机械工程图中常用的英语词汇
A
Abbreviation 缩写
Accuracy 精度、准确性
Acme thread 梯形螺纹(29°)
Addendum 齿顶高
Addendum angle 齿顶角
Addendum circle 齿顶圆
Addendum of mating gear 啮合齿轮的齿顶高
Adjacent-part lines 相邻零件线
Aligned sections 旋转剖视
Aligned view旋转视图
Allowance 容差、加工余量
Alloy 合金
Alloy steel 合金钢
Alphabet 字母
Alteration 变更、更改
Alternate-position views 位置改变的视图
Alternator 交流发电机
Induction alternator 感应(交流)发电机
Motor alternator 电动(交流)发电机
Single-phase alternator 单向(交流)发电机
Synchronous alternator 同步(交流)发电机
Three-phase alternator 三相(交流)发电机
Amount 总量、总计
Analyzable assembly 分析装配图
Anchor bolt 地脚螺栓
Angles 角
Acute angle 锐角
Blunt angle 钝角
Right angle 直角
Sliding angle 摩擦角
Spiral angle 螺旋角
Taper angle 锥角
Angular 有角的
Angular bearing 径向止推轴承
Angular bevel gears 斜交伞齿轮
Angular gear人字齿轮
Angular section斜剖面
Anneal 退火
Approval 批准、许可
Arc 弧、圆弧
Arc thickness 弧长厚度(齿厚)
Arc welding 弧焊
Arrangement 布置、装置Arrangement of views 视图的布置
Clamping arrangement 夹紧装置
Cramping arrangement 紧固装置
General arrangement 总体布置
Arrow 箭头
Arrowheads 箭头
Assembly 装配图、组装图
Assembly drawing 装配图
Assembly drawing number 装配图图号 Assembly for installation 安装图
Assembly parts 组装配合零件
Assembly sections 装配图剖视
Assembly sketches 装配草图Auxiliary elevation 辅助立面图Auxiliary line辅助线
Auxiliary section 辅助剖视
Auxiliary surface 辅助面
Auxiliary view 辅助视图
Average 平均数
Axial 轴的、轴向的
Axial pitch 轴向节距
Axial plane 轴向平面
Axial thickness 轴向厚度
Axis 轴线、中心线
Axis of revolution 回转轴线
Axis of rotation 旋转轴线
Axis of symmetry 对称轴线
Horizontal axis 水平轴
Major axis 长轴
Minor axis 短轴
Vertical axis 垂直轴
X axis X轴
Y axis Y轴
Axle 轴
Axle bearing 轴向(止推)轴承
Axle sleeve 轴向(止推)套筒Axonometric drawing 轴测图
B Babbitt 巴氏合金
Back cone 背锥
Back cone radius 背锥半径
Back elevation 后视图
Backstop 托架、棘爪
Ball bearing 球轴承
Bar 杆
Angle bar 角钢
Channel bar 槽钢
Flat bar 扁钢
Round bar 圆棒、圆钢
Base 基础、底座、基线、基面、基准
Base circle 基圆
Base circular thickness 基圆弧线齿厚
Base cylinder 基圆柱
Base helix angle 基圆上的螺旋角
Base plane 基平面
Base point 基点
Key base 键座
Basic circle 基准圆
Basic hole system 基孔制
Base shaft system 基轴制
Basic size 基本尺寸、公称尺寸、标称直径Basis 基础、基准、基线
Battery 电池、蓄电池
Bearing 轴承、支撑、方位
Bearing accuracy 定位精度
Bearing box 轴承箱
Bearing brass 铜轴衬
Bearing bridge 轴承支架
Bearing oil seal 轴承油封圈
Bearing support 轴承架
Bearing unit 轴承组合件
Anti-friction bearing 减摩轴承
Ball and socket bearing 球窝轴承
Conical bearing 锥形轴承
Journal bearing 径向轴承
Needle bearing 滚针轴承
Plain bearing 滑动轴承
Roller bearing 滚柱轴承
Self-aligning bearing 自位轴承
Thrust bearing 止推轴承
Belt 带、皮带
Bench 工作台
Work bench 工作台
Bend 弯头、接头
Elbow bend 肘形弯管
Normal bend 正弯管(90°)
Bender 弯曲机
Bending 挠曲
Bending strength 抗弯强度
Bent axle 曲轴
Bevel 倾斜的、斜角的、斜面
Bevel gear 圆锥齿轮、伞齿轮
Bevel pinion 小圆锥齿轮
Bevel washer 斜垫圈
Bevel wheel 伞齿轮、斜摩擦齿轮Bilateral tolerance 双向公差
Bill of materials 送料单
Block in、block out 画草图
Blue paper 蓝晒纸
Blueprint 蓝图、设计图
Board 板、(管理)局、厅
Bottom board 底板
Moulding board 模板
Body 机体、机身
Boiler 锅炉
Bolt 螺栓、插销
Adjusting bolt 调整螺栓
Assembling bolt 装配螺栓
Binding bolt 连接螺栓
Bright blot 光制螺栓
Captive bolt 固定螺栓
Double-screw bolt 双头螺栓
Fitter bolt 装配螺栓
Foundation bolt 地脚螺栓Hexagonal head bolt 六角头螺栓Hook bolt 钩形螺栓
Screw bolt 全螺纹螺栓
Snap bolt 圆头螺栓
Tension bolt 拉紧螺栓
Bolted joints 螺栓连接
Book 书、册
Hand book 手册
Instruction book 说明书
Bore face machine 镗孔端面加工机床Borer 镗床
Jig borer 坐标镗床
Table borer 台式镗床
Boring 镗孔
Boring machine 镗床
Boring mill 镗床
Bottom case 底座
Bottom clearance 径向间隙
Bottom view 底视图
Bracket 托架、支柱
Brake 制动器、闸
Brass 黄铜、铜轴衬
Braze 铜焊
Brazing 铜焊
Breadth 宽度、厚度
Break line 断裂线
Brinell figure (number) 布氏硬度Brinell hardness 布氏硬度
Broacher 拉床、绞孔机
Broaching 扩孔机、拉床、拉削Broken circle 虚线圆
Broken out section 断裂剖面
Broken view 局部视图
Bronze 青铜
Burnishing 抛光、磨光
Burr 三角矬、毛刺、去毛刺
Bush 衬套、轴瓦
Bushing 轴衬、衬套、套管
Butt joint 对接焊
Butterfly nut 蝶形螺母
Butterfly valve 蝶形阀
Button 按钮
Push button 控制按钮
C Cable 电缆
Cage 盒、罩、箱
Caliper 卡尺、卡钳
Gauge caliper 卡规、量规
Internal caliper 内卡钳
Sliding (vernier) caliper 游标卡尺Cam 凸轮
Cam design 凸轮设计
Cam shaft 凸轮轴
Actuating cam 主动凸轮
Adjustable cam 可调凸轮
Control cam 控制凸轮
Cap 盖、帽、罩
Cap screw 带帽螺钉
Capital 大写字母
Carburizing 渗碳
Card 卡片
Cartographer 制图员
Cartography 制图学、制图法
Case 箱、盒、容器、表面
Case hardened 表面淬火、硬化Nitrogen case hardening 渗氮硬化
Casing箱、盒、壳
Oil pump casing 油泵(壳)
Casting 铸造、铸件
Defect casting 铸件缺陷
Die casting 压铸
Sand casting 砂型铸造
Spun casting 离心铸造
Steel casting 铸钢
Cast-iron 铸铁
Castle circular nut 六角圆螺母
Castle nut 蝶形螺母
Catalogue data 表列数据
Cave 凹槽、内腔
Centre 中心、圆心
Centre distance 中心距
