UC-3100SeriesArm Cortex-A81GHz IIoT gateway with built-in LTE Cat.1and Wi-FimodulesFeatures and Benefits•Armv7Cortex-A81000MHz processor•Integrated Wi-Fi802.11a/b/g/n and LTE Cat.1for the US,EU,and APAC regions•Bluetooth4.2support•LTE-ready computer with Verizon/AT&T certification and industrial-grade CE/ FCC/UL certifications•Industrial CAN2.0A/B protocols supported•Robust root file system to prevent the system from being bricked due to a firmware update failure•-40to70°C operating temperature range•Meets the EN61000-6-2and EN61000-6-4standards for industrial EMC applications•Long-term Linux support until2027;includes bug fixes and security patchesCertificationsIntroductionMoxa’s UC-3100Series computers can be used as smart gateways in the field for data pre-processing and transmission,as well as for other embedded data-acquisition applications.The series includes9models,each supporting different wireless options and protocols.The UC-3100’s advanced heat dissipation design makes it suitable for use in temperatures ranging from-40to70°C.In fact,the Wi-Fi and LTE connections can be used simultaneously in both cold and hot environments,allowing you to maximize the data pre-processing and data transmission capabilities of your applications in most harsh environments.The UC-3100is more than just a hardware solution.In order to offer a better user experience with a Moxa Arm-based computer,the UC-3100 supports the following software features,allowing you to use the most suitable configuration for your application.•High VPN performance;more than70Mbps Ethernet throughput with AES-256encryption•Robust file system to prevent the system from being bricked due to a firmware upgrade failure•Real COM mode to provide a control interface to Moxa’s NPort productsIn addition,Moxa provides10years of Linux OS support.With a new version of the Debian repository released on an average every2to3years, you can create a reliable solution that will be supported now and long into the future.Applications•Remote Terminal Unit(RTU)•Data acquisition•M2M communication(smart gateway)•Digital signage•Factory automation•In-vehicle monitor/data logger(transportation)•Programmable router•Energy usage optimization•Predictive maintenance•Asset managementAppearance UC-3101UC-3111UC-3121SpecificationsComputerDRAM1GB DDR3Supported OS Linux Debian9kernel4.4(Moxa Industrial Linux)See /MILStorage Pre-installed8GB eMMCStorage Slot UC-3111/3121:SD slots x1Computer InterfaceTPM EU and AP models:TPM v2.0Ethernet Ports Auto-sensing10/100Mbps ports(RJ45connector)x2Serial Ports UC-3101/3121:RS-232/422/485ports x1,software-selectable(DB9)UC-3111:RS-232/422/485ports x2,software-selectable(DB9) USB2.0USB2.0hosts x1,type-A connectorsCellular Antenna Connector SMA x2SIM Format NanoNumber of SIMs2GPS Antenna Connector SMA x1Wi-Fi Antenna Connector RP-SMA x2for UC-3111/UC-3121onlyConsole Port RS-232(TxD,RxD,GND),4-pin header output(115200,n,8,1) Ethernet InterfaceMagnetic Isolation Protection 1.5kV(built-in)Cellular InterfaceBand Options US models:LTE Bands:Band2(1900MHz)/Band4(1700MHz)/Band5(850MHz)/Band12(700MHz)/Band13(700MHz)/Band14(700MHz)/Band66(1700MHz)/Band71(600MHz)UMTS Bands:2(1900MHz)/Band4(1700MHz)/Band5(850MHz)Carrier Approval:Verizon,AT&TEU models:LTE Bands:Band1(2100MHz)/Band3(1800MHz)/Band7(2600MHz)/Band8(900MHz)/Band20(800MHz)/Band28A(700MHz)UMTS Bands:Band1(2100MHz)/Band3(1800MHz)Band8(900MHz)AP models:LTE Bands:Band1(2100MHz)/3(1800MHz)/Band5(850MHz)/Band8(900MHz)/Band9(1700MHz)/Band18(850MHz)/Band19(850MHz)/Band28(700MHz)UMTS Bands:1(2100MHz)/Band5(850MHz)/Band6(800MHz)/Band8(900MHz)/Band19(800MHz)WLAN InterfaceWLAN Standards802.11a/b/g/n:UC-3111-T-LX and UC-3121-T-LX modelsBluetooth4.2compliance:UC-3111-T-LX and UC-3121-T-LX modelsFrequency Band 2.4GHz/5GHz:UC-3111-T-LX and UC-3121-T-LX modelsSerial InterfaceData Bits5,6,7,8Parity None,Even,Odd,Space,MarkStop Bits1,1.5,2Serial SignalsRS-232TxD,RxD,RTS,CTS,DTR,DSR,DCD,GNDRS-422Tx+,Tx-,Rx+,Rx-,GNDRS-485-2w Data+,Data-,GNDRS-485-4w Tx+,Tx-,Rx+,Rx-,GNDCAN InterfaceBaudrate UC-3121-T-US-LX:10to1000kbpsUC-3121-T-EU-LX:10to1000kbpsUC-3121-T-AP-LX:10to1000kbpsConnector