特耐凯纷说明书解读35页PPT

PartekPFA/PTFE Products Quick Reference GuideBulletin 4180-QRG/USARevised, May 2005Fluoropolymer Tubing ProductsFluoropolymer tubing products are offered through Atlantic Tubing Operation (A TO). A TO manufactures high quality fluoropolymer tubing that may be used in conjunction with Partek’s PFA/PTFE products. A wide range of products are available in PTFE, FEP, PFA, High Purity PFA, and PVDF. Other materials are available on request. All tubing and pipeare made from 100% virgin resins.Chemical Properties Electrical Properties Mechanical Properties• Resistivity to corrosive agents • Low dielectric constant • Flexibility at low temperatures• Non-solubility • Low dissipation factor • Low coefficient of friction• Long term weatherability • High arc resistance • Stability at high temperatures• Non-adhesiveness • High surface resistance• Nonflammability • High volume resistivityFluid Handling Tubing and PipeHigh Purity T ubingRetractable Coils & Formed ShapesFractional Industrial & Heavy Wall T ubingConvoluted T ubingDual Containment T ubingStriped T ubingWelding & Standard RodT ubing for Air & Water SamplingSchedule 40 & 80 PipeMetric SizesElectrical Insulation TubingSpiral Cut Cable Wrap Convoluted Tubing Heat Shrink TubingProvides harnessing for wires and Allows for insulation of wire bundles “Shrink to Fit” covers for wires, cable while allowing for leads at where sharp bends are required. cables and other components various points. Offered in both Available with cuffed ends to provide where electrical, abrasion orleft and right hand cuts. sealed environment. chemical resistance is required. Round Beading/Miniature Rod (Not Shown)Excellent as a filler in loose bundles of cables, as a pull cord, or cut into pieces as bearings. The smoother finish, greater flexibility, and longer lengths outperform “granular” extrusions. AWG Spaghetti Size Tubing (Not Shown)Provides “Slip On” protection against extreme electrical or chemical exposure or applications where abrasion resistance is critical.Additionally, it has higher mechanical strength at elevated temperatures (to 500° F ).Custom SpecificationsSpecial orders and custom configuration of standard products are available. All Partek products are cleaned, assembled, tested and bagged in a clean room environment.OverviewPartek serves global markets with a broad range of high-quality flow control products, which include Parflare PFA Tube Fittings, Pargrip PFA T ube Fittings, Parbond PFA Fusible Pipe Fittings, PFA Pipe Fittings, PFA Valves, PTFE Valves, PTFE Pressure Regulators, PTFE Flow Meters, PFA Gauge Protectors, PFA Spray Guns, and PTFE Vacuum Generators. Fluoropolymer tubing and pipe are manufactured and offered at the Atlantic T ubing Operation in Chestnut Ridge, New Y ork.This PFA/PTFE Product Digest is offered as a handy reference guide and overview of Partek products. For more information on PFA/PTFE products contact Partek Operation, the Atlantic T ubing Operation, the Parker Information Center toll-free 1-800-C-Parker (1-800-272-7537) or your local distributor.Partek PFA /PTFE ProductsGeneral Product InformationParker Hannifin's Partek Operation facilities manufacture flow control products for use in fluid systems where corro-sion protection is required or where media purity must be safeguarded. The wetted surfaces of all products are of chemically inert, corrosion-resistant PFA, or PTFE.External materials used are anodized aluminum, polyethyl-ene (HDPE), polyvinylchloride (PVC), polyvinylidene fluoride (PVDF), or perfluoroalkoxy (PFA). ABS plastic knobs are used in some products.Durable, leak-free Partek products are used in a variety of applications including semiconductor manufacturing; chemical, food, and pharmaceutical processing; and biomedical and analytical instrumentation.Material PropertiesPTFE fluorocarbon resins, among the most versatile of all plastics, are rapidly becoming the material of choice for applications involving corrosion resistance. The strong interatomic bonds between carbon and fluorine atoms, and the almost perfect shielding of the polymer's carbon backbone by fluorine atoms make the material inert to most industrial chemicals and solvents.PFA, a close relation, has properties rivaling those of PTFE. Its excellent melt-processability permits conventionalthermoplastic molding and high-speed extrusion processing.End Connections (PFA Products )Male Pipe EndFemale Pipe EndPargrip Tube (Ferrule/Gripper)ConnectionParflare Tube ConnectionEnd Connections (PTFE Products )Partek Parflare PFATube FittingsProvides low dead volume, which decrease the possibility of particle entrapment and bacteria growth.Partek Pargrip PFA Tube FittingsPerfect for applications where ease of assembly is a requisite.Partek PFA Pipe FittingsAvailable in a variety of configurations, all with standard NPT threads.Partek Parbond PFA Fusible Pipe FittingsThe leak-free design eliminates threaded connections.Field proven and high cycle life.Parker Hannifin Corporation Partek Operation7075 E. Southpoint Rd. Tucson, AZ 85706 (520) 574-2600 (520) 574-2700 Fax© Copyright 2003, 2005, Parker Hannifin Corporation. All Rights ReservedParker Hannifin Corporation Parflex Division/Atlantic Tubing 1300 N. Freedom Street Ravenn , OH 44266 (330) 296-2871 (330) 296-8433 FaxISO 9001:2000 Certified FacilityBulletin 4180-QRG, 10M, 05/05。

