© 2019 Siemens Product Lifecycle Management Software Inc.
Client – Server
One Program, Two Processes Client – GUI Server – Computatied
Hotkey . R T S F H
Pan
Action Probe Reset Top View Side View Front View Fit in View
© 2019 Siemens Product Lifecycle Management Software Inc.
Toolbars
Commonly used actions have shortcuts in the Toolbars at the top of the GUI.
01_EssentialConcepts. 3. Select mixer.sim and click Open. 4. Right-click the Scenes node and select Open All Scenes.
© 2019 Siemens Product Lifecycle Management Software Inc.
© 2019 Siemens Product Lifecycle Management Software Inc.
Toolbars
Graphics Window View/interact with 3D Scenes and 2D Plots Output Window Displays messages, information, warnings to the user
Interacting with the graphics window
Mouse/keyboard controls used to navigate the Graphics Window include:
Rotate
Zoom
(Ctrl + Left) Rotate about Axis into screen
Selection Toolbar (Zone select, selection filter, etc.) Visualization Toolbar (Create Scene, Reset, Store/restore View, etc.) Solution Toolbar (Initialize, step, run, stop) Mesh Generation Toolbar (Repair Surface, Generate surface/volume mesh, etc)
If available, property customizer (icon) can be opened for more options.
Edit value directly in-line
Click to open property customizer for more options
© 2019 Siemens Product Lifecycle Management Software Inc.
Client and Server
No client is connected to the running server
Software license is checked out by the server process
Server
© 2019 Siemens Product Lifecycle Management Software Inc.
Sub objects unopened
No sub objects
© 2019 Siemens Product Lifecycle Management Software Inc.
Interacting with simulation objects
Properties can be modified directly in the Properties Window.
Simulation tree
Contains all of the simulation objects in the .sim file.
Sub objects opened
Folders are added/removed as objects/nodes are created in the simulation.
STAR-CCM+ GUI – Default layout
Menu Bar
Explorer Pane
Simulation objects, embedded tools, current scene/plot
Properties Window
Display/edit object properties
Discussion STAR-CCM+ essential concepts
© 2019 Siemens Product Lifecycle Management Software Inc.
Demo – User exercise
1. Launch STAR-CCM+. 2. In the menu, select File > Load and browse to the folder InputFiles >
Thought questions
Can you identify the menu bar, toolbar, panes, and windows of the STARCCM+ GUI? Where in the simulation tree are geometries and meshes prepared? Where in the simulation tree are physics simulations conducted? Where are the boundary conditions applied? Which node in the tree makes the connection between mesh and physics?
