la u n a ms 'r e n w o THE SINGER'S ULTIMATE CHOICEUHF-5805Features:• 4 mic outputs• 4 rechargeable wireless handheld mics included • 2 dual microphone chargers• Individual Volume controls for precise vocal bala • Individual Volume controls for precise vocal balancing • 4 independent field-replaceable Modules• Rugged 1 RU metal receiver chassis • Dimensions 19” (W) x 8.2” (D) x 1.8” (H)4-Channel Rechargeable Wireless Microphone System• Interference-resistant UHF Band operation from 614 MHZ - 649 MHzTable of contentsSafety instructions (2)FCC information (3)Welcome (4)Listening for a lifetime (5)Specifications (6)Microphone basics (7)Before getting started (8)Mounting (9)Getting connected (10)Maintenance procedures (11)Charging the Microphones (12)Front and rear panel descriptions and functions (13)UHF-5805 & stage monitor/P.A. loudspeakers (14)Operations (14)Troubleshooting (15)��������������������CAUTION: To reduce the risk of electric shock, do not remove cover (or back). Nouser-serviceable parts inside. Only refer servicing to qualified service personnel.�������To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture.��������������������������������The lightning flash & arrowheadsymbol, within an equilateral triangle, is intended to alert you to the presence of danger.The exclamation point within anequilateral triangle is intended to alert you to the presence of importantoperating and servicing instructions.�������������������� - All the safety and operating instructions should be read before the appliance is operated.���������������������� - The safety and operating instructions should be retained for future reference.���������������� - All warnings on the appliance and in the operating instructions should be adhered to.���������������������� - All operating and use instructions should be followed.�������������� - Do not use attachments notrecommended by the product manufacturer as they may cause hazards.��������������������� - Do not use this unit near water. For example, near a bathtub or in a wet basement and the like.������������������� - The appliance should be used only with a cart or stand that is recommended by the manufacturer.���� An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause an overturn.�������������� - The appliance should be situated so its location does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation slots.������� - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.����������������� - The appliance should beconnected to a power supply only of the type described in the operating instructions or as marked on the appliance.����������������������������� - Precautions should be taken so that the grounding or polarization means of an appliance is not defeated.������������������������� - Power-supply cordsshould be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs,convenience receptacles, and the point where they exit from the appliance.������������ - Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.��������������� - An outdoor antenna should be located away from power lines.������������������ - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.��������������������������� - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.���������������������������� - The appliance should be serviced by qualified service personnel when:A. The power supply cord or plug has been damaged; or B. Objects have fallen into the appliance; or C. The appliance has been exposed to rain; orD. The appliance does not appear to operate normally or exhibits a marked change in performance; orE. The appliance has been dropped, or the enclosure damaged.������������� - The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.������To CATV system installer's (U.S.A.): This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected as close to the point of cable entry as practical.SAFETY INSTRUCTIONS1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!: This product, when installed as indicated in the instructions contained in this manual, meets FCCrequirements. Modifications not expressly approved by Vocopro may void your authority, granted by the FCC, to use this product.2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable(s) supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the U.S.A.3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class "B" digital devices. Compliance with these requirements provides a reasonable level of assurances that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the owner's manual, may cause interference harmful to the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit "Off" and "On", please try to eliminate the problem by using one of the following measures:Relocate either this product or the device that is being affected by the interference.Use power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter(s).In the case of radio or TV interference,relocate/reorient the antenna. If the antenna lead-in is 300-ohm ribbon lead, change the lead-in to coaxial type cable.If these corrective measures do not produce satisfactory results, please contact your local retailer authorized to distribute Vocopro products. If you can not locate the appropriate retailer, please contact Vocopro, 1728 Curtiss Court, La Verne, CA 91750.1. To ensure the finest performance, please read this manual carefully. Keep it in a safe place for future reference.2. Install your unit in a cool, dry, clean place - away from windows, heat sources, and too much vibration, dust, moisture or cold. Avoid sources of hum (transformers, v motors). To prevent fire or electrical shock, do not expose to rain and water.3. Do not operate the unit upside-down.4. Never open the cabinet. If a foreign object drops into the set, contact your dealer.5. Place the unit in a location with adequate air circulation. Do not interfere with its proper ventilation; this will cause the internal temperature to rise and may result in a failure.6. Do not use force on switches, knobs or cords. When moving the unit, first turn the unit off. Then gently disconnect the power plug and the cords connecting to other equipment. Never pull the cord itself.7. Do not attempt to clean the unit with chemical solvents: this might damage the finish. Use a clean, dry cloth.8. Be sure to read the "Troubleshooting" section on common operating errors before concluding that your unit is faulty.9. This unit consumes a fair amount of power even when the power switch is turned off. We recommend that you unplug the power cord from the wall outlet if the unit is not going to be used for a long time. This will save electricity and help prevent fire hazards. To disconnect the cord, pull it out by grasping the plug. Never pull the cord itself.10. To prevent lightning damage, pull out the power cord and remove the antenna cable during an electrical storm. 11. The general digital signals may interfere with other equipment such as tuners or receivers. Move the system farther away from such equipment if interference is observed.NOTE:Please check the copyright laws in your country beforerecording from records, compact discs, radio, etc.Recording of copyrighted material may infringecopyright laws.CAUTIONThe apparatus is not disconnected from the AC power source so long as it is connected to the wall outlet, even if the apparatus itself is turned off. To fully insure that the apparatus is indeed fully void if residual power, leave unit disconnected from the AC outlet for at least fifteen seconds. ����������������������������������������������������������������������������������Be sure to position the voltage selector to match the voltage of your local power lines before installing the unit.240V120VFCC INFORMATION (U.S.A.)Welcome...And Thank you for purchasing the UHF-5805from VocoPro, your ultimate choice in Karaoke entertainment! With years of experience in the music entertainment business, VocoPro is a leading manufacturer of Karaoke equipment, and has been providing patrons of bars, churches, schools, clubs and individual consumers the opportunity to sound like a star with full-scale club models, in-home systems and mobile units. All our products offer solid performance and sound reliability, and to reinforce our commitment to customer satisfaction, we have customer service and technical support professionals ready to assist you with your needs. We have provided some contact information for you below.VocoPro1728 Curtiss CourtLa Verne, CA 91750Toll Free: 800-678-5348TEL: 909-593-8893FAX: 909-593-8890VocoPro Company Email DirectoryCustomer Service & General Information****************Tech Support***********************Remember Our WebsiteBe sure to visit the VocoPro website for the latest information on new products, packages and promos. And while you're there don't forget to check out our Club VocoPro for Karaoke news and events, chat rooms, club directories and evena KJ Service directory!We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in Karaoke entertainment.FOR YOUR RECORDSPlease record the model number and serial number below, for easy reference, in case of loss or theft. These numbers are located on the rear panel of the unit. Space is also provided for other relevant informationModel NumberSerial NumberDate of PurchasePlace of PurchaseSelecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. VocoPro and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing.Sound can be deceiving. Over time your hearing “comfort level” adapts to a higher volume of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts.To establish a safe level:• Start your volume control at a low setting.• Slowly increase the sound until you can hear it comfortably and clearly, and withoutdistortion.Once you have established a comfortable sound level:• Set the dial and leave it there.• Pay attention to the different levels in various recordings.Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime.Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise. This list of sound levels is included for your protection.���������������������������Level������������ExampleQuiet library, Soft whispersLiving room, Refrigerator, Bedroom away from traffic Light traffic, Normal ConversationAir Conditioner at 20 ft., Sewing machineVacuum cleaner, Hair dryer, Noisy RestaurantAverage city traffic, Garbage disposals, Alarm clock at 2 ft.