198150-15217-01Rev. DT-BERD 2207USER’S GUIDEThis manual applies to all T-BERD 2207 software incorporating software level 3.x.JANUARY 2000Copyright ©1998 TTC®USA 1-800-638-2049 • +1-301-353-1550 • FAX +1-301-353-0234Canada 1-888-689-2165 • +1-905-507-4117 • FAX +1-905-507-4126SECTION 9 - SpecificationsGeneral SpecificationsSECTION 9 SPECIFICATIONS9.1GENERAL SPECIFICATIONS9.1.1Physical Characteristics:Height:7.5" (19 cm)Width:11.5" (29.2 cm)Depth: 2.25" (5.7 cm)Weight: 4.25 lb. (1.93 kg.)9.1.2Environmental Characteristics:Temperature:Operating:32°F to 122°F (0°C to +50°C)Non-Operating:-40°F to 167°F (-40°C to +75°C)Humidity:10% to 90% Relative Humidity, non-condensing9.1.3Electrical Characteristics:Battery Type:10.8 V Nickel-Metal Hydride (NiMH)Operating Time:Typically, up to three hours of continuous operation on a full chargeRecharging Period:Maximum of two hours from full dischargeAC Adaptor:120VAC to 18 VDC 1.2A9.2DS1 SPECIFICATIONS9.2.1Input Specifications9.2.1.1RX JackConnector Type:Bantam jackFrequency:1,544,000 Hz ±5000 HzUser’s Guide T-BERD 22079-1SECTION 9 - SpecificationsDS1 SpecificationsImpedanceBRIDGE:1000 ohms minimumTERM:100 ohms ±5%DSX-MON:100 ohms ±5%RangeBRIDGE:+6 to -35.0 dBdsxTERM:+6 to -35.0 dBdsxDSX-MON:+6 to -24.0 dBdsx of resistive los9.2.1.2Loop Codes Detection CriteriaIn-Band:At least 177 error-free bits of the selected repetitive pattern must be received(loop up or loop down).Out-of-Band:Datalink monitored every 125 ms for loop codes (loop up and loop down).9.2.1.3Pattern Synchronization Detection CriteriaFixed Patterns:30 consecutive error-free bitsPseudo-random:30 + n consecutive error-free bits for a pattern length of 2^n-19.2.2Output Specifications9.2.2.1TX JackConnector Type:Bantam jackLBO Level:Line build-out of 0, -7.5, -15.0, and -22.5 dB of cable loss at 772 HzLBO Tolerance:±2 dB at 772 kHzTiming:±7 ppm internal or recoveredLine Codes:AMI or B8ZSError Insert Type:Logic, BP V, or FramePulse Shape:With output terminated in 100 ohms resistive load and 0 dB line build-outselected, the T-BERD 2207 meets ITU-T Recommendation G.703; AT&TPublications CB113, CB119, CB132, CB143, and PUB62508; and AT&TPUB62411 pulse shape specifications.9-2T-BERD 2207User’s GuideSECTION 9 - SpecificationsDS1 Specifications 9.2.2.2Transmitted Loop CodesIn-BandCSU:Loop-up: 10000; Loop-down: 100Facility 1:Loop-up: 1100; Loop-down: 1110Facility 2:Loop-up: 11000; Loop-down: 11100Facility 3:Loop-up: 100000; Loop-down: 100Out-of-BandLine:Loop up: 1111 1111 0111 0000Loop down: 1111 1111 0001 1100Payload:Loop up: 1111 1111 0010 1000Loop down: 1111 1111 0100 1100Network:Loop up: 1111 1111 0100 1000Loop down: 1111 1111 0010 01009.2.3Measurement SpecificationsFrequencyRange:1,544,000 ±5000 HzAccuracy:± 7 ppmResolution: 1 HzReceived LevelRange:+6 dBdsx to -40 dBdsxAccuracy:±1.0 dB between +6 and -10 dBdsx±2.0 dB between -10 and -20 dBdsx±3.0 dB between -20 and -40 dBdsxResolution:0.1 dBVp-p Range:60 mV to 12.0 VVp-p Resolution:0.05 VSimplex CurrentRange:10 mA to 180 mAccuracy:±5%Resolution: 1 mASimplex path:13.2 ohms (nominal)User’s Guide T-BERD 22079-3SECTION 9 - SpecificationsDS1 Specifications9.2.4Alarm CriteriaSignal Loss:175 ±75 consecutive zerosFrame LossD4: 2 out of 5 Ft bits in errorESF: 2 out of 5 frame bits in errorSLC-96: 2 out of 5 Ft bits in errorPattern Loss:100 errors detected in 1000 or fewer bitsOnes DensityQRSS:Alarm is suppressed.Other Patterns:Received data contains less than n ones in 8(n+1) bits, where n=1 to 23.Excess ZeroAMI:16 or more consecutive zerosB8ZS:8 or more consecutive zerosYellow AlarmD4:Bit 2 is a 0 for 255 consecutive channels.ESF:256 bits ±16 bits of a repetitive (1111 1111 0000 0000) pattern received inthe 4 kb/s datalink.SLC-96:Bit 2 is a 0 for 255 consecutive channels.AIS:Unframed T1 signal has 2048 consecutive ones.Low Battery:Battery has less than 25% energy remaining.9-4T-BERD 2207User’s GuideSECTION 9 - Specifications DS3 Option SpecificationsUser’s Guide T-BERD 22079-59.3DS3 OPTION SPECIFICATIONS9.3.1DS3 Specifications9.3.1.1Framing Formats9.3.1.2Patterns9.3.1.3Line Coding•B3ZS9.3.1.4Connectors•WECO 560A jack9.3.1.5Receiver (Single)Frequency:44,736 Mb/s ±300ppmLevel:HIGH: Accepts Nominal 1.2 Vp, 0 ft. of cable from High sourceDSX: Accepts Nominal 0.6 Vp, 450 ft. of c able from High source or monitor LOW: Accepts Nominal 0.3 Vp, 900 ft. of cable from High source9.3.1.6Transmitter (Single)Frequency:44,736 Mb/s ±20ppmPulse:HIGH: Nominal 1.2 Vp (Signal meets ANSI specification T1.102-1993 and ITU-TG.703 when subjected to 450 feet of cable loss.)•Auto• Muxed M13•Unframed • C-bit•M13• Muxed C-bit•1111• 215-1•1100 (Idle)• 220-1•1010 (AIS)• 223-1•1010• User (3 to 24 bit programmable)SECTION 9 - SpecificationsDS3 Option SpecificationsDSX: Nominal 0.91 Vp (Signal meets ANSI specification T1.102-1993 andITU-TG.703.)LOW: Nominal 0.31 VpTiming:Internal ClockRecovered Clock9.3.2DS3 Measurements9.3.2.1Summary•Bit Errors•Frame Errors•Bipolar Violations•Receive Frequenc•Parity Errors•FEAC Messages•C-bit Errors•DS2 Frame Errors•FEBE•Pattern Slip9.3.2.2Logic•Bit Errors•Pattern Slips•Bit Error Rate•Pattern Loss Seconds•Bit Errored Seconds•Error Free Seconds•Pattern Losses•% Error Free Seconds9.3.2.3Bipolar Violations•BPV•BPV Rate•BPV Errored Seconds9-6T-BERD 2207User’s GuideSECTION 9 - SpecificationsDS3 Option Specifications 9.3.2.4Frame Errors•Frame Error Rate•FEBE Rate•Frame Error Seconds•DS2 Frame Errors•Out of Frame Seconds•DS2 Frame Error Rate•C-bit Errors•Received X-bit•C-bit Error Rate•Transmit X-bit•FEBE•Frame Loss Count9.3.2.5Parity•Parity Errors•Parity Error Rate•Parity Error Seconds9.3.2.6Signal•Signal Loss•Signal Loss Seconds•Receive Frequency•Receive Signal Level•Transmit FrequencyUser’s Guide T-BERD 22079-7。
