GB162B VER: 3.0 - 0 - Issue date: 2006/07/27 JEWEL HILL ELECTRONIC CO.,LTD. ED
Module No. GB162B JEWEL HILL ELECTRONIC CO.,LTD.
SPECIFICATIONS FOR LCD MODULE
Office Address: Rm. 518,5/F., 101 Shangbu Industrial District, HuaqiangNorthRoad, Shenzhen, China TEL : (86)-755-83362489 83617492 FAX: (86)-755-83286396 83365871 E-mail: sales@jhlcd.com jhlcd@21cn.com Website: www.jhlcd.com
元器件交易网www.cecb2b.com GB162B VER: 3.0 - 1 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. TABLE OF CONTENTS LCM NUMBER SYSTEM.....................................................................2 1. GENERAL DESCRIPTION...........................................................3 2. FEATURES......................................................................................3 3. MECHANICAL SPECIFICATION..............................................3 4. MECHANICAL DIMENSION.......................................................4 5. MAXIMUM RATINGS..................................................................5 6. ELECTRICAL CHARACTERISTICS.........................................5 7. MODULE FUNCTION DESCRIPTION......................................6 8. ELECTRO-OPTICAL CHARACTERISTICS..........................12 9. RELIABILITY...............................................................................16 10. PRECAUTIONS FOR USING LCD MODULES......................17 11. USING LCD MODULES..............................................................19 12. REVISION HISTORY..................................................................21 SAMPLE APPROVED REPORT.......................................................22
元器件交易网www.cecb2b.com GB162B VER: 3.0 - 2 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. LCM Number System
NUMBER OF CHAR. PER LINEF: FSTN; X: OTHERVERSION NUMBER: V00~V99IC TYPE:
VIEWING DIRECTION:TEMPERATURE RANGE:
BACKLIGHT TYPE:
SERIAL NUMBER: A~ZGRAPHIC MODULEs: NUMBER OF COMMONs
GRAPHIC MODULEs:NUMBER OF SEGMENTs
COB & SMT LCM
BACKLIGHT COLOR:CHARACTER MODULEs:CHARACTER MODULEs: NUMBER OF LINEG: REFLECTIVE,NONE BACKLIGHTA: TRANSFLECTIVE, EL BACKLIGHTB: TRANSMISSIVE, EL BACKLIGHTC: TRANSFLECTIVE, LED BACKLIGHTD: TRANSMISSIVE, LED BACKLIGHTE: TRANSFLECTIVE, CCFL BACKLIGHTF: TRANSMISSIVE, CCFL BACKLIGHT
A: AMBER; B: BLUE; Y: YELLOW-GREENR: RED; W: WHITE; O: THER COLOR
N: NORMAL TEMPERATURE RANGEU: UPPER(12:00); D: DOWN(6:00)L: LEFT(9:00); R: RIGHT(3:00);
A: BONDING IC, WITH CONTROLLERB: BONDING IC, WITHOUT CONTROLLERC: SMT IC, WITH CONTROLLERD: SMT IC, WITHOUT CONTROLLERO: OTHER TYPE
W: BLACK-WHITE; O: OTHERG: GRAY; Y: YELLOW-GREEN; B: BLUE; LCD COLOR MODE:N: TN; H: HTN; S: STNLCD TYPE:
S: SUPER WIDE TEMPERATURE RANGEW: WIDE TEMPERATURE RANGEM: MIDDLE TEMPERATURE RANGEGB 16 2 B S Y C Y N D A - V01 元器件交易网www.cecb2b.com GB162B VER: 3.0 - 3 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. 1. GENERAL DESCRIPTION The GB162B is a 16C x 2L Character LCD module. It has a STN panel composed of 80 segments and 16 commons. The LCM can be easily accessed by micro-controller via parallel interface.
2. FEATURES Transflective and positive Display Mode STN(Yellow - Green) module
Display Format Character 16C x 2L Input Data 8/4-bit parallel data input from MPU Multiplexing Ratio 1/16 Duty Bias 1/5 Bias Viewing Direction 6 O’clock Backlight LED
3. MECHANICAL SPECIFICATION Item Specifications Unit Dimensional outline 122.0 x44.0 x 13.5(max) mm Resolution 80segs x 16coms dots Active area 94.84(W) x 20.0(H) mm Char. pitch 6.0(W) x 10.34(H) mm Char. size 4.84(W) x 9.66(H) mm Dots pitch 0.98 (W)×1.16(H) mm Dots size 0. 92(W)×1.1(H) mm
元器件交易网www.cecb2b.com GB162B VER: 3.0 - 4 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. 4. MECHANICAL DIMENSION
--*1R&ELTYPE9.41514LED1613.5*2--LED+
DB7
LED-
1312
91011DB5
DB2DB3DB4
DB6
87645R/WRS
EDB0
DB1
321VSSVDDVO
