深圳市视康达电子有限公司高清广告机解码驱动一体板使用说明书1．产品概述本款广告机驱动解码一体板，能直接驱动1920*1080及其以下的分辨率的LVDS屏，内含强大的音视频处理功能，能输出高质量的画面和音质。
两路USB2.0接口，支持高清视频和图片的播放。
支持USB之间相互拷贝功能，能方便用户更新文件。
2.使用说明2.1 遥控器说明本产品使用的遥控器如下图所示：遥控器各按键功能：电源键:电源键，控制开关机静音:静音功能:快进，连续按速度加快:快退，连续按速度加快:暂停/播放功能: 向上移动光标（播放时弹出控制条菜单）: 向左移动光标: 向右移动光标: 向下移动光标（播放时弹出控制条菜单）MENU :进入设定菜单，进入菜单后是确认功能VOL+:音量加VOL-:音量减播放过程中，按该键进入下一曲:播放过程中，按该键进入上一曲EXIT :退出菜单或播放DEL:光标停留在文件上时，按该键弹出删除菜单2.2 设定菜单设定菜单主界面如下图：2.2.1 通用设定该页设定菜单图片如下：以下个项功能均按左右键来选择。
a.菜单语言：中文：设定菜单语言为中文英文：设定菜单语言为英文b.重复模式：单曲重复：循环播放同一个文件全部重复：循环播放USB根目录下的文件重复取消：播放完一遍根目录下的文件后，停止播放c.播放记录：打开带功能，会自动记录播放的文件名和开始播放的时间，还会记录开关机的时间注：该功能需要用户先在U盘中建立一个PLAY.LOG（可先建立一个同名的txt文件，然后改下后缀就可以了）。
d.断电记忆：播放时自动记录文件播放的文件和播放的时候，断电开机后接着上次断电的地方继续播放（注：不支持音乐文件的断电记忆）e.图片转场模式：设定图片播放时的转场模式。
f.图片播放时间：设定图片刷新的时间（分5s->7s->10s->15s）g.滚动字幕：设定是否打开滚动字幕h.滚动字幕颜色：设定滚动字幕字体的颜色i.字幕背景颜色：设定滚动字幕背景的颜色j.播放类型：图片：只播放存储卡根目录下的图片文件音乐：只播放存储卡根目录下的音乐文件音画同步：播放图片时带有音乐背景，并且一直重复播放图片和音乐文件播放列表：按制作好的播放列表进行播放视频：只播放存储卡根目录下的视频文件全部：播放存储卡根目录下所有能识别的图片音乐和视频文件。
康佳LED42MS05DC（MST6M182,35015540-V0）液晶彩电主板图纸5544332211DDCCBBAAEN_USBBKLT_ENBKL_ONBKLT_ADJPOWER-ON/OFF-INVBKL_ADJPW-ON/OFF-INV5V-STBINBKLT_ENPOWER-ON/OFF-INVBKLT_ADJEN_USBAVDD2P5_MODAU25+2.5VAAVDD25_DEMODADC2P5+3.3VstbAVDD_DDR_1.8V+1.8V_DDR2AVSS_PGA25AVDD_DMPLL33AVDD_ADC33AVDD_DVI33+3.3VstbAVDD_NODIE_3.3V +5VA5Vstb+3.3Vstb+1.8V+3.3VA+5VA+3.3VAV12+1.2V_VDDCVCC-1.26V+5VAVCC-1.26V+5VA+5VA+3.3VA+3.3VA+3.3VAV12-1V125V_Tuner+5VUSB+12VVCC-Panel+3.3VA5VstbVDD33AVDD_PLL33+5VA+2.5VA+2.5VA+2.5V_PGA+1.8V_DDR2VCC1.2V_MEMC+5VAVCC3.3V_MEMCVCC3.3V_MEMC+12V+12VVCC1.8V_MEMC5Vstb+12V+5VUSB5VstbAU335Vstb+3.3VstbPWR-ON/OFFPOWER-ON/OFF-INVBKL_ONBKL_ADJON_PANELPWR-ON/OFFON_USBLG_STATEBKLT_ADJ标记数量等级标记批准标准化工艺审核拟制签名日期分区单号数量签名单号分区标记日期工艺人员标准化人员批准人员MST6M48+MST6M20143Vout=0.8(1+R1/R2)R1:R841//R8426KR2:R84310KPOWERINPUTNormalPower2.5V1.86VforDDR2USB预留5V_TunerDDR21.8VVcc1.26VforMST6M182Corepowerand6m30NormalPower1.2V3.3VstbStandbyPower3.3V3.3VANormalPower3.3V2.5VA预留5V_USBVout=0.8(1+R1/R2)R1:R806//R80752.5K(R80675K,R807180K)R2:R80410K H:OFFL:ON增加R868，R867，V813，CF38增加C83910nF,C8320.1uF修改R804,R806,R807的阻值VCC3.3V_MEMCPOWERINPUTVCC_PANEL5V_USB+5VAVCC1.8V_MEMC50mA200mA 200mARU7847KC81310uF/16VV811NC/PMV65XP C87910uF/16VR885NC/0R CF130.1uFCF6410uF/10VCF4910uF/10VC808220uF/16VC8710.1uFCF5910uF/10V123V8043904C8530.1uFR8564.7K/NC0.1uFC84610uF/16VCU630.1uFVD801NC/PMEG2020 CF300.1uFR8301KR838180K1%VD804NC/PMEG2020 12L820FBR83447K12L811FB/NC12L813FBCF290.1uFC87410uF/10VCF040.1uFCF630.1uF10uF/16V CF5710uF/10V 123V810 3904+CF40 100uF/16V CF430.47 R809NC12L815FB12L829FB123V806 3904L831FB12L806FBL82610uH C8890.1uFL82875K1%CF010.1uFR807180K1%CF230.1uF12345XS808CON5_2.0R83210KR8480/27KC85210uF/10VR81447K3214ADJOUTINN804AMS1117-5.0VCF510.1uF12L827FBR833NCCF600.1uFC8090.1uFC84110uF/10V CF452.2uF CU62 0.47uFL507FBCF332.2uFR8500C8580.1uFCF190.1uF12L817 FBC816FBR8684.7KC8100.1uFCF520.1uFCF270.1uF C805220uF/16V12L822FBC85510uF/10VC82410uF/10VC8663.3n/50VC802NC/180p/50V R8114.7KCF210.1uFR85515/0C8420.1uFF801F5A/32VC8760.1uFC8630.1uFCF180.1uFL832FBR86710KC85110uF/10VC8040.1uF6712345XS803D3913-07AW C8860.1uFC86710uF/16VC89510uF/10VC8900.1uF12L823FBC884NC/10uF RU79100KCF060.1uFC8032.2uFR839100K CF250.1uFR854100K R8444.7KC86410nFR81710K/NC