Leading-Edge Mounting Technology and ASICs Reduce the Size of 2-Channel Modules Modules701250701251701255701260701265701270701271s High-Speed 10 MS/s 12-Bit Isolation Module (701250) Broad bandwidth (3 MHz) and high accuracy (0.5%) inputs s High-Speed 1 MS/s 16-Bit Isolation Module (701251) High resolution inputs combined with high-sensitivity (1 mV/ div)s Temperature/High-Precision Voltage Module (701265) 100 Hz frequency range, high-accuracy (0.08%) voltage measurements, and an ultra high-sensitivity range value (100µV/div)s High-Speed 10 MS/s 12-Bit Non-Isolation Module (701255)Non-isolated model with the same performance as the model 701250s High-Voltage 100 kS/s 16-Bit Isolation Module (with RMS) (701260)850 V (DC+ACpeak) direct input, RMS mode Accuracy of 0.25%s Strain Modules (701270 & 701271)NDIS-type (701270) and DSUB-type (701271)Wide range of bridge voltages (2 V, 5 V, & 10 V) Accuracy of 0.5%4 new modules for a variety of applicationsN E WN E WN E W2DualCapture: A Powerful Tool for Durability Test Data AnalysisThe waveform shown above was captured at a sampling rate of 50 kS/s. The occurrence of noise can be confirmed in the graph, but the time resolution is too low to capture the waveform accurately.With DualCapture, the user sets triggers for capturing sudden phenomena. Up to 100 phenomena can be collected in a memory length of 10 kW at a maximum sampling rate of 10 MS/s.10 kWPhenomena canbe accuratelyassessed at 10MS/s Maximum 100 phenomenaRoll-mode viewUser-specified captured screen and thecorresponding time are displayed.This is the limit for 50 kS/s.phenomenonMaximum 100 MWA Wide Range of Trigger Functions for Accurately Capturing a Variety of WaveformsHaving a wide range of triggers is of course very useful for obtaining stable observations of variety of different waveforms. In Action-On TriggerAutomatically Save Measured Data When this trigger is activated, the DL750performs a specified action each time a waveform is captured and displayed on the screen. This feature is useful for saving data automatically and reliably (e.g., for data collection in automated, continuous tests).Manual TriggerA Trigger Can Be Activated with Press of a Button.With this feature, a trigger can be executed whenever you like,separate from the preset trigger conditions.riggers the n-th time that condition B goes true after condition riggers if condition B goes true after condition A has gone true and an interval at least equal to the delay setting has elapsed. Activates an edge trigger on another input during the interval riggers when any one of the individual channel conditions set riggers when a preset waveform frequency condition goes true.Triggers when a trigger source enters or leaves a level set by two points Triggers when a signal leaves an automatically-defined "wave window"Multi-Channel 2-Location Zoom FunctionGO/NO-GO Judgmentscreenshot to a specified destination, saving waveform data to a specified storage medium, sounding a buzzer, and6Display and Data Recording FunctionsReal-Time Hard Drive Recording (with the /C8 Option)Recorder-Like Real-Time Data Recording over Extended PeriodsWith the optional internalhard drive, you can record measurements to the harddrive in real time. Thismakes it easier to manage and analyze data usingPCs and other tools.Maximum data capacity:1 GWMaximum sampling rate:100 kS/s(using 1 channel only)Memory Backup FunctionProtects Your Data Even If the Power Supply Goes Out This function backs up about 10 hours of data saved to the acquisition memory immediately prior to power loss. Memory backup helps you avoid losing important data even if the power supply is unstable and gets cut off.