www.gztaixi.com 翔京联合传感器有限公司技术资料
工业传感器》接近传感器》电感式接近开关
Inductivesensor H8-D5NK
•
0.6 mm flush
•
Miniature design
参数表节选：的技术参数H8-D5NK
General specifications
Switching function Normally open (NO)
Output type PNP
Rated operating distance 0.6 mm
Installation flush
Output polarity DC
Assured operating distance 0 ... 0.486 mm
Reduction factor rAl 0.4
www.gztaixi.com 翔京联合传感器有限公司技术资料
工业传感器》接近传感器》电感式接近开关
Reduction factor rCu 0.29
Reduction factor r304 0.76
Reduction factor rBrass 0.46
Nominal ratings
Operating voltage 10 ... 30 V
Switching frequency 0 ... 1400 Hz
Hysteresis typ. 5%
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop ≤ 3 V
Operating current 0 ... 100 mA
www.gztaixi.com 翔京联合传感器有限公司技术资料
工业传感器》接近传感器》电感式接近开关
Off-state current 0 ... 0.1 mA typ. at 25 °C
No-load supply current ≤ 10 mA
Switching state indicator LED, yellow
Approvals and certificates
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
CCC approval CCC approval / marking not required for products rated ≤36 V
Ambient conditions
Ambient temperature -25 ... 70 °C (-13 ... 158 °F)
Mechanical specifications
Connection type cable PVC , 2 m
www.gztaixi.com 翔京联合传感器有限公司技术资料
工业传感器》接近传感器》电感式接近开关
Core cross-section 0.055 mm
2
Housing material Stainless steel 1.4305 / AISI 303
Sensing face PC
Housing diameter 3 mm
Degree of protection IP67
