诺基亚手机CPU频率一览表诺基亚手机CPU频率一览诺基亚手机（CPU）频率一览转的有兴趣，就看看，毕竟明白下自己爱机的CPU类型型号类型处理器类型架构频率Nokia 3230 RM-51 32-bit RISC CPU ARM-9 123 MHz ;Nokia 3600 NHM-10 32-bit RISC CPU ARM-9 104 MHz Nokia 3620 NHM-10(X) 32-bit RISC CPU ARM-9 104 MHz 'Nokia3650 NHL-8 32-bit RISC CPU ARM-9 104 MHzNokia 3660 NHL-8X 32-bit RISC CPU ARM-9 104 MHzNokia 6260 RM-25 32-bit RISC CPU ARM-9 123 MHzNokia 6600 NHL-10 32-bit RISC CPU ARM-9 104 MHz Nokia 6620 NHL-12 32-bit RISC CPU ARM-9150 MHzNokia 6630 RM-1 TIOMAP 1710 ARM-926 220 MHzNokia 6670 RH-67 32-bit RISC CPU ARM-9 123 MHzNokia 6670B RH-68 32-bitRISC CPU ARM-9 123 MHzNokia 6680 RM-36 TI OMAP1710 ARM-926 220 MHzNokia 6681 RM-57 TI OMAP1710 ARM-926 220 MHzNokia 6682 RM-58 TI OMAP1710 ARM-926 220 MHzNokia 7610 RM-51 32-bitRISC CPU ARM-9 123 MHzNokia 7610B RH-52 32-bitRISC CPU ARM-9 123 MHzNokia 7650 NHL-2(NA); 32-bitRISC CPU ARM-9 104 MHzNokia 770 SU-18 TI OMAP 1710 ARM-926 220 MHzNokia 7710 RM-12 32-bitRISC CPU ARM-9 150 MHzNokia 9210 RAE-3(N); 32-bitRISC CPU ARM-9 52 MHzNokia 9210c RAE-3(N); 32-bitRISC CPU ARM-9 52 MHzNokia 9210i RAE-5(N); 32-bitRISC CPU ARM-9 52 MHzNokia 9290 RAB-3(N); 32-bitRISC CPU ARM-9 52 MHzNokia 9300 RAE-6(N); TI OMAP1510 ARM-925 150 MHNokia 9300B RA-4 TI OMAP1510 ARM-925 150 MHzNokia 9300i RA-8 TI OMAP 1510 ARM-925 150 MHNokia 9500 RA-2 TI OMAP 1510 ARM-925 150 MHzNokia 9500B RA-3 TI OMAP1510 ARM-925 150 MHzNokia E50-1 RM-170 TI OMAP1710 ARM-926 220 MHzNokia E50-2 RM-171 TI OMAP 1710 ARM-926 220 MHzNokia E60 RM-49 TI OMAP 1710 ARM-926 220 MHzNokia E61 RM-89 TI OMAP 1710 ARM-926 220 MHNokia E62-1 RM-8 TI OMAP 1710 ARM-926 220 MHzNokia E62-1 RM-8A TI OMAP 1710 ARM-926 220 MHzNokia E70-1 RM-10 TI OMAP1710 ARM-926 220 MHzNokia E70-2 RM-24 TI OMAP 1710 ARM-926 220 MHzNokia N-Gage NEM-4 32-bit RISCCPU ARM-9 104 MHzNokia N-Gage QD RH-29 32-bitRISC CPU ARM-9 104 MHzNokia N-Gage QDA RH-47 32-bit RISC CPU ARM-9 104 MHzNokia N70-1 RM-84 TI OMAP1710 ARM-926 220 MHzNokia N70-5 RM-99 TI OMAP1710 ARM-926 220 MHzNokia N71-1 RM-67 TI OMAP1710 ARM-926 220 MHzNokia N71-5 RM-112 TI OMAP1710 ARM-926 220 MHz ,Nokia N72-5 RM-180 TI OMAP1710 ARM-926 220 MHzNokia N73-1 RM-133 TI OMAP1710 ARM-926 220 MHzNokia N73-? RM-132 TI OMAP1710 ARM-926 220 MHzNokia N80-1 RM-92 TI OMAP1710 ARM-926 220 MHzNokia N80-3 RM-91 TI OMAP1710 ARM-926 220 MHzNokia N90-1 RM-42 TI OMAP 1710 ARM-926 220 MHzNokia N91-1 RM-43 TI OMAP1710 ARM-926 220 MHzNokia N91-5 RM-158 TI OMAP1710 ARM-926 220 MHzNokiaN92 TI OMAP 1710 ARM-926 220 MHzNokia N93-1 RM-55 TI OMAP2420 ARM-11 330 MHzNokia N93-5 RM-153 TI OMAP2420 ARM-11 330 MHz解密NOKIA最新两代手机CPU的玄机以N95/6120C等为例大家也明白NOKIA最近新出的手机比如 N76，5700，6120C等是越来越便宜，最便宜的6210的水货价格甚至1.５K，而且配置上感受越来越高。

