Omega CNi32 1 32 DIN 仪器说明书

9段式显示屏OMEGA ®属于小巧玲珑的iSeries 控制器，它采用普及程度不断扩大的 1⁄32 DIN 尺寸（22.5 x 45 mm 开孔）。

CNi32是拥有纤巧1⁄32 DIN 外形的最先进、最精确的仪器，但其配置仍然很容易。

与其它任何1⁄32 DIN 控制器相比，CNi32能够处理更多热电偶、RTD 、过程电压和电流输入。

CNi32是第一款可提供24 Vdc @ 25 mA 内置激励电压的1⁄32 DIN 的仪器。

CNiS32可为桥式传感器提供5 Vdc @ 40 mA 或10 Vdc @ 60 mA 内置激励电压。

安装通讯选件后，可以通过将外部激励连接到传感器引线来使用外部激励并且保持比率计量操作。

内部与外部激励均支持4线制或6线制桥式配置。

非比率计量操作受电压和电流传感器的支持，并且在制造和校准过程中非比率计量在测量偏差和毫伏输出时也很有用。

此型号还具有10点线性化，这让用户能够线性化来自各种极端非线性化传感器的信号输入。

CNi32推出了许多其它任何1⁄32 DIN 仪器至今仍然不能提供的独有功能。

CNi32是第一款配备完全可编程显示屏的1⁄32 DIN 控制器，其显示屏可针对任何设定值或报警值在绿色、琥珀色和红色之间更改颜色。

独有的9段式LED 字符显著改善了字母数字的显示效果。

CNi32是首款提供2个C 型继电器的1⁄32 DIN 控制器，而普通1⁄32 DIN 控制器使用的是单掷继电器。

CNi32是首款同时提供RS232和RS422/485串口通讯功能的1⁄32 DIN 控制器（C24选件）。

ASCII 协议可从菜单中选择。

U 高精度：读数的±0.03%， 0.5°C (±0.9°F)U 完全可编程彩色显示屏U 用户易于使用，易于配置U 提供软件U 完全自动调谐PID 控制U 通用输入：热电偶、RTD 、过程电压／电流、应变U R S232和RS485串口通讯（可选）U 内置激励电压 U 温度稳定性：±0.04°C/°C RTD 和±0.05°C/°C 热电偶 @ 25°C (77°F)U N EMA 4 (IP65)防护等级前盖U 两个控制或报警输出（可选）：DC 脉冲、固态继电器、机械式继电器、模拟电压和电流U 正面可拆卸和插接的连接器CNi3233 图片大于实际尺寸。
