White OLED and Color Filter-updated

Identity Number K1.0024074Model ALEXA Mini LFSensor Type Large Format ARRI ALEV III (A2X) CMOS sensor with Bayer pattern colorfilter arraySensor Maximum Resolution and Size4448 x 309636.70 x 25.54 mm / 1.444 x 1.005"⌀ 44.71 mm / 1.760"Sensor Frame Rates0.75 - 90 fpsWeight∼2.6 kg / ∼5.7 lbs(camera body with LPL lens mount)800 g (MVF-2)Photosite Pitch8.25 μmSensor Active Image Area Photosites LF Open Gate ProRes 4.5K: 4448 x 3096LF Open Gate ARRIRAW 4.5K: 4448 x 3096LF 16:9 ProRes HD: 3840 x 2160LF 16:9 ProRes 2K: 3840 x 2160LF 16:9 ProRes UHD: 3840 x 2160LF 16:9 ARRIRAW UHD: 3840 x 2160LF 2.39:1 ProRes 4.5K: 4448 x 1856LF 2.39:1 ARRIRAW 4.5K: 4448 x 1856Sensor Active Image Area Dimensions LF Open Gate ProRes 4.5K: 36.70 x 25.54 mm / 1.445 x 1.006"LF Open Gate ARRIRAW 4.5K: 36.70 x 25.54 mm / 1.445 x 1.006"LF 16:9 ProRes HD: 31.68 x 17.82 mm / 1.247 x 0.702"LF 16:9 ProRes 2K: 31.68 x 17.82 mm / 1.247 x 0.702"LF 16:9 ProRes UHD: 31.68 x 17.82 mm / 1.247 x 0.702"LF 16:9 ARRIRAW UHD: 31.68 x 17.82 mm / 1.247 x 0.702"LF 2.39:1 ProRes 4.5K: 36.70 x 15.31 mm / 1.445 x 0.603"LF 2.39:1 ARRIRAW 4.5K: 36.70 x 15.31 mm / 1.445 x 0.603" Recording File Container Size LF Open Gate ProRes 4.5K: 4480 x 3096LF Open Gate ARRIRAW 4.5K: 4448 x 3096LF 16:9 ProRes HD: 1920 x 1080LF 16:9 ProRes 2K: 2048 x 1152LF 16:9 ProRes UHD: 3840 x 2160LF 16:9 ARRIRAW UHD: 3840 x 2160LF 2.39:1 ProRes 4.5K: 4480 x 1856LF 2.39:1 ARRIRAW 4.5K: 4448 x 1856Recording File Image Content LF Open Gate ProRes 4.5K: 4448 x 3096LF Open Gate ARRIRAW 4.5K: 4448 x 3096LF 16:9 ProRes HD: 1920 x 1080LF 16:9 ProRes 2K: 2048 x 1152LF 16:9 ProRes UHD: 3840 x 2160LF 16:9 ARRIRAW UHD: 3840 x 2160LF 2.39:1 ProRes 4.5K: 4448 x 1856LF 2.39:1 ARRIRAW 4.5K: 4448 x 1856Exposure Latitude14+ stops over the entire sensitivity range from EI 160 to EI 3200 asmeasured with the ARRI Dynamic Range Test Chart (DRTC-1) Exposure Index Adjustable from EI 160-3200 in 1/3 stopsEI 800 base sensitivityShutter Electronic shutter, 5.0°- 356° or 1s - 1/8000sRecording Formats MXF/ARRIRAWMXF/Apple ProRes 4444 XQMXF/Apple ProRes 4444MXF/Apple ProRes 422 HQRecording Media Codex Compact DrivesRecording Frame Rates LF Open Gate ProRes 4.5K: 0.75 - 40 fpsLF Open Gate ARRIRAW 4.5K: 0.75 - 40 fpsLF 16:9 ProRes HD: 0.75 - 90 fpsLF 16:9 ProRes 2K: 0.75 - 90 fpsLF 16:9 ProRes UHD: 0.75 - 60 fpsLF 16:9 ARRIRAW UHD: 0.75 - 60 fpsLF 2.39:1 ProRes 4.5K: 0.75 - 60 fpsLF 2.39:1 ARRIRAW 4.5K: 0.75 - 60 fpsNote: maximum fps values are preliminary informationRecording Modes Standard real-time recordingNo Pre-recordingNo IntervalometerViewfinder Type Multi Viewfinder MVF-2 with 4" flip-out monitorViewfinder Technology OLED viewfinder displayLCD fold out monitorViewfinder Resolution Pixel1920 x 1080Viewfinder Diopter Adjustable from -5 to +5 dioptersColor Output Rec 709Rec 2020Log CCustom Look (ARRI Look File ALF-2)Look Control Import of custom 3D LUTASC CDL parameters (slope, offset, power, saturation)White Balance Manual and auto white balance, adjustable from 2000K to 11000K in 10KstepsColor correction adjustable range from -16 to +16 CC1 CC corresponds to 035 Kodak CC values or 1/8 Rosco valuesFilters Built-in motorized ND filters 0.6, 1.2, 1.8Fixed optical low pass, UV, IR filterImage Outputs 1x proprietary signal output for MVF-2 viewfinder on VF CoaXPressconnector (video, audio, power, control signals)SDI 1:-HD only, Processed or Clean, with or without a look file applied-1.5G 422 HD (SMPTE ST292-1, up to 30 fps, progessive (p) or progressivesegmented frame (psf))-3G 422 HD (SMPTE ST425-1, up to 60 fps, p)-3G 444 HD (SMPTE ST425-3, up to 30 fps, p)SDI 2:-HD or UHD, Clean only, with or without a look file applied, or SDI 1 clone-1.5G 422 HD (SMPTE ST292-1, up to 30 fps, p or psf)-3G 422 HD (SMPTE ST425-1, up to 60 fps, p)-3G 444 HD (SMPTE ST425-3, up to 30 fps, p)-6G 422 UHD (SMPTE ST2081-10, up to 30 fps, p)“Clean” is an image without surround view or overlays (status, false color,zebra, framelines, etc.)