TPO414中文资料1：三端DC-DC脉宽调制开关。
2：产品亮点。
分离转换开关的低成本替代品。
只有较少的15个元件，降低成本，提高可靠性。
允许12毫米以下更小更轻的所有表面装载元件解决方案。
3：在反击式拓扑中有80%的能效。
内置的启动和电流限制，减少DC电流损耗。
低电容的MOSFET（金属氧化物半导体场效应晶体管）CMOS（互补金属氧化物半导体）控制器/门驱动器的消耗只有7Mw.70%的最大占空比最大限度的降低了传导损耗。
4：简化设计，缩短上市时间集成的脉宽调制控制器和大功率的MOSFET（金属氧化物半导体场效应晶体管）只需要一个补偿电容。
旁路和启动/自动重启的功能。
5：系统电平错误保护特征自动重启和逐周期电流限制（逐周期电流感测）即时性电流限制功能。
处理初级和次级的错误。
在线的片锁热关断保护整个系统，预防过载。
6：高度灵活，多功能实现降压，升压，反激式和正激式拓扑。
轻松接口，同时包含OPTO和初级反馈。
支持连续和不连续的运作模式。
指定用于DC16V以下输入。
7：说明TOPS开关系列，实现只有3个终端，为所有DC-DC所必须的功能：高电压N沟道功率MOSFET（金属氧化物半导体场效应晶体管），包含受控的启动门驱动，电压模式的脉宽调节控制器有内部集成的120KHZ的震荡器。
高电压启动偏置电路，能隙带派生参考，并联分流稳压器，误差放大器电路是为环路补偿和错误保护的，相比分离的MOSFET 和控制器或字激的开关转换器解决方案，TOPS开关集成电路能降低总成本，元件的数量，尺寸，和重量，同时提高效率和系统可靠性，这个器件非常适合电信，电报，和其他DC-DC的高达21W的输出功率。
在内部，SMD-8的引线框架，使用6个引脚将热量从芯片传递到电路板上，减少了散热片的成本。
8：典型应用9：输出能力：10：引脚功能描述。
漏极引脚：输出MOSFET的漏极连接，在启动运行时候，通过内部开关式的高压电流源。
提供内部的偏置电流。
