择CPU再选择其他的配件，当然这也没什么不对。

只是选择了CPU就应该选择与之相适应的主板，而其余的配件就必须与主板相配套，那么了解主板芯片组的特性就显得非常重要了。

本文的目的就是让那些购机、升级的菜鸟朋友们了解芯片组特性，再根据自己的需求确定主板，之后，有方向地去选择内存、显卡、硬盘等主要配件。

Intel芯片组：一、845系列芯片组包括：支持SDRAM的845芯片组、支持DDR266的845D芯片组、支持DDR266以及FSB533的845E/G/GL芯片组、支持DDR333以及FSB533的845PE/GE/GV 芯片组等诸多子产品。

845系列芯片组的82845E/82845GL/82845G/82845GV/82845GE/82845PE，除82845GL以外都支持533MHz FSB（82845GL只支持400MHz FSB），支持内存方面，所有845系列北桥都支持最大2GB内存。

82845GL/82845E支持DDR 266，其余都支持DDR 333。

除82845GL/82845GV之外都支持AGP 4X规范。

所有的533Mhz 外频芯片组都将支持Hyper-Threading（超线程技术）。

但对于845G 芯片组来说，即使升级BIOS也不能支持Hyper-Threading ，因为它的硬件架构不允许其支持Hyper-Threading。

而i845E 和850E就可以通过升级BIOS 来获得支持。

Intel将发布845G B-step以取代845G A-step芯片组，而且之后的845GV、GE、PE和Springdale都将支持Hyper-Threading。

845E芯片组对于845D芯片组来说，其实并没有重大改变，仅仅是使用了支持USB2.0的ICH4和支持FSB533而已，但845D芯片组也同样能够支持FSB533，而且经过超频之后内存子系统性能更高，整体甚至超过了845PE芯片组。
