AS-4133 L

AmodelAS-4133Lpolyphthalamide(PPA)isa33%glassrein-

forcedresindesignedtogivehighcrystallinitywhenmoldedinwa-

ter-cooledmolds.Keypropertiesoftheresinarehighheat

resistance,highstrengthandstiffnessoverabroadtemperature

range,lowmoistureabsorption,excellentchemicalresistance,

andexcellentelectricalproperties.

AmodelAS-4133Lresincanbeadvantageouslyusedformany

automotiveelectricalandelectronicapplications.Theseapplica-tionsmayincludeconnectors,sockets,switches,sensors,enclo-

sures,andhousingsforsystems,suchasanti-lockbrake,traction

control,steering,electronicenginecontrol,transmissioncontrol,

andchassiscontrols.

Thismaterialprocessesreadilyonconventionalinjectionmolding

equipmentusingwater-cooledmolds.Itsrapidcrystallizationrate

andhighflowcanresultinshortcyclesandthereforehighmolding

productivityandlowerpartcost.

Solvay Advanced Polymers, L.L.C.4500 McGinnis Ferry RoadAlpharetta, Georgia 30005-3914www.solvayadvancedpolymers.comProduct DataAMODEL®

polyphthalamide

Typical Properties of Amodel AS-4133 L Resin

ASTMTypical Values(1)

TestU.S. Customary UnitsSI Units

PropertyMethodDAM(2)50% RH(3)UnitsDAM(2)50% RH(3)Units

Mechanical

Tensile StrengthD 63829.025.0kpsi200172MPaTensile ElongationD 6382.52.2%2.52.2%Tensile ModulusD 6381,7001,700kpsi11.711.7GPaFlexural StrengthD 79042.035.0kpsi290241MPaFlexural ModulusD 7901,6001,600kpsi11.011.0GPaShear StrengthD 73213.011.0kpsi9076MPaCompressive Strength(4)D 69526.025.0kpsi179172MPaPoisson’s Ratio0.410.41Izod Impact, NotchedD 2561.51.3ft-lb/in8070J/mIzod Impact, Unnotched18ft-lb/in960J/m

Thermal

Heat Deflection Temperature(5)D 648at 264 psi (1.8 MPa)572°F300°Cat 66 psi (0.45 MPa)608°F320°CMelting PointD 570620°F327°CFlammability(6),1/8" (3.2 mm) barUL 94HBHBCoefficient of Thermal ExpansionE 83132° to 194°F (0° to 90°C) FD(7)12ppm/°F22ppm/°C32° to 194°F (0° to 90°C) TD(7)33ppm/°F59ppm/°C300° to 480°F (150° to 250°C)FD(7)8ppm/°F15ppm/°C300° to 480°F (150° to 250°C)TD(7)67ppm/°F121ppm/°C

Electrical

Dielectric Strength, 1/16" (1.6 mm)D 149510520V/mil2121kV/mmVolume ResistivityD 2572 x 10165 x 1014ohm-cm2 x 10165 x 1014ohm-cmHigh Voltage Arc Track Rate- UL746A§221418mm/min1418mm/minComparative Tracking IndexD 3638>600>600volts>600>600voltsDielectric Constant at 60 HzD 1503.84.33.84.3Dielectric Constant at 106Hz3.63.43.63.4Dissipation Factor at 60 HzD 1500.0040.0200.0040.020Dissipation Factor at 106Hz0.0120.0190.0120.019

General

Specific GravityD 7921.451.45Moisture Absorption, 24 hoursD 5700.29%0.29%Mold Shrinkage Flow DirectionD 9550.5%0.5%Mold Shrinkage Transverse Direction1.0%1.0%

(1)Actual properties of individual batches will vary within specification limits. Properties are typicalof uncolored resin. Colorants or other additives may alter values.(2)Dry as molded.(3)Conditioned to 50% RH in accordance with ISO-1110, Accelerated Method.(4)Test specimen 0.5 x 0.5 x 1" (12.7 x 12.7 x 25.4 mm).(5)0.125 inch (3.2 mm) thick specimens annealed in air for 3 hours at 320°F (160°C).(6)These flammability ratings are not intended to reflect hazards presented by these or any othermaterials under actual fire conditions.(7)FD = Flow direction; TD = Transverse direction.Drying

Resin should be dried before molding because excessive

moisture will result in nozzle drool, reduced mechanical

properties, poor surface appearance, and sprue sticking.

Extremely wet resin will result in a foamy extrudate. The

target moisture level is 0.03 to 0.06% (300 to 600 ppm)

and the maximum recommended drying temperature is

135°C (275°F).

Although Amodel resins are shipped with less than 0.15%

moisture and packaged in moisture-proof foil-lined bags

or boxes, the resin should be dried for optimum molding

results. The preferred drying condition is 4 hours at 120°C

(248°F). Alternatively, the resins can be dried for 8 hours

at 90°C (194°F). In either case, a desiccant bed dryer with

a dew point below -30°C (-22°F) should be used.

Drying Tips:

•Do not open containers until ready to process.

•Drying at temperatures higher than 125°C (257°F) may result in

the darkening of natural colored pellets.

•If a thermogravimetric moisture analyzer is used, it should be set

to 170°C (338°F)

•Amodel resin inan open container needs to be dried as shown in

the following table. The recommended drying time depends on

how long the container has been open and the estimated relativehumidity.

Drying Time at 120°C (248°F), hoursRelative Humidity, %Elapsed Time From Container Opening, hours

0.250.5123

304.55.05.56.06.5

505.05.56.07.07.5

755.05.56.57.58.0

1005.56.57.58.59.0

Injection Molding

AmodelAS-4133Lresincanbereadilyinjectionmoldedin

mostscrewinjectionmoldingmachines.Ageneralpurpose

screwisrecommended,withminimumbackpressure.
