面板LED 燈號 PCB 接點及Jumper跳線LED 燈號 顯示說明Jumper 跳線說明出廠設定 PWR 正常情況持續閃爍表CPU 有在正常運作 JP5 DI 外部或控制器內部供電切換 控制器內部供電 COM 未接卡機約每秒閃爍一次，接卡機閃爍速度變快JP6 設定繼電器(RELAY)是否由控制器供電控制器不供電 10M 當網路(LAN)通訊速率為10Mbps 時會亮燈 閉路(Close)表示由控制器供12VDC 電源100M 當網路(LAN)通訊速率為100Mbps 時會亮燈 JP7~JP12 繼電器(RELAY) NC 或NO 切換Normal Open DI1~DI8 當燈亮時表示該輸入接點導通JP15 韌體AP 是否啟用，開路(Open)表示啟用 韌體AP 啟用 RY1~RY6當燈亮時表示其對應之輸出接點繼電器作動後側板接點 接線說明接點及按鈕 接線說明C+ DI 外部電源輸入 (注意事項8) RESET 長按10秒控制器重置回出廠設定 DI1~DI4 出門按鈕接點對應1~4門點 預設IP 位址：10.0.50.100 DI5~DI8 火災發報接點對應1~4門點 COM RS485(2線/4線)串接讀卡機使用 G控制器共地接點 (注意事項8) LAN RJ45網路接線RY1+~RY4+ 外部電源輸入接點對應1~4門的電鎖使用DC JACK 控制器電源輸入(12VDC) RY1-~RY4-電源輸出至1~4門的電鎖使用PWR控制器電源輸入(12VDC)注意事項1. 控制器請使用12VDC 供電，允許的輸入電壓為9VDC~13VDC；控制器輸入電源，DC JACK 與端子接點(PWR)兩者擇一2. 控制器若斷電超過24小時，系統時鐘需重新設定3. 控制器韌體版本必須與讀卡機相符方可正常使用；版本ATOP 4Door ATT 是Atop 讀卡機使用，ATOP 4Door SOYAL 是Soyal 讀卡機使用4. 讀卡機RS-485 ID1~ID4為進入卡機，ID5~ID8為出門卡機5. 讀卡機的通訊線路建議使用22AWG 具Shielding 防護之雙絞線材；以一進一出方式串接卡機6. 電鎖的電源與控制器的電源分開供電，避免電鎖作動瞬間影響控制器7. 訊號傳輸線與電源線建議分開配管，避免訊號干擾8.當JP5切換使用"C+"外部電源時，勿使用"G"接點作為共地接點，應使用DI 外部電源之地電壓當迴路地控制器與HID卡機、AR1200韋根轉換器、電鎖建議接線圖控制器與卡機、電鎖建議接線圖電鎖由卡機控制接線圖控制器進出管制接線圖注意事項1. 電鎖及出門按鈕由控制器直接控制，安全性較高2. 若為節省佈線，可將電鎖及出門按鈕由轉換器控制3. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC4. 電鎖的電源建議獨立供電5. 電鎖建議外加一個反向二級體(1N4001)保護電路注意事項1. 進讀卡機的RS-485 ID為1~4，出讀卡機的RS-485 ID為5~82. 電鎖及出門按鈕由控制器直接控制，安全性較高3. 若為節省佈線，可將電鎖及出門按鈕由進讀卡機控制4. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC5. NC/NO使用控制器PCB之JUMPER JP7~JP10跳線6. 電鎖的電源建議獨立供電7. 電鎖建議外加一個反向二級體(1N4001)保護電路RS485 D+RS485 D-出門按鈕V+DI1DI COMVIN+NC1COM1To Vout+To Vout-控制器Wiegand注意事項1. 電鎖及出門按鈕由卡機控制，可節省佈線，但安全性較低2. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC3. 電鎖的電源建議獨立供電4. 電鎖建議外加一個反向二級體(1N4001)保護電路注意事項1. 電鎖及出門按鈕由控制器直接控制，安全性較高2. 電鎖繼電器的NC/NO依電鎖型式決定，一般的陽極鎖或磁力鎖為NC3. NC/NO使用控制器PCB之JUMPER JP7~JP10跳線4. 電鎖的電源建議獨立供電5. 電鎖建議外加一個反向二級體(1N4001)保護電路磁簧DI_GDIPCB跳線控制器出門按鈕警報器V+外部電源V-Pin6PCB跳線參見注意事項Pin7Pin8Pin1Pin2GND控制器電源供應器(For 控制器&卡機)出門按鈕V-RS485 D+DI_GDIGND V+(12V)電源供應器(For 電鎖)GNDID=1控制器警報器磁簧外部電源V+V+Pin5Pin6Pin9Pin7。
EDS-G4014Series8G+62.5GbE-port full Gigabit managed Ethernet switchesFeatures and Benefits•Developed according to the IEC62443-4-1and compliant with the IEC62443-4-2industrial cybersecurity standards•Turbo Ring and Turbo Chain(recovery time<50ms@250switches),andRSTP/STP for network redundancy•Wide range of power input options for flexible deployment•Compact and flexible housing design to fit into confined spaces•Supports MXstudio for easy,visualized industrial network management•Increased bandwidth capabilities with fiber SFP slots supporting up to2.5GbpsCertificationsIntroductionThe EDS-G4014Series is equipped with eight Gigabit Ethernet ports and six2.5Gbps fiber-optic ports,making it ideal for upgrading an existing network to Gigabit speed or building a new full Gigabit backbone.Gigabit transmission speed increases bandwidth for higher performance and can transfer large amounts of triple-play services across a network quickly.Redundant Ethernet technologies such as Turbo Ring,Turbo Chain,and RSTP/STP increase the reliability of your system and improve the availability of your network backbone.The EDS-G4014Series is designed specifically for demanding applications such as video and process monitoring,ITS,and DCS systems,all of which can benefit from a scalable backbone.The EDS-G4014Series is compliant with the IEC62443-4-2and IEC62443-4-1Industrial Cybersecurity certifications,which