��������������������������������������������������������������Level��������������ExampleSubway, Motorcycle, Truck traffic, Lawn MowerGarbage truck, Chainsaw, Pneumatics drillRock band concert in front of speakersGunshot blast, Jet planeRocket launching pad-Information courtesy of the Deafness Research FoundationListening For A LifetimeSpecifi cationsReceiverCarrier Frequency Range: UHF 614~694MHzOscillation Mode: Quartz Controlled Fixed Frequency Stability: 10 PPMSensitivity: 1.6uV @ sinad =12dBMax. Deviation Range: 50HzS/N Ratio:>105dBT.H.D.: <0.5% @ 1kHzImage rejection: 85dB typicalSpurious Rejection: 75dB typicalFrequency Response: 40Hz~16kHzSquelch Control: dual-squelch circuitMax. Output Level: Balance: 0~400mV, Unbalance: 0~200mV Power Supply: External DC Power Supply, 0.7A, 12~15V DC Dimensions: 19”(L) x 8.2”(D) x 1.8”(H)Microphone basicsMicrophone PositionThe UHF-5805 is ideal for close-up vocals and can be held in the hand or mounted on a mic stand. The most common applications and placement techniques are listed below. Keep in mind that microphone technique is largely a matter of personal taste, and there is no one “correct” microphone position.Proximity EffectWhen the sound source is less than ¼ in. from the microphone, the microphone boosts bass frequencies (by 6 to 10 dB at 100 Hz), creating a warmer and richer bass sound than when farther away. This effect, known as proximity effect, happens only in unidirectional dynamic microphones like the UHF-5805.FeedbackFeedback occurs when the amplified sound from any loudspeaker reenters the sound system through any open microphone and is repeatedly amplified. Most commonly, feedback is caused by the following condi-tions: placing loudspeakers too close to microphones, having too many open active microphones, boosting tone controls indiscriminately (mainly treble) and performing in areas with high ratios of room surfaces that have hard and reflective surfaces such as glass, marble and wood. What to do if feedback occurs before the sound system is loud enough?• Request that the talker speak louder into the microphone.• Reduce the distance from the talker to the microphone. Each time this distance ishalved, the sound system output will increase by 6dB.• Reduce the number of open microphones.• Move the loudspeaker farther away from the microphone. Each time this distance isdoubled, the sound system output can be increased by 6dB.• Move the loudspeaker closer to the listener.• Use an equalizer/feedback reducer to cut the frequency bands in which the feedbackoccurs.Microphone Placement & Tone QualityLead & Backup VocalsLips should be less than 3” from or even touching the windscreen on an axis to the microphone. Doing this creates a robust sound, emphasizes bass and provides maximum isolation from other sources.SpeechWhen giving a speech or simply speaking, place the microphone 4” to 10” away from the mouth, just above nose height for a natural sound with reduced bass. You can also place the microphone 8” to 16” away from the mouth, slightly off to one side, for a more “distant” sound with highly reduced bass and minimal “s” sounds.Before getting startedBefore starting any installation procedures, it is recommend to completely unpack all the package contents. The original packaging should be kept in the event that re-shipping is needed. Upon unpacking the UHF-5805, you should have received the following items:•Custom Aluminum Travel Case (1)• UHF-5805 Receiver (1)• Handheld Microphones (4)• 3 ft. male/male ¼” cable (1)• 14V DC Main Unit power adapter (1), 9V DC Charger power adapter (2)• Dual Microphone Charger (2)9V9VUniversal Mic Charger Universal Mic Charger14VTo install the UHF-5805 to a 19” rack case, complete the steps below.1. Attach mounting brackets to the UHF-5805 via the supplied mounting screws.2. Align the UHF-5805 with the desired space in rack and slowly slide in, rear panel first.3. While aligned, use rack case screws (not included) in the order shown below to stabilize the UHF-5805 in its space, using the “X” rotation (numbered below) will ensure even tension and flush alignment.MountingNOTE: Depending on your rack case design, it may be neces-sary to allow for sufficient space for the antennas.NOTE: Do not tighten screws firmly until all screws are in place.����Maintenance proceduresRemoving the Field Replaceable ModulesEach of the 4 microphone modules on the UHF-5805 were designed in a way that allows them to slide out. This is a convenient feature if ever a module needs to be repaired or replaced.1. Remove the two screws that fasten the module to the front panel.2. To remove the module, simply slide the module out of the compartmentNOTE: It might be helpful to use a flat-head screwdriver to nudge the module out of its compartment.3. To re-insert, slide the module into compartment until it is completely secured. Secure the module withthe screws.The UHF-5805 comes with two dual chargers that let you charge all four microphones at the same time.Charging the MicrophonesIf the LED light on the microphone(s) does not light up when the microphone is turned on, this indicates that the microphone needs to be chargedTo charge:1. Place the microphone in the charger slot, the LED on the charger will be lit while the microphone is charging.2. When the LED on the charger turns off, the microphone is charged and can be removed.NOTE: For longest battery life, be sure to turn the microphones off when not in use.Reading the LED IndicatorsThe LEDs on the charger indicate the charging status. There are three states: blinking, on, and off.• Blinking - The power is connected to the charger but there are no microphones being charged • On - The microphone is being charged• Off - The microphone is completely charged and can be removed.Charger and Microphone Descriptions and Functions1. Microphone slots - Insert ne slots the microphones in these slots to charge2. Bodypack charger2. Body - pack charger Insert the optional rechargeable body pack in this slot to charge3. Microphone charge LED charge LED charge LE D in D - Indicate the - I indicators charging status of the microphones4. Bodypack charge LED in 4. Body - Indicates the charging status of the bodypack- I dicator - The color of this LED indicates the microphone’s charge level. Green means 5. Charge Indicator LED the charge is high, Orange means the charge is getting low and should be charged, and Red means the charge is very low and must be charged immediately.