ONE SOURCE. INFINITE SOLUTIONS.®Maxima C Plus™Vacuum Pumps for:Vacuum Ovens, Glove Boxes, Freeze Dryers,Centrifugal Concentrators, Annular Spaces/Transfer Lines2Design FeaturesPTFE Coated Oil Case Prevents particles and sludge from clinging to the walls of the oil case to simplify oil change.Oil Mist EliminatorTrapped oils naturally fall back into theoil case via gravity after pump down.Hose Barb Allowing two sizes of I.D. hose to connect to your system per pump.Funnel Provided to allow quick oil adds.Intake Antisuckback Valve To prevent oil back flow on power shut down or power failure.Hose Clamp Holds hose tight to hose rge Site Glass Easily assures proper oil level.3Find the correct vacuum pump/system to address your application needs. The Fisher Scientific product line offers a wide range ofvacuum pumps – each expertly designed for optimum function in your application.Dry Ice/Liquid Nitrogen Trap fast freezing to condense vapors. Also prevents oil backstreaming. duce at a temperature of (-79° C) or liquid nitrogen (-198°) may be used as refrigerant. Accepts adapters, and clamps for vacuum- tight connection to Fisher Scientific Isotemp™* vacuum ovens, models Catalog No.4Replacement Parts and ServiceAvailable are minor repair kits and gasket and seal kits for each pump model. For a complete listing, pricing and availability of service parts, call FisherScientific Services Division at 1-800-395-5442. We also offer service after the sale. Several types of service agreements are available to cover your Maxima C Plus pump. For information and pricing, call Fisher Scientific Services Division at 1-800-395-5442.BN1217025Application Note for Filtration, Aspiration and Drying Electrophoresis GelsFisher Scientific Models M2C, M4C, M6C, M8C, M12C and M16C high vacuum pumps are not recommended for filtration, aspiration or drying electrophoresis gels. The reason is these drying process occur in the rough vacuum level (above 30 Torr (40 mbar)) and these vane pumps are not designed for high pressure operation.Set-ups for Lab ApplicationsProper vacuum system set-up in lab applications does reduce pump maintenance which lowers cost and increases user productivity. Proper vacuum system set-ups consist of the lab appliance, tubing, vacuum pump, and normally cold or liquid trap. Failure to use or maintain the appropriate trap will result in a shortened service life of the pump.1Maxima and Isotemp™ are registered trademarks of Fisher Scientific.。

专利名称：VACUUM PUMP WITH DETOXIFICATION FUNCTION发明人：FURUTA TAKUMI,古田 拓己,IWASAKI KOICHI,岩崎 弘一,ISHIKAWA KEIICHI,石川 敬一,KOMAITETSUO,駒井 哲夫,SEKIGUCHI SHINICHI,関口信一申请号：JP2014256365申请日：20141218公开号：JP2015195344A公开日：20151105专利内容由知识产权出版社提供专利附图：摘要：PROBLEM TO BE SOLVED: To provide a vacuum pump with a detoxification function capable of preventing contamination of a process chamber by preventing backflow of a product that is precipitated as a result of exhaust gas processing, reducing the quantity of processing gas by preventing purge gas or dilution gas from being contained in exhaust gas, and attaining energy saving by reducing energy required for gas processing in a detoxification section.SOLUTION: In the vacuum pump, a detoxification section for processing exhaust gas is additionally provided. The vacuum pump includes a dry vacuum pump including a main pump 1 capable of performing exhaustion from an atmospheric pressure, and a booster pump 2 that accelerates an exhaustion speed of the main pump 1. At least one detoxification section 3 for processing exhaust gas is connected between the main pump 1 and the booster pump 2.申请人：EBARA CORP,株式会社荏原製作所地址：東京都大田区羽田旭町１１番１号国籍：JP代理人：渡邉 勇,廣澤 哲也更多信息请下载全文后查看。

