UniOhm 常用器件规格书总合-6

Page 4•Small size and lightweight• Suitable for both flow and reflow soldering•Reduction of assembly costs and matching with placement machines2006 - 20072006 - 2007 Page 52006 - 2007Marking on the Resistors Body:• For 0402 size, no marking on the body due to the small size of the resistor.•±5% tolerance product. (Including resistance values less than 1Ω; both 1% and 5%) The marking is 3 digits, the first 2 digits are the significant figures of the resistance and the 3rd digit denotes number of zeros.153 = 15000Ω = 15K Ω; 120 = 12ΩBelow 10Ω shown as this: 6R8 = 6.8Ω• 1% tolerance marking of case size 0805 and bigger is 4 digits, the first 3 digits are the significant figures of the resistance and the 4th digit denotes number of zeros.2372 = 23700Ω = 23.7K Ω; 1430 = 143Ω Below 10Ω shown as this: 3R24 = 3.24ΩPage 6* More details, please see pages 77-78.• Standard E-96 series values (±1% tolerance) of 0603 size. Due to the small size of the resistor’s body, 3 digitsmarking will be used to indicate the accurate resistance value by using the Multiplier code & Standard E-96 Series Resistance Value Code as shown on Page 6.1.96K Ω = 196 x 101 Ω = 29B12.4Ω = 124 x 10-1 Ω = 10X• Standard E-24 series values which does not belong to E-96 series values (±1% tolerance) of 0603 size. The marking is the same as 5% tolerance but mark with underline.122 = 1200 = 1.2K Ω 680 = 68ΩTemperature coefficient ±5%: 1Ω ~ 10M Ω ≤ ±200PPM/°C±1%: 10Ω ~ 100Ω ≤ ±200PPM/°C; 101Ω ~ 1M Ω ≤ ±100PPM/°CShort-time overload ±5%: ±(2.0% + 0.1Ω) Max.±1%: ±(1.0% + 0.1Ω) Max.Insulation resistanceMin. 1,000 Mega OhmDielectric withstanding voltageNo evidence of flashover, mechanical damage, arcing or insulation breakdown Terminal bending±(1.0% + 0.05Ω) Max.Soldering heat ±(1.0% + 0.05Ω) Max.SolderabilityMin. 95% coverage Temperature cycling±5%: ±(1.0% + 0.05Ω) Max.±1%: ±(0.5% + 0.05Ω) Max.Humidity (Steady s tate) ±5%: ±(3.0% + 0.1Ω) Max.±1%: ±(0.5% + 0.1Ω) Max.Load life in humidity±5%: ±(3.0% + 0.1Ω) Max.±1%: ±(1.0% + 0.1Ω) Max.Load life±5%: ±(3.0% + 0.1Ω) Max.±1%: ±(1.0% + 0.1Ω) Max.* The values which are not of standard E-24 series (2% & 5%) and not of E-96 series (1%) could be offered on a case to case basis.2006 - 2007Page 7。

更多精彩等你发现产品手册PRODUCT MANUAL松诺盟科技有限公司推动科学技术与应用融合为中国高端传感器产业“国产化”做出贡献松诺盟科技有限公司是一家拥有多项传感器核心技术，致力于研发、生产与销售国产高性能纳米薄膜传感器的国家高新技术企业。

公司成立于 2018 年，总部位于国家级浏阳经济技术开发区，注册资金 12000 万元。

松诺盟立足于高性能纳米薄膜传感器研发制造技术的研究，不断增强企业核心竞争力，至今已荣获国内外授权的专利八十余项。

公司产品涵盖压力传感器、智能压力变送器、扭矩传感器、力传感器、液位变送器、温度传感器及其相关精密仪器仪表，且业务正不断向智慧消防、智慧水务、智慧桥隧等智慧物联拓展。

产品广泛应用于工业过程测控、国防装备、机器人、冶金、石油化工、工程机械等领域及水电、火电、核电、氢能等能源行业，已为多家知名企业成功解决核心传感器国产化替代难题。

松诺盟研发与生产的高性能纳米薄膜传感器同时具有精度高、长期稳定性好、寿命长、工作温度范围宽、体积小、功耗低、耐恶劣环境等优点。

产品经湖南省生产力促进中心院士专家评定为：整体技术达到国际先进水平，部分性能指标达到国际领先水平。

松诺盟拟通过五年努力，总投资 30 亿元，建成我国军民两用高性能智能压力、扭矩、温度、力传感器及其相关精密仪器仪表研发和生产基地，为我国国防建设、经济建设及我国高性能传感器跻身世界先进行列做出积极贡献。