- Used to turn the microphone power ON and OFF . The mic power is ON when the 6. Power Switch switch is in the ON position and the power is OFF when the switch is in the OFF position.Charging the MicrophonesUniversal Mic Charger11562334NOTE:Make sure you are using the 9V power adapter for microphone chargersFront and rear panel descriptions and functions1.ANTEN ANTE NNA N - P NAS rovide both RF and AF signals.- Indicates whether the UHF-5805 is ON or OFF . When it is lit, the power is ON.2. POWER (LED) - Lights when RF signals are received from the microphone channels. - L 3. RF (LED) - 4. AF (LED)Lights when AF signals are received from the microphone channels.5. SQUELCH controls SQUELCH - Manual controls for controlling each microphone’s signal strength for bestcontrols performance. Turn clockwise to increase SQUELCH control and turn counter-clockwise to decreaseSQUELCH application.- Adjusts the individual VOLUME of the receiver’s 4 microphone channels.6. VOLUME controls - Contains the SQUELCH and VOLUME controls for each of the 4 wireless 7. MICROPHONE modules - C microphones. Each module can be easily removed individually. - Turns the UHF-5805 ON/OFF .8. POWER button - Main power jack for connection to an AC electrical outlet or power strip/surge 9. AC POWER connection - M protector. NOTE: Make sure you are connecting the 14V power adapter here.- This ¼” unbalanced output jack is for output connection to amplifiers, effects devices 10. MIXED OUTPUT or mixers. Both mic channels are output through this jack for mixed output. - These XLR unbalanced output jacks are for output connections to amplifiers, effects 11. XLR AUDIO OUTS devices or mixers. These are for separate mic channel connections with unmixed mic output.1567910113428UHF-5805 & stage monitor/p.a. loudspeakersIf you will be using the UHF-5805 with stage monitors and/or P.A. system, try the following:• Place the stage monitor directly behind the microphone.• Locate the P.A. loudspeakers so that they point away from the rear of the microphone. (With the speakers located in these positions, the possibility of feedback is greatly reduced).• Always check the stage setup before a performance to ensure optimum placement of microphone and monitors.IMPORTANT: Every wireless microphone installation is a unique situation, and can present a variety of prob-lems. Never attempt a live performance without first conducting a “walkthrough” test of the system in the performing area. If major changes (additional wireless systems or intercoms, relocation of scenery, etc.) have been made since the last walk-through test, check the wireless system again, as close to performance time as possible.P.A. Speakers Facing AwayFrom Rear of MicrophoneMonitor Directly BehindMicrophoneOperations2. Adjust the receiver’s VOLUME controls to approximately 50%.3. Switch the microphone’s POWER BUTTONS to the ON positions.4. Talk or sing into the microphones. During normal operation, the RF/AF signal LED’s will light when amicrophone is being used.5. Adjust the receiver’s VOLUME controls until the output levels are balanced w ith each other and otherpossible source output i.e. CD+G tracks.TroubleshootingProblemsNo sound output, RF/AF LED(s) are not glowingReceived signal is noisy or contains extraneous sounds with the microphone(s) ON.There is noise coming from the receiver with the microphones turned OFF.Momentary loss of sound as microphone(s) are moved throughout the operating range.Solutions• Make sure the microphone and receiver power switches and receiver are set to the ON position.• Check microphone charge to ensure there is sufficient power. Charge mic if necessary• Check receiver’s AC power connection.• Make sure antennas are firmly connected and extended to an optimal position.• If necessary, reduce the distance between the microphones and receiver.• Turn up the receiver’s VOLUME level controls.• Check for proper connection between receiver and external amplifier/mixer.• Talk into the microphone and observe the receiver’s RF/AF signal LED’s. If they glow, the problem is elsewhere in the sound system.• Check microphone(s) charge and recharge if the charge is low.• Remove local sources of UHF interference, such as lighting equipment.• Adjust the squelch controls on the front of the UHF-5805 receiver.• Signal may be too weak. If so, reposition antennas. (If possible, move them closer to the transmitter).• Remove local sources of UHF interference, such as lighting equipment.• Reposition the receiver or antennas.• Reposition the receiver, perform a “walkthrough”, and observe the signal strengths. If audio dropouts persist, mark these “dead spots” in the operating area and avoid them during the performance.UHF-5805 Manual © VocoPro 2011V 1.1Erratic LED blinking on the main receiver modules• Make sure the 14V power adapter is pluggedin to the main unit. Do not use the 9V adapterswith the main receiver unit.• If the power adapter is the 14V and the main unitlights are still blinking, contact VocoPro for areplacement。
Product Catalog 2009UHF 合成无线话筒系列AV 数字管理中心使用SONY UWP 系列产品，让您感受到抗干扰，低成本的操作。
无线话筒系统在各个应用领域中的使用越来越广泛，这种低成本的系统也越来越受到大家的欢迎，但与此同时，发射稳定性和噪音的问题往往为人们所忽视。
SONY 推出了完美的解决方案——专为那些考虑财政预算，寻求高度可靠无线操作的使用者设计的UWP 系列UHF 合成无线话筒系列。
UWP 系列有6个核心组成部分——耳夹式/腰包式发射器，无线手持式话筒，插接式发射器，便携式调谐器，半机架宽的调谐器，以及调谐器模块。
它们可以组合成多种功能完备的设备系统，每一种都包括一个话筒，一个发射器和一个调谐器，打开包装，就可以立即投入工作。