中星9号接收机各厂家芯片资料大全和升级接口品牌产品型号芯片配置海尔 2晶10芯 IC:HI2023E+1108+5812海尔高清OST-666 2晶6芯 IC:M88VS2000+241674K.1+M88TS2020海尔高清OST-666 3晶12芯 IC:High032E+His121+M88TS2020海尔 3晶10芯 (9针接口) IC:HI2023E+1108+5812+ESMTM12L64164A-GNR1T80AB海尔高清OST-666 2晶6芯 IC:Hi2023E+3160+TS2020欧视达ABS-209B 3晶10芯 IC:GX3001+GX1121+LW37欧视达ABS-209B 3晶11芯 IC:GX3001+5037+8211欧视达ABS-309B 3晶11芯 IC:GX3001+GX1121+MGCE5037欧视达AS-900S 1晶11芯 IC:GX6121+25L80+LW37城市之宝BEX868 Y32S-93AT 2晶10芯 IC:HTV903F+AVL1108+TS2020通达Y35S-8BAT/Y35S-8CAT 2晶10芯 IC:HTV903+AVL1108+5812通达Y30S-01BT 2晶12芯 IC:HTV903+AVL1108+2020皇朝HSR-268 10芯 IC:Hi2023+AVL1108+5812小霸王TDX-668E ABS-S1 1晶 6芯 IC:Hi2023+Hi3102+FT8211+HT1117天地星小霸王TDX-328B 1晶10芯 IC:ALi M3328F+5810天地星小霸王TDX-668A (9针接口) IC:HI2023+1108+夏普头天地星小霸王TDX-668B 2晶振 IC:HTV903+AVL1108EGA+RDA5812+25L8005天地星小霸王(三星数码王)TDX-668B 单晶6芯 .针脚定义①-TXD ②-RXD ③ VCC ④-GND ⑤-BL IC:Hi2023E+RDA5812+AVL1108E+MXT8211a+25L8005天地星（原大盒中星九号）3晶 IC:Hi2023+1108+5037天地星TDX-668B 2晶10芯 IC:Hi2023+AVL1108+5812天地星小霸王TDX-668C 2晶 6芯 IC:HTV903+AVL1108EGA+RDK5812+25F80小霸王TDX-328B 1晶10芯 IC:ALi M3328F+5810小霸王TDX-668B 6芯 IC:Hi2023+RDA5812+AVL1108E小霸王TDX-668B 2晶 6芯 IC:HTV903+1108+5812小霸王TDX-668E 1晶 6芯 IC:Hi2023EC+Hi3121+5812小霸王TDX-668E 2晶 6芯 IC:HTV903+1108+5812小霰王XC-B298 1晶 12芯 IC:HTV903-RDA5812-AVL1108小霸王ABS-1388 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+Hi3121+AV2020小霸王ABS-1688 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+Hi3122E+5812小霸王GF902 IC:AVL1118a+AV2020+EN25F80索尼高清ABS-S 258 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+Hi3122E+5812索尼高清ABS-S 258 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi3102E+Hi2023EC+AV2020太阳红TYH-279ABS/289ABS/299ABS 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+H i3121+AV2020松下科技星TDX-668B1/松下科技星-668E IC:Hi3102E+Hi2023EC+5812松下科技星TDX-668B 2晶6芯 IC:HTV903FH42+AVL1108EGA+RGK5812松下科技星668B 2晶6芯 Hi2023(E0908)+EVl1108EG2+5812松下科技星-668C 2晶 6芯针脚定义①-RX .②-TX .③-GND .④ VCC. ⑤-BL IC:AVL1108EG+HTV903F+5812松下科技星668E 2晶6芯 IC:HV903+AVL1108E+5812松下科技星/海尔数码/海信数码单双晶 6芯 IC:Hi2023E+Hi3102(Hi3121)+5812松下科技星TDX-668B 2晶 6芯针脚定义①-RXD .②-TXD .③-GND .④ VCC. ⑤-BL IC:Hi2023+AVL1108+5812+25L8005 松下高清 SX168 3晶 6芯 IC:HTV903F+AVL1108+AV2020松下数码王P-269A 2晶 6芯 IC:Hi2023E+Hi3122+AV2020松下高清OST168 2晶10芯 IC:Hi2023E+Hi3121+AV2020松下科技PS-228 11芯 IC:Hi2023+Hi3122+5812松下科技PS-228 2晶 6芯 IC:M88VS2000+M88TS2020+ES261474K松下科技PS-228 1晶12芯 N88VS2000+ES261344K+M88TS2020高频头+T25P80+S163816STS 松下科技PS-228 2晶 IC:HTV903+1108+2020松下科技PS-228 2晶 10芯 IC:GX3001+GX1211+5812松下数码王OST-266 10芯 (4针)针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023E+Hi3106+2020松下数码王OST-266 2晶 6芯 IC:M88VS2000+M88TS2020+261414k+25F80松下数码王OST-266 2晶 6芯 IC:Hi2023E+Hi3102E+ M88TS2020+MXT8211松下高清OST-466 2晶10芯 IC:Hi2023e+Hi3121+MBBTS2020+MBDA80CG松下科技星 3晶 6芯 IC:Hi2023+AVL1108+WGCE5037松下科技星.