Rev.1.00, May 11, 2004, page 1 of 7

RD74LVC02B

Quad. 2-input NOR Gates

REJ03D0223–0100Z

Rev.1.00May 11, 2004

Description

The RD74LVC02B has four 2-input NOR gates in a 14 pin package. Low voltage and high speed operation is suitable

at the battery drive product (note type personal computer) and low power consumption extends the life of a battery for

long time operation.

Features

• VCC = 1.65 V to 5.5 V

• All inputs VIH (Max.) = 5.5 V (@VCC = 0 V to 5.5 V)

• Typical VOL ground bounce < 0.8 V (@VCC = 3.3 V, Ta = 25°C)

• Typical VOH undershoot > 2.0 V (@VCC = 3.3 V, Ta = 25°C)

• High output current±4 mA (@VCC = 1.65 V)

±8 mA (@VCC = 2.3 V)

±12 mA (@VCC = 2.7 V)

±24 mA (@VCC = 3.0 V to 5.5 V)• Ordering Information

Part NamePackage TypePackage CodePackage

AbbreviationTaping Abbreviation

(Quantity)

RD74LVC02BFPELSOP–14 pin (JEITA)FP–14DAVFPEL (2,000 pcs/reel)

RD74LVC02BTELLTSSOP–14 pinTTP–14DVTELL (2,000 pcs/reel)

Function Table

Inputs

ABOutput Y

LLH

LHL

HLL

HHL

H :High level

L :Low level元器件交易网www.cecb2b.comRD74LVC02BRev.1.00, May 11, 2004, page 2 of 7Pin Arrangement

(Top view)11121314VCC

4Y

4B

4A

3Y

3B1

2

3

4

5

6

789101Y

GND3A1A

1B

2Y

2A

2B

Absolute Maximum RatingsItemSymbolRatingsUnitConditions

Supply voltageVCC–0.5 to 7.0V

Input diode currentIIK–50mAVI = –0.5 V

Input voltageVI–0.5 to 7.0V

–50mAVO = –0.5 VOutput diode currentIOK50mAVO = VCC+0.5 V

Output voltageVO–0.5 to VCC+0.5V

Output currentIO±50mA

VCC, GND current / pinICC or IGND100mA

Storage temperatureTstg–65 to +150°C

Note:The absolute maximum ratings are values, which must not individually be exceeded, and furthermore, no two of

which may be realized at the same time.元器件交易网www.cecb2b.comRD74LVC02BRev.1.00, May 11, 2004, page 3 of 7Recommended Operating ConditionsItemSymbolRatingsUnitConditions

1.5 to 5.5Data holdSupply voltageVCC1.65 to 5.5V

At operation

VI0 to 5.5A, BInput / Output voltage

VO0 to VCCV

Y

Operating temperatureTa–40 to 85°C

–4VCC = 1.65 V

–8VCC = 2.3 V

–12VCC = 2.7 VIOH

–24VCC = 3.0 V to 5.5 V

4VCC = 1.65 V

8VCC = 2.3 V

12VCC = 2.7 VOutput current

IOL

24mA

VCC = 3.0 V to 5.5 V

20VCC = 1.65 V to 2.7 VInput rise / fall time*1tr, tf10ns/V

VCC = 3.0 V to 5.5 V

Notes:1.This item guarantees maximum limit when one input switches.

Waveform: Refer to test circuit of switching characteristics.元器件交易网www.cecb2b.comRD74LVC02BRev.1.00, May 11, 2004, page 4 of 7Electrical CharacteristicsTa = –40 to 85°C

ItemSymbolVCC (V)MinMaxUnitTest Conditions

1.65 to 1.95VCC×0.65—

2.3 to 2.71.7—

2.7 to 3.62.0—VIH

4.5 to 5.5VCC×0.7—

1.65 to 1.95—VCC×0.35

2.3 to 2.7—0.7

2.7 to 3.6—0.8Input voltage

VIL

4.5 to 5.5—VCC×0.3V

1.65 to 5.5VCC–0.2—IOH = –100 µA

1.651.2—IOH = –4 mA

2.31.7—IOH = –8 mA

2.72.2—

3.02.4—IOH = –12 mA

3.02.2—VOH

4.53.8—IOH = –24 mA

1.65 to 5.5—0.2IOL = 100 µA

1.65—0.45IOL = 4 mA

2.3—0.7IOL = 8 mA

2.7—0.4IOL = 12 mA

3.0—0.55Output voltage

VOL

4.5—0.55V

IOL = 24 mA

Input currentIIN0 to 5.5—±5.0µAVIN = 5.5 V or GND

2.7 to 3.6—±5.0VIN = 3.6 V to 5.5 VICC2.7 to 5.5—5.0VIN = VCC or GNDQuiescent supply current

∆ICC2.7 to 3.6—500µA

VIN = one input at (VCC–0.6)V,

other inputs at VCC or GND元器件交易网www.cecb2b.comRD74LVC02BRev.1.00, May 11, 2004, page 5 of 7Switching CharacteristicsTa = –40 to 85°C

ItemSymbolVCC (V)MinTypMaxUnitFrom

(Input)To

(Output)

1.8±0.151.0—8.9

2.5±0.21.0—7.4

2.71.0—5.4

3.3±0.31.0—4.4Propagation delay timetPLHtPHL

5.0±0.51.0—3.9nsA or BY

1.8±0.15———

2.5±0.2———

2.7———

3.3±0.3——1.0Between output pins skew*1tOSLHtOSHL

5.0±0.5——1.0ns

Input capacitanceCIN3.3—5.0—pF

Note:1.This parameter is characterized but not tested.

tOSLH = |tPLHm – tPLHn|, tOSHL = |tPHLm – tPHLn|

Operating Characteristics

Ta = 25°C

ItemSymbolVCC (V)MinTypMaxUnitTest conditions

1.8—10—

2.5—12—

3.3—12—Power dissipation CapacitanceCPD

5.0—15—pFf = 10 MHz元器件交易网www.cecb2b.comRD74LVC02BRev.1.00, May 11, 2004, page 6 of 7Test CircuitInput

Pulse Generator

Z = 50outΩVCC

Output

C LR L

Note:1.CL includes probe and jig capacitance.

Waveforms

VOH

VOLInput A or B

10 %GND90 %trtf

90 %

10 %

Output YtPHLtPLHVIH

VrefVref

VrefVref

1.5 V

1.5 VVrefCLRL

1/2 VCC30 pF1.0 kΩ

500 Ω

500 Ω

500 Ω

500 Ω30 pF

50 pF

50 pF

50 pF1/2 VCC

1/2 VCC2.7 V

2.7 VINPUTS

VCC

VCC

VCCVIHtr/tf

VCC = 1.8±0.15 V

VCC = 2.5±0.2 V

VCC = 3.3±0.3 V

VCC = 5.0±0.5 VVCC = 2.7 VVCC (V)

≤ 2 ns

≤ 2 ns

≤ 2.5 ns

≤ 2.5 ns

≤ 2.5 ns

Notes: 1.Input waveform : PRR = 10 MHz, duty cycle 50%.元器件交易网www.cecb2b.com