CF320.1uFR85315/012L805FB LU2110uH CF160.1uFC89410uF/10V C84810uF/16V3V8133904R8750R12L814FBC8390.1uFS1S2S3G4D8D7D6D5V8019435A 12L816FBR8614.7K+C82110uF/16VC8610.1uFR84915R84212K1%+C878NC/220uF/16V C82510K123V8143904/NCR8031KCF032.2uFC865NC/180p/50V C81410uF/16VR80410K1%D1D2D3G4S8S7S6S5VU219435A+C88210uFCF200.1uF+CF53100uF/16V3214ADJOUTINN807AZ1117-3.3 ADJOUTINC8230.1uF12L834FB/NCC84710uF/16V R81627K/0R822100CF080.1uFR878NC/0R R86330K/NCC8700.1uF12L821FBC8013.3n/50V CF120.1uFC8690.1uFR81510KR8244.7KCF170.1uFC8170.1uFCF350.1uFR857012L809FB+C811NC/220uF/16V +CF65NC/220uF/16V CF070.1uFCF38NC/0.1uFR823NC/4.7KR877NC/100RC83710n/50VCF240.1uFR829NC/100CF550.1uFC838NC/180p/50V CF360.1uFCF690.1uFL80110uHC83210nFC82710uF/16VV8123904 132OUTGNDINN813QOUTGNDVDU21NC/PMEG2020 CF100.1uFR84310K1%CF150.1uFF805F3A/32VCF540.1uF12LU09FB_300_Ohm_4A IN2GND4BS1FB5COMP6EN7SS8SW3N801AP3503C818220uF/16VCF6110uF/10VCF0210uF/10VCF344ADJOUTINN810AZ1117-2.5ADJOUTINC80610uF/16VR810100V8033904C8560.1uFCF140.1uF3214ADJOUTINN811AZ1117-1.8V-252 ADJOUTIN0.1uFR80510K1%CF5610uF/10V3214ADJOUTINN809AZ1117-3.3V-252AD JOUTIN+CU04220uF/16VS1S2S3G4D8D7D6D5V8099435AR8720RR84112K1%+C845NC/220uF/16VR8271K/NCC8680.1uFR858NC/1KCF222.2uFCF410.1uF3214ADJOUTINN806AZ1117-3.3V-252AD JOUTINR85930K/NCVD805GREENONC8330.1uFC85910uF/16VR845NC/PMV65XP R83610KR8691512L808FBV8053904CF392.2uFC8190.1uFCF090.1uFC88110uF/16VCF620.1uFRU8110KIN2GND4BS1FB5COMP6EN7SS8SW3N805MP1482DS +C887100uF/16V 1212VU013904C87510uF/10VR8016.8K3214ADJOUTINN808AZ1117-1.8V-252 ADJOUTINC860NC/10uF/10V12L818FBCF280.1uFC81210uF/16VR883NC/0RR8841KR87115C85710uF/16V CF480.1uFR835100KR8026.8KCF4710nF12L824FBIN2GND4BS1FB5 COMP6 EN7SS8SW3NU21MP1482DS CF110.1uFR81310KR80875K1%C8730.1uFCF5810uF/10VC8720.1uFC8830.1uFCF4210uF/10VC88010uF/16V12LU08FB_300_Ohm_4ACF260.1uFPDF文件以"PDF制作工厂"试用版创建 5544332211DDCCBBAAMDDR_VREFA_MCLKZA_MCLKVGA-AULin0 VGA-AURin0 XTALO XTALIA_MCLKZA_MCLKA_MDQSUA_MDQSUZA_MDQML A_MDQSLA_MDQSLZ A_MDQMU BKL_CTL AUMCK_OUTAUBCK_A_MCKE A_MODTAV-AUOUTR3VIFPVIFMSIFPSIFMAMP-AUOUTRAV-AUOUTL3AMP-AUOUCA_MADR11A_MADR12 A_MADR9 A_MADR5 A_MADR10 A_MADR1 A_MADR3 A_MADR7 A_MDATA15A_MADR6A_MADRA_MADR2A_MADR8AVSS_PGA25VIF_SW SELVDS#MI2C-SDAAUR4XTALIXTALOA_MDATA11 A_MDATA8A_MDATA3 A_MDATA4 A_A_MDATA1A_MDATA12 A_MDATA6 A_MDATA1 A_MDATA7A_MDATA0A_MDATA14 A_MDATA9 A_MDATA2A_MDATA5ON-USBUSB2_DMA_MWEZA_MCASZA_MRASZSystem-RST USB0_DMUSB0_DPSPI-SCKA_MBADR1 A_MBADR0 A_MBADR2 WP_FL-CECSPI-CS0NIR-inMDDR_VREFCVBS3PSPI-SDICVBS1PCVBS2PA_MADR13SPI-SDOHDMI2-SCL_SINK HOTPLUG HDMI2-RX1N HDMI2-CLKNHDMI2-RX2N HDMI2-RX2P HDMI2-RX1P HDMI2-RX0P HDMI2-SDA_SINK BIN0GIN0MGIN0PSOGIN0VGA_HSVGA_VSRIN0AUR0AUL0AUR1AUL1AUL4AUR3AUL3AUL2AUR2CVBS4P AUVRPAUVAGAUVRMVCOM0CVBS_OUTGIN2PGIN2MBIN2CVBS0P RGB0_B+ RGB0_G+ RGB0_G-SOG RGB0_R+ System-RST AUBCK_OUT AUMCK_OUT PWM1GPIO/PWM0 SPI_Flash-SDISPI_Flash-SDOSPI_Flash-SCKSPI_CS0NL_CTL3D_EN#MI2C-SCLAMP-AUOUTL0 AV-AUOUTL3 AV-AUOUTR3 AMP-AUOUTR0 AV_AUOUTLAV_AUOUTRI2C_SCLI2C_SDAGPIO/PWM0 PANEL_CTL3D_EN#BKL_CTLBKL_ON ON_PANELON-USBMUTE-ENG3_TRXE0-B5_TRXEC-B6_TRXE2+R7_TRXO0-R6_TRXO0+ B1_TRXE4-B2_TRXE3+ B0_TRXE4+ B3_TRXE3-R0_TRXOC+ R2_TRXO2+ R1_TRXOC-R3_TRXO2-G2_TRXE0+ G7_TRXO3-G6_TRXO3+ G5_TRXO4-G4_TRXO4+ G0_TRXE1+ G2_TRXE0+ G3_TRXE0-B5_TRXEC-R6_TRXO0+ G1_TRXE1-B4_TRXEC+ B7_TRXE2-R7_TRXO0-B1_TRXE4-B2_TRXE3+ B6_TRXE2+ R5_TRXO1-B3_TRXE3-R1_TRXOC-R2_TRXO2+ G6_TRXO3+ G5_TRXO4-G4_TRXO4+ G7_TRXO3-G3_TRXE00-G1_TRXE01-G2_TRXE00+ G0_TRXE01+ B4_TRXE0C+ B5_TRXE0C-B6_TRXE02+ B7_TRXE02-R6_TRXO00+ B1_TRXE04-B2_TRXE03+ R4_TRXO01+ R5_TRXO01-R7_TRXO00-R2_TRXO02+ R1_TRXO0C-R3_TRXO02-B0_TRXE04+ B3_TRXE03-R0_TRXO0C+ G5_TRXO04-G4_TRXO04+ G7_TRXO03-G6_TRXO03+ G1_TRXE1-DBL#OD_SEL#L_DIM_DBL# OD_SEL# SELVDS# DVDD_NODIE_1.2VDVDD_NODIE_1.2VMUTE-ENMUTE-ECTL PWM1 3D-EN B5_TRX EC-B6_TRXE2+B7_TRXE2-B4_TRX EC+B1_TRXE4-B2B0_TRXE4+B3_TRXE3-R6_TRXO0+ R0_TRXOC+ R7_TRXO0-R5_TRXO1-R4_TRXO1+ G6_TRXO3+ G7_TRXO3-R3_TRXO2-R1_TRXOC-R2_TRXO2+ G2_TRXE0+ G3_TRXE0-G4_TRXO4+ G5_TRXO4-G0_TRXE1+ G1_TRXE1-G1_TRXE1E1#-G1_TRXE1#+G1_TRXE1#-SIF_SWAVDD_DDR_1.8V VDDC1.2V AVDD_DDR_1.8V AVDD_DDR_1.8VAVDD1P2AVDD2P5_MODAU33AVDD_DDR_1.8VAV.8VAVDD_ADC33 AVDD_DVI33VDDC1.2VAVDD25_DEMODAVDD_NODIE_3.3VAVDD_DDR_1.8VAVDD_DDR_1.8V VDDC1.2VVDDCVDD33AVDD2P5_MOD AU25AVDD_PLL33VDD33+2.5V_PGAAVDD_DMPLL33AVDD_DDR_1.8V DVDD_DDR_1.2V VDDC1.2V AVDD_DDR_1.8V AVDD_DVI33ADC2P5AVDD_PLL333+3.3VAAVSS_PGA25+3.3Vstb+3.3VAHDMI-CECHOTPLUGHDMI2-RX2P HDMI2-RX2N HDMI2-RX1P HDMI2-RX1N HDMI2-RX0P HDMI2-RX0N HDMI2-CLKP HDMI2-CLKN HDMI2-SCL_SINK HDMI2-SDA_SINK USB2_D-USB2_D-USB1_D+VGA_HS VGA_VS RGB0_B+ RGB0_G-SOG RGB0_G+ RGB0_R+PB+SOYY+PR+SideAV-Vin+ AV2-Vin+AV1-RinPC-LinPC-RinAV1-LinHD_L_INHD_R_INsideAV_RinVIFMVIFPSIFPSIFMT_AGCBKL_ADJKEY0-inON_USB MUTE_EN AV_AUOUTL AV_AUOUTR MI2C-SCLMI2C-SDAI2C_SAMP_AUOUTR0 AMP_AUOUTL0 A_MADR12A_MADR9A_MADR7A_MADR5A_MADR3A_MADR10A_MADR1A_MBADR2A_MBADR0A_MBADR1A_MCKEA_MWEZA_MDATA4A_MDATA11A_MDATA6A_MDATA1A_MDATA3A_MDQMLA_MDQMUA_MDATA14A_MDATA9A_MDATA12A_MDQSLZA_MDQSLA_MADR13A_ MA DR 8 A_ MA DR 6 A_ MA DR 4 A_ MA DR 2 A_ MA DR 0 A_ MC AS Z A_ MR AS Z A_ MOZ A_ MC LK A_ MD AT A5 A_ MD AT A2 A_ MD AT A0 A_ MD AT A7 A_ MD AT A1 3 A_ MD AT A1 0A_ MD AT A1 5A_ MD QS UZ A_ MD QS UIR -inW P_ FL AS H UA RT -TX UA RT -R X PW R_ DE。
液晶电视机进入工厂模式方法当液晶电视机更换主板后，出现画屏的现象时，需要进入工厂模式调整液晶电视：HDLT26V8 .HDLT32A800 .HDLT37V70 .HDLT42A800. HDLT46V70. HDLT55V6. 遥控器A60型号主板：MST6M181V20-B：主板进入工厂模式1、遥控器上面的“菜单键”2、遥控器上面的数字键“2580”3、幕上面出现中文菜单.选择“参数设置”按确定键.翻页4、择'屏参设置”按确定键.翻页5、果画面有问题选择“Pa nelTIMOde TI_8BIT_MODE 调整6、体有问题选择“PanelDualport 开/关7、菜单键退出，然后用遥控器关机，关机后再开机重新启动即可。
如不行请重新操作主板：MST6M481V20 :主板进入工厂模式1、控器上面的“菜单键”2、遥控器上面的数字键“2580”3、幕上面出现英文菜单.选择“SPECIAL_SET”按确定键.翻页4、择'Panel_setting”按确定键.翻页5、果画面有问题选择“PanelTIMOde TI_8B IT_MODE 调整6、体有问题选择“PanelDualport off/on7、菜单键退出，然后用遥控器关机，关机后再开机重新启动即可。
如不行请重新操作LED:3D液晶电视：主板：MS6M182:机型：HDLT55V8 遥控器A60型号1、遥控器上面的“菜单键”2、遥控器上面的数字键“1147”3、幕上面出现中文菜单.选择“通用设置”按确定键.翻页4、择“LVDS_Map” 调整画面5、菜单键退出，然后用遥控器关机，关机后再开机重新启动即可。
如不行请重新操作A、3D画面.要按菜单键选择3D模式_3D关.按确定键进入菜单画面.选择左右格式b、3D左右画面切换——要切换程式.左右模式LED:液晶电视：LED26V8.LED32HD100.LED42HD100.主板型号：LAM181_C3_C4_C5_B4_H2 遥控器A60型号1、按遥控器上面的“菜单键”2、按遥控器上面的数字键“1147”3、屏幕上面出现中文菜单.选择“特殊设置”按确定键.翻页4、.如果画面有问题选择“LVDS_Map” 调整5、如果字体有问题选择“LVDS Swap port OFF/ON 调整6、按菜单键退出，然后用遥控器关机，关机后再开机重新启动即可。
