华为GPON OLT单业务配置命令

MA5683T(config)#MA5683T(config)#MA5683T(config)#DISPLAY CURRent-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：DISPLAY CURRent-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0x64110001alarm output alarmid 0x64120001dba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F9389148000A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "485754433F52DD9A" omci ont-lineprofile-id 100ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "485754433F52DE9A" omci ont-lineprofile-id 100ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address 192.168.1.254 255.255.255.0#[meth]<meth0>interface meth0ip address 10.11.104.2 255.255.255.0#[null]<null0>interface null0#[aaa]<aaa>aaaauthentication-scheme "default"#authorization-scheme "default"#accounting-scheme "default"#domain "default"#returnMA5683T(config)#MA5683T(config)#MA5683T(config)#disdev^% 未知的命令，错误位于'^'所指的位置MA5683T(config)#display dev^% 未知的命令，错误位于'^'所指的位置MA5683T(config)#display version{ <cr>|backplane<K>|frameid/slotid<S><Length 1-15> }:命令：display version版本: MA5600V800R011C00补丁: SPC100 SPH102 HP1007 HP1102产品类型: MA5683T主用主控板运行区域信息:-------------------------------------------------- 当前程序运行区: A当前数据运行区: AA区程序的版本: MA5600V800R011C00B区程序的版本: MA5600V800R011C00A区数据的版本: MA5600V800R011C00B区数据的版本: MA5600V800R011C00--------------------------------------------------备用主控板运行区域信息:-------------------------------------------------- 当前程序运行区: A当前数据运行区: AA区程序的版本: MA5600V800R011C00B区程序的版本: MA5600V800R011C00A区数据的版本: MA5600V800R011C00B区数据的版本: MA5600V800R011C00-------------------------------------------------- 已经运行: 0 天, 0 小时, 37 分钟, 38 秒MA5683T(config)#MA5683T(config)#MA5683T(config)#display interface br^% 参数错误，错误位于'^'所指的位置MA5683T(config)#display ip interface{ <cr>|brief<K>|meth<K>|null<K>|vlanif<K> }:命令：display ip interfacemeth0当前状态：DOWN链路层协议当前状态：DOWNMTU是1500字节输入0包, 共0字节, 有0多播包输出0包, 共0字节, 有0多播包本接口地址是10.11.104.2/24广播地址是: 10.11.104.255收到的TTL等于1的报文个数: 0收到的TTL非法的报文个数: 0收到的ICMP报文总数: 0ECHO应答: 0不可达: 0源地址抑止: 0路由重定向: 0ECHO请求: 0 路由广播: 0路由请求: 0时间超期: 0IP头错: 0时间戳请求: 0时间戳响应: 0信息请求: 0信息响应: 0掩码请求: 0掩码响应: 0未知类型: 0null0当前状态：UP链路层协议当前状态：UP (Spoofing)MTU是1500字节输入0包, 共0字节, 有0多播包输出0包, 共0字节, 有0多播包没有配置Internet协议处理广播地址是: 0.0.0.0收到的TTL等于1的报文个数: 0 收到的TTL非法的报文个数: 0 收到的ICMP报文总数: 0 ECHO应答: 0 不可达: 0源地址抑止: 0路由重定向: 0 ECHO请求: 0 路由广播: 0路由请求: 0时间超期: 0IP头错: 0时间戳请求: 0时间戳响应: 0信息请求: 0信息响应: 0掩码请求: 0 MA5683T(config)#interface vlanif 100MA5683T(config-if-vlanif100)#display this^ % 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#display curr^% 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)# display curr^% 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)#?---------------------------------------------vlanif100 模式命令：---------------------------------------------arp 地址解析协议description 设置接口描述信息dhcp DHCP命令组dhcp-client DHCP client 命令dhcp-server 配置此三层接口的DHCP server组dhcpv6-server 配置此三层接口的DHCPv6 server组display 显示相关信息firewall 设定防火墙igmp 设置IGMP参数ip <组>ip命令组ipv6 <组>ipv6命令组isis 配置ISIS协议接口参数mpls <组>mpls命令组mtu <组>MTU命令组ntp-service 指定NTP(网络时间协议)配置信息ospf <组>ospf命令组pim 设置PIM 协议接口参数priority-mark 为本接口发出的报文标记优先级quit 退出当前命令模式进入前一级命令模式，也可以退出配置环境return 退出当前命令模式进入Privilege模式MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#quitMA5683T(config)#display current-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：display current-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0x64110001alarm output alarmid 0x64120001dba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F9389148000A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "485754433F52DD9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "485754433F52DE9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address 192.168.1.254 255.255.255.0#[meth]<meth0>interface meth0ip address 10.11.104.2 255.255.255.0#[null]<null0>interface null0#MA5683T(config)#interface vlanif 100MA5683T(config-if-vlanif100)#ip address 192.168.88.254 24{ <cr>|description<K>|sub<K> }:命令：ip address 192.168.88.254 24MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#quitMA5683T(config)#display current-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：display current-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0x64110001alarm output alarmid 0x64120001dba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F9389148000A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "485754433F52DD9A" omci ont-lineprofile-id 100ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "485754433F52DE9A" omci ont-lineprofile-id 100ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-tableindex 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address 192.168.88.254 255.255.255.0#[meth]<meth0>interface meth0ip address 10.11.104.2 255.255.255.0#[null]<null0>MA5683T(config)#MA5683T(config)#save{ <cr>|configuration<K>|data<K> }:命令：saveMA5683T(config)#保存配置文件操作需要一段时间，请稍候...MA5683T(config)#MA5683T(config)#MA5683T(config)#Warning: There is a risk on the user-interface which you login through. Please change the configuration of the user-interface as soon as possible.<switch-ceshi><switch-ceshi><switch-ceshi>sysEnter system view, return user view with Ctrl+Z.[switch-ceshi]inter vla n100^Error: Wrong parameter found at '^' position.[switch-ceshi]inter vlan 100[switch-ceshi-Vlanif100]ip add 192^Error: Wrong parameter found at '^' position.[switch-ceshi-Vlanif100]168^Error: Unrecognized command found at '^' position.[switch-ceshi-Vlanif100]88^Error: Unrecognized command found at '^' position.[switch-ceshi-Vlanif100]ip add 192.168.88.1 24[switch-ceshi-Vlanif100]Apr 2 2000 00:25:37 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[0]:The router ID is 0.0.0.0. (InstanceID=0)Apr 2 2000 00:25:37 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[1]:The router ID is 192.168.88.1. (InstanceID=0)[switch-ceshi-Vlanif100]dis this#interface Vlanif100ip address 192.168.88.1 255.255.255.0#return[switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100]q[switch-ceshi]q<switch-ceshi>savThe current configuration (excluding the configurations of unregistered boards or cards) will be written to flash:/vrpcfg.zip.Are you sure to continue?[Y/N]Error: Please choose 'YES' or 'NO' first before pressing 'Enter'. [Y/N]:yNow saving the current configuration to the slot 0..Apr 2 2000 00:25:40 switch-ceshi %%01CFM/4/SAVE(s)[2]:The user chose Y when deciding whether to save the configuration to the device..Save the configuration successfully.<switch-ceshi><switch-ceshi>Apr 2 2000 00:25:46 switch-ceshi DS/4/DATASYNC_CFGCHANGE:OID 1.3.6.1.4.1.2011.5.25.191.3.1 configurations have been changed. The current change number is 1, the change loop count is 0, and the maximum number of records is 4095.<switch-ceshi><switch-ceshi><switch-ceshi>sysEnter system view, return user view with Ctrl+Z.[switch-ceshi]inter vlan 100[switch-ceshi-Vlanif100]ip add 192.168.88.100 24[switch-ceshi-Vlanif100]Apr 2 2000 00:26:20 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[3]:The router ID is 0.0.0.0. (InstanceID=0)Apr 2 2000 00:26:20 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[4]:The router ID is 192.168.88.100. (InstanceID=0)[switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100]dis this#interface Vlanif100ip address 192.168.88.100 255.255.255.0#return[switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100]q[switch-ceshi]q<switch-ceshi>savThe current configuration (excluding the configurations of unregistered boards or cards) will be written to flash:/vrpcfg.zip.Are you sure to continue?[Y/N]yNow saving the current configuration to the slot 0..Apr 2 2000 00:26:24 switch-ceshi %%01CFM/4/SAVE(s)[5]:The user chose Y when deciding whether to save the configuration to the device...Save the configuration successfully.<switch-ceshi><switch-ceshi>Apr 2 2000 00:26:26 switch-ceshi DS/4/DATASYNC_CFGCHANGE:OID 1.3.6.1.4.1.2011.5.25.191.3.1 configurations have been changed. The current change number is 2, the change loop count is 0, and the maximum number of records is 4095.