自主研发已获授权专利 80 余项国产芯完全国产化注册资金12000 万元I S O体系认证五项管理体系认证公司介绍＋80＋10由湖南省生产力促进中心主持，中国工程院桂卫华院士任主任委员的科技成果评价专家委员会评价：松诺盟纳米薄膜压力传感器整体技术达到国际先进水平 其中，零点漂移、工作温度范围性能指标达到国际领先水平。

资质与荣誉QUALIFICATION AND HONOR高新技术企业证书科技成果评价核电先进传感技术研究中心机器人智能传感技术联合创新实验室中美俄日发明专利国内国际授权专利 80 余项扭矩传感器校准证书压力传感器检定证书CE 认证证书产品防爆证书评价纳米薄膜传感器专利中美俄日发明专利五大体系认证证书HIGH-PERFORMANCESENSOR金属弹性体技术、新型敏感材料技术、真空原子薄膜沉积技术等。

Surface Mount Ultra Fast RectifierFEATURES•Low profile package•Ideal for automated placement•Glass passivated pallet chip junction•Ultrafast reverse recovery time•Low switching losses, high efficiency•High forward surge capability•AEC-Q101 qualified available•Meets MSL level 1, per J-STD-020, LF maximum peak of260 °C-Automotive ordering code: base P/NHE3 or P/NHM3•Material categorization: for definitions of complianceplease see /doc?99912TYPICAL APPLICATIONS For use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer, automotive, and telecommunication.MECHANICAL DATA Case: SMA (DO-214AC) Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade Base P/N-M3 - halogen-free, RoHS-compliant, commercialgradeBase P/NHE3_X - RoHS-compliant and AEC-Q101 qualifiedBase P/NHM3_X - halogen-free, RoHS-compliant andAEC-Q101 qualified(“_X” denotes revision code e.g. A, B,.....)Terminals: matte tin plated leads, solderable perJ-STD-002 and JESD 22-B102E3, M3, HE3, and HM3 suffix meets JESD 201 class 2whisker testPolarity: color band denotes cathode end PRIMARY CHARACTERISTICS IF(AV) 1.0 A V RRM50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V I FSM30 A t rr50 ns, 75 ns V F at I F1.0 V, 1.7 V T J max.150 °C PackageSMA (DO-214AC)Diode variations Single S MA (DO-214AC)AvailableMAXIMUM RATINGS (T A = 25 °C unless otherwise noted)PARAMETERSYMBOL US1A US1B US1D US1G US1J US1K US1M UNIT Device marking codeUA UB UD UG UJ UK UM Maximum repetitive peak reverse voltageV RRM 501002004006008001000V Maximum RMS voltageV RMS 3570140280420560700V Maximum DC blocking voltageV DC 501002004006008001000V Maximum average forward rectified current at T L = 110 °CI F(AV) 1.0A Peak forward surge current 8.3 ms single half sine-wavesuperimposed on rated loadI FSM 30A Operating and storage temperature range T J , T STG -55 to +150°CNote(1)Pulse test: 300 μs pulse width, 1 % duty cycleNote(1)PCB mounted on 0.2" x 0.2" (5.0 mm x 5.0 mm) copper pad area ELECTRICAL CHARACTERISTICS (T A = 25 °C unless otherwise noted)PARAMETERTEST CONDITIONS SYMBOL US1A US1B US1D US1G US1J US1K US1M UNIT Maximum instantaneous forward voltage1.0 A V F (1) 1.0 1.7V Maximum DC reverse currentat rated DC blocking voltageT A = 25 °C I R 10μA T A = 100 °C 50Maximum reverse recovery timeI F = 0.5 A, I R = 1.0 A, I rr = 0.25 A t rr 5075ns Typical junction capacitance 4.0 V, 1 MHz C J 1510pF THERMAL CHARACTERISTICS (T A = 25 °C unless otherwise noted)PARAMETERSYMBOL US1A US1B US1D US1G US1J US1K US1M UNIT Maximum thermal resistanceR θJA (1)75°C/W R θJL (1)27RATINGS AND CHARACTERISTICS CURVES (T A = 25 °C unless otherwise noted)Fig. 1 - Forward Current Derating CurveFig. 2 - Maximum Non-Repetitive Peak Forward Surge Current Fig. 3 - Typical Instantaneous Forward Characteristics Fig. 4 - Typical Reverse Leakage CharacteristicsFig. 6 - Typical Reverse Leakage CharacteristicsFig. 7 - Typical Junction Capacitance Fig. 8 - Typical Transient Thermal ImpedancePACKAGE OUTLINE DIMENSIONS in inches (millimeters)找电子元器件上宇航军工Legal Disclaimer Notice。