CONTENTSTITLE PAGE CONTENTS········································page 1 of10 RECORD OF REVISIONS····························page 1 of10 GENERAL DESCRIPTION····························page 2 of10 FUNCTION LAYOUT·································page 2 of10 FEATURES·········································page 3 of10 INTERFACE DEFINITION····························page 5 of10 CONTROLLER DIMENSIONS·························page 9 of10KEY & IR BOARD SYSTEM SCHEMATIC··············page 9 of10 OPERATION REQUIREMENT·························page 10 of10RECORD OF REVISIONSREVISION NO. DATE PAGE DESCRIPTION1. GENERAL DESCRIPTIONMST182VG V6.0 is a multi-purpose LCD controller, it is suitable Asia market.It is designed to support FULL HD LCD panel.MST182VG V6.0 can support PC-RGB,HDMI,AV,YPBPR,USB, VGA,TV signal input.It can also support Earphone output.Note:The specification of the board includes the description of all functions. Therefore,our clients can select the functions which they require to produce the board.But the specification can be introduced universally.2. FUNCTION LAYOUTThe following all pictures are a reference only. Please take the actual objects as a standard.Elevation of MST6M182VG V6.0Side Elevation of MST6M182VG V6.03. FEATURESBelow you will find the detailed feature.CHIPSET MST6M182VG MARKET AREA AsiaOSD LANGUAGEEnglish,Chinese,(French,Spanish,Polish,Portuguese,Italian,German,Dutch,Russian)(Option )VIDEO SYSTEM PAL/SECAM,NTSC(Option)SOUND SYSTEM BG ,DK ,I, MTV RECEIVE CHANNELATV:200CVBS 1.0Vp-p +/-5% YPbPr / YCbCr 480i 、480p 、576i 、576p 、720p 、1080i 、1080pFormat Up to 1920*1080@60HZPC-RGBColor 16bit, 24bit, 32bitVIDEO INPUTHDMI 480i 、480p 、576i 、576p 、720p 、1080i 、1080p Build-in powersupply 5V,5VS,12V or only 12V （Option ）To panel 5V,12V POWERManage Low power consumable mode: standby ≤0.5WPC-RGB YESAUDIO INPUTAV/YPbPr Audio InputYESEXPANSIONFUNCTIONUSB YESPANELRESOLUTIONSSupport up to 10-bit dual LVDS FULL HD panel interface KEY FUNCTIONS CH-,CH+,MENU,VOL-,VOL+,SOURCE,ON/OFFAUDIO OUTPUT2*8 W @ 8Ω COMB FILTER3D DE-INTERLACE3D WEAK SIGNAL ENHANCEMENTYES NOISE REDUCTION3D NICAM/A2, TELETEXT,BTSC,CC,VCHIPYES TV Input 1 IEC 75 Ω PC-RGB Input 1D-SUB 15PIN terminal blue color HDMI Input 3HDMI terminal CVBS Input 1RCA terminal yellow colorYPbPr Input3RCA terminal green color,blue color andred colorYPbPr Audio InputCVBS Audio Input 2*2RCA terminal white color, red colorInput USB 2 USB terminal To Panel Double LVDS 38PIN/2.0 jackSPDIF 1RCA terminal orange colorTERMINALSOutput Earphone Out 1earphone terminal black color USB MULTIMEDIA PLAYBACK FORMAT MEDIA FILE EXTENSIONPicture JPEG 、BMP 、PNG .jpg 、.bmp 、.pngMovieMPEG1、MPEG2、MPEG4、H264、RM 、RMVB 、MOV 、MJPEG 、VC1、Divx 、FLV.avi 、.mpg 、.dat 、.vob 、.div 、.mov 、.mkv 、.rm 、.rmvb 、.mp4、.mjpeg 、ts 、.trp 、.wmv 、.asf 、.flvMusic WMA 、MP3、M4A 、AAC .wma 、.mp3、.m4aFILE TYPE\THE RELEVANT PARAMETERSRESOLUTIONCOMPRESSIONOPTION SUPPORT BOUNDARIES Progressive JPEGResolution Only Support 1024*768Baseline （”standard”） supportJPEG 15360*8640 Baseline optimizedsupporthomochromatism Support16color Support256color Support 16bit Support24bit SupportBMP 9600*640032bit supportNo interlacingSupport PNG 9600*6400InterlacedResolution Only Support 1200*800*Realize that only when you gain the copyright of the corresponding USB functions ，can the above-mentioned USB functions be used. 4. INTERFACE DEFINITIONCN1 ( 13PIN/2.0 ) MAIN POWER SUPPLYNO.SYMBOLDESCRIPTIONELECTRIC