<switch-ceshi><switch-ceshi><switch-ceshi>ping 192.168.88.1PING 192.168.88.1: 56 data bytes, press CTRL_C to breakRequest time outRequest time outRequest time outRequest time outRequest time out--- 192.168.88.1 ping statistics ---5 packet(s) transmitted0 packet(s) received100.00% packet loss<switch-ceshi>ping 192.168.88.254PING 192.168.88.254: 56 data bytes, press CTRL_C to breakReply from 192.168.88.254: bytes=56 Sequence=1 ttl=255 time=4 msReply from 192.168.88.254: bytes=56 Sequence=2 ttl=255 time=1 msReply from 192.168.88.254: bytes=56 Sequence=3 ttl=255 time=1 msReply from 192.168.88.254: bytes=56 Sequence=4 ttl=255 time=1 msReply from 192.168.88.254: bytes=56 Sequence=5 ttl=255 time=1 ms--- 192.168.88.254 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 1/1/4 ms<switch-ceshi>ping 192.168.88.11PING 192.168.88.11: 56 data bytes, press CTRL_C to breakReply from 192.168.88.11: bytes=56 Sequence=1 ttl=64 time=4 msReply from 192.168.88.11: bytes=56 Sequence=2 ttl=64 time=1 msReply from 192.168.88.11: bytes=56 Sequence=3 ttl=64 time=1 msReply from 192.168.88.11: bytes=56 Sequence=4 ttl=64 time=1 msReply from 192.168.88.11: bytes=56 Sequence=5 ttl=64 time=1 ms--- 192.168.88.11 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 1/1/4 ms<switch-ceshi>Apr 2 2000 00:30:55 switch-ceshi %%01IFPDT/4/IF_STATE(l)[6]:Interface GigabitEthernet0/0/4 has turned into UP state.<switch-ceshi><switch-ceshi>dis mac-ade^Error: Unrecognized command found at '^' position.<switch-ceshi>dis mac-add------------------------------------------------------------------------------- MAC Address VLAN/VSI Learned-From Type------------------------------------------------------------------------------- 000c-296e-ed9a 100/- GE0/0/4 dynamic04f9-3891-4805 100/- GE0/0/28 dynamic 0800-0699-4ae5 100/- GE0/0/28 dynamic 28d2-44c8-1c31 100/- GE0/0/28 dynamica01d-48b7-59c8 100/- GE0/0/4 dynamice0dc-a08b-d21d 100/- GE0/0/28 dynamic------------------------------------------------------------------------------- Total items displayed = 6<switch-ceshi>dis arpIP ADDRESS MAC ADDRESS EXPIRE(M) TYPE INTERFACE VPN-INSTANCEVLAN------------------------------------------------------------------------------ 192.168.88.100 c4ff-1f4c-1c30 I - Vlanif100192.168.88.254 04f9-3891-4805 16 D-0 GE0/0/28100192.168.88.11 28d2-44c8-1c31 17 D-0 GE0/0/28100------------------------------------------------------------------------------ Total:3 Dynamic:2 Static:0 Interface:1<switch-ceshi>ping 192.168.88.345Error: Unknown host 192.168.88.345.<switch-ceshi>ping 192.168.88.35PING 192.168.88.35: 56 data bytes, press CTRL_C to breakReply from 192.168.88.35: bytes=56 Sequence=1 ttl=64 time=1 msReply from 192.168.88.35: bytes=56 Sequence=2 ttl=64 time=1 msReply from 192.168.88.35: bytes=56 Sequence=3 ttl=64 time=1 msReply from 192.168.88.35: bytes=56 Sequence=4 ttl=64 time=1 msReply from 192.168.88.35: bytes=56 Sequence=5 ttl=64 time=1 ms--- 192.168.88.35 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 1/1/1 ms<switch-ceshi>ping 192.168.88.1PING 192.168.88.1: 56 data bytes, press CTRL_C to breakReply from 192.168.88.1: bytes=56 Sequence=1 ttl=30 time=3 msReply from 192.168.88.1: bytes=56 Sequence=2 ttl=30 time=1 msReply from 192.168.88.1: bytes=56 Sequence=3 ttl=30 time=1 msReply from 192.168.88.1: bytes=56 Sequence=4 ttl=30 time=3 msReply from 192.168.88.1: bytes=56 Sequence=5 ttl=30 time=1 ms--- 192.168.88.1 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 1/1/3 ms<switch-ceshi>ping 192.168.88.2PING 192.168.88.2: 56 data bytes, press CTRL_C to breakReply from 192.168.88.2: bytes=56 Sequence=1 ttl=30 time=3 msReply from 192.168.88.2: bytes=56 Sequence=2 ttl=30 time=3 msReply from 192.168.88.2: bytes=56 Sequence=3 ttl=30 time=2 msReply from 192.168.88.2: bytes=56 Sequence=4 ttl=30 time=2 msReply from 192.168.88.2: bytes=56 Sequence=5 ttl=30 time=2 ms--- 192.168.88.2 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 2/2/3 ms<switch-ceshi>Apr 2 2000 00:37:43 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[7]:Interface GigabitEthernet0/0/4 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, 2.5G: No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, 2.5G: No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No))Apr 2 2000 00:37:43 switch-ceshi %%01IFPDT/4/IF_STATE(l)[8]:Interface GigabitEthernet0/0/4 has turned into DOWN state.<switch-ceshi>Apr 2 2000 00:38:19 switch-ceshi %%01IFPDT/4/IF_STATE(l)[9]:Interface GigabitEthernet0/0/6 has turned into UP state.<switch-ceshi>Apr 2 2000 00:38:49 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[10]:Interface GigabitEthernet0/0/6 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, 2.5G: No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, 2.5G: No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No))Apr 2 2000 00:38:49 switch-ceshi %%01IFPDT/4/IF_STATE(l)[11]:Interface GigabitEthernet0/0/6 has turned into DOWN state.<switch-ceshi>Apr 2 2000 00:39:14 switch-ceshi %%01IFPDT/4/IF_STATE(l)[12]:Interface GigabitEthernet0/0/6 has turned into UP state.<switch-ceshi>Apr 2 2000 00:39:28 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[13]:Interface GigabitEthernet0/0/6 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, 2.5G: No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, 2.5G: No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, 2.5G: No, 10G: No))Apr 2 2000 00:39:28 switch-ceshi %%01IFPDT/4/IF_STATE(l)[14]:Interface GigabitEthernet0/0/6 has turned into DOWN state.<switch-ceshi><switch-ceshi><switch-ceshi>ping 192.168.88.2PING 192.168.88.2: 56 data bytes, press CTRL_C to breakReply from 192.168.88.2: bytes=56 Sequence=1 ttl=30 time=5 msReply from 192.168.88.2: bytes=56 Sequence=2 ttl=30 time=2 msReply from 192.168.88.2: bytes=56 Sequence=3 ttl=30 time=3 msReply from 192.168.88.2: bytes=56 Sequence=4 ttl=30 time=2 msReply from 192.168.88.2: bytes=56 Sequence=5 ttl=30 time=2 ms--- 192.168.88.2 ping statistics ---5 packet(s) transmitted5 packet(s) received0.00% packet lossround-trip min/avg/max = 2/2/5 ms<switch-ceshi>\^Error: Unrecognized command found at '^' position.<switch-ceshi><switch-ceshi>dis port vlan actT=TAG U=UNTAG------------------------------------------------------------------------------- Port Link Type PVID VLAN List------------------------------------------------------------------------------- GE0/0/1 access 100 U: 100GE0/0/2 access 100 U: 100GE0/0/3 access 100 U: 100GE0/0/4 access 100 U: 100GE0/0/5 access 100 U: 100GE0/0/6 access 100 U: 100GE0/0/7 access 100 U: 100GE0/0/8 access 100 U: 100GE0/0/9 access 100 U: 100GE0/0/10 access 100 U: 100GE0/0/11 access 100 U: 100GE0/0/12 access 100 U: 100GE0/0/13 access 100 U: 100GE0/0/14 access 100 U: 100GE0/0/15 access 100 U: 100GE0/0/16 access 100 U: 100GE0/0/17 access 100 U: 100GE0/0/18 access 100 U: 100GE0/0/19 access 100 U: 100GE0/0/20 access 100 U: 100GE0/0/21 access 100 U: 100GE0/0/22 access 100 U: 100GE0/0/23 access 100 U: 100GE0/0/24 trunk 1 T: 100GE0/0/25 access 1 U: 1GE0/0/26 access 1 U: 1GE0/0/27 access 1 U: 1GE0/0/28 trunk 1 T: 100<switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi>dis mac-add------------------------------------------------------------------------------- MAC Address VLAN/VSI Learned-From Type------------------------------------------------------------------------------- 04f9-3891-4805 100/- GE0/0/28 dynamic 0800-0699-4ae5 100/- GE0/0/28 dynamice0dc-a08b-d21d 100/- GE0/0/28 dynamic------------------------------------------------------------------------------- Total items displayed = 3<switch-ceshi>dis arpIP ADDRESS MAC ADDRESS EXPIRE(M) TYPE INTERFACE VPN-INSTANCEVLAN------------------------------------------------------------------------------ 192.168.88.100 c4ff-1f4c-1c30 I - Vlanif100192.168.88.254 04f9-3891-4805 20 D-0 GE0/0/28100192.168.88.11 28d2-44c8-1c31 6 D-0 GE0/0/28100192.168.88.1 0800-0699-4ae5 10 D-0 GE0/0/28100192.168.88.2 e0dc-a08b-d21d 19 D-0 GE0/0/28100------------------------------------------------------------------------------ Total:5 Dynamic:4 Static:0 Interface:1<switch-ceshi>Apr 2 2000 00:43:07 switch-ceshi %%01IFPDT/4/IF_STATE(l)[15]:Interface GigabitEthernet0/0/4 has turned into UP state.<switch-ceshi>。