“Processed” is an image with surround view or overlays.Lens Squeeze Factors 1.001.251.301.501.651.802.00Exposure and Focus Tools False ColorZebraZoomAperture and Color PeakingAudio Input1x LEMO 6pin balanced stereo line in with 12V power output(Line input max. level +24dBu correlating to 0dBFS)Audio Output SDI (embedded)3,5mm stereo headphone jack (on MVF-2)Audio Recording 2 channel linear PCM, 24 bit 48 kHzRemote Control Options MVF-2 viewfinder can act as wired remote control with 10m/33ft cableWeb-based remote control from smart phones, tablets and laptops viaWiFi & Ethernet (beta version)Camera Access Protocol (CAP) via Ethernet & WiFiGPIO interface for integration with custom control interfacesWCU-4 hand-unit with control over lens motors and operationalparameters via built-in white radioSXU-1 hand-unit with control over one lens channelOCU-1 and Master Grip control of lens and user buttonsInterfaces1x LEMO 5pin LTC Timecode In/Out1x LEMO 10pin Ethernet for remote control and service1x BNC SYNC IN1x LEMO 7pin EXT multi purpose accessory interface w. RS pin and 24Vpower output1x LEMO 4pin LBUS (on lens mount) for lens motors, daisy chainable1x USB 2.0 in media bay (for user setups, look files etc)Wireless Interfaces Built-in WiFi module (IEEE 802.11b/g)Built-in White Radio for ARRI lens and camera remote controlLens Mounts LPL lens mount with LBUS connectorPL-to-LPL adapterLeitz M mount (available from Leitz)Flange Focal Depth LPL mount: 44 mmwith PL-to-LPL adapter: 52 mmPower Input1x LEMO 8pin (11-34 V DC)Power Consumption Around 65 W when recording ARRIRAW at 24 fps with MVF-2 attached(preliminary information)Power Outputs 1x Fischer 3pin 24V RS1x LEMO 2pin 12V1x LEMO 7pin EXT 24V power outputPower Management-Measurements HxWxL140 x 143 x 188 mm / 5.5 x 5.6 x 7.4"(camera body with LPL lens mount)Operating Temperature-20° C to +45° C / -4° F to +113° F @ 95% relative humidity max, noncondensing, splash and dust proof through sealed electronics Storage Temperature-30° C to +70° C / -22° F to +158° FSound Level< 20 dB(A) at 24fpsSoftware Licenses-。

A 0.23-in. High-Resolution OLED Microdisplay for Wearable Displays Reo Asaki*, Seiichi Yokoyama*, Hideyuki Kitagawa*, Shingo Makimura*, Fumiaki Abe*, Takashi Yamazaki**, Takayoshi Kato**, Michihiro Kanno**,Yusuke Onoyama***, Eiji Hasegawa***, Katsuhide Uchino**** Display Device Department1, Image Sensor Business Division, Device Solutions Business Group ** Device Technology Department, Semiconductor Technology Development Division, R&D Platform *** OLED Display Engineering Department, Display Development Division, R&D PlatformSony Corporation, 4-14-1, Asahi-cho, Atsugi, Kanagawa, JapanAbstractA 0.23 inch nHD+ OLED microdisplay has been developed with high-resolution 7.8μm pixel pitch, long life, and lower power consumption than prior OLED microdisplays. This newly developed OLED microdisplay is suitable for wearable displays and viewfinders. A 0.39 inch XGA and 0.7 inch Full-HD microdisplay will also be discussed.Author KeywordsMicrodisplay; OLED; Wearable Display; Near-to-Eye1. IntroductionWe have launched 0.5inch XGA OLED microdisplay(M-OLED) for an electronic view finder of the digital camera, and 0.7inch 720p display for a head mounted display in 2011 [1-2]. The shipment quantity of the M-OLED displays achieved one million panels in January 2013. The application extends for consumer and professional camcorders, electronic binoculars, and head mounted displays for medical use. In a notable thing, Sony’s head mounted displays developed new market of image experience that is realized by the M-OLED display with superior image quality. The wearable device market has been enlarging rapidly with the spread of smart phone, and smart watch catches attention. A glass type display for exclusive use such as sports glass gains popularity. In addition, the