CHARACTER1 12VA2 12VA+12V DC Power supply2A+Panel Electric Current +electric Current of extended module 3 GND4 GND5 GND Ground ---6 5V7 5V+5V DC Power supply2A+Panel Electric Current + electricCurrent of extended module 8 5VS +5V DC Power standby 1A 9 PW ON/OFF --- 10 5V 11 5V+5V DC Power supply2A+Panel Electric Current + electricCurrent of extended module 12 GND Ground ---13 GND Ground ---CN2 (5PIN/2.0) DVD POWER SUPPLYNO. SYMBOL DESCRIPTION1 12VIN +12V DC Power supply2 GND Ground3 GND Ground4 5V_DVD DVD +5V DC Power supply5 5V_DVD DVD +5V DC Power supplyCN4( 6PIN/2.0 ) INVERTER INTERFACENO. SYMBOL DESCRIPTION ELECTRIC CHARACTER1 GNDGround ---2 GNDadjustableadjustment 0-5V3 ADJUST Brightness4 ON/OFF Back-light ON/OFF control 5V ，1K ohm output impedance5 12VA +12V DC Power supply INVERTER Power Supply6 12VA +12V DC Power supply INVERTER Power SupplyCN5 (4PIN/2.0) DVD DEBUGGING INTERFACENO. SYMBOL DESCRIPTION1 GND Grounddata2 DVD-TXD Transmitdata3 DVD-RXD ReceiveIR4 DVD_IR DVDCN6 (2PIN/2.0) EXTERNAL MEMC CONTROL I2CNO. SYMBOL DESCRIPTION1 SDA I2C Master bus for SDA2 SCL I2C Master bus for SCLCN7 (9PIN/2.0) KEY BOARD INTERFACENO. SYMBOL DESCRIPTION1 GND Ground2 CH- CH-keyKey3 CH+ CH+4 MENU MENUKeyKey5 VOL- VOL-Key6 VOL+ VOL+7 GND GroundKey8 SOURCE SOURCEkey9 ON/OFF ON/OFFCN8 (5PIN/2.0) REMOTE RECEIVER INTERFACENO. SYMBOL DESCRIPTION1 GND Groundreceiver2 IR_IN Remote3 LED_G Greenindicatorindicator4 LED_R Red5 IR_VCC +5V DC power supplyCN9 (2*19PIN/2.0) LVDS PANEL INTERFACENO. SYMBOL DESCRIPTION1 VDD Power for panel2 CT mode pin for panel3 VDD Power for panel4 GNDGround5 GND6 GND7 RXO0- LVDS ODD 0- Signal8 RXO0+ LVDS ODD 0+ Signal9 RXO1- LVDS ODD 1- Signal10 RXO1+ LVDS ODD 1+ Signal11 RXO2- LVDS ODD 2- Signal12 RXO2+ LVDS ODD 2+ Signal13 GNDGround14 GND15 RXOC- LVDS ODD Clock- Signal16 RXOC+ LVDS ODD Clock+ Signal17 RXO3- LVDS ODD 3- Signal18 RXO3+ LVDS ODD 3+ Signal19 RXE0- LVDS EVEN 0- Signal20 RXE0+ LVDS EVEN 0+ Signal21 RXE1- LVDS EVEN 1- Signal22 RXE1+ LVDS EVEN 1+ Signal23 RXE2- LVDS EVEN 2- Signal24 RXE2+ LVDS EVEN 2+ Signal25 GND Ground26 GND Ground27 RXEC- LVDS EVEN Clock- Signal28 RXEC+ LVDS EVEN Clock+ Signal29 RXE3- LVDS EVEN 3- Signal30 RXE3+ LVDS EVEN 3+ Signal31 RXE4- LVDS EVEN 4- Signal32 RXE4+ LVDS EVEN 4+ Signal33 RXO4- LVDS ODD 4- Signal34 RXO4+ LVDS ODD 4+ Signal35 SCL SCL36 SDA SDAflag37 3D_FLAG 3Dbrightness adjustment38 PB_ADJUST Back-lightCN10 (4PIN/2.0) DEBUGGING INTERFACENO. SYMBOL DESCRIPTION1 GND Grounddata2 UART-RX Receivedata3 UART-TX Transmit4 +5V_Standby +5V Power supplyCN28 (9PIN/2.0) YPBPR INPUTNO. SYMBOL DESCRIPTION1 Y Y signal input2 GND Ground3 PB PB signal input4 GND Ground5 PR PR signal input6 GND Ground7 R YPBPR right audio input8 GND Ground9 L YPBPR left audio input CN30 (4PIN/2.54) SPEAKER INTERFACENO. SYMBOL DESCRIPTION1 R+ Positive right audio channel out2 R- Negative right audio channel out3 L- Negative left audio channel out4 L+ Positive left audio channel out5. CONTROLLER DIMENSIONSThe dimension is identical to the actual objects.But maybe exist the slight error of measures about 1%.It is allowed in design.6. KEY & IR BOARD SYSTEM SCHEMATICMST6M182VG V6.0 Specification- 10 -7. OPERTION REQUIREMENT· Do not pressed and distorted. · Keep away from static and water. · Relative humidity: ≤80%· Storage temperature:-10~ +60℃ · Operation temperature:0~ +40℃。