OLT业务配置一、华为OLT操作EPON1、开局配置（暂时不用管）2、查看上联口的VLANDisplay port vlan 0/8/13、创建DBA （动态带宽分配）模版①在创建DBA模版之前，先用命令display dba-profile all查看哪些Profile-ID已经被占用，我们创建新DBA时要避开这些已经创建好的DBAo②d ba-profile add profile-id 21 profile-name "Li” type3 assure 4096 max10240…-创建新的DBA模版也可以先不指定profile-id,设置为缺省值，有系统自动分配其ID号dba-profile add profile-name qian type3 assure 1024 max 10240---缺省值③display dba-profile profile-id 21---查看新建的DBA 模版dba-profile delete profile-id 21删除新建的DBA 模版dba-profile modify profile-id 21・・■修改新建的DBA 模版2、创建线路模版display ont-lineprofile epon all—首先用命令查看现有的线路板模型<ont-lineprofile epon profile-id 22 profile-name "Li"—创建新的线路板模型2 PON接口绑定VLANZXAN(config)#interface epon-onu_ 1/4/8:15ZXAN(config-if)#switchport mode trunkZXAN(config-if)#switchport vlan 666 tag查询PON-ON U接口的vlan信息：ZXAN(config・if)#show vlan port epon-onu_l/4/8:153 ONU端口VLAN配置在ONU远程管理模式下，配置用户端口vlanZXAN(config)#pon-onu-mng epon-onu_ 1/4/8:15ZXAN(epon-onu-mng)#vlan port eth_O/l mode tag vlan 666 priority 0 ZXAN(gpon-onu-mng)#end组播测试：SFU与HGU方法相同1.在ONU接口配置模式下，配置ONU带宽。

华为OLT的命令：常见命令：查看LOID的命令：display ont autofind all 查看是否有新接入interface epon 0/2display ont info 1 all （显示该PON下已注册的ONU设备）display ont info 1 1 （显示ONU注册后的具体信息，这里面需关注的是SNMP pro 、Line pro两个值）添加删除注册信息命令：添加和删除已注册的ONT信息（这里是以MAC认证的方式举例）：ont add 0 7 mac-auth 0018-82E8-1007 snmp ont-linepro 13 desc "XXX" //在第0个pon口添加ID为7的ONU，注册方式为MAC认证，ONT的线路模板为13ont ipconfig 0 7 ip-address 192.168.68.182 mask 255.255.255.0 gateway192.168.68.254 manage-vlan 996 priority 0 //自动给ONU下发管理地址并定义管理vlan。

删除已经注册的ONU：1.先删除给ONU下发的管理地址：undo ont ipconfig 0 7 ip-address 192.168.68.182 mask 255.255.255.0 gateway 192.168.68.254 manage-vlan 996 priority 02.再删除ONU在OLT上的MAC地址认证：undo ont add 0 7 mac-auth 0018-82E8-1007 snmp ont-linepro 13 desc "XXX"详细命令说明：普通用户模式下，使用display board 0命令查询所有单板的状态。

所有单板的状态正常，即所有单板在线状态为“Online”且运行状态不为“Fault”。

O L T配置方法以及维护手册Revised by Petrel at 2021OLT配置手册以及维护常见问题OLT作为GPON的核心设备，平时经常遇到各种问题，下面就配置方法以及遇到的问题做一下说明：一、登录：1.超级终端登录：进入后选择T（TL1命令），输入口令即可，EnterUsername:SUPERUSER/EnterPassword:ANS#150CLI命令如图：进入后直接输入口令即可。

login:isadmin/password:ans#1502.telnet登录方式：进入后输入口令即可进行操作；进入后输入口令即可。

3.SecureCRT登录：进入后输入口令即可登录TL1命令；同样道理CLI命令如图：输入口令即可登录。

口二、数据的查看以及配置：1.TL1数据的配置总体来说，TL1数据配置分几大类：1.ENT_创建；2.ED_修改；3.DLT_删除；4.RTRV_查询。

一般情况下只有在前期进行数据配置的时候才会有ENT，数据配置后自动保存，没有特殊情况不会进行ED以及DLT的操作，而平时最常用的则为RTRV命令,下面专门针对RTRV进行说明；登录成功后输入RTRV，进入如下界面：即可进行如图标记的各种查询，平时用的较多查询为ONT（onu），ALM(告警)，PONVLAN(vlan的配置)，PONFDBDYNAMIC（故障处理vlan学习下联mac），PON（PON口状态），EQPT（板卡状态）等，输入后回车可进行下一步的选择，也可进行ALL的选择，根据自己需要而定。