(Backup time varies according to the usage environment. Four AA batteries are required for memory backup.)Snapshot FunctionEnables On-Screen Waveform Comparisons Using the snapshot function, you can keep the currently displayed waveform with the touch of a button. Snapshots are useful for comparing a reference waveform with an input waveform. In addition, snapshots can be saved to and loaded from the storage media.X-Y Display FunctionDisplay an Overlay of up to Four X-Y Displays This function lets you display multiple X-Y plots together,making relative phase comparisons easy. The X-Y display function is a powerful tool for applications such asevaluating DC motors based on a Lissajous waveform.All-Channel Setup MenuQuickly View the Setup of All ChannelsThis menu lets you review and modify all of the channel setups from a single screen display. Parameters such as voltage axis sensitivity, screen scale settings, and linear scaling can be configured for each channel.Wide Waveform DisplayIncrease the Viewing Area of DisplayWith the SVGA color TFT liquid crystal display, the number of display pixels has been greatly increased. For wide waveform display, set the resolution to 750 × 512 pixels.Volume control for recording andwaveform can be viewed on anUSBBasic 6.0 to control the DL750 through a USB interface.• Connecting USB Peripheral EquipmentUSB keyboards, USB mouse and USB printers can bedirectly connected to the DL750.Thumbnail displayUSB printer, or a network printer.operation using Internet Explorer.Data CaptureThis function downloads values of waveform parameters periodically, launches MS Excel and graphs the parameters on a spreadsheet values. This enables you to check the Measurement TrendUsing Internet Explorer,you can periodically or manually download screen images to a PC for remote waveform monitoring. Y ou can also download waveform data,start or stop ameasurement, or setup a split display all from a PC.Software for Waveform Measurement on a PC Software for Remotely Controlling the DL SeriesThe Wirepuller software program displays a screen image of the DL on your PC so that you can monitor waveform signals.In addition, you can use the PC’s mouse and keyboard to control the DL. The DL can be controlled via an Ethernet, USB, or GP-IB.This software program can be downloaded from the following URL (requires registration):/tm/Bu/DLsoft/wire/A trial version of this software program can be downloaded from the following URL:/tm/Bu/700919/Plug-In Module SpecificationsHigh-Speed 10 MS/s 12-Bit Isolation Module (701250)Input channels2Input couplings AC, DC, GNDMaximum sampling rate10 MS/sA/D conversion resolution12 bits (150 LSB/div)Input type Isolated unbalancedFrequency range(–3 dB)1DC, up to 3 MHzInput range(10:1)50 mV/div to 200 V/div (in steps of 1, 2, or 5),(1:1) 5 mV/div to 20 V/div (in steps of 1, 2, or 5) Effective measurement range20 div (display range: 10 div)DC offset±5 divMaximum input voltage (1 kHz or less)In combination with 700929 (10:1) 2600 V (DC + ACpeak)Direct input (1:1) 6, 10250 V (DC + ACpeak)Maximum allowable in-phase voltageIn combination with 700929 (10:1) 3400 Vrms (CA T I), 300 Vrms (CA T II) In combination with 7019in steps of 1, 2, or 5+701954 (1:1) 9400 Vrms (CA T I), 300 Vrms (CA T II) Main unit only (1:1) 1142 V (DC + ACpeak) (CA T I and CAT II, 30 Vrms) DC accuracy1±(0.5% of 10 div)Input impedance 1 MΩ± 1%, approx. 35 pFConnector type Isolation type BNC connectorInput filter OFF, 500 Hz, 5 kHz, 50 kHz, 500 kHz Temperature coefficientZero point±(0.05% of 10 div)/°C (typical value)Gain±(0.02% of 10 div)/°C (typical value)High-Speed 1 MS/s 16-Bit Isolation Module (701251)Input channels2Input couplings AC, DC, GNDMaximum sampling rate 1 MS/sA/D conversion resolution16 bits (2400 LSB/div)Input type Isolated unbalancedFrequency range (–3 dB)1DC, up to 300 kHz (20 V/div to 5 mV/div)Input range(10:1)10 mV/div to 200 V/div (in steps of 1, 2, or 5)(1:1) 1 mV/div to 20 V/div (in steps of 1, 2, or 5) Maximum input voltage (1 kHz or less)In combination with 700929 (10:1) 2600 V (DC + ACpeak)Direct input (1:1) 6, 10140 V (DC + ACpeak)Maximum allowable in-phase voltageIn combination with 700929 (10:1) 3400 Vrms (CA T I), 300 Vrms (CA T II) In combination with 701901+701954 (1:1) 9400 Vrms (CA T I), 300 Vrms (CA T II)Main unit only (1:1) 1142 V (DC + ACpeak) (CA T I and CAT II, 30 Vrms) DC accuracy15 mV/div to 20 V/div±(0.25% of 10 div)2 mV/div±(0.3% of 10 div)1 mV/div±(0.5% of 10 div)Input impedance 1 MΩ± 1%, approx. 35 pFConnector type Isolated type BNC connectorInput filter OFF, 400 Hz, 4 kHz, 40 kHzTemperature coefficientZero point 5 mV/div to 20 V/div: ±(0.02% of 10 div)/°C (typical value)2 mV/div: ±(0.05% of 10 div)/°C (typical value)1 mV/div: ±(0.10% of 10 div)/°C (typical value)Gain 1 mV/div to 20 V/div: ±(0.02% of 10 div)/°C (typical value) High-Speed 10 MS/s 12-Bit Non-Isolation Module (701255)Input channels2Input couplings AC, DC, GNDMaximum sampling rate10 MS/sA/D conversion resolution12 bits (150 LSB/div)Input type Non-isolated unbalancedFrequency range (–3 dB)1DC, up to 3 MHzInput range(10:1)50 mV/div to 200 V/div (in steps of 1, 2, or 5)(1:1) 5 mV/div to 20 V/div (in steps of 1, 2, or 5) Effective measurement range20 div (display range 10 div)DC offset±5 divMaximum input voltage (1 kHz or less)In combination with 701940 (10:1)600 V (DC + ACpeak)Direct input (1:1)250 V (DC + ACpeak)DC accuracy1±(0.5% of 10 div)Input impedance 1 MΩ± 1%, approx. 