目录一、概述二、主要特性三、A/D驱动板外观图四、VGA预设支持模式表五、输入/输出接口定义及接口电气要求六、主板结构与尺寸七、运输，存储，使用要求一、功能概述JRY1A31液晶显示器控制板卡(支持1440*900及以下分辨率TFT Panel,主芯片用TSUM1PFR-LF或TSUM1PLR-LF。
)它完成从PC输出的VGA模拟信号到液晶模块能够支持的LVDS 信号的转换，该设计主要用于配接TFT LCD PANEL，该产品适用于1440*900及以下分辨率8-BIT和6-BIT屏，实现模拟R、G、B输入和输出，实现最高分辨率可达UXGA的模拟R、G、B输入信号的再现，色彩再现可支持到24bit,最高可达16.7百万像素,ADC 频率达165MHz,并具有去抖动，降躁，锐度增强等特殊功能，使色彩再现更逼真、更鲜艳、更生动。
可实现同步自动检测。
同步方式要求使用行场分离的同步信号；具有精美的OSD界面风格，7种可供选择的OSD语言。
软件支持16:10与4:3显示模式的切换功能，此功能为玩游戏的用户提供了很大的方便，主板上的软件支持在线更新，本产品支持VGA功能，最大输出分辨率支持1440*900。
非另有说明，产品所符合规范在本文档内描述。
二、主要特性控制板支持规格：输入信号：模拟RGB(0.7Vp-p)，行场分离同步信号支持模式：DOS，VGA，SVGA，XGA，SXGA，WXGA, 色彩：18bit/24bit (根据屏参数可选择)行同步范围：31.5-80KHz场同步范围：60-75Hz输出信号：LVDS 标准控制按键：POWER、LEFT、RIGHT、AUTO、MENU、UP、DOWN、7键（可根据客户要求，通过软件更改成5键或6键）OSD 菜单：亮度，对比度，自动校正，相位，时钟，行场位置，功能设置，复位等目前国际流行标准功能OSD 语言：English,Espanlo,Francais,Deutsch，中文，韩语等多国语言程序升级: 支持VGA在线升级电源输入：此板配内置二合一电源板，5.0 VDC（+/-0.2V）电源操作：正常工作模式，低功耗模式待机功耗：＜1.0WPCB尺寸：62mm(L)×62mm(W)×1.2mm(H)即插即用：支持配接 TFT LCD PANEL类型可支持AU,SAMSUNG，CPT，SHARP，CHIMEI，HUAMMSTAR，TOSHIBA ,LG-Philips 等等厂家的19英寸及其以下的大多数型号的数字TFT LCD，具体可能需要对 LCD接口电缆和软件做一定修改。
创佳彩电产品介绍按产品功能介绍USB电影播放功能：创佳电视32HME5000 X12基本参数品牌canca创佳型号32HME5000 X12颜色黑色外观用料ABS创佳电视42LWE6300 F1创佳电视19HDE3000 V6创佳电视32HME8000 R35创佳电视22HZE9000 C68创佳电视32HZE9000 C68创佳电视19HZE9000 C68创佳电视26HZE9000 C68创佳电视32LME7000 T25创佳电视43HPD6000 K91创佳电视40HZE9000 C68创佳电视46HZE9000 C68创佳电视32LME8800 E6创佳电视51HPD6000 K91创佳电视22HDE3000 V655HZE9000 C6839HWE6300 F1创佳电视32HDE3000 V6创佳电视40LME8800 E6互联网电视功能：创佳电视32HME5000 X12创佳电视32LME8800 E6创佳电视40LME8800 E6电视/显示屏两用功能：创佳电视32HME5000 X12创佳电视19HDE3000 V6创佳电视22HZE9000 C68创佳电视32HZE9000 C68创佳电视32LME7000 T25创佳电视40HZE9000 C68创佳电视46HZE9000 C68创佳电视32LME8800 E6创佳电视22HDE3000 V6创佳电视 55HZE9000 C68创佳电视32HDE3000 V6创佳电视40LME8800 E6超窄边电视功能：创佳电视42LWE6300 F1创佳电视32HME8000 R35创佳电视32LME7000 T25。
液晶万能通用主板有了此套全能通用套板，即可对市面上各种品牌机快速检测断定故障部位，一般对一台大屏幕液晶电视故障检测可在2---10分钟内完成，大大减轻维修负担！！！各插口功能：1.遥控接收板2.按键接收板3.主板供电及开关机控制（包括：12V 5V GND 5VS ON/OFF ）4.背光控制(包括：12V GND BKL （背光开关信号）ADJ （背光亮度信号）注意：在点大屏的时候12V 不要通电，只需要接GND 和BKL 和ADJ 或是GND 和BKL 我们现在用的屏基本上第12脚为BKL 脚我们可以注意看一下高压板上面的标识)5.显示屏电压选择(3.3V 5V 12V 这个要特别注意弄不好就会烧屏，一定要先786查清楚你所要点的屏上电电压)6.LVDS屏线（屏线不能插反或是插错，不然会引起烧板或是烧屏，注意屏线的电源一头应插在长方形的角有个一缺口的那一端，或是打有白点的那一端）7.接口功能未开通8.喇叭接口9.接口功能未开通10.接口功能未开通11.主板程序写入接口12.接口功能未开通万能液晶驱动板主板特点:此液晶驱动主板可以从:5.6寸直接点到65寸，不管你是高分低分，只需要一个高分程序和一个低分程序即可搞定（建议买家够买两套此液晶主板，一板写高分程序，一板写低分程序这样用起来更方便），目前我这还有一种液晶主板不论高分低分屏，可全部通过遥控器来操作，不用因屏不同而又要重新烧录程序。
但是我不建议大家买这样的板，虽然不用重新写程序，但是你每次点一个高分屏或是一个低分屏后，再点另一种屏时，又得用遥控器进总线进行程序的改写，有时候还改写不成功，造成我们以为屏坏的错觉，所以我建议大家也不是为了省那么100多块钱而去影响我们的工作效率。
此主板带了现在主流的HDMI高清接口两路，一路AV输出和输入，两路高清分量信号输入，一路S端子，一路RF，和一路声音带来听觉震撼的同轴声音输出，给我们带来不一样的听觉效果。
