DIN6796型尺寸示意图

取代77.07版单位mm1 适用范围和用途本标准规定的张力轮是根据DIN ISO 898 第1部分8.8到10.9强度等级的用于螺栓连接的传递力的和共同夹紧的弹簧元件。

张力轮应该能够防止例如Setzbetrage造成的螺栓连接的松动（键DIN 267第26部分）。

在变化的横向负载下的拧出过程中，张力轮不能提供有效的防护，因此只能用在主要轴向承受负载的较短的螺栓。

2尺寸标称尺寸d1d2s h 重量（7.85kg/dm3）Kg 每1000个≈螺纹标称直径H14 h14 3) Max 1) Min2)2 4) 2.2 5 0.4 0.6 0.5 0.05 22.5 4) 2.7 6 0.5 0.72 0.61 0.09 2.53 4) 3.2 7 0.6 0.85 0.72 0.14 33.5 4) 3.7 8 0.8 1.06 0.92 0.25 3.54 4.3 9 1 1.3 1.12 0.38 45 5.3 11 1.2 1.55 1.35 0.69 56 6.4 14 1.5 2 1.7 1.43 67 7.4 17 1.75 2.3 2 2.53 78 8.4 18 2 2.6 2.24 3.13 810 10.5 23 2.5 3.2 2.8 6.45 1012 13 29 3 3.95 3.43 12.4 1214 15 35 3.5 4.65 4.04 21.6 1416 17 39 4 5.25 4.58 30.4 1618 19 42 4.5 5.8 5.08 38.9 1820 21 45 5 6.4 5.6 48.8 2022 23 49 5.5 7.05 6.15 63.5 2224 25 56 6 7.75 6.77 92.9 2427 28 60 6.5 8.35 7.3 113 2730 31 70 7 9.2 8 170 30 1）发货状态时最大尺寸2）根据DIN 267第26部分Setzprufung的最小尺寸。