UC-3121-T-US-LX:DB9maleUC-3121-T-EU-LX:DB9maleUC-3121-T-AP-LX:DB9maleIsolation UC-3121-T-US-LX:2kV(built-in)UC-3121-T-EU-LX:2kV(built-in)UC-3121-T-AP-LX:2kV(built-in)Signals UC-3121-T-US-LX:CAN_H,CAN_L,CAN_GND,CAN_SHLD,CAN_V+,GNDUC-3121-T-EU-LX:CAN_H,CAN_L,CAN_GND,CAN_SHLD,CAN_V+,GNDUC-3121-T-AP-LX:CAN_H,CAN_L,CAN_GND,CAN_SHLD,CAN_V+,GNDLED IndicatorsSystem Power x1CAN UC-3121-T-US-LX:1per port(Tx,Rx)UC-3121-T-EU-LX:1per port(Tx,Rx)UC-3121-T-AP-LX:1per port(Tx,Rx)Serial1per port(Tx,Rx)LAN1per port(10/100Mbps)Wireless Signal Strength UC-3101:3x cellularUC-3111/UC-3121:3x cellular and3x Wi-FiPower ParametersPower Consumption UC-3101:6W(max.)UC-3111/UC-3121:8W(max.)Input Current500mA@12VDCInput Voltage9to36VDCPhysical CharacteristicsHousing MetalInstallation DIN-rail mountingWall mounting(with optional kit)Dimensions(without ears)128.5x89.1x26mm(5.06x3.51x1.02in)for UC-3101128.5x89.1x41mm(5.06x3.51x1.61in)for UC-3111/UC-3121Weight Product only:550g(1.22lb)Environmental LimitsOperating Temperature-40to70°C(-40to158°F)Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Vibration5Grms@IEC60068-2-64,random wave,5-500Hz,1hr per axis(without USB devicesattached)Shock IEC60068-2-27Standards and CertificationsEMC EN61000-6-2/-6-4EN55032/24EMI CISPR22,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:4kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:10V/mIEC61000-4-4EFT:Power:2kV;Signal:1kVIEC61000-4-5Surge:Power:0.5kV;Signal:1kVIEC61000-4-6CS:10VIEC61000-4-8PFMFCarrier Approvals VerizonAT&TCellular Standards EN301511EN301908-1EN62311(MPE SAR)EN301489-1/-52EN301489-1/17Radio Frequency FCCPTCRBRCMSafety IEC60950-1IEC62368-1UL62368-1UL60950-1WLAN Standards EN301489-1-17EN300328EN301893Green Product RoHS,CRoHS,WEEEHazardous Locations Class I Division2IECExATEXMTBFStandards Telcordia(Bellcore)StandardTime UC-3101-T-US-LX:702,846hrsUC-3101-T-EU-LX:585,775hrsUC-3101-T-AP-LX:585,775hrsUC-3111-T-US-LX:465,569hrsUC-3111-T-EU-LX:416,081hrsUC-3111-T-AP-LX:416,081hrsUC-3121-T-US-LX:474,796hrsUC-3121-T-EU-LX:428,931hrsUC-3121-T-AP-LX:428,931hrs WarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x UC-3100Series computerCable1x terminal block to power jack converter Documentation1x quick installation guide1x warranty cardDimensions UC-3101UC-3111UC-3121Ordering InformationModel NameCarrierApprovalCPU SD Slot RAM eMMC Serial TPM2.0CAN LTE Wi-Fi BLTUC-3101-T-US-LXAT&T,Verizon1GHz–1GB8GB1––Cat.1––UC-3111-T-US-LXAT&T,Verizon1GHz11GB8GB2––Cat.1✓✓UC-3121-T-US-LXAT&T,Verizon1GHz11GB8GB1–1Cat.1✓✓UC-3101-T-EU-LX–1GHz–1GB8GB1✓–Cat.1––UC-3111-T-EU-LX–1GHz11GB8GB2✓–Cat.1✓✓UC-3121-T-EU-LX–1GHz11GB8GB1✓1Cat.1✓✓UC-3101-T-AP-LX–1GHz–1GB8GB1✓–Cat.1––UC-3111-T-AP-LX–1GHz11GB8GB2✓–Cat.1✓✓UC-3121-T-AP-LX–1GHz11GB8GB1✓1Cat.1✓✓Accessories(sold separately)Power AdaptersPWR-12150-CN-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,China(CN)plug,-40to75°C operatingtemperaturePWR-12150-EU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,Continental Europe(EU)plug,-40to75°Coperating temperaturePWR-12150-UK-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,United Kingdom(UK)plug,-40to75°C operatingtemperaturePWR-12150-AU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,Australia(AU)plug,-40to75°C operatingtemperaturePWR-12150-USJP-SA-T Locking barrel plug,12VDC1.5A,100to240VAC,United States/Japan(US/JP)plug,-40to75°Coperating temperatureCablesCBL-F9DPF1x4-BK-100Console cable with4-pin connector,1mDIN-Rail Mounting KitsUC-3100DIN-Rail Kit DIN-rail kit with screwsWall-Mounting KitsUC-3100Wall-Mounting Kit Wall-mounting kit with screwsAntennasANT-LTE-ASM-02GPRS/EDGE/UMTS/HSPA/LTE,omni-directional rubber duck antenna,2dBiANT-WDB-ARM-02 2.4/5GHz,omni-directional rubber duck antenna,2dBi,RP-SMA(male)ANT-LTEUS-ASM-01GSM/GPRS/EDGE/UMTS/HSPA/LTE,omni-directional rubber duck antenna,1dBiUC-3100Antenna Set4dBi at1575MHz to1610MHz,SMA(male),active GPS/GLONASS,adhesive-type antenna with20-cm cable;2x4dBi at2.4GHz or5dBi at5GHz,RP-SMA(female),omnidirectional antennas;2x1.5dBi698to960MHz or1710to2700MHz,SMA(male),LTE,swivel-type omnidirectional portableantennas©Moxa Inc.All rights reserved.Updated Jun29,2021.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。