35 pFConnector type Metal type BNC connectorInput filter OFF, 500 Hz, 5 kHz, 50 kHz, 500 kHz Temperature coefficientZero point±(0.05% of 10 div)/°C (typical value)Gain±(0.02% of 10 div)/°C (typical value)Adaptive passive probe (10:1)701940High-Voltage 100 kS/s 16-Bit Isolation Module (with RMS) (701260)Input channels2Input couplings AC, DC, GND, AC-RMS, DC-RMSMaximum sampling rate100 kS/sA/D conversion resolution16 bits (2400 LSB/div)Input type Isolated unbalancedFrequency range (–3 dB)1Waveform measurement modeDC, up to 40 kHzRMS measurement mode DC, 40 Hz to 10 kHzInput range(10:1)200 mV/div to 2000 V/div (in steps of 1, 2, or 5)(1:1)20 mV/div to 200 V/div (in steps of 1, 2, or 5) Effective measurement range20 div (display range 10 div)DC offset±5 divMaximum input voltage (1 kHz or less)In combination with 700929 (10:1) 21000 V (DC + ACpeak)In combination with 701901+701954 (1:1) 6850 V (DC + ACpeak)Maximum allowable in-phase voltageIn combination with 700929 (10:1)H side: 1000 Vrms (CAT II) 4, L side: 400 Vrms (CAT II) 5In combination with 701901+701954 (1:1)H side: 700 Vrms (CA T II) 7, L side: 400 Vrms (CA T II) 8Direct input (when using a cable which doesn’t comply with the safety standard)H/L sides: 30 Vrms (42 V DC + ACpeak)11 DC accuracy (waveform measurement mode)1±(0.25% of 10 div)DC accuracy (RMS measurement mode)1±(1.0% of 10 div)AC accuracy (RMS measurement mode)1Sine wave input±(1.5% of 10 div)Crest factor of 2 or less±(2.0% of 10 div)Crest factor of 3 or less±(3.0% of 10 div)Input impedance 1 MΩ± 1%, approx. 35 pFConnector type Isolated type BNC connectorInput filter OFF, 100 Hz, 1 kHz, 10 kHzT emperature coefficient (waveform measurement mode)Zero point±(0.02% of 10 div)/°C (typical value)Gain±(0.02% of 10 div)/°C (typical value) Response time (RMS mode)Rise (0 to 90% of 10 div)100 ms (typical)Fall (100 to 10% of 10 div)250 ms (typical)Crest factor (only at RMS measurement)3 or less*Please use 701901 (1:1 safety adaptor lead) or 700929 (10:1 safety probe), which complies with the safety standard, for high-voltage input.*It is very dangerous to use cables that do not comply with the safety standard.Temperature/High-Precision Voltage Module (701265)Input channels2Input couplings TC (thermocouple), DC, GNDInput type Isolated unbalancedApplicable sensors (input coupling: TC)K, E, J, T, L, U, N, R, S, B, W, iron-doped gold/chromel Data updating rate500 HzFrequency range (-3 dB)1DC, up to 100 HzVoltage accuracy1 (at voltage mode)±(0.08% of 10 div + 2 µV)T emperature measurement accuracy 1, 12Type Measured range AccuracyK–200°C to 1300°C±(0.1% of reading + 1.5°C)E–200°C to 800°C except –200 to 0°C:J–200°C to 1100°C±(0.2% of reading + 1.5°C) T–200°C to 400°CL–200°C to 900°CU–200°C to 400°CN0°C to 1300°CR, S0°C to 1700°C±(0.1% of reading + 3°C)except0 to 200°C: ±8°C200 to 800°C: ±5°C B0°C to 1800°C±(0.1% of reading + 2°C),except 400 to 700°C: ±8°CEffective range: 400 to 1800°C W0°C to 2300°C±(0.1% of reading + 3°C)Iron-doped gold/chromel0 to 300 K0 to 50 K: ±4 K50 to 300 K: ±2.5 KMaximum input voltage (1 kHz or less)42 V (DC + ACpeak) (CAT I and CA T II, 30 Vrms)Input range (for 10 div display)100 µV/div to 10 V/div (in steps of 1, 2, or 5) Input connector Binding postInput impedance Approx. 