海尔数码.海信数码单双晶+6芯 IC:Hi2023E+Hi3102(3121)+5812中星科技单晶14芯 IC:Hi2023E+1108+5812+25L8单晶14芯中星科技ZG-N02 12芯 IC:GX3001+AV2020中星科技 2晶 10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+Hi3102E+5812+M12L64164A中兴科技ABS-S323 2晶 10芯 IC:Hi2023EC+HI3102E+5812+M12L64164A村村通ABS-S323- 2晶10芯针脚定义①-GND ②-RXD ③-TXD ④ VCC IC:Hi2023EC+Hi3122E+5812村村通 2晶6芯 IC:HN4+0001+5812村村通ZL5188 1晶13芯 IC:HTV903+1108+SHARP高频头村村通ZL-5188A 2晶11芯 IC:HTV903+AVL1108+RDK5812村村通ZL-5188B 2晶13芯 IC:HTV903+AVL1108+RDK5812村村通ZL-5188B 2晶10芯 IC:HTV903+AVL1108EGA+5812村村通ZL5188B 1晶13芯 IC:HTV903+AV1108+SHARP6306村村通ZJ-11 IC:HTV903+1108+夏普头S7ZH6306村村通wx-666 3晶10芯 IC:GX3001+GX1121+RDK5812村村通ZL-6188 2晶10芯 IC:HTV903+AVL1108EGA+5812村村通ZL-6188C 10芯 IC:GX3001+GX1121+RDK5812村村通DTH(铁壳) 3晶12芯 IC:AVL1108EG+HTV903F+AV2020村村通001 3晶10芯 IC:GX3001+GX1121+RDK5812村村通ABS-S GD-1008 3晶10芯 IC:Hi2023E+AVL1108E+ZL10037+F16-100HIP村村通 ABS-S888A IC:Hi2023EC+Hi3121+ET8211+RDA5812+25X80视美人ABS-S PS-1288 2晶10芯 IC:Hi3102E+Hi2023EC+AV2020视美人PS-1288 ICM88VS2000+ES256454K+M88TS2020视美人 2晶10芯 IC:Hi2023+3106+AV2020太平鸟HJ321 3晶10芯针脚定义①-GND .②-RXD .③-TXD .④ VCC IC:GX3001+GX1121+TS2020太平鸟HJ321 3晶11芯 IC:GX3001+GX1121+5812焦点yj5888 2晶10芯 IC:HTV903+AVL1108+RDA5812幸运之星YJ5988 2晶 10芯 IC:HTV903F+AVL1108EGa+AV2020克莱尔HT701 1晶10芯 IC:AVL1108EG+HTV903F+M88TS2000中电电子J-6288 ABS-S 3晶12芯 IC:GX3001+GX1121+5812小福星 3晶 11芯针脚定义①-GND .②-(空) .③-RXD .④-TXD (） IC:GX3001+GX1121+5812 东仕DIS-2000K 单晶10芯 IC:HTV903F+AVL1108E+AV2020Souy Ericsson英文机 2晶10芯 IC:GX3001+GX1121+AV2020高斯贝尔/歌德威尔ABS-208F 3晶14芯针脚定义①-GND .②-TXD .③-RXD .④ VCC .⑤-BL IC:AVL1108EG+Hi2023+5812高斯贝尔ABS-208 1晶 14芯 (5针).针脚定义①-GND .②-TXD .③-RXD .④ VCC .⑤-BL IC:AVL1108EG+Hi2023+5812歌德威尔ABS-208H/高斯贝尔208P 3晶14芯针脚定义①-GND .②-TXD .③-RXD .④ VCC IC:M3330E+AVL1108EG+AV2020+M12L64164高斯贝尔ABS-208P/歌德威尔208H 1晶14芯针脚定义①-GND .②-TXD .③-RXD .④ VCC .⑤-BL IC:AVL1108EGi+Hi2023+5812高斯贝尔ABS-208P/歌德威尔208H 1晶14芯针脚定义①-GND .②-TXD .③-RXD .④ VCC IC:M3330E+AVL1108EG+AV2020+M12L64164A高斯贝尔ABS—208F IC:Hi2023+AVL1108EGA+M88TS2020高斯贝尔ABS—208 2晶 14芯 IC:HTV903+1108+5812吉祥ABS-208C IC:Hi2023+AVL1108EGa+GST GAIM-18R ABS-STUNER吉祥ABS-2009B 3晶 14芯 IC:GX3001+GX1121+RDK5812吉祥ABS-2009大铁壳 2晶 IC:GX3001+GX1121+夏普高频头ABS-2009 2晶 12芯 IC:HTV903+1108+GAIM-18R歌德威尔ABS-208 3晶 6芯 IC:D61216GJ+1108+5812歌德威尔ABS-208 3晶 14芯 (9针接口) IC:M3330+1108+5812高斯贝尔ABS-208 3晶 (9针母串口) IC:AVL1108+Hi2023+GAIM-18RIC:D61216GJ100+AVL1108EG+S29AL016D70TF102+ISSI高斯贝尔ABS-208N 铁壳(9针母串口) IC42s16400F高斯贝尔ABS-208 IC:D61216GJ+A V1108+29AL016D+5812高斯贝尔ABS-208S 1晶IC:NEC D61216GJ+A VL1108EGa+高频头高斯贝尔ABS-208Q 1晶14芯IC:A VL1108EGA+M3330E+M12L64164A+A V2020ABS-S LX-3688A 1晶12芯IC:GX3001+GX1121+5812现代V4、V5 3晶9芯IC:GX3001+GX1121+5812+EN25D80+HY57V641620ETP-6集信科技V6铁壳(海尔机芯) 3晶9芯针脚定义①VCC .