每一种设备套装都经过精心设计，对应一种专门的操作应用。
这意味着在几乎任何一种应用中，UWP 系列都能够满足需要。
在发射稳定性方面UWP 系列表现杰出。
SONY 将久经考验SONY UHF 合成无线话筒系列产品介绍的无线科技与新开发的尖端无线话筒系列结合起来，将UHF PLL-合成系统融入其中，使产品具备了空间分集接收功能和噪声抑制功能。
这些出类拔萃的特点只有在高端的无线系列产品中才可得见。
不论您是进行低成本的ENG （电子新闻采访），EFP(电子新闻节目制作)或者PA （扩声场所）系统操作，UWP 系列都会提供给您异常便捷、可靠的无线话筒解决方案，而成本却非常低廉。
稳定的发射和接收UWP系列无线话筒使用了三种核心科技，确保了信号在发射和接收过程中的稳定性。
锁相环(PLL)合成系统●保证稳定的发射和接收之关键所在，是使用了一种载波信号，以避免与其它频率通道的相互干扰，在多个频率中进行选择。
为达到这一目的，UWP系列使用了UHF锁相环(PLL)频率合成系统，它可以提供正确的载波信号频率。
●发射器和调谐器同样采用了这种系统，这样，发射器就可发射出稳定的载波，调谐器可正确地进行调谐。
UHF Wireless Microphone System UwMic10User ManualStatementThis user manual is available for these packages:• U wMic10 RX10+TX10, a portable receiver and a body-pack transmitter.• U wMic10 RX10+TX10+TX10, a portable receiver and two body-pack transmitters.• UwMic10 HU10, a hand-held microphone transmitter.• UwMic10 TX10, a body-pack transmitter.Please read this manual carefully before using and strictly operate and store in accordance with the instructions. Please save it for your future reference.If the user manual can not help you to solve certain problems, please ask your retailer for help or email us: info@saramonic. com.Cautions1. Do not use the unit under water, don't expose it to rain.Please store it in a cool, dry place.2. Please use and store it in normal temperature. Donot move it from overheated to supercooled conditionfrequently as well as keep away from heat sources such as heater and oven.3. When using and storing, please pay attention to dust andmoisture.4. Be careful to violent collision.5. To avoid acoustical feed-back, do not hold the microphoneclose to the loudspeakers.6. For the best sound pick-up pattern do not hold your handagainst the microphone head.7. Remove the batteries from the battery compartment whenthe device is not used for a long time.CONTENTSGeneral Introduction (2)Portable Receiver UwMic10-RX10 (2)Introduction (2)Product Structure (2)Attaching Accessories (4)LCD Display Operation Guide (5)Body-pack Transmitter UwMic10-TX10 (8)Introduction (8)Product Structure (8)Attaching Accessories (10)LCD Display Operation Guide (11)Hand-held Microphone UwMic10-HU10 (14)Introduction (14)Product Structure (14)Setup Guide (15)Operation Guide (16)Specification (20)Receiver RX10 (20)Transmitter TX10 and HU10 (21)Packing list (22)/ 1General IntroductionThe Saramonic UwMic10 UHF wireless microphone systemis intended for portable wireless operation and can be usedin several environments for applications such as DSLR video, field recording, broadcast TV, electronic news gathering (ENG), on-the-spot interviews, and more.Portable Receiver UwMic10-RX10 IntroductionThe Saramonic UwMic10-RX10 is a camera-mountable integrated wireless receiver. It features a wide switchingRF bandwidth, an easy-to-read LCD display and infrared synchronization between transmitter and receiver. Equipped with an auto-scan function, the RX10 can automatically search for an available transmission frequency. The phone jack enables real-time monitoring of receiver via headphones, especially useful for cameras that lack a monitor output.Product Structure①②⑤⑦③④⑥⑧⑩⑨⑪/ 2① Antennas② P ower buttonPress to turn on or off the RX10.③ SET buttonLong press the SET button to enter the displayed menu.Then, short press the SET button to confirm your option or long press again to exit without saving.④ POWER indicatorIndicates the battery level as follows:Green light: Sufficient battery level.Red light: Low battery level.⑤ RF indicator and infrared transmitter portThe infrared transmitter port sends the set frequency to a transmitter.RF indicator displays the RF input level as follows:Green light: RF signal is strong.Red light: RF signal is weak or disconnected.⑥ + or – buttonSelects functions or values shown on the display.⑦ LCD displayDisplay menus, please refer to "LCD Display OperationGuide" (page 5) for more details.⑧ Battery compartmentOperates on two AA batteries (not included).⑨ PHONE jackIt is a 3.5mm diameter and stereo mini headphone jack.Connect a headphone to monitor the audio output.Note: Please do not connect a headphone with a mona-ural mini jack. As this may short-circuit the headphonejack and distorted sound output.⑩ OUTPUT jackConnect the RX10 to a video camera, camcorder, mixer or amplifier with the supplied output cable.⑪ Standard cold shoe/ 3/ 4Attaching Accessories1 Connect the supplied cable to the output jack.2 A ttach a belt clip. Please Refer to “Attaching Accessories" (page 10).3 Attach the shoe mount adapter .① P lug the supplied cable into the OUTPUT jack.② F or a secure connection, turn to lock the connector.①②①③②① P lease attach the belt clip upside-down before attach-ing the shoe mount adapter .② P ush the bottom of the belt clip to make some spacebetween the belt clip and thereceiver .③ A lign the belt clip with the two vertical grooves on theshoe mount adapter andinsert the adapter in thedirection of the arrow.④ P ush the shoe mount adap-ter in fully until the belt clip fits into the horizontal grooveon the adapter holds./ 5LCD Display Operation GuideHome screen. If no operation is performed for 20 seconds onthe other screens, the display will automatically return to the home screen.① Group icon Indicates the power of group A is turned off.Indicates the power of group A is turned on. ② RF level indicatorIndicates the current reception level.③ Battery level indicator Displays the battery level. Please replace both batteries immediately when the indicator starts flashing.④ Name of the channel group ⑤ Current channelDisplays the current channel number .