Centre hole 中心孔
Centre line 中心线
Centre-section 中心剖面
Centre to centre 中心距
Centesimal 百分的、百分之一的Centimeter 厘米、公分
Central hole 中心孔
Central plane 中心平面
Central projection 中心投影
Chafe 摩擦、磨损
Chain 链
Drive chain 主动链
Transmission chain 传动链
Chamfer 倒角、倒棱、斜面Dimensioning of chamfer 倒角的尺寸注法Changes on drawing 图的更改
Channel 沟槽
Chapter 章
Chart 图表、计算图
Chart of symbols 符号图表
Auxiliary chart 辅助图
Dimensions chart 外廓尺寸图Graphical chart 图表
Process chart 工艺程序图
Progress chart 工艺程序表、工作进度表 Charting 制图(表)、填图
Check 校验、校核、制动装置
Check drawings 校图
Check nut 防松螺母
Check ring 挡圈
Check test校核试验
Chief draftsman 主任制图员
Chromium 铬
Chromizing 镀铬处理
Circle 圆、圆周
Circle of reference 参考圆
Addendum circle 齿顶圆
Base circle 基圆
Graduated circle 分度圆
Imaginary circle 虚圆
Outside circle 齿顶圆、外圆
Pitch circle 节圆
Rack circle 平面齿轮、扇形齿轮
Root circle 根圆
Top circle齿顶圆
Circular cylinder 圆柱
Circular pitch 弧线节距
Circular thickness 弧线(齿)厚度Circumference 圆周长
Clamp 夹紧、夹板
Class 种类
Class of fit 配合级别
Classification 分类
Claw 爪、钩、卡爪
Clearance fit 间隙配合
Clevice /clevis U形钩、U形夹
Clevis bolt 套环(插销)螺栓
Clevis pin U形夹销
Clockwise 顺时针方向
Clutch 离合器、联轴器
Coat 外层、涂镀层
Coat of metal 金属镀层
First coat 底漆
Coating 镀、覆盖
Electrodeposited coating 电镀层
Coaxial circle 共轴圆
Cock 旋塞
Coil 蛇形管、螺管、线圈
Coil spring 盘簧
Coincident line 重叠线
Cold-rolled steel 冷轧钢
Collet 夹头
Collet chuck 弹簧夹头
Color-harden 着色硬化、发蓝、煮黑Common difference 公差
Company 公司
Joint company 股份公司
Limited company 有限公司
Compass 圆规
Compass of proportion 比例规Component 零件、构件
Compression spring 压力弹簧
Compressor 压缩机
Computer 计算机
Concave face 凹面
Concentricity 同心度
Cone 圆锥
Cones development 锥面展开
Cone pulley 锥形轮、塔轮
Conical spring 锥形弹簧
Connection 联接
Bolt-on connection 螺栓联接
Flange connection 法兰联接
Rivet connection 铆钉联接
Screw connection 螺钉联接
Contact 接触、接合、啮合
Contact angle 啮合角
Angular contact ball bearing 向心止推球轴承Contour 外形、轮廓线
Contracted drawing 缩图
Contrast 对比、对照、比较
Convention 惯例、常规、习惯
Convention for materials 材料的习惯表示法 Conventional break 习惯断裂画法
Conventional diagram 习惯画法
Conventional intersection 习惯交线(画法) Conventional practice 习惯画法Conventional sign 图例、习惯符号
Convex 凸面
Conveyer 输送机、传送机
Cooler 冷冻机
Coordinate axis 坐标轴
Coordinate paper 方格纸、坐标纸Copper 铜
Copy 抄本、样板
Correction 校正、修正
Cotter pin 开口销
Split cotter 开口销
Counterbore 埋头孔、锥口孔Counterclockwise 逆时针方向Countersink 埋头孔、沉孔
Countersink drill 中心钻、钻Countersunk 钻埋头孔、钻锥口孔
Countersunk bolt 埋头螺钉
Countersunk head 埋头
Countersunk hole 锥坑
Coupling 联轴节
Cover 盖、罩
Cylinder cover 汽缸盖
Dust cover 防尘罩
Cowl 壳、套、盖
Crane 起重机
Crank 曲柄、曲轴
Crankshaft 曲轴
Crest 峰、尖、牙尖
Cross head 十字头
Cross section 横剖面、横断面
Crown gear 冕状齿轮
Cube 立方形体、正六面体
Current 电流
Curvature 曲率
Curvature radius 曲率半径
Curve 弯曲、曲线、曲线板
Curve plotter 绘图仪
Curve ruler 曲线板
French curve 曲线板
Moment curve 力矩曲线、力矩图
Cutter 刀、刀具
Cutting plane 截平面
Cutting plane symbols 剖切(迹线)平面符号Cycloid 摆线
Cycloidal gear 摆线齿轮
Cylinder 圆柱体
Cylinder base 汽缸座
Pump cylinder 泵缸
Cylindrical cam 圆柱凸轮
Cylindrical fit 圆柱配合
Cylindrical roller bearing 圆柱滚子轴承
D Dash 短划线、虚线、破折号
Dash and dot line 点划线
Broken dash 断裂线
Data 数据、资料
Engineering data工程数据
Master data 主要数据
Date 日期、年代
Datum 基准(点、线、面)、资料
Datum line 基准线
Datum point 基准点
Datum plane 基准面
Decade 十进制、十进位
Decelerator 减速器、制动器、缓动装置Decimal 小数的、十进位小数的
Decimal fraction 十进制分数
Decimal fraction system 十进小数制
Decimal scale 十进位比例尺Decimeter 分米、公分
Dedendum angle 齿根角
Dedendum circle 齿根圆
Definition 定义
Deformation 变形、扭曲
Degree 度、程度
Degree of accuracy 精度
Degree of freedom 自由度
Degree of hardness 硬度
Degree scale 刻度
Circular degree 圆度
Delineation 轮廓、草图
Delineator 制图者
Department 科、处、系、车间
Draft department 设计科Engineering department 技术科
Fitting department 装配车间
Heat treatment department 热处理车间Mechanical department 机加工车间
Processing department 工艺科
Depth 深度、高度
Depth dial gauge 深度千分表
Depth of engagement 啮合深度Depth of thread 螺纹深度
Depth of tooth 齿高
Contact depth of tooth 啮合高度Working depth of tooth 齿工作高度Derivation 偏差
Standard derivation 标准偏差Description 描述、作图、绘制Design 设计、计划
Design activity 设计机关(组织) Design assembly 设计装配图Design drawing 设计图
Design layout 设计草图、初步设计图Preliminary design 初步设计Standard design 标准设计Technical design 技术设计Designation 符号、标志Designation strip 铭牌
Designer 设计员、制图者、设计师Desk 桌、控制台
Drawing desk 绘图桌
Detail 细目、细节、详图、零件Detail drawing 详图、零件工作图
Detail paper底图纸、描图纸
Detail specification 详细规格
Detent 棘爪、扳手、制动器Developable surface 可展曲面Developed view 展开图Development inner port 内表面展开图Development of surface 表面展开图Deviation 偏差、偏移