②-TXD .③-RXD .④-GND IC:1108EG(Hi3121)+Hi2023+5812.集信科技V4.V6(铁壳) 2晶9芯( B型)针脚定义① VCC .②-RXD .③-TXD .④-GND IC:0001(GX3001)+HN4F74+5812集信科技V4 .V6(铁壳) 2晶10芯针脚定义①VCC. ②-RXD .③-TXD .④-GND IC:00001(GX3001)+HN4LSW+S6416AHTA+5812 集信科技V4.V6(铁壳) IC:HN4LSW+S6416AHTA-6BZH+EN25F80-1000CP+5812集信科技V4.V6(铁壳) IC:0002P1M43700ta06+5812+EN25F80+TM8211+POL4558集信科技V4.V5 1晶10芯(A型)针脚定义①VCC .②-RXD .③-TXD .④-GND IC:0002(GX6121)+5812+M12L64164A艾雷特2晶10芯IC:M88VS2000+ES256454K+M88TS2020艾雷特V5 IC:HN4F910931M2EE+0001G1K729-1TA060932+5812艾雷特ALT5812 IC:GX3001+GX1121+5812艾雷特ALT600A 2晶11芯IC:M3330E+A VL108的+夏普高频头艾雷特ALT600A/吉祥ABS-2009 2晶IC:GX3001+GX1121-ES29L160FB+SHARP高频头艾雷特ALT600G IC:HTV903+A VL1108+25L160+ST2020(Y32S-8BA T 081113)艾雷特ALT6812 1晶10芯IC:GX6121+RDA5812+ZB-1A艾雷特ALT6815 1晶10芯IC:GX6121-RDA5812-2B-1A艾雷特ALT7815 3晶10芯IC:GX3001+1121+TS2020艾雷特1000 黑珍珠V4.V5 1晶10芯IC:0002(GX6121)+EEPLDA+5812+M12L64164A 艾雷特alt 7812 3晶10芯IC:GX3001+GX1121+5812艾雷特ALT7812 3晶11芯针脚定义①VCC .②-RXD .③-TXD .④-GND IC:GX3001+GX1121+5812艾雷特ALT600c 2晶10芯IC:GX3001+GX1121+5812艾雷特ALT600c 2晶11芯IC:GX3001+GX1121+5812艾雷特ALT600c 1晶11芯IC:CH216H+A VL1108+C6XS-8CA深圳亿通DVB-V5 10芯IC:HN4N46+EN25F80+G1N540-1TA06+IS42S16400-7T+5812亿通电子WS-3688ZL 1晶10芯IC:Hi2023EC+Hi3102E+A V2020中大WS-3688ZJ (铁壳) 1晶10芯针脚定义①-GND .②-RXD .③-TXD .④VCC IC:Hi2023EC+Hi3102E+A V2020中大WS-3688ZJ (铁壳) 2晶10芯IC:Hi2023+A VL1108EG+夏普高频头皇视HSR-208A 2晶10芯IC:Hi2023E+A VL1108EG+A V2020皇视HSR-208B 2晶10芯IC:Hi2023+1108+2020皇视HSR-208B 单晶10芯IC:3330+1108+2020皇视HSR-208B 单晶10芯针脚定义①-GND ②-TXD ③-RXD ④-VCC IC:Hi2023EC+Hi3102+A V2020皇视HSR-2090 2晶11芯IC:Hi2023+1108EGa+夏普头++EN29LV160皇视HSR-210A 单晶6芯IC:Hi2023ec+Hi3122e+A V2020皇视HSR-260A 铁盒2晶10芯IC:Hi+1108+SHARP夏普头皇视HRS-268 3晶10芯IC:Hi2023EC+Hi3102E+A V2020皇视HRS-268 2晶10芯IC:Hi2023EC+Hi3121+5812皇视HSR-268 单晶10线IC:HTV903+A VL1108+5812皇视HSR-268 单晶10线IC:Hi2023+Hi3121+A V2020皇视HRS-268 3晶10芯IC:Hi2023EC+A VL1108+5812皇视HSR-260B 3晶10芯IC:Hi2023+1108+2020皇视HSR-260B/索尼高清258 1晶10芯IC:2023E+3121+A V2020皇视HSR-260B 3晶10芯IC:HI2023+1108+5812皇朝HSR-268 10芯IC:Hi2023+A VL1108+5812凯恩斯KES-2066S 6芯针脚定义①-TXD .②-RXD .③VCC .④-GND .⑤-BL IC:Hi3122E+Hi2023ECE+N25F80 凯恩斯KES-2077Z 1晶6芯针脚定义①-TXD .②-RXD .③VCC .④-GND .⑤-BL IC:Hi2023EC+3122E+5812凯恩斯2077ABS 2晶10芯IC:M3330+A VL1108+5812凯恩斯2077ABS 2晶10芯IC:Hi2023+1108E+5812+25L800凯恩斯KES-2088S 2晶6芯IC:Hi2023EC+HI3102E+RDA5812凯恩斯KES-2088S 2晶10芯IC:Hi2023EC+HI3102E+RDA5812凯恩斯KES-2088S 2晶6芯针脚定义①-TXD .②-RXD .