OWNERS / OPERATORS MANUALforNacho ChipwarmersModels: CW-1, CW-2 and CW-4Part Number: 18400-3051bPrinted in The United States of AmericaRev: 071708JJOTABLE OF CONTENTSSAFETYPRECAUTIONS.............................................. 2 FEATURES & SPECIFICATIONS................................... 3 UNPACKING AND INSPECTION................................... 4 INSTALLATION ......................................................... 5 STARTUP................................................................. 6 NORMAL OPERATION................................................. 6 THERMOSTAT AND THERMOMETER CALIBRATION....... 7 DIGITAL CONTROL PROGRAMMING............................ 8-9 REGULAR CLEANING PROCEDURES........................... 10 MONTHLY CLEANING PROCEDURES (11)WIRING DIAGRAMS…………………………………………… 12-13TROUBLESHOOTING GUIDE ...................................... 14 WARRANTY STATEMENT. (15)MANUFACTURED BY:CARTER-HOFFMANN 1551 McCormick Avenue Mundelein, IL 60060 U.S.A.Phone: 847-362-5500 Fax: 847-367-8981 Toll Free: 800-323-9793Email:***************************CW-1CW-2 CW-4Since 1947, Equipment That Delivers!3FEATURES & SPECIFICATIONSModelNumberChip CapacityCubic feet GallonsOverall DimensionsHeight * Depth Widthin (mm)Legsin (mm)Class 100ShippingWeightlbs (kg)CW1 2.75 20 27-1/4 25-1/2 28-3/8(692) (648) (721)4(102)135(61)CW2 3.00 22 38-3/4 23 22-3/4(984) (584) (578)4(102)154(69)CW4 5.75 44 45-1/2 28 29-5/8(1156) (711) (752)4(102)245(111) Features & Benefits• Gentle, even heating—our exclusive heat duct and baffle system forces air down rear wall duct and up through the chips. No hot or cold spots - and no burned chips!• Top-mounted heating system — all components easily accessible for service and located away from chip dust, crumbs and oils.• Serving door flips down for a handy shelf to set baskets while serving.• Factory pre-set temperature of 180°F (79°C). Adjustable thermostat.• Pull-out crumb pan for easy cleaning.*Height includes 4” for legs. Ordering optional casters (CW1), or rolling stands (CW2, CW4) will alter height.220 or 240 volt operation2” casters (CW1 only)Rolling standClear polycarbonate doorsCW1 CW2 & CW4NOTE:Heating system should cycle at least two times after the last adjustment to achieve accurate calibration.to increase turn set screw counter clockwiseto decrease turn set screw clockwiseSet screwwithout the decal so button positions need to be noted for program-To View or Change the Temperature set point:NORMAL OPERATIONPROGRAMMING INSTRUCTIONS:FOR UNITS WITH DIGITAL CONTROLSChanging the Temperature Range:The temperature range is the range that the cabinet is designed to op-erate within. With the cabinet power off, press and hold the UP and DOWN arrow buttons. While still holding in the arrow buttons, turn back on the power to the cabinet. The display will read: Ser F and then F (if temperature scale is set to F) will display .To change the range, press and release the TEMP SET button. The display will read: rLo and then the current low temperature range set point. To change the temperature, press the UP or DOWN arrows until the desired temperature is displayed. The low setting should be set to 140°F .Press the TEMP SET button again. The display will read Rhi . and then the current high temperature range set point. To change the tem-perature, press the UP or DOWN arrows button until the desired tem-perature is displayed. The high setting should be set to 200°F. Turn off the power to the cabinet to save the changes in the controller memory.Changing the Alarm Range:The alarm range is the range that the low temperature alarm is de-signed to operated under. The alarm range should be programmed for 140°F Maximum and 65°F Minimum. The cabinet low tempera-ture alarm can be programmed to operate within these two set points.With the cabinet power off, press and hold the UP and DOWN arrow buttons. While still holding in the arrow buttons, turn back on the power to the cabinet. The display will read: Ser F and then F will dis-play. (if temperature scale is set to F) To change the range, press and release the ALARM RESET button. The display will read ALo and then the current low alarm temperature set point. To change the low alarm temperature, press the UP or DOWN arrows until the desired temperature is displayed. The low setting should be set to 65°F .Press the ALARM RESET button again. The display will read AHi and then the current high alarm temperature set point. To change the high alarm temperature, press the UP or DOWN arrows until the desired temperature is displayed. The high setting should be set to 140°F. Turn off the power to the cabinet to save the changes in the controller mem-ory.Default values-temp setpoint =180F-operating range=140-200F -low temp alarm = 140F --temp scale = FDown arrowUp arrowAlarm setTemp set 165DIGITAL CONTROLTROUBLESHOOTING GUIDESYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY No power to unit Not plugged in or circuit breaker tripped Check or reset circuit breakerConnect to proper receptaclePower cord damaged Check - replace if requiredPower switch damaged or defective Check - replace if requiredProduct dries out too quickly Operation where product temp is too high Check product temps going into holdingcabinetThermostat incorrectly set or defective Check proper operation or calibration ofthermostatInternal wiring error Call service technicianElement hi-limit trip / defective Call service technicianTakes too long to get to temperature Improper voltage Call service technician to verify in-coming voltage matches cabinet specifi-cations.Unit is hotbut low or no airflow Internal wiring error Call service technicianCirculation motor has quit Call service technicianImproper voltage Call service technician to verify in-coming voltage matches cabinet specifi-cations.Unit is on, motors are running but no heatNOTE:The technical content of this manual, including any wiring diagrams, schemat-ics, parts breakdown illustrations and / or adjustment procedures, is intended for use ONLY by qualified technical personnel.NOTE:For warranty service, call Carter-Hoffmann direct at 800-323-9793 for authorization,we will dispatch the nearest authorizedservice agency.14。