所有DIN标准螺栓•焊接螺栓Weld screws with metric headDIN 34817•方头凸缘螺栓Squate head bolts with collarDIN 478•沉头带榫螺栓Flat countersunk nib boltsDIN 604•沉头高方颈螺栓Flat countersunk square neck bolts with long squareDIN 605•半圆头带榫螺栓Cup head nib boltsDIN 607•沉头短方颈螺栓Flat countersunk square neck bolts with short squareDIN 608•六角花形大法兰面钢制螺栓Steel hexalobular head bolts with large flange DIN 34801•六角头螺栓—全螺纹—产品等级C级Hexagon head screws - Product grade C DIN EN ISO 4018 | 代替DIN 558•六角头螺栓—细牙—全螺纹—产品等级A和B级Hexagon head screws with metric fine pitch thread - Product grade A and BDIN EN ISO 8676 | 代替DIN 961•六角头螺栓—细牙—产品等级A和B级Hexagon head bolts with fine pitch thread - Product grades A and BDIN EN ISO 8765 | 代替DIN 960•钢结构用—大六角头高强度螺栓High-strength hexagon head bolts with large widths across flats for structural steel boltingDIN 6914•六角头铰制孔用螺栓Hexagon fit boltsDIN 609•M42-M160*6 六角头螺栓—产品等级B级M42 to M160*6 hexagon head bolts - Product grade BDIN 931-2•六角法兰面螺栓—小系列Hexagon bolts with flange - Small seriesDIN EN 1662•六角法兰面螺栓—加大系列Hexagon bolts with flange - Heavy seriesDIN EN 1665 | 代替DIN 6921|DIN 6922•六角头螺栓—－产品等级B级－细杆（杆径近似等于中径）Hexagon head bolts with reduced shank(shank diameter=pitch diameter)-Product grade BDIN EN 24015•六角头螺栓—产品等级A和B级Hexagon head bolts - Product grades A and B DIN EN ISO 4014 | 代替DIN 931-1•六角头螺栓—产品等级C级Hexagon head bolts - Product grade CDIN EN ISO 4016 | 代替DIN 601•短螺纹端的六角头铰制孔用螺栓DIN 610-84•粗杆六角头螺栓重量DIN 931-87(3)•T型螺栓188•T型螺栓186•Clevis pinsDIN 1445•Plain washers for metric bolts,screws and nuts .for general purposes General plan DIN EN ISO 887•Hexagon head bolts with metric fine pitch thread(Product grade A and B)DIN EN ISO 8765•Thread run-outs and thread undercuts for ISO metric threads as in IND 13-1 DIN 76-1•Thread run-outs and thread undercutsDIN 76•Bolt end protrusionsDIN 78•Diameters of counterbores(holes)DIN 974•Split pin holes and wire holes in bolts,screws and studsDIN 34803•Bolts,screws,studs and nutsDIN EN 20225•Clearance holes for bolts and screwsDIN EN 20273•T形头螺栓ISO general purpose metric screw threads. General planDIN ISO 261•一般用途螺栓和螺钉.米制系列.端头半径General purpose bolts and screws-metric series DIN ISO 885•活节螺栓Eyelet bolts【DIN444-1983】•【DIN 933】六角头螺栓—全螺纹—产品等级A和B级Hexagon head screws - Product gradeA and BDIN EN ISO 4017 | 代替DIN 933•平圆头方颈螺栓Mushroom head square neck boltsDIN 603螺钉•DIN316-1983 蝶形螺钉Wing screwsDIN316-1983 蝶形螺钉•DIN85-1990 开槽盘头螺钉85-1990•DIN551-1986 开槽平端紧定螺钉Slotted set screws with flat pointDIN551-1986•DIN7505 十字槽圆头塑料牙螺钉DIN7505DIN7505•方头短圆柱端紧定螺钉Square head bolts with short dog pointDIN 479•方头短圆柱球面端紧定螺钉Square head bolts with collar and oval half dog point DIN 480•开槽圆柱头螺钉—产品等级A级Slotted cheese head screws-Product grade A DIN EN ISO 1207 | 代替DIN 84•开槽沉头螺钉（通用头型）－产品等级A级Slotted pan head screws-Product grade A DIN EN ISO 1580 | 代替DIN 85•开槽沉头螺钉（通用头型）－产品等级A级Slotted countersunk flat head screws(common head style)DIN EN ISO 2009 | 代替DIN 963•开槽半沉头螺钉（通用头型）－产品等级A级Countersunk slotted raised head screws(common head style)-Produce grade ADIN EN ISO 2010 | 代替DIN 964•十字槽盘头凸缘螺钉— 产品等级A级Product grade A cross recessed pan head screws with collarDIN 967•十字槽沉头（通用头型）螺钉－产品等级A级－第2部分：性能等级钢8.8级、不锈钢和有色金属Cross recessed countersunk flat head screws (common head style),product gradeA-Part2:Steel of property class 8.8,stainless steel and nonferous metalsDIN EN ISO 7046-2 | 代替DIN 965•开槽十字孔螺钉DIN 404-86•开槽小盘头螺钉DIN 920-86•十字槽沉头自钻自攻螺钉Cross recessed countersunk head drilling screws with tapping screw threadDIN EN ISO 15482•十字槽半沉头自钻自攻螺钉Cross recessed raised countersunk head drilling screws with tapping screw threadDIN EN ISO 15483•十字槽沉头自攻螺钉（通用头型）Cross recessed countersunk (flat) head tapping screws(common head style)ISO 7050 | 代替DIN 7982•钢结构用—大六角头高强度螺栓和六角螺母连接副Steel hexagon fit bolts for structural steel bolting for supply with hexagon nutsDIN 7968•钢结构用—六角头螺栓和六角螺母连接副Steel hexagon head bolts for structural steel bolting for supply with hexagon nutsDIN 7990•小六角头长圆柱导向端紧定螺钉Hexagon set screws with small hexangon and full dog point DIN 561•小六角头短圆柱导向锥端紧定螺钉Hexagon set screws with samll hexagon,half dog point and flat cone pointDIN 564•十字槽半沉头自攻螺钉Cross recessed raised countersunk (oval) head tapping screws ISO 7051 | 代替DIN 7983•DIN910-1992 六角头螺塞DIN910-1992•十字槽半沉头（通用头型）螺钉－产品等级A级Countersunk raised head screws (common head style) with type H or type Z cross recess-Product grade ADIN EN ISO 7047 | 代替DIN 966•十字槽圆柱头螺钉Cross