JHQ-A型聚氨酯缓冲器：

序号型号

D

mm

H

mm

M

mm

h

mm

缓冲容量

KN.m

缓冲行程

mm

缓冲力

KN

1JHQ-A-1658016350.57347.0526.47 2JHQ-A-2808016350.4006042 3JHQ-A-38010016350.5027542 4JHQ-A-41008016350.6286066 5JHQ-A-510010016350.7857566 6JHQ-A-610012516350.9809466 7JHQ-A-71251001635 1.22775103 8JHQ-A-81251251635 1.53394103 9JHQ-A-91251601635 1.960720169 10JHQ-A-101601251635 2.51294169 11JHQ-A-111601601635 3.215120169 12JHQ-A-121602001635 4.019150265 13JHQ-A-132001602045 5.024120265 14JHQ-A-142002002045 6.280150265 15JHQ-A-1520025020457.850188265 16JHQ-A-1625020020459.810150414 17JHQ-A-17250250204512.266188414 18JHQ-A-18250320204515.700240414 19JHQ-A-19320250204520.096188675 20JHQ-A-20320320204525.732240675

JHQ-C型聚氨酯缓冲器：

序号型号D H B b缓冲容量缓冲行程缓冲力

mm KN.m mm KN

1JHQ-C-16580100700.2656028 2JHQ-C-28080115850.46042 3JHQ-C-380100115850.5027542 4JHQ-C-4100801301000.6286066 5JHQ-C-51001001301000.7857566 6JHQ-C-61001251301000.989042 7JHQ-C-7125100165130 1.22275103 8JHQ-C-8125125165130 1.53394103 9JHQ-C-9125160165130 1.96120103 10JHQ-C-10160125200160 2.51294169 11JHQ-C-11160160200160 3.215120169 12JHQ-C-12160200200160 4.019150169 13JHQ-C-13200160250200 5.024120265 14JHQ-C-14200200250200 6.28150265 15JHQ-C-152002502502007.85188265 16JHQ-C-162502003202509.81240414 17JHQ-C-1725025032025012.266188414 18JHQ-C-1825032032025015.7240414 19JHQ-C-1932025040031520.096188675 20JHQ-C-2032032040031525.723240675 21JHQ-C-2132040040031532.154300675
