实验平台简介EGO1开发平台简介本课程所使用的另外一个硬件设备为依元素科技公司生产的EGO1开发板，FPGA芯片为Xilinx Artix-7系列，型号为XC7A35T。

EGO1开发平台简介输入外设：5个通用按键，编号S0~S45个通用按键默认为低电平，按下时为高电平EGO1开发平台简介输入外设：5个通用按键，编号S0~S4对应的FPGA管脚：EGO1开发平台简介输入外设：2个专用按键，用于逻辑复位RST（S6）和擦除FPGA 配置管脚PROG（S5）。

当设计中不需要外部触发复位时，RST 按键可以用作其他逻辑触发功能。

RST对应的FPGA引脚为P15。

默认为高电平，按下时为低电平EGO1开发平台简介输入外设：16个开关，开关包括8 个拨码开关和一个8 位DIP 开关往上拨动接高电平1，往下拨动接低电平0。

EGO1开发平台简介输入外设：16个开关，开关包括8 个拨码开关和一个8 位DIP 开关对应的FPGA管脚：16个绿色LEDEGO1开发平台简介输出外设：16个绿色LED 灯，编号D0~D15，经限流电阻直接和FPGA 管脚相连。

对应的FPGA引脚七段数码管EGO1开发平台简介输出外设：8个七段共阴极数码管，即公共极输入低电平。

共阴极由三极管驱动，FPGA 需要提供高电平，三极管饱和导通，公共电极输出低电平，同时段选端连接高电平，数码管上的对应位置才可以被点亮。

EGO1开发平台简介输出外设：数码管对应的FPGA管脚EGO1开发平台简介系统时钟：EGO1搭载一个100MHz的时钟芯片，时钟信号直接与FPGA全局时钟输入管脚（P17）相连。

若设计中还需要其他频率的时钟，可以采用FPGA内部的MMCM生成。

EGO1开发平台简介FPGA 配置：板上提供以下方式配置FPGA ：B 转JTAG 接口J222.6-pin JTAG 连接器接口J3J22与J3SPI Flash 配置在使用SPI Flash 配置FPGA 时，需要提前将配置文件写入到Flash中。

《FPGA设计与应用》数码管显示实验一、实验目的和要求
1．学习动态数码管的工作原理；
2．实现对EGO1开发板四位动态数码管的控制；
二、实验内容
实现对EGO1开发板四位动态数码管的控制，使其能够正常工作；
三、实验要求
在EGO1开发板上显示想要的数字。

四、操作方法与实验步骤
1、八段数码管的动态显示原理：
2、数码管显示的设计共分3个模块：
（1）数码管封装模块
（2）数码管设计模块
（3）顶层模块
数码管动态显示的MODULE实现：
模块顶层设计——显示4个（位）十进制数
逻辑实现：
确定当前显示的位
确定当前“位”需要显示的“数”：
将“数”翻译成相应的“段码”
仿真测试台代码编写与仿真测试定义时间标尺：
定义测试Moudle
实例化被测Moudle
定义激励信号与响应信号
构造激励信号：
五、实验数据记录和处理实验代码如下：
设计文件：（部分）
仿真文件：
约束文件：
六、实验结果与分析网表结构：
仿真图像：
实物图：
七、讨论和心得
通过这次实验，我学会了数码管的动态显示，每一个数码管共用一套电路，显示时只需控制哪一个数码管进行显示。

虽然一次只能控制单独一个数码管进行显示，但可以快速切换数码管显示，利用人眼的”视觉暂留"来“同步”进行显示。

最后我明白了我们不要遇到一点困难就退缩，就去向老师同学寻求帮助，自己是自己最好的老师，只有我们靠自己的不断修改出正确结果，才会对这个知识掌握的更加透彻。