cover both product security and secure development life-cycle requirements,helping our customers meet the compliance requirements of secure industrial network design.SpecificationsEthernet Interface10/100/1000BaseT(X)Ports(RJ45connector)8Auto MDI/MDI-X connectionAuto negotiation speedFull/Half duplex mode100/1000/2500BaseSFP Ports41000/2500BaseSFP Ports2Standards IEEE802.3for10BaseTIEEE802.3u for100BaseT(X)IEEE802.3ab for1000BaseT(X)IEEE802.3z for1000BaseXIEEE802.3bz for2.5GBaseXIEEE802.3x for flow controlIEEE802.3ad for Port Trunk with LACPIEEE802.1Q for VLAN TaggingIEEE802.1D-2004for Spanning Tree ProtocolIEEE802.1w for Rapid Spanning Tree ProtocolIEEE802.1p for Class of ServiceIEEE802.1X for authenticationEthernet Software FeaturesFilter GMRP,GVRP,GARP,802.1Q VLAN,IGMP Snooping v1/v2/v3,IGMP Querier Management IPv4/IPv6,Flow control,Back Pressure Flow Control,DHCP Server/Client,ARP,RARP,LLDP,Port Mirror,Linkup Delay,SMTP,SNMP Trap,SNMP Inform,SNMPv1/v2c/v3,RMON,TFTP,SFTP,HTTP,HTTPS,Telnet,Syslog,Private MIBMIB P-BRIDGE MIB,Q-BRIDGE MIB,IEEE8021-SPANNING-TREE-MIB,IEEE8021-PAE-MIB,IEEE8023-LAG-MIB,LLDP-EXT-DOT1-MIB,LLDP-EXT-DOT3-MIB,SNMPv2-MIB,RMON MIB Groups1,2,3,9Redundancy Protocols STP,RSTP,Turbo Ring v2,Turbo Chain,Ring Coupling,Dual-Homing,Link Aggregation Security Broadcast storm protection,Rate Limit,Trust access control,Static Port Lock,MACSticky,HTTPS/SSL,SSH,RADIUS,TACACS+,Login and Password PolicyTime Management SNTP,NTP Server/Client,NTP AuthenticationProtocols IPv4/IPv6,TCP/IP,UDP,ICMP,ARP,RARP,TFTP,DNS,NTP Client,DHCP Server,DHCP Client,802.1X,QoS,HTTPS,HTTP,Telnet,SMTP,SNMPv1/v2c/v3,RMON,SyslogSwitch PropertiesMAC Table Size16KJumbo Frame Size9.216KBMax.No.of VLANs256VLAN ID Range VID1to4094IGMP Groups512Priority Queues4Packet Buffer Size1MBLED InterfaceLED Indicators PWR1,PWR2,STATE,FAULT,MSTR/HEAD,CPLR/TAIL,SYNCSerial InterfaceConsole Port RS-232(TxD,RxD,GND),8-pin RJ45(115200,n,8,1)USB InterfaceUSB Connector USB Type A(Reserved)Input/Output InterfaceAlarm Contact Channels1,Relay output with current carrying capacity of1A@24VDCDigital Input Channels1Digital Inputs+13to+30V for state1-30to+3V for state0Max.input current:8mAButtons Reset buttonDIP Switch ConfigurationDIP Switches Turbo Ring,Master,Coupler,ReservePower ParametersConnection2removable4-contact terminal block(s)Pre-installed Power Module-LV/-LV-T models:PWR-100-LV-HV/-HV-T models:PWR-105-HV-INote The EDS-G4014Series supports modular power supplies.The model names and powerparameters are determined by the installed power module.For example:EDS-G4014-6QGS-T+PWR-100-LV=EDS-G4014-6QGS-LV-TEDS-G4014-6QGS-T+PWR-105-HV-I=EDS-G4014-6QGS-HV-TIf you install a different power module,refer to the specifications of the correspondingmodel.For example,if you replace the power module of the EDS-G4014-6QGS-LV-Twith the PWR-105-HV-I,refer to the specifications of the EDS-G4014-6QGS-HV-T. Input Voltage-LV/-LV-T models:12/24/48VDC,Redundant dual inputs-HV/-HV-T models:110/220VDC/VAC,Single inputOperating Voltage-LV/-LV-T models:9.6to60VDC-HV/-HV-T models:88to300VDC,85to264VACInput Current-LV/-LV-T models:12-48VDC,1.50-0.40A or24VDC,0.70A-HV/-HV-T models:110-220VAC,50-60Hz,0.30-0.20A or110-220VDC,0.30-0.20A Power Consumption(Max.)EDS-G4014-6QGS-LV(-T)models:14.91WEDS-G4014-6QGS-HV(-T)models:17.32WOverload Current Protection SupportedReverse Polarity