BF591中文资料
DATA SHEET
Product speci?cation
Supersedes data of September 1994
File under Discrete Semiconductors, SC041997Jul02
DISCRETE SEMICONDUCTORS BF591; BF593
NPN high-voltage transistors
M3D067
NPN high-voltage transistors BF591; BF593
FEATURES
Low current (max. 150mA)
High voltage (max. 210V).
APPLICATIONS
Telephone systems.
DESCRIPTION
NPN high-voltage transistor in a TO-202; SOT128B plastic
package.PINNING
PIN DESCRIPTION
1emitter
2collector, connected to mounting base
3base
Fig.1Simplified outline (TO-202; SOT128B)
and symbol.
handbook, halfpage
2
1
3
MAM305
123 QUICK REFERENCE DATA
SYMBOL PARAMETER CONDITIONS MIN.MAX.UNIT V CBO
collector-base voltage open emitter
BF591?210V
BF593?250V
V CEO collector-emitter voltage open base
BF591?170V
BF593?210V
I CM peak collector current?300mA
P tot total power dissipation T amb≤55°C? 1.3W
h FE DC current gain I C=20mA; V CE=5V30?
I C=100mA; V CE=6V30?
NPN high-voltage transistors BF591; BF593
LIMITING VALUES
In accordance with the Absolute Maximum Rating System
(IEC134).
SYMBOL PARAMETER CONDITIONS MIN.MAX.UNIT V CBO
collector-base voltage open emitter
BF591?210V
BF593?250V
V CEO collector-emitter voltage open base
BF591?170V
BF593?210V
V EBO emitter-base voltage open collector?5V
I C collector current (DC)?150mA
I CM peak collector current?300mA
I BM peak base current?100mA
P tot total power dissipation T amb≤55°C? 1.3W
T stg storage temperature?65+150°C
T j junction temperature?150°C T amb operating ambient temperature?65+150°C
THERMAL CHARACTERISTICS
SYMBOL PARAMETER CONDITIONS VALUE UNIT
R th j-a thermal resistance from junction to ambient in free
air73K/W
CHARACTERISTICS
T j=25°C unless otherwise speci?ed.
SYMBOL PARAMETER CONDITIONS MIN.MAX.UNIT I CBO
collector cut-off current I E=0; V CB=60V?50nA
I E=0; V CB=60V; T j=140°C?1μA
I EBO emitter cut-off current I C=0; V EB=5V?100nA
h FE DC current gain note1
I C=20mA; V CE=5V30?
I C=100mA; V CE=6V30?
I C=150mA; V CE=7V20?
Note
1.Pulse test: t p≤300μs;δ≤0.01.
NPN high-voltage transistors
BF591; BF593
PACKAGE OUTLINE
UNIT b p D E 1L 1L 2(1)max L c c 1E P Q w REFERENCES
OUTLINE VERSION EUROPEAN PROJECTION
ISSUE DATE IEC
JEDEC EIAJ
mm
0.80.6
0.650.5
0.560.46
8.68.4
10.19.9 10.410.0
2.54
13.312.2
e 15.08
e H E 24.223.8
2.42.0
3.83.6
P 13.93.7
0.25
1.71.5
DIMENSIONS (mm are the original dimensions) 2.5
SOT128B
TO-202
97-02-28
A c 1
D
E
L 1
L 2L
b p c
E 1H E
P
Q
A
P 1
4.64.4
Plastic single-ended leaded (through hole) package; with
cooling fin, mountable to heatsink,1 mounting hole; 3 leads (in-line)
SOT128B e e 112
3
510 mm
scale
w M
Note
1. Plastic flash allowed within this zone
NPN high-voltage transistors BF591; BF593
DEFINITIONS
Data sheet status
Objective speci?cation This data sheet contains target or
goal speci?cations for product development. Preliminary
speci?cation This data sheet contains preliminary data;
supplementary data may be published later. Product speci?cation
This data sheet contains ?nal product speci?cations.
Limiting values
Limiting values given are in accordance with the Absolute
Maximum Rating System (IEC 134). Stress above one or more of
the limiting values may cause permanent damage to the device.
These are stress ratings only and operation of the device at these
or at any other conditions above those given in the
Characteristics sections of the speci?cation is not implied.
Exposure to limiting values for extended periods may affect
device reliability.
Application information
Where application information is given, it is advisory and
does not form part of the speci?cation.
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support
appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury.
Philips customers using or selling these products for use in such
applications do so at their own risk and agree to fully indemnify
Philips for any damages resulting from such improper use or sale.
