记本开机错误代码解析大全
导读:我根据大家的需要整理了一份关于《记本开机错误代码解析大全》的内容,具体内容:本文为大家带来笔,希望能帮到大家。Symptom / Error (开机错误代码) FRU / Action in Sequence(检查范围及解决方法)10X1...本文为大家带来笔,希望能帮到大家。
Symptom / Error (开机错误代码) FRU / Action in Sequence(检查范围及解决方法)
10X
101: Interrupt failure;(中断故障)
102: Timer failure;(计时器故障)
103: Timer interrupt failure; (计时器中断故障)
104: Protected mode failure; (保护模式故障)
105: Last 8042 command not accepted;
107: NMI test failure;(NMI 测试失败)
108: Timer bus test failure.
109: Low meg-chip select test. 1. System board. (主板问题)
110 :(Planar parity.) (内存奇偶校验出错) 1. Go to Memory Checkout 2. DIMM card.3. Detach the expansion unit if it is attached to the computer.4. System board.
111:(I/O parity.) 1. Go to Memory Checkout2. Expansion unit or port replicator.3. System board.
11XX
1101: Serial_A test failure.(A 串行口测试失败) 1. Serial device (串行设备)2. Communication cable (相关通讯电缆)3. System board (主板)
12XX
1201: Serial_B test failure.(B 串行口测试失败) 1. System board (infrared) (检查主板:红外线口)
158 :(Hard disk password was not set even though the supervisor password is set.) (超级用户密码已设,但硬盘密码没有设置) 1. Set the password for hard disk drive.(设置硬盘密码)
159 :(Hard disk password is not set the same as the supervisor password.) (硬盘密码与超级用户密码不一样) 1. Set the correct password for hard disk drive.(设置正确的硬盘密码)
161:(Dead battery.) (CMOS 电池不行) 1. Go to Checking the Backup Battery 2. Backup battery.(CMOS 备份电池,在内存插槽旁边)3. System board. (主板)
163:(Time and date were not set.) (系统时间没有设好或混乱) 1. Set time and date.(设置正确的系统时间) 2. System board. (主板问题) 173:(Configuration data was lost.) (CMOS 设备配置信息丢失) 1. Select OK in the error screen; then set the time and date.(在开机 ERROR 画面上按OK,然后设置系统时间)2. Backup battery. (CMOS 电池需要更换)3. System board. (主板问题)
174:(Configuration error: Perform Checking the Installed Devices List before changing any FRUs.) 1. Check device configuration.2. Hard disk drive assembly.3. System board.
175
177
178175: EEPROM CRC #1 error.
177: Supervisor password check sum error.
178: EEPROM is not functional. 1. System board. (检查主板)
17XX
1701: Hard disk controller failure. (硬盘控制器故障)
1780, 1790: Hard disk 0 error. (主硬盘有问题)
1781, 1791: Hard disk 1 error.(从硬盘有问题) 1. Hard disk drive (检查硬盘)
2. System board (检查主板)
183 :(Incorrect password entered at the supervisor password prompt.) (超级用户开机密码不对) 1. Have the user examine the password.(请用户检查密码)
184:(Power-on password check sum error.) (Power-on 密码有误) 1. Reset the power-on password in Easy-Setup.(重设Power-on 密码)
185:(The startup sequence is not valid. Suspect that power was off when the startup sequence was being updated.) (系统启动顺序无效,怀疑是更新启动顺序时电源关掉) 1. Reset the startup sequence
