Document Title M190MWW1 Finial Specification Page No.1/33Document No. CAS-061225004 Issue date2007/5/18 Revision01
________________________________________________________________________ The copyright belongs to MTDis Co., Ltd. Any unauthorized use is prohibited. TO:
Wealth Star Technology Limited
MTDis Product Specification Model Name: M190MWW1
Issue date: 2007/ 5 / 18
Product Development and Customer Engineering Division Customer
2007/5/18
Note: 1. Please contact MTDis Corp. before designing your product based on this product. 2. The information contained herein is presented merely to indicate the characteristics and performance of our products. No responsibility is assumed by MTDis for any intellectual property claims or other problems that may result from application based on the module described herein.
From www.fpdclub.net
Document Title M190MWW1 Finial Specification Page No.2/33Document No. CAS-061225004 Issue date2007/5/18 Revision01
________________________________________________________________________ The copyright belongs to MTDis Co., Ltd. Any unauthorized use is prohibited. Revision Date PageOld Description New Description Remark01 2007/5 /18 M190MWW1 finial spec. was first issued.
From www.fpdclub.net
Document Title M190MWW1 Finial Specification Page No.3/33Document No. CAS-061225004 Issue date2007/5/18 Revision01
________________________________________________________________________ The copyright belongs to MTDis Co., Ltd. Any unauthorized use is prohibited. Contents
1.0 General Descriptions ……………………………….… p.4 2.0 Absolute Maximum Ratings ………………………….. p.6 3.0 Pixel Format Image ……………………………….. p.7 4.0 Optical Characteristics …………………………………… p.8 5.0 Backlight Characteristics…………………….. p.11 6.0 Electrical Characteristics ………………….………. p.13 7.0 Interface Timings…………………………………… …… p.20 8.0 Power Consumption …………………………….… …… p.21 9.0 Power ON/OFF sequence …………………………………….p.22 10.0 Mechanical Characteristic……………………………………..p .23 11.0 Package Specification ……. ……………………………...…p.26 12.0 Lot Mark…. ……………………………………………………p.27 13.0 General Precaution …………………………………………… p.28 14.0 Inspection Standards for LCD Modules………………………p.30
From www.fpdclub.net
Document Title M190MWW1 Finial Specification Page No.4/33Document No. CAS-061225004 Issue date2007/5/18 Revision01
________________________________________________________________________ The copyright belongs to MTDis Co., Ltd. Any unauthorized use is prohibited. 1.0 GENERAL DESCRIPTIONS 1.1 Introduction The M190MWW1 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. It is composed of a TFT LCD panel, a timing controler, voltage reference, common voltage, driver DC-DC converter, column driver, and row driver circuit. This TFT LCD has a 19-inch diagonally measured active display area with WXGA+ resolution (1440 vertical by 900 horizontal pixel array). 1.2 Features ■ 19”WXGA+ TFT LCD Panel ■ 4 CCFLs Backlight System ■ Supported WXGA+ (V:1440 lines, H:900 pixels) resolution ■ Supported to 75Hz Refresh Rate ■ Compatible with RoHS Standard 1.3 Product Summary Items Specifications Unit Screen Diagonal 19.05 inch Inch Active Area 410.4(H) x 256.5(V) mm Pixels H x V 1,440 (x3) x 900 Pixel Pitch 0.285 (per one triad) x 0.285 mm Pixel Arrangement R.G.B. Vertical Stripe Display Mode Normally White
White Luminance 300 typical cd/ m2 (CCFL current 7.0mA) Contrast Ratio 800 : 1 typical Response Time 5 typical msec Input Voltage +5.0 typical V Logic Power Consumption 2.6 typical (Black pattern, 60Hz) Watt Backlight Power Consumption 21.0 typical (CCFL current 7.0mA) Watt
Weight 2,500 maximum g Outline Dimension 427.2 (W) x 277.4 (H) x 15.5 (T) typical mm Electrical Interface (Logic) 8bit dual LVDS Support Color 16.2M
Lamp Life Time 50,000(Ta=25+/-3degC and ICCFL=7.0mA, brightness becomes lower than 50% of initial value) Hours
Luminance Uniformity 1.3 typical (@9 points) Optimum Viewing Direction 6 o’colok
From www.fpdclub.net
Document Title M190MWW1 Finial Specification Page No.5/33Document No. CAS-061225004 Issue date2007/5/18 Revision01
________________________________________________________________________ The copyright belongs to MTDis Co., Ltd. Any unauthorized use is prohibited. 1.4 Functional Block Diagram . Figure 1 shows the functional block diagram of the LCD module. Figure 1 Block Diagram
VCC GND RXinO0+/- RXinO1+/- RXinO2+/- RXinO3+/- RXinOC+/- RXinE0+/- RXinE1+/- RXinE2+/- RXinE3+/- RXinEC+/- TFT LCD Module LCD Drive Card
Backlight Unit Signal Connector FI-XB30SRL-11
DC/DC Converter Reference Voltage Timing Controller