科罗纳实验室（CORONA LAB．）Please refer to the manual in detail before installing, operating and debugging.安装，操作或调试设备前，请先详细阅读本说明一.概述南京苏曼电子有限公司始建于1983年。

二十几年来一直致力于低温等离子体（电浆）技术的理论研究和材料表面改性处理技术的产品开发，成熟的掌握了各种低温等离子体的实现方法和辉光放电、电晕放电、电弧放电、等产生低温等离子体的工艺技术和知识产权。

并将谐振型脉宽调制技术、微程序控制技术、数字信号处理技术、模糊程序控制等现代先进技术融合在苏曼公司的系列产品之中。

使苏曼公司推出的相关产品实现了电路数字化、软件模糊化、结构模块化、产品系列化。

在体积、效率、功率、可靠性、外观、可操作性及系列方面在国内都处于领先水平。

尤其在价格和易用性方面更具中国特色。

苏曼公司创建的科罗纳实验室（CORONA Lab.）现在已经成为国内最具技术实力的低温等离子体技术和表面处理技术相关产品的研发基地。

推出了十几款用于各种材料和形状的表面改性处理系列产品和大功率臭氧电源，成功的推动了我国高分子材料表面改性处理技术的发展和设备的更新换代。

苏曼公司对各种高分子和金属材料所制成的薄膜、片材、二维和三维零件、高分子和金属材料的复合零件都有对应的表面处理产品。

对印刷、吹膜、复合、流延、涂覆、胶结、真空镀铝、编织布、化纤布、无纺布、片材、管材、合成纸、粉粒等表面处理也有其对应的解决方案。

另外，我们还可为高等院校和研究院所设计和定制用于表面聚合、表面接枝、金属渗氮、冶金、表面催化、化学合成和气液态污染物的处理等各种低温等离子体的处理设备和实验装置。

目前在线生产的系列产品有、ZW-A，CTE-K，CTR（薄膜表面处理系列）、CTT-K，CTT-F （供暖管，天然气管，石油管等内外管壁PE表面处理系列）、CTB(冰箱盖处理)，CTD，CTD-K，RFD，RFD-F（二维和三维零件表面处理系列）、CTP（低温等离子体实验仪器仪表系列）、CTK （片材处理系列）、HPD系列次大气辉光放电低温等离子表面处理系统、CTO（大功率臭氧电源系列）等产品系列。