以PON为例查询如图：图中看到1.3口IS状态表示PON口开启，下面连接设备；2口OOS-AU为自动关闭状态，一旦下面连接设备即可开启，可收到PON的光；4口OOS-AUMA为手动关闭状态，下面连接设备也不会收到OLT的发光，需要我们手动进行开启。

查询ONT时也同样道理，IS代表ONU开启运行状态，OOS-AU表示自动关闭状态，OOS-AUMA表示手动关闭状态。

华为OLTMA5680TGPON开局指导配置指南1.确认设备连接及环境准备首先，确保MA5680T设备已正确连接到光纤网络，并与主控PC通过网线连接。

确认所连接环境的准备工作已就绪，例如光缆连接稳定、线缆接口无松动、设备通电正常等。

2.打开配置工具使用终端软件如SecureCRT等打开MA5680T设备的配置界面。

输入默认的用户名和密码进行登录，默认用户名为"root"，密码为"admin"。

登录成功后，可以进入设备的操作界面。

3.确认设备信息进入设备操作界面后，通过命令"show version"确认设备的基本信息，包括设备型号、软件版本、设备序列号等。

确保设备信息无误后，可以开始进行后续的配置工作。

4.创建配置模板使用命令"system-view"进入全局配置模式，通过命令"template"创建配置模板。

模板包括用户名、密码、接口设置、业务配置等内容。

可以根据实际需求创建多个不同的配置模板。

5.添加用户及口配置在配置模板中，通过命令"ont-lineprofile gpon profile-id"添加用户配置信息。

其中"profile-id"为用户配置的ID号。

可以配置用户的上下行速率、VLAN ID等参数。

接着，通过命令"ont-srvprofile gponprofile-id vport-mode gemport"配置用户的业务信息。

其中"gemport"为GEM端口的配置信息，包括VLAN的配置、业务的类型、业务的模式等。

6.端口配置通过命令"interface gpon X/X/X"进入Gpon端口的配置模式，通过命令"port hybrid gpon"将端口配置为GPON类型。

华为OLT数据配置（宽带+电话业务）及光猫配置教程1、olt数据配置及光猫注册登陆OLTTelnet：10.11.104.2>>User name:root>>User password:adminma5680t>enablema5680t#configma5680t(config)#switch language-mode当前语言模式已切换到本地语种ma5680t(config)#Vlan10//新建电话业务vlanVlan100//新建宽带业务vlanPort vlan100/190Port vlan1000/190//vlan数据加入上行端口ont-srvprofile gpon profile-id101profile-name"101"ont-port pots adaptive eth adaptiveport vlan eth1translation100user-vlan100port vlan eth2translation100user-vlan100port vlan eth3translation100user-vlan100port vlan eth4translation100user-vlan100port vlan iphost translation10user-vlan10CommitQuit//新建业务模版ont-lineprofile gpon profile-id101profile-name"101"tr069-management ip-index0tcont1dba-profile-id100gem add1eth tcont1gem add2eth tcont1gem add3eth tcont1gem add4eth tcont1gem mapping11vlan100gem mapping12vlan10commitquit//新建线路模版ma5680t(config)#display ont autofind all----------------------------------------------------------------------------序列号:1框/槽/端口:0/1/4ONT SN:43494F54019E0AA0密码:0x00000000000000000000逻辑标识:校验码:生产厂商ID:CIOTONT版本:HV1.1.00.053ONT软件版本:V1.1.00.053ONT设备ID:GM219-SONT自动发现时间:2020-08-2913:15:12+08:00----------------------------------------------------------------------------GPON自动发现ONT个数为1ma5680t(config)#interface gpon0/1ma5680t(config-if-gpon-0/1)#ont confirm4all sn-auth omci ont-lineprofile-id101 ont-srvprofile-id101{<cr>|desc<K>}:命令：ont confirm4all sn-auth omci ont-lineprofile-id101ont-srvprofile-id101可以被添加的ONT数目:1,成功数目:1端口号:4,ONT号:8ma5680t(config-if-gpon-0/1)#ont port native-vlan48eth1vlan100{<cr>|priority<K>}:命令：ont port native-vlan48eth1vlan100ma5680t(config-if-gpon-0/1)#ont port native-vlan48eth2vlan100{<cr>|priority<K>}:命令：ont port native-vlan48eth2vlan100ma5680t(config-if-gpon-0/1)#ont port native-vlan48eth3vlan100{<cr>|priority<K>}:命令：ont port native-vlan48eth3vlan100ma5680t(config-if-gpon-0/1)#ont port native-vlan48eth4vlan100{<cr>|priority<K>}:命令：ont port native-vlan48eth4vlan100ma5680t(config-if-gpon-0/1)#ont port native-vlan48iphost vlan10{<cr>|priority<K>}:命令：ont port native-vlan48iphost vlan10ma5680t(config-if-gpon-0/1)#quitma5680t(config)#service-port vlan100gpon0/1/4ont8gemport1multi-service user-vlan 100{<cr>|bundle<K>|inbound<K>|rx-cttr<K>|tag-transform<K>|user-encap<K>}:命令：service-port vlan100gpon0/1/4ont8gemport1multi-service user-vlan100ma5680t(config)#service-port vlan10gpon0/1/4ont8gemport1multi-service user-vlan 10{<cr>|bundle<K>|inbound<K>|rx-cttr<K>|tag-transform<K>|user-encap<K>}:命令：service-port vlan10gpon0/1/4ont8gemport1multi-service user-vlan10ma5680t(config)#ma5680t(config)#save//最后保存数据至此OLT数据配置完成。

《1-常用命令》1.1进入特权模式MA5680T>enable //打开特权EXECMA5680T#config //进入终端配置模式MA5680T(config)#sysname SJZ-HW-OLT-1//设备命名(一般为开局配置)MA5680T(config)#switch language-mode //切换语言,可以在中英文语言中转换。

1.2创建一个用户MA5680T(config) #terminal user name //添加操作用户huaweiUser Name(length<6,15>):huawei//设置用户名User Password(length<6,15>):huawei123//要求输入密码.输入部分实际为不可见的Confirm Password(length<6,15>):huawei123//要求再次确认一遍密码User profile name(<=15 chars)[root]:root//输入用户管理级别User's Level:1. Common User2. Operator3. Administrator:3//选择用户权限Permitted Reenter Number(0--4):4 //设置此用户名可重复登录次数，一般要求为1次User's Appended Info(<=30 chars):HuaweiAdm//添加描述，可不设置。

Adding user succeedsRepeat this operation? (y/n)[n]:1.3其它常用命令MA5680T(config)#display board 0 //检查设备单板状态，此命令最常用。

