BOSS RC3 LOOP的使用说明一般使用：一插进OUT PUT A（而不是通常单块的INPUT），RC3就开始进入工作状态，因此我觉得它没有专门的BYPASS状态；红灯亮表示在录音，绿灯亮表示在播放。
两个音量旋钮就不用说了吧。
普通模式时（一般一开机就是普通模式），0、先选择你想播放或使用的音轨（1~99）编号，数字右下角如果带点的（比如1.）表示该编号已有录音，且绿灯会闪烁，表示正在读取记忆；不带点则该存储为空白1、设定拍速，根据你想要的拍速，以一定的时间间隔按几次TAP TEMPO，设定拍速，该按键会按你的拍速闪烁，同时播放节拍，此步骤可以省略，或者按一下RHYTHM停止节拍；RC3在你踩下踏板的瞬间开始录音（红灯亮），如果是已经有录音的（数字带点），则只是开始播放所选录音，如果之前没有设定拍速，这时TAP灯会在假设你弹奏了1、2、4、8、16……个小节的基础上，根据智能计算的拍速闪烁，但不会播放拍子。
2、再踩一下开始重复loop，同时继续保持录音状态（绿灯和红灯同时亮），另外两个节奏灯也开始按照一定拍速闪烁，这时可以继续弹奏叠加音轨，3、再踩一下录音状态结束（红灯灭），继续重复你已经弹奏、叠加的音轨。
此时2、3步骤可以一直重复，使你能不断叠加4、在播放的任何时候（不管红灯亮还是灭）踩住踏板2秒，屏幕会显示Un（Undo），此操作会删除你最近一次叠加的音轨，若想反悔，则再踩踏板2秒，屏幕显示Re（Redo），恢复刚刚删除的部分。
5、快速踩两次踏板，播放、录音都停止（但是设了拍速的话，TAP灯会继续闪），再踩则又从头播放。
如果在停止时踩住踏板2秒，则清除你刚刚已录下的所有段子，屏幕显示CL，此步骤不能恢复，但也只是删除临时内存里的，内置存储不影响，内置删除见7。
6、想要存储你已弹奏、叠加好的段子，就在停止播放时，先按一下WRITE，屏幕在Wr和数字之间闪烁，然后选择想存位置的数字编号，（此时可踩踏板取消存储步骤）再按一下WRITE，待屏幕、绿灯快速闪烁完后，存储完毕。
