drill

专利名称：Drill发明人：Mori, Yoshikatsu,Dohi, Yoshio,Fukagawa,Hideo申请号：EP84104937.2申请日：19840502公开号：EP0127009A1公开日：19841205专利内容由知识产权出版社提供专利附图：摘要：A drill made of cemented carbide. To compensate for the brittleness ofcemented carbide to increase its cross-break strength, the ratio of the diameter (c) of the web portion (1) to the drill diameter (d) is set in the range of 25% to 35%, and the flutewidth ratio (b : a) is set in the range of 0.4 : 1 to 0.8 : 1. Further, to decrease the cutting resistance on the drill, the radial rake (o,) angel of the cutting lip (4) measured at positions spaced at least 213 of the drill diameter toward the outer peripheral side is set in the range of -5° to positive. Furthermore, to promote the chip ejecting function, the relative distance (L) between the cutting lip (4) and the flute wall (5) opposed thereto is decreased.申请人：SUMITOMO ELECTRIC INDUSTRIES LIMITED地址：No. 15, Kitahama 5-chome, Higashi-ku Osaka-shi, Osaka 541 JP国籍：JP代理机构：Patentanwälte Kirschner & Grosse更多信息请下载全文后查看。

专利名称：Drill发明人：Grossmann, Günter,Iwata, Yoshikazu申请号：EP93114727.6申请日：19930914公开号：EP0589333A1公开日：19940330专利内容由知识产权出版社提供专利附图：摘要：A drill includes a substantially cylindrical bit body 10 having an axis O. The bit body 10 has a flange portion 13 which includes a converging portion 13a which reduces its diameter progressively towards the front end of the bit body and a flange 13b which is provided with a rearwardly facing annular surface 13c. The annular end surface iscontactable with the front end surface of a drill holding portion of a machine too. Chip discharging flutes 14A,14B, each having an inner surface constituted by first and second inner surface portions 14a,14b and a third inner surface portion 14c arcuately recessed therefrom, are formed in the front end portion of the tip body 10. An inner peripheral cutting insert 16A and an outer peripheral cutting insert 16B are mounted on the ends of the chip-discharging flutes 14A,14B. The cross-sectional area SA of the first-mentioned chip-discharging flute 14A is determined to be greater than that SB of the second-mentioned chip-discharging flute 14B. A plurality of grooves 25 are formed in the third inner surface portion 14c so as to extend along each chip-discharging flute.申请人：MITSUBISHI MATERIALS CORPORATION地址：6-1, Ohtemachi 1-chome Chiyoda-ku, Tokyo 100 JP国籍：JP代理机构：Türk, Gille, Hrabal, Leifert更多信息请下载全文后查看。

专利名称：DRILL发明人：NAKAMURA TERUHIRO 申请号：JP19683485申请日：19850905公开号：JPS6257807A公开日：19870313专利内容由知识产权出版社提供摘要：PURPOSE:To improve straightness and out of roundness of a drilled hole, by forming the successively provided part of a microdrill, so that its diameter continuously increases from the diameter of an edge part to the diameter of a shank part, and reducing stress concentration and eccentricity of the drill so as to prevent its damage and flection. CONSTITUTION:A drill 2 in a diameter of 0.2mm or less provides between its edge part 11 and shank part 12 a successively connecting part (tapered part) 21 with a uniform rate of increasing its external diameter. And a curved surface part 22, smoothly connecting its peripheral surface, is formed between the successively connecting part 21 and the edge part 11. Accordingly, the drill, decreasing a section change rate to a small value, prevents stress concentration from being easily generated while easily obtains the concentricity in a manufacturing process. Consequently, the drill can reduce its damage and flection simultaneously improve straightness and out of roundness of a drilled hole.申请人：MITSUBISHI METAL CORP更多信息请下载全文后查看。

drill的用法和短语例句drill有练习;钻孔;(军事)训练等意思，那么你知道drill的用法吗?下面为大家带来有关drill的用法和短语例句，供大家参考学习!drill的用法：drill的用法1：drill用作名词的基本意思是“钻头,钻床”,指的是一种用来钻孔的工具或机器,是可数名词。

drill的用法2：drill还可作“操练,训练”解,在表示具体的“操练”时,用作可数名词。

反复多次的“操练”可用复数形式; 在表示抽象意义的“操练”时,多用作不可数名词。

drill的用法3drill引申还可作“规定程序; 正确方法; 常规”解,主要用于英式英语中。

drill的用法4：drill可作“钻孔”解,指用装有尖锐旋转工具的器械在坚硬的物质上钻孔,此时既可用作及物动词也可用作不及物动词。

drill的用法5：drill常用的意思是“操练,训练”,指严格地、反复地、系统地训练、操练等,有时特指军事操练,即“训练士兵的一系列动作”或“按照拟订模式重复练习某一学习内容”,强调养成某种身体上的或思想上的习惯,就像用钻钻得很深一样。