Dimensions: [mm]sectional drawing A-AScale - 2:1Product Marking:Start of Winding•7447452683744745268374474526837447452683T e m p e r a t u r eT T T 7447452683Cautions and Warnings:The following conditions apply to all goods within the product series of WE-TI of Würth Elektronik eiSos GmbH & Co. KG:General:•This electronic component was designed and manufactured for use in general electronic equipment.•Würth Elektronik must be asked for written approval (following the PPAP procedure) before incorporating the components into any equipment in fields such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network, etc. where higher safety and reliability are especially required and/or if there is the possibility of direct damage or human injury.•Electronic components that will be used in safety-critical or high-reliability applications, should be pre-evaluated by the customer. •The component is designed and manufactured to be used within the datasheet specified values. If the usage and operation conditions specified in the datasheet are not met, the wire insulation may be damaged or dissolved.•Do not drop or impact the components, the component may be damaged.•Würth Elektronik products are qualified according to international standards, which are listed in each product reliability report. Würth Elektronik does not warrant any customer qualified product characteristics beyond Würth Elektroniks’ specifications, for its validity and sustainability over time.•The customer is responsible for the functionality of their own products. All technical specifications for standard products also apply to customer specific products.Product specific:Soldering:•The solder profile must comply with the technical product specifications. All other profiles will void the warranty.•All other soldering methods are at the customers’ own risk.Cleaning and Washing:•Washing agents used during the production to clean the customer application might damage or change the characteristics of the wire insulation, marking or plating. Washing agents may have a negative effect on the long-term functionality of the product. Potting:•If the product is potted in the costumer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the core. Expansion could damage the components. We recommend a manual inspection after potting to avoid these effects. Storage Conditions:• A storage of Würth Elektronik products for longer than 12 months is not recommended. Within other effects, the terminals may suffer degradation, resulting in bad solderability. Therefore, all products shall be used within the period of 12 months based on the day of shipment.•Do not expose the components to direct sunlight.•The storage conditions in the original packaging are defined according to DIN EN 61760-2.•The storage conditions stated in the original packaging apply to the storage time and not to the transportation time of the components. Packaging:•The packaging specifications apply only to purchase orders comprising whole packaging units. If the ordered quantity exceeds or is lower than the specified packaging unit, packaging in accordance with the packaging specifications cannot be ensured. Handling:•Violation of the technical product specifications such as exceeding the nominal rated current will void the warranty.•Applying currents with audio-frequency signals might result in audible noise due to the magnetostrictive material properties. •Due to heavy weight of the components, strong forces and high accelerations might have the effect to damage the electrical connection or to harm the circuit board and will void the warranty.•Please be aware that products provided in bulk packaging may get bent and might lead to derivations from the mechanical manufacturing tolerances mentioned in our datasheet, which is not considered to be a material defect.•The temperature rise of the component must be taken into consideration. The operating temperature is comprised of ambient temperature and temperature rise of the component.The operating temperature of the component shall not exceed the maximum temperature specified.These cautions and warnings comply with the state of the scientific and technical knowledge and are believed to be accurate and reliable.However, no responsibility is assumed for inaccuracies or incompleteness.Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi002.0072019-08-05DIN ISO 2768-1mDESCRIPTIONWE-TI Radial Leaded Wire WoundInductor ORDER CODE7447452683SIZE/TYPE BUSINESS UNIT STATUS PAGEImportant NotesThe following conditions apply to all goods within the product range of Würth Elektronik eiSos GmbH & Co. KG:1. General Customer ResponsibilitySome goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas. These statements about suitability are based on our knowledge and experience of typical requirements concerning the areas, serve as general guidance and cannot be estimated as binding statements about the suitability for a customer application. The responsibility for the applicability and use in a particular customer design is always solely within the authority of the customer. Due to this fact it is up to the customer to evaluate, where appropriate to investigate and decide whether the device with the specific product characteristics described in the product specification is valid and suitable for the respective customer application or not.2. Customer Responsibility related to Specific, in particular Safety-Relevant ApplicationsIt has to be clearly pointed out that the possibility of a malfunction of electronic components or failure before the end of the usual lifetime cannot be completely eliminated in the current state of the art, even if the products are operated within the range of the specifications.In certain customer applications requiring a very high level of safety and especially in customer applications in which the malfunction or failure of an electronic component could endanger human life or health it must be ensured by most advanced technological aid of suitable design of the customer application that no injury or damage is caused to third parties in the event of malfunction or failure of an electronic component. Therefore, customer is cautioned to verify that data sheets are current before placing orders. The current data sheets can be downloaded at .3. Best Care and AttentionAny product-specific notes, cautions and warnings must be strictly observed. Any disregard will result in the loss of warranty.4. Customer Support for Product SpecificationsSome products within the product range may contain substances which are subject to restrictions in certain jurisdictions in order to serve specific technical requirements. Necessary information is available on request. In this case the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter.5. Product R&DDue to constant product improvement product specifications may change from time to time. As a standard reporting procedure of the Product Change Notification (PCN) according to the JEDEC-Standard inform about minor and major changes. In case of further queries regarding the PCN, the field sales engineer or the internal sales person in charge should be contacted. The basic responsibility of the customer as per Section 1 and 2 remains unaffected.6. Product Life CycleDue to technical progress and economical evaluation we also reserve the right to discontinue production and delivery of products. As a standard reporting procedure of the Product Termination Notification (PTN) according to the JEDEC-Standard we will inform at an early stage about inevitable product discontinuance. According to this we cannot guarantee that all products within our product range will always be available. Therefore it needs to be verified with the field sales engineer or the internal sales person in charge about the current product availability expectancy before or when the product for application design-in disposal is considered. The approach named above does not apply in the case of individual agreements deviating from the foregoing for customer-specific products.7. Property RightsAll the rights for contractual products produced by Würth Elektronik eiSos GmbH & Co. KG on the basis of ideas, development contracts as well as models or templates that are subject to copyright, patent or commercial protection supplied to the customer will remain with Würth Elektronik eiSos GmbH & Co. KG. Würth Elektronik eiSos GmbH & Co. KG does not warrant or represent that any license, either expressed or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, application, or process in which Würth Elektronik eiSos GmbH & Co. KG components or services are used.8. General Terms and ConditionsUnless otherwise agreed in individual contracts, all orders are subject to the current version of the “General Terms and Conditions of Würth Elektronik eiSos Group”, last version available at .Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi002.0072019-08-05DIN ISO 2768-1mDESCRIPTIONWE-TI Radial Leaded Wire WoundInductor ORDER CODE7447452683SIZE/TYPE BUSINESS UNIT STATUS PAGE。

