SM5006 series SEIKO NPC CORPORATION —1 Crystal Oscillator Module ICs
OVERVIEW The SM5006 series are crystal oscillator module ICs, that incorporate high-frequency, low current consump-tion oscillator and output buffer circuits. Highly accurate thin-film feedback resistors and high-frequencycapacitors are built-in, eliminating the need for external components to make a stable 3rd overtone oscillator.
FEATURES
I Up to 107MHz operation I Capacitors C G , C D built-in I Inverter amplifier feedback resistor built-in I TTL input level I 16mA (V DD = 4.5V) drive capability I 4mA (V DD = 4.5V) drive capability (5006AH × ) I Output three-state function I 2.7 to 5.5V supply voltage
I Oscillator frequency output
I 8-pin SOP (SM5006 ××× S)
I Chip form (CF5006 ××× )
SERIES CONFIGURATION
Version *1 *1. Chip form devices have designation CF5006 ××× . gm ratio3V operating5V operatingBuilt-in capacitanceR f [k Ω ]Input levelOutput duty level
