-5 * default:romdata=32'b10101100000001000000000000010000; //sw $0,$4,16 endcaseassign data=romdata;initial$monitor($time,,"rom:romdata=%h",romdata);endmodule//Selectormodule selector(input [31:0] addr0,input [31:0] addr1,input [31:0] addr2,input [31:0] addr3,input [1:0] pcsource,output reg [31:0] next_addr);always @(*)begincase(pcsource)2'b00:beginnext_addr=addr0;end2'b01:beginnext_addr=addr1; //bne,beqend2'b10:beginnext_addr=addr2; //jend2'b11:beginnext_addr=addr3; //jal,jrendendcaseendinitial$monitor($time,,"selector: pcsource=%h, next_addr=%h",pcsource,next_addr); endmodule四. 所使⽤的控制信号pcindex: pc值的来源ram2reg: 是否将数据从RAM写⼊到寄存器中，=1为是，否则为否ramWE: 是否写内存，=1为是，否则为否aluOP: ALU的运算类型regWE: 是否写寄存器，=1为是，否则为否imm: 是否产⽣⽴即数，=1为是，否则为否shift: 是否移位，=1为是，否则为否isrt: ⽬的寄存器地址，=1选择rt，否则选择rdsign_ext: ⽴即数拓展，=1为符号数拓展，否则为零拓展jal: 是否调⽤⼦程序跳转，=1为是，否则为否五. 各指令对应产⽣的控制信号pcindex ram2reg ramWE aluOP regWE imm shift isrt sign_ext jal add 0 0 0 0001 1 0 00 00 sub 0 0 0 0010 1 0 0 0 0 0 and 0 0 0 00111 0 00 0 0 or0 0 0 0100 1 0 0 0 0 0 xor0 0 0 01011 0 0 0 0 0 sll0 0 0 01101 0 1 1 0 0 srl0 0 0 01111 0 1 1 0 0 sra0 0 0 1000 1 0 1 1 0 0 jr10 0 0 0 0 0 0 0 0 0 addi0 0 0 00011 1 0 1 1 0 andi0 0 0 0011 1 1 0 1 0 0 ori0 0 0 01001 1 0 1 0 0 xori0 0 0 01011 1 0 1 0 0 lw0 1 0 0001 1 1 0 1 1 0 sw 0 0 1 000101 0 1 1 0 beq00/01 0 0 00100 0 0 0 1 0 bne00/01 0 0 0010 0 0 0 0 1 0 lui 0 0 0 100111 0 1 0 0 j 11 0 0 00 0 0 0 0 0 jal 11 0 0 01 0 0 0 0 1六. 分析指令（ID）相关模块代码//IDmodule ID(input [31:0] instrument,output reg [5:0] opcode,output reg [5:0] func,output reg [4:0] rs,output reg [4:0] rt,output reg [4:0] rd,output reg [4:0] sa,output reg [15:0] immediate,output reg [25:0] addr);always @(*)beginopcode=instrument[31:26];rs=5'b0;rt=5'b0;rd=5'b0;sa=5'b0;immediate=16'b0;addr=25'b0;case(opcode)6'b000000: //R类型beginfunc=instrument[5:0];sa=instrument[10:6];rd=instrument[15:11];rt=instrument[20:16];rs=instrument[25:21];end6'b001000,6'b001100,6'b001101,6'b001110,6'b100011,6'b101011,6'b000100,6'b000101,6'b001111: beginimmediate=instrument[15:0];rt=instrument[20:16];rs=instrument[25:21];end6'b000010,6'b000011:beginaddr=instrument[25:0];enddefault: rs=5'b00000;endcaseendendmodule//CUmodule CU(input [5:0] opcode,input [5:0] func,input z,output reg [1:0] pcindex,output reg ram2reg,output reg ramWE,output reg [3:0] aluOP,output reg regWE,output reg imm,output reg shift,output reg isrt,output reg sign_ext,output reg jal);always @(*)begin//设置默认值shift=1'b0;ram2reg=1'b0;ramWE=1'b0;regWE=1'b0;imm=1'b0;isrt=1'b0;sign_ext=1'b0;pcindex=2'b00;aluOP=4'b0000;jal=1'b0;case(opcode)//R指令6'b000000:begincase(func)6'b100000: //add指令beginaluOP=4'b0001;regWE=1'b1;end6'b100010: //sub指令beginaluOP=4'b0010;regWE=1'b1;end6'b100100: //and指令beginaluOP=4'b0011;regWE=1'b1;end6'b100101: //or指令beginaluOP=4'b0100;regWE=1'b1;end6'b100110: //xor指令beginaluOP=4'b0101;regWE=1'b1;end6'b000000: //sll指令beginaluOP=4'b0110; regWE=1'b1;shift=1'b1;isrt=1'b1;end6'b000010: //srl指令beginaluOP=4'b0111; regWE=1'b1;shift=1'b1;isrt=1'b1;end6'b000011: //sra指令beginaluOP=4'b1000; regWE=1'b1;shift=1'b1;isrt=1'b1;end6'b001000: //jr指令beginpcindex=2'b10;endendcaseend//I指令6'b001000: //addi指令beginaluOP=4'b0001;imm=1'b1;regWE=1'b1;sign_ext=1'b1;isrt=1'b1;end6'b001100: //andi指令beginaluOP=4'b0011;imm=1'b1;regWE=1'b1;isrt=1'b1;end6'b001101: //ori指令beginaluOP=4'b0100;imm=1'b1;regWE=1'b1;isrt=1'b1;end6'b001110: //xori指令beginaluOP=4'b0101;imm=1'b1;regWE=1'b1;isrt=1'b1;end6'b100011: //lw指令beginram2reg=1'b1;aluOP=4'b0001;imm=1'b1;regWE=1'b1;sign_ext=1'b1;isrt=1'b1;end6'b101011: //sw指令beginramWE=1'b1;aluOP=4'b0001;imm=1'b1;sign_ext=1'b1;isrt=1'b1;end6'b000100: //beq指令beginaluOP=4'b0010;sign_ext=1'b1;if(z==1'b1)beginpcindex=2'b01;endend6'b000101: //bne指令beginaluOP=4'b0010;sign_ext=1'b1;if(z==1'b0)beginpcindex=2'b01;endend6'b001111: //lui指令beginregWE=1'b1;imm=1'b1;isrt=1'b1;aluOP=4'b1001;end//J指令6'b000010: //j指令beginpcindex=2'b11;end6'b000011: //jal指令beginjal=1'b1;regWE=1'b1;pcindex=2'b11;endendcaseendinitial$monitor($time,,"CU:imm=%b,op=%h, isrt=%h, pcindex=%h, regWE=%h, shift=%h, ram2reg=%h, ramWE=%h ",imm,aluOP,isrt,pcindex,regWE,shift,ram2reg,ramWE); endmodule七. 总体电路图⼋. 执⾏指令（EXE）相关模块的代码//selector_5module selector_5(input [4:0] a,input [4:0] b,input choice,output [4:0] f);assign f=(choice==1'b0)?a:b;initial$monitor($time,,"selector_5: a=%h, b=%h, f=%h",a,b,f);endmodule//selector_32module selector_32(input [31:0] a,input [31:0] b,input choice,output [31:0] f);assign f=(choice==1'b0)?a:b;initial$monitor($time,,"selector_32: f=%h",f);endmodule//ext_immmodule ext_imm(input [15:0] immediate,input sign_ext,output [31:0] imm);//sign_ext为1时，有符号拓展；为0时，0拓展assign imm=(sign_ext==0)?{{16{1'b0}},immediate}:{{16{immediate[15]}},immediate}; initial$monitor($time,,"ext_imm: imm=%h",imm);endmodule//alu_add_4module alu_add_4(input [31:0] a,output [31:0] f);assign f=a+32'b0100;initial$monitor($time,,"alu_add_4：f=%h",f);endmodule//registersmodule registers(input clk,input oc,input [4:0] raddr1,input [4:0] raddr2,input [4:0] waddr,input [31:0] wdata,input we,output reg [31:0] rdata1,output reg [31:0] rdata2);reg[31:0] regts[1:31];always @(*)beginif(oc==1'b1)beginrdata1=32'bz;endelse if(raddr1==5'b00000)beginrdata1=32'b0;endelsebeginrdata1=regts[raddr1];$monitor($time,,"Read R %d data1=%d",raddr1,rdata1); endalways @(*)beginif(oc==1'b1)beginrdata2=32'bz;endelse if(raddr2==5'b00000)beginrdata2=32'b0;endelsebeginrdata2=regts[raddr2];end$monitor($time,,"Read R %d data2=%d",raddr2,rdata2); endalways @(posedge clk)begin#1if((we==1'b1)&&(waddr!=5'b00000))beginregts[waddr]<=wdata;$monitor($time,,"write %h to data=%d",waddr,wdata);endendendmodule//isimmmodule isimm(input [31:0] rt,input [31:0] immediate,input imm,output [31:0] b);assign b=imm?immediate:rt;initial$monitor($time,,"isimm:b=%h",b);endmodule//ALUmodule alu(input [31:0] a,input [31:0] b,input [3:0] op,output [31:0] f,output z);reg [31:0]result;always@(*)begincase(op)4'b0000:result=32'b0;4'b0001:result=a+b;4'b0010:result=a-b;4'b0011:result=a&b;4'b0100:result=a|b;4'b0101:result=a^b;4'b0110:result=b<<a;4'b0111:result=b>>a;4'b1000:result=$signed(b)>>>a;4'b1001:result={b,{16{1'b0}}};default:result=32'b0;endcaseendassign f=result;assign z=~(|result);initial$monitor($time,,"alu:a:%h,b:%h,op:%h,",a,b,op);initial$monitor($time,,"alu:f:%h,z:%b",f,z);endmodulemodule IOManager(input [5:0] addr,input [31:0] din,output [31:0] dout,input we,input clk,input [3:0] switch,output reg[31:0] displaydata);reg [31:0] indata,outdata;wire [31:0] ramdout;wire ramWE;wire enable;assign enable=(|addr[5:4]);ram dram(addr[3:0],din,clk,enable,ramWE,ramdout);assign dout=(addr[5]==1'b1)?