多士炉安规测试-----GS部分多士炉产品申请GS认证，涉及的标准有EN60335-1和EN60335-2-9。
1、输出功率：1.1、输入额定电压使产品工作至稳定时，读取产品的实际功率。
功率偏差必须符合偏差要求1.2、率标识方法：a)单一的输入电压和功率，如230V 1000W。
只要测试230V的实际输入功率符合1000W（+5％，－10％）的偏差要求。
11章就输入1000×1.15W的功率做测试。
b)有范围的输入电压和单一的输入功率，如220-240V 1000W。
它实际指的也是230V 1000W，所以要测试230V时的实际输入功率要符合1000W（+5％，－10％）的偏差要求；但还要测试220V和240V的实际输入功率来做参考。
按照最严酷条件，11章就输入1000×（240÷230）2×1.15W的功率做测试。
b)有范围的输入电压和功率，如220-240V 800W-1000W。
就要求测试输入220V和240V电压下的实际输入功率符合800W和1000W（+5％，－10％）的偏差要求。
按照最严酷条件，11章就输入1000×1.15W的功率做测试。
2、电气强度：公司多士炉产品为I类器具：电气强度所设定的漏电流值为0.5mA。
2.1、Ⅰ类结构部位为1000V 1min；2.2、Ⅱ类结构部位为3000V 1min，测试部位要用接触面积不得超过20cm×10cm的锡箔纸包住。
样品在耐压测试中，应无击穿或发生闪络现象；测试初始，施加的电压不超过规定电压值的一半，然后逐渐地升高到满值.3、泄漏电流：连接泄漏电流仪并使产品再1.15倍的额定功率工作至稳态或Clause 11.7规定的时间，测试泄漏电流,切换L/N开关,记录最大的泄漏电流值.符合以下限值：加强绝缘处（如按键）≤0.25 mA，基本绝缘处（接地金属部件）≤0.75 mA。
4、接地电阻测试：4.1、接通电源，将接地电阻仪设置在12V，25A,并将电阻最大值设置为0.1Ω，时间设置为30秒。