⑥ Audio input level meter Displays the audio input level.2Power key. Long press the SET button to unlocked or locked the power key. Lock the power key to prevent the receiver being turned off unwittingly while using.• U nlocked: Long press the power key to turn the receiver on or off (System default).• L ocked: The receiver will not be turned off even after pressing the power key.①②②③④⑤⑥①1Note: If the batteries are removed and reinserted while the power key is set to Locked, the lock state of the Power key will not be changed. You can turn on the receiver by long pressing the power button.38Power of the Group. When you only use one group signal, please turn off the other group to save battery. To save battery, system default of the Group B is power off while the Group A is power on.When operating two transmitters simultaneously, please set each transmitter to a different group to prevent interference or noise.49Select channel. Details of operation, please refer to "Manually setting the receiver channel" (page 18).The system default of Group A is in RF frequence 614.560MHz, Channel 01.The system default of Group B is in RF frequence 656.510MHz, Channel 01.510Set output volume. Set the volume of output audio within the range 0 to 30. The setting is retained even after the power is turned off. Default is 30./ 6/ 7Auto scan function. Automatically scan an available and clear channel. Details of operation, please refer to "Using the auto scan function" (page 17).7Group Matc h with TX ettings12 Group Matc h with TX ettings Infrared matching function. Match the receiver andtransmitter via infrared. Details of operation, please refer to "Match the channel of receiver and transmitter" (page 18).13Set backlight. Set the backgroud LED light to ON or Delay 60 /30 /10 seconds or OFF. Default is “Delay 10s.”14Restore settings. Confirm it then the parameters of RX10 are restored to their factory default settings.15Version of the UwMic-RX10.①⑦⑧⑨②③⑤④⑥Serial Number.Body-pack Transmitter UwMic10-TX10 IntroductionThis transmitter is a compact transmitter that employs a crystal-controlled PLL synthesizer. It is equipped with a muting function and a BMP-type microphone input connector. The RF power output can be switched among high, middle and low.Product Structure/ 8① Antenna② AUDIO indicator / IR (infrared detector)AUDIO indicator: Indicates the audio input level.IR (infrared detector): Gets the frequency from the receiver Solid Green: Audio input level is appropriate.Flashing Red: Audio is muted (i.e., disabled).For details on setting the mute function, please refer to"Set Mute key" (page 12).③ POWER indicatorIndicates the battery level as follows:Solid Green: Sufficient battery level.Solid Red: Battery is getting low.④ Audio input connector (BMP type)Connect to the supplied lavalier microphone.⑤ + or – buttonSelects functions or values shown on the display.⑥ Battery compartmentAccepts two AA batteries (alkaline, nickel metal hydride,or lithium batteries).⑦ Power / Mute buttonFunction OperationPower ON Press button for one second or longerPower OFF Press button until it turns offMute ONShort press buttonMute OFF⑧ SET buttonLong press the SET button to enter the displayed menu.Then, short press the SET button to confirm your option or long press again to exit without saving.⑨ LCD displayDisplay menus, please refer to "LCD Display OperationGuide" (page 11) for more details.Attaching Accessories1Attach a belt clip.Insert one end of the belt clipinto one of two holes on eitherside of the transmitter, andthen insert the other end intothe hole on the other side.2 Connect the mcirophone.For a secure connection, turnto lock the connector.Note: Please turn off thetransmitter before attach orremove the microphone.LCD Display Operation GuideH ome screen. If no operatIon is performed for 20 seconds on the other screens, the display will automatically return to the home screen.① RF transmission power indicatorIndicates the current transmission power level.For details on setting the level, please see “Select RF power level” (page 12).② Channel group indicator Indicates the channel group. ③ Mute indicatorMute OFF Mute ON④ Battery level indicatorDisplays the battery level. Please replace both batteries immediately when the indicator starts flashing.⑤ Name of the channel group ⑥ Channel and frequencyIndicate the current channel and frequency.⑦ The statue of Power / Mute button.12⑤⑦⑥①①②③④① M enu display section. Displays various functions. Press the + or - button to switch functions.Set Power key. Select Unlocked or Locked.Set ”Locked” to lock the power button to prevent the unit being turned off or muted unwittingly while using. Default is “Unlocked.”Select Channel. There are 96 channels with carrier frequency ranging from 614MHz to 696MHz. Default is “Channel 01” and “614.560MHz.”4Select Group. You can choose “A” or “B” channel group. Each group has 96 channels. Default is “Group A.”5Select RF power level. You can set the transmitted RF power to High, Middle or Low. Default is “High.”6Set Mute key. If you want to mute the audio, please select “Enable” first and then short press the power button. Default is “Enable.”IR Match. Set to match with the receiver. The screen will display “Matching” when in process. After successful matching, it will indicate “Match finished.”8Set Backlight. Select ON, OFF or Delay 10 / 30 /60 seconds. Default is “Delay 10s.”9Restore default setting.10Version of the UwMic10-TX10.11Serial Number.