®The Series RHP Humidity/Temperature Transmitters combine the voltage or current humidity transmitter output with a passive temperature thermistor or RTD output. The polymer capacitance humidity sensor reduces longterm affect of condensation, fog, or high humidity. The humidity sensors are available with 2%, 3% or 5% accuracies. Duct mounted transmitters are available with an optional two-line alpha numeric LCD display.• Reduced installation cost with combined humidity and temperature• Wide application environment from a large selection of temperature sensors and 2%, 3% and 5% accuracies • Reduced system operating costs with radiation shield protecting the sensor from radiant heat• Air economizers• Outdoor temperature and relative humidity reference for building systemsFEATURES/BENEFITSDESCRIPTIONAPPLICATIONSSERIES RHP | HUMIDITY/TEMPERATURE TRANSMITTERSOSA (outside air)OSA (outside air)with sintered filter OSA (outside air)with radiation shield Duct mountSPECIFICATIONSRelative Humidity Range 0 to 100% RH.Temperature Range -40 to 140°F (-40 to 60°C).Accuracy, RH RHP-2XXX ±2% 10-90% RH @ 25°C; RHP-3XXX ±3% 20-80% RH @ 25°C; RHP-5XXX ±5% 20-80% RH @25°C.Accuracy, Thermistor Temp Sensor ±0.2°C @ 25°C (±0.36°F @ 77°F).Accuracy, RTD Temp Sensor DIN Class B; ±0.3°C @ 0°C (±0.54°F @ 32°F).Accuracy, Solid State Band Gap ±0.9°F @ 77°F (±0.5°C @ 25°C).Hysteresis ±1%.Repeatability ±0.1% typical.Temperature Limits -40 to 140°F (-40 to 60°C).Storage Temperature -40 to 176°F (-40 to 80°C).Compensated Temperature Range -4 to 140°F (-20 to 60°C).Power Requirements 4-20 mA loop powered models: 10-35 VDC; 0-5/10 V output models: 15-35 VDC or 15-29 VAC.Output Signal (Model Dependent)4-20 mA; 0-5/10V @ 5 mA max.Response Time 15 s.Electrical Connections Removable screw terminal block.Conduit Connection Duct mount: 1/2˝ NPS; OSA: PG11 or PG16 (1/2˝ conduit) knockouts.Drift < 1% RH/year.RH Sensor Capacitance polymer.Temperature Sensor Types 1, 2, 3: Solid state band gap; Curves A, B, C: Thermistor; Curves D, E: Platinum RTD DIN 385.Enclosure Material Duct mount sensor tube: PVC-UL 94 V-0; Duct mount sensor cap: Polycarbonate ABS blend-greater than UL94 V-0; Duct mount electronics housing and cover: Makrolon ® polycarbonate-UL 94V-HB; OSA: Polycarbonate.Enclosure Rating Duct mount: NEMA 4X (IP66) for housing only; OSA: NEMA 4X (IP66).Display Duct mount only, optional 2-line alpha numeric, 8 characters/line.Display Resolution RH: 0.1%; 0.1°F (0.1°C).Weight Duct mount: .616 lb (.3 kg); OSA: 1 lb (.45 kg).Compliance CE.©Copyright 2022 Dwyer Instruments, LLC Printed in U.S.A. 3/22DS-RHP Rev. 7ORDER ONLINE TOD DWYER INSTRUMENTS, LLCImportant Notice: Dwyer Instruments, Inc. reserves the right to make changes to or discontinue any product or service identified in this publication without notice. Dwyer advises its customers to obtain the latest version of the relevant information to verify, before placing any orders, that the information being relied upon is current.ACCESSORIESModel DescriptionA-RHP-FC A-RHP-RTReplacement plastic hydrophobic filterRetrofit tool for fitting O-ring on RHP-D/M models for new filter A-RHP-FCHOW TO ORDERSERIESRHP: RH/passive temperature sensor transmitter ACCURACY -2: 2% accuracy -3: 3% accuracy -5: 5% accuracyHOUSING TYPED: Duct mount with plastic hydrophobic filter O: OSA (outside air)S: OSA with sintered filter*R: Radiation shield*Use OSA with sintered filter models when purchasing Series RHRS separately.OPTIONS-LCD: LCD display-NIST: NIST traceable calibration certificate TEMPERATURE SENSOR 0: None 1: 4-20 mA 2: 0-10 VDC 3: 0-5 VDCA: 10K @ 25°C thermistor type III B: 10K @ 25°C thermistor type II C: 3K @ 25°C thermistor D: 100 Ω RTD DIN 385E: 1K Ω RTD DIN 385F: 20K Ω @ 25°C thermistor RH OUTPUT 1: 4-20 mA 2: 0-10 V 3: 0-5 VDCRHP-2D1Use the bold characters from the chart below to construct a product code.-LCDADIMENSIONS6-25/32[172.09]5-1/8[130.18]4-17/32[115.09]2-15/64[56.75]3-1/8[79.38]4-17/32[115.09]Ø3/16[4.76]MOUNTING HOLES TYP 4 PLCS3-1/8[79.38]1-13/64[30.56][21.83]Duct mountOSA (outside air)OSA (outside air) with sintered filter2-1/4[57.15][21.83]6-25/32[172.16]3-45/64[94.06]2-41/645-1/8[130.18]1/2 NPT2-11/64[55.17]8-61/64[227.30]2-41/64 [67.03]2-9/64[54.37]3-11/64[80.57]35/64[13.89]2-9/16[64.96]2-11/64 [55.12][3] 3/16 [4.76] HOLES EQUALLY SPACED ON A 4.115 [104.52] BCA-RHP-FCMakrolon ® is a registered trademark of Covestro AG.。