1 MΩInput filter OFF, 2 Hz, 8 Hz, 30 HzT emperature coefficient (for voltage)Zero point±((0.01% of 10 div)/°C + 0.05 µV)/°C (typical value)Gain±(0.02% of 10 div)/°C (typical value) Strain Module (NDIS) (701270)Input channels2Input types DC bridge input (automatic balancing), balanceddifferential input, DC amplifier (floating) Automatic balancing method Electronic auto-balanceAutomatic balancing range±10,000 µSTR (1 gauge method)Bridge voltages Select from 2 V, 5 V, or 10 VGauge resistances120 to 1000 Ω (bridge voltage of 2 V)350 to 1000 Ω (bridge voltage of 2/5/10 V) Gauge rate 1.90 to 2.20 (variable in steps of 0.01)A/D resolution16 bits (4800 LSB/div: Upper=ϩFS, Lower=–FS) Maximum sampling rate100 kS/sFrequency range (–3 dB)1DC, up to 20 kHzDC accuracy1±(0.5% of FS + 5 µSTR)Measurement range/measurable rangeMeasurement range (FS)Measurable range (–FS to +FS)500 µSTR–500 µSTR to 500 µSTR1000 µSTR–1000 µSTR to 1000 µSTR2000 µSTR–2000 µSTR to 2000 µSTR5000 µSTR–5000 µSTR to 5000 µSTR10,000 µSTR–10,000 µSTR to 10,000 µSTR20,000 µSTR–20,000 µSTR to 20,000 µSTRmV/V range support mV/V range = 0.5 ϫ (µSTR range/1000)Maximum allowable input voltage (1 kHz or less)10 V (DC + ACpeak)Maximum allowable in-phase voltage42 V (DC + ACpeak) (CAT I and CA T II, 30 Vrms)T emperature coefficientZero point±5 µSTR/°C (typical value)Gain±(0.02% of FS)/°C (typical value)Internal filter OFF, 1 kHz, 100 Hz, 10 HzInput connector NDIS standardAccessory (a set of connector shell for solder connection)2 NDIS connectors (A1002JC)Recommended bridge head (NDIS type) (sold separately)701955 (bridge resistance of 120 Ω) (w/ 5 m cable)701956 (bridge resistance of 350 Ω) (w/ 5 m cable)10Alligator clip (701954)Isolated probe (700929)Safety adaptor lead (701901)Isolated logic probe (700987)Earphone Mic (w/ PUSH switch) (701951)Microsoft, MS-DOS, and Windows are either trademarks or registered trademarks of。
H Certifications and compliancesCode of protection categoriesATEX:IECEx / INMETRO / EAC:CSA:CCC:I M2, Ex db I/IIC Mb/Gb, Ex eb IIC Gb, Ex tb IIIC Db Ex d I/IIC, Ex e I/IIC, Ex tb IIIC Db Cl I Zn 1 AEx db IIC Gb, Ex db IIC Gb (see certificate for threadforms& material details)Raxton Exd/Exe adaptors and reducers provide a means of connection between dissimilar thread forms or sizes. Metallic adaptors have a hexagonal body; if space is a critical factor, round adaptors can be offered with an equivalent diameter of the standard hexagonal item.Raxton adaptors and reducers are marked with the applicable approval number and size.IECEx:CSA:IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 60079-31 CSA-C22.2 No. 60079-0, CSA-C22.2 No. 60079-1ANSI/UL 60079-0, ANSI/UL 60079-1Certificate detailsATEX: IECEx: CSA: EAC:ITS16ATEX101336X IECEx ITS16.0011X CSA 200455-1003277 (brass and stainless only) TC RUC-G B.M Ю62.B.00447/19INMETRO:NCC 18.0133XCCOE:P393297/1Temperature-60°C to +200°C ; depending on O-ring or sealing washer usedIngress protection (IP):Independently tested to IP66 / IP68 when fitted in accordance tomanufacturer’s instructions.Type ABTypeBBTechnicalspecificationType ABHexType BB HexØDBC A/FEF EGA DF REFAB Compliance standardsATEX /EAC: INMETRO:EN 60079-0, EN 60079-1, EN 60079-7, EN 60079-31ABNT NBR IEC 60079-0, ABNT NBR IEC 60079-1, ABNT NBR IEC 60079-7, ABNT NBR IEC 60079-31Ex