② Power / Mute buttonPower: Long press to turn on/off the HU10.Mute: Short press the button while transmitting, the audio will be muted. Press it again to restore the audio output.Note: In muting, the audio signal is not output but an RF signal is still transmitted.③ Antenna⑤① LCD screenA. Channel Groups.Two channel groups: A and B. Each group has 96 channels.B. Channel number.C. Battery level indicator .D. MUTE. Audio is muted.This LCD display indicates it isoperating on channel 96 of group A.①②③④A B CDHand-held Microphone UwMic10-HU10IntroductionSaramonic HU10 is a handheld wireless UHF microphonetransmitter features a compact metallic body, an easy-to-read LCD display, a RF power switch and a PLL synthesizer . The broadcast quality microphone will capture crystal clear and rich sound. It has a built-in antenna, a muting function and power lock function. The channel of HU10 is synced up with the receiver via infrared.Product Structure④ Operation panelONOFF HIGHLOW LOCKUHFRFBA CA. Infrared detector. Receives the frequency set on the receiver.B. Lock switch. Set to ON will lock the power button. It will prevent the power being turned off inadvertently during transmission.N ote: The lock switch will not lock the mute function.C. RF power. Set the transmit output level to HIGH or LOW.⑤ Battery compartmentOperates on two AA batteries (not included).You could use alkaline, lithium or nickel metal hydride batteries.Setup Guide1 Install the batteries. Refer to "UwMic10-HU10" (page 16).2 (Option) Set the lock switch to ON or OFF.3 (Option) Set the RF power to HIGH or LOW. The transmitpower level varies depending on the model.4 Press the power button to turn on the HU10.5 T urn on the receiver UwMic10-RX10 and sync with thetransmitter HU10. Details of operation, please refer to "For HU10" (page 19).6 W hen sync successfully, the screen of HU10 will show the group and channel same as the receiver .7 Close the grip in the direction of the arrows.8 Now it is ready to use.Operation Guide1 Install the batteries.① UwMic10-RX10 and UwMic10-TX10:② UwMic10-HU10• L ong press the Power key to turn the unit off.• S lide the two catches inward and pull out the battery compartment.• I nsert two AA size batteries according to the polarity indicators and close the compartment. Please be sure the battery compartment is locked securely.• L ong press the power button to turn the power off.• T urn the grip in the direction of the arrow, and pull the grip down until the battery compartment is visible.• I nsert two new AAbatteries into the battery compartment with and polarities in the correct orientation.Note:① P lease remove the batteries from the battery compartment when the device is not used for a long time.② Please always use sets of the same type of battery.③ R eplacing the batteries during operation may generate noise. Please make sure that the unit is turned off before replacing batteries.• U se the + or – button todisplay the auto scan screen on the receiver .• L ong press the SET button to select “Auto scan?”• P ress the SET button to confirm.• T he channel with the least noise and interference will be displayed.A. Indicates the current least noise channel is CH 03 and ask you if you would like to use it. You can short press the SET button to confirm the channel in 20 seconds or long press the SET button to exit the displayed menu without saving.B. Counting down 20 secondNote:① A fter 20 seconds have elapsed, the display returns to the home screen without saving.② S ome noise may occur when power is turned on, you could turn down the audio input level of devices connected to the receiver accordingly.A B2 C onnect the receiver to the mic jack of a camera,camcorder or mixer with the supplied cable.3 Turn on the receiver by long pressing the power button.4 Set the channel of the receiver by two ways:① Using the auto scan function② Manually setting the receiver channel.• U se the + or – button to display the channel menu on the receiver.• Long press the SET button to select the menu.• U se the + or – button to select the desired channel and confirm it by short pressing the SET button.5 Match the channel of receiver and transmitter.① U sing infrared transmission to transfer the frequency seton the receiver to a transmitter.For TX10• Turn on the transmitter by long pressing the power button.• U se the + or – button to display the “Match with TX” menu on receiver.• U se the + or – button to display the “Match with RX” menu on transmitter.• B oth long press the SET button to select the menu and short press it to confirm.• P lace the infrared transmitter port on the receiver near the infrared detector on the transmitter.• I f “Match finished” displayed on the LCD screen, the frequency for use on the transmitter is set.• A fter matching successfully, press the SET button of receiver to return to the previous menu.For HU10• Turn the transmitter power on.• U se the + or – button to display the “Match with TX” menu on receiver.• P lace the infrared transmitter port on the receiver near the infrared detector on the transmitter.• I f sync successfully, the group and channel of HU10 are the same as the receiver's.• A fter matching successfully, press the SET button of receiver to return to the previous menu.Note: When using the infrared link, please place the receiver and transmitter within about 20cm of each other within20 seconds. After 20 seconds have elapsed, the infrared transmission finishes and the display returns to the previous menu./ 19② M anually setting the transmitter channel (Only availableon the UwMic10-TX10).• Turn on the transmitter by long pressing the power button.