Angular deviation 角偏差
Average deviation 平均偏差Standard deviation 标准偏差Tolerance deviation 允许偏差Device 装置、设备
Diagram 示意图、图解
Diagram drawing 图解图、结构图Arrangement diagram 布置图
Assembly diagram 装配示意图
Block diagram 方框图
Schematic diagram 原理图、简图Diagrammatic drawing 草图、示意图Dial gauge 千分表
Dial inside micrometer 内径千分表Diameter 直径
Diameter of aperture 孔径
Diameter of pitch circle 节圆直径Diameter pitch (齿轮)径节
Diameter run-out径向跳动
Major diameter 大直径、螺纹外径Minor diameter 小直径、螺纹内径Nominal diameter 公称直径
Pitch diameter of screw thread 螺纹中径Thread diameter 螺纹外径(直径) Diametral pitch 齿轮径节
Die 模具、扳牙
Diesel 柴油机、内燃机
Dimension 尺寸
Dimension line 尺寸线
Limiting dimension 极限尺寸Nominal dimension 公称尺寸
Outer dimension 外形尺寸、轮廓尺寸Direction 方位、方向
Clockwise direction 顺时针方向
Disc = disk 圆盘、原板
Disk cam 圆盘凸轮
Dismount 拆卸
Dismountable 可拆卸的Displacement 移位、变位
Distance 距离、路程
Distortion 变形、歪扭
Distribution 分配、分布、配置
Ditto machine 复印机
Diversion 变更、转换
Dividing head 分规
Dot line 虚线
Dotted line 虚线
Double dots line 双点划线
Double helical pinion 人字小齿轮Double helical spur gear 人字齿轮Double thread 双头螺柱
Dowel thread 定位销、圆柱销
Dozer 推土机
Draft = draught (拔模)斜度、草图、制图
Drafting 制图
Drafting board 制图板
Drafting machine 制图机
Drafting tape 制图带、胶带
Draftsman 绘图员
Drawer 制图员
Drawing 绘图、图样
Drawing board 绘图纸
Drawing control 图样管理
Drawing free-head 草图
Drawing instrument 绘图仪器
Drawing number 图号
Drawing pencil 绘图铅笔
Drawing pin 图钉
Drawing size 图纸尺寸
Drawing table 制图桌
Drawing with compass 用圆规画图
Blue print drawing 蓝图
Free hand drawing 徒手图
Full size drawing 原大图
Skeleton drawing 草图、结构图
Working drawing 施工图、制造图、工作图Drill 钻孔、穿孔、穿孔器
Drive 传动、驱动
Drive fit 打入配合
Air drive 气动
Belt drive 带传动
Chain drive 链传动
Friction drive 摩擦传动
Gear drive 齿轮传动
Hydromatic drive 液压传动
Speed-reducer drive 减速器传动
Variable-speed drive 变速传动
Worm-wheel drive 蜗轮传动
Driven gear 从动齿轮
Driven shaft 从动轴
Driving gear 主动齿轮
Driving shaft 主动轴
Drum cam 凸轮轴
Ductile iron 球墨铸铁
Duplicating tracing 复制描图
Durometer (钢轨)硬度计
Dusting cloth 抹灰布、撒粉布
E
Eccentricity 偏心距
Edge iron 角铁
Edge round 外圆角
Edge view 边视图
Effective diameter 有效直径
Effective face width 有效齿宽Efficiency 效率、性能
Mechanical efficiency 机械效率Elastic deformation 弹性变形Elasticity 弹性
Elbow 肘形弯管、弯头
Electric current 电流
Electric element 电池
Elephant 绘图纸(28X23英寸) Elevation 正面图、立视图
End 末端、头
Ball end 秋端
Butt end 平端、端面
Tail end 尾端
Top end 顶端
Engagement 啮合
Engineer 工程技术人员、工程师Engineer-in-chief 总工程师Equipment 设备
Eraser 橡皮
Erasing shield 擦图片
Erection diagram 安装图、装配图Error 误差
Accumulated error 累积误差Allowance error 容许误差
Average error 平均误差Permissible error 容许误差
Relative error 相对误差
Exterior 外表面
External 外部
External diameter 外径
External dimension 外形尺寸External fillet 外圆角
External thread 外螺纹
Extra fine(screw)特细牙螺纹
Eyelet = eyelet-hole 小孔
F Fabrication 建造、制造
Face 面、正面、表面、端面
Face cam 平面凸轮
Face gear 平面齿轮
Face hardening 表面硬化
Inner face 里面
Outer face 外面
Face off 倒角
Factor of safety 安全系数
Factory 工厂、制造厂
Factory made 工厂制造的
Fastener 接合件、紧固件
Fastening 连接件、紧固件
Fatigue 疲劳
Faucet 旋塞、龙头、开关
Feather 滑键、冒口
Feather key 滑键
Feature 特征、特性、性能
Basic mechanical design feature 主要机械设计性能Mechanical feature 机械性能(特性)
Feed-pump 供油泵、供水泵
Feet 英尺
Ferrous metal 黑色金属
Field 工场、现场
Figure 形状、图样、插图、数字
File 锉刀、锉平
Filler 填料、垫片
Fillet (内)圆角、填角、嵌条
Fillet radius 内圆角半径
Filter 过滤器
Fine thread series 细螺纹级(系列)
Finish 完工、加工、磨光
Finish all over 全部加工
Finish marks 加工符号
Machine finish 机器光制
Fit 配合
Clearance fit 间隙配合
Free fit 自由配合
Interference fit 静配合
Light press fit 轻压配合
Light running fit 轻传动配合
Loose fit 松配合
Normal-running fit 传动配合
Running fit 动配合
Shrink fit 冷缩配合
Slide fit 滑动配合
Transition fit 过渡配合
Fix 安装、装配、调整、修理、固定Flange 法兰盘、凸缘
Flank 边、侧面、齿侧、后面
Flat 扁头、平面
Flat key 平键
Flat spring 板弹簧
Flat surface 平面
Flexible disk coupling 挠性盘形联轴节Flexible gear-type coupling 挠性齿轮联轴节Flywheel 飞轮
Foot 英尺
Foot screw 地脚螺钉
Force 力
Fore word 序、前言
Forge 锻
Forge steel 锻钢
Former 样板、模型、量规
Wooden former 木模
Formula 公式
Foundation 基础、基座
Foundation bolt 地脚螺栓
Foundry 铸件、铸工车间
Fraction 分数、小数
Front view 前视图、主视图
Full diameter 大直径、主直径
Full line 实线
Full size 原大
Full scale 原大
Full section 全剖视
Full section view 全剖视图
Furbish 研磨、擦光
Fuse 保险丝、熔断器
G Gage = gauge 量规
Gallon 加仑
Galvanize 镀锌、电镀
Gasket 垫圈、密封垫
Gasket material 填料
Gasoline engine 汽油(内燃)机
Gate 门、阀门
Gear 齿轮
Gear addendum angle 齿顶角
Gear box(case) 齿轮箱
Gear centre 齿轮中心
Gear dedendum angle 齿根角(圆锥齿轮) Epicyclic gear 行星齿轮