MA5680T(config)#board confirm 0 //对于自动发现的单板，需要确认后，单板才能使用。

//对于未确认的单板，单板硬件运行指示灯正常，但是业务端口无法工作。

华为OLT业务配置MA5683T>enableMA5683T#config//OLT升级：开启tftp服务器huawei(config)#load packetfile sftp x.x.x.x V800RxxxCxxSPxxxx_wholepackage(SPCx00)_zzzz_new.bin The new packet file will overwrite the old one Rollback function will be disabled Be sure that the system needn't this function Are you sure to load new packet file? (y/n)[n]:y huawei(config)#display progress load//load完成后active configuration systemMA5683T(config)#active configuration systemSystem will reboot after this command, continue? (y/n)[n]:y /*********EPON宽带配置***********/// 创建vlan并在上行口做透传MA5683T(config)#vlan 3800 smart //创建vlanMA5683T(config)#vlan 3780 to 3781 smart // 宽带外层vlan MA5683T(config)#vlan attrib 3780 to 3781 q-in-q //设置宽带外层VLAN QinQ属性MA5683T(config)#vlan attrib 3800 q-in-q //设置语音外层VLAN QinQ属性MA5683T(config)#port vlan 164 0/8 0MA5683T(config)#port vlan 3800 0/9 0MA5680T(config)#port vlan 3780 to 3781 0/9 0 //上行口透传olt上所有vlanMA5683T(config)#display port vlan 0/8/0MA5683T(config)#display port vlan 0/9/0MA5683T(config)#display interface vlanif 3800MA5683T(config)#interface scu 0/6MA5683T(config-if-scu-0/6)#native-vlan 2 vlan 49//DBA（动态带宽分配）模版------------------MA5683T(config)#display dba-profile all//创建DBA（动态带宽分配）模版MA5683T(config)#dba-profile add profile-name ftth type3 assure 1024 max 10240MA5683T(config)#display dba-profile profile-name 10M//线路模版----------------------MA5683T(config)#display ont-lineprofile epon allMA5683T(config)#ont-lineprofile epon profile-name ftthMA5683T(config-epon-lineprofile-17)#llid dba-profile-name 10M /绑定dba模版MA5683T(config-epon-lineprofile-17)#commitMA5683T(config-epon-lineprofile-17)#quitMA5683T(config)#MA5683T(config)#display ont-lineprofile epon profile-id 17 //查看新建线路板模型//undo ont-lineprofile epon profile-id 17 //删除新建线路板模型//业务模版-------------------MA5683T(config)#display ont-srvprofile epon allMA5683T(config)#ont-srvprofile epon profile-name ftth{ |profile-id }:Command:ont-srvprofile epon profile-name ftthMA5683T(config-epon-srvprofile-4)#ont-port pots 2 eth 4 //指定接口类型MA5683T(config-epon-srvprofile-4)#port vlan eth 1 transparent //以太网口全部设置成透传模式MA5683T(config-epon-srvprofile-4)#commitMA5683T(config-epon-srvprofile-4)#quitMA5683T(config)#//MA5683T(config)#undo ont-srvprofile epon profile-name ftthMA5683T(config)#//ONT认证--------------MA5683T(config)#interface epon 0/3MA5683T(config-if-epon-0/3)#port 0 ont-auto-find enable //第0个PON口设置成自动发现MA5683T(config-if-gpon-0/1)#display port info 0MA5683T(config)#display ont autofind allMA5683T(config)#interfaceepon 0/3//注册上线ONUMA5683T(config-if-epon-0/3)#ont add 7 [loid-auth ****/mac-auth ****-****-****] oam ont-lineprofile-name ftth ont-srvprofile-name ftthMA5683T(config-if-epon-0/3)#quitMA5683T(config)#display current-configuration ont 0/3/7 6 //MA5683T(config-if-epon-0/3)#ont modify 2 6 mac 1111-1111-1111 //替换设备MA5683T(config-if-epon-0/3)#display ont alarm-state 7 all //查看ONT当前告警状态MA5683T(config-if-epon-0/3)#display ont optical-info 7 all //查看ONT光模块信息MA5683T(config)#display ont info ... //查看某个mac地址的ONU信息(by-sn/by-mac/槽位.端口)MA5683T(config)#display board 0/3 //查看某个板卡上ONU 状态信息MA5683T(config)#display current-configuration port 0/3/7 //查看当前配置MA5683T(config)#display board 0 //查看板卡信息MA5683T(config)#display mac-address ... //查看用户macaddress//上网业务流-----------------------MA5683T(config)#service-port vlan 48 epon 0/3/7 ont 6 multi-service user-vlan 1001MA5683T(config)#display service-port port 0/3/7 ont 6//ONU端口数据MA5683T(config)#interface epon 0/3MA5683T(config-if-epon-0/3)#ont port native-vlan 7 6 eth 1 vlan 1001MA5683T(config-if-epon-0/3)#display ont port vlan remote 7 6 eth 1MA5683T(config-if-epon-0/3)#quit/*********GPON宽带配置***********//*上联业务vlan用48,用户vlan1001//DBA（动态带宽分配）模版------------------MA5683T(config)#display dba-profile all//创建DBA（动态带宽分配）模版MA5683T(config)#dba-profile add profile-name ftth type3 assure 1024 max 10240MA5683T(config)#display dba-profile profile-name 20M//线路模版----------------------MA5683T(config)#display ont-lineprofile gpon allMA5683T(config)#ont-lineprofile gpon profile-name g103 MA5683T(config-gpon-lineprofile-17)#tcont 4 dba-profile-name 20MMA5683T(config-gpon-lineprofile-17)#gem add 11 eth tcont 4MA5683T(config-gpon-lineprofile-17)#gem mapping 11 0 vlan 1001MA5683T(config-gpon-lineprofile-17)#commitMA5683T(config-gpon-lineprofile-17)#quitMA5683T(config)#业务模版---------------------MA5683T(config)#ont-srvprofile gpon profile-name g103MA5683T(config-gpon-srvprofile-5)#ont-port eth adaptive pots adaptiveMA5683T(config-gpon-srvprofile-5)#port vlan eth 1 1001MA5683T(config-gpon-srvprofile-5)#commitMA5683T(config-gpon-srvprofile-5)#quitMA5683T(config)#/ONT认证----------------------MA5683T(config)#interface gpon 0/1MA5683T(config-if-gpon-0/1)#port 0 ont-auto-find enable //第0个PON口设置成自动发现MA5683T(config)#display ont autofind allMA5683T(config)#interface gpon 0/1//注册上线ONUMA5683T(config-if-gpon-0/1)#ont add 7 [loid-auth ****/sn-auth ****-****-****] omci ont-lineprofile-name g103 ont-srvprofile-name g103MA5683T(config-if-gpon-0/1)#display ont version 7 6 查看ONU版本MA5683T(config)#display ont info 0 1 7 3//上网业务流-----------------------MA5683T(config)#MA5683T(config)#display service-port port 0/1/7 ont 3MA5683T(config)#service-port vlan 48 gpon 0/1/7 ont 3 gemport 11 multi-service user-vlan 1001//ONU端口数据MA5683T(config)#interface gpon 0/1MA5683T(config-if-gpon-0/1)#ont port native-vlan 7 3 eth 1 vlan 1001MA5683T(config-if-gpon-0/1)#quitMA5683T(config)#display current-configuration ont 0/1/7 3组播业务：1.上联业务vlan配置huawei(config)#vlan 1000 smarthuawei(config)#port vlan 1000 0/19 0huawei(config)#display port vlan 0/19/02.配置ONT配置ONT线路模板和业务模板、注册ONT（0/1/7 ONT 4）3.创建组播业务流service-port 1741 vlan 1000 gpon 0/1/7 ont 4 gemport 1 multi-service user-vlan 10004.创建组播VLAN并配置IGMPhuawei(config)#multicast-vlan 1000huawei(config-mvlan1000)#igmp version v3huawei(config-mvlan1000)#igmp mode proxyAre you sure to change IGMP mode?(y/n)[n]:y//huawei(config)#display igmp config vlan 10005.配置IGMP上行端口huawei(config-mvlan1000)#igmp uplink-port 0/19/0huawei(config-mvlan1000)#display igmp uplink-port vlan 1000huawei(config-mvlan1000)#btvhuawei(config-btv)#igmp uplink-port-mode defaultAre you sure to change the uplink port mode?(y/n)[n]:y6.配置节目库huawei(config-btv)#multicast-vlan 1000huawei(config-mvlan1000)#igmp program add name program1 ip 224.1.1.10 [host e][sourceip 10.10.10.10] //huawei(config-mvlan1000)#display igmp program vlan 10007.配置组播用户huawei(config-btv)#igmp user add service-port 1741 authhuawei(config-btv)#multicast-vlan 1000huawei(config-mvlan1000)#igmp multicast-vlan member service-port 1741//MA5683T(config-mvlan1000)#display igmp user smart-vlan 1000。