recessed cheese head screwsDIN EN ISO 7048•滚花指旋螺钉DIN 464-86•滚花薄头指旋螺钉DIN 653-80•带螺杆的六角头螺钉DIN 7964-77•开槽大盘头螺钉DIN 921-86•Designation system for fastenersDIN 962•Plastic washers. Standard seriesDIN 34815•Slotted set screws with flat pointDIN EN 24766•Slotted set screws with cone pointDIN EN 27434•Slotted set screws with long dog pointDIN EN 27435•Slotted set screws with cup pointDIN EN 27436•Slotted cheese head screwsDIN EN ISO 1207•Slotted pan head screwsDIN EN ISO 1580•Slotted countersunk flat head screws (common head style) DIN EN ISO 2009•Countersunk slotted raised head screws(common head style) DIN EN ISO 2010•Slotted headless screws with shandDIN EN ISO 2342•Hexagon head screws(Product grade A and B)DIN EN ISO 4017•Hexagon head screws(Product grade C)DIN EN ISO 4018•Hexagon socket set screws with flat pointDIN EN ISO 4026•Hexagon socket set screws with cone pointDIN EN ISO 4027•Hexagon socket set screws with dog pointDIN EN ISO 4028•Hexagon socket set screws with cup pointDIN EN ISO 4029•Hexagon socket head cap screwsDIN EN ISO 4762•Pan head screws with H or type Z cross recess(Product grade A)DIN EN ISO 7045•Countersunk flat head screws(common head style)with type H or type Z cross recess(Product grade A)DIN EN ISO 7046-1•Countersunk flat head screws(common head style)with type H or type Z cross recess(Product grade A)DIN EN ISO 7047•Countersunk flat head screwsDIN EN ISO 7048•Hexagon socket button head screwsDIN EN ISO 7380•Hexagon head screws with metric fine pitch thread(Product grade A and B) DIN EN ISO 8676•Tapping screw and washer assemblies with plain washersDIN EN ISO 10510•Hexagon socket countersunk head screwsDIN EN ISO 10642•Hexalobular socket head cap screwsDIN EN ISO 14579•Hexalobular socket cheese head screwsDIN EN ISO 14580•Hexalobular socket pan head screwsDIN EN ISO 14583•Hexalobular socket raised countersunk head screwsDIN EN ISO 14584•Scres and washer assemblies with plain washers(Washer hardness classes 200 HV and 300 HV)DIN EN ISO 10644•Hexalobular socket pan head tapping screwsDIN EN ISO 14585•Hexalobular socket countersunk headDIN EN ISO 14586•Hexalobular socket raised countersunk(oval)head tapping screwsDIN EN ISO 14587•Hexagon washer head drilling screws with tapping screw threadDIN EN ISO 15480•Cross recessed pan head drilling screws with tapping screw threadDIN EN ISO 15481•Cross recessed countersunk head drilling screws with tapping screw thread DIN EN ISO 15482•Cross recessed raisedcountersunk head drilling screws with tapping screw thread DIN EN ISO 15483•Countersinks. For countersunk head screwsDIN 66•Countersinks. For countersunk head screwsDIN 74•Screw threadsDIN 202•Thread rolling screwsDIN 7500•Tapping screw connectionsDIN 7975•Threads and thread endsDIN 7998•Wire thread inserts for ISO metric screw threadsDIN 8140-1•Countersunk head screwsDIN EN 27721•Tapping screw threadsDIN EN ISO 1478•十字槽螺丝Cross recesses for screwsDIN EN ISO 4757•螺栓和螺钉用内板拧的六角花形Hexalobular internal driving feature for bolts and screws DIN EN ISO 10664•十字槽沉头螺钉ISO general purpose metric screw threads-tolerances DIN ISO 965•十字槽球面圆柱头螺钉DIN 7985-86•开槽盘头螺钉DIN 85-72•十字槽圆头螺钉Cross recessed round head screwsDIN 7996•内六角紧定螺钉—平端Hexagon socket set screws with flat pointDin 913•内六角紧定螺钉—截锥端Hexagon socket set screws with cone point Din 914•内六角紧定螺钉—导向圆柱端Hexagon socket set screws with dog point Din 915•内六角紧定螺钉—凹端Hexagon socket set screws with cup pointDin 916•十字槽沉头螺钉ISO general purpose metric screw threads-tolerancesDIN ISO 965-2•十字槽沉头螺钉ISO general purpose metric screw threads-tolerancesDIN ISO 965-3•十字槽沉头螺钉ISO general purpose metric screw threads-tolerancesDIN ISO 965-4•十字槽沉头螺钉ISO general purpose metric screw threads-tolerancesDIN ISO 965-5内六角螺钉•【DIN 7991】内六角沉头螺钉Hexagon socket countersunk head screws DIN EN ISO 10642 | 代替DIN 7991•薄圆柱头内六角螺钉Hexagon socket thin head cap screwsDIN 7984•薄圆柱头内六角螺钉Hexagon socket thin head cap screws with pilot recess for wrench key DIN 6912•六角花形小法兰面钢制螺栓Steel hexalobular head bolts with small flange DIN 34800•内六角喉塞Hexagon socket pipe plugs,steelDIN 906•内六角平圆头螺钉Hexagon socket button head screwsDIN EN ISO 7380•内六角圆柱头螺钉socket head cap screws,stellDin 912 | 代替Din 912•圆柱头内六角花形钢制螺钉Steel hexalobular head cap screws with large driving feature DIN 34802•圆柱头内六角螺钉Hexagon socket head cap screwsDIN EN ISO 4762 | 代替DIN 912自攻螺钉•十字槽盘头自钻自攻螺钉Cross