d IIC Gb, Ex e IIC Gb, Ex tD A21 IP6X CCC:2020322313001350 (Adaptors), 2020322313001351 (Reducers)CCC:GB 3836.1-2010, GB 3836.2-2010, GB 3836.3-2010, GB 12476.1-2013, GB 12476.5-2013DimensionsA BC ØD EFG HMale metric (6g)Female metric (6H)A/F BoreThread lengthThread depth Ref Hex wall M12M1215.97.015.017.021.0 4.0M1619.17.015.017.021.0 4.0M16M1619.110.415.017.021.0 4.0M2024.010.415.017.021.0 4.0M2530.510.415.017.021.0 4.0M20M2024.014.415.017.021.0 4.0M2530.514.415.017.021.0 4.0M3237.614.415.017.022.0 5.0M25M2530.519.415.017.021.0 4.0M3237.619.415.017.022.0 5.0M32M3237.626.815.017.022.0 5.0M4047.226.815.017.022.0 5.0M5055.926.815.017.022.0 5.0M40M4047.233.515.017.022.0 5.0M5055.933.515.017.022.0 5.0M50M5055.942.815.017.022.0 5.0M6370.142.815.017.022.0 5.0M63M6370.154.415.017.022.0 5.0M7580.054.415.017.022.0 5.0M75M7580.066.715.017.022.05.0Type ABMetallic adaptors are available for up to two step sizing, e.g. M20 male x M32 female Other sizes / theads are available upon request.Type BBOther sizes / theads are available upon request.ABC DE FMale metric (6g)Female metric (6H)A/FThread lengthHex lengthTotal lengthM16M12 & BELOW 19.115.0 4.019.0M20M16 & BELOW 24.015.0 4.019.0M25M20 & BELOW 27.915.0 4.019.0M32M25 & BELOW 37.515.0 4.019.0M40M32 & BELOW 47.215.0 5.020.0M50M40 & BELOW 55.915.0 6.021.0M63M50 & BELOW 70.115.07.022.0M75M63 & BELOW 80.015.08.023.0M80M63 & BELOW 90.020.09.029.0M90M80 & BELOW 95.020.010.030.0M100M90 & BELOW110.020.011.031.0Metallic adaptors and reducers-Product codingIsometric to BS 3643:1981Certified products -Raxton adaptors now available in 2 step formatBritish Standard Pipe to BS 21:1985National Pipe Threadto ANSI / ASME:1983AdaptorsReducersNotcertifiedSize Major diamete r (mm)Threadsperinch Pitch 16mm(M16)15.96816.93 1.5020mm(M20)19.96816.93 1.5025mm(M25)24.96816.93 1.5032mm(M32)31.96816.93 1.5040mm(M40)39.96816.93 1.5050mm(M50)49.96816.93 1.5063mm(M63)62.96816.93 1.5075mm(M75)74.96816.931.50Size Majordiamete r (mm)Threadsperinch Pitch ⅛"NPT 10.2827.000.94¼"NPT 13.7218.00 1.41⅜"NPT 17.1518.00 1.41½"NPT 21.3414.00 1.81¾"NPT 26.6714.00 1.811"NPT 33.4011.50 2.211¼"NPT 42.1611.50 2.211½"NPT 48.2611.50 2.212"NPT 60.3311.50 2.212½"NPT 73.038.00 3.183"NPT 88.908.00 3.184"NPT114.308.003.18Other sizes and theads are available including ET, PG, BSPT and NPSM, contact Customer Services for details.Size Major diamete r (mm)Threadsperinch Pitch ⅛" BSP P 9.73628.000.91¼" BSP P 13.1619.00 1.34⅜" BSP P 16.6619.00 1.34½" BSP P 20.9614.00 1.81¾" BSP P 26.4414.00 1.811" BSP P 33.2511.00 2.311¼" BSP P 41.9111.00 2.311½" BSP P 47.8011.00 2.312" BSP P 59.8111.00 2.312½" BSP P 75.1811.00 2.313" BSP P 87.8811.00 2.314" BSP P113.0311.002.31Female threadM 16M 20M 25M 32M 40M 50M 63M 75½"N P T /B S P¾"N P T /B S P1"N P T /B S P1¼"N P T /B S P1½"N P T /B S P2"N P T /B S P2½"N P T /B S P3"N P T /B S P4"N P TM a l e t h r e a dM16M20M25M32M40M50M63M75½"NPT ¾"NPT 1"NPT1¼"NPT 1½"NPT 2"NPT 2½"NPT 3"NPT 4"NPT ½"BSP ¾"BSP 1"BSP 1¼"BSP 1½"BSP 2"BSP 2½"BSP 3"BSPMetallic adaptors and reducers –Thread selection / dimensions。