MA5683T(config)#MA5683T(config)#MA5683T(config)#DISPLAY CURRent-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：DISPLAY CURRent-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0xalarm output alarmid 0xdba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F00A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "3F52DD9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "3F52DE9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address <meth0>interface meth0ip address <null0>interface null0#[aaa]<aaa>aaaauthentication-scheme "default"#authorization-scheme "default"#accounting-scheme "default"#domain "default"#returnMA5683T(config)#MA5683T(config)#MA5683T(config)#disdev^% 未知的命令，错误位于'^'所指的位置MA5683T(config)#display dev^% 未知的命令，错误位于'^'所指的位置MA5683T(config)#display version{ <cr>|backplane<K>|frameid/slotid<S><Length 1-15> }:命令：display version版本 : MA5600V800R011C00补丁 : SPC100 SPH102 HP1007 HP1102产品类型: MA5683T主用主控板运行区域信息 :--------------------------------------------------当前程序运行区 : A当前数据运行区 : AA区程序的版本 : MA5600V800R011C00B区程序的版本 : MA5600V800R011C00A区数据的版本 : MA5600V800R011C00B区数据的版本 : MA5600V800R011C00--------------------------------------------------备用主控板运行区域信息 :--------------------------------------------------当前程序运行区 : A当前数据运行区 : AA区程序的版本 : MA5600V800R011C00B区程序的版本 : MA5600V800R011C00A区数据的版本 : MA5600V800R011C00B区数据的版本 : MA5600V800R011C00--------------------------------------------------已经运行: 0 天, 0 小时, 37 分钟, 38 秒MA5683T(config)#MA5683T(config)#MA5683T(config)#display interface br^% 参数错误，错误位于'^'所指的位置MA5683T(config)#display ip interface{ <cr>|brief<K>|meth<K>|null<K>|vlanif<K> }:命令：display ip interfacemeth0当前状态：DOWN链路层协议当前状态：DOWNMTU是1500字节输入0包, 共0字节, 有0多播包输出0包, 共0字节, 有0多播包本接口地址是广播地址是: 收到的TTL等于1的报文个数: 0收到的TTL非法的报文个数: 0收到的ICMP报文总数: 0ECHO应答: 0不可达: 0源地址抑止: 0路由重定向: 0ECHO请求: 0路由广播: 0路由请求: 0时间超期: 0IP头错: 0时间戳请求: 0时间戳响应: 0信息请求: 0信息响应: 0掩码请求: 0掩码响应: 0未知类型: 0null0当前状态：UP链路层协议当前状态：UP (Spoofing)MTU是1500字节输入0包, 共0字节, 有0多播包输出0包, 共0字节, 有0多播包没有配置Internet协议处理广播地址是: 收到的TTL等于1的报文个数: 0收到的TTL非法的报文个数: 0收到的ICMP报文总数: 0ECHO应答: 0不可达: 0源地址抑止: 0路由重定向: 0ECHO请求: 0路由广播: 0路由请求: 0时间超期: 0IP头错: 0时间戳请求: 0时间戳响应: 0信息请求: 0信息响应: 0掩码请求: 0MA5683T(config)#interface vlanif 100MA5683T(config-if-vlanif100)#display this^% 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#display curr^% 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)# display curr^% 未知的命令，错误位于'^'所指的位置MA5683T(config-if-vlanif100)#---------------------------------------------vlanif100 模式命令：---------------------------------------------arp 地址解析协议description 设置接口描述信息dhcp DHCP命令组dhcp-client DHCP client 命令dhcp-server 配置此三层接口的DHCP server组dhcpv6-server 配置此三层接口的DHCPv6 server组display 显示相关信息firewall 设定防火墙igmp 设置IGMP参数ip <组>ip命令组ipv6 <组>ipv6命令组isis 配置ISIS协议接口参数mpls <组>mpls命令组mtu <组>MTU命令组ntp-service 指定NTP(网络时间协议)配置信息ospf <组>ospf命令组pim 设置PIM 协议接口参数priority-mark 为本接口发出的报文标记优先级quit 退出当前命令模式进入前一级命令模式，也可以退出配置环境return 退出当前命令模式进入Privilege模式MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#quitMA5683T(config)#display current-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：display current-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0xalarm output alarmid 0xdba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F00A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "3F52DD9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "3F52DE9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address <meth0>interface meth0ip address<null0>interface null0#MA5683T(config)#interface vlanif 100MA5683T(config-if-vlanif100)#ip address 24{ <cr>|description<K>|sub<K> }:命令：ip address 24MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#MA5683T(config-if-vlanif100)#quitMA5683T(config)#display current-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }:命令：display current-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248system ex-mode backup#[global-config]<global-config>alarm output alarmid 0xalarm output alarmid 0xdba-profile add profile-id 100 profile-name "ceshi" type3 assure 409600 max 1024000ont-srvprofile gpon profile-id 100 profile-name "ceshi"ont-port eth 4commitont-lineprofile gpon profile-id 0 profile-name "line-profile_default_0"tcont 0 dba-profile-id 2tcont 1 dba-profile-id 0commitquitont-lineprofile gpon profile-id 100 profile-name "ceshi"tcont 1 dba-profile-id 100gem add 1 eth tcont 1gem mapping 1 0 vlan 100commitquit#[device-config]<device-config>board add 0/5 H802GPBDboard add 0/9 H801GICKboard add 0/12 H801CITD sub0 BITSBboard add standby sub0 CKMCrack info 0 description "RACK-300" name "RACK-300" manufactured-name "Huawei" #[public-config]<public-config>snmp-agent local-engineid 800007DB0304F00A#[vlan-config]<vlan-config>vlan 100 smartport vlan 100 0/9 0#[vlan-srvprof]<vlan-srvprof>vlan service-profile profile-id 100 profile-name "ceshi"user-bridging enablecommitvlan bind service-profile 100 profile-id 100#[gpon]<gpon-0/5>interface gpon 0/5port 0 ont-auto-find enableport 1 ont-auto-find enableport 2 ont-auto-find enableport 3 ont-auto-find enableport 4 ont-auto-find enableport 5 ont-auto-find enableport 6 ont-auto-find enableport 7 ont-auto-find enableont add 0 1 sn-auth "3F52DD9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont add 0 2 sn-auth "3F52DE9A" omci ont-lineprofile-id 100 ont-srvprofile-id 100 desc "ceshi-1"ont port native-vlan 0 1 eth 1 vlan 100 priority 0ont port native-vlan 0 1 eth 2 vlan 100 priority 0ont port native-vlan 0 1 eth 3 vlan 100 priority 0ont port native-vlan 0 1 eth 4 vlan 100 priority 0ont port native-vlan 0 2 eth 1 vlan 100 priority 0ont port native-vlan 0 2 eth 2 vlan 100 priority 0ont port native-vlan 0 2 eth 3 vlan 100 priority 0ont port native-vlan 0 2 eth 4 vlan 100 priority 0#[giu]<giu-0/12>interface giu 0/12mdi 2 normal#[emu-config]<emu-config>emu add 0 fan 0 1 "H801FCBI"emu add 1 h801citd 0 10 "H801CITD"#[bbs-config]<bbs-config>service-port 1 vlan 100 gpon 0/5/0 ont 1 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6service-port 2 vlan 100 gpon 0/5/0 ont 2 gemport 1 multi-service user-vlan 100 tag-transform translate inbound traffic-table index 6 outbound traffic-table index 6#[abs-config]<abs-config>config#[config]<config>mpls label start 8192#[prevlanif]<prevlanif>interface vlanif100#[vlanif]<vlanif100>interface vlanif100ip address <meth0>interface meth0ip address<null0>MA5683T(config)#MA5683T(config)#save{ <cr>|configuration<K>|data<K> }:命令：saveMA5683T(config)#保存配置文件操作需要一段时间，请稍候...MA5683T(config)#MA5683T(config)#MA5683T(config)#Warning: There is a risk on the user-interface which you login through. Please change the configuration of the user-interface as soon as possible.