Herringbone gear 人字齿轮
Ratchet gear 棘轮
General drawing 总图
Geometry 几何学
Gland 压盖、填料盖、密封装置
Glass 玻璃
Glasscloth 砂布、玻璃布
Glossary 词汇(表)
Grade 等级、斜度
Steel grade 钢号
Graduated hardening 分级淬火Graduated scale 比例尺、分度尺
Gram 克
Graph 图(表、解、形)、曲线图
Graph paper 方格纸
Graphic图示、制图学
Grease 滑脂
Grind 磨削、抛光
Grinding machine 磨床
Grinding wheel 砂轮
Groove cam 槽凸轮
Groove pulley 槽轮、三角带轮
Guide 手册、指南
Guide bar 导杆
Guide pin 定位销、导向销
Guide screw 丝杠
Guidebook 参考手册、指南、入门
H Half 二分之一、一部分
Half bearing 轴瓦
Half section 半剖视
Half section view 半剖视图
Hammer 锤子
Handbook 手册、指南
Hand-made 手工制造的
Hand-operated 手控的
Handle 手柄
Hand wheel 手轮
Hard casting 白口铁
Hard drawn 冷拔
Hard rolled 冷轧的
Hard surfacing 表面硬化
Harden 淬火、硬化
Hardened and tempered 调质的Hardened-steel 淬火钢
Hardening 硬化
Hardness 硬度
Hardometer 硬度计
Hatch 剖面线
H-beam 工字梁、H形梁
Heat–treatment 热处理
Heavy force fit 重压配合
Height 高度
Helical bevel gear 螺旋伞齿轮
Helical gear 螺旋齿轮、圆柱斜齿轮Helical rack 斜齿齿条
Helical spring 螺旋弹簧
Hex nut 六角螺母
Hexagon jam nut 六角锁紧螺母Hexagon socket head 内六角头Hidden line 虚线
Hidden outline 看不见的轮廓线
High-carbon steel 高碳钢
High-duty 重型的、大型的、优产的 High-speed steel 高速钢
Hosting jack 千斤顶
Hole 孔
Horizontal datum plane 水平基准面Horizontal line 水平线
Horizontal projection 水平投影Horizontal projection plane 水平投影面Horse-power 马力、功率
Hose 软管
Hose coupling 软管接头
Hot-rolled steel 热轧钢
Hot-work 热加工
Hour 小时
Housing 机座
Housing of pump 泵体
Bearing housing 轴承箱
Gear housing 齿轮箱
Hub 轮、中心、衬套
Hydraulic(al) 液压的、液压传动装置Hydro-motor 液压马达
Hypoid gear 准双曲面齿轮
I I-beam 工字钢
Illustration 插图、实例
Inaccuracy 不精确、不准确
Incenter 内(切圆)心
Inch 英寸
Incline 斜度、斜面
Index plate 分度盘
Indicator 指示计、百分表
Industrial 工业公司
Industrial drawing 工业制图Industry 工业
Inertia 惯性
Ink 墨水、油墨
Ink holder 钢笔杆
China ink 墨汁
Inscription 标题
Inside diameter 内径
Inspection 检修、检查
Inspection machine 检修机器Inspector 检查员
Installation 装置、设备、安装
Installation diagram 安装图
Institute 研究所、协会、学院、学会Instruction 说明、指示
Instrument 仪器、仪表、工具
Instrument drawing 仪器图
Intensity 强度
Interchangeability 互换性1 Interconnection 互相连接Interference fit 静配合
Interior view 内部(的)视图
Internal combustion engine 内燃机Internal fillet 内圆角
Internal gear 内齿轮
Introduction 引言、介绍、序言Invisible line 虚线
Involute 渐(伸)开线
Involute gear 渐开线齿轮
Involute rack 渐开线齿条
Involute spline 渐开线花键
Involute teeth 渐开线齿形
Iron 铁
Ingot iron 低碳铁、工业纯铁Knobbled iron 熟铁
Magnetic iron 磁铁
Malleable iron 可锻铁、韧性铁
Plate iron 铁板、钢板
Quadrant iron 方钢
Rod iron 圆铁、棒钢
Round iron 圆铁、圆钢
Rustless iron 不锈铁
Section iron 型钢
Structural iron 结构钢
White iron 白口铁
Wrought iron 熟铁、锻铁
Isometric diagram 等轴测图
Isometric drawing 等轴测图
J Jack-screw 螺旋千斤顶
Job sheet 零件图纸
Joint 结合、连接、焊接
Bolt joint 螺栓连接
Riveted joint 铆钉连接
Welded joint 焊接
Journal 轴径
Journal bearing 径向轴承
K Keeper 保持器(片)、架、定位件卡箍Keep-ring 保持环
Key diagram 键、按钮
Key way(seat、seating、slot)键槽
Key wrench 套筒扳手
Gib-head taper key 钩头斜键
Square key 方形键
Tightening key 斜扁键
Woodruff key 半圆键
Key-bolt 键螺栓
Kilogram(me)公斤、千克
Kilogram-meter 公斤米、千克米Kilometer 公里、千米
Kilovolt 千瓦
家具常用英语词汇 1、factory 工厂27、poplar 白杨木 2、Date of Loading 装柜日28、Rubber Wood 橡胶木 3、Seal# 封条号码29、Walnut 胡桃木 4、Consolidated vendor 并柜工厂30、Solid Wood 实木 5、Customer 客户名31、Particle Board (PB板) 6、Port of discharge 装货港32、Fiber Board(PF.MDF板) 7、Final destination 目的地中纤板、密度板 8、ETA 装船/开船日33、Allen Wrench 内六角扳手 9、ETA Final Destination 到达日34、Apron 立水.台雅 10、Group 系列.群35、Top 面板 11、Order No. 订单号36、Leg 脚 12、P.O Number 订单号码37、Leaf 中板 13、Item Number 产品编号38、Shelf 层板 14、Quantity Loaded 装柜数量39、Bottom 底板 15、Quantity Ordered 订单数量40、Base 底座 16、Spare/Repair parts 补件41、Knob 把手 17、Sample 样品42、Door 门 18、Alder 赤杨木43、Drawer 抽屉 19、Ash 水曲柳44、Draw Back Panel 抽后板 20、Bass Wood 椴木45、Draw Front Pane 抽前板 21、Beech 榉木46、Draw Side Panel 抽侧板 22、Birch 桦木47、Draw Bottom 抽底板 23、Cherry 樱桃木48、Flat Washer 平面华司 24、Maple 枫木49、Slide 滑轨 25、Poplar 白杨木50、Machine Screw 内六角螺丝 26、Red Oak 红橡木 51、Rail 饰条77、Screen 屏风 52、Roller 软门78、Folding Screen 折屏
陶瓷ceramics 合成纤维synthetic fibre 电化学腐蚀electrochemical corrosion 车架automotive chassis 悬架suspension 转向器redirector 变速器speed changer 板料冲压sheet metal parts 孔加工spot facing machining 车间workshop 工程技术人员engineer 气动夹紧pneuma lock 数学模型mathematical model 画法几何descriptive geometry 机械制图Mechanical drawing 投影projection 视图view 剖视图profile chart 标准件standard component 零件图part drawing 装配图assembly drawing 尺寸标注size marking 技术要求technical requirements 刚度rigidity 内力internal force 位移displacement 截面section 疲劳极限fatigue limit 断裂fracture 塑性变形plastic distortion 脆性材料brittleness material 刚度准则rigidity criterion 垫圈washer 垫片spacer 直齿圆柱齿轮straight toothed spur gear 斜齿圆柱齿轮helical-spur gear 直齿锥齿轮straight bevel gear 运动简图kinematic sketch 齿轮齿条pinion and rack 蜗杆蜗轮worm and worm gear 虚约束passive constraint 曲柄crank 摇杆racker 凸轮cams