③VCC .④-GND .⑤-BL IC:Hi2023EC+HI3122E+RDA5812 凯恩斯KES-2088Z (5针).针脚定义①-TXD .②-RXD .③VCC .④-GND .⑤-BL IC:Hi2023EC+HI3102E+RDA5812 凯恩斯KES-2099S 2晶6芯IC:Hi2023EC+Hi3102E+5812+25L80凯恩斯KES-2188T 3晶10芯IC:Hi2023+1108+5812凯恩斯KES-2188T 3晶12芯IC:Hi2023+1108E+5037凯恩斯KES-2288S 3晶10芯IC:M3330E+A VL1108+RDA5812+M12L64164A凯恩斯KES-2688b 2晶10芯IC:Hi2023e+1108e+5812凯恩斯KES-2688S 2晶10芯IC:Hi2023e+1108e+5812凯恩斯KES-2788S 3晶10芯IC:Hi2023E+A VL1108EGa+5812凯恩斯KES-2788S 2晶6芯IC:Hi2023EC+Hi3122E+5812凯恩斯KES-5188 11芯IC:HTV903+A VL1108EGA+A V2020凯恩斯KES-5188A铁盒2晶10芯IC:HTV903F+A VL1108+RDK5812+F80+PT8211凯恩斯KES-5188B 2晶13芯IC:HTV903+RDA5812+A VL1108+8211+F80美路3晶13芯IC:Hi2023E+1108+2119美路2晶12芯IC:GX3003+GX1121+5812美路MR-1809 IC:Hi2023E+A VL1108E+高频头MAX2119C美路MR-5598铁壳3晶12芯IC:GX3003+GX1121+5812美路MR-5598 3晶12芯针脚定义①VCC. ②-RXD .③-TXD .④-GND IC:Hi2023E+1108+2119C美路-5798 IC:Hi2023E+1108+2119C美路-5598 IC:Hi2023+1108+GAIM-18R+29lv160ZY 5518A 2晶10芯IC:Hi2023E+3102E+5812万利达ZY-5518A 1晶6芯((5针)) IC:Hi2023E+Hi3102E+5812万利达ZY-5518A 2晶10芯IC:CX3001+GX1121+5812万利达ZY-5518A 3晶10芯(9针接口) IC:Hi2023+1108+5812长虹新一代3晶10芯IC:HI2023E+1108E+FL016ALF长虹新一代，海尔数码、海信数码单双晶体6芯IC:HI2023E+3102(3121)+5812长虹数码CH930 3晶12芯IC:HTV903F+1108+A V2020+M80长虹精品TC-6688ABS 2晶10芯IC:HTV903+A VL1108EG+5812长虹精工YJ5978 1晶10芯IC:HTV903F+1108EGa+2000+F80-100+8211长虹KES-2099S 2晶5芯IC:Hi2023+Hi3102E+5812长虹KES 2晶6芯IC:Hi2023+Hi3102+5812长虹CH920 3晶6芯IC:HTV903F+1108EGa+A V2020+25L80航天天信WTD198J 2晶12芯(9针接口) IC:GX3001+GX1121+5812+ES29LV160FB-70TG 航天珠江WTD-198J 2晶12芯IC:GX3001+GX1121+5812航天珠江ABS-209B IC:GX3001+GX1121++WGSE5037航天数码ABS-3809 2晶12芯IC:GX3001+GX1121+5812航天直播HT-168 3晶12芯IC:Hi2023+1108+夏普头航天高清王-HS-166 2晶12芯IC:Hi2023EC+Hi3102E+RDA5812航天高清王HS-169 2晶12芯针脚定义①-GND .②-TX .③-RX .④-VCC IC:Hi2023EC+3122+5812天诚TCD-219 2晶10芯IC:Hi2023EC+Hi3121+5812天诚TCD-219ABS 2晶10芯IC:M3330E+A VL1108EGA+5812天诚TCD-299Z 2晶10芯IC:Hi2023+3206+5812天诚TD-299Z 2晶5芯IC:Hi2023+3206+5812天诚TD-2992 2晶6芯IC:Hi3122E+Hi2023E+5812+F80+MXT8211天诚539 2晶10芯IC:HTV903+A V1108+5812天诚519型2晶10芯IC:HTV903+1108E+5812天诚TCD-239ABS 3晶10芯IC:M3330+1108+5812天诚TCD-239ABS 2晶10芯IC:Hi2023+1108E+5812天诚TCD-239 2晶10芯IC:M3330E+1108E+5812天诚TCD-279 2晶10芯IC:Hi2023EC+Hi3102E+5812天诚TCD-299ABS 2晶10芯IC:Hi2023EC+Hi3121+5812天诚TCD-319ABS 3晶10芯IC:Hi2023E0914+A VL1108EGa+RDA5812天诚TCD-319ABS 3晶12芯IC:Hi2302+A VL1108+5037天诚TCD-369ABS 3晶10芯IC:Hi2023+1108+5812天诚TCD-369ABS 3晶10芯IC:M3330E+1108+5812天诚TCD-369ABS 3晶5芯IC:Hi2023+1108+WCGE5037天诚TCD-509ABS 3晶10芯IC:M3330E-A VL1108EGa-5812天诚TCD-509ABS 10芯(5针) IC:Hi2023+A VL1108+5812+M12L6416A天诚TCD-539ABS 2晶10芯(5针)针脚定义①-RX .②-TX .③VCC .④-GND .