UniOhm Uniroyal Electronics Industry Co., Ltd.厚声电子工业有限公司88 LongTeng Road, Economic & Technical Development Zone,Kunshan City, Jiangsu, China中国江苏省昆山市经济技术开发区龙腾路88号邮编: 215301Tel: +86 512 5763 1400 / 1411 /1422 /1433Fax: +86 512 5763 4599*******************************************Contents目录Metal Strip Current Sensing Chip Resistors - MS 金属带电流检测片式电阻器22MS06, MS07, MS10, MS11, MS12, MS17, MS20, MS27Anti-Electro Static Discharge Thick Film Chip Resistors - ES 抗静电膜晶片电阻器24ES01, ES02, ES03, ES05, ES06, ES07Low T.C.R Thick Film Chip Resistors - LT 低温度系数厚膜晶片电阻器26LT02, LT03, LT05, LT06AEC-Q200 Version Chip Resistors - HQ 汽车用晶片电阻器28HQ02, HQ03, HQ05, HQ06, HQ07, HQ10 , HQ12Thick Film Chip Resistors Network 厚膜晶片网络电阻器4610P8, 10S8, 10T8, 10E9Packing of Surface Mount Resistors 表面贴装式电阻器包装47Packing of Surface Mount ResistorsResistor Network - SIP Series 网络电阻器 - SIP 系列48RNL-A, RNL-B, RNL-C, RNL-D, RNL-E, RNL-L, RNL-R,RNL-G, RNL-PHigh Power Resistor Network - SIP RPL Series 高功率网络电阻器- SIP RPL 系列50RPL-A, RPL-B, RPL-RHigh Power Resistors Network Medium Profile–SIP RNM Series高功率中宽度网络电阻器 - SIP RNM 系列52RNM-A, RNM-B, RNM-RHigh Power Resistors Network High Profile–SIP RPH Series高功率高宽度网络电阻器 - SIP RPH 系列54RPH-A, RPH-B, RPH-RSpecial Network –SIP Series 特殊网络电阻器 - SIP 系列56SN0001, SN0002, SN0003, SN0004Resistor/Capacitor Network-SIP Series 网络阻容器电阻器 - SIP 系列57RCN-A, RCN-BCapacitor Network-SIP Series 网络电容器 - SIP 系列58CNM-1High Voltage Flat Resistors 高压扁平式电阻器59HFRCarbon Film Fixed Resistors 碳膜电阻器60CFRPrecision Metal Film Fixed Resistors 精密金属膜电阻器62MFRCarbon Film Power Resistors 高功率碳膜电阻器64CPR Metal Film Power Resistors 高功率金属膜电阻器65MPRWire-wound Fusible Resistors 绕线保险丝型电阻器74KFRThermal Fusing Wire-wound Fixed Resistors 绕线型温度保险丝电阻器76TFRCurrent Sense Resistors 电流检测线电阻器77CSRCurrent Sense Spring Resistors 弹簧式电流检测电阻器78CSSA, CSSB, CSSCThrough Hole Category - Network Resistors & Traditional Coated Resistors (插件式 - 排列电阻 & 涂装型电阻)New New New New UniOhm1Contents目录Axial Leaded Terminal Type-PRW Series 轴式导线型 - PRW 系列 97PRW , PRWA, PRWCRadial Leaded T ype-PRM & PRS Series 立式导线型 - PRM & PRS 系列 98PRM, PRMA, PRMB, PRMT , PRSUltra-Low Value Cement Resistors 超低阻水泥固定电阻器108PRWUPower Flat Alloy Resistors 功率型合金箔电阻器109PFAS, PFATColumnar Type Cement Fixed Resistors 圆柱状水泥电阻器111QHOStandard Packing of Cement Type Resistors 水泥型电阻器包装标准112Bulk/BoxPower Dissipation Mount Resistors 铝外壳电阻器115PDMHigh-Power Wire-wound Resistors 高功率绕线型固定电阻器116BTRVitreous Enameled Wire-wound Resistors 珐琅釉绕线固定电阻器127URXPower Type Thermal Fusing Resistors 功率型温度保险丝电阻128TFO, TFRCPower (Ribbon) Wire-wound Resistors 功率（合金带）绕线型电阻器129QH, QL, QR, QRZGTest Method of JIS-C-5201 & JIS-C-5202JIS-C-5201和 JIS-C-5202 检测方法131Standard Nominal Resistance Value 标准电阻值133Explnation of Part No. System 料号系统注释135Standard Color Code System 