IQ200series multi-function harmonic component meter user manualA.Function,technical parameter1、Function1）、Measurement of three-phase voltage,current,active power,reactive power,apparent power,Four quadrant power,power factor,frequency,maximum power2）、Measurement of3-63sub harmonic of each phase voltage,current harmonic content and total content3）、1active energy pulse output,1reactive energy pulse output 4）、Maximum Demand(U,I,P,Q,S)5）、6DI，2DO（relay output），2Analog Output4-20mA6）、1RS485,MODBUS-RTU,LCD display2、Technical Data B,Programming and operating1、Display：three-phasevoltagefrequencythree-phasecurrentPower factorThree-phaseactive powerPsumThree phasereactive powerQs(Figure1)(Figure2)(Figure3)(Figure4)Three phaseapparent powersumThree phasepower factorTotal powerfactoractive energy(forward/backforward)reactive energy(forward/backforward)(Figure5)(Figure6)(Figure7)(Figure8)Total harmoniccontent ofvoltage3-63secondharmoniccontentTotal currentharmoniccontent3-63secondharmoniccontentThe MaximumDeamandandThe CurrentDemand6input state2output state(Figure12)Note1(Figure11)Note2(Figure10)Note3(Figure9)Explain:1)Figure1-Figure10shows the interface of common data display instrument,according to the""or""button switch interface.2)According to the""button in the common data interface,enter the phasevoltage harmonic data display interface such as(Figure12).3)According to the""button in the common data interface,enter the datadisplay interface such as phase current harmonics(Figure11).4)In the harmonic data display interface,press"MENU"key,can return to thecommonly used data display interface.Note1:according to the""key A/B/C phase voltage harmonic distortiondata display interface switchingAccording to the""or""can choose to display the time harmoniccontent(3-63).Note2:according to the""key A/B/C phase current harmonic distortion datadisplay interface switchingAccording to the""or""can choose to display the time harmoniccontent(3-63).Note3:at this screen,you can press the"MENU"key to see the otherDemand Values(I-current,P-total active power,Q-total reactivepower,S-total apparent power)2.Setting up:Press"MENU".""."".""."".""to finish setting up.MENU:press this button to enter into the programming mode when inMeter measurement display,displaying‘password’on the meter.Programand set up the meter only after entering the correct password,instrumentfactory initial password0001;the other function of the“MENU”button is to backspace during theprogramming process.Press“”and“”to choose the parameter for modification select thenumber in each digit(in XXXX form).“”and“”key:select the parameters or to increase or decrease thecursor position data""key parameters:enter the next layer of menus or save theModified value and returns a layer on the menu.The organizational structure of the menu is as follows:Users can choosethe appropriate programming setting parameters according to the actualsituation.Featrue DataWiring3-phase3-wire,3-phase4-Wire Citification GB/T 22264.1-2008 (China)Input voltage AC380V(100%-120%)Continuous Input Current0～5A Continuous:20Ie/1s Voltage Operation AC220V(85~265V)Active power pulse output5000imp/kwhReactive power pulse output5000imp/kvarhDigital Input Passive contact inputDigital Output Relay output AC220V5A Communication interface RS-485、MODBUS-RTU Accuracy0.2classDisplay LCDFrequency40~60Hz,0.1HzConsumption≤5VAEnvironment -10~55℃without corrosive gas (at20℃RH≤90%,at40℃RH≤50%)Dimensions96×96×75（L*W*D）Level1Level2Level3DescriptionPasswordInput passwordDefaultpassword0001Enter into programmingonly when the enteredpassword is correctSystemsetupChangePassword0-9999Reset passwordEnergyclearance YES/NOElectric energy is clearedto zero after confirmation backlighttime0-9999Unit:second.Default value:120NetWorksetupConnectionmodeN.3.4N.3.3Default value：N.3.4Voltagetransformingratio1-9999Set up voltage signal atio=Primary alue/secondaryvalueCurrenttransformingratio1-9999Set up current signal ratio=Primary alue/secondaryvalueComm.setupComm.rate BAUD4800,960019200Default：9600Communication data type N.8.1N.8.1:nonecannot changeAddress1-247Meter addressrange:1-247AlarmsetupUaMax0-9999（V）Set A/B/C phase alarmvoltage valueThe default setting of0,touse the alarm functionUbMax0-9999（V）UcMax0-9999（V）Analog1/2outputsetupEnable