TV04A330J中文资料Working Peak Reverse Voltage: 5.0 - 170 Volts Power Dissipation: 400 WattsTV04A5V0 Thru TV04A171FeaturesIdeal for surface mount applications Easy pick and placePlastic package has Underwriters Lab. flammability classification 94V-0 Typical IR less than 1uA above 10V Fast reponse time: typically less 1nS for uni-direction, less than 5nS for bi-directiona, from 0 V to BV min.Mechanical dataCase: JEDEC DO-214AC molded plastic Terminals: solderable per MIL-STD-750,method 2026Polarity: Cathode band denoted Mounting position: AnyApprox. weight:0.064 gram Maximum Ratings and Electrical CharactericsRating at 25 C ambient temperature unless otherwise specified.Single phase, half wave, 60Hz, resistive or inductive load.For capacitive load, derate current by 20%Characteristics Peak Power Dissipation on 10/1000uS Waveform (Note 1, Fig. 1)Peak Pulse Current of on 10/1000uS Waveform (Note 1, Fig.3)Steady State Power Dissipation at T L =75 C (Note 2)Peak Forfard Surge Current, 8.3mS SingleHalf Sine-Wave Superimposed on RatedLoad, Uni-Directional Only (Note 3)Maxinum Instantaneous Forward Voltage at 25.0A for Uni-Directional only (Note 3 & 4) Operation Junction T emperature Range Storage Temperature RangeSymbolP PPMI PPM P M(AV)I FSM VF Tj T STGNote: 1. Non-Repetitive Current Pulse, per Fig. 3 and Derated above T A=25 C, per Fig. 2. 2. Mounted on 5.0x5.0mm Copper Pads to Each T erminal. 3. Lead T emperature at TL=75 C per Fig. 54. Measured on 8.3 mS Single Half Sine-Wave for Uni-Directional Devices Only.5. Peak Pulse Power Waveform is 10/1000uS.Value 400 See Table 1 1.040 3.5 -55 to +150 -55 to +150UnitsWatts A WattsAVolts C CRating and Characteristic Curves (TV04A5V0 Thru TV04A171) Fig. 1 - Reverse CharacteristicsFig. 2 - Pulse Derating Ciurve0.1 1.0 10 100 1000 10000Pulse Width, t d (uS)P e a k P u l s e P o w e r , P P P M (K W )0 25 50 75 100 125 150 175Ambient Temperature,T A ( C)P e a k p u l s e P o w e r (P p p ) o r C u r r e n t (I p p )D e r a t i n g i n P e r c e n t (%)Fig. 4 - Typica l Junction CapacitanceJ u n c t i o n C a p a c i t a n c e , C j (p F ) Breakdown Voltage,V BR (Volts)1.0 10 100 1,000Fig. 5 - Steady State Power Derating CurveLeadt Temperature,T L ( C)S t e a d y S t a t e P o w e r D i s s i p a t i o n , P M (A V ), W a t t sFig. 6 - Maxinum Non-Repetitive Peak Forward Surge Current (Uni- Directional Only)P e a k F o r w a r d S u r g e C u r r e n t , I F S M (A )100503010Number of Cycle at 60Hz1.41.2 1.0 0.8 0.6 0.4 0.2 0Fig. 3 - Pulse WaveformTime, t (mS)0 1.0 2.0 3.0 4.0P e a k P u l s e C u r r e n t , I P P M ( %)Table 1. Specification1) Suffix K Denotes 10% tolerance devices, suffix J denotes 5% tolerance devices.2) Suffix B after part number to specify bi-directional devices.3) For bi-directional devices having VR of 10 volts and under, the IR limit is double.。