recessed pan head drlling screws with tapping screw thread DIN EN ISO 15481 | 代替DIN 7504•十字槽沉头自钻自攻螺钉Cross recessed countersunk head drilling screws with tapping screw threadDIN EN ISO 15482 | 代替DIN 7504•十字槽半沉头自钻自攻螺钉Cross recessed raised counterunk head drilling screws with tapping screw threadDIN EN ISO 15483 | 代替DIN 7504•自钻自攻螺钉Drilling screws with tapping screw threadDIN EN ISO 10666 | 代替DIN 7504•六角头和开槽头三角牙螺钉—尺寸、技术要求及试验Hexagon head and slotted head thread cutting screws - Dimensions,requirements and testingDIN 7513•十字槽螺纹滚成自攻螺钉—尺寸、技术要求及试验Cross recessed head thread cutting screws -Dimensions,requirements and testingDIN 7516•米制螺纹滚成自攻螺钉—型式、名称及技术要求ISO metric thread rolling screws -Types,designation and requirementsDIN 7500-1•米制螺纹滚成自攻螺钉—预制孔直径尺寸方案Tread rolling screws for ISO metric thread -Guideline values for hole diametersDIN 7500-2•紧固件供货技术条件—米制螺纹—性能等级为10.9级的螺纹滚成自攻螺钉Technical delivery conditions for fasteners - Metric thread rolling screws of property class 10.9DIN 267-30•十字槽盘头凸缘自攻螺钉Cross recessed pan head tapping screws with collar DIN 968•六角凸缘自攻螺钉Hexagon washer head tapping screwsDIN 6928•自攻螺钉用螺纹Tapping screw threadsDIN EN ISO 1478 | 代替DIN 7970•六角头自攻螺钉Hexagon head tapping screwsISO 1479 | 代替DIN 7976•开槽盘头自攻螺钉Slotted pan head tapping screwsISO 1481 | 代替DIN 7971•开槽沉头自攻螺钉（通用头型）Slotted countersunk(flat)head tapping screws(common head style)ISO 1482 | 代替DIN 7972•开槽半沉头自攻螺钉（通用头型）Slotted raised countersunk (oval) head tapping screws(common head style)ISO 1483 | 代替DIN 7973•十字槽盘头自攻螺钉Cross recessed pan head tapping screwsISO 7049 | 代替DIN 7981•六角凸缘头自钻自攻螺钉Hexagon washer head drilling screws with tapping screws thread DIN EN ISO 15480•十字槽盘头自钻自攻螺钉Cross recessed pan head drilling screws with tapping screw thread DIN EN ISO 15481•六角头自钻自攻螺钉Hexagon washer head drilling screws with tapping screw thread DIN EN ISO 15480 | 代替DIN 7504木螺钉•开槽半沉头木螺钉Slotted raised countersunk(oval) head wood screwsDin 95•开槽半圆头木螺钉Slotted round head wood screwsDin 96•开槽沉头木螺钉Slotted countersunk(flat) head wood screwsDin 97•六角头木螺钉Hexagon wood screwsDin 571•十字沉头木螺钉Cross recessed countersunk (flat) head wood screwsDIN 7997螺杆和螺柱•螺杆—过盈配合螺纹Metric interference-fit thread stud bolts DIN 976-2•Welding studs for turnbucklesDIN 34828•High-strength structural bolting assemblies. For preloading DIN EN 14399-3•High-strength structural bolting assemblies. For preloading DIN EN 14399-4•Hexagon bolts with flange-Small seriesDIN EN 1662•Hexagon bolts with flange-Heavy seriesDIN EN 1665•Hexagon bolts with flange with metric fine pitch thread DIN EN 14219•High-strength structural bolting assemblies for preloading DIN EN 14399-3•High-strength structural bolting assemblies for preloading DIN EN 14399-4•Hexagon head bolts with reduced shankDIN EN 24015•Hexagon head bolts(Product grade A and B)DIN EN ISO 4014•Hexagon head bolts(Product grade C)DIN EN ISO 4016•螺杆Metric thread stud boltsDIN 976-1•牙条Threaded rodDIN 975铆钉•沉头实心铆钉德标DIN302-1993 DIN302-1993DIN302-1993•半圆头钢铆钉—公称直径10~36mm Steel round head rivets with nominal diameters from 10 to36 mmDIN 124•沉头钢铆钉—公称直径10~36mm Steel countersunk head rivets with nominal diameters from10 to 36 mmDIN 302•半圆头铆钉—公称直径1~8mm Round head rivets with nominal diameters from 1 to 8 mm DIN 660•沉头铆钉—公称直径1~8mm Countersunk head rivets with nominal diameters from 1 to 8 mm DIN 661•半沉头铆钉—公称直径1.6~6mm Oval-head rivets with nominal diameters from 1,6 to 6 mm DIN 662•大半圆头铆钉—公称直径1.6~6mm Mushroom head rivets with nominal diameters from 1,6 to 6 mmDIN 674•沉头铆钉—公称直径3~5mm Flat countersunk head rivets with nominal diameters from 3 to 5 mmDIN 675•铆钉用具Rivet setsDIN 6434•盘头半空心铆钉—公称直径1.6~10mm Semitubular pan head rives with nominal diameters from 1,6 to 10 mmDIN 6791•沉头半空心铆钉—公称直径1.6~10mm Semitubular countersunk head rivets with nominal diameters from 1,6 to 10 mmDIN 6792•冲制铆钉Compression rivetsDIN 7331•开口型盲铆钉Break mandrel blind rivetsDIN 7337•开口型和封闭型铆钉Break and clutch lining rivetsDIN 7338•板料拉延管铆钉One-piece tubular rivets drawn from strip DIN 7339•管制空心铆钉Tubular rivets made from tubeDIN 7340•Steel round head rivetsDIN 124•Round head rivetsDIN 660•Countersunk head rivetsDIN 661•Oval-head rivetsDIN 662•Mushroom head rivetsDIN 674•Flat countersunk head rivetsDIN 675•Semitubular pan head rivets. With nominal diameters from 1,6 to 10mm DIN 6791•Compression rivetsDIN 7331•Brake and clutch lining rivetsDIN 7338•One-piece