CONTENTSTITLE PAGE CONTENTS········································page 1 of10 RECORD OF REVISIONS····························page 1 of10 GENERAL DESCRIPTION····························page 2 of10 FUNCTION LAYOUT·································page 2 of10 FEATURES·········································page 3 of10 INTERFACE DEFINITION····························page 5 of10 CONTROLLER DIMENSIONS·························page 9 of10KEY & IR BOARD SYSTEM SCHEMATIC··············page 9 of10 OPERATION REQUIREMENT·························page 10 of10RECORD OF REVISIONSREVISION NO. DATE PAGE DESCRIPTION1. GENERAL DESCRIPTIONMST182VG V6.0 is a multi-purpose LCD controller, it is suitable Asia market.It is designed to support FULL HD LCD panel.MST182VG V6.0 can support PC-RGB,HDMI,AV,YPBPR,USB, VGA,TV signal input.It can also support Earphone output.Note:The specification of the board includes the description of all functions. Therefore,our clients can select the functions which they require to produce the board.But the specification can be introduced universally.2. FUNCTION LAYOUTThe following all pictures are a reference only. Please take the actual objects as a standard.Elevation of MST6M182VG V6.0Side Elevation of MST6M182VG V6.03. FEATURESBelow you will find the detailed feature.CHIPSET MST6M182VG MARKET AREA AsiaOSD LANGUAGEEnglish,Chinese,(French,Spanish,Polish,Portuguese,Italian,German,Dutch,Russian)(Option )VIDEO SYSTEM PAL/SECAM,NTSC(Option)SOUND SYSTEM BG ,DK ,I, MTV RECEIVE CHANNELATV:200CVBS 1.0Vp-p +/-5% YPbPr / YCbCr 480i 、480p 、576i 、576p 、720p 、1080i 、1080pFormat Up to 1920*1080@60HZPC-RGBColor 16bit, 24bit, 32bitVIDEO INPUTHDMI 480i 、480p 、576i 、576p 、720p 、1080i 、1080p Build-in powersupply 5V,5VS,12V or only 12V （Option ）To panel 5V,12V POWERManage Low power consumable mode: standby ≤0.5WPC-RGB YESAUDIO INPUTAV/YPbPr Audio InputYESEXPANSIONFUNCTIONUSB YESPANELRESOLUTIONSSupport up to 10-bit dual LVDS FULL HD panel interface KEY FUNCTIONS CH-,CH+,MENU,VOL-,VOL+,SOURCE,ON/OFFAUDIO OUTPUT2*8 W @ 8Ω COMB FILTER3D DE-INTERLACE3D WEAK SIGNAL ENHANCEMENTYES NOISE REDUCTION3D NICAM/A2, TELETEXT,BTSC,CC,VCHIPYES TV Input 1 IEC 75 Ω PC-RGB Input 1D-SUB 15PIN terminal blue color HDMI Input 3HDMI terminal CVBS Input 1RCA terminal yellow colorYPbPr Input3RCA terminal green color,blue color andred colorYPbPr Audio InputCVBS Audio Input 2*2RCA terminal white color, red colorInput USB 2 USB terminal To Panel Double LVDS 38PIN/2.0 jackSPDIF 1RCA terminal orange colorTERMINALSOutput Earphone Out 1earphone terminal black color USB MULTIMEDIA PLAYBACK FORMAT MEDIA FILE EXTENSIONPicture JPEG 、BMP 、PNG .jpg 、.bmp 、.pngMovieMPEG1、MPEG2、MPEG4、H264、RM 、RMVB 、MOV 、MJPEG 、VC1、Divx 、FLV.avi 、.mpg 、.dat 、.vob 、.div 、.mov 、.mkv 、.rm 、.rmvb 、.mp4、.mjpeg 、ts 、.trp 、.wmv 、.asf 、.flvMusic WMA 、MP3、M4A 、AAC .wma 、.mp3、.m4aFILE TYPE\THE RELEVANT PARAMETERSRESOLUTIONCOMPRESSIONOPTION SUPPORT BOUNDARIES Progressive JPEGResolution Only Support 1024*768Baseline （”standard”） supportJPEG 15360*8640 Baseline optimizedsupporthomochromatism Support16color Support256color Support 16bit Support24bit SupportBMP 9600*640032bit supportNo interlacingSupport PNG 9600*6400InterlacedResolution Only Support 1200*800*Realize that only when you gain the copyright of the corresponding USB functions ，can the above-mentioned USB functions be used. 4. INTERFACE DEFINITIONCN1 ( 13PIN/2.0 ) MAIN POWER SUPPLYNO.SYMBOLDESCRIPTIONELECTRIC CHARACTER1 12VA2 12VA+12V DC Power supply2A+Panel Electric Current +electric Current of extended module 3 GND4 GND5 GND Ground ---6 5V7 5V+5V DC Power supply2A+Panel