在有限元分析中的非弹性响应模型中,通过分离变形到恢复(弹性)和不可恢复的(非弹性)来区分弹性和非弹性的反应。

这种分离是基于假设有一种应变率之间的附加的关系:是总应变率，是弹性应变的变化率，是非弹性应变的变化率。

一个更一般的假设是总变形，，是由非弹性变形和纯粹的弹性变形组成的(伴随着加在任何阶段流程中的刚体旋转):在《附加应变率分解》章节1.4.4,方程4.1.1-1和 4.1.1-2是近似方程。

我们认为,如果1.方程4.1.1-1中使用的总应变速率是测量变形的速率:是速度，是当前空间质点的位置；2.弹性压力很小。

并且这种近似是一致的。

有限元分析使用变形率作为在限制变形问题中测量应变率的原因。

(只有当压力忽略不计时，不同的应变测量之间的区别很重要,也就是限制变形问题。

)实际中许多材料的弹性压力始终保持很小，例如,一个金属的屈服应力通常是小于它的弹性模量三个数量级,这意味着弹性应变应乘以。

然而,一些材料(例如，聚合物)也可以接受大的弹性应变并且伸缩自如,在这种情况下,附加应变率分解不再是一个近似值。

有限元分析提供了各种弹性响应模型。

其中最简单的是线性弹性:是可能取决于温度的一个矩阵,但并不依赖于变形(除非这种依赖是由损伤模型引入的)。

这种弹性模型用于小变形问题或模拟在弹性压力总是小的弹塑性模型中的弹性。

一个扩展的弹性行为的类型是次弹性模型:可能取决于变形的地方。

在这种情况下,弹性可能不再是非线性,但有限元分析仍然基于假设弹性压力总是很小。

在多孔和散体介质,弹性性质主要依赖于体积应变;多孔介质的弹性行为在《多孔弹性》的4.1.1节中讲解。

最通用的一种非线性弹性行为是超弹性的模型,我们定义假设有一个的由压力产生U为潜在的能量密度。

和是共轭应力和应变措施。

这种形式的弹性模型一般用来模拟弹性体:长期反应是完全可恢复的(弹性)的大变形材料。

有限元分析中提供的超弹性建模在《大应变超弹性平面分析程序》章节4.6中叙述过。
