FeaturesLED Driver• 3W Class II AC-DC LED power supply • 350mA, 500mA and 700mA CC/CV output • Fused input and SCP , OVP , OLP , OTP • 3kVAC isolation • IP66 rated •Low costRACD03AC/DC ConverterDescriptionA compact universal AC input 3W constant current switching power module suitable for driving 1 - 6high power LEDs. The output (dual constant voltage / constant current mode) current limit is fixed at 350mA, 500mA or 700mA. At lower output currents, the output is constant voltage. Connections are via118mm long flying leads.E3406963 Watt CC/CVSingle OutputUL8750 certified UL1310 certifiedCAN/CSA-C22.2 No. 223-M91 certified IEC/EN61347 certifiedIEC/EN61347-2-13 certified ENEC certified CB reportSelection GuidePart Input CC CV (1)Efficiency Rated Number Voltage RangeMode Mode typ. Power nom./max.[VAC] [VDC] [mA] [VDC] [mA] [%] [W]RACD03-350 90-264 3-12 350 15 0-300 72 3 / 4.2RACD03-500 90-264 3-9.5 500 none71 3 / 4.6RACD03-70090-2643-4.5 70060-600623 / 3.1BASIC CHARACTERISTICSParameterCondition Min.Typ.Max.Input Voltage Range 90VAC 230VAC264VAC 120VDC370VDC Input Current full load, 100VAC 110mA Inrush Current 230VAC, <2ms10A Input Frequency Range 47Hz 63HzPower Factor full load, 230VAC 0.55Hold-up Time 18msOutput Ripple Current100mAp-pcontinued on next page Specifications (measured @ Ta= 25°C, nom. Vin, rated load and after warm-up unless otherwise stated)All LED Drivers may not be used without a load. They must be switched on the primary side only.Noncompliance may damage the LED or reduce its lifetime.Model Numberingnom. Output PowerRACD03-___nom. Output CurrentSpecifications (measured @ Ta= 25°C, nom. Vin, rated load and after warm-up unless otherwise stated)ENVIRONMENTALParameterConditionValueOperating Temperature Range according to UL according to ENEC-20°C to +50°C -20°C to +40°CMax. Case Temperature according to UL according to ENECRACD03-350, RACD03-700RACD03-500+67°C +65°C +75°CIP Rating IP66Operating Humidity non condensing 5% - 85% RH max.Design Lifetime+25°C ambient 20 x 103 hourscontinued on next pagePROTECTIONParameterCondition ValueInput Fuse(2)T1A, slow blowShort Circuit Protection (SCP)continuous, current limitOverload Protection (OLP)120% typ.Output Over Voltage Protection (OVP)zener diode clampRACD03-350RACD03-500RACD03-70017VDC max.14VDC max.8VDC max.Over Temperature Protection (OTP)shutdown, automatic resatart after cooling down Isolation Voltage I/P to O/P3.75kVAC/1 minute typ. / 3kVAC/1 minute min.Leakage Current0.2mA typ.Maximum loading of automatic circuit breakers*Circuit BreakerCircuit Breaker CurrentTyp 10A 16A 20A 25A C221247337430Circuit BreakerCircuit Breaker CurrentTyp 10A 16A 20A 25A B 80157200254C265317437550* @ 115VAC, 1Ohm, 90° phase angle and max. load* @ 230VAC, 1Ohm, 90° phase angle and max. loadNotes:Note2: Refer to local wiring regulations if input over-current protection is also requiredSpecifications (measured @ Ta= 25°C, nom. Vin, rated load and after warm-up unless otherwise stated)SAFETY AND CERTIFICATIONSCertificate Type (Safety)Report Number Standard Standard for LED Equipment for use in Lighting Products E340696-1-4UL8750, 1st Edition, 2009Standard for Class 2 Power Units UL1310, 6th Edition, 2011Extra Low Voltage Class 2 Outputs CAN/CSA-C22.2 No. 223-M91, 2nd Edition, 2009Lamp Controlgear Particular Requirements SH12051509-001IEC/EN61347-2-13,2006Lamp Controlgear General Requirments for Safety IEC61347-1, 2nd edition, 2010EN61347-1, 2nd edition, 2011Safety of control gear for LED modules (CB Scheme)12CA61285-1IEC/EN61347-2-13,2006Safety requirements for lamp controlgear (CB Scheme)IEC61347-1, 2nd Edition, 2010EN61347-1, 2nd Edition, 2011Lamp Controlgear General Requirments for Safety (ENEC License) ENEC-00611EN61347-1Lamp Controlgear Particular Requirements (ENEC License)EN61347-2-13D.C. or A.C. Controlgears for LED Performance Requirements (ENEC License)EN62348, 2006RoHS RoHS 6/6, 2011/65/EU EACRU Д- AT.A Г03. В.67369TP TC 004/020, 2011EMC ComplianceCondition Standard / CriterionEMC for industrial, scientific and medical