1、家具种类 A Adjustable bed 可调床 Air bed 气床 Anti-slip strip for stairs (儿童床)防滑楼梯打击扶手Antique furniture 古式家具 Antique reproduction furniture 仿古家具 Armchair 扶手椅 B Baby crib 婴儿床 Backless wall-unit 不设背板的壁橱 Bamboo furniture 竹家具 Banqueting chair 宴会椅 Barstool 吧椅 Bathroom accessories 浴室配套装置 Bathroom combination 浴室组合柜 Bathroom consoles 浴室多用架 Bathroom furniture 浴室家具 Bathroom vanity 浴室盥洗台 Batten door 板条门 Bed base床架,床套 Bed base set 成套床架 Bedroom suite 卧室系列家具 Bedstead 床架 Bentwood furniture 曲木家具 Beside table 床头柜 Birch door 桦木门 Board-room and conference table 会议桌 Bookcase 书柜 Bookshelf 书架 Built-in kitchen 配套厨房家具 Bunk 双层床 Bunk bed 双层床 C Cabin bed 儿童多功能床 Cabin furniture for ships 船用家具 Canopy bed 带天篷的床,四柱床 CD-video storage cabinet边音响组合柜 Chair with castors 脚轮椅 Changing table 可调桌 Chest of drawers 多屉橱柜 Child cot 童床 Children’s bed 儿童床 Children’s bedroom suite 儿童卧房系列家具
机械工程图技术要求综合 一、机械零件常用技术要求: 1、锐角倒钝、去除毛刺飞边。 2、零件去除氧化皮。 3、未注圆角半径R5。 4、未注倒角均为2×45°。 5、未注形状公差应符合GB1184-80的要求。 6、未注长度尺寸允许偏差±0.5mm。 7、零件加工表面上,不应有划痕、擦伤等损伤零件表面的缺陷。 8、精加工后的零件摆放时不得直接放在地面上,应采取必要的支撑、保护措施。加 工面不允许有锈蛀和影响性能、寿命或外观的磕碰、划伤等缺陷。 9、加工的螺纹表面不允许有黑皮、磕碰、乱扣和毛刺等缺陷。 二、铸件技术要求: 1、铸件表面上不允许有冷隔、裂纹、缩孔和穿透性缺陷及严重的残缺类缺陷(如欠铸、 机械损伤等)。 2、铸件应清理干净,不得有毛刺、飞边,非加工表面上的浇冒口应清理与铸件表面齐 平。 3、对错型、凸台铸偏等应予以修正,达到圆滑过渡,一保证外观质量。 4、铸件非加工表面上的铸字和标志应清晰可辨,位置和字体应符合图样要求。 5、铸件非加工表面的粗糙度,砂型铸造R,不大于50μm。 6、铸件应清除浇冒口、飞刺等。非加工表面上的浇冒口残留量要铲平、磨光,达到表 面质量要求。 7、铸件上的型砂、芯砂和芯骨应清除干净。 8、铸件有倾斜的部位、其尺寸公差带应沿倾斜面对称配置。 9、铸件上的型砂、芯砂、芯骨、多肉、粘沙等应铲磨平整,清理干净。 10、铸件公差带对称于毛坯铸件基本尺寸配置。 11、铸件非加工表面的皱褶,深度小于2mm,间距应大于100mm。 12、机器产品铸件的非加工表面均需喷丸处理或滚筒处理,达到清洁度Sa2 1/2级的 要求。 13、经喷丸或手工除锈的待涂表面与涂底漆的时间间隔不得多于6h。 14、铸件表面应平整,浇口、毛刺、粘砂等应清除干净。 15、铸件不允许存在有损于使用的冷隔、裂纹、孔洞等铸造缺陷。 16、所有需要进行涂装的钢铁制件表面在涂漆前,必须将铁锈、氧化皮、油脂、灰尘、 泥土、盐和污物等除去。 17、除锈前,先用有机溶剂、碱液、乳化剂、蒸汽等除去钢铁制件表面的油脂、污垢。 18、铸件必须进行水韧处理。
Lesson 1 Basic Concepts in Mechanics 机械学的基本概念 mechanics n.力学 modify v.修改,调解,变更manageable a.可控制【管理】的 incline v.(使)倾斜 ramp n.斜板,斜坡【道】 slope v.(使)倾斜 friction n.摩擦 roll v.滚动 multiplier n.放大器,乘法器 broom n.扫帚 convert v.转变【化】 handle n.手柄【把】 sweep v.扫荡【描】,掠过efficiency n.效率 gauge vt.测【计】量,校验bearing n.轴承 ideal mechanical advantage 理想的机械效益 neglect vt.忽略Lesson 2 Basic Assumption in Plasticity Theory 塑性理论的基本假设 assumption n.假定 plasticity n.塑性 investigate v.调查,研究deformation n.变形 metal forming process 金属成型工艺【过程】 strain (rate) n.应变【速率】 strength n.强度 stress n.应力 yield stress 屈服应力 flow stress 流动应力 tensile stress 拉【伸】应力compressive stress 压【缩】应力 shear stress 剪【切】应力 geometry n.几何形状 elastic a.弹性的 springback n.回弹 bending n.弯曲,折弯
Adjustable bed 可调床 Air bed 气床 Anti-slip strip for stairs (儿童床)防滑楼梯打击扶手Antique furniture 古式家具 Antique reproduction furniture 仿古家具 Armchair 扶手椅 B Baby crib 婴儿床 Backless wall-unit 不设背板的壁橱 Bamboo furniture 竹家具 Banqueting chair 宴会椅 Barstool 吧椅 Bathroom accessories 浴室配套装置 Bathroom combination 浴室组合柜 Bathroom consoles 浴室多用架 Bathroom furniture 浴室家具 Bathroom vanity 浴室盥洗台 Batten door 板条门 Bed base床架,床套 Bed base set 成套床架 Bedroom suite 卧室系列家具 Bedstead 床架 Bentwood furniture 曲木家具 Beside table 床头柜 Birch door 桦木门 Board-room and conference table 会议桌 Bookcase 书柜 Bookshelf 书架 Built-in kitchen 配套厨房家具 Bunk 双层床 Bunk bed 双层床 C Cabin bed 儿童多功能床 Cabin furniture for ships 船用家具 Canopy bed 带天篷的床,四柱床 CD-video storage cabinet边音响组合柜 Chair with castors 脚轮椅 Changing table 可调桌 Chest of drawers 多屉橱柜 Child cot 童床 Children’s bed 儿童床 Children’s bedroom suite 儿童卧房系列家具Children’s chair 儿童椅 CKD(complete knock down) 整体拆装式家具Clothes rail 挂衣杆 Cocktail cabinet 吧柜,酒柜 Cocktail table 鸡尾酒桌 Coffee table 茶几,咖啡桌 Combine-unit 组合柜
机械制图常用技术要求 ?技术要求(冲压件) 1.锐边去毛刺,冲压切口粗糙度6.3. 2.冲件表面氧化处理:H.Y.或(表面镀锌钝彩.Zn8.DC.). 3.未注公差尺寸的极限偏差按GB/T 1804-92 m级. 技术要求(铸件) 1.铸件不得有气孔、夹渣、裂纹等缺陷. 2.未注明铸造斜度为1~2.5%%d. 3.铸造公差按GB6414-86 CT6. 4.未注明铸造圆角为R1~R2. 5. 5.未注公差尺寸的极限偏差按GB/T 1804-92 m级. 6.未注形位公差按GB/T1184-96 H级. 7.去毛刺,未注倒角0.5x45%%D. ?技术要求(锻件) 1.未注锻造圆角半径为R1~R 2. 2.未注锻造斜度为1~1.5%%D,锻造公差为IT15级. 3.锻件组织应致密,不得有折叠、裂纹等缺陷,并去飞边. 4.去锐边毛刺,直角处倒钝. 5.未注公差尺寸的极限偏差按GB/T 1804-92 m级. 6.未注形位公差按GB/T1184-96 H级. 技术要求(活塞件) 1.未注公差尺寸的极限偏差按GB/T 1804-92 m级. 2.未注形位公差按GB/T1184-96 H级. 3.去毛刺,未注倒角0.5x45%%D. 4.表面磷化处理.