ON/OFF Turn on or turn off theAnalog outputItem Ua/Ia/Ps……Set Part-E to get more info Up Limit0-7500Set Part-E to get more infoDemandsetupEnable ON/OFF Turn on or turn off thisfunctionTime15(min)Demand Periodcannot changeClear YES/NO Clear the DemandＤＣ２２０Ｖ±１５％Page.01Page.02Page.03Page.04Page.05Page.06C.Mounting and wiring1.Mounting dimensions:2.Mounting method:Installed in a dark way installed on the panel 2.Terminalwiring:Note:L-N is the auxiliary power supply.Make proper wiring according to themeter enclosure wiring diagram!1）Auxiliary power supply:The IQ200series multi-functional power meter has universal AC/DC switch power supply input interface,offering standard products with the 220V AC/DC or 110V AC/DC power supply interface when not stated specially.The meter’s operating power supply voltage limit is 85to 265V (AC/DC).Make sure that the supplied power supply is suitable for this series product,to avoid damages to the product.A).For AC power supply,it is recommended to install a 1A fuse on thelive-wire side.B).In regions of worse power quality,it is recommended to install a surgeprotector in the power supply circuit to avoid lightning,and install a fast pulse burst suppressor.2)Input signal:The IQ200series product uses the calculation method of individual collection in each measurement channel,ensuring consistency and symmetry when in use,suitable for different load types.Remark:A)Voltage input:the input voltage should not exceed the product’srated input voltage (100V or 400V).Otherwise,a PT should be considered to use,and a 1A fuse must be installed in the voltage input end.B)Current input:the standard rated input current is 5A.An externalCT should be used for above 5A current.If the used CT is connected to other meters,serial connection should be made.Make sure to disconnect the CT’s primary circuit or short circuit the secondary circuit before removing the product’s current input wiring.A connection bar is recommended to use.Do not directly connect to the CT,convenient for removal.C)Make sure that the input voltage and current are corresponding,with consistent phase sequence and direction;otherwise,value and symbol errors (power and energy)will occur!D)The meter input network is configured to the CT quantity in thesystem.Choose the 3-phase 3-wire 2-compnent method for 2-CT cases,while the 3-phase 4-wire 3-component method is chosen for 3-CT cases.The input net setup in the meter wiring and meter programming should be consistent with the wiring methods for the measured loads.Otherwise,this will result in incorrect voltage or power measurements by the meter.In a 3-phase 3-wire system,the voltage measurement and displayed value are related to line to line voltage,while in a 3-phae 4-wire system,the voltage measurement and displayed value are phase to phase voltage.3)communication port:41for the RS485(A+),42for the RS485(B-),43for the shieldeThe communication line adopts ZR-RVSP 2×1.5mm2two core shielded twisted pairThere must be a shield must be tightly twisted 4)electric energy pulse output:31-active power pulse output (-)32-active power pulse output (+)33-reactive power pulse output (-)34-reactive power pulse output (+)5)2 way relay output (4-7):4-5 for a set of ,6-7 for a set of .Normally open passive contact signal output,the contact capacity of 5A AC220V (resistive load) (the relay controlled by the communication command)6)digital input (60-66):6sets of passive contact input,60for the COM (common)7)analog output (50-52):2analog output,50is the common GND for the analog.the maximum load 400Ω,the output current 4-20mA.see the Part-E to get the output items info.this feature is optional.D.Digital communication The serial asynchronous half-duplex RS485communication interface is offered,using MOD-BUS-RTU protocol.E.Analog Output ItemsThe following items are the secondary side of the electrical parameters that IQ200mesaured.Eaton corporationAsia Pacific Headquarterne 280,Linhong Road Changning District Shanghai 200335Tel:86-21-52000099Eaton is a registered trademark of Fax:86-21-52000200Eaton Corporation All trademarks are property of their respective owners © 2018 Eaton Corporation All Rights Reserved Printed in China APr -20188) screw reated tightening torque 5.1kgf.cm (0.5N.m)。