专利名称：Vacuum pump发明人：Yasushi Maejima,Yoshiyuki Sakaguchi申请号：US10187573申请日：20020703公开号：US20030021673A1公开日：20030130专利内容由知识产权出版社提供专利附图：摘要：To provide a vacuum pump used for semiconductor manufacturing, which has improved reliability and safety and in which damages to a pump casing, peripheralapparatuses, or the like are prevented from occurring by preventing the occurrence of rotor breakage due to corrosion. A balancer is provided in the outer circumferentialsurface of the rotor so as to face the inside of the gas passageway. A balancer main body is supported against the outer circumferential surface of a rotor through a fragile portion that is weak with respect to corrosive gasses, the fragile portion of the balancer is damaged by corrosion before any corrosive gas influence appears in rotor blades or the rotor, and the balancer falls off, thus forcibly causing an unbalanced state to appear in the rotor. The balancer thus possesses a function for balancing the rotor and a corrosion detecting function. The unbalanced state of the rotor is then detected by a sensor, and damages to the vacuum pump itself and to the peripheral apparatuses can be prevented by stopping the pump.申请人：MAEJIMA YASUSHI,SAKAGUCHI YOSHIYUKI更多信息请下载全文后查看。

专利名称：Vacuum pump发明人：眞鍋 雅嗣,斎藤 英文申请号：JP2018113743申请日：20180614公开号：JP2019214992A公开日：20191219专利内容由知识产权出版社提供专利附图：摘要：An object of the present invention is to provide a vacuum pump capable of stably supplying an appropriate amount of lubricating fluid to a rolling bearing thatrotates at high speed in a vacuum environment. The vacuum pump includes a bearing for supporting a shaft provided with a pump rotor, a lubricating fluid storing portion forstoring a lubricating fluid supplied to the bearing, and lubrication of the lubricating fluid storing portion. A MEMS element 40 in which a minute flow pump 401 for transferring a fluid to the bearing 8 is formed, and a suction tube 61 which is a flow passage having a capillary structure for moving the lubricating fluid in the lubricating fluid storage unit 60 to the minute flow pump 401 by capillary force. , Is provided. [Selection] Figure 2申请人：株式会社島津製作所地址：京都府京都市中京区西ノ京桑原町１番地国籍：JP代理人：永井 冬紀更多信息请下载全文后查看。

专利名称：VACUUM PUMP发明人：OSAKABE ICHIRO,NAGAOKATAKASHI,TANIYAMA MINORU,MASEMASAHIRO,NISHIUCHI AKIRA申请号：JP22818086申请日：19860929公开号：JPS6385291A公开日：19880415专利内容由知识产权出版社提供摘要：PURPOSE:To obtain a small-sized vacuum pump which operates from the atmospheric pressure to a high vacuum by installing at least a siegbahn pump stage on a suction port side and arranging a circumferential flow compression pump stage on an exhaust port side. CONSTITUTION:A rotary shaft 1 penetrates through a housing 2 having a suction port 2A and an exhaust port 2B and is supported by a bearing 7. In this case, an axial flow compression pump stage 15 and a siegbahn pump stage 14 are arranged in connection in the suction port 2A, and a circumferential compression pump stage 13 is connected in succession in the exhaust port 2B. The pump stage 15 is constituted of an axial flow vane wheel 15A and a fixed blade 15B, and the pump stage 14 is constituted of fixed plates 14A and rotary discs 14B. Further the pump stage 13 is constituted of the vane wheels 13A having vanes 13C radially installed and fixed plates 13B. Therefore, in the transient state in the initial stage of the pump operation, each pump stage 14, 15 is allowed to act as compressor, and in the stationary state, sealing action is secured by the pump stages 15 and 14.申请人：HITACHI LTD更多信息请下载全文后查看。

专利名称：VACUUM PUMP发明人：OSAKABE ICHIRO,NAGAOKATAKASHI,TANIYAMA MINORU,MASEMASAHIRO,TSURU SEIJI申请号：JP22817986申请日：19860929公开号：JPS6385290A公开日：19880415专利内容由知识产权出版社提供摘要：PURPOSE:To effectively operate a vacuum pump in a wide pressure range by installing a siegbahn pump stage as the pump stage in the molecular flow or intermediate flow range and arranging a centrifugal compression pump stage and a circumferential flow compression pump stage, onto the slip stream side of the Siegbahn pump stage. CONSTITUTION:A rotary shaft 1 is rotatably supported by a bearing 7 in a housing 2 having a suction port 2A And an exhaust port 2B. In this case, in the housing 2, the following pump stages are arranged in succession from the suction port 2A side. In other words, an axial flow turbomolecular pump stage 3 in which axial flow vane wheels 3A And fixed vanes 3B are arranged alternately, siegbahn pump stage in which rotary discs 9A and fixed discs 9B are arranged alternately, centrifugal compression pump stage 5 in which centrifugal vane wheels 5A and fixed discs 5B are arranged alternately, and a circumferential flow compression pump stage 10 in which circumferential flow vane wheels 10A and fixed discs 10B are arranged alternately are arranged in connection. Therefore, the deterioration of the faculty of the vacuum pump due to the increase of the pressure at the suction port 2A can be suppressed.申请人：HITACHI LTD 更多信息请下载全文后查看。