drill的用法6：drill作“操作”“训练”解时可用作不及物动词,也可用作及物动词,可接名词或代词作宾语,其宾语用来表示训练的对象,而训练的内容有时用介词in引出。

drill的用法7：drill常用于被动结构。

drill的常用短语：用作动词(v.)drill down (v.+adv.)drill in1 (v.+adv.)drill in2 (v.+prep.)drill into (v.+prep.)drill的用法例句：1. A plug had been inserted in the drill hole.钻孔已塞上了塞子。

2. The drill should be slowly rotated to ensure a clean hole.钻头必须缓慢转动，以保证钻孔平整光滑。

专利名称：DRILL发明人：HOSOI TOSHIAKI 申请号：JP1563187申请日：19870126公开号：JPS63185507A 公开日：19880801专利内容由知识产权出版社提供摘要：PURPOSE:To prevent rotating resistance from increasing and to prevent a marginal section from being damaged, by forming outer peripheral cutting edges extending in a substantially axial direction from the outer peripheral ends of a pair of tip end cutting edges, and by setting the diameter of a circular locus depicted by the cutting edges to be greater than the outer diameter of the shank of the drill. CONSTITUTION:Tip end cutting edges 3 cut the bottom surface of a drilled hole, and simultaneously, outer peripheral cutting edges 20 cut the inner wall 100 of the drilled hole. Further, during the above-mentioned drilling, even though heat generation due to the cutting causes the forward end of the drill to expand, the outer peripheral cutting edges 20 cuts into the inner wall 100 of the drilled hole only by a degree corresponding to the expansion. Thus, during deep drilling, no rotating resistance is increased so that the drill may hold a satisfactory cutting performance for a long period, thereby it is possible to increase the life of the drill.申请人：HOSOI TOSHIAKI更多信息请下载全文后查看。

专利名称：DRILL发明人：HOSONO HIDEJI 申请号：JP5340086申请日：19860311公开号：JPS62208808A 公开日：19870914专利内容由知识产权出版社提供摘要：PURPOSE:To keep the after end periphery of a drill off the internal wall of a hole in drilling in a bent state and prevent an accident such as a drill fracture by taking the diameter of a cutter rotary locus at 'D' and setting the diameter of a portion aft of a range of 0.2-2D from a cutter peripheral edge at 0.92-0.98D. CONSTITUTION:When the diameter of a cutter 6 is taken at 'D' in the rotary locus formed on the tip flank 5 of a drill body 4, diameter D1 aft of a range of 0.2-2D from the peripheral edge of the cutter 6 toward the aft side thereof is taken at 0.92-0.98D. When drilling work is carried out with the whole drill in a bent state, the aft end periphery thereof does not come in contact with the internal wall of a hole and an accident such as a drill fracture can be prevented in a drilling process with a workpiece under rotation. Also, as the whole drill is liable to be flexible, the centripetal effect of the drill becomes easy to appear in drilling and furthermore deep hole drilling can be made with out any loss of guiding quality.申请人：MITSUBISHI METAL CORP更多信息请下载全文后查看。

drill的过去式和用法例句drill的过去式和其他时态：过去式: drilled过去分词: drilled 过现在分词: drillingdrill的用法：drill的用法1：drill可作“钻孔”解,指用装有尖锐旋转工具的器械在坚硬的物质上钻孔,此时既可用作及物动词也可用作不及物动词。

drill的用法2：drill常用的意思是“操练,训练”,指严格地、反复地、系统地训练、操练等,有时特指军事操练,即“训练士兵的一系列动作”或“按照拟订模式重复练习某一学习内容”,强调养成某种身体上的或思想上的习惯,就像用钻钻得很深一样。

drill的用法3：drill作“操作”“训练”解时可用作不及物动词,也可用作及物动词,可接名词或代词作宾语,其宾语用来表示训练的对象,而训练的内容有时用介词in引出。

drill的用法4：drill常用于被动结构。

drill的过去式例句：1. of 27 new wells drilled, 16 have proved exploitable.在新钻成的27口井中，已经有16口证明有开发价值。

2. they drilled through several layers of rock to reach他们钻透了几层岩石寻找石油。

3. we had multiplication tables drilled into us at school.以前我们上学得反复背诵乘法表.4. the recruits drilled regularly.新兵们定时操练.5. the dentist drilled my tooth.牙医在我的牙齿上钻孔.6. the pain is often likened to being drilled through the side of the head.这种疼痛常被比作钻头钻入头部的感觉。