Protection SupportedPhysical CharacteristicsIP Rating IP40Dimensions55x140x122.5mm(2.17x5.51x4.82in)Weight846g(1.87lb)Installation DIN-rail mounting,Wall mounting(with optional kit)Housing MetalEnvironmental LimitsOperating Temperature Standard Models:-10to60°C(14to140°F)Wide Temp.Models:-40to75°C(-40to167°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsIndustrial Cybersecurity IEC62443-4-1IEC62443-4-2Safety UL61010-2-201,EN62368-1(LVD)EMC EN55032/35,EN61000-6-2/-6-4EMI CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:8kV;Air:15kVIEC61000-4-3RS:80MHz to1GHz:20V/mIEC61000-4-4EFT:Power:4kV;Signal:4kVIEC61000-4-5Surge:Power:4kV;Signal:4kVIEC61000-4-6CS:10VIEC61000-4-8PFMFMaritime-LV/-LV-T models:DNV,ABS,NK,LRVibration IEC60068-2-6Shock IEC60068-2-27Freefall IEC60068-2-32Railway EN50121-4Traffic Control NEMA TS2MTBFTime EDS-G4014-6QGS-LV/LV-T models:994,797hrsEDS-G4014-6QGS-HV/HV-T models:487,613hrsWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x EDS-G4014Series switchDocumentation1x quick installation guide1x product notice,Simplified Chinese1x product certificates of quality inspection,Simplified Chinese1x warranty cardDimensionsOrdering InformationModel Name10/100/1000BaseT(X)Ports(RJ45Connector)100/1000/2500BaseSFPPorts1000/2500BaseSFPPortsOperating VoltagePre-installedPower ModuleOperating Temp.EDS-G4014-6QGS-LV8429.6to60VDC PWR-100-LV-10to60°C EDS-G4014-6QGS-LV-T8429.6to60VDC PWR-100-LV-40to70°CEDS-G4014-6QGS-HV84288to300VDC,85to264VACPWR-105-HV-I-10to60°CEDS-G4014-6QGS-HV-T84288to300VDC,85to264VACPWR-105-HV-I-40to70°CAccessories(sold separately)SFP ModulesSFP-1GEZXLC SFP module with11000BaseEZX port with LC connector for110km transmission,0to60°C operatingtemperatureSFP-1GEZXLC-120SFP module with11000BaseEZX port with LC connector for120km transmission,0to60°C operatingtemperatureSFP-1GLHLC SFP module with11000BaseLH port with LC connector for30km transmission,0to60°C operatingtemperatureSFP-1GLHXLC SFP module with11000BaseLHX port with LC connector for40km transmission,0to60°C operatingtemperatureSFP-1GLSXLC SFP module with11000BaseLSX port with LC connector for1km/2km transmission,0to60°Coperating temperatureSFP-1GLXLC SFP module with11000BaseLX port with LC connector for10km transmission,0to60°C operatingtemperatureSFP-1GSXLC SFP module with11000BaseSX port with LC connector for300m/550m transmission,0to60°Coperating temperatureSFP-1GZXLC SFP module with11000BaseZX port with LC connector for80km transmission,0to60°C operatingtemperatureSFP-1GLHLC-T SFP module with11000BaseLH port with LC connector for30km transmission,-40to85°C operatingtemperatureSFP-1GLHXLC-T SFP module with11000BaseLHX port with LC connector for40km transmission,-40to85°Coperating temperatureSFP-1GLSXLC-T SFP module with11000BaseLSX port with LC connector for1km/2km transmission,-40to85°Coperating temperatureSFP-1GLXLC-T SFP module with11000BaseLX port with LC connector for10km transmission,-40to85°C operatingtemperatureSFP-1GSXLC-T SFP module with11000BaseSX port with LC connector for300m/550m transmission,-40to85°Coperating temperatureSFP-1GZXLC-T SFP module with11000BaseZX port with LC connector for80km transmission,-40to85°C operatingtemperatureSFP-1G10ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G10BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G20ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G20BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G40ALC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,0to60°C