Page 1/4Fax:+49 661 6003-607e-mail:Internet: Fax:+44 1279 635262e-mail:Internet: Fax:315-697-5867e-mail:Internet:Screw-in RTD temperature probewith terminal head form J■For temperatures from -50 to +400°C■As single or double RTD temperature probes ■Available with transmitter ■Protection class IP65Screw-in RTD temperature probes are preferentially used for measuring temperatures in liquids and gases. A decisive selection criterion is the reliable sealing feature of this installation type with vacuum and with overpressure. The application areas are, among others, in the air conditioning technology and refrigeration engineering as well as the HVAC, kiln and apparatus engineering sector.The measuring insert is normally fitted with a Pt100 temperature sensor according to DIN EN 60751, Class B in 2-wire circuit; versions with Pt500 or Pt1000 temperature sensors can also be supplied, as well as 3- and 4-wire circuit connections. A transmitter can be optionally integrated into the connection head.Technical DataTerminal headForm J, die-cast aluminum, M 16x1.5; IP65, ambient temperature -40 to +100°C Caution: reduced ambient temperature range when using transmitters,Data Sheet 70.7030Process connection thread, stainless steel 1.4571Protection tube Stainless steel 1.4571, Ø6mm and Ø8mmMeasuring insert Pt100 temperature sensor according to DIN EN 60751, Class B, two-wire circuit Response times t 0.5 = 5 sec, t 0.9 = 14 sec, in water 0.4m/sec, 6mm dia.Transmitter Analog transmitter, output 4 to 20mA, Data sheet 70.7030AccessoriesSheath, Data Sheet 90.9710 (90.9721)Page 2/4Fax:+49 661 6003-607e-mail:*************Internet: Fax:+44 1279 635262e-mail:*************.uk Internet: Fax:315-697-5867e-mail:************Internet:DimensionsType 902030/10Type 902030/11Type 902030/31Type 902030/80Page 3/4Fax:+49 661 6003-607e-mail:*************Internet: Fax:+44 1279 635262e-mail:*************.uk Internet: Fax:315-697-5867e-mail:************Internet:Order details:Screw-in RTD temperature probe with terminal head form J(1)Basic type902030/10Screw-in RTD temperature probes with continuous sheath902030/11Screw-in RTD temperature probes with stepped sheath(with Ø6 to Ø3.8mm; with Ø8 to Ø6mm)902030/31Screw-in RTD temperature probes with stepped sheath for air measurement902030/80Screw-in RTD temperature probes with spring-loaded connection,12mm spring deflection,connection head rotatable by 360°(2)Operating temperature in °Cx x647-20 to +150°C (only in conjunction with class B and 1x Pt100/1x Pt1000 in 2-wire circuit)x378-50 to +180°C x x x380-50 to +200°C x x 386-50 to +260°C x x 402-50 to +400°C (3)Measuring insertx x x x 10011x Pt100 in 3-wire-circuit x x x x 10031x Pt100 in 2-wire circuit x x x x 10051x Pt1000 in 2-wire circuit x x x x 10111x Pt100 in 4-wire circuit x x x x20032x Pt100 in 2-wire circuit(4)Tolerance class according to EN 60751x x x x 1Class B (standard)x x x x 2Class A(5)Protection tube diameter D in mm x x x 6Ø6mm (standard)x x 8Ø8mm (6)Fitting length EL in mm (100≤EL ≤1000)x x 5050mm x x x x 100100mm x x x x 150150mm x x x x 250250mm x x x x 300300mmxx xx...Specification in plain text (50mm steps)(7)Process connection x x x 102Screw connection (thread) G 1/4x x x 103Screw connection (thread) G 3/8x x x x 104Screw connection (thread) G 1/2(8)Extra codesx x x x 000without extra codesx x x x3301x analog transmitter, 4 to 20mA 1 output, Data sheet 70.7030(1)(2)(3)(4)(5)(6)(7)(8)Order code ------/Order example902030/10-402-1001-1-6-100-104/0001Specify measuring range in plain text.Page 4/4Fax:+49 661 6003-607e-mail:*************Internet: Fax:+44 1279 635262e-mail:*************.uk Internet: Fax:315-697-5867e-mail:************Internet:Stock versions(1)(2)(3)(4)(5)(6)(7)(8)Part No.902030/10-380-2003-1-6-50-104/00090/00533450902030/10-380-2003-1-6-100-104/00090/00533451902030/10-380-2003-1-6-150-104/00090/00533452902030/10-402-1003-1-6-50-104/00090/00055692902030/10-402-1003-1-6-100-104/00090/00055693902030/10-402-1003-1-6-150-104/00090/00055694902030/10-402-1003-1-6-300-104/00090/00065691902030/10-402-1003-1-6-250-104/00090/00533433902030/10-402-2003-1-6-50-104/00090/00383011902030/10-402-2003-1-6-100-104/00090/00526429902030/10-402-2003-1-6-150-104/00090/00533442902030/10-402-1003-1-6-50-103/00090/00478984902030/10-402-1003-1-6-100-103/00090/00424045902030/10-380-1003-1-6-100-104/330(-40 to +60°C)90/00533453902030/10-647-1003-1-6-100-104/330(0 to 100°C)90/00533454902030/10-647-1003-1-6-150-104/330(0 to 100°C)90/00533468902030/10-402-1005-1-6-100-104/00090/00359611902030/10-402-1005-1-6-150-104/00090/00411610902030/10-647-1003-1-6-50-104/00090/00533448902030/10-647-1003-1-6-100-104/00090/00533449902030/10-647-1003-1-6-150-104/00090/00508957902030/31-380-1003-1-6-75-104/00090/00438406902030/31-380-1003-1-6-100-104/00090/00438408902030/31-380-1003-1-6-150-104/00090/00438409。