?技术要求(橡胶件) 1.零件表面应光洁.(模具表面粗糙度应在Ra0.4以上) 且不允许有气泡.杂技级凸凹等缺陷. 2.合模缝不允许错位,合模飞边的凸起级厚度不得大于0.02mm. 3.邵氏A型硬度65%%P5. 4.去净飞边. ?技术要求(塑料件) 1.成形前材料应预热干燥. 2.成形后制件应光整不得有扭曲变形现象. 3.未注圆角为R0.5. 4.外表面应光滑,其粗糙度不大于Ra0.4. 且不得有划伤,刻痕等缺陷. 5.未注尺寸公差按GB/T 1804-92 m级. ?技术要求(弹簧件) 1.旋向:左旋. 2.总圈数:no=12 3.工作圈数:no=10 4.钢丝硬度:HRC42~48. 5.表面氧化处理:H.Y.(俗称发黑) 6.单端并紧磨平.
汉译英 大坝dam 水轮机turbine or a hydraulic turbine 调压井suger tanks 变压器transformation 核能nuclear power 水斗叶片bucket 叶片,轮叶vane 喷射器,喷嘴injector 转轮runner 喷嘴nozzle 喷针needle 折向器deflector 调速器governor 气蚀,空化空蚀cavitation 围堰coffer dam 水头head 功率power 闸门gate 阀门valve 流量flow 转速revolving speed 压力钢管penstock 速度velocity 容量capacity 电枢armature 母线busbars 有功功率real power 无功功率reactive power 整流器commutator 集电环slipring 碳刷brushes 定子stator 转子rotor 磁极pole 继电器relay 断路器break 中控室control room 水锤water hammer 伺服电机servomotor 低电压low-tension 高电压high-tension 自动automatic 手动manual 变电站substation 调频regulation AGC automatic generation control 自动发电控制 A VC automatic voltage control 自动电压控制 RTU remote terminal units 远程控制单元 DCS distributed control System 分布式控制系统 SGC自动闸门控制 英译汉 Spillways溢洪道,泄洪道Open flumes开敞水槽 Canal渠道 Tunnel隧洞 Similarity laws相似理论 Model turbine efficiency模型水轮机效率 Prototype turbine efficiency原型水路机效率 Model turbine diameter模型水轮机直径 Prototype turbine diameter原型水轮机直径 Hill curves效率曲线 Rated output power额定出力 Rated power额定功率 Synchronous generators同步发电机 Induction generator异步发电机,感应发电机 Alternating current交流电 Direct current直流电 Excitation current励磁电流 Auxiliary generators测速发电机 Salient-pole凸级 Copper losses铜耗 Core losses铁芯损耗 Friction and windage losses摩擦风阻损失 The generation voltage发电机出口电压 Transmission voltage传输电压 Three-phase transformation三相变压器 Lagging current滞后电流 Leading current超前电流 Air gap空气间隙 Three-phase alternator三相交流发电机 Three-phase stator winding三相定子绕组 Exciting coil励磁线圈 Alternator terminals交流发电机终端 Main exciter主励磁机 Auxiliary equipment辅助设备 Governor oil pumps调速器油泵 Air compressors空气压缩机 Surface powerhouse地面厂房 Layout of a power station发电厂平面图 Section of a power station发电厂立面图 Trash rack slot拦污栅 Service valve slot检修阀门 Gantry crane龙门起重机 Ground wire接地线,避雷线 Amplifying devices放大装置 Hydraulic-mechanical governor机械液压型调速器 Electro-hydraulic type governor电气液压型调速器 Digital governor数字型调速器 Control error控制误差 Spinning reserve热备用 Regulations reserve调频备用 Processing modes控制模式 Master station主站 Operation consoles运行操作台 Local control level现地控制层 Remote control level远程控制层 英汉配对 1、 Hydraulic turbine水轮机 Impulse turbine冲击式水轮机 Velocity turbine流速式水轮机 Reaction turbine反击式水轮机 Pressure turbine压力式水轮机 2、 Head race引水渠 Tail race尾水渠 Inlet进水口 Conduit管道,水道 Storage reservoir蓄水库 Tail water pool尾水池 Head water pool前池 3、 Bucket水斗叶片 Nozzle喷嘴 V ane叶片,轮叶 4、 Earthfill dam土坝 Rockfill dam堆石坝 Gravity dam重力坝 Arch dam拱坝,拱形坝 Buttress dam支墩坝 Spillways溢洪道,泄洪道 5、 The spherical valve球阀 The butterfly valve蝶阀 The needle valve针型阀 Tube valve管阀 Hollow jet valve空心射流卸荷阀 Conical dispersion valve锥形分散阀 Dispersers分散器 6、 Vertical lift gates垂直提升式闸门 The sliding gates滑动式闸门 The fix-wheel gates固定轮闸门 Radial gates弧形闸门 Cylindrical gates圆筒形闸门 Draft tube gates尾水管闸门 7、 supporting frame支架 Shaft that transmits the rotating motion of the turbine轴 Exciter励磁机 Assembly of the built-up rotor转子组合装配 Rotor poles转子磁极 Collector rings and brushes or solid-state rectifiers集电环和 碳刷或者整流二极管 Stator and its component coils定子线圈 Stator coil supports定子线圈支架 Air cooler空气冷却器 Thrust bearing for vertical shaft machines推力轴承 Brake刹车 汉译英 大坝dam 水轮机turbine or a hydraulic turbine 调压井suger tanks 变压器transformation 核能nuclear power 水斗叶片bucket 叶片,轮叶vane 喷射器,喷嘴injector 转轮runner 喷嘴nozzle 喷针needle 折向器deflector 调速器governor 气蚀,空化空蚀cavitation 围堰coffer dam 水头head 功率power 闸门gate 阀门valve 流量flow 转速revolving speed 压力钢管penstock 速度velocity 容量capacity 电枢armature 母线busbars 有功功率real power 无功功率reactive power 整流器commutator 集电环slipring 碳刷brushes 定子stator 转子rotor 磁极pole 继电器relay 断路器break 中控室control room 水锤water hammer 伺服电机servomotor 低电压low-tension 高电压high-tension 自动automatic 手动manual 变电站substation 调频regulation AGC automatic generation control 自动发电控制 A VC automatic voltage control 自动电压控制 RTU remote terminal units 远程控制单元 DCS distributed control System 分布式控制系统 SGC自动闸门控制 英译汉 Spillways溢洪道,泄洪道 Open flumes开敞水槽 Canal渠道 Tunnel隧洞 Similarity laws相似理论 Model turbine efficiency模型水轮机效率 Prototype turbine efficiency原型水路机效率 Model turbine diameter模型水轮机直径 Prototype turbine diameter原型水轮机直径 Hill curves效率曲线 Rated output power额定出力 Rated power额定功率 Synchronous generators同步发电机 Induction generator异步发电机,感应发电机 Alternating current交流电 Direct current直流电 Excitation current励磁电流 Auxiliary generators测速发电机 Salient-pole凸级 Copper losses铜耗 Core losses铁芯损耗 Friction and windage losses摩擦风阻损失 The generation voltage发电机出口电压 Transmission voltage传输电压 Three-phase transformation三相变压器 Lagging current滞后电流 Leading current超前电流 Air gap空气间隙 Three-phase alternator三相交流发电机 Three-phase stator winding三相定子绕组 Exciting coil励磁线圈 Alternator terminals交流发电机终端 Main exciter主励磁机 Auxiliary equipment辅助设备 Governor oil pumps调速器油泵 Air compressors空气压缩机 Surface powerhouse地面厂房 Layout of a power station发电厂平面图 Section of a power station发电厂立面图 Trash rack slot拦污栅 Service valve slot检修阀门 Gantry crane龙门起重机 Ground wire接地线,避雷线 Amplifying devices放大装置 Hydraulic-mechanical governor机械液压型调速器 Electro-hydraulic type governor电气液压型调速器 Digital governor数字型调速器 Control error控制误差 Spinning reserve热备用 Regulations reserve调频备用 Processing modes控制模式 Master station主站 Operation consoles运行操作台 Local control level现地控制层 Remote control level远程控制层