tubular rivetsDIN 7339•Tubular rivetsDIN 7340•Rivet pinsDIN 7341•Grooved pins with countersunk headDIN EN ISO 8747•沉头锥端铆钉德标DIN675-1993 DIN675-1993DIN675-1993螺母•DIN6334 六角长螺母hexagon long nutsDIN6334•非金属嵌件六角法兰面锁紧螺母Prevailing torque type hexagon nuts with flange(with non-metallic insert)DIN EN 1663 | 代替DIN 6926•非金属嵌件六角锁紧薄螺母Prevailing torque type hexagon thin nuts (with non-metallic insert ) DIN EN ISO 10511 | 代替DIN 985•吊环螺母Adjusting rings,steelDIN705•德制六角薄螺母HEXAGON NUTS UNIDin 5587•薄型方螺母—产品等级B级Square thin nuts - Product grade BDIN 562•六角薄螺母（倒角型）—产品等级A和B级Hexagon thin nuts(chamfered)-Product grade A and BDIN EN ISO 4035 | 代替DIN 439-2•六角薄螺母（无倒角型）—产品等级B级Hexagon thin nuts - Product grade B(unchamfered) DIN EN ISO 4036 | 代替DIN 439-1•1型六角螺母—细牙螺纹—产品等级A和B级Hexagon nuts,style 1,with metric fine pitch thread - Product grades A and BDIN EN ISO 8673 | 代替DIN 934|DIN 971-1•2型六角螺母—细牙螺纹—产品等级A和B级Hexagon nuts,style 2,with metric fine pitch thread - Product grades A and BDIN EN ISO 8674 | 代替DIN 971-2•六角薄螺母—细牙螺纹—产品等级A和B级Hexagon thin nuts with metric fine pitch thread -Product grades A and BDIN EN ISO 8675 | 代替DIN 439-2•六角开槽螺母—粗牙螺纹和细牙螺纹—产品等级A和B级Hexagon slotted nuts and caltle nuts with metric coarse and fine pitch thread - Product grades A and BDIN 935-1•六角开槽螺母—产品等级C级Hexagon slotted nuts with metric coarse pitch thread - Product grade CDIN 935-3•六角开槽薄螺母—产品等级A和B级Hexagon thin slotted nuts and castle nuts with metric coarse and fine pitch thread - Product grade A and BDIN 979•六角盖形螺母—扁球型Hexagon cap nutsDIN 917•六角盖形螺母—半圆球型Hexagon domed cap nutsDIN 1587•非金属嵌件六角组合式盖形锁紧螺母Prevailing torque hexagon domed cap nuts with non-metallic insertDIN 986•1型全金属六角锁紧螺母—性能等级5、8和10级Prevailing torque type all-metal hexagon nuts,style 1- Property classes 5,8 and 10DIN EN ISO 7719•开槽螺塞(螺纹塞）Screwed inserts(screw plugs)DIN 7965•冲压自锁螺母Self-locking counter nutsDIN 7967•三角凸缘螺母—矿山用防雷防爆电气设备用Triangular nuts for use with electrical equipment in miningDIN 22425•小对边薄螺母—粗牙和细牙Thin nuts with coarse pitch and fine pitch thread and with small widths across flatsDIN 80705•钢结构用—大六角螺母Steel hexagon nuts with large widths across flats for high - strength structural boltingDIN 6915•塑料六角螺母Plastic hexagon nutsDIN 34814•2型六角螺母—产品等级A和B级Hexagon nuts,style 2-Product grades A and B DIN EN ISO 4033•六角螺母—产品等级C级Hexagon nuts - Product grade CDIN EN ISO 4034 | 代替DIN 555•全金属六角法兰面锁紧螺母Prevailing torque type all-metal hexagon nuts with flange DIN EN 1664 | 代替DIN 6927•非金属嵌件六角法兰面锁紧螺母－细牙Prevailing torque type hexagon nuts with flange(with non-metallic insert)with metric fine pitch threadDIN EN 1666 | 代替DIN 6926•全金属六角法兰面锁紧螺母－细牙Prevailing torque type all-metal hexagon nuts with flange with metric fine pitch threadDIN EN 1667 | 代替DIN 6927•1型非金属嵌件六角锁紧螺母—性能等级5、8和10级Prevailing torque type hexagon nuts (with non-metallic insert),style 1 - Property classes 5,8 and 10DIN EN ISO 7040 | 代替DIN 982|DIN 6924•2型全金属六角锁紧螺母—性能等级5、8、10和12级Prevailing torque type all-metal hexagon nuts,style 2 - Property classes 5,8, 10 and 12DIN EN ISO 7042 | 代替DIN 980|DIN 6925•1型非金属嵌件六角锁紧螺母—细牙—性能等级6、8和10级Prevailing torque type hexagon nuts (with non-metallic insert),style 1,with metric fine pitch thread-Property classes 6,8 and 10 DIN EN ISO 10512 | 代替DIN 982|DIN 6924•2型全金属六角锁紧螺母—细牙—性能等级8、10和12级Prevailing torque type all-metal hexagon nuts,style 2,with metric fine pitch thread - Property classes 8,10 and 12DIN EN ISO 10513 | 代替DIN 980|DIN 6925•焊接方螺母Square weld nutsDIN 928•焊接六角螺母Hexagon weld nutsDIN 929•焊接六角法兰面螺母Hexagon weld nuts with flangeDIN 977•圆头滚花螺母Knurled nuts with collarDIN 466•圆头滚花薄螺母Knurled nutsDIN 467•厚圆头滚花螺母Knurled nutsDIN 6303•蝶形螺母—方翼Wing nuts with edged wingsDIN 314•蝶形螺母—圆翼Wing nuts with rounded wingsDIN 315•管螺母—螺纹符合ISO 228-1 Pipe nuts with thread as in ISO 228-1DIN 431•圆螺母—端面开槽Slotted round nutsDIN 546•圆螺母—端面带孔Round nuts with drilled holes in one faceDIN 547•圆螺母—恻面带孔Round nuts with set pin holes in sideDIN 548•吊耳螺母Lifting eye nutsDIN 582•圆型套筒螺母—钢制Turnbuckles made from steel tube or round steel bars DIN 1478•六角套筒螺母Hexagon turnbucklesDIN 1479•套筒螺母—组合开启型Turnbuckles,forged（open type)DIN 1480•六角螺母—腰状杆螺栓连接副用Hexagon nuts for use with bolts with waisted shank DIN 2510-5•罩螺母—腰状杆螺栓连接副用Cap nuts for use with bolts with waisted shank DIN 2510-6•受力管套—腰状杆螺栓连接副用Sleeves for use with bolts with waisted shank DIN 2510-7•六角螺母—m=1.5d Hexagon nuts with a height of 1,5dDIN 6330•六角凸缘螺母—m=1.5d Hexagon collar nuts with a height of 1,5dDIN 6331•专用地脚螺钉用地脚螺母DIN 798-1972•六角薄螺母（老标准）（产品等级A和B级）DIN 936-1985•六角冕形薄螺母（原类型）DIN 937-1987•六角开槽薄螺母和六角冕形薄螺母米制粗牙和细牙产品等级A和B级DIN 979-1987•汽车和拖车用圆盘轮螺母螺柱定心用紧固件DIN 74361-1982 第2部分•载重汽车和拖挂车的圆盘轮外部件紧固件DIN 74361-1979 第3部分•非钎焊和钎焊压合接头.