clear; clc;

%生成各种分布的随机数

x1=unifrnd(-1,1,1,1024);%生成长度为1024的均匀分布

x2=normrnd(0,1,1,1024);%生成长度为1024的正态分布

x3=exprnd(1,1,1024);%生成长度为1024的指数分布均值为零

x4=raylrnd(1,1,1024);%生成长度为1024的瑞利分布

x5=chi2rnd(1,1,1024);%生成长度为1024的kaifang分布%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%求各种分布的均值

m1=mean(x1),m2=mean(x2),m3=mean(x3),m4=mean(x4),m5=mean(x5) %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%求各种分布的方差

v1=var(x1),v2=var(x2),v3=var(x3),v4=var(x4),v5=var(x5) %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%求各种分布的自相关函数

figure(1);title('自相关函数图');

cor1=xcorr(x1);cor2=xcorr(x2);cor3=xcorr(x3);cor4=xcorr(x4);cor5=xcorr(x5); subplot(3,2,1),plot(1:2047,cor1);title('均匀分布自相关函数图');

subplot(3,2,2),plot(1:2047,cor2);title('正态分布');

subplot(3,2,3),plot(1:2047,cor3);title('指数分布');

subplot(3,2,4),plot(1:2047,cor4);title('瑞利分布');

subplot(3,2,5),plot(1:2047,cor5);title('K方分布'); %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %求各种分布的概率密度函数

y1=unifpdf(x1,-1,1);

y2=normpdf(x2,0,1);

y3=exppdf(x3,1);

y4=raylpdf(x4,1);

y5=chi2pdf(x5,1); %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% %各种分布的频数直方图

figure(2);

subplot(3,2,1),hist(x1);title('均匀分布频数直方图');

subplot(3,2,2),hist(x2,[-4:0.1:4]);title('正态分布');

subplot(3,2,3),hist(x3,[0:.1:20]);title('指数分布');

subplot(3,2,4),hist(x4,[0:0.1:4]);title('瑞利分布');

subplot(3,2,5),hist(x5,[0:0.1:10]);title('K方分布'); %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%各种分布的概率密度估计

figure(3);

[k1,n1]=ksdensity(x1);

[k2,n2]=ksdensity(x2);[k3,n3]=ksdensity(x3);[k4,n4]=ksdensity(x4);[k5,n5]=ksden sity(x5);

subplot(3,2,1),plot(n1,k1);title('均匀分布概率密度');

subplot(3,2,2),plot(n2,k2);title('正态分布');

subplot(3,2,3),plot(n3,k3);title('指数分布');

subplot(3,2,4),plot(n4,k4);title('瑞利分布');

subplot(3,2,5),plot(n5,k5);title('K方分布'); %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%功率谱密度

%plot(abs(fft(cor2,2^18)));plot(fft(cor2,2^18));plot(fft(cor3,2^18));plot(fft(c or4,2^18));plot(fft(cor5,2^18));

figure(4);

f1=fft(x1,1024);

f2=fft(x2,1024);

f3=fft(x3,1024);

f4=fft(x4,1024);

f5=fft(x5,1024);

p1=f1.*conj(f1)/1024; p2=f2.*conj(f2)/1024; p3=f3.*conj(f3)/1024; p4=f4 .*conj(f4)/1024; p5=f5.*conj(f5)/1024;

f=1000*(0:511)/1024;

subplot(3,2,1),plot(f,log10(p1(1:512)));title('均匀分布功率谱密度');%axis([0 511 0 10]);

subplot(3,2,2),plot(f,log10(p2(1:512)));title('正态分布');%axis([0 511 0 10]); subplot(3,2,3),plot(f,log10(p3(1:512)));title('指数分布');%axis([0 511 0 10]); subplot(3,2,4),plot(f,log10(p4(1:512)));title('瑞利分布');%axis([0 511 0 10]); subplot(3,2,5),plot(f,log10(p5(1:512)));title('K方分布');%axis([0 511 0 10]); %时域，频域特性曲线

%时域特性曲线：

figure(5);

subplot(3,2,1),plot(1:1024,x1);title('均匀分布时域特性曲线');

subplot(3,2,2),plot(1:1024,x2);title('正态分布');

subplot(3,2,3),plot(1:1024,x3);title('指数分布');

subplot(3,2,4),plot(1:1024,x4);title('瑞利分布');

subplot(3,2,5),plot(1:1024,x5);title('K方分布');

%幅频特性曲线%%%%%%%%%%%%%%%

figure(6);

subplot(3,2,1),plot(abs(f1)),axis([0 1023 0 50]);title('均匀分布幅频特性'); subplot(3,2,2),plot(abs(f2));title('正态分布');

subplot(3,2,3),plot(abs(f3)),axis([0 1023 0 200]);title('指数分布');

subplot(3,2,4),plot(abs(f4)),axis([0 1023 0 50]);title('瑞利分布');

subplot(3,2,5),plot(abs(f5)),axis([0 1023 0 100]);title('K方分布');

%相频特性曲线%%%%%%%%%%%%%%%

figure(7);
