IPB100N06S3L-04中文资料

  • 格式：pdf
  • 大小：197.16 KB
  • 文档页数：9

IPB100N06S3L-04IPI100N06S3L-04, IPP100N06S3L-04

OptiMOS®-T2 Power-Transistor

Features• N-channel - Enhancement mode

• Automotive AEC Q101 qualified• MSL1 up to 260°C peak reflow• 175°C operating temperature• Green product (RoHS compliant)• 100% Avalanche tested

Maximum ratings, at Tj=25 °C, unless otherwise specified

ParameterSymbolConditionsUnitContinuous drain current1)IDTC=25 °C, VGS=10 V

100A

TC=100 °C, VGS=10 V

2)

100

Pulsed drain current2)ID,pulseTC=25 °C

400

Avalanche energy, single pulse2)EASID=50 A

1090mJ

Avalanche current, single pulseIAS100A

Gate source voltage3)V

GS±16V

Power dissipationPtotTC=25 °C214WOperating and storage temperatureTj, Tstg-55 ... +175°CIEC climatic category; DIN IEC 68-155/175/56

Value

VDS 55VRDS(on),max (SMD version)3.5mΩ

ID100A

Product Summary

TypePackageMarkingIPB100N06S3L-04PG-TO263-3-23PN06L04IPI100N06S3L-04PG-TO262-3-13PN06L04IPP100N06S3L-04PG-TO220-3-13PN06L04

PG-TO220-3-1PG-TO262-3-1PG-TO263-3-2

Rev. 1.1page 12007-11-07

元器件交易网www.cecb2b.com IPB100N06S3L-04IPI100N06S3L-04, IPP100N06S3L-04

ParameterSymbolConditionsUnitmin.typ.max.

Thermal characteristics2)Thermal resistance, junction - caseRthJC--0.7K/WThermal resistance, junction - ambient, leadedRthJA--62

SMD version, device on PCBRthJAminimal footprint--62

6 cm2 cooling area4)--40

Electrical characteristics, at Tj=25 °C, unless otherwise specifiedStatic characteristicsDrain-source breakdown voltageV(BR)DSSVGS=0 V, ID= 1 mA

55--V

Gate threshold voltageVGS(th)VDS=VGS, ID=150 µA1.21.62.2

Zero gate voltage drain currentIDSSVDS=55 V, VGS=0 V, Tj=25 °C-0.011µAVDS=55 V, VGS=0 V,

Tj=125 °C

2)

-1100

Gate-source leakage currentIGSSVGS=16 V, VDS=0 V-1100nADrain-source on-state resistanceRDS(on)VGS=5 V, ID=59 A

-4.96.2mΩ

VGS=5 V, ID=59 A,

SMD version-4.65.9

VGS=10 V, ID=80 A

-3.13.8

VGS=10 V, ID=80 A,

SMD version-2.83.5

Values

Rev. 1.1page 22007-11-07元器件交易网www.cecb2b.com IPB100N06S3L-04IPI100N06S3L-04, IPP100N06S3L-04

ParameterSymbolConditionsUnitmin.typ.max.

Dynamic characteristics2)Input capacitanceCiss-17270-pFOutput capacitanceCoss-2165-

Reverse transfer capacitanceCrss-2070-

Turn-on delay timetd(on)-30-ns

Rise timetr-58-

Turn-off delay timetd(off)-82-

Fall timetf-55-

Gate Charge Characteristics2)Gate to source chargeQgs-71-nCGate to drain chargeQgd-45-

Gate charge totalQg-241362

Gate plateau voltageVplateau-3.8-V

Reverse DiodeDiode continous forward current2)I

S--100A

Diode pulse current2)I

S,pulse--400

Diode forward voltageVSDVGS=0 V, IF=80 A, Tj=25 °C0.60.91.3VReverse recovery time2)t

rr-95-ns

Reverse recovery charge2)Q

rr-135-nC

2) Defined by design. Not subject to production test.

3) Qualified at -5V and +16V.

4) Device on 40 mm x 40 mm x 1.5 mm epoxy PCB FR4 with 6 cm2 (one layer, 70 µm thick) copper area for drain

connection. PCB is vertical in still air.

1) Current is limited by bondwire; with an RthJC = 0.7 K/W the chip is able to carry 176 A at 25°C. For detailed

information see Application Note ANPS071E

TC=25 °C

ValuesVGS=0 V, VDS=25 V,

f=1 MHz

VDD=27.5 V,

VGS=10 V, ID=80 A,

RG=2 Ω

VDD=11 V, ID=80 A, VGS=0 to 10 V

VR=27.5 V, IF=IS,

diF/dt=100 A/µs

Rev. 1.1page 32007-11-07

元器件交易网www.cecb2b.com IPB100N06S3L-04IPI100N06S3L-04, IPP100N06S3L-041 Power dissipation2 Drain currentPtot=f(TC); VGS ≥ 4 VID=f(TC); VGS ≥ 4 V

3 Safe operating area4 Max. transient thermal impedanceID=f(VDS); TC=25 °C; D=0ZthJC=f(tp)

parameter: tpparameter: D=tp/T

1 µs10 µs

100 µs1 ms

110100

1000

0.1110100VDS [V]

ID [A]single pulse0.010.050.10.510010-110-210-310-410-510-610010-110-210-3tp [s]ZthJC [K/W]

050100150200250050100150200TC [°C]Ptot [W]020406080100120050100150200TC [°C]

ID [A]

Rev. 1.1page 42007-11-07