operating temperatureSFP-1G40BLC WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,0to60°C operating temperatureSFP-1G10ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G10BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for10km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G20ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G20BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for20km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1G40ALC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1310nm,RX1550nm,-40to85°C operating temperatureSFP-1G40BLC-T WDM-type(BiDi)SFP module with11000BaseSFP port with LC connector for40km transmission;TX1550nm,RX1310nm,-40to85°C operating temperatureSFP-1FELLC-T SFP module with1100Base single-mode with LC connector for80km transmission,-40to85°Coperating temperatureSFP-1FEMLC-T SFP module with1100Base multi-mode,LC connector for2/4km transmission,-40to85°C operatingtemperatureSFP-1FESLC-T SFP module with1100Base single-mode with LC connector for40km transmission,-40to85°Coperating temperatureSFP-2.5GLSLC-T SFP module with12.5GBaseFX port with LC connector,single-mode,for20km transmission,-40to85°C operating temperatureSFP-2.5GSLHLC-T SFP module with12.5GBaseFX port with LC connector,single-mode,for45km transmission,-40to85°C operating temperatureSFP-2.5GMLC-T SFP module with12.5GBaseFX port with LC connector,multi-mode,for170,200,550,600mtransmission,-40to85°C operating temperatureSFP-2.5GSLC-T SFP module with12.5GBaseFX port with LC connector,single-mode,for5km transmission,-40to85°C operating temperaturePower SuppliesHDR-60-2460W/2.5A DIN-rail24VDC power supply,universal85to264VAC or120to370VDC input voltage,-30to70°C operating temperatureNDR-120-24120W/5.0A DIN-rail24VDC power supply,universal90to264VAC or127to370VDC input voltage,-20to70°C operating temperatureNDR-120-48120W/2.5A DIN-rail48VDC power supply,universal90to264VAC or127to370VDC input voltage,-20to70°C operating temperatureNDR-240-48240W/5.0A DIN-rail48VDC power supply,universal90to264VAC or127to370VDC input voltage,-20to70°C operating temperatureMDR-40-24DIN-rail24VDC power supply with40W/1.7A,85to264VAC,or120to370VDC input,-20to70°Coperating temperatureMDR-60-24DIN-rail24VDC power supply with60W/2.5A,85to264VAC,or120to370VDC input,-20to70°Coperating temperature©Moxa Inc.All rights reserved.Updated Jun02,2022.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。
技术文件技术文件名称：PDC401NRV0R技术文件编号：JS00429A版本：A/0共 13 页(包括封面)拟制审核标准化批准南京丙鼎电子有限公司1.显示指标22.极限参数23.直流特性24.光电特性35.管脚连接36.编码表37.外观要求38.质量保证99.LCD模块使用注意事项111.显示指标显示像素：4个七段8字+4个圆点+1个冒号可视区域：36.8（W）×16.3（H）毫米外型尺寸：最大60（W）×35.5（H）×10（T）毫米LCD类型：TN显示模式：反射式、正显示视角：6：00点钟控制/驱动芯片：KS0065温度范围：工作-30℃~+70℃存储- 40℃~+75℃模块工作电压：5V.背光源工作电压：5V2.极限参数2.1电压及温度极限参数注意（1）T a= 0°C ：最大50Hr（2）T a≤40°C ：最大90%RHT a≥40°C ：绝对湿度必须低于40°C、90%RH下的湿度。
3.直流特性4.光电特性4.1 TN屏体光电特性5.管脚连接6.编码表7.外观要求7.1检查项目7.2 判定标准8.质量保证8.1 测试条件8.1.1 温度和湿度(环境温度)温度:20±5℃湿度:65±5％RH8.1.2 测试频率单循环注意1：常温下恢复4小时注意2：观察时无露水凝结注意3：各项试验后，在规定测试条件下模块能正常工作。
8.1.4 试验条件低温运行：-30℃持续时间：4h高温运行：+70℃持续时间：4h高温存贮：+75℃持续时间：4h恢复时间：2h低温存贮：-40℃持续时间：4h恢复时间：2h恒定湿热：+35℃湿度：93%+2%/-3%持续时间48h高低温冲击：跌落：整机做跌落试验，按照整机跌落试验的条件进行。
8.2 试验内容LCD测试：测试时，笔划有无多缺、颜色是否均匀、对比度是否良好。
环境测试：如果测试条件不允许，可以考虑将以下所有“箱内在线测试”改为“取出后立即测试”。