标准色码系统137Metal Glaze Film Fixed Resistors 金属玻璃釉膜固定电阻器79MGRHigh-Value Metal Glaze Film Fixed Resistors 超高阻玻璃釉膜固定电阻器81HMGRHigh-Voltage Metal Glaze Film Fixed Resistors 耐高压型玻璃釉膜固定电阻器82HVRTerminal Type Metal Oxide Film Resistors 端片型金属氧化膜电阻器83TMOR, TMOV , TMOLJumper Wires & Zero-Ohm Resistors 跳线及零欧姆电阻器84ZW , ZO, ZFCopper Plated Steel Lead Wire Type & Cutting Type 铜包钢导线型及切割半成品型85CP, CO Panasert Type (Panasert 型)86Avisert Type (Avisert 型)87AVI-1, AVI-2, AVI-3M & F Forming Type (M 型 & F 型 <成型> )89MF , MK, ML, F , F1, F2, F3Standard Packing of Coated Type Resistors 涂装型电阻器包装标准91Tape/Box, Tape/Reel, Bulk/BoxThrough Hole Category - Traditional Cement Resistors (插件式 - 水泥型电阻)Power Type Resistors (功率型)RELATIVE INFORMATION (相关资料)UniOhm2• Small size & light weight 短小轻薄• Reduction of assembly costs and matching with placement machine. 可降低装置成本及配合机器组装• Suitable for both wave & re-flow soldering. 适合波峰焊与回流焊• Applications: Navigator (GPS), Mobile Phone,Telecom, PDA, Setbox, Meter.应用于GPS， 移动电话，PDA，机顶盒，仪表Feature (特性)Figures (型状)Derating Curve & Specification降功率曲线及性能Thick Film Chip ResistorsPercentratedload(%)Ambient termperature 环境温度 (°C)厚膜晶片电阻器负载比率(%)UniOhm3 RoHS CompliantValue阻值Code 代码Value 阻值Code 代码Value 阻值Code 代码Value 阻值Code 代码Value 阻值Code 代码Value 阻值Code 代码100011471721533316494646568181102021501822134324504756669882105031541922635332514876771583107041582023236340524996873284110051622123737348535116975085113061652224338357545237076886115071692324939365555367178787118081742425540374565497280688121091782526141383575627382589124101822626742392585767484590127111872727443402595907586691130121912828044412606047688792133131962928745422616197790993137142003029446432626347893194140152053130147442636497995395143162103230948453646658097696Thick Film Chip Resistors• For 01005, 0201, 0402 size, no marking on the body due to the small size of the resistor. 01005, 0201, 0402因电阻本体太小，故本体无标示字码• ±5% tolerance product: the marking is 3 digits, the first 2 digits are the significant of theresistance and the 3rd digit denotes number of zeros following.±5%公差产品字码是三位数，前二位是阻值的有效数，第三位表示有几个 0• 0805, 1206, 1210, 2010, 2512 ≤±1%: the marking is 4 digits, the first 3 digits are the significant of the resistance and the 4th digit denotes number of zeros following. 0805, 1206, 1210, 2010, 2512 ≤±1%公差产品字码有四位数，前三位是阻值的有效数，第四位表示有几个 0Marking on the Resistors Body (电阻本体字码标示)2372 = 23700Ω = 23.7KΩBelow 10Ω : 3R24 = 3.24Ω10Ω 以下标示: 3R24 = 3.24Ω153 = 15000Ω = 15KΩBelow 10Ω: 6R8 = 6.8Ω10Ω 以下标示: 6R8 = 6.8Ω• Standard E-96 series values of 0603 ≤±1%: due to the small size of the resistor’s body, 3 digits marking will be used to indicate the accurate resistance value by using the following Multiplier & Resistance Code. 0603 ≤±1%公差 E-96系列标准阻值，因电阻本体太小，采用三位阻值代码（数字）及下列指数代码（字母）配合来指明标准的阻值。