⑤-BL IC:M3330E+A VL1108+25L80+5812天诚TCD-579ABS 2晶10芯IC:Hi2023+Hi1108+5812天诚TCD-579ABS 3晶10芯IC:HiM3330+A VL1108EGa+RDA5812天诚TCD-589ABS 3晶10芯IC:Hi2023+1108+5812天诚TCD-689ABS铁壳机2晶12芯(9针接口) IC:Hi2023+A VL1108+夏普头天诚TC-ABS1108A 11芯IC:Hi2023EC+A VL1108+5812TCD--239ABS 2晶10芯IC:M3330E+A VL1108E+5812TCD-339ABS 3晶10芯(9针接口) IC:Hi2023+1108+5812TCD-509ABS 3晶10芯IC:Hi2023E0915+A VL1108EGa+RDA5812TCD-509ABS 2晶10芯(5针) IC:Hi2023EC+HI3121+5812TCD-519ABS 2晶10芯IC:Hi2023+A VL1108+5812TCD-599 2晶10芯IC:M3330+A VL1008+5812TCD-219ABS 2晶振10芯针脚定义①-TXD .②-RXD .③-VCC .④-GND .⑤-BL IC:Hi2023EC+Hi3121+5812爱普思DVB-2568 3晶10芯IC:HTV903+1121+2020卓异5518A 3晶10芯IC:Hi2023E+1108+5812卓异5518A(铁壳)3晶11芯IC:Hi2023E+1108+5812卓异5518A(铁壳)2晶11芯(9针接口) IC:Hi2023+1108+夏普独立高频头卓异5518A G 1晶10芯爱百信针脚定义①-GND .②-TXD .③-RXD .④VCC IC:HTV903+A VL1108+5812卓异ZY-5518A G 驰骋天下针脚定义①-GND .②-RXD .③-TXD .④VCC IC:HTV903+A VL1108+5812+F80卓异5518AG 2晶11芯针脚定义①-GND .②-RXD .③-TXD .④VCC ⑤-BL IC:Hi2023E+1108+5812卓异ZY-5518A H 春1晶6芯针脚定义①-GND .②-TXD .③-RXD .④VCC IC:GX3001+5812+25L8005卓异ZY-5518A H 春2晶10芯针脚定义①-GND .②-TXD .③-RXD .④VCC .⑤-BL IC:Hi2023E+HI3121+5812+F25L008A。

中九机顶盒各机型所用芯片大全注:山寨机机型比较杂即使是同型号的机型,而用的芯片及晶体数量.面板芯数等都不同,注意区分。

建议刷机时最好打开机盖看一下芯片核对后再刷机.勉得刷成砖.此资料的收集只做为参考。

海尔 2晶10芯IC:HI2023E+1108+5812海尔高清OST-666 2晶6芯IC:Hi2023E+3160+TS2020欧视达ABS-209B 3晶10芯IC:GX3001+GX1121+LW37欧视达209B 3晶11芯IC:GX3001+5037+8211欧视达AS-900S 1晶11芯IC:GX6121+25L80+LW37城市之宝BEX868 Y32S-93AT 2晶10芯IC:HTV903F+AVL1108+TS2020通达Y35S-8BAT/Y35S-8CAT 2晶10芯IC:HTV903+AVL1108+5812通达Y30S-01BT 2晶12芯IC:HTV903+AVL1108+2020皇朝HSR-268 10芯IC:Hi2023+AVL1108+5812IC:Hi2023+AVL1108+5812小霸王TDX-328B 单晶10芯IC:ALi3328F+5810小霸王TDX-668B 2晶 6芯IC:HTV903+1108+5812现代数码TDX-668B 2晶 6芯IC:AVL1108EG+HI2023EC+5812小霸王ABS-1388 2晶10芯IC:Hi2023EC+Hi3121+AV2020小霸王ABS-1688 2晶10芯IC:Hi2023EC+Hi3122E+5812索尼高清ABS-S 258 2晶10芯IC:Hi2023EC+Hi3122E+5812索尼高清ABS-S 258 2晶10芯IC:HI3102E+HI2023EC+AV2020太阳红TYH-279ABS/TYH-289ABS/TYH-299ABS 2晶10芯 IC:Hi2023EC+Hi3121+AV2020松下科技星TDX-668B1/松下科技星-668EIC:HI3102E+HI2023EC+5812松下科技星TDX-668B 2晶6芯IC:HTV903FH42+AVL1108EGA+RGK5812IC:Hi2023EC+3121+5812松下科技星-668C 2晶 6芯IC:AVL1108EG+HTV903F+5812松下数码王OST-266 10芯IC:HI2023E+HI3106+2020松下数码王OST-266 2晶 6芯IC:HI2023E+HI3102E+ M88TS2020+MXT8211松下科技星 3晶 6芯IC:Hi2023+AVL1108+WGCE5037松下科技星.海尔数码.海信数码单双晶+6芯 IC:Hi2023E+Hi3102(3121)+5812中星科技单晶14芯IC:Hi2023E+1108+5812+25L8单晶14芯中星科技ZG-N02 12芯IC:GX3001+AV2020中星科技 2晶 10芯IC:Hi2023EC+Hi3102E+5812+M12L64164A村村通ABS-S323- 2晶10芯IC:Hi2023EC+Hi3122E+5812村村通 2晶6芯IC:HN4+0001+5812IC:HTV903+AVL1108+RDK5812村村通ZL-5188B 2晶13芯IC:HTV903+AVL1108+RDK5812村村通ZL-5188B 2晶10芯IC:HTV903+AVL1108EGA+5812村村通ZL5188B 1晶13芯IC:HTV903+AV1108+SHARP6306村村通ZJ-11IC:HTV903+1108+夏普头S7ZH6306村村通wx-666 3晶10芯IC:GX3001+GX1121+RDK5812村村通ZL-6188C 