smart glass will attract considerable attention in 2014.As noted above, the M-OLED display is establishing a high recognition by incorporated in the mirror-less camera and the head mounted display. It can also provide a suitable solution for wearable display which has been enlarging the market rapidly [3-6]. We have commercialized 9.9μm pixel pitch M-OLED displays, however wearable display requires a higher resolution. We have developed the new M-OLED displays with a 7.8μm pixel pitch, which evolved higher resolution from our conventional products. The newly developed M-OLED displays realized the characteristics improvement of the lifetime and the power consumption. In this work, we report the 0.23inch nHD+ suitable for wearable display. 0.39inch XGA, and 0.7inch Full-HD display are also presented.2. Target PerformanceLow image quality has been hindered growing of the head mounted display market. Our M-OLED display solved this problem. The M-OLED is a high image quality display having excellent characteristics such as high contrast, wide color gamut, and fast response time [1,3]. Furthermore, the M-OLED display is suitable for the new type of head mounted display like a see- through type smart glass, because it has high visibility as well as high image quality. Wearabilities without a sense of incongruity, smart and fashionable design are needed to make the wearable display popular. In addition, the display with small size, lightweight, long lifetime, low power consumption, and high reliability are required. Sony’s M-OLED display can provide high image quality, high visibility, small size, lightweight and high reliability for the mass production. However, long lifetime and low power consumption are generally weak points of the OLED device, so we worked on these improvements.3. Features of M-OLED Display(a) Device StructureFigure 1 shows the schematic diagram of M-OLED display cross sectional structure. Our top emission white OLED and color filter structure is employed to realize ultra-high definition. The anode electrode is formed on a Si back plane, and white OLED and the cathode electrode are deposited on the Si back plane. The white OLED device is a single stack with top emission structure. In order to protect the OLED device, a passivation layer is formed on it. The color filter array on glass is aligned with pixels and attached on the Si back plane.(b) High Image Quality and High VisibilitySony’s M-OLED display accomplished high image quality and high visibility by excellent characteristics of self-emitting OLED device. Figure 2 shows the relation between luminance and signal level for M-OLED. A black float occurred in LCD due to a light leakage from a backlight, while M-OLED which was self-emitting device achieved a high dynamic range by its higher reproducibility in low luminance range. The newly developed 7.8μm pixel pitch displays achieved above 10000:1 contrast ratio. Figure 3 shows the gradation dependence of color gamut for M-OLED. It is found that gradation dependence of the color gamut for LCD is large, and the color gamut drastically becomes narrow at low gradation. In contrast, the M-OLED display can keep wide color gamut in low gradation, therefore it is capable of natural color expression. The M-OLED display can also express a clear image without moving picture blurring, because this responseFigure 1. Schematic diagram of M-OLED displaySID 2014 DIGEST • 219ISSN 0097-966X/14/4501-0219-$1.00 © 2014 SIDFigure 2. Luminance vs. Signal level for M-OLED and LCDFigure 3. Gradation dependence of color gamutfor M-OLED and LCDtime is less than 10μs. The M-OLED display with high contrast, wide color gamut, and fast response time can realize high visibility for a see-through display as well as high image quality for a non-transparent head mounted display.