管接螺母系列LL Non-soldering and soldering compression fittings -Union nuts series LL3870-2001 | 代替DIN 3870-1985;DIN 3870-19•Wing nuts with edged wingsDIN 314•Pipe nuts with thread as in ISO 228-1DIN 431•Knurled nuts with collarDIN 466•Short knurled nutsDIN 467•Slotted round nutsDIN 546•Round nuts with drilled holes in one faceDIN 547•Round nuts with set pin holes in sideDIN 548•Product grade C square nutsDIN 557•Square thin nutsDIN 562•Eyenuts for lifting purposesDIN 582•Hexagon cap nutsDIN 917•Overview of European Standards for fastenersDIN 918•Square weld nutsDIN 928•Hexagon weld nutsDIN 929•Hexagon slotted nuts and castle nuts with metric coarse and fine pitch thread(Product grade A and B)DIN 935-1•Hexagon slotted nuts with metric coarse pitch thread(Product grade C)DIN 935-3•Hexagon thin slotted nuts and castle nuts with metric coarse and fine pitch thread(Product grade A and B)DIN 979•Prevailing torque type hexagon domed cap nuts with non-metallic insertDIN 986•Hexagon domed cap nutsDIN 1587•Boloted connections with reduced shank hexagon nutsDIN 2510•Knurled nutsDIN 6303•Hexagon nuts with a height of 1,5 dDIN 6330•Hexagon nuts with collar,with a height of 1,5 dDIN 6331•Plastic hexagon nutsDIN 34814•Plastic washers. large seriesDIN 34816•Thin nuts with coarse pitch and fine pitch thread and with small widths across flats DIN 80705•Hexagon nuts with flangeDIN EN 1661•Prevailing torque type hexagon nuts with flange(with non-metallic insert)DIN EN 1663•Prevailing torque type all-metal hexagon nuts with flangeDIN EN 1664•Prevailing torque type hexagon nuts with flange(with non-metallic insert),with metric fine pitch threadDIN EN 1666•Prevailing torque type all-metal hexagon nuts with flange,with metric fine pitch thread DIN EN 1667•Hexagon nuts with flange. Fine pitch threadDIN EN 14218•Hexagon nuts,style 1(Product grades A and B)DIN EN ISO 4032•Hexagon nuts,style 2(Product grades A and B)DIN EN ISO 4033•Hexagon nuts(Product grades C)DIN EN ISO 4034•Hexagon thin nuts(chamfered)(Product grades A and B)DIN EN ISO 4035•Hexagon thin nuts(unchamfered)(Product grades B)DIN EN ISO 4036•Tolerances for fastenersDIN EN ISO 4759•Prevailing torque type hexagon nuts(with non-metallicinsert),style 1 Property classes5,8 and 10DIN EN ISO 7040•Prevailing torque type hexagon nuts(with non-metallicinsert),style 2 -Property classes 5,8,10 and 12DIN EN ISO 7042•Hexagon nuts,style 1,with metric fine pitch thread (Product grades B)DIN EN ISO 8673•Hexagon nuts,style 2,with metric fine pitch thread (Product grades A and B) DIN EN ISO 8674•Prevailing torque type hexagon thin nuts(with non-metallic insert)DIN EN ISO 10511•Prevailing torque type all-metal hexagon nuts,style 1 Property classes 5,8 and 10 DIN EN ISO 7719•Hexagon thin nuts (chamfered)with metric fine pitch thread(Product grades A and B) DIN EN ISO 8675•Prevailing torque type hexagon nuts(with non-metallic insert),style 1,with metric fine pitch thread-Property classes6,8 and 10DIN EN ISO 10512•Prevailing torque type all-metal hexagon nuts,style 2,with metric fine pitch thread-Property classes8,10 and 12DIN EN ISO 10513•Hexagon weld nuts with flangeDIN EN ISO 21670•Bolted connections with reduced shankDIN 2510•方螺母—产品等级C级Product grade C square nutsDIN 557•六角法兰面螺母Hexagon nuts with flangeDIN EN 1661 | 代替DIN 6923•【DIN 934】1型六角螺母—产品等级A和B级Hexagon nuts,style 1-Product grades A and B DIN EN ISO 4032 | 代替DIN 934垫圈•球面垫圈德标DIN6319C Spherical washers,steel case hardenedDIN6319C•DIN6319D-锥面垫圈conical seats,steel case hardenedDIN6319D-•DIN 7980 圆柱头螺栓用弹簧垫圈Spring lock washers with square ends for cheese head screwsDIN 7980•DIN2093 蝶形弹簧垫圈德标Wing spring washersDIN2093•单耳止动垫圈德标DIN93-1974 DIN93-1974DIN93-1974•弹簧垫圈(DIN 127) Helical spring lock washers,sprint steel127•十字槽盘头螺钉—产品等级A级Pan head screws with type H or type Z cross recess-Product grade ADIN EN ISO 7045 | 代替DIN 7985•十字槽沉头（通用头型）螺钉－产品等级A级－第1部分：性能等级钢4.8级Countersunk flat head screws (common head style)with type H or type Z cross recess,product grade A-Part 1:Steel of property class 4.8DIN EN ISO 7046-1 | 代替DIN 