• U se the + or – button to display the channel setting menu on the transmitter.• Long press the SET button to select the menu.• U se the + or – button to select the same channel as the receiver and confirm it by short pressing the SET button.6 A ttach the accessories you need for the receiver andtransmitter. Refer to "Attaching Accessories" (page 4 and page 10).7 You are ready to record.SpecificationReceiver RX10Channel number96Channel group A and BOscillator type PLL synthesizerAudio output connector 3.5 mm mini jackAntenna1/4λ wire antennaAudio output level–60 dBVHeadphone output level30mW (16 Ω)Receive frequencies614 MHz - 696 MHzReceive sensitivity-95 dBmSignal to noise ratio70 dB or moreVoice delay12 msReference deviation±5 kHz (–60 dBV, 1 kHz input)Frequency response40 Hz to 18 kHz (+/-3dB)Distortion0.5% or less/ 20Spur suppression-60 dBWeight Approx. 218.7g (excluding batteries) Battery Two AA size batteries Dimensions170.9 × 63.5 × 30.0 mm Operating temperature0 °C to 50 °CStorage temperature–20 °C to +55°CTransmitter TX10 and HU10Channel number96Channel group A or BOscillator type PLL synthesizerCarrier frequencies614 MHz - 696 MHzReference deviation±5 kHz (–60 dBV, 1 kHz input) Signal to noise ratio70 dB or moreSpur suppression-60 dBVoice delay12 msAntenna1/4λ wire antennaAudio input connector TX10: 3.5mm mini jack HU10: noneReference audio input level–60 dBV (MIC input, 0 dB attenuation) RF output level30mW/20mW/10mW selectable Distortion0.5% or lessWeight TX10: Approx. 211.4g (excluding batteries) HU10: Approx. 338.2g (excluding batteries)Battery Two AA size batteriesDimensions TX10: 170.9 × 63.5 × 30.0 mm HU10: 254.0 × 52.0 × 52.0 mmOperating temperature0°C to 50°CStorage temperature–20°C to +55°C/ 21Packing listTX10• Body-pack transmitter: TX10• Omni-directional lavalier microphone • Microphone holder clip• Wind screen• Belt clip/ 22RX10• Portable receiver: RX10• Shoe mount adapter• Belt clip• XLR-BMP audio output cable• 3.5mm plug-bmp audio cableHU10• Hand-held microphone: HU10Warranty cardUser manual/ 23/ 24The Saramonic logo is trademark which is registered and owned by Saramonic International.COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL ( A brand of DSQN ) Email: info@。
VHF-4005 Professional Quad VHF Wireless Microphone System o w n e r’s m a n u a lWelcomeAnd thank you for purchasing the VHF-4005 from VocoPro, your ultimate choice in Karaoke entertainment! With years of experience in the music entertainment business, VocoPro is a leading manufacturer of Karaoke equipment, and has been providing patrons of bars, churches, schools, clubs and individual consumers the opportunity to sound like a star with full-scale club models, in-home systems and mobile units. All our products offer solid performance and sound reliability, and to reinforce our commitment to customer satisfaction, we have customer service and technical support professionals ready to assist you with your needs. We have provided some contact information for you below.VocoPro1728 Curtiss CourtLa Verne, CA 91750Toll Free: 800-678-5348TEL: 909-593-8893FAX: 909-593-8890VocoPro Company Email DirectoryCustomer Service & General Information****************Tech Support***********************Remember Our WebsiteBe sure to visit the VocoPro website for the latest information on new products, packages and promos. And while you're there don't forget to check out our Club VocoPro for Karaoke news and events, chat rooms, club directories and evena KJ Service directory!We look forward to hearing you sound like a PRO, with VocoPro, the singer’s ultimate choice.FOR YOUR RECORDSPlease record the model number and serial number below, for easy reference, in case of loss or theft. These numbers are located on the rear panel of the unit. Space is also provided for other relevant informationModel NumberSerial NumberDate of PurchasePlace of PurchaseCONNECTING POWERConnect the AC power adapter to the power input jack on the far right of the back panel on the VHF-4005 .CONNECTING AUDIO OUTPUTUSING THE XLR OUTPUTS:The XLR outputs allow you to connect each channel to the mixer independently . This gives you more control over the volume on individual microphone channels when connected to a mixer .You’ll need:• VHF-4005• (4) XLR patch cables (not included)• An input device, such as a mixer or amplifier (not included)TO CONNECT THE XLR OUTPUTS:1 . Ensure the main power switch is turned off .2 . Connect one end of an XLR cable to the CH .1output of the VHF-4000 .3 . Connect the other end of the XLR cable to thedesired input on your mixer .Note: To avoid confusion, it’s recommended that the XLR jacks are attached correspondingly (e.g. CH.1 to CH.1, CH.2 to CH. 2, etc. illustration is for clarity not accuracy).4 . Repeat steps 2 and 3 until all the XLR outputsare connected .USING THE 1/4” MIXED OUTPUT:The 1/4” mixed output is useful if you have limited inputs available on your mixer . All four microphone signals are mixed together in this single output .You’ll need:• VHF-4005• (1) 1/4” patch cables (included)• An input device, such as a mixer or amplifier (not included) .TO CONNECT THE 1/4” MIXED OUTPUT:1 . Ensure the main power switch is turned off .2 . Connect one end of a 1/4” cable to the 1/4”mixed output on the rear panel of the VHF-4005 .3 . Connect the other end of the 1/4” cable to thedesired input on your mixer or amplifier .Getting ConnectedVHF-4005 Rear PanelVHF-4005 Rear PanelMixerMixerVHF-4005 Rear Panel11VHF-4005 Owner’s Manual © VocoPro 2014v1.1119。