家具英语词汇 3-section mirror 三面梳妆镜 Adjustable bed 可调床 Air bed 气床 altar 供桌( (教堂内的)圣坛,祭坛;(基督教教堂内的)圣餐台) ancient folding chair 高背椅 Anti-slip strip for stairs 楼梯防滑条 armchair 扶手椅;高背椅;帆布椅;单人沙发 armoire 雕饰衣柜(装潢精美之大衣柜) baby chair 婴儿座椅 crib 婴儿床 crib tent 有帐婴儿床 Backless wall-unit 不设背板的壁橱 back-rest chair 可翻动椅 banquet/banqueting chair 宴会椅 banquet/banqueting table 宴会桌 bar stool 吧椅;酒吧高脚凳 Bathroom combination 浴室组合柜 Bathroom consoles 浴室多用架 Bathroom vanity 浴室盥洗台 beauty(/dressing) case 女用化装箱 bed 床 bedside screen 床边屏风 bedside table;night table;bedside cupboard;beside table;nightstand 床头柜bench 长凳(条凳) Board-room table 会议桌 boisseries (具西方古典风格的家具,可放电视机、书和装饰陈列品等)bookcase 书橱、书架 Bookshelf 书架 bookslide 活动书架 built-in cupboard(/cabinet) 壁橱/壁柜 Bunk (车、船等倚壁而设常有上、下铺的)架式床铺,铺位 Bunk bed 两张或三张单人床叠架设置,通常有扶梯 bureau 五斗柜/五斗橱 bureau with mirror 有镜衣柜;五斗柜;梳妆台(美);写字台,书桌(英)Cabin bed 儿童多功能床 Cabin furniture for ships 船用家具 cabinet for cleaning-tools 清扫用具柜 camp bed(/cot) 行军床;帆布床 Canopy bed 带天篷的床,四柱床 car bed 可携式童床 CD-video storage cabinet 音响组合柜 chair 椅子(通常指单人用的) chair bed 坐卧两用椅
机械制图工程图技术要求综合汇总 一、机械零件常用技术要求: 1、锐角倒钝、去除毛刺飞边。 2、零件去除氧化皮。 3、未注圆角半径R5。 4、未注倒角均为2×45°。 5、未注形状公差应符合GB1184-80的要求。 6、未注长度尺寸允许偏差±0.5mm。 7、零件加工表面上,不应有划痕、擦伤等损伤零件表面的缺陷。 8、精加工后的零件摆放时不得直接放在地面上,应采取必要的支撑、保护措施。加工面不允许有锈蛀和影响性能、寿命或外观的磕碰、划伤等缺陷。 9、加工的螺纹表面不允许有黑皮、磕碰、乱扣和毛刺等缺陷。 二、铸件技术要求: 1、铸件表面上不允许有冷隔、裂纹、缩孔和穿透性缺陷及严重的残缺类缺陷(如欠铸、机械损伤等)。 2、铸件应清理干净,不得有毛刺、飞边,非加工表面上的浇冒口应清理与铸件表面齐平。 3、对错型、凸台铸偏等应予以修正,达到圆滑过渡,一保证外观质量。 4、铸件非加工表面上的铸字和标志应清晰可辨,位置和字体应符合图样要求。 5、铸件非加工表面的粗糙度,砂型铸造R,不大于50μm。 6、铸件应清除浇冒口、飞刺等。非加工表面上的浇冒口残留量要铲平、磨光,达到表面质量要求。 7、铸件上的型砂、芯砂和芯骨应清除干净。 8、铸件有倾斜的部位、其尺寸公差带应沿倾斜面对称配置。 9、铸件上的型砂、芯砂、芯骨、多肉、粘沙等应铲磨平整,清理干净。 10、铸件公差带对称于毛坯铸件基本尺寸配置。 11、铸件非加工表面的皱褶,深度小于2mm,间距应大于100mm。 12、机器产品铸件的非加工表面均需喷丸处理或滚筒处理,达到清洁度Sa2 1/2级的要求。 13、经喷丸或手工除锈的待涂表面与涂底漆的时间间隔不得多于6h。 14、铸件表面应平整,浇口、毛刺、粘砂等应清除干净。 15、铸件不允许存在有损于使用的冷隔、裂纹、孔洞等铸造缺陷。 16、所有需要进行涂装的钢铁制件表面在涂漆前,必须将铁锈、氧化皮、油脂、灰尘、泥土、盐和污物等除去。 17、除锈前,先用有机溶剂、碱液、乳化剂、蒸汽等除去钢铁制件表面的油脂、污垢。 18、铸件必须进行水韧处理。 19、铆接件相互接触的表面,在连接前必须涂厚度为30~40μm防锈漆。搭接边缘应用油漆、腻子或粘接剂封闭。由于加工或焊接损坏的底漆,要重新涂装。 20、每个钢锭的水口、冒口应有足够的切除量,一以保证锻件无缩孔和严重的偏折。 三、热处理要求: 1、经调质处理,HRC50~55。 2、零件进行高频淬火,350~370℃回火,HRC40~45。 3、渗碳深度0.3mm。
1.开口系统:与外界既有物质交换又有能量交换,把研究对象控制在某个空间。---定容积系统 An Open system (or a control volume 控制体积)is a properly selected region in space. Both mass and energy can cross the boundary of a control volume. such as, A Water heater, a turbine and a compressor, etc 2.闭口系统:系统与外界只有能量(功量、热量)的交换而无质量交换。——定质量系统A Closed system (a control mass 控制质量) consists of a fixed amount of mass, and no mass can cross its boundary. That is, no mass enters or leave a closed system. such as, Piston-cylinder device (汽缸-活塞装置) 3.绝热系统:系统与外界只有功量和质量的交换,而无热量的交换。Adiabatic system is that no heat cross the boundary or heat is negligible compared with work cross the boundary 4.孤立系统:系统与外界既无能量交换又无质量交换,即系统与环境不发生任何作用。Isolated system is a special case that no mass and energy cross the boundary. 5.热力学第一定律:自然界一切物体都具有能量,能量有各种不同形式,它能从一种形式转化为另一种形式,从一个物体传递给另一个物体,在转化和传递过程中能量的总和不变。 The first explicit statement of the first law of thermodynamics:"In all cases in which work is produced by the agency of heat, a quantity of heat is consumed which is proportional to the work done; and conversely, by the expenditure of an equal quantity of work an equal quantity of heat is produced." 6.热力学第二定律:不可能把热从低温物体传到高温物体而不产生其他影响;不可能从单一热源取热使之完全转换为有用的功而不产生其他影响;不可逆热力过程中熵的微增量总是大于零。 Second law of thermodynamics: Impossible to heat from low temperature to high temperature object object does not produce other effects; not possible from a single heat source heat so completely converted into useful work and does not produce other effects; irreversible thermodynamic entropy in the process of the incremental volume is always greater than zero. 7.锅炉:锅炉利用热量使水转变成蒸汽以进行各种利用。 Boilers use heat to convert water into steam for a variety of applications. 8.汽轮机:将蒸汽的热能转换为机械能的叶轮式旋转原动机。 Steam Turbine is the impeller rotating prime mover that the thermal energy of the steam is converted to mechanical energy 。 9.省煤器:省煤器(英文名称Economizer)就是锅炉尾部烟道中将锅炉给水加热成汽包压力下的饱和水的受热面。The economizer (Name Economizer) is the rear of the boiler flue of the boiler feed water is heated into steam drum pressure saturated water heating surface。 10.空预器:空气预热器就是锅炉尾部烟道中的烟气通过内部的散热片将进入锅炉前的空气预热到一定温度的受热面。 The air preheater through the fins of the internal heating surface will enter the air is preheated to a certain