专利名称：VACUUM PUMP发明人：SAKAGAMI SEIJI,MASEMASAHIRO,NAGAOKA TAKASHI,NISHIUCHIAKIRA,YANO ISAO申请号：JP32400687申请日：19871223公开号：JPH01167497A公开日：19890703专利内容由知识产权出版社提供摘要：PURPOSE:To prevent reaction product from sticking to a wall surface of an exhaust passage by providing a hollow type heat pipe leading heat generated inside of a pump to the spot in an exhaust port of a vacuum pump. CONSTITUTION:A hollow type heat pipe 17 is inserted into an exhaust port 11B, and gas sucked into from a suction port 11A is compressed in order and flows through hollow portion of the heat pipe 17 and is exhausted from the exhaust port 11B. As the heat pipe 17 gets to high temperature through conveying heat generated in circular flow compression pump stages 15, high temperature gas from the circular flow pump stages 15 is exhausted to the exhaust port 11B without cooled. Therefore, blockade due to reaction product, for hollow portion of the heat pipe 17, that is, for exhaust passage doesn't generate.申请人：HITACHI LTD更多信息请下载全文后查看。

专利名称：VACUUM PUMP发明人：KAISER, Alexander,KAISER, Alexander 申请号：EP2017/072519申请日：20170907公开号：WO2018/050545A1公开日：20180322专利内容由知识产权出版社提供专利附图：摘要：The invention relates to an oil-sealed vacuum pump such as a rotary vane pump having at least one pump rotor (12) in a housing (10). Furthermore, an oil reservoir (36) for supplying oil is provided. This serves for sealing the vane (18) for lubrication of bearings and/or for cooling the pump. Furthermore, a heating device is provided. Theheating device has a main heating element (44) and an additional heating element (46), wherein the additional heating element (46) is connected to a temperature switch (48). By corresponding switching of the two heating elements (44, 46), a rapid and energy-saving heating of the vacuum pump to the operating temperature and maintaining the temperature between operating cycles can occur. In this case, the additional heating element (46) is in particular only used for heating to the operating temperature.申请人：LEYBOLD GMBH,LEYBOLD GMBH地址：50968 DE国籍：DE代理人：VON KIRCHBAUM, Alexander更多信息请下载全文后查看。

专利名称：VACUUM PUMP发明人：GIEBMANNS, Wolfgang 申请号：EP2007059521申请日：20070911公开号：WO08/031819P1公开日：20080320专利内容由知识产权出版社提供摘要：The invention relates to a fast rotating vacuum pump for generating a high vacuum. Fast rotating vacuum pumps could be combined together with fast rotating high vacuum pumps, for example turbomolecular pumps, to form single shaft vacuum pumps which can compress from high vacuum or ultra high vacuum to atmospheric pressure. For this purpose, the inventive vacuum pump (10) has a suction stage (12) and a centripetal compressor stage (21) placed thereafter in line, with radially extending compression chambers (33), the outlet cross section of which is smaller than 0.4 times the cross section of the inlet. The centripetal compressor is not a displacement machine and can therefore be operated at high rotational speeds and can compress gases from pre-vacuum pressures to atmospheric pressure at high rotational speeds. This creates the possibility of generating a high vacuum or ultra high vacuum with only one single shaft fast rotating vacuum pump.申请人：GIEBMANNS, Wolfgang地址：DE,DE国籍：DE,DE代理机构：EBERLEIN, Jasper更多信息请下载全文后查看。
