非常感谢您阅览我们的产品介绍电力行业软件产品手册我们的优势在开始介绍我们产品之前，我非常荣幸的为您介绍我们的开发团队，在科技突飞猛进的今天，电力企业的发展已经不再局限于员工的高强度工作，更多的需要自动化程度较高、可靠性强的硬件、软件来支持，一方面不仅降低了员工的工作压力，另一方面也大大提高了电力运行的可靠性、灵敏性、选择性、快速性。
我们致力于电力软件开发数年，具备着雄厚的开发经验和技术实力，同时与其他软件开发商相比，我们有部分开发人员来自于电力生产一线，熟悉内部工作流程，对变电、供电、送电、人教、管理方面有着独特的经验。
如何更好、更紧密的让生产软件适应到工作中，是我们奋斗的目标，在我们的工作中，太多的软件似乎功能很强悍，但一旦投入到生产一线，听到的只是抱怨，据调查发现，大多原因存在于开发人员不了解电力业务流程，导致做出来的软件难以满足生产，或复杂化了原本简单的工作流程。
我们总结多年工作经验，把生产与软件结合在一起，所有软件在投入应用前都将会在杭州、湖州、桐庐等供电单位进行定点测试，使其能更好的服务于生产一线。
再次感谢您对我们的支持！产品目录变电运行 (3)一、操作票微机开票系统 (3)1、主要功能及概述： (3)二、两票统计报表系统 (4)1、主要功能及概述： (4)2、软件预览： (5)三、变电设备巡视系统（智能电网） (7)1、主要功能及概述： (7)2、软件预览： (8)部门管理 (12)一、OA办公系统（线上办公系统） (12)1、主要功能及概述： (12)人教培训 (14)一、变电站网络仿真培训系统 (14)变电运行一、操作票微机开票系统1、主要功能及概述：熟悉变电业务的您一定知道“操作票”在变电运行工作中的重要性，规范的操作票能大大的提高倒闸操作的可靠性与安全性。
本软件主要通过配置变电站一次、二次状态改变来完成操作票面自动生成打印的功能。
比如：备用1112线由运行改热备用，在软件中您只需指定初始状态为“运行”终止状态为“热备用”，点击打印按钮，系统将会自动生成逻辑票面传送至打印机打印，使用非常简单。