10芯IC:GX3001+GX1121+RDK5812村村通DTH(铁壳) 3晶12芯IC:AVL1108EG+HTV903F+AV2020村村通001 3晶10芯C:GX3001+GX1121+RDK5812视美人ABS-S PS-1288 2晶10芯 IC:HI3102E+HI2023EC+AV2020太平鸟HJ321 3晶10芯IC:GX3001+GX1121+TS2020太平鸟HJ321 3晶11芯IC:GX3001+GX1121+5812焦点yj5888 2晶10芯IC:HTV903+AVL1108+RDA5812_幸运之星YJ5988 2晶 10芯IC:HTV903F+AVL1108EGa+AV2020克莱尔HT701 1晶10芯IC:AVL1108EG+HTV903F+M88TS2000---------------------------------------------------------------------------------- 作者：adok-- 发布时间：2010-2-18 13:25:45--中电电子J-6288 ABS-S 3晶12芯IC:GX3001+GX1121+5812小福星 3晶 11芯IC:GX3001+GX1121+5812东仕DIS-2000K 单晶10芯IC:HTV903F+AVL1108E+AV2020Souy Ericsson英文机 2晶10芯IC:GX3001+GX1121+AV2020高斯贝尔/歌德威尔ABS-208F 3晶 14芯 5针IC:AVL1108EG(Hi3121)+HI2023+5812高斯贝尔ABS-208 单晶 14芯 5针IC:AVL1108EG(Hi3121)+HI2023+5812歌德威尔ABS-208H/高斯贝尔ABS-208P 3晶 14芯 4针 IC:M3330E+AVL1108EG+AV2020+M12L64164A高斯贝尔ABS-208P/歌德威尔ABS-208H 1晶 14芯 5针 IC:AVL1108EG(Hi3121)+HI2023+5812高斯贝尔ABS-208P/歌德威尔ABS-208H 1晶 14芯 4针 IC:M3330E+AVL1108EG+AV2020+M12L64164A吉祥2009 3晶 14芯IC:GX3001＋GX1121＋RDK5812ABS-S LX-3688A 单晶12芯IC:GX3001+GX1121+5812集信科技V6 3晶9芯IC:1108EG(Hi3121)+HI2023+5812集信科技 V4.V6 2晶9芯 B型IC:0001+HN4F74+5812集信科技 V4.V6 A型HN4LSW+S6416AHTA-6BZH+EN25F80-1000CP+5812集信科技 V4.V6IC:0002P1M43700ta06+5812+EN25F80+TM8211+POL4558集信科技 V5 单晶10芯IC:0002(6121)+5812+M12L64164A艾雷特V5IC:HN4F910931M2EE+0001G1K729-1TA060932+5812艾雷特 alt 7812 3晶10芯IC:GX3001+GX1121+5812艾雷特ALT7812 3晶11芯IC:GX3001+GX1121+5812艾雷特ALT600c 2晶10芯IC:GX3001+GX1121+5812艾雷特ALT600c 2晶11芯IC:GX3001+GX1121+5812艾雷特ALT600c 1晶IC:CH216H+AVL1108+C6XS-8CA中大WS-3688ZJ (铁壳) 10芯单晶IC:Hi2023EC+Hi3102E+AV2020皇视HRS-268 3晶10芯IC:Hi2023EC+Hi3102E+AV2020皇视HSR-208B 2晶10芯IC:Hi2023+1108+2020皇视 208B 单晶10芯IC:3330+1108+2020皇视 210A 单晶6芯IC:Hi2023ec+Hi3122e+AV2020IC:Hi+1108+SHARP夏普头皇视HSR-268 单晶10线IC:HTV903+AVL1108+5812皇视HRS-268 3晶10芯IC:Hi2023EC+AVL1108+5812皇视260B 3晶10芯IC:Hi2023+1108+2020皇视260B 3晶10芯IC:HI2023+1108+5812天地星小霸王TDX-328B 1晶10芯IC:ALi M3328F+5810天地星小霸王 TDX-668B 2晶振IC:HTV903+AVL1108EGA+RDA5812+25L8005天地星小霸王 TDX-668B 单晶 6芯IC:Hi2023E+RDA5812+AVL1108E+MXT8211a+25L8005凯恩斯KES-2088S 2晶6芯IC:HI2023EC+HI3102E+RDA5812凯恩斯2077Z 单晶 6芯IC:2023EC+3122E+5812凯恩斯KES-2788S 3晶 10芯HC:HI2023E+AVL1108EGa+5812IC:HI2023EC+HI3102E+RDA5812凯恩斯KES-2088S 2晶 6芯IC:HI2023EC+HI3122E+RDA5812凯恩斯KES-2688b 2晶 10芯IC:Hi2023e+1108e+5812美路 3晶13芯IC:2023E+1108+2119美路 2晶12芯IC:GX3003+GX1121+F80+5812美路5598IC:Hi2023+1108+GAIM-18R+29lv160ZY 5518A 2晶10芯IC:Hi2023E+3102E+5812万利达ZY-5518A 2晶10芯IC:CX3001+GX1121+5812长虹新一代 3晶10芯IC:HI2023E+1108E+FL016ALF长虹数码CH930 3晶12芯IC:HTV903F+1108+AV2020+M80长虹精品TC-6688ABS 2晶10芯IC:HTV903+AVL1108EG+5812长虹KES-2099S 2晶5芯IC:Hi2023+Hi3102E+5812航天天信WTD198J 2晶12芯IC:GX3001+GX1121+5812+ES29LV160FB-70TG航天珠江 