NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.
comLarge Can Aluminum Electrolytic Capacitors
FEATURES
• LOW PROFILE (20mm HEIGHT)
• LOW DISSIPATION FACTOR AND LOW ESR
• HIGH RIPPLE CURRENT
• WIDE CV SELECTION
• SUITABLE FOR SWITCHING POWER SUPPLIESNRLF Series
SPECIFICATIONS
MECHANICAL CHARACTERISTICS:1. Safety Vent:: The capacitors are provided with a pressure sensitive safety vent on the top. The vent is designed to
rupture in the event that high internal gas pressure is developed by circuit mal func tion or mis-use like reverse voltage.
2. Terminal Strength: Each terminal of the capacitor shall withstand an axial pull force of 4.5Kg for a period 10 seconds or
a radial bent force of 2.5Kg for a period of 30 seconds.
Notice for MountingThe space from the top of the can shall be more than (3mm) from chassis or other construction materials so that safety vent has room to expand in case of emer gen cy.Sleeve Color: Dark BlueCan Top Safety VentInsulation Sleeve and Minus Polarity Marking
(4.0mm Leads Available As Option)D+1Max.
L ± 26.3 ± 10.8
10(-)(+)MAXIMUM EX PAN SION FOR SAFETY VENT
Approx. 3.0mmPC Board Mounting Holes:
10 ± .1∅= 2 ± 0.1
D∅ ± 0.5PC BoardOperating Temperature Range-40 ~ +85°C-25 ~ +85°C
Rated Voltage Range16 ~ 250Vdc350 ~ 450Vdc
Rated Capacitance Range100 ~ 15,000µF33 ~ 150µF
Capacitance Tolerance±20% (M)
Max. Leakage Current (µA)After 5 minutes (20°C)3 x C(µF)V
Max. Tan δat 120Hz/20°CW.V. (Vdc)162535506380100160~450
Tan δ max.0.500.400.350.300.250.200.200.15
Surge VoltageW.V. (Vdc)162535506380100160
S.V. (Vdc)2032446379100125200
W.V. (Vdc)180200250350400450--
S.V. (Vdc)220250300400450500--
Ripple CurrentCorrection FactorsFrequency (Hz)50601001205001K10K ~ 50K-
Multiplier at 85°C16 ~ 100Vdc0.930.950.991.001.051.081.15-
160 ~ 450Vdc0.750.800.951.01.201.251.40
Low TemperatureStability (16 to 250Vdc)Temperature (°C)0-25-40-----
Capacitance Change-5%-10-30%-----
Impedance Ratio1.539-----
Load Life Test2,000 hours at +85°CCapacitance ChangeWithin ±20% of initial measured value
Tan δLess than 200% of specifi ed maximum value
Leakage CurrentLess than specifi ed maximum value
Shelf Life Test1,000 hours at +85°C(no load)Capacitance ChangeWithin ±20% of initial measured value
Tan δLess than 200% of specifi ed maximum value
Leakage CurrentLess than specifi ed maximum value
Surge Voltage TestPer JIS-C-5141 (table #6, #4)Surge voltage applied: 30 seconds "On" and 5.5 minutes no voltage "Off"Capacitance ChangeWithin ±20% of initial measured value
Tan δLess than 200% of specifi ed maximum value
Leakage CurrentLess than specifi ed maximum value
Soldering EffectRefer to MIL-STD-202F Method 210ACapacitance ChangeWithin ±10% of initial measured value
Tan δLess than specifi ed maximum value
Leakage CurrentLess than specifi ed maximum value
PRECAUTIONSPlease review the notes on correct use, safety and precautions found on pages T10 & T11 of NIC’s Electrolytic Capacitor catalog. Also found at www.niccomp.com/precautions If in doubt or uncertainty, please review your specifi c application - process details with NIC’s technical support personnel: tpmg@niccomp.com RoHS
Compliant
includes all homogeneous materials
*See Part Number System for Details元器件交易网www.cecb2b.com
148®NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.
comLarge Can Aluminum Electrolytic CapacitorsNRLF Series
STANDARD PRODUCT LIST, CASE SIZE AND SPECIFICATIONS
NRLF 152 M 50V 22X20 F
RoHS compliant Case Size (mm) Voltage Rating Tolerance Code Capacitance Code SeriesPART NUMBER SYSTEMW.V.Cap(µF)CaseSizeESR (Ω @ 20°C)Max. Ripple Current (Arms@85°C)
120Hz20KHz120Hz10K ~ 50KHz
164,70022x200.1590.1351.601.84
6,80025x200.1100.0931.802.07
10,00030x200.0830.0702.402.76
15,00035x200.0550.0473.203.68
253,30022x200.1760.1411.601.84
4,70025.x200.1230.0991.802.07
6,80030x200.0780.0622.302.65
10,00035x200.0610.0492.703.11
352,20022x200.1810.1361.401.61
3,30025x200.1210.0901.701.96
4,70030x200.0880.0662.002.30
6,80035x200.0710.0532.402.76
501,50022x200.2540.1911.201.38
2,20025x200.1730.1301.401.612
3,30030x200.1160.0871.701.96
4,70035x200.0810.0612.102.42
631,00022x200.3810.2861.201.38
1,50025x200.2540.1911.301.50
2,20030x200.1730.1301.501.96
3,30035x200.1260.0941.701.96
8068022x200.4390.3291.001.15
1,00025x200.2980.2441.201.38
1,50030x200.1990.1491.401.61
2,20035x200.1360.1021.701.96
10047022x200.5290.3441.001.15
68025x200.3660.2381.101.27
1,00030x200.2490.1621.201.38
1,50035x200.1770.1151.501.73
16022022x200.9800.4900.751.05
27025x200.7980.3990.871.22
39030x200.5950.2981.101.54
56035x200.4140.2071.301.82
20015022x201.3260.5970.650.91
22025x200.9040.4070.871.22
33030x200.6530.2941.001.40
