BT588-20中文资料

带尾插 不带尾插
最小线径尺寸AWG
20
18
20
18
电线种类
XTW
SPT-1/SPT-2
XTW
SPT-1/SPT-2
最小电线温度 最大额定电流（A） 保险丝规格 保险丝位置
105度 1.75A 5 火线及地线处
105度 1.75A 5 火线及地线处
105度 3.5A 5 火线处
105度 3.5A 5 火线处
2019/2/1 3
UL部件认证标志
UL列名标志
2019/2/1
4
进入北美市场的其它安规标志
2019/2/1
5
2. UL588涵盖范围
2.1 串联灯串 (Series connected light string)
2019/2/1
6
2. UL588涵盖范围
2.2 并联灯串 (Candelabra. Or Intermediatescrew Lampholder)
2019/2/1
7
2. UL588涵盖范围
2.3 装饰灯(OUTFIT) 2.3.1 灯串带套花(Attachment) 2.3.2 雪屋 (Snow house) 2.3.3 框架灯 (Frame) 2.3.4 铁架灯(Sculpture) 2.3.5 烛台灯(Candle light) 2.3.6 Tree Stand 2.3.7 电动马达产品 (Motorized decorative displays)
电动产品（Motorized）的外部电源线，至少为18AWG Type SPT-2
2019/2/1
16
3.结构及部件分解说明
3.2.1 一串联灯串之最大电流仅可为 0.6A 例外: 一灯串不带尾插且配有极性之插头, 其最大之电流可达1.8A