965•钢制的，普通系列平垫圈Flat Washers, steel normal series【Din 125B】| 代替7090•钢制的，普通系列平垫圈Flat Washers, steel normal series【Din 125A】•小垫圈samll seriesDin 433 | 代替Din 433•方垫圈—木结构用Square washers for use in timber constructionsDIN 436•方孔方垫圈—木结构用Washers with square hole for use in timber constructions DIN 440•粗制平垫圈—螺栓用Washers,coarse type,or boltsDIN 1441•精制平垫圈Washers for clamping devicesDIN 6340•平垫圈—带重型夹紧套螺栓用Plain washers for bolts with heavy clamping sleeves DIN 7349•塑料垫圈—标准系列Plastic washers-Standard seriesDIN 34815•塑料垫圈—大系列Plastic washers-Large seriesDIN 34816•销轴用平垫圈—产品等级A级Plain washers for use with clevis pins-Product grade A DIN EN 28738 | 代替DIN 1440•平垫圈—标准系列—产品等级A级Plain washers-Normal series-Product grade A DIN EN ISO 7089•平垫圈—倒角型—标准系列—产品等级A级Plain washers,chamfered-Normal series-Product grade ADIN EN ISO 7090•平垫圈—标准系列—产品等级C级Plain washers-Normal series-Product grade C DIN EN ISO 7091•平垫圈—小系列—产品等级A级Plain washers-Small series-Product grade A DIN EN ISO 7092•平垫圈—大系列—第一部分：产品等级A级Plain washers-Large series-Part 1: Product grade A DIN EN ISO 7093-1•平垫圈—标准系列—第3部分：产品等级C级Plain washers-Normal series-Part 3: Product grade CDIN EN ISO 7093-2•平垫圈—特大系列—产品等级C级Plain washers-Extra large series -Product grade C DIN EN ISO 7094•长单耳止动垫片Tab washers with long tabDIN 93•螺钉和垫圈组合件用外锯齿锁紧垫圈Serrated lock washers with extermal teeth for screw and washer assembliesDIN 6907•螺钉和垫圈组合件用锥形弹性垫圈Conical sring washers for screw and washer assemblies DIN 6908•自攻螺钉和垫圈组合件用平垫圈—标准系列和大系列—产品等级A级Plain washers for tapping screw and washer assemblies - Normal and large series - Product grade ADIN EN ISO 10669•螺钉和垫圈组合件用平垫圈—小系列、标准系列及大系列—产品等级A级Plain washers for screw and washer assemblies - Small,normal and large series - Product grade ADIN EN ISO 10673•槽钢用方斜垫圈Square taper washers for use with channel sectionsDIN 434•I型工字钢用方斜垫圈Square taper washers for use with I sectionsDIN 435•钢结构高强度螺栓连接—圆垫圈Round washers for high-strength structural steel bolting DIN 6916•钢结构高强度螺栓连接—I型工字钢用方斜垫圈Square taper washers for high-strength structural bolting of steel I sectionsDIN 6917•钢结构高强度螺栓连接—槽钢用方斜垫圈Square taper washers for high-strength structural bolting of steel channel sectionsDIN 6918•钢结构用垫圈—产品等级C级Washers for use in structural steelwork - Product grade C DIN7989-1•钢结构用垫圈—产品等级A级Washers for use in structural steelwork - Product grade A DIN7989-2•波形弹性垫圈Wave spring washersDIN 137•外舌止动垫片External tab washers(locking tab washers)DIN 432•双耳止动垫片Tab washers with short and long tab at right anglesDIN 463•安全杯—DIN84开槽圆柱头螺钉用Safety cups for cheese head screws according to DIN 84 DIN 526•密封垫圈Shim rings and supporting ringsDIN 988•螺栓、螺母组合件用锥形弹性垫圈Conical spring washers for bolt/nut assemblies DIN 6796•锯齿锁紧弹性垫圈Toothed lock washersDIN 6797•外锯齿锁紧垫圈Serrated lock washersDIN 6798•螺钉和垫圈组合件用波形弹性垫圈Curved spring washers for screw and washer assemblies DIN 6904•螺钉和垫圈组合件用弹簧垫圈Spring lock washers for screw and washer assemblies DIN 6905•密封垫圈Shim rings and supporting ringsDIN 988•平垫圈—重型螺栓用Plain washers for bolts with heavy clamping sleeves DIN 7349•垫圈Flat washers stellDin 126•平垫圈Flat washer,stainless stellDIN 9021 | 代替DIN 9021•Shim rings and supporting ringsDIN 988•Plain washers. For bolts with heavy clamping sleevesDIN 7349•Blind rivetsDIN EN ISO 14589•Square taper steel washers for use with channel sectionsDIN 434•Square taper steel washers for use with I sectionsDIN 435•Square washersDIN 436•Washers with square hole for use in timber constructionsDIN 440•Shim rings and supporting ringsDIN 988•Washers type coarse for boltsDIN 1441•Washers for clamping devicesDIN 6340•Conical spring washers. for bolt/nut assembliesDIN 6796•Conical spring washersDIN 6908•Square taper washers. For high-strength structural bolting of steel | sections DIN 6917•Square taper washers. For high-strength structural bolting of steel channel sections DIN 6918•Plain washers. For Bolts with Heavy Clamping SleevesDIN 7349•Washers for use in structural steelwork(Product grade C)DIN 7989-1•Washers for use in structural steelwork(Product grade A)DIN 7989-2•Chamfered plain washers for use in structural steelworkDIN 34820•High-strength structural bolting assemblies. For preloadingDIN EN 14399-5•High-strength structural bolting assemblies. For preloadingDIN EN 14399-6•Plain washers-Normal series(Product grades A)DIN EN ISO 7089•Plain washers,chamfered-Normal series(Product grades A)DIN EN ISO 7090。