常用家具英文翻译: A Adjustable bed 可调床 Air bed 气床 Anti-slip strip for stairs (儿童床)防滑楼梯打击扶手Antique furniture 古式家具 Antique reproduction furniture 仿古家具 Armchair 扶手椅 B Baby crib 婴儿床 Backless wall-unit 不设背板的壁橱 Bamboo furniture 竹家具 Banqueting chair 宴会椅 Barstool 吧椅 Bathroom accessories 浴室配套装置 Bathroom combination 浴室组合柜 Bathroom consoles 浴室多用架 Bathroom furniture 浴室家具 Bathroom vanity 浴室盥洗台 Batten door 板条门 Bed base床架,床套 Bed base set 成套床架 Bedroom suite 卧室系列家具 Bedstead 床架 Bentwood furniture 曲木家具 Beside table 床头柜 Birch door 桦木门 Board-room and conference table 会议桌Bookcase 书柜 Bookshelf 书架 Built-in kitchen 配套厨房家具 Bunk 双层床 Bunk bed 双层床 C Cabin bed 儿童多功能床 Cabin furniture for ships 船用家具 Canopy bed 带天篷的床,四柱床 CD-video storage cabinet边音响组合柜 Chair with castors 脚轮椅
Enhancement of Forced Convection Heat Transfer Rongzhen You Class 1202 of Power Engineering In my College Students Innovative Project, we are supposed to adopt some methods to enhance the forced convection heat transfer on the plain surface. Although we have taken several technical methods into consideration, most of them are too difficult for us to apply in our project. Therefore, I would like to make an introduction to these methods here. Firstly, machining some grooves or dimples on the plain plates is one of important methods to enhance the convection heat transfer. The grooves or dimples can change the flow field of the fluid near the surface, for which the fluid would be turbulent than before. In this way, the Nusselt number of the near surface fluid would be raised, and than the convection heat-transfer coefficient would increase. This method can enhance the convection heat transfer on the plain plate to some extent, but it’s still ineffective for the reason that the improvement of heat-transfer coefficient of the fluid in the near wall region can not enhance the heat-transfer of the mainstream. Secondly, some researchers come up with an idea that using spiral fine ribs (SFRs) in plate channel to enhance the convection heat transfer. They equally placed the SFRs in the channel, which can form a packing layer resembling a kind of quasi-porous media with large porosity and can produce efficient disturbance both to the boundary layer and the mainstream. The operation principle of SFRs is that the multi-longitudinal vortices induced by SFRs can significantly increase the tangential velocity components in the cross section, which is helpful to promote the micro-fluctuation in the fluid. What’s more, the transport action caused by the longitudinal vortices can improve the mass exchange between the boundary layer and the mainstream. These two factors can not only speed up the heat migration from the channel walls, but also enhance the heat diffusion in the mainstream. This improves the temperature distribution uniformity in channel. Thirdly, the most efficient way to enhance the convection heat transfer is installing fins on the plain plate. Base on this thought, some researchers have fabricated many different types of fins, such as columned pin fins, conical pin fins, elliptical pin fins, cross-cut pin fins and longitudinal vortex generator arrays (LVG). Nowadays, fins with geometric shape pins have been commonly used to in the engineering. As for the vortex generator, it can disturb the flow field by the vortex and generate vortex after the generator, which can break the boundary lay on the surface and transfer the heat into mainstream quickly. Nowadays, many researchers have proved that the LVG effect is much better than the straight fins within a certain limit of Reynolds number, as well as that the multi rows LVG can improve the whole heat transfer effect. The methods mentioned above sounds pretty advanced, but it’s quiet difficult for us, regular college students, to apply these methods in our project. Because we couldn’t analysis the complex flow field in these special structure, unless we use the FLUENT software to build up their mathematic model. As the advanced usage of FLUENT is out of our ability, we have no choices but to install the straight fins on the heat transfer surface. Some researchers have found that the overall thermal resistance of straight fins is lower than other geometric pin fins, due to the combination effect of enhanced later conduction along the fins and the lower flow bypass characteristics. At last, our experiment also proved that the straight fin can meet the requirement of the enhancement of forced convection heat transfer.