7. i simply don't believe that spoken skills can be drilled into learners in a language laboratory.我简直不相信在语言实验室里能够把说话的技能传授给学生.8. he drilled into the wall of lili's bedroom.他在莉莉卧室的墙上钻了个孔。

专利名称：Drill发明人：Yanagida, Kazuya, Mitsubishi MaterialsCorp.,Takiguchi, Syoji, Mitsubishi MaterialsCorp.,Suzuki, Katsuyuki, Mitsubishi MaterialsCorp.,Inoue, Takeshi, Mitsubishi MaterialsCorp.申请号：EP02006673.4申请日：20020326公开号：EP1275458A1公开日：20030115专利内容由知识产权出版社提供专利附图：摘要：The present invention provides a drill comprising: a drill main body (1) rotatable about an axis of rotation (O), and having a tip end with a tip flank (2) and a shank; a chip discharge flute (3) formed on a periphery of the drill main body (1), and extending from the tip end toward the shank ofthe drill main body (1); and a cutting edge (5) formed along an intersecting ridge where a wall surface (4) of the chip discharge flute facing in the direction of drill rotation (T) intersects the tip flank (2) of the drill main body (1), wherein the cutting edge (5) comprises a convex cutting edge (16) toward the periphery and a concave cutting edge (17) smoothly extending from the convex cutting edge (16). When drilling work is performed with this drill, the chips are generally curled and can be smoothly discharged without being excessively abutted against the wall surface (4, 9) of the chip discharge flute (3); consequently, the chips can be smoothly discharged, and the drill main body (1) is subjected to less frictional resistance, which leads to less wear on the drill and less driving torque for drilling. Therefore, the drill life can be preferably extended even under severe drilling conditions, such as during high speed drilling, and smooth and stable drilling can be performed.申请人：MITSUBISHI MATERIALS CORPORATION地址：5-1, Otemachi 1-chome Chiyoda-ku, Tokyo JP国籍：JP代理机构：HOFFMANN - EITLE更多信息请下载全文后查看。

专利名称：DRILL发明人：KUME KENJI,HATTORI TATSUO,ASHINO YOSHIHARU,HAYASETATSUHIKO,MATSUMOTO KATSUNORI 申请号：JP7519687申请日：19870328公开号：JPS63245312A公开日：19881012专利内容由知识产权出版社提供摘要：PURPOSE:To prevent the occurrence of an exit burr at the passing through edge of a hole, improve the life of a cutting edge and make regrinding possible by forming the drill by specifying a point angle formed by the two cutting edges and brazing a superhigh pressure sintered body on the flank of the cutting edge. CONSTITUTION:A point angle formed by two cutting edges 35 at the tip of a tool body 33 is formed in an angle from 35 deg. to 40 deg., and a drill flank is formed of a superhigh pressure sintered body made of diamond from a chisel part at a tool tip to an end on the outer peripheral side of the tool and to the depth of about 0.7mm from a flank surface, and the above-mentioned superhigh pressure sintered body is fixed on the tool body 33 by brazing. Thus, in this drill 31, the point angle restricted as mentioned above can prevent the occurrence of an exit burr at the passing through edge of hole, and the superhigh pressure sintered body formed on the flank surface can improve the life of the cutting edge 35, and moreover its formation extending over the whole flank surface and having the above-prescribed depth can simplify drill regrinding work, and apply the cutting edge again to a machining process.申请人：MITSUBISHI METAL CORP,MITSUBISHI HEAVY IND LTD 更多信息请下载全文后查看。

专利名称：DRILL发明人：SUZUKI HIROMI 申请号：JP5847382申请日：19820408公开号：JPS58177214A 公开日：19831017专利内容由知识产权出版社提供摘要：PURPOSE:To provide a drill which can be fed at its tip with sufficient cutting oil when it is used for deep hole drilling and as well which is simple in manufacturing. CONSTITUTION:A drill comprises a body 2 formed with chip discharge grooves 10 and a shank 10 provided in the base end side of the body. A liquid guide groove 28 is formed in the auxiliary flank 20 of the body 2, extending from the base end of the body 2 to the tip of the drill substantially in parallel with the chip discharge grooves 10. Cutting oil may be fed to the drill tip easily without hindrance by chips since it is led through the exclusive liquid guide groove formed independently from the chip guide grooves 10. The liquid guide groove 28 may be easily formed in the auxiliary flank since the latter is the outer surface of a land 12.申请人：FUJI SEIKOU KK,YAMAHA HATSUDOKI KK更多信息请下载全文后查看。