WTD-198J 2晶12芯IC:GX3001+GX1121+5812航天数码ABS-3809 2晶12芯IC:GX3001+GX1121+5812航天直播HT-168 3晶12芯IC:Hi2023+1108+夏普头天成TCD-2192晶 10芯IC:Hi2023EC+Hi3121+5812天成TCD-299Z 2晶10芯IC:Hi2023+3206+5812天成TD-299Z 2晶5芯IC:Hi2023+3206+5812天诚539 2晶10芯IC:HTV903+AV1108+5812天诚519型 2晶10芯IC:HTV903+1108E+5812天诚TCD-239ABS 3晶10芯IC:M3330+1108+5812天诚TCD-239ABS 2晶10芯IC:Hi2023+1108E+5812天诚TCD-239 2晶10芯IC:M3330E+1108E+5812天诚TCD-279 2晶10芯IC:Hi2023EC+Hi3102E+5812天诚TCD-369ABS 3晶10芯IC:Hi2023+1108+5812天成TCD-539ABS 2晶10芯IC:M3330E+AVL1108+25L80+5812TCD--239ABS 2晶10芯IC:M3330E+AVL1108E+5812TCD-519ABS 2晶10芯IC:Hi2023+AVL1108+5812TCD-599 2晶10芯IC:M3330+AVL1008+5812TCD-219ABS 2晶振 10芯IC:HI2023EC+HI3121+5812爱普思DVB-2568 3晶10芯IC:HTV903+1121+2020卓异5518A 3晶10芯IC:Hi2023E+1108+5812卓异5518A(铁壳)3晶11芯IC:Hi2023E+1108+5812卓异5518AG 2晶11芯IC:Hi2023E+1108+5812绿达视美人\\卓异 1晶10芯 IC:Hi2023EC+3121+2020绿达金统帅 3晶10芯IC:M3330+1108+5812三星高清王 2晶12芯IC:GX3001+GX1121+5812三星数码王TDX668B 2晶6芯 IC:Hi2023+1108+5812三星数码王TDX668B 2晶6芯 IC:HTV903F+AVL1108E+5812三星数码王TDX668E 1晶6芯 IC:Hi2023EC+3102C+5812开门红KSP638 单晶10芯IC:HTV903F+AVL1108E+AV2020日立创新TDX-668B 2晶6芯 IC:Hi2023+AVL1108+5812志高之星HS166 2晶12芯IC:Hi3102+Hi2023+5812金牛ABS-1108 3晶10芯IC:Hi2023+1108+5812小灵通 2晶6线IC:Hi2023+1108+5812福临门ABS-S 3晶9线IC:112i+3001+5812C60S-93AT 单晶10芯IC:CT216H+AVL1108EGa+AV2020其乐达CT216 2晶10芯IC:CT216+1108+AV2020科海单晶11芯IC:HTV903+AVL1108EGa+RDa5812+25X16AVSIG大旗920 3晶12芯IC:HTV903+AVL1108+AV2020大旗DQ920 3晶12芯IC:GX3001+GX1121+5812+25X16大旗930 3晶12芯IC:HTV903+AVL1108+AV2020众昌电子ABS--2088 2晶10芯IC: Hi2023+1108+5812众昌电子ABS-2087 2晶10芯IC:M3330+1108+5812创维S600 3晶IC:M3330E+1108E+5812创维新一代 3晶10芯IC:Hi2023E+1108+5037+FL016A中广通XC-B188 3晶12芯IC:GX3001+GX1121+5812深圳知音ABSTAR KT-2309 3晶10芯 IC:Hi2023+AVL1108E+5812铁壳ABS-2009 2晶11芯IC:Hi2023+1108+夏普头王牌数码OST-366 2晶6芯IC:Hi3102+Hi2023EC+AV2020。

mtk6592cpu怎么样mtk 6592的这款cpu好不好呢?用起来怎么样?下面由店铺给你做出详细的mtk 6592 cpu介绍!希望对你有帮助!mtk 6592 cpu介绍一目前还没有真8核的手机芯片MP, 三星的8核也是伪8核, 同时只能工作4核;MT6592是真8核, A7内核, 28nm制程, 但是要到今年年底才MP, 所以手机上市要到春节前后了.MT6592的安兔兔跑分成绩已经浮出了水面，从中可以看出，它在主频1.7GHz下的分数为29600，表现相当不错。

之前联发科全球智能手机总经理朱尚祖曾表示，MT6592是基于28nm工艺制程，主频为2GHz，照这个趋势看，其分数还能有提升。

之前搭载骁龙800和Tegra 4处理器机型的安兔兔跑分基本在33000左右，而2GHz的MT6592的表现应该也能接近或达到这个水平，当然了需要说明的是，如果1.7GHz MT6592的分数是在1080p 终端下跑出来的.此外，之前联发科的负责人给出的消息还称，MT6592采用的图形处理器是Mali四核，其将锁定在2500-3000元区间旗舰手机。

mtk 6592 cpu介绍二八核手机，顾名思义，通常指拥有八核CPU处理器的手机。

卓普小黑Ⅱ——号称全球首款真八核智能手机在北京有开发布会，搭载联发科MT6592八核芯片，卓普小黑2代智能手机同时推出多种高科技技术配件。

处理器是手机的心脏。

市面上智能手机都已走进双核四核八核时代，多核手机处理器，这通常指移动处理器的多核CPU，其中包括异步多核(aSMP)和同步多核(SMP)两种结构。

同步多核是指多个CPU核心一起以相同频率和电压完成同一任务异步多核中，多个核心以相同或不同频率及电压单独执行处理指令，不需要多个一起开动来完成一个任务而造成不必要的能耗。

同步异步的区别：同步的多个CPU是一个整体，无论多少个任务指令，都同时合力先完成一个，然后再完成下一个，和电脑CPU相似。