<switch-ceshi><switch-ceshi><switch-ceshi>sysEnter system view, return user view with Ctrl+Z.[switch-ceshi]inter vla n100^Error: Wrong parameter found at '^' position.[switch-ceshi]inter vlan 100[switch-ceshi-Vlanif100]ip add 192^Error: Wrong parameter found at '^' position.[switch-ceshi-Vlanif100]168^Error: Unrecognized command found at '^' position.[switch-ceshi-Vlanif100]88^Error: Unrecognized command found at '^' position.[switch-ceshi-Vlanif100]ip add 24[switch-ceshi-Vlanif100]Apr 2 2000 00:25:37 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[0]:The router ID is (InstanceID=0)Apr 2 2000 00:25:37 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[1]:The router ID is (InstanceID=0)[switch-ceshi-Vlanif100]dis this#interface Vlanif100ip address[switch-ceshi]q<switch-ceshi>savThe current configuration (excluding the configurations of unregistered boards or cards) will be written to flash:/.Are you sure to continue[Y/N]Error: Please choose 'YES' or 'NO' first before pressing 'Enter'. [Y/N]:yNow saving the current configuration to the slot 0..Apr 2 2000 00:25:40 switch-ceshi %%01CFM/4/SAVE(s)[2]:The user chose Y when deciding whether to save the configuration to the device..Save the configuration successfully.<switch-ceshi><switch-ceshi>Apr 2 2000 00:25:46 switch-ceshi DS/4/DATASYNC_CFGCHANGE:OID configurations have been changed. The current change number is 1, the change loop count is 0, and the maximum number of records is 4095.<switch-ceshi><switch-ceshi><switch-ceshi>sysEnter system view, return user view with Ctrl+Z.[switch-ceshi]inter vlan 100[switch-ceshi-Vlanif100]ip add 24[switch-ceshi-Vlanif100]Apr 2 2000 00:26:20 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[3]:The router ID is (InstanceID=0)Apr 2 2000 00:26:20 switch-ceshi %%01RM/4/ROUTERID_CHANGE(l)[4]:The router ID is (InstanceID=0)[switch-ceshi-Vlanif100][switch-ceshi-Vlanif100][switch-ceshi-Vlanif100]dis this#interface Vlanif100ip address[switch-ceshi]q<switch-ceshi>savThe current configuration (excluding the configurations of unregistered boards or cards) will be written to flash:/.Are you sure to continue[Y/N]yNow saving the current configuration to the slot 0..Apr 2 2000 00:26:24 switch-ceshi %%01CFM/4/SAVE(s)[5]:The user chose Y when deciding whether to save the configuration to the device...Save the configuration successfully.<switch-ceshi><switch-ceshi>Apr 2 2000 00:26:26 switch-ceshi DS/4/DATASYNC_CFGCHANGE:OID configurations have been changed. The current change number is 2, the change loop count is 0, and the maximum number of records is 4095.<switch-ceshi><switch-ceshi><switch-ceshi>pingPING 56 data bytes, press CTRL_C to breakRequest time outRequest time outRequest time outRequest time outRequest time out--- ping statistics ---5 packet(s) transmitted0 packet(s) received% packet loss<switch-ceshi>ping PING 56 data bytes, press CTRL_C to break Reply from bytes=56 Sequence=1 ttl=255 time=4 msReply from bytes=56 Sequence=2 ttl=255 time=1 msReply from bytes=56 Sequence=3 ttl=255 time=1 msReply from bytes=56 Sequence=4 ttl=255 time=1 msReply from bytes=56 Sequence=5 ttl=255 time=1 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 1/1/4 ms<switch-ceshi>pingPING 56 data bytes, press CTRL_C to breakReply from bytes=56 Sequence=1 ttl=64 time=4 msReply from bytes=56 Sequence=2 ttl=64 time=1 msReply from bytes=56 Sequence=3 ttl=64 time=1 msReply from bytes=56 Sequence=4 ttl=64 time=1 msReply from bytes=56 Sequence=5 ttl=64 time=1 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 1/1/4 ms<switch-ceshi>Apr 2 2000 00:30:55 switch-ceshi %%01IFPDT/4/IF_STATE(l)[6]:Interface GigabitEthernet0/0/4 has turned into UP state.<switch-ceshi><switch-ceshi>dis mac-ade^Error: Unrecognized command found at '^' position.<switch-ceshi>dis mac-add-------------------------------------------------------------------------------MAC Address VLAN/VSI Learned-From Type -------------------------------------------------------------------------------000c-296e-ed9a 100/- GE0/0/4 dynamic 04f9-3891-4805 100/- GE0/0/28 dynamic 0800-0699-4ae5 100/- GE0/0/28 dynamic 28d2-44c8-1c31 100/- GE0/0/28 dynamic a01d-48b7-59c8 100/- GE0/0/4 dynamic e0dc-a08b-d21d 100/- GE0/0/28 dynamic-------------------------------------------------------------------------------Total items displayed = 6<switch-ceshi>dis arpIP ADDRESS MAC ADDRESS EXPIRE(M) TYPE INTERFACE VPN-INSTANCE VLAN------------------------------------------------------------------------------ c4ff-1f4c-1c30 I - Vlanif10004f9-3891-4805 16 D-0 GE0/0/2810028d2-44c8-1c31 17 D-0 GE0/0/28100------------------------------------------------------------------------------Total:3 Dynamic:2 Static:0 Interface:1<switch-ceshi>ping Unknown hostPING 56 data bytes, press CTRL_C to breakReply from bytes=56 Sequence=1 ttl=64 time=1 msReply from bytes=56 Sequence=2 ttl=64 time=1 msReply from bytes=56 Sequence=3 ttl=64 time=1 msReply from bytes=56 Sequence=4 ttl=64 time=1 msReply from bytes=56 Sequence=5 ttl=64 time=1 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 1/1/1 ms<switch-ceshi>pingPING 56 data bytes, press CTRL_C to breakReply from bytes=56 Sequence=1 ttl=30 time=3 msReply from bytes=56 Sequence=2 ttl=30 time=1 msReply from bytes=56 Sequence=3 ttl=30 time=1 msReply from bytes=56 Sequence=4 ttl=30 time=3 msReply from bytes=56 Sequence=5 ttl=30 time=1 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 1/1/3 ms<switch-ceshi>ping PING 56 data bytes, press CTRL_C to breakReply from bytes=56 Sequence=1 ttl=30 time=3 msReply from bytes=56 Sequence=2 ttl=30 time=3 msReply from bytes=56 Sequence=3 ttl=30 time=2 msReply from bytes=56 Sequence=4 ttl=30 time=2 msReply from bytes=56 Sequence=5 ttl=30 time=2 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 2/2/3 ms<switch-ceshi>Apr 2 2000 00:37:43 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[7]:Interface GigabitEthernet0/0/4 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, : No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, : No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No))Apr 2 2000 00:37:43 switch-ceshi %%01IFPDT/4/IF_STATE(l)[8]:Interface GigabitEthernet0/0/4 has turned into DOWN state.