Electric Current + electricCurrent of extended module 8 5VS +5V DC Power standby 1A 9 PW ON/OFF --- 10 5V 11 5V+5V DC Power supply2A+Panel Electric Current + electricCurrent of extended module 12 GND Ground ---13 GND Ground ---CN2 (5PIN/2.0) DVD POWER SUPPLYNO. SYMBOL DESCRIPTION1 12VIN +12V DC Power supply2 GND Ground3 GND Ground4 5V_DVD DVD +5V DC Power supply5 5V_DVD DVD +5V DC Power supplyCN4( 6PIN/2.0 ) INVERTER INTERFACENO. SYMBOL DESCRIPTION ELECTRIC CHARACTER1 GNDGround ---2 GNDadjustableadjustment 0-5V3 ADJUST Brightness4 ON/OFF Back-light ON/OFF control 5V ，1K ohm output impedance5 12VA +12V DC Power supply INVERTER Power Supply6 12VA +12V DC Power supply INVERTER Power SupplyCN5 (4PIN/2.0) DVD DEBUGGING INTERFACENO. SYMBOL DESCRIPTION1 GND Grounddata2 DVD-TXD Transmitdata3 DVD-RXD ReceiveIR4 DVD_IR DVDCN6 (2PIN/2.0) EXTERNAL MEMC CONTROL I2CNO. SYMBOL DESCRIPTION1 SDA I2C Master bus for SDA2 SCL I2C Master bus for SCLCN7 (9PIN/2.0) KEY BOARD INTERFACENO. SYMBOL DESCRIPTION1 GND Ground2 CH- CH-keyKey3 CH+ CH+4 MENU MENUKeyKey5 VOL- VOL-Key6 VOL+ VOL+7 GND GroundKey8 SOURCE SOURCEkey9 ON/OFF ON/OFFCN8 (5PIN/2.0) REMOTE RECEIVER INTERFACENO. SYMBOL DESCRIPTION1 GND Groundreceiver2 IR_IN Remote3 LED_G Greenindicatorindicator4 LED_R Red5 IR_VCC +5V DC power supplyCN9 (2*19PIN/2.0) LVDS PANEL INTERFACENO. SYMBOL DESCRIPTION1 VDD Power for panel2 CT mode pin for panel3 VDD Power for panel4 GNDGround5 GND6 GND7 RXO0- LVDS ODD 0- Signal8 RXO0+ LVDS ODD 0+ Signal9 RXO1- LVDS ODD 1- Signal10 RXO1+ LVDS ODD 1+ Signal11 RXO2- LVDS ODD 2- Signal12 RXO2+ LVDS ODD 2+ Signal13 GNDGround14 GND15 RXOC- LVDS ODD Clock- Signal16 RXOC+ LVDS ODD Clock+ Signal17 RXO3- LVDS ODD 3- Signal18 RXO3+ LVDS ODD 3+ Signal19 RXE0- LVDS EVEN 0- Signal20 RXE0+ LVDS EVEN 0+ Signal21 RXE1- LVDS EVEN 1- Signal22 RXE1+ LVDS EVEN 1+ Signal23 RXE2- LVDS EVEN 2- Signal24 RXE2+ LVDS EVEN 2+ Signal25 GND Ground26 GND Ground27 RXEC- LVDS EVEN Clock- Signal28 RXEC+ LVDS EVEN Clock+ Signal29 RXE3- LVDS EVEN 3- Signal30 RXE3+ LVDS EVEN 3+ Signal31 RXE4- LVDS EVEN 4- Signal32 RXE4+ LVDS EVEN 4+ Signal33 RXO4- LVDS ODD 4- Signal34 RXO4+ LVDS ODD 4+ Signal35 SCL SCL36 SDA SDAflag37 3D_FLAG 3Dbrightness adjustment38 PB_ADJUST Back-lightCN10 (4PIN/2.0) DEBUGGING INTERFACENO. SYMBOL DESCRIPTION1 GND Grounddata2 UART-RX Receivedata3 UART-TX Transmit4 +5V_Standby +5V Power supplyCN28 (9PIN/2.0) YPBPR INPUTNO. SYMBOL DESCRIPTION1 Y Y signal input2 GND Ground3 PB PB signal input4 GND Ground5 PR PR signal input6 GND Ground7 R YPBPR right audio input8 GND Ground9 L YPBPR left audio input CN30 (4PIN/2.54) SPEAKER INTERFACENO. SYMBOL DESCRIPTION1 R+ Positive right audio channel out2 R- Negative right audio channel out3 L- Negative left audio channel out4 L+ Positive left audio channel out5. CONTROLLER DIMENSIONSThe dimension is identical to the actual objects.But maybe exist the slight error of measures about 1%.It is allowed in design.6. KEY & IR BOARD SYSTEM SCHEMATICMST6M182VG V6.0 Specification- 10 -7. OPERTION REQUIREMENT· Do not pressed and distorted. · Keep away from static and water. · Relative humidity: ≤80%· Storage temperature:-10~ +60℃ · Operation temperature:0~ +40℃。