(c) Mobile PerformanceThe M-OLED display is a simple panel structure, small size, and lightweight without a backlight and a polarizer. The timing controller and the source driver are built in the same Si back plane. This all-In-One package can provide flexible and smart design for mobile products.(d) High ReliabilityIt is considered that OLED device is influenced by temperature and humidity. A typical M-OLED display is especially sensitive because the distance from an active area to a panel edge is very short. The excellent environmental resistance is required for the mobile display such as a smart glass. Therefore, we solved the problem by employing the panel structure and the fabrication process that is hard to receive an external influence. The reliability measurements of the M-OLED display are shown in figure 4 and 5. The results of the high temperature storage test at 85o C are shown in Fig.4, and the results of the temperature humidity storage test at 60o C 90%RH are shown in Fig.5. We realized the high environmental resistant display which characteristics degradation did not occur.4. Characteristics ImprovementWe describe the characteristics of the long lifetime, and the low power consumption realized with the newly developed 7.8μm pixel pitch M-OLED display.(a) Long Lifetime TechnologyThe white OLED device with RGB color filters is employed to realize wide color gamut. Higher efficiency, longer lifetime, and a stable white emission of the white OLED device are accomplished by controlling a carrier balance [2]. The newly developed M-OLED display achieved the improvement of three times longer lifetime in comparison with a conventional one. Figure 6 shows the results of the lifetime measurements under 40o C at 80cd/m2. The lifetime was improved with new OLED materials and the optimization of the new M-OLED device structure. The good stability in color changes was also achieved. Moreover, the long lifetime was realized by improvement of luminance efficiency.Figure 4. Luminance change in high temperature storagetest at 85o CFigure 5. Luminance change in temperature humiditystorage test at 60o C 90%RH220 • SID 2014 DIGESTFigure 6. Luminance vs. time curves at 40o C, 80cd/m2Figure 7. Power consumption of M-OLED displays(b) Low Power Consumption TechnologyIt has been recognized that low power consumption is one of the most important factor in mobile use. The low power M-OLED display is possible to reduce a heat radiation mechanism as well as battery capacity. It affects the size, weight and design flexibility of mobile products. The power consumption of the M-OLED display was reduced by low power supply voltage and luminance efficiency improvement of OLED device. The newly developed M-OLED display achieved halving power consumption as compared to a conventional one. Figure 7 shows the power consumption of the M-OLED displays.The reduction of a power supply voltage contributes to the reduction of power consumption of both OLED emission and driving circuits. Although the power supply voltage of a conventional M-OLED display was logic 3.0V and analog 15V, the voltage of new one achieved logic 1.8V and analog 10V. High current efficiency contributes the reduction of OLED current. We have improved the luminance efficiency of the newly developed M-OLED display to 1.5 times in comparison with a conventional one. This improvement was accomplished by increasing aperture ratio of pixels. The aperture ratio of color filter and the anode electrode was expanded without color mixture between adjacent pixels. The M-OLED device has the micro cavity structure with a reflective anode electrode and a semitransparent cathode [7]. The white OLED device requires the micro cavity filter with high transparency over a wide wavelength region. The micro cavity filter of the new device achieved higher transparency than that ofa conventional one.5. Newly developed M-OLED DisplaysWe have developed the new 0.23inch nHD+, 0.39inch XGA, and 0.7inch Full-HD M-OLED displays. Table 1 shows the specifications of 