<switch-ceshi>Apr 2 2000 00:38:19 switch-ceshi %%01IFPDT/4/IF_STATE(l)[9]:Interface GigabitEthernet0/0/6 has turned into UP state.<switch-ceshi>Apr 2 2000 00:38:49 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[10]:Interface GigabitEthernet0/0/6 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, : No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, : No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No))Apr 2 2000 00:38:49 switch-ceshi %%01IFPDT/4/IF_STATE(l)[11]:Interface GigabitEthernet0/0/6 has turned into DOWN state.<switch-ceshi>Apr 2 2000 00:39:14 switch-ceshi %%01IFPDT/4/IF_STATE(l)[12]:Interface GigabitEthernet0/0/6 has turned into UP state.<switch-ceshi>Apr 2 2000 00:39:28 switch-ceshi %%01IFADP/4/PORTDOWNINFO(l)[13]:Interface GigabitEthernet0/0/6 has turned into DOWN state. (Information=Physical state: DOWN, Negotiation: ENABLE, Negotiation complete: No, Local full-duplex(10M: Yes, 100M: Yes, 1000M: Yes, : No, 10G: No), Local half-duplex(10M: Yes, 100M: Yes, 1000M: No, : No, 10G: No), Remote full-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No), Remote half-duplex(10M: No, 100M: No, 1000M: No, : No, 10G: No))Apr 2 2000 00:39:28 switch-ceshi %%01IFPDT/4/IF_STATE(l)[14]:Interface GigabitEthernet0/0/6 has turned into DOWN state.<switch-ceshi><switch-ceshi><switch-ceshi>ping PING 56 data bytes, press CTRL_C to breakReply from bytes=56 Sequence=1 ttl=30 time=5 msReply from bytes=56 Sequence=2 ttl=30 time=2 msReply from bytes=56 Sequence=3 ttl=30 time=3 msReply from bytes=56 Sequence=4 ttl=30 time=2 msReply from bytes=56 Sequence=5 ttl=30 time=2 ms--- ping statistics ---5 packet(s) transmitted5 packet(s) received% packet lossround-trip min/avg/max = 2/2/5 ms<switch-ceshi>\^Error: Unrecognized command found at '^' position.<switch-ceshi><switch-ceshi>dis port vlan actT=TAG U=UNTAG-------------------------------------------------------------------------------Port Link Type PVID VLAN List-------------------------------------------------------------------------------GE0/0/1 access 100 U: 100GE0/0/2 access 100 U: 100GE0/0/3 access 100 U: 100GE0/0/4 access 100 U: 100GE0/0/5 access 100 U: 100GE0/0/6 access 100 U: 100GE0/0/7 access 100 U: 100GE0/0/8 access 100 U: 100 GE0/0/9 access 100 U: 100 GE0/0/10 access 100 U: 100 GE0/0/11 access 100 U: 100 GE0/0/12 access 100 U: 100 GE0/0/13 access 100 U: 100 GE0/0/14 access 100 U: 100 GE0/0/15 access 100 U: 100 GE0/0/16 access 100 U: 100 GE0/0/17 access 100 U: 100 GE0/0/18 access 100 U: 100 GE0/0/19 access 100 U: 100 GE0/0/20 access 100 U: 100 GE0/0/21 access 100 U: 100 GE0/0/22 access 100 U: 100 GE0/0/23 access 100 U: 100 GE0/0/24 trunk 1 T: 100 GE0/0/25 access 1 U: 1 GE0/0/26 access 1 U: 1 GE0/0/27 access 1 U: 1 GE0/0/28 trunk 1 T: 100 <switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi><switch-ceshi>dis mac-add-------------------------------------------------------------------------------MAC Address VLAN/VSI Learned-From Type -------------------------------------------------------------------------------04f9-3891-4805 100/- GE0/0/28 dynamic 0800-0699-4ae5 100/- GE0/0/28 dynamic e0dc-a08b-d21d 100/- GE0/0/28 dynamic-------------------------------------------------------------------------------Total items displayed = 3<switch-ceshi>dis arpIP ADDRESS MAC ADDRESS EXPIRE(M) TYPE INTERFACE VPN-INSTANCE VLAN------------------------------------------------------------------------------ c4ff-1f4c-1c30 I - Vlanif10004f9-3891-4805 20 D-0 GE0/0/2810028d2-44c8-1c31 6 D-0 GE0/0/281000800-0699-4ae5 10 D-0 GE0/0/28100e0dc-a08b-d21d 19 D-0 GE0/0/28100------------------------------------------------------------------------------Total:5 Dynamic:4 Static:0 Interface:1<switch-ceshi>Apr 2 2000 00:43:07 switch-ceshi %%01IFPDT/4/IF_STATE(l)[15]:Interface GigabitEthernet0/0/4 has turned into UP state.<switch-ceshi>>>User name:root>>User password:Huawei Integrated Access Software.Copyright(C) Huawei Technologies Co., Ltd. 2002-2012. All rights reserved.----------------------------------------------------------------------------- User last login information:----------------------------------------------------------------------------- Access Type : SerialIP-Address : --Login Time : 2019-10-27 14:04:15+08:00Logout Time : 2019-10-27 14:43:29+08:00----------------------------------------------------------------------------- ----------------------------------------------------------------------------- All user fail login information:----------------------------------------------------------------------------- Access Type IP-Address Time Login Times----------------------------------------------------------------------------- Serial -- 2019-10-27 14:04:11+08:00 2----------------------------------------------------------------------------- User root has used a default password. Change the password in time.MA5683T>enableMA5683T#configMA5683T(config)#undo interface vlanif 100---------------------------------------------Command of config Mode:---------------------------------------------<cr> Please press ENTER to execute commandMA5683T(config)#undo interface vlanif 100This operation may take several minutes, please wait...Operation of deleting vlanif is successfulMA5683T(config)#discurr^% Unknown command, the error locates at '^'MA5683T(config)#display current-configuration{ <cr>|ont<K>|port<K>|section<K>|service-port<K>|simple<K>||<K> }: Command:display current-configuration[MA5600V800R011: 5800]#[sysmode]<sysmode>switch adsl mode to rfc2662 vdsl mode to tr129xpon mode switch-to profile-modeprotocol support h248。