{{28{1'b0}},switch}:ramdout;assign ramWE=we&(~addr[4]);always @(posedge clk)beginif((addr[4]==1'b1)&&we)displaydata<=din;endinitial$monitor($time,,"IOM: addr=%h, din=%h, dout=%h",addr,din,dout); initial$monitor($time,,"IOM: switch=%h, displaydata=%h",switch,displaydata); endmodule//rammodule ram(input [3:0] addr,input [31:0] wdata,input clk,input ce,input we1,output reg[31:0] rdata);reg [31:0] ram[0:30];always @(*)beginif(ce==1'b0)beginrdata=ram[addr];endendalways @(posedge clk)begin#1if((ce==1'b0)&&(we1==1'b1))beginram[addr]<=wdata;endendinitial$monitor($time,,"ram: ram=%h,rdata=%h",ram[addr],rdata); endmodule//leftmodule left(input [31:0] a,output [31:0] b);assign b=a<<2;endmodule//alu_add_bmodule alu_add_b(input [31:0] addr,input [31:0] immediate,output [31:0] f);assign f=addr+immediate;initial$monitor($time,,"alu_add_b: addr=%h, immediate=%h, f=%h ",addr,immediate,f); endmodule//ext_addermodule ext_adder(input [25:0] address,output [27:0] f);assign f={address,{2{1'b0}}};initial$monitor($time,,"ext_addr: address=%h, f=%h ",address,f);endmodule//mixaddrmodule mixAddr(input [31:0] addr,input [27:0] address,output [31:0] f);assign f={{addr[31:28]},address};initial$monitor($time,,"mixAddr: addr=%h, address=%h, f=%h",addr,address,f);endmodule九. TOP⽂件代码1module top(2input clk,3input rst,4input [4:0] n,5output [31:0] result6 );78wire [31:0] next_addr;9wire [31:0] addr,addr0,addr1,addr2,addr3;10wire [31:0] immediate;11wire [27:0] fAddress;12wire [31:0] instrument;13wire [5:0] opcode,func;14wire [4:0] rs,rt,rd,sa;15wire [15:0] imm;16wire [25:0] address;17wire z;18wire [1:0] pcindex;19wire ram2reg,ramWE,regWE,isimm,shift,isrt,sign_ext,jal;20wire [3:0] aluOP;21wire [4:0] waddr;22wire [4:0] tmp_waddr;23wire [4:0] regs31=5'b11111;24wire [31:0] wdata,rdata1,rdata2,f,tmp_f;25wire oc=1'b0;26wire [31:0] a,b;27wire [31:0] dout;28wire [31:0] lImmediate;29wire [31:0] fsa;3031 PC myPC(next_addr,rst,clk,addr);32 rom myRom(addr,instrument);33 ID myID(instrument,opcode,func,rs,rt,rd,sa,imm,address);34 CU myCU(opcode,func,z,pcindex,ram2reg,ramWE,aluOP,regWE,isimm,shift,isrt,sign_ext,jal);35 ext_imm myExtImm(imm,sign_ext,immediate);36 selector_5 mySelector5_1(rd,rt,isrt,tmp_waddr); //⽬的寄存器是否rt37 selector_5 mySelector5_2(tmp_waddr,regs31,jal,waddr); //是否调⽤⼦程序调转wa38 alu_add_4 myAdd4(addr,addr0);39 selector_32 mySelector32_1(f,addr0,jal,wdata); //是否调⽤⼦程序调转wd40 registers myRegs(clk,oc,rs,rt,waddr,wdata,regWE,rdata1,rdata2);41 isimm myIsImm(rdata2,immediate,isimm,b);42assign fsa={{27{1'b0}},sa};43 selector_32 mySelector32_2(rdata1,fsa,shift,a); //选择sa和rs数据44 alu myAlu(a,b,aluOP,tmp_f,z);45 IOManager myIOM(tmp_f,rdata2,dout,ramWE,clk,n,result);46 selector_32 mySelector32_3(tmp_f,dout,ram2reg,f); //是否将数据从ram中写⼊reg47 left myLeft(immediate,lImmediate);48 alu_add_b myAddb(addr0,lImmediate,addr1);49 ext_adder myExtAddr(address,fAddress);50 mixAddr myMixAddr(addr,fAddress,addr3);51 selector mySelector(addr0,addr1,rdata1,addr3,pcindex,next_addr);525354initial55 $monitor($time,,"top: n=%h, result=%h",n,result);5657endmodule。