由于整理份数较多以及版本较多请用CTRL+F 快速查找想要的元件名第一份：protues元件库中英文对照表AND 与门ANTENNA 天线BA TTERY 直流电源BELL 铃,钟BVC 同轴电缆接插件BRIDEG 1 整流桥(二极管)BRIDEG 2 整流桥(集成块)BUFFER 缓冲器BUZZER 蜂鸣器CAP 电容CAPACITOR 电容CAPACITOR POL 有极性电容CAPV AR 可调电容CIRCUIT BREAKER 熔断丝COAX 同轴电缆CON 插口CRYSTAL 晶体整荡器DB 并行插口DIODE 二极管DIODE SCHOTTKY 稳压二极管DIODE VARACTOR 变容二极管DPY_3-SEG 3段LEDDPY_7-SEG 7段LEDDPY_7-SEG_DP 7段LED(带小数点)ELECTRO 电解电容FUSE 熔断器INDUCTOR 电感INDUCTOR IRON 带铁芯电感INDUCTOR3 可调电感JFET N N沟道场效应管JFET P P沟道场效应管LAMP 灯泡LAMP NEDN 起辉器LED 发光二极管METER 仪表MICROPHONE 麦克风MOSFET MOS管MOTOR AC 交流电机MOTOR SERVO 伺服电机NAND 与非门NOR 或非门NOT 非门NPN NPN三极管NPN-PHOTO 感光三极管OPAMP 运放OR 或门PHOTO 感光二极管PNP 三极管NPN DAR NPN三极管PNP DAR PNP三极管POT 滑线变阻器PELAY-DPDT 双刀双掷继电器RES1.2 电阻RES3.4 可变电阻RESISTOR BRIDGE ? 桥式电阻RESPACK ? 电阻SCR 晶闸管PLUG ? 插头PLUG AC FEMALE 三相交流插头SOCKET ? 插座SOURCE CURRENT 电流源SOURCE VOLTAGE 电压源SPEAKER 扬声器SW ? 开关SW-DPDY ? 双刀双掷开关SW-SPST ? 单刀单掷开关SW-PB 按钮THERMISTOR 电热调节器TRANS1 变压器TRANS2 可调变压器TRIAC ? 三端双向可控硅TRIODE ? 三极真空管V ARISTOR 变阻器ZENER ? 齐纳二极管DPY_7-SEG_DP 数码管SW-PB 开关原理图常用库文件：Miscellaneous Devices.ddbDallas Microprocessor.ddbIntel Databooks.ddbProtel DOS Schematic Libraries.ddb PCB元件常用库：Advpcb.ddbGeneral IC.ddbMiscellaneous.ddb分立元件库部分分立元件库元件名称及中英对照AND 与门ANTENNA 天线BA TTERY 直流电源BELL 铃,钟BVC 同轴电缆接插件BRIDEG 1 整流桥(二极管) BRIDEG 2 整流桥(集成块) BUFFER 缓冲器BUZZER 蜂鸣器SOUNDERCAP 电容CAPACITOR 电容CAPACITOR POL 有极性电容CAPV AR 可调电容CIRCUIT BREAKER 熔断丝COAX 同轴电缆CON 插口CRYSTAL 晶体整荡器DB 并行插口DIODE 二极管DIODE SCHOTTKY 稳压二极管DIODE VARACTOR 变容二极管DPY_3-SEG 3段LEDDPY_7-SEG 7段LEDDPY_7-SEG_DP 7段LED(带小数点) ELECTRO 电解电容FUSE 熔断器INDUCTOR 电感INDUCTOR IRON 带铁芯电感INDUCTOR3 可调电感JFET N N沟道场效应管JFET P P沟道场效应管LAMP 灯泡LAMP NEDN 起辉器LED 发光二极管METER 仪表MICROPHONE 麦克风MOSFET MOS管MOTOR AC 交流电机MOTOR SERVO 伺服电机NAND 与非门NOR 或非门NOT 非门NPN NPN三极管NPN-PHOTO 感光三极管OPAMP 运放OR 或门PHOTO 感光二极管PNP 三极管NPN DAR NPN三极管PNP DAR PNP三极管POT 滑线变阻器PELAY-DPDT 双刀双掷继电器RES1.2 电阻RES3.4 可变电阻RESISTOR BRIDGE ? 桥式电阻RESPACK ? 电阻SCR 晶闸管PLUG ? 插头PLUG AC FEMALE 三相交流插头SOCKET ? 插座SOURCE CURRENT 电流源SOURCE VOLTAGE 电压源SPEAKER 扬声器SW ? 开关SW-DPDY ? 双刀双掷开关SW-SPST ? 单刀单掷开关SW-PB 按钮THERMISTOR 电热调节器TRANS1 变压器TRANS2 可调变压器TRIAC ? 三端双向可控硅TRIODE ? 三极真空管V ARISTOR 变阻器ZENER ? 齐纳二极管7SEG 数码管SW-PB 开关其他元件库Protel Dos Schematic 4000 Cmos .Lib40.系列CMOS管集成块元件库4013 D 触发器4027 JK 触发器Protel Dos Schematic Analog Digital.Lib 模拟数字式集成块元件库AD系列DAC系列HD系列MC系列Protel Dos Schematic Comparator.Lib 比较放大器元件库Protel Dos Shcematic Intel.Lib INTEL公司生产的80系列CPU集成块元件库Protel Dos Schematic Linear.lib 线性元件库例555Protel Dos Schemattic Memory Devices.Lib 内存存储器元件库Protel Dos Schematic SYnertek.Lib SY系列集成块元件库Protes Dos Schematic Motorlla.Lib 摩托罗拉公司生产的元件库Protes Dos Schematic NEC.lib NEC公司生产的集成块元件库Protes Dos Schematic Operationel Amplifers.lib 运算放大器元件库Protes Dos Schematic TTL.Lib 晶体管集成块元件库74系列Protel Dos Schematic V oltage Regulator.lib 电压调整集成块元件库Protes Dos Schematic Zilog.Lib 齐格格公司生产的Z80系列CPU集成块元件库元件属性对话框中英文对照Lib ref 元件名称Footprint 器件封装Designator 元件称号Part 器件类别或标示值Schematic Tools 主工具栏Writing Tools 连线工具栏Drawing Tools 绘图工具栏Power Objects 电源工具栏Digital Objects 数字器件工具栏Simulation Sources 模拟信号源工具栏PLD Toolbars 映象工具栏Proteus 元件名称对照1元件名称中文名说明7407 驱动门1N914 二极管74Ls00 与非门74LS04 非门74LS08 与门74LS390 TTL 双十进制计数器7SEG 4针BCD-LED 输出从0-9 对应于4根线的BCD码7SEG 3-8译码器电路BCD-7SEG[size=+0]转换电路ALTERNATOR 交流发电机AMMETER-MILLI mA安培计AND 与门BA TTERY 电池/电池组BUS 总线CAP 电容CAPACITOR 电容器CLOCK 时钟信号源CRYSTAL 晶振D-FLIPFLOP D触发器FUSE 保险丝GROUND 地LAMP 灯LED-RED 红色发光二极管LM016L 2行16列液晶可显示2行16列英文字符，有8位数据总线D0-D7，RS，R/W，EN三个控制端口（共14线），工作电压为5V。