《英科宇三维CAD图库》简介北京英科宇科技开发中心是面向制造业信息化软件研究、开发、应用的专业软件公司,北京市科委认定的软件企业.在十几年的历程中，公司开发出机械、电气、建筑、化工四大领域的软件产品，并为多家知名企业提供了专业软件开发服务.英科宇软件在机械、电气、建筑、化工等行业内享有非常高的知名度，其产品性能和市场占有率已遥遥领先于国内同类产品，用户不但遍及全国三十个省市自治区，而且还远播到世界各地。

在机械领域的设计工作中,广大工程技术人员经常采用生产厂家的标准零部件，他们迫切希望软件企业能够提供内容全、专业细的三维CAD图库，以减少重复劳动，提高绘图效率。

为此，我公司以机械设计手册为基础，参考了相关手册、最新国家标准和行业标准，采用先进的软件技术，推出了基于UG和Pro/E软件的《英科宇三维CAD图库》系列软件。

《英科宇三维CAD图库》按专业分类,分为联接与紧固、轴承、型材、管件与管接头、联轴器、电机、减速器、气缸与液压缸、阀门、弹簧、操作件、密封件、传动件(齿轮、链轮、带轮）、机床夹具、机床刀具、塑料模具、冲压模具、法兰、人孔和手孔等。

本软件是《英科宇三维CAD图库》中的联接与紧固卷，涉及的资料有：螺母、螺栓、螺柱、螺钉、垫圈、挡圈、键、销、铆钉等。

《英科宇三维CAD图库》遵循机械行业的设计习惯，自备强大的专业数据库，具有开放结构,采用中文界面,各项功能完备齐全，在机械设计方面具有很高的专业水准。

相信它一定会给您的设计工作带来巨大的帮助。

《英科宇三维CAD图库》运行于简体中文WindowsXP/WIN7操作系统，UGNX6.0或Pro/E3。

0以上版本支持,大于500MB硬盘空间，CD—ROM驱动器.北京英科宇科技开发中心地址:北京市丰台区西四环南路46号国润商务大厦2509室邮政编码：100073传真：010—电话：010—63839E-mail:yingkeyu＠图库标准件列表：GB/T39-1988 方螺母C级GB/T41—2000 六角螺母C级GB/T56-1988 六角厚螺母GB/T804—1988 球面六角螺母GB/T805-1988 扣紧螺母GB/T808-1988 小六角特扁细牙螺母GB/T889。

D I N6796碟形弹簧垫圈DIN 6796碟形弹簧垫圈DIN 6796 是一种用于螺栓和螺钉连接的防松垫圈，我们习惯称之为碟形弹性垫圈或锥形弹性垫圈，主要用于中等或高强度螺栓、螺钉的连接如CL8.8/10.9级，可以有效地取代普通弹簧垫圈。

碟形弹性垫圈原理：DIN6796碟形弹性垫圈是一种锥形结构垫圈，在于螺栓、螺母连接副装配时，受轴向载荷，产生形变储存轴向张力势能，当螺母或螺栓出现松动时，垫圈回弹释放势能起到防松作用。

可见DIN6796设计原理是为了消除螺栓螺母在装配时出现松脱的不良影响，从而起到锁紧作用。

锥形弹性垫圈适用于受轴向载荷的螺栓螺母连接副。

下图所示为DIN6796(MZP)规格以及实物图,常见材料和规格常见材质主要有：1）弹簧钢 2）不锈钢 A2和A4规格涵盖：M2-M30弹簧钢表面处理：DIN6796主要以GEO等非电解锌片涂层和机械镀锌为主。

另外由于DIN6796材质为高硬度弹簧钢，为避免其出现氢脆的，不建议使用且也不能提供镀锌处理。

关于垫圈的防腐性能主要视涂层厚度、储藏环境和使用环境而言，但是涂层的附着性视运输情况。

一般情况下，机械镀锌的涂层附着性相对较好。

如有特殊的具体要求可电话咨询。

DIN 6796的技术要求：参照DIN 267-26标准规定。

主要有两个，硬度和回弹。

（此两项性能要求只针对碳钢材质产品）硬度要求为：420HV-510HV关于回弹主要考量永久载荷和剩余回弹力两方面：永久载荷试验中根据标准规定的条件，要求垫圈不应有裂纹和断裂，见下表，压力释放后的自由高度不应超过下表规定数值的2%DIN 6796与DIN 2093的区别有些人认为DIN 6796就是德标的碟簧，这种说法是错误的，DIN 6796实质上就是一种防松垫圈。

下面就这两者的区别进行说明：1）制定单位不同：DIN 2093是德国工业标准弹簧委员会AF制定；DIN 6796是德国工业标准紧固件委员会FMV制定。