equipment (design to meet)FCC18, Class A Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment (design to meet)EN55015, Class ACISPR15, 7th Edition, 2009Electromagnetic compatibility - Requirements for household appliances, electric tools and similar apparatus - Part 1: Emission (design to meet)EN55014-1Limits of harmonic current emissionsVoltage Fluctuations and Flicker in Public Low-Voltage Systems <=16A per phaseIEC61000-3-2, 3rd Edition, 2009IEC61000-3-3, 2nd Edition, 2008Derating Graph-20-101020304050601008060409070503020100O u t p u t L o a d [%]Ambient Temperature [°C]Specifications (measured @ Ta= 25°C, nom. Vin, rated load and after warm-up unless otherwise stated)TypeUL-1007, AWG18UL-1007, AWG18PACKAGING INFORMATIONParameter Type Value Packaging Dimension (LxWxH) cardboard Box265.0 x 80.0 x 115.0mm Packaging Quantity10pcs Storage Temperature Range-30°C to +80°C Storage Humidity non-condensing5%-85% RHThe product information and specifications may be subject to changes even without prior written notice.The product has been designed for various applications; its suitability lies in the responsibility of each customer. The products are not authorized for use in safety-critical applications without RECOM’s explicit written consent. A safety-critical application is an application where a failure may reasonably be expected to endanger or cause loss of life, inflict bodily harm or damage property. The applicant shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorizeduse of RECOM products in such safety-critical applications.。

Specifications subject to change without notice, contact your sales representatives for the most recent information. PWM (Pulse Width Modulation) 功能使用方法1 适用产品：1.1 SM39R16A2/ SM39R12A2/ SM39R08A2 2 PWM 使用说明:2.1 提供2组独立的PWM 信号2.2 输入频率可由缓存器PWMCS[2:0]选择2.3 PWM 为10-bit 模式，但最大数据计数可由PWMMDH 及PWMMDL 设定为1~10243 PWM 相关的特殊缓存器PWM Special Function Register (SFR)Mnemonic Description Direct Bit 7Bit 6Bit 5 Bit 4Bit 3Bit 2 Bit 1Bit 0RESETPWMPWMC PWM Control registerB5hPWMCS[2:0] - - -PWM1EN PWM0EN 00H PWMD0H PWM 0 Data register high byte BCh PWMP0 - - - - - PWMD0[9:8]00H PWMD0L PWM 0 Data register low byte BDhPWMD0[7:0]00H PWMD1H PWM 1 Data register high byte BEh PWMP1 - - - - - PWMD1[9:8]00H PWMD1L PWM 1 Data register low byte BFhPWMD1[7:0]00H PWMMDH PWM Max Data register high byte CEh - - - - - - PWMMD[9:8] 00H PWMMDLPWM Max Data register low byteCFhPWMMD[7:0]FFHMnemonic: PWMCAddress: B5h7 6 5 4 3 2 1 0 Reset PWMCS[2:0] - - - PWM1EN PWM0EN 00HPWMCS[2:0]: 频率选择位(PWM clock select)PWMCS [2:0] Mode000 Fosc 001 Fosc/2 010 Fosc/4Specifications subject to change without notice, contact your sales representatives for the most recent information.011 Fosc/6 100 Fosc/8 101 Fosc/12 110 Timer 0 overflow 111 Timer 0 external input (P3.4/T0)PWM1EN:信道1致能位(PWM channel 1 enable control bit) PWM1EN = 1 – PWM 通道1致能. PWM1EN = 0 – PWM 通道1禁能.PWM0EN:信道0致能位(PWM channel 0 enable control bit) PWM0EN = 1 – PWM 通道0致能. PWM0EN = 0 – PWM 通道0禁能.Mnemonic: PWMD0HAddress: BCh7 6 5 4 3 2 1 0 ResetPWMP0 - - - - - PWMD0[9:8]00HMnemonic: PWMD0L Address: BDh7 6 5 4 3 2 1 0 ResetPWMD0[7:0]00hPWMP0: 信道0闲置准位选择位(PWM channel 0 idle polarity select)“0” –通道0闲置时为低准位(PWM channel 0 will idle low) “1” –通道0闲置时为高准位(PWM channel 0 will idle high)PWMD0[9:0]: 信道0数据缓存器(PWM channel 0 data register)可调整PWM 信道0 责任周期(Duty Cycle)Mnemonic: PWMD1HAddress: BEh7 6 5 4 3 2 1 0 ResetPWMP1 - - - - - PWMD1[9:8]00HMnemonic: PWMD1LAddress: BFh7 6 5 4 3 2 1 0 ResetPWMD1[7:0]00HPWMP1: 信道1闲置准位选择位(PWM channel 1 idle polarity select)“0” –通道1闲置时为低准位(PWM channel 1 will idle low) “1” –通道1闲置时为高准位(PWM channel 1 will idle high)PWMD1[9:0]: 信道1数据缓存器(PWM channel 1 data register)可调整PWM 通道1 Duty CycleMnemonic: PWMMDHAddress: CEh7 6 5 4 3 2 1 0 Reset - - - - - - PWMMD[9:8]00HSpecifications subject to change without notice, contact your sales representatives for the most recent information.Mnemonic: PWMMDLAddress: CFh7 6 5 4 3 2 1 0 ResetPWMMD[7:0]FFHPWMMD[9:0]: 最大数据设定缓存器(PWM Max Data register)PWM 由0000计数至PWMMD[9:0]，当计数等于PWMMD[9:0]时会产生溢位。