复旦微电子FM11NC08SFM11NC08是复旦微电子公司开发的符合 ISO/IEC14443－A 协议的 NFC 通道芯片。

FM11NC08 分为两种子类型：FM11NC08S 和 FM11NC08I，FM11N 非接触接口之间的数据交互，FM11NC08I 可完成 I2C 接口和 NFC 非接触接口之间的数据交互。

FM11NC08 可以为只有接触接口的通用 MCU 提供一个非接触通道，使通用 MCU 可以和读卡器或 NFC 手机进行实时的数据交互。

非接触端口数据传输速率可达到 848Kbps。

FM11NC08 内置 8Kbit EEPROM，可用于通用 MCU 和NFC手机之间的非实时的数据交互，比如：由 NFC 手机向 EEPROM 中写入配置信息，通用 MCU 空闲时再进行FM11NC08 具有非接触场能量对外供电功能，配合低功耗 MCU，可应用于一些便携式 NFC 应用。

FM11NC08 配合外部主控 MCU，可以作为 NFC FORUM type4 TAG 使用。

产品说明书FM1208FM1208 是上海复旦微电子股份有限公司设计的单界面非接触 CPU 卡，容量为 64K Byte EEPROM，符合 ISO14443 Type A 标准，工作频率为13.56MHz，工作距离不小PBOC 2.0 标准（电子钱包）及建设部 IC 卡应用规范，具有较好的安全性。

数据手册COS 手册华翼微电子华翼微电子HYm4616A1/2/3/4/5/6HYm4616A1-6 是支持 ISO/IEC 14443 TYPE A 通信协议的非接触式 CPU 卡芯片。

HYm4616A1-6 集成了 Turbo 51 微处理器、32bit 随机数发生器、DES / 3DES 算法模块、国密33、SM1 加密算法、M1 协处理器。

NXPTITITRF7970ATRF7970A 是一款用于 13.56MHz RFID/近场通信系统的集成模拟前端和数据组帧器件。
