台湾飞特气动工具产品参数说明
尊敬的客户:
您好!
台湾飞特气动工具产品相关参数说明如下:
一、扭矩值
①FW-4SR-1为飞特冲击式气动扳手,正常拧紧螺丝的时间在5秒钟以内时,扭矩范围为8-16N.m。
超过5秒钟后扭矩值会加大。
②FW-4SRD-1、D-10为飞特冲击式气动起子,正常拧紧螺丝的时间在5秒钟以内时,扭矩范围为6-13N.m。
超过5秒钟后扭矩值会加大。
③FW-60SR-1为飞特双气缸油浴式气动扳手,正常拧紧螺丝的时间在5秒钟以内时,扭矩范围为14-26N.m。
超过5秒钟后扭矩值会加大。
④FW-60SRD-1、D-10为飞特双气缸油浴式气动起子,正常拧紧螺丝的时间在5秒钟以内时,扭矩范围为11-20N.m。
超过5秒钟后扭矩值会加大。
二、噪音值
在噪音测量方面,我们遵照ISO15744的标准,噪音值为85分贝,测量等级可增加3dB(A)用以消除生产和测量方法上的偏差。
绝大多数数值均依照Pneurop测试标准得出。
自2002年开始,针对声音测量的官方测试标准更改为ISO15744。
这两个标准之间的区别甚小,在多数情况下可以忽略不计。
在表述上,我们声明噪音级别低,我们是指与性价比不高的类似产品相比较。
在很多实际工位中,生产过程的噪音要远远高于工具无负载时的噪声,因此,通常建议操作者在使用时佩戴听力保护用具。
上海芊华机械有限公司。
