Linear PTC Thermistors, Surface Mount ChipTFPTVishay For technical questions, contact: thermistor1@document number: 33017FEATURES•Solderable wraparound terminations•Alumina substrate base with PTC thin film element •0603, 0805 and 1206 sizes available •Available in tape and reel packaging•Standard tolerances: ± 0.5 %, ± 1 %, ± 5 %•Contact factory for non-standard tolerance •Operation range - 55 °C to + 125 °CNotes1.Contact Vishay if closer TCR lot tolerance is desired2.Other R 25 values and tolerances are available upon requestNote1.Rated Continuous Working Voltage is maximum working voltage or square root of the power rating times resistance value, whichever is less.STANDARD ELECTRICAL SPECIFICATIONSTCR AT ROOM TEMPERATURE (25 °C) SEE TYPICAL CURVE FOR TCR AT OTHER TEMPS.TCR 1)TOLERANCEppm/KR 25 Ω VALUE RANGE (0.5 %, 1 %, 5 % TOLERANCE)2)060308051206MIN.MAX.MIN.MAX.MIN.MAX.4110 ppm/K± 400100-1K100- 5K100-10KSTANDARD RESISTANCE VALUES100270680 1.8K 4.7K 120330820 2.2K 5.6K 1503901K 2.7K 6.8K 180470 1.2K 3.3K 8.2K 2205601.5K3.9K10.0KSTANDARD TECHNICAL SPECIFICATIONSPART NUMBER POWER RATINGMAXIMUM WORKING VOLTAGE RCWV 1)TFPT 060375 mW 30 V DC TFPT 0805100 mW 40 V DC TFPT 1206125 mW50 V DCTFPTLinear PTC Thermistors, Surface Mount ChipVishaydocument number: 33017For technical questions, contact: thermistor1@DIMENSIONS in millimetersCONSTRUCTION TYPICAL CURVENotes1.Environmental performance specifications use test procedures as outlined in MIL-R-23648D and MIL-STD-2022.TFPTs are ESD sensitivePART NUMBER A B C DE TFPT 0603 1.60 ± 0.100.85 ± 0.100.45 ± 0.100.30 ± 0.200.30 ± 0.20TFPT 0805 2.00 ± 0.15 1.25 ± 0.150.45 ± 0.100.40 ± 0.200.40 ± 0.20TFPT 12063.20 ± 0.151.60 ± 0.150.55 ± 0.100.50 ± 0.250.50 ± 0.25PERFORMANCE 1)TESTMAXIMUM % ΔR 2)High T emperature Exposure (100 hours at 125 °C)0.25 %Effects of Bonding (10 seconds solder dip at 260 °C)0.25 %Thermal Shock (30 minutes at 65 °C, 30 minutes at 125 °C, 5 cycles)0.25 %Low Temperature Operation (Maximum rated power for 2 hours at - 65 °C)0.25 %Short Time Overload (2.5 x RCWV for 5 seconds)0.25 %Load Life (1000 hours 70 °C, maximum rated power 1.5 hours “O N ”, 0.5 hours “OFF”0.25 %Solderability (95 % coverage P/F)P Leaching (Physical damage P/F)PTFPTVishayLinear PTC Thermistors, Surface Mount Chip For technical questions, contact: thermistor1@document number: 33017Ratio Tolerance Examples:At 40 °C, Ratio = 1.063 ± 0.5 % (0.005)so, Ratio = 1.058 to 1.068At 125 °C, Ratio = 1.460 ± 3 % (0.044)so, Ratio = 1.416 to 1.504AVERAGE T.C.S TFPT ALL SIZES & VALUESTEMP RATIO TEMP RATIO TEMP RATIO TEMP RATIO - 550.698- 100.86135 1.04280 1.240- 540.701- 90.86536 1.04681 1.244- 530.705- 80.86937 1.05082 1.249- 520.708- 70.87338 1.05483 1.254- 510.712- 60.87639 1.05884 1.258- 500.715- 50.88040 1.06385 1.263- 490.719- 40.88441 1.06786 1.268- 480.722- 30.88842 1.07187 1.272- 470.726- 20.89243 1.07588 1.277- 460.729- 10.89644 1.08089 1.282- 450.73300.90045 1.08490 1.287- 440.73610.90446 1.08891 1.291- 430.74020.90847 1.09292 1.296- 420.74330.91148 1.09793 1.301- 410.74740.91549 1.10194 1.306- 400.75050.91950 1.10595 1.311- 390.75460.92351 1.11096 1.315- 380.75770.92752 1.11497 1.320- 370.76180.93153 1.11898 1.325- 360.76590.93554 1.12399 1.330- 350.768100.93955 1.127100 1.335- 340.772110.94356 1.131101 1.340- 330.775120.94757 1.136102 1.345- 320.779130.95158 1.140103 1.349- 310.783140.95559 1.145104 1.354- 300.786150.95960 1.149105 1.359- 290.790160.96361 1.153106 1.364- 280.794170.96762 1.158107 1.369- 270.797180.97163 1.162108 1.374- 260.801190.97564 1.167109 1.379- 250.805200.98065 1.171110 1.384- 240.808210.98466 1.176111 1.389- 230.812220.98867 1.180112 1.394- 220.816230.99268 1.185113 1.399- 210.820240.99669 1.189114 1.404- 200.82325 1.00070 1.194115 1.409- 190.82726 1.00471 1.198116 1.414- 180.83127 1.00872 1.203117 1.419- 170.83428 1.01273 1.208118 1.424- 160.83829 1.01774 1.212119 1.429- 150.84230 1.02175 1.217120 1.434- 140.84631 1.02576 1.221121 1.439- 130.85032 1.02977 1.226122 1.444- 120.85333 1.03378 1.230123 1.450- 110.857341.037791.235124 1.4551251.460RATIO TOLERANCESLOW TEMPERATURE HIGH TEMPERATURE TOLERANCE - 55 °C ± 4 %- 40 °C + 125 °C ± 3 %- 20 °C + 85 °C ± 2 %0 °C + 55 °C ± 1 %+ 12 °C + 40 °C ± 0.5 %Legal Disclaimer NoticeVishay Document Number: NoticeSpecifications of the products displayed herein are subject to change without notice. Vishay Intertechnology, Inc., or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies.Information contained herein is intended to provide a product description only. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Vishay's terms and conditions of sale for such products, Vishay assumes no liability whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of Vishay products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications. Customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Vishay for any damages resulting from such improper use or sale.。