0.23inch nHD+ M-OLED display. Figure 8 shows the block diagram of driving circuits and system configuration. The M-OLED display is an all-in-one package. The vertical and horizontal scan drivers are both fabricated on the Si back plane. Additionally, the 8-bit digital-to-analog (DAC) converters, the gamma voltage generation circuit, and the timing controllers (T-CON) were fabricated on it.Table 2 and 3 show the specifications of 0.39inch XGA and 0.7inch Full-HD M-OLED display respectively. The both 0.23inch and 039inch M-OLED display are suitable for mobile use such as wearable display and an electronic view finder of the digital camera. The 0.7inch M-OLED display has Full-HD resolution that is the flagship model in our products, and LVDS is employed as a high speed interface. It is suitable for the head mounted display for a high-end AV, an electronic view finder of the professional camcorders, and medical equipment.Table 1. 0.23inch nHD+ display specificationsSpecifications0.23inchResolution(Number of Dots)nHD+(640 x RGB x 400)Pixel Pitch7.8μmMaximum Luminance Target 1000cd/m2Contrast Ratio Typ. 10000:1Color Gamut(u’v’)sRGB : 113%Color Temperature7000KSignal I/FParallel RGB 24bitYCbCr 16bitPower Supply 1.8V(logic), 10VPower Consumptionwhite 200cd/m280mWFigure 8. Block diagram of driving circuitsSID 2014 DIGEST • 221Table 2. 0.39inch XGA display specifications Specifications0.39inchResolution (Number of Dots)XGA (1028 x RGB x 768)Pixel Pitch7.8μm Maximum Luminance500cd/m2 Contrast Ratio Typ. 10000:1 Color Gamut(u’v’) sRGB : 113% Color Temperature7000KSignal I/F Parallel RGB 24bit YCbCr 16bitPower Supply 1.8V(logic), 10V Power Consumptionwhite 200cd/m2180mWTable 3. 0.7inch Full-HD display specifications Specifications0.7inchResolution (Number of Dots)Full-HD (1920 x RGB x 1080)Pixel Pitch8.1μm Maximum Luminance 200cd/m2 Contrast Ratio Typ. 10000:1 Color Gamut(u’v’) sRGB : 113% Color Temperature6500K Signal I/F LVDSPower Supply 1.8V(logic), 10VPower Consumption white 200cd/m2390mW6. ConclusionsWe have successfully developed the 0.23inch nHD+ M-OLEDdisplay with high resolution 7.8μm pixel pitch suitable forwearable display. The 0.39inch XGA and the 0.7inch Full-HDdisplays have also developed. The Sony’s M-OLED displays haveexcellent characteristics of high visibility, small size, lightweight,and high reliability. The newly developed M-OLED displaysachieved three times longer lifetime and halving powerconsumption.7. AcknowledgementsWe would like to express our deepest gratitude to all the membersof a Sony’s M-OLED team who offered tremendous support forrealizing new displays and technologies.8. References[1]Y. Onoyama, J. Yamashita, H. Kitagawa, E. Hasegawa, A.Makita, S. Yokoyama, R. Asaki, E. Kambe, T. Nishimura, J.Yamada, K. Uchino, S. Makimura, Y. Shiraishi, T. Urabe,“0.5-inch XGA Micro-OLED Display on a SiliconBackplane with High-Definition Technologies”, SID’12Digest, p.950 (2012).[2] E. Kambe, M. Nakamura, J. Yamada, K. Uchino, Y.Shiraishi, “Stable White OLED Device Structure for 3D-Compatible Head Mounted Display”, SID’12 Digest, p.363(2012).[3]G. Haas, E. Marcellin-Dibon, “High Resolution OLEDMicrodisplays for Electronic Vision Systems”, IDW’12Digest, p.1083 (2012).[4] A. Ghosh, I. Wacyk, T. Ali, I. Khayrullin, O. Prache, S.Ziesmer, “High-Brightness and High Resolution AMOLEDMicrodisplay”, IDW’12 Digest, p.1079 (2012).[5]I. Khayrullin, I. Wacyk, T. Ali, S. Ziesmer, S. Barry, O.Prache, A. Ghosh, “WUXGA Resolution 3D StereoscopicHead Mounted Full Color AMOLED Microdisplay”, SID’12Digest, p.244 (2012).[6]M. Scholles, U. Vogel, I. Underwood, G. Notni, C. Zilstorff,K. Meerholz, G. Haas, “HYPOLED - High-PerformanceOLED Microdisplays for Mobile Multimedia HMD andProjection Applications”, SID’10 Digest, p.1926 (2010).[7]J. Yamada, T. Hirano, Y. Iwase, T. Sasaoka, “Micro CavityStructures for Full Color AM-OLED Displays”, AM-LCD’02 Digest, p